Model: A300 Series
LCD Multi-Media Projector
User's Manual

2
Statement
Note:
- The screen menu and pictures in the manual may slightly differ from the real product.
- The manual is subject to change without prior notice.

3
Contents
Statement 2
Contents 3
Safety Instructions 4
Safety Guide 5
Air circuitlation 6
Moving the projector 6
Installing the projector properly 6
Part names and functions 7
Front 7
Back 7
Bottom 7
Terminals 8
Control Panel and Indicators 9
Remote control 10
Install remote control batteries 12
Operating range 12
Installation 13
Screen size and throw distance 13
Projection distance 13
Projection distance formulas 15
Adjustable foot 15
Connecting to computer 16
Connecting to video equipment 17
Connecting the AC power cord 18
Basic operation 19
Turn on the projector 19
Turn off the projector 20
How to operate the screen menu 21
Menu bar 22
Adjust zoom and focus 23
Auto setup function 23
Keystone 23
Sound 24
Remote control operation 25
Input select 27
Display 28
Auto PC adj. 28
Fine sync 28
H Position 28
V Position 28
H.Size 28
Aspect 29
Project Way 29
Menu Position 29
Background Display 30
System 30
Color adjust 32
Image Mode 32
Contrast 33
Brightness 33
Color temp. 33
Color* 33
Tint* 33
Red(White balance) 33
Green(White balance) 33
Blue(White balance) 33
Sharpness 33
Setting 34
On start 34
Standby mode 34
High land 35
Lamp control 35
Cooling fast 35
Closed Caption 36
Key lock 36
Iris* 37
Terminal* 37
Sound 37
HDMI setup 38
Expand 39
Language 39
Auto setup 39
Keystone 40
Logo 42
Security 43
Power management 44
Filter counter 44
Test Pattern 45
Network* 45
Factory default 46
Image viewer 47
Set slide 47
Set transition effect 47
Sort order 47
Rotate 48
Best t 48
Repeat 48
Apply 48
Infomation 49
Useful functions 50
Memory View function 50
USB Display function 52
Maintenance and cleaning 54
WARNING indicator 54
Cleaning the lter 55
Filter counter reset 55
Clean the project lens 56
Clean the cabinet 56
Replace the lamp 57
Troubleshooting 59
Appendix 59
Indicator and projector state 61
Compatible computer specications 62
Congurations of terminals 64
Content of hazardous substances and
elements 65
PIN code memorandum 65
Dimensions 66
RS232 Control Method 67
LAN control 71
Network Control Instructions 71

