1.a - Working principle P 1
9.a - Humidity and temperature offset adjustment (THA 300) ............................P 20
Summary
CPA 300 & THA 300 transmitters configuration via remote control / Modbus

Sommaire
10.c - Air velocity correction coefficient input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P 23
11. Configuration de la mesure en débit • F600 ...................................P 24
12. Other functions................................................................................P 27
12.a - Activation / Deactivation of the RS 232 and home bus ............................P 27
12.b - Serial number display ................................................................P 27
12.c - Modification of Modbus commonication speed .....................................P 28
12.d - Mode Purge ...........................................................................P 29
13. Error codes .....................................................................................P 32
14. Functions recap...............................................................................P 33
CPA 300 & THA 300 transmitters configuration via remote control / Modbus

Page 1
CPA
Voie 1 Voie 2 Voie 3
Using remote control / Modbus configuration, you can activate (or deactivate) a channel, change the measuring
range, set the set points and time-delay...
Principle: the configuration options are accessed via folders and sub-folders (similar to Windows ).Access is
made via a numerical code (full details in this manual).
®
Visual LED
Value Graphic display
Units Graphic display
1.a.1 - Infrared remote control
Meaning of the remote control keys
To increment a value or a level
To decrement a value or a level
To validate an input
To cancel an input or to return to the previous step
Channel selector
With this selector, you can swap the transmission channel so that it
matchs with the transmitter reception channel. See page 6 to configure
the transmitter reception channel.
1. Prerequesite
1.a - Working principle
CPA 300 & THA 300 transmitters configuration via remote control / Modbus

1. Prerequisite
The Class 300 can output either a voltage or a current signal.
Voltage or Current ?
1.b - Output signal selection
Page 2 CPA 300 & THA 300 transmitters configuration via remote control / Modbus
Transmitter with
24 Vac/dc
power supply
Transmitter with
230 Vac
power supply
(Ref. HV).
The on-off switch is located on the left of the terminal block for
transmitters with a 24 Vac/dc power supply model and on the right
of the relay 1 and 2 for transmitters with a 230 Vac power supply
model (Ref.HV). With the on-off switch you can choose analogue
output 0-10V (voltage) or 4-20 mA (current).
Down
0-10 V
Up
4-20 mA 230 Vac power supply model (Ref. HV)
24 Vac/dc power supply model
It's extremely unwise to remove the protection tip of our hygrometry
probes as the sensitive element is very fragile even to light contacts.
However, if you have to remove the protection tip, take all possible
precautions and avoid any contact with the sensitive element.
To remove the protection tip, unscrew it or unclip it.
1.c - Protection tip of the sensor
Protection tip
to unscrew
!
Protection tip
to unscrew
Sensitive
element
Sensitive
element

