A-Key to better communications.
Screen Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3500 ANSI Lumens
Illumination Uniformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90%
Size of Color Palette . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16.7 Million
Contrast Ratio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .600:1 (Full ON/OFF)
Horizontal Resolution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 800 TV Lines
Projection Lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .440 Watt Metal Halide DC
Recommended Lamp Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1,000 Hrs.
Imaging System . . . . . . . . . . . . . . . . . . .1.8" PolySilicon active matrix TFT Panels x 3
Screen Pixels . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1024 x 768 in stripe configuration
Total Pixels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2,359,296 (1024 x 768) x 3
Lens Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Power Zoom and Focus
Lens Speed & Focal Length . . . . . . . . . . . . . .f:2.0~2.3; 2.98~3.84 in. (75.7~97.5 mm.)
Lens Ratios . . . . . . . . . . . . . . . . . . . . .Zoom Max:Min: 1.29:1; Throw:Width: 2.1~2.6:1
Image Diagonal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31 ~ 600 in.
Image Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2.6 ~ 40 ft. (0.8 ~ 12.2 m.)
Throw Distance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 ~ 106 ft. (1.5 ~ 33.2 m.)
Front Elevation / Maximum Pitch . . . . . . . . . . . . . . . . . .up to 4° up / 45° up or down
Anti-Keystone . . . . . . . . . . . . . . . . . . . . . . . . .Power Lens Shift, Ratio (T:B) 10:0~0:10
Scanning Frequency . . . . . . . . . . . . . .Auto: H Sync. 15~120kHz; V Sync. 50~120 Hz.
Dot-Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 180 MHz.
Image Orientation . . . . . . . . . . . . . . . . . .Normal, Reversed (projector does not invert)
Local Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Full Function
Remote Projector & Mouse Ctrl . . . . . . . . . . . . . . .Wireless (Infra Red x 1) w/ Pointer
Mouse Control Ports . . . . . . . . . . . . . . . . . . . . Two Sets: 12 Pin DIN x 1, USB port x 1
Remote Projector Control . . . . . . . . . . . . . . . . . . . . . . Wireless (Infra Red) / Wired x 1
Wired Remote Jack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Mini Stereo x 1
RS-232 Control Port . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Serial Port type) Dsub9 x 1)
Computer Native Resolution . . . . . . . . . . . . . . . . . . . . . . . 1024 x 768 (XGA/MAC 19)
Computer Compatibility . . . . . . . . . . . . . . . . . . . . . . SXGA, XGA, SVGA, VGA & MAC
Computer: Higher Resolution . . . . . . . . . . . . .Displayed panned or Smart compressed
INCLUDED ACCESSORIES: Owner's Manual. AC Power Cord 10’(3.m). Lens Cap. Computer Input Cable 6’(1.8m) HD-15~HD-15. MACAdapter.
Wireless Remote Control with Mouse and Laser Pointer & 2 xAAbatteries. Mouse cables 9’(2.75m) each for PS/2, Serial Port, ADB Port. Wired Remote
Control & 2 xAAbatteries & 5’(1.5m)cord. Dust Cover.
OPTIONAL ACCESSORIES: Replacement Lamp. MAC Monitor Cable. PCI bus Graphics Adapter. DFPcable 10’(3.m). PCMCIA DFPadapter. DFPcable
33’(10.m). Mouse Extension Cable 33’(10M). Wired Remote Cord 30’(9M). 13W3 Input/ OutputAdaptersfor SGI,SUN, IBM, NeXT.Telephoto, Midrangeand
WideAngle Lenses. Soft Carry Bag with wheels and telescoping handle. ATAShipping Case with wheels and telescoping handle. Ceiling Mount and Post &
Plate. Stacker Stand.
KEY FEATURES: Model LC-X3
•Projects 1024 x 768 pixels, for real XGA/ MAC19 resolution.
•3500 ANSI Lumens at 90% uniformity with a 600:1 contrast ratio.
•Projects images up to 40' wide (600" diagonal) over distances up to 106'.
•180 MHz dot clock for compatibility with most workstations.
•Smart data compression/expansion: compatibility up to SXGA/ down to VGA.
•Digital Connectivity: DFPdata input, Panel Link™technology.
•HDTV Ready: 1080i, 720p and 1035i compatible.
•Progressive video scaling resizes the video image beautifully.
•Accepts Composite, Component, and S-Video Input. Displays 4:3 and 16:9.