4
Safety Instructions
Please read this manual completely before installing
and operating the projector.
The projector provides many convenient features
and functions. Proper operation may enable you to
fully utilize the features and keep it in good condition.
Otherwise, it will not only shorten the service life of
the unit, but also may cause malfunction, a fire, or
other accidents.
If your projector cannot work properly, please read
this manual again, check the operating methods and
cable connection, and try the solutions in the part of
Troubleshooting. If the problem still exists, contact the
dealer or the service center.
The lamp of the projector is a wearing part. The
luminance may decrease after a period of operation
and be weaker than that of a new lamp. This is
normal. Please strictly follow the steps in Turning
on the unit and Turning off the unit to turn on/off
the projector, and the requirements in Maintaining
and cleaning the projector to service and clean the
projector regularly. Or the high temperature residual
heat may not radiate, greatly shortening the service
life of the projector and lamp, or even damaging them
within a short period.
Caution
ELECTRIC SHOCK
DO NOT OPEN
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK) NO
USER SERVICEABLE PARTS INSIDE EXCEPT
LAMP REPLACEMENT. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
THIS SYMBOL INDICATES
THAT DANGEROUS VOLTAGE
CONSTITUTING A RISK OF ELECTRIC
SHOCK IS PRESENT WITHIN THIS
UNIT.
THIS SYMBOL INDICATES THAT THERE
ARE IMPORTANT OPERATING AND
MAINTENANCE INSTRUCTIONS IN THE
USER’S MANUAL WITH THIS UNIT.
Safety precautions
Caution
Caution: • The projector must be grounded.
• Do not expose the projector to
raindrops or high humidity to avoid
a re or electric shock.
- This projector produces intense light from the
projection lens. Avoid staring directly into the
lens, otherwise eye damage could be caused.
Be especially careful that children do not stare
directly into the beam.
- Place the projector in a proper position.
Otherwise it may result in re hazard.
- Leave an appropriate space from the top,
sides, and back of the shell in order to
ventilate and cool down the projector. The
gures below indicate the minimum distance
to be left. It must be satised if the projector is
placed in sealed environment like a cabinet.
- Do not cover the vent of the projector. Poor
radiation may shorten the service life or even
cause dangers.
- Remove the AC power plug if the projector
is not to be used for a long time.
- Do not project the same image for a long time;
otherwise, a residual image may appear on
the LCD panel due to its characteristic.
Do not set the projector in greasy, wet, or smoky
conditions such as in a kitchen, to prevent a
malfunction or accident. If the projector comes
in contact with oil or chemicals, it may become
deteriorated.
Read and keep this manual for future reference.
SIDE and TOP REAR
0.7’(20cm)
1.5’(50cm) 3’(1m) 3’(1m)
10
Environment-friendly use conditions: The environment-
friendly life time of the projector and remote control is 10
years, the lamp (consumable) 5 years, and the provided
batteries (consumable) 5 years.
The use conditions of the environment-friendly use period
are the same with that of the product. Properly operate and
effectively maintain the projector according to the requirements
in this manual.
Disposal of old Electrical & Electronic Equipment (Applicable throughout
the European Union and other European countries with separate
collection programs)
This symbol found on your product or on its packaging, indicates that
this product should not be treated as household waste when you wish
to dispose of it. Instead, it should be handed over to an applicable
collection point for the recycling of electrical and electronic equipment.
By ensuring this product is disposed of correctly, you will help prevent
potential negative consequences to the environment and human
health, which could otherwise be caused by inappropriate disposal of
this product. The recycling of materials will help to conserve natural
resources.
This symbol is only valid in the European Union.
If you wish to discard this product, please contact
your local authorities or dealer and ask for the correct
method of disposal.
The mains plug/appliance coupler is used as
disconnect device, the disconnect device shall
remain readily operable.

5
Safety Guide
All the safety and operating instructions should be
read before the product is operated.
Read all of the instructions given here and retain them
for later use. Unplug this projector from AC power
supply before cleaning. Do not use liquid or aerosol
cleaners.
Use a damp cloth for cleaning.
Follow all warnings and instructions marked on the
projector.
For added protection to the projector during a lightning
storm, or when it is left unattended and unused for
long periods of time, unplug it from the wall outlet.
This will prevent damage due to lightning and power
line surges.
Do not expose this unit to rain or use near water... for
example, in a wet basement, near a swimming pool,
etc...
Do not use attachments not recommended by the
manufacturer as they may cause hazards.
Do not place this projector on an unstable cart, stand,
or table. The projector may fall, causing serious
injury to a child or adult, and serious damage to the
projector.
Use only with a cart or stand recommended by the
manufacturer, or sold with the projector. Wall or
shelf mounting should follow the manufacturer’s
instructions, and should use a mounting kit approved
by the manufacturers.
An appliance and cart combination
should be moved with care. Quick
stops, excessive force, and uneven
surfaces may cause the appliance
and cart combination to overturn.
Slots and openings in the back and bottom of the
cabinet are provided for ventilation, to ensure reliable
operation of the equipment and to protect it from
overheating.
The openings should never be covered with cloth or
other materials, and the bottom opening should not be
blocked by placing the projector on a bed, sofa, rug,
or other similar surface. This projector should never
be placed near or over a radiator or heat register.
This projector should not be placed in a built- in
installation such as a book case unless proper
ventilation is provided.
Never push objects of any kind into this projector
through cabinet slots as they may touch dangerous
voltage points or short out parts that could result in a
re or electric shock. Never spill liquid of any kind on
the projector.
Do not install the projector near the ventilation duct of
air-conditioning equipment.
This projector should be operated only from the type
of power source indicated on the marking label. If you
are not sure of the type of power supplied, consult
your authorized dealer or local power company.
Do not overload wall outlets and extension cords as
this can result in re or electric shock. Do not allow
anything to rest on the power cord. Do not locate this
projector where the cord may be damaged by persons
walking on it.
Do not attempt to service this projector yourself as
opening or removing Covers may expose you to
dangerous voltage or other hazards. Refer all
servicing to qualied service personnel.
Unplug this projector from wall outlet and refer
servicing to qualied service personnel under the
following conditions:
a. When the power cord or plug is damaged or
frayed.
b. If liquid has been spilled into the projector.
c. If the projector has been exposed to rain or water.
d. If the projector does not operate normally by
following the operating instructions. Adjust only
those controls that are covered by the operating
instructions as improper adjustment of other
controls may result in damage and will often
require extensive work by a qualied technician to
restore the projector to normal operation.
e. If the projector has been dropped or the cabinet
has been damaged.
f. When the projector exhibits a distinct change in
performance-this indicates a need for service.
When replacement parts are required, be sure the
service technician has used replacement parts
specied by the manufacturer that have the same
characteristics as the original part. Unauthorized
substitutions may result in re, electric shock, or injury
to persons.
Upon completion of any service or repairs to this
projector, ask the service technician to perform routine
safety checks to determine that the projector is in safe
operating condition.