• Values formatting - Modbus code :
1444 (channel 2)
1448 (channel 3 or value 1 of the external transmitter)
1452 (channel 4 or value 2 of the external transmitter)
1440 (channel 1)
2. Modbus parameters
2.a - Configuration parameters
• commonication speed .....................19200 Bauds (see page 28 to configure the speed)
• Data bits.................................8 bits
• Stop bit..................................1 bit
• Parity....................................None
• Flow control.............................None
• Transmitter addressing.................between 1 and 255
default address “0” for single ended bus configuration
(see page 6)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . to change the addressing,see page 8.
2.b - Functions
• Register reading ...................................Function 03
• Register writing...............................Function 16
• commonication loop test .....................Function 08
2.c - Access codes to Registers
• Registers type .....................................Signed long integer (32 bits), permuted (LSB, MSB)
• Alarms status - Modbus code : 1436
For 24 Vac/dc power supply model
Relay 3
Relay 4
0 1 0 1
Ex. The value sent by the transmitter is 5
Alarm condition 1
and relay 1 excited
• Values - Modbus code : 1438 (channel 1)
1442 (channel 2)
1446 (channel 3 or value 1 of the external transmitter)
1450 (channel 4 or value 2 of the external transmitter)
Ex. the value sent by the transmitter is 6321
... b4 b3 b2 b1 b0
b31
b31 ... b12 b11 b10 b9 b8 b7 b5 b4 b3 b2 b1 b0 b6
0 0 0 1 0 0 0 0 1 1 0 0
Unit of measurement (see chart)
Nr of digits after the comma
Value sign (0=>+, 1=> -)
Ex. The formatting displayed is 268.
Unit of measurement => 12 (see chart)
Figure(s) after the comma => 1
Sign => positive
If the value measured is equal to 6231 :
Result => 623,1 mmH O
2
Relay 1
Relay 2
1m/s 12 mmH O
2
2fpm 13 inWg
3m3/h 14 Kpa
4L/s 15 mmHg
5cfm 16 mbar
6m3/s 17 g/kg (absolute humidity.
7°C 18 °C (dew temp. Td)
8°F 19 °F (dew temp. Td)
9%RH 20 °C (wet temp. Tw)
10 PSI 21 °F (wet temp. Tw)
11 Pa 22 KJ/Kg (Enthalpy i)
ñ)
Units of measurement
Page 3
CPA 300 & THA 300 transmitters configuration via remote control / Modbus
0 1
... b4 b3 b2 b1 b0
b31
Relay 1
Relay 2
For ower supply model
(Ref. HV)
230 Vac p

2. Modbus parameters
2.c - Access code to Registers (sequel)
• Serial number of sensing element (SPI - CPA 300 / Humidity - THA 300)
Modbus code : 1402
Other access codes to different registers are indicated on each function at stage n°2.
Shown as this pictogram :
d
b
u
o
s
M
202
Page 4 CPA 300 & THA 300 transmitters configuration via remote control / Modbus

3. Activation code and access to functions
!
This step is COMPULSORY for each configuration.
To access the transmitter functions, and for safety, you have to first enter a safety code.
• Please check that the transmitter is powered on.
• If the transmitter displays an error code, please see “Errors Code” section on page 31
Step 1
Press on
to get this screen
Enter the CODE “0101”
with the keypad and
validate with
Step 2 The code must be entered from left to right.
To increment a value or a level, press
To decrement a value or a level, press
To validate a value (level) or to validate the code, press
To return to the previous status or to cancel, press
The first “0” blinks, which means that this column is activated and you can
enter data from the keypad.
This screen appears:
Step 3
This screen confirms that the code was correctly entered, and that you can
configure the transmitter.
If the code was wrongly entered, the transmitter initializes and returns to the
starting display.
Configuration folder number
The transmitter includes 6 folders maximum :
• 100 • 400
• 200 • 500
• 300 • 600
Configuration folder
selection
Step 4 To select your configuration folder, press to increment 100 or press to
decrement 100.
Once the folder is selected, press to validate.
L
On the top left of each page of this manual, you can find a reminder of the
configuration folder where the function is available.
F400
Ex. In the folder 400, you can configure the alarms
and relays. See page 12.
Page 5
CPA 300 & THA 300 transmitters configuration via remote control / Modbus

1
Etape
Etape
d
b
u
o
s
M
200
d
b
u
o
s
M
206
4. Display and keypad configuration
F100
4.a - Transmitter channel for infrared remote control
You can change the channel number for receiving the signal from the infrared remote control.
The advantage is that only one remote control is required to drive several transmitters, and that
there is no interference if 2 transmitters are located side by side.
Step Go into the configuration mode (see page 5). The folder number displayed
corresponds to the last configuration folder used.
Select the folder “100” and validate with .
2
Step
Select the sub-folder “100” and validate with .
The cursor >goes to the line of available choices.
3
Step With and keys, select the channel number (from 00 to 09).
Validate with .
4
Step The cursor >returns to sub-folders line.
• press twice to return to reading mode
• press once to select another folder.
• with and keys, you can choose another sub-folder from the folder 100.
d
b
u
o
s
M
200
By default, the channel number is 0.
4.b - Slave addressing (Modbus)
Go into configuration mode (see page 5). The folder number displayed
corresponds to the last configuration folder used.
Select the folder “100” and validate with .
Select the sub-folder “103” and validate with .
The cursor >goes to available choices.
With and keys, set the slave addressing number (from 1 to255).
Validate with .
The cursor >goes to sub-folders line.
• press twice to return to reading mode.
• press once to return to another folder selection.
• with and keys to choose another sub-folder from the folder 100.
1
Step
2
Step
3
Step
4
Step
Page 6 CPA 300 & THA 300 transmitters configuration via remote control / Modbus