•Multi-Format Video: NTSC / PAL / SECAM / NTSC 4.43 / PAL-M / PAL-N.
•Power Lens Shift offsets the image in both directions: up & down.
•Wireless remote control with mouse and laser pointer.
•Optional Telephoto, Midrange and WideAngle Lenses.
•3 Year* Projector Warranty! 90 Days* Lamp Warranty!
SPECIFICATIONS: Model LC-X3
Computer: Lower Resolution . . . . . . . . . . . . . . . .Displayed normal or Smart expanded
Computer: Channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Computer: Input: Channel 1 . . . . . . . . . . . . . . . . . HD-15 x 1 & MDR20 (DFP Port) x 1
Computer. Input: Channel 2 . . . . . . . . . . . . . . . . . . . . . . . . . . .5 BNC (R,G,B,H,V) x 1
Computer: Monitor Out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .HD-15 x 1
Computer: Audio Input . . . . . . . . . . . . . . . . . . . . . Two Sets: (Stereo) RCA x 2 (L & R)
Video: Standards . . . . . . . . . . . . . . . . .NTSC/PAL/SECAM/NTSC 4.43/PAL-M/PAL-N
Video: Formats Supported . . . . . . . . . . . . . . . . . . . .Normal 4:3 and Wide Screen 16:9
Video: Image Sizing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Progressive Video Scaling
Video: Channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Video: Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . .Composite, Component, S-Video
Video: Input Connections . . . . . . . . . . . . . . . . . . . . . . Two Sets: BNC x 3, S-Video x I
Video: Audio Input . . . . . . . . . . . . . . . . . . . . . . . . .Two Sets: (Stereo) RCA x 2 (L&R)
Video: Monitor Output Systems . . . . . . . . . . . . . . . . Composite, Component, S-Video
Video: Audio Monitor Output . . . . . . . . . . . . . . . . . . . . . . . . .(Stereo) RCA x 2 (L & R)
Audio Output: Amplifier . . . . . . . . . . . . . . . . . . . . . . .3 Watts RMS (each L&R) Stereo
Audio Output: Speakers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 x 3.5 in. (5 x9 cm) x 2
Fan Noise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45 dBA
Size (H x W x D) . . . . . . . . . . . . . . . . . . . . . 9.7x15.4x23.1 in. (245 x 390 x 585 mm.)
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39.3 lbs. (17.8 kg.)
Packaged Size (H x W x D) . . . . . . . . . . . . .16.3x21.1x28.8 in. (412 x 534 x 730 mm.)
Packaged Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51.8lbs. (23.5 kg.)
Power Requirements . . . . . . . . . . . . . . . . . . . . . . .100~120/200~240V AC, 50/60 Hz.
Power Consumption / Heat . . . . . . . . . . . . . . . 670 Watts / 2,287 BTU /hr. (577 KC/hr.)
Power Cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10’ (3.m) Type 3, Detachable
Safety Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .UL Listed
Operating Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41~95°F (5~35°C)
User Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Clean Air Filter, Replace Lamp
Warranty Projector . . . . . . . . . . .3 Yr. / 6000 Hr. *(Parts & Labor to Correct Defects)
Warranty Lamp . . . . . . . . .90 Days / 500 Hr. * (Pro-Rata Replacement of Failed Lamp)
* Whichever occurs first.
Specifications subject to change without notice. ©2001 EIKI International, Inc. Issued April 10, 2001.
Eiki International, Inc., 26794 Vista Terrace Dr., Lake Forest, CA 92630 Tel: [phone]; Fax: [phone], E-mail: [email protected]
In Canada, 310 First St.- Unit 2, P.O. Box 156, Midland, ON L4R 4K8 Phone: [phone], Fax: [phone] E-mail: [email protected]
Fax-on-Demand: (Toll Free) 877-345-4329 •Visit our World Wide Web site: http://www.eiki.com
The following warning is required by the U.S. FDAand pertains to the laser pointer in the wireless remote control of this projector.
Caution! Laser Radiation – Do not stare into beam. Max. Output: 1 mW. Wave Length: 660 +/- 20 mm. Class II Laser Product.
LC-X3L (Lensless Model)
This model is ready for the installation of an optional lens selected from an extensive list of fixed, manual zoom, and power zoom lenses with throw-to-width ratios
ranging from approximately 1:1 up to more than 12:1. Lens and weight specifications vary.