6
M4x10
10mm
Torque:1.40N.m
Safety Guide
Air circuitlation
Vents in the cabinet are provided for ventilation.
To ensure reliable operation of the product and
to protect it from overheating, these openings
must not be blocked or covered.
Caution
Hot air is exhausted from the exhaust vent.
When using or installing the projector, the
following precautions should be taken.
- Do not put any ammable objects, or spray
can near the projector. Hot air is exhausted
from the air vents.
- Keep the exhaust vent at least 1m away from
any objects.
- Do not touch a peripheral part of the exhaust
vent, especially screws and metallic part. This
area will become hot while the projector is
being used.
- Do not put anything on the projector. Objects
put on the cabinet will not only get damaged
but also may cause re hazard by heat.
Cooling fans are provided to cool down the
projector.
- The fan’s running speed is changed according
to the temperature inside the projector.
Moving the projector
When moving the projector, cover the lens
cap and retract the adjustable feet to prevent
damage to the lens and cabinet. Put it into a
pouch (provided) with the lens facing upwards
if the projector is not in use for a long period.
Air Intake Vent
Exhaust Vent
Installing the projector properly
Be sure to install the projector properly.
Improper installation may reduce the lamp
lifetime and even cause a re hazard.
Caution in ceiling installation the projector
Do not roll the projector over 20
degrees from side to side.
Do not point the projector up to
project an image.
Do not point the projector down
to project an image.
Do not put the projector on either
side to project an image.
- Only qualied personal is authorized for ceiling
installation.
- We are not responsible for the hurt and damage
caused by ceiling brakect that purchased from
unauthorized dealer even in warranty period.
- Remove the ceiling bracket immediately while
not use.
- While installing, torque screwdriver is suggested,
don't use electric or impact-type screwdriver.
Caution in moving or transporting the
projector
– Do not drop or bump the projector, otherwise
damages or malfunctions may result.
– When carrying the projector, use a suitable
carrying case.
– Do not transport the projector by courier or
any other transport service in an unsuitable
transport case. This may cause damage
to the projector. For information about
transporting the projector by courier or any
other transport service, consult your dealer.
– Do not put the projector in a case before it is
cooled enough.
(
Do not pitch the projector more
than 20 degrees backward and
forward.

7
Front
Back
Bottom
Part names and functions
①Top control and Indicators
② Lamp cover
③ Air Intake Vent/Filter
④ Remote control receiver
⑤ Projector lens
⑥ Focus ring(front)
⑦ Zoom ring(back)
⑧ AC cord terminal
⑨ Security slot
⑩ Rear terminals
⑪ Security Chain Hook
⑫ Speaker
⑬ Adjustable foot
⑭ Exhaust vent
⑨
⑬
⑫
⑭
⑥
①②
③④ ⑤
⑦
⑧⑩⑪
Caution
Hot air is exhausted from the exhaust vent. Do
not put heat-sensitive objects near this side.