1
Step
2
Step
3
Step
4
Step
5. Configuring channels and units of measurement
F200
Class 300 transmitters have 4 measuring channels. You can activate 1, 2, 3 or 4 channels and select each unit of
measurement.
Go into configuration mode (see page 5). The folder number displayed
corresponds to the last configuration folder used.
Select the folder “200” and validate with .
Channel 1 Channel 2 Channel 3 Channel 4
Select sub-folder 200 201 202 203
With and keys, select the unit of measurement (see chart below).
Validate with .
The cursor >returns to sub-folders line.
• press twice to return to reading mode.
• press once to return to another folder selection.
• with and keys to choose another sub-folder from the folder 200.
and validate with . The
cursor >goes to choices ligne.
For a CPA 300 transmitter (301, 302, 303 and 304 or 301HV, 302HV, 303HV et 304HV), the SQR
option is required in order to activate the units of air velocity and airflow.
d
b
u
o
s
M
400
d
b
u
o
s
M
d
b
u
o
s
M
d
b
u
o
s
M
402 404 406
Page 7
CPA 300 & THA 300 transmitters configuration via remote control / Modbus
CPA301, 302 et 303 CPA304 THA300
CPA301HV, 302HV et 303HV CPA304HV THA300HV
Inactive channel
Pa Pa °C
mmH O mmH O °F
2
inWg inWg %HR
mbar mbar g/Kg (Hygro. absolue
m/s mmHg °C (Temp. de rosée Td)
fpm m/s °F (Temp. de rosée Td)
m³/h fpm °C (Temp. humide Tw)
L/s m³/h °F (Temp. humide Tw)
cfm L/s KJ/Kg (Enthalpie i)
m³/s cfm
m³/s
Inactive channel Inactive channel
2
ñ)

6. Analogue output management
F300
6.a - Output diagnostics
With this function, you can check with a multimeter (or a regulator/display, or a PLC/BMS) if the transmitter
outputs are working properly. The transmitter generates a voltage of 0 V, 5 V and 10 V or a current of 4 mA, 12 mA
and 20 mA.
6.a.1 - Multimeter connection configuration
Before carrying out the output diagnostics, all connections and configurations of the transmitter must be
enabled, to avoid any damage on the transmitter and the multimeter !
1
Step First, select a channel for the output diagnostics.
Selection of the channel
to be checked
2
Step Example of
connection
Page 8 CPA 300 & THA 300 transmitters configuration via remote control / Modbus
The Channel numbers are
indicated on the board located
below the terminal block.
Channel n°1 Channel n°2
On the opposite pictures, multimeters are
plugged on the 0-10V output of the channel 1.
NO........normally opened
COM.....common
NC ........normally closed
Relay 3
NO........normally opened
COM.....common
NC ........normally closed
Relay 4
B
-
A
+
0-10 V ..............voltage
GND .................ground
4-20 mA ...........current
Analogue output 1
0-10 V ..............voltage
GND .................ground
4-20 mA ...........current
Analogue output 2
24 Vac/dc
NO........normally open
COM.....common
NC ........normally closed
Relay 1
NO........normally open
COM.....common
NC ........normally closed
Relay 2
Transmitter with
24 Vac/dc power supply
Transmitter with
230 Vac power supply
(Ref. HV)
Transmitter with
230 Vac power supply (Ref. HV)
Transmitter with
24 Vac/dc power supply
230 Vac
Relays 3 and 4,
available only on 24 Vac
power supply models.

