Kinfine HOMEPOP K1401.24 User manual

Open Back 24" Barstool
>>assembly instructions
Style Number : K1401.24

2
Congratulations on your latest HomePop purchase.
Now what? Don’t start sweating over this box of parts. This will be easy. We did the hard work for you.
All you need to do is follow our simple instructions and you’ll be on your way to transforming your
room in no time. Good luck --though we’re confident you won’t need it.
1. Check for damaged or missing parts. Customers can email or call 1-888-626-0888 to order missing supplies.service@kinfine.com
2. Use the carton as a working surface to prevent product damage during assembly.
3. Gather all tools prior to assembly.
before you begin

..............................................
table of contents
introduction
hardware
parts list
assembly
2
4
5
6 - 12
QUESTIONS? Just email or call 1-888-626-0888 parts and service. For fast service, have the style number and article number ready when calling.service@kinfine.com 3

(A) x 4
5/16" x 90mm
round hex screw
............................................................................
(J) x 2
plug
(M) x 1
4mm Ball end
Hex wrench
hardware
4
(G) x 10
Φ 22mm flat washer
(D) x 2
1/4" x 45mm
round hex screw
(E) x 2
1/4" x 20mm
round hex screw
(I) x 4
Φ 15mm flat washer
(C) x 4
5/16" x 60mm
round hex screw
(F) x 10
Φ 8mm lock washer
(H) x 4
Φ 6mm lock washer
(L) x 1
5mm Ball end
Hex wrench
(B) x 2
5/16" x 70mm
round hex screw
(K) x 1
dowel 10x40mm

............................................................................
5
ITEM DESCRIPTION QUANTITY
1
2
3
4
1
1
1
2
chair back
seat cushion
front leg
bar
1
2
3
4
4

............................................................................
step 1.
1 2
6
Please do not assemble with power tools.
Open the velcro.
2
(C) x 4
5/16" x 60mm
round hex screw
(F) x 4
Φ 8mm lock washer
(G) x 4
Φ 22mm flat washer
(L) x 1
5mm Ball end
Hex wrench
3
LCFG

............................................................................
step 2.
1 2
7
Please do not assemble with power tools.
(E) x 2
1/4" x 20mm
round hex screw
(H) x 2
Φ 6mm lock washer
(I) x 2
Φ 15mm flat washer
(M) x 1
4mm Ball end
Hex wrench
4
4
M
E
H
I

............................................................................
step 3.
1
2
8
Please do not assemble with power tools.
Do not tighten these two bolts
until the next step.
(F) x 2
Φ 8mm lock washer
(G) x 2
Φ 22mm flat washer
(L) x 1
5mm Ball end
Hex wrench
(B) x 2
5/16" x 70mm
round hex screw
(K) x 1
dowel 10x40mm
1
K
L
B
F
G

............................................................................
step 4.
1
9
Please do not assemble with power tools.
Now you may tighten all 6 bolts.
(F) x 4
Φ 8mm lock washer
(G) x 4
Φ 22mm flat washer
(L) x 1
5mm Ball end
Hex wrench
(A) x 4
5/16" x 90mm
round hex screw
L
A
F
G

............................................................................
step 5.
1
10
Please do not assemble with power tools.
2Use plugs to cover the holes.
(H) x 2
Φ 6mm lock washer
(I) x 2
Φ 15mm flat washer
(M) x 1
4mm Ball end
Hex wrench
(D) x 2
1/4" x 45mm
round hex screw
(J) x 2
plug
M
D
H
IJ

............................................................................
step 6.
1
11
Close the velcro.

............................................................................
step 7.
12
A friendly reminder from us:
Please keep the Allen wrench.
After a period of time, there may be a chance the
KD furniture may become loose, please use an
Allen wrench to tighten the loose bolts.
Level the furniture, use leveling feet if needed.
Adjustable leveling feet
( This part is already attached on the end cap of 4 legs. )