8
Part names and functions
Terminals
①
②③④⑤⑥ ⑦
⑨
⑩ ⑪
① VARIABLE AUDIO OUT
This is the terminal to output the input audio
signal to the projector.
② VIDEO IN
This is the terminal to input video signals.
③ COMPUTER 1 IN
This is the terminal to input RGB, YPBPR/
YCBCRor S-video signals.
④ COMPUTER 2 IN/1 OUT
This is the terminal to input RGB signals or
output the RGB signals to external monitor.
⑤ HDMI
This is the terminal to input HDMI signals.
⑥ LAN*
This is the terminal to connect to the network.
⑦ USB B(DISPLAY)*
This terminal is used to connect the
projector to the computer with a USB cable
when you want to project the computer
screen.
⑧ USB A(VIEWER)*
When usding the Memory Viewer function,
insert the USB memory directly to this
terminal.
⑨ AUDIO IN 1
This is the terminal to input computer audio
signals.
In addition, if you have set Sound to
Computer in HDMI setup menu, it outputs
the analog audio of the input signal which is
input to AUDIO IN 1 terminal when the
HDMI input source is selected.
⑩ AUDIO IN 2(L/R)
This is the terminal to input Video, S-video
and YPBPR/ YCBCR audio signals.
⑪ SERIAL IN
This is the RS-232C compatible terminal to
externally control the projector by connecting
a computer.
*:Some model has no this terminal.
⑧

9
Part names and functions
Control Panel and Indicators
KEYSTONE
①②
④
⑥
⑦
③
⑤
① POWER indicator
Displays the status of the power.
②WARNING indicator
Indicates the abnormal conditions of the
projector.
③ Power button
Turns the projector on/off.
④ KEYSTONE button
Used to correct the keystone.
⑤▲▼ button
Used to select the menu items in the menu
operation.
⑥ MENU/◄button
- Displays or exit the menu screen.
- Return to the prerious menu.
⑦ INPUT/OK / ►button
- Displays the input source menu.
- Used to execute OK button when the
menu screen appears.

10
Remote control
① POWER button
Turn on or turn off the projector.
②COMPUTER 1 button
Switch Computer 1 or Component as input
source.
③INPUT button
Enter input source menu to select input
source directly.
④HDMI button
Select HDMI as input source.
⑤COMPUTER 2 button
Select Computer 2 as input source.
⑥VIDEO button
Select Video as input source.
⑦MEMORY VIEWER/USB DISPLAY button
Switch Memory Viewer or USB Display
signal.
⑧S-VIDEO button
Select S-video as input source.
⑨OK button
Enter screen menu or execute selected
items.
⑩ button
- Select items or adjust the data in screen
menu.
- Select the image display area in digital
zoom mode.
⑪LAMP button
Select lamp mode.
⑫BLANK button
Temporarily close the image on the screen.
⑬TIMER button
Enable the timer function.
⑱
⑲
㉑
㉓
㉕
①③ ②
④
⑧
⑩
⑭
⑯
⑥
⑫
⑦
⑬
⑮
⑪
⑤
⑰
⑳
㉒
⑨
㉔
㉖
INPUT POWER
VIDEO
HDMI
S-
VIDEO
MENU
KEYSTONE
VOLUME- D.ZOOM- BLANK FREEZE
VOLUME+ D.ZOOM+ MUTE IMAGE
SCREEN AUTOSET INFO.
BACK LAMP TIMER
OK
MEMORY VIEWER
/USB DISPLAY
COMPUTER 1 COMPUTER 2
Part names and functions

11
⑱
⑲
㉑
㉓
㉕
①③ ②
④
⑧
⑩
⑭
⑯
⑥
⑫
⑦
⑬
⑮
⑪
⑤
⑰
⑳
㉒
⑨
⑭ MENU button
Open or close the screen menu.
⑮AUTOSET button
Enter auto setup mode.
⑯SCREEN button
Select the screen size.
⑰ INFO. button
Display the projector information.
⑱KEYSTONE button
Enter Keystone menu to execute keystone
correction.
⑲ BACK button
Return to main menu.
⑳D.ZOOM- button
Select the digital zoom - mode.
㉑FREEZE button
Freeze the projected image.
㉒VOUME - button
Decrease the volume level.
㉓MUTE button
Mute the sound.
㉔D.ZOOM+ button
Select the digital zoom + mode.
㉕IMAGE button
Select the image mode.
㉖VOUME + button
Increase the volume level.
㉔
㉖
INPUT POWER
VIDEO
HDMI
S-
VIDEO
MENU
KEYSTONE
VOLUME- D.ZOOM- BLANK FREEZE
VOLUME+ D.ZOOM+ MUTE IMAGE
SCREEN AUTOSET INFO.
BACK LAMP TIMER
OK
MEMORY VIEWER
/USB DISPLAY
COMPUTER 1 COMPUTER 2
Part names and functions