6.a.2 - Output diagnostics
Once the connection of the transmitter to the multimeter (or regulator or PLC/BMS is complete, see page 6),
you can carry out the analogue output diagnostics on several check points.
6. Analogue output management
Go into configuration mode (see page 5). The folder number displayed
corresponds to the last configuration folder used.
Select the folder “300” and validate with .
Channel n° 1 output
Select sub-folder “300”
and validate with . The cursor >goes to available choices.
Channel n° 2 output
Select sub-folder “303”
Diagnostic Output
00 0 V
01 5 V
02 10 V
03 4 mA
04 12 mA
05 20 mA
F300
With and keys, select the signal that the transmitter must output (see
chart below). Note : no need to validate with .
1
Step
2
Step
3
Step
!
If the deviations are too big (>0,05 V or >0,05 mA) between the signal issued and
the value displayed on the multimeter, we recommend that you return the
transmitter to our factory.
The cursor >returns to sub-folders line.
• press twice to return to reading mode.
• press once to return to another folder selection.
• with and keys to choose another sub-folder from the folder 300.
4
Step
d
b
u
o
s
M
d
b
u
o
s
M
600 606
Page 9
CPA 300 & THA 300 transmitters configuration via remote control / Modbus

6. Analogue output management
F300
6.b - Analogue output settings
With this function, you can modify the measuring range of the transmitter, and you can equate the new limits to the
analogue output (0-10 V or 4-20 mA).
You can enter the measuring range required on your own !
Go into configuration mode (see page 5). The folder number displayed
corresponds to the last configuration folder used.
Select the folder “300” and validate with .
Minimum of Channel n°1
output
Select sub-folder “301”
With and keys, select the value sign : negative or positive, validate
with . Then, enter the minimum limit value and validate with .
and validate with . The cursor >returns to the input line.
Minimum of Channel n°2
output
Select sub-folder “304”
Maximum of Channel n°1
output
Select sub-folder “302”
Etape
With and keys, select the value sign : negative or positive, validate
with .
Then, enter the maximum limit value and validate with .
and validate with . The cursor >goes to the input line.
Maximum of Channel n°2
output
Select sub-folder “305”
!
You must enter the values according to the units of measurement selected, not
according to the measuring range of the transmitter.
Eg. on a CPA 303 pressure transmitter (0 to ±1000 Pa) with a reading in mmH O, the minimum and maximum ranges must
2
be configured on measuring range of 0 to ±102 mmH O. See conversion chart on following page.
2
6
Step The cursor >goes to sub-folders line.
• press twice to return to reading mode.
• press once to return to another folder selection.
• with and keys you can choose another sub-folder from the folder 300.
After an analogue output setting, if the unit of measurement is modified (see page 5), you have to reconfigure
the outputs according to the new unit of measurement.
!
We recommend that the interval between the minimum and maximum is > 5% of the measuring range.
1
Step
2
Step
3
Step
4
Step
5
Step
d
b
u
o
s
M
602
d
b
u
o
s
M
608
d
b
u
o
s
M
604
d
b
u
o
s
M
610
Page 10 CPA 300 & THA 300 transmitters configuration via remote control / Modbus

