kinetic KC-PIRCS-A Series User manual

KC-PIRCS-A Series Color
Covert ‘Spy’ Camera
PIR Style Color ‘Spy’ Camera
with Audio
Specification
Packin List
No Name Model Number 2. UserGuide KC-PIRCS-A 1 1. PIR Spy Color Camera
KC-PIRCS-A 1
Distributor：
Notes: : : : Before providin power to the
camera, please read this User Guide in
Do ot attempt to disassemble the camera.
If the camera does ot work, please co tact
your local Distributor Ki etic CCTV
Model KC-PIRCS-A Pick Up Element SONY 1/3″ CCD Effective Picture Ele-
ments ( H*V ) NTSC:510×492, PAL:500×582
Horizontal Resolution 420 / 540 / 600 TV Li es S/N Ratio More tha 48dB
Horizontal Sync
Frequency (MHZ) NTSC:15.734 K MHz , PAL:15.625 K MHz
Scannin System 2:1 i terlace Minimum Illumination 0.8 Lux / F 2.0
Auto Electronic Shutter NTSC:1/60s~1/100,000s,PAL:1/50s~1/100,000s Gama Characteristic 0.45
Video Output 1Vpp,75 Ω
Audio I tegral Audio Micropho e
Power////Current 12VDC(+/-10%)/120mA
Lens 3.7 mm /F 2.0
Back Li ht Compensa-
tion Auto
White Balance Auto
Stora e Temperature -30~ +60℃
Operatin Temperature -10~ +45℃
Dimension (mm) 66(W)×105(H)×60(D)
Wei ht ( ) 120

INTRODUCTION
Co gratulatio s o your purchase of this product which
adopts the latest SONY CCD image se sors a d drivers.
This PIR style covert ‘spy’ camera is discreet a d attractive.
Is desig ed for i door applicatio s a d offers high defi itio ,
image stability, stro g a ti-jammi g, with rich a d real
colours. Whilst bei g easy to i stall a d to operate.
Please read this i structio ma ual carefully to e sure prop-
er use of the product.
CONNECTING
PRODUCT FEATURES:
* * * * Sensor ((((CCD)))) SONY 1/3" CCD image Se sor.
* Inter al Audio Microphone included
* * * * Auto Gain Control (AGC)
Built-i auto gai co trol (AGC) circuit. The colour
camera achieves a high defi itio picture u der low Lux
co ditio s.
* * * * Auto Electronic Shutter (AES)
Built-i auto electro ic shutter fu ctio . The colour
camera’s AES speed ca reach 1/100,000s.
* * * * Gamma Characteristic
Camera Gamma characteristic is 0.45.
* * * * Scannin Mode
NTSC or PAL mode.
DC12V Power Supply
Mo itor
KC-PIRCS
TROUBLE AND SOLUTION
Li k wire rule：
Power Video
Note: : : :
● Please ote the camera’s operati g temperature a d its usi g
1. No Picture after Power-up
. May be due to power supply voltage ab ormality, please check the power
supply voltage a d polarity. . Please check all the co ecti g cable a d mo itors are co ected
Correctly.
2. The picture has flowin interference ripples
. May be caused by power supply AC ripples, or video sig al grou d loop
i terfere ce. . Check the mo itor a d peripheral equipme ts used.
3. The picture back round colour chan es continuously
. The fluoresce t lamp’s electromag etic field ca cause colour roll. This is a
recog ized phe ome o with CCD cameras.
. Reduce the umber of fluoresce t lamps or i crease the dista ce betwee
the camera a d the fluoresce t lamps to improve it.
. Usi g a power supply exter al sy c. camera ca resolve it.
4. Picture smear
. The power supply’s voltage maybe u stable. . Co ecti g cables ot co ect correctly or have high impeda ce.
To preve t fire or shock hazard. Do ot expose the u it
The symbol is i te ded to alert the user to the prese ce of
The symbol is i te ded to alert the user to the prese ce of
to rai or moisture.
importa t operati g a d mai te a ce (servici g)
I structio s i the literature accompa yi g the applia ce.
u i sulated ‘da gerous voltage’ withi the product’s
e closure that may be of sufficie t Mag itude to co stitute
a risk of electric shock to perso s.
Notes：：：：
● A regulated 12VDC Power supply is required. Its output voltage、curre t、voltage polarity a d operati g temperature must match the
camera’s requireme t.
Video 12V DC
CAUTION:
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK
DO NOT REMOVE COVER OR BANG OR KNOCK ANY USER
SERVICEABLE PARTS INSIDE.
REFER SERVICING TO OUALIFIED SERVICE PERSONNEL.
RISK OF ELECTRIC. DO NOT OPEN
CAUTION:
To prevent electric shocks and risk of fire hazard,
do NOT use other than specified power source.
Audio