12
Install remote control batteries
Operating range
① Open the battery
compartment lid.
②Install new batteries
into the compartment. ③Replace the
compartment lid.
Two AAA batteries
For correct polarity
(+ and –), be sure
battery terminals
are in contact
with pins in the
compartment.
Point the remote control toward the projector
remote receiver when pressing any button.
The maximum operating range for the remote
control is about 5 meters and 60 degrees.
30°
30°
5m
Part names and functions
To ensure safe operation, please observe the following precautions:
● Use two (2) AAA or LR03 type alkaline batteries.
● Always replace batteries in sets.
● Do not use a new battery with a used battery.
● Avoid contact with water or liquid matter.
● Do not expose the remote control to moisture or heat.
● Do not drop the remote control.
● If the battery has leaked on the remote control, carefully wipe the case clean and
install new batteries.
● Risk of explosion if a battery is replaced by an incorrect type.
● Dispose of used batteries according to the instructions on the battery or local
regulations or guides.

13
Installation
Screen size and throw distance
Projection distance
Refer to the screen size and projection distances to install the projector. Image size and image
position can be adjusted in accordance with the screen size and screen position.
Projected image
SH
SW
SD
SH
Screen
L (LW/LT)
Screen
L (LW/LT)
SW
H
L (LW/LT) *1 Projection distance (m)
SH Image height (m)
SW Image width (m)
H Distance from the center of lens to the image lower end (m)
SD Projected image size (m)
*1 LW : Minimum distance
LT : Maximum distance
For A310XU/A315XU/A320XU/A325XU/A335XU:
Note: All measurements below are approximate and may differ slightly from the actual
measurements. (Unit: m)
Projection size 4:3 aspect ratio 16:9 aspect ratio 16:10 aspect ratio
Screen
diagonal (SD)
Minimum
distance
(LW)
Maximum
distance
(LT)
Height
position
(H)
Minimum
distance
(LW)
Maximum
distance
(LT)
Height
position
(H)
Minimum
distance
(LW)
Maximum
distance
(LT)
Height
position
(H)
0.76(30") 0.887 1.069 0.065 0.967 1.166 0.009 0.941 1.134 0.029
1.02(40") 1.190 1.433 0.087 1.298 1.562 0.012 1.263 1.520 0.038
1.27(50") 1.493 1.797 0.109 1.628 1.959 0.015 1.584 1.906 0.048
1.52(60") 1.797 2.161 0.131 1.959 2.356 0.018 1.906 2.292 0.058
1.78(70") 2.100 2.525 0.152 2.290 2.752 0.021 2.228 2.678 0.067
2.03(80") 2.404 2.889 0.174 2.620 3.149 0.024 2.549 3.064 0.077
2.29(90") 2.707 3.253 0.196 2.951 3.546 0.027 2.871 3.450 0.087
2.54(100") 3.010 3.617 0.218 3.281 3.943 0.030 3.192 3.836 0.096
3.05(120") 3.615 4.345 0.261 3.940 4.736 0.036 3.833 4.608 0.115
3.81(150") 4.527 5.438 0.327 4.933 5.926 0.044 4.800 5.766 0.144
5.08(200") 6.044 7.258 0.435 6.586 7.909 0.059 6.408 7.695 0.192
6.35(250") 7.559 9.078 0.544 8.238 9.892 0.074 8.016 9.625 0.240
7.62(300") 9.077 10.899 0.653 9.891 11.876 0.089 9.623 11.555 0.288