6.b.1 - Units of measurement conversion chart
6. Analogue output management
F300
Page 11
CPA 300 & THA 300 transmitters configuration via remote control / Modbus
°C °F
THA 300 - St.steel probe -40,0 à +180,0 -40,0 à +356,0
THA 300 - Probe PC -20,0 à +80,0 -4,0 à +176,0
Temperature
Pa mmH2O inWg mbar mmHg
CPA 301 0 à ±100 0 à ±10,2 0 à ±0,401 0 à ±1,00 -
CPA 302 0 à ±500 0 à ±51,0 0 à ±2,005 0 à ±5,00 -
CPA 303 0 à ±1000 0 à ±102,0 0 à ±4,015 0 à ±10,00 -
CPA 304 0 à ±10000 0 à ±1020,0 0 à ±40,01 0 à ±100,00 0 à ±75,00
°C °F
THA 300HV - St.steel probe -40,0 à +180,0 -40,0 à +356,0
THA 300HV - Probe PC -20,0 à +80,0 -4,0 à +176,0
Temperature
Pressure
Pa mmH2O inWg mbar mmHg
CPA 301HV 0 à ±100 0 à ±10,2 0 à ±0,401 0 à ±1,00 -
CPA 302HV 0 à ±500 0 à ±51,0 0 à ±2,005 0 à ±5,00 -
CPA 303HV 0 à ±1000 0 à ±102,0 0 à ±4,015 0 à ±10,00 -
CPA 304HV 0 à ±10000 0 à ±1020,0 0 à ±40,01 0 à ±100,00 0 à ±75,00
Pressure

7. Alarm / relay settings
F400
7.a - Activation / Deactivation of BEEP alarm
Go into configuration mode (see page 5). The folder number displayed
corresponds to the last configuration folder used.
Select the folder “400” and validate with .
Select sub-folder “400” and validate with .
The cursor >goes to available choices.
With and keys, select 01 to activate the BEEP alarm or 00 to
deactivate. Validate with .
The cursor >goes to sub-folders line.
• press twice to return to reading mode.
• press once to return to another folder selection.
• with and keys you can choose another sub-folder from the folder 400.
7.b - Relay security
Enter in configuration mode (see page 5). The folder number
displayed corresponds to the last configuration folder used.
Select folder “400” and validate with .
Select sub-folder “401” and validate with .
The cursor >goes to available choices.
With the keys and , select 01 for a positive security or 00 for a
negative security. Validate with .
The cursor >returns to sub-folders line.
• press twice on to return to reading mode.
• press once on to return to another folder selection.
• with and keys, you can choose another sub-folder from the folder 400.
The relay outputs are by default, in negative security: the relay is energized when a set point is reached.
With the keypad, you can swap the relays in positive security : then, the relay is de-energized when a set point is
reached or during a power outage.
The beep alarm (audible alarm) is activated when a set point is reached.
For more details on the setpoint settings, see page 20.
1
Step
2
Step
3
Step
4
Step
1
Step
2
Step
3
Step
4
Step
d
b
u
o
s
M
800
d
b
u
o
s
M
802
Page 12 CPA 300 & THA 300 transmitters configuration via remote control / Modbus

7. Alarm / relay settings
F400
7.c - Alarm / relay functions and LED colour codes
CPA 300 & THA300 transmitters have 4 relays visible on the transmitter board with 24 Vac/dc power supply model
(2 relays visible on the transmitter board with 230 Vac power supply model Ref.HV). Each relay has one LED to
allow real-time checking.
Relay LED colour codes
Red The relay is
None The relay is not energized
or has not been configured
energized
The relay is energized when the setpoint is reached,
taking into account the time-delay, the action type
and also the alarms security mode.
Set points, time-delay and action type setting : see
page 17
Alarm security settings : see page 12
7.d - Selection of the channel for visual and relays alarms
CPA 300 & THA300 transmitters have 4 audible relay alarms with 24 Vac power supply model (2 audible alarms
with 230 Vac power supply model Ref.HV). The transmitter can be configured with 4 different alarms setups with
24 Vac/dc power supply model (2 audible alarms setups with 230 Vac power supply model Ref.HV) .
Go into configuration mode (see page 5). The folder number displayed
corresponds to the last configuration folder used.
Select the folder “400” and validate with . Select sub-folder :
With and keys, select the channel number for which you want to
configure an alarm. Validate with .
The cursor >returns to sub-folders line.
• press twice to return to reading mode.
• press once to return to another folder selection.
• with and keys, you can choose another sub-folder from the folder 400
(i.e. for example to configure another alarm / relay)
“402” “407” “412” “417”
Relay 1Relay 2Relay 3Relay 4
(LED 1) (LED 2)
and validate with .
1
Step
2
Step
3
Step
4
Step
d
b
u
o
s
M
814
d
b
u
o
s
M
824
d
b
u
o
s
M
834
Before any alarm setup, check that the corresponding channel(s) is activated.
!
d
b
u
o
s
M
804
Page 13
CPA 300 & THA 300 transmitters configuration via remote control / Modbus
Relay n°3
Relay n°4
Relay n°1
Relay n°2
230 Vac
power supply
model
Ref. HV
24 Vac/dc
power supply
model
Relay n°1
Relay n°2
Relay n°2
LED
Relay n°1
LED
Available only on power supply models.24 Vac/dc