14
Installation
For A345XU:
For A315WU/A335WU:
Projection size 4:3 aspect ratio 16:9 aspect ratio 16:10 aspect ratio
Screen
diagonal (SD)
Minimum
distance
(LW)
Maximum
distance
(LT)
Height
position
(H)
Minimum
distance
(LW)
Maximum
distance
(LT)
Height
position
(H)
Minimum
distance
(LW)
Maximum
distance
(LT)
Height
position
(H)
0.76(30") 0.888 1.071 0.065 0.969 1.169 0.009 0.942 1.137 0.029
1.02(40") 1.192 1.436 0.087 1.300 1.567 0.012 1.265 1.524 0.038
1.27(50") 1.496 1.802 0.109 1.632 1.965 0.015 1.587 1.911 0.048
1.52(60") 1.8 2.167 0.131 1.963 2.364 0.018 1.910 2.299 0.058
1.78(70") 2.104 2.532 0.152 2.294 2.762 0.021 2.232 2.686 0.067
2.03(80") 2.408 2.898 0.174 2.626 3.160 0.024 2.554 3.073 0.077
2.29(90") 2.713 3.263 0.196 2.957 3.558 0.027 2.877 3.461 0.087
2.54(100") 3.017 3.629 0.218 3.288 3.956 0.030 3.199 3.848 0.096
3.05(120") 3.625 4.359 0.261 3.951 4.752 0.036 3.844 4.623 0.115
3.81(150") 4.537 5.456 0.327 4.945 5.946 0.044 4.811 5.785 0.144
5.08(200") 6.058 7.283 0.435 6.602 7.937 0.059 6.423 7.721 0.192
6.35(250") 7.579 9.11 0.544 8.259 9.927 0.074 8.035 9.658 0.240
7.62(300") 9.099 10.937 0.653 9.915 11.918 0.089 9.647 11.595 0.288
Projection size 4:3 aspect ratio 16:9 aspect ratio 16:10 aspect ratio
Screen
diagonal (SD)
Minimum
distance
(LW)
Maximum
distance
(LT)
Height
position
(H)
Minimum
distance
(LW)
Maximum
distance
(LT)
Height
position
(H)
Minimum
distance
(LW)
Maximum
distance
(LT)
Height
position
(H)
0.76(30") 1.070 1.290 0.065 0.969 1.169 0.009 0.942 1.137 0.029
1.02(40") 1.435 1.729 0.087 1.300 1.567 0.012 1.265 1.524 0.038
1.27(50") 1.800 2.167 0.109 1.632 1.965 0.015 1.587 1.911 0.048
1.52(60") 2.165 2.606 0.131 1.963 2.364 0.018 1.910 2.299 0.058
1.78(70") 2.530 3.044 0.152 2.294 2.762 0.021 2.232 2.686 0.067
2.03(80") 2.895 3.483 0.174 2.626 3.160 0.024 2.554 3.073 0.077
2.29(90") 3.260 3.921 0.196 2.957 3.558 0.027 2.877 3.461 0.087
2.54(100") 3.625 4.360 0.218 3.288 3.956 0.030 3.199 3.848 0.096
3.05(120") 4.355 5.237 0.261 3.951 4.752 0.036 3.844 4.623 0.115
3.81(150") 5.449 6.552 0.327 4.945 5.946 0.044 4.811 5.785 0.144
5.08(200") 7.274 8.745 0.435 6.602 7.937 0.059 6.423 7.721 0.192
6.35(250") 9.099 10.937 0.544 8.259 9.927 0.074 8.035 9.658 0.240
7.62(300") 10.924 13.130 0.653 9.915 11.918 0.089 9.647 11.595 0.288