7.e - Alarm mode details
7. Alarm / relay settings
F400
7.e.1 - Definitions
Setpoint
The setpoint is a limit which, on being reached and/or exceeded , activates an alarm or energizes a relay (in negative
security, see page 14 for more details).
Time-delay
Once the setpoint is reached and/or exceeded, the time-delay postpones the alarm activation (or relay excitation) for a
short period (in seconds). Once this period is elapsed, and if the setpoint is still exceeded, then the alarm is activated or
the relay is energized (in negative security).
Action type
For alarm activation or relay excitation, you can choose the action type : rising or falling action.
• Rising action : the alarm is activated once the measurement goes over the setpoint
• Falling action : the alarm is activated once the measurement goes below the setpoint
7.e.2 - Available configurations
Configuration N°1 : 2 setpoints and time-delay activated (Control Mode)
Setpoint 1
Setpoint 2
Time
Measurement
Energized
Not energized
Relay status
Negative security
Energized
Not energized
Relay status
Positive security
<T> <T> <T>
<T>
Alarm set
Time-delay
Setpoint 1 > Setpoint 2
Setpoint 2
Setpoint 1
Time
Measurement
Energized
Not energized
Relay status
Negative security
Energized
Not energized
Status relay
Positive security
<T> <T> <T>
<T>
Alarm set
Time-delay
Setpoint 2 > Setpoint 1
Control mode (or
regulation mode)
=>you can regulate the
measurement within a
range determined by 2
setpoints.
Page 14 CPA 300 & THA 300 transmitters configuration via remote control / Modbus

7. Alarm / relay settings
F400
Configuration N°2 : 1 setpoint, time-delay and rising action activated
Setpoint 1
Time
Measurement
Energized
Not energized
Relay status
Negative security
Energized
Not energized
Relay status
Positive security
<T> <T> <T>
<T>
Alarm set
Time-delay
Configuration N°3 : 1 setpoint, time-delay and falling action activated
Setpoint 1
Time
Energized
Not energized
Relay status
Negative security
Energized
Not energized
Relay status
Positive security
<T> <T> <T>
<T>
Alarm set
Time-delay
Measurement
Page 15
CPA 300 & THA 300 transmitters configuration via remote control / Modbus

7.f - Alarm mode selection
7. Alarm / relay settings
F400
Go into configuration mode (see page 5). The folder number displayed
corresponds to the last configuration folder used.
Select the folder “400” and validate with .
With and keys, select the code relative to the alarm mode (see chart
below). Validate with .
The cursor >returns to sub-folders line.
• press twice to return to reading mode.
• press once to return to another folder selection.
• with and keys, you can choose another sub-folder from the folder 400.
Code Alarm mode Drawing
00 No alarm
01 2 setpoints with time-delay (control mode) N° 1 page 14
02 1 setpoint with time-delay and rising action
03 1 setpoint with time-delay and falling action N° 3 page 15
N° 2 page 15
1
Step
2
Step
3
Step
4
Step
“403” “408” “413” “418”
Relay 1Relay 2Relay 3Relay 4
Select sub-folder
and validate with .
d
b
u
o
s
M
806
d
b
u
o
s
M
816
d
b
u
o
s
M
826
d
b
u
o
s
M
836
Page 16 CPA 300 & THA 300 transmitters configuration via remote control / Modbus
Available only on 24 Vac/dc power supply models.