15
Installation
To use a screen size not listed in this manual, check the screen size SD (m) and use the respective
formula to calculate projection distance.
The unit of all the formulae is m. (Values obtained by the following calculation formulae contain a
slight error.)
If you want to calculate the projection distance with projected image size SD (unit: inch) by
substituting, please assign 0.0254 times to the SD value.
Projection distance formulas
For A310XU/A315XU/A320XU/A325XU/A335XU:
For A345XU:
For A315WU/A335WU:
4:3 aspect ratio 16:9 aspect ratio 16:10 aspect ratio
Screen height (SH) =SD(m)×0.6 =SD(m)×0.490 =SD(m)×0.530
Screen width (SW) =SD(m)×0.8 =SD(m)×0.872 =SD(m)×0.848
Minimum distance (LW) =1.1942994×SD(m)-0.02327 =1.300795×SD(m)-0.02327 =1.26596×SD(m)-0.02327
Maximum distance (LT) =1.4334636×SD(m)-0.02367 =1.561545×SD(m)-0.02367 =1.519494×SD(m)-0.02367
4:3 aspect ratio 16:9 aspect ratio 16:10 aspect ratio
Screen height (SH) =SD×0.6 =SD×0.490 =SD×0.530
Screen width (SW) =SD×0.8 =SD×0.872 =SD×0.848
Minimum distance (LW) =1.197386823×SD(m)-0.025 =1.30451338×SD(m)-0.025 =1.269224628×SD(m)-0.025
Maximum distance (LT) =1.438596804×SD(m)-0.025 =1.56730578×SD(m)-0.025 =1.524908155×SD(m)-0.025
4:3 aspect ratio 16:9 aspect ratio 16:10 aspect ratio
Screen height (SH) =SD(m)×0.6 =SD(m)×0.490 =SD(m)×0.530
Screen width (SW) =SD(m)×0.8 =SD(m)×0.872 =SD(m)×0.848
Minimum distance (LW) =1.4368609×SD(m)-0.025 =1.30451338×SD(m)-0.025 =1.269224628×SD(m)-0.025
Maximum distance (LT) =1.7263145×SD(m)-0.025 =1.56730578×SD(m)-0.025 =1.524908155×SD(m)-0.025
The projection angle can be adjusted up to 10
degrees with the adjustable foot.
Lift the front of the projector up and press the
lock on the adjustable foot to release it.
Release the lock,the foot is then locked. Rotate
the foot to adjust the height and tilt angle.
Keystone distortion of projected images can be
corrected by remote control or menu operation.
Adjustable foot
Adjustable foot

16
Installation
Connecting to computer
Cables used for connection:
● VGA cable ● Serial control cable*
● HDMI cable* ● Auido cable*
● USB B cable* ● LAN cable*
(*=Cables are not supplied with the projector)
Unplug the power cords of both the projector and external equipment from the AC outlet
before connecting the cables.
USB memory
USB B cable
HDMI cable
VGA cable
VGA cable
LAN cable
Serial
control cable
Audio cable
Audio
cable
Control computer
Control computer
Audio equipment
Computer
Computer
Computer
Computer
When the VARIABLE AUDIO OUT
terminal is connected with cable,
the sound will not be output from
the built-in speaker.

17
Installation
Connecting to video equipment
Cables used for connection:
● Video cable* ● S-Video cable*
● HDMI cable* ● Auido cable*
● D-SUB - S Video conversion cable *
● D-SUB - S Video conversion cable (ET-ADSV)*
(*=Cables are not supplied with the projector)
Unplug the power cords of both the projector and external equipment from the AC outlet
before connecting the cables.
Audio equipment
DVD player
Video player DVD player
HDMI cable
Blu-ray disc player with
HDMI terminal
D-SUB - S Video
conversion cable
(ET-ADSV)
S-Video cable
D-SUB - S Video
conversion cable
When the VARIABLE AUDIO OUT
terminal is connected with cable,
the sound will not be output from
the built-in speaker.
Audio cable
Video
cable
Audio
cable
Audio
cable Audio
cable

18
Installation
Connect the AC power cord
(supplied) to the projector.
Connecting the AC power cord
This projector uses nominal input voltages of
100–240V AC and it automatically applies to
different input voltages. It is designed to work
with a single-phase power system having a
grounded neutral conductor. To reduce the risk
of electrical shock, do not plug into any other
type of power system. If you are not sure of
the type of power being supplied, consult your
authorized dealer or service station. Connect
the projector with all peripheral equipment
before turning it on.
The AC outlet should be near this equipment
and must be easily accessible.
Note:
Note:
For safety, unplug the AC power cord when the projector is not in use. When the projector is
connected to an outlet with AC power cord, it is in stand-by mode and consumes a little electric
power.
√ Note:
● Using incorrect power cord may inuence the product performance, or even cause hazards like an
electric shock or re. To ensure the product performance and security, please apply the cable of the
same model with the original one.
● Common connecting cables include the AC power cord, various VGA cables, video cable,and serial
control cable.
Note on the power cord
AC power cord must meet the requirements of the country where you use the projector. Conrm the AC
plug type with the chart below and proper AC power cord must be used. If the supplied AC power cord
does not match.
Projector side
AC outlet side
For the U.S.A. and
Canada
For Continental
Europe For the U.K.
To power cord
connector on your
projector.
Ground
To the AC outlet. To the AC outlet. To the AC outlet.
Ground

19
1.Complete peripheral connections (with a
computer, VCR, etc.) before turning on the
projector.
2. Connect the projector’s AC power cord into
AC outlet. The POWER indicator turns red.
3. Press the Power button on top control or
on the remote control. The ON(G)/
STANDBY(R) indicator
becomes green and the cooling fans start to
work. The preparation display appears on
the screen.
4. If the projector is locked with a PIN code, a
PIN code input dialog box appears. Enter
the PIN code as instructed below.
Caution on handling the PIN code
If you forget your PIN code, the
projector can not longer be started.
Take a special care in setting a
newPIN code. Write down the
number in a column on page 65 of
this manualand keep it properly.
Should the PIN code be missing
or forgotten, consult your dealer or
service center.
Enter a PIN code
Press OK button, press  button to select a
number, then press OK button. select a number
and enter it to the PIN code box, then number
changes to "*", automatically move the cursor
to next box.If you fixed an incorrect number,
press MENU button to reset it again.
Repeat this step to complete entering a three-
digit number.
After entering the three-digit number, move the
cursor to “OK”, then you can start to operate
the projector.
If you entered an incorrect PIN code, the “PIN
code” and the number (***) turn red.PIN dode
will be reset within one second automatically,
Enter the correct PIN code all over again.
What is PIN code?
PIN (Personal Identification Number) code is a
security code that allows the person who knows
it to operate the projector. Setting the PIN code
can prevent unauthorized use of the projector.
A PIN code consists of a three-digit number.
Refer to the PIN code lock function in the
"Expand" "Security" menu on pages 43 for PIN
code lock operation of the projector.
Move the cursor to OK, and press OK.
Move Select Reset
PIN Code
OK Cancel
*
Basic operation
Turn on the projector
Note:
● When the logo select is set to be "Off", the
logo will not be displayed on the screen.
----- Input PIN code Exit
PIN Code
OK Cancel

20
Basic operation
Turn off the projector
Power off ?
“Power off ? ” disappears after 4 seconds.
1. Press the Power button on top control
or on the remote control, and “Power off?”
appears on the screen.
2. Then, press the Power button again in 4
seconds. The POWER indicator
starts to ash red, and the cooling fans
keep running (You can select the level of
fans’ quietness and running speed.). Now
you can unplug the AC power cord after the
fans stop running.
3. When the projector has cooled down enough
to be turned on again, the POWER indicator
stops ashing.
Note:
● When the On start function is “On” , this
projector is turned on automatically by
connecting the AC power cord to an AC outlet .
● The running speed of cooling fans is changed
according to the temperature inside the
projector.
● Do not put the projector in a case before it is
cooled enough.
● If the WARNING indicator flashes or
emits a red light, see “WARNING indicator”.
● While the POWER indicator is flashing, the
lamp is being cooled down and the projector
cannot be turned on. Wait until the POWER
indicator turns red to turn on the projector
again.
● The fan rotation will terminate directly if the
AC power cord is unplugged immediately after
the projector is turned off.
● The projector can be turned on after the
POWER indicator turns red. The waiting time
to restart will be shortened when the normal
power-off processing for fan cooling is
completed, comparing with the time the AC
power cord is immediately unplugged after the
power-off.
To maintain the lamp life, once you turn
the projector on, wait at least 5 minutes
before turning it off.
Do not operate the projector
continuously without reset.
Continuous use may result in shortening
the lamp life.Turn off the projector and
let it stand for about an hour in every 24
hours.
