King Canada 8342 User manual

Service Manual / Manuel de Service
14” Cut-Off Saw
Tronçonneuse 14”
8342
Revised/Revisé 08/2008

Parts Pricing List / Liste de Prix des Pièces 8342
Diag.
1
2
3
4-1
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
Order # Com.
4983420010
4983420020
4983420030
4983420041
4983420050
4983420060
4983420070
4983420080
4983420090
4983420100
4983420110
4983420120
4983420130
4983420140
4983420150
4983420160
4983420170
4983420180
4983420190
4983420200
4983420210
4983420220
4983420230
4983420240
4983420250
4983420260
4983420270
4983420280
4983420290
4983420300
4983420310
4983420320
4983420330
4983420340
4983420350
4983420360
4983420370
4983420380
4983420390
4983420400
4983420410
4983420420
4983420430
4983420440
4983420450
4983420460
4983420470
English Description
RUBBER FOOT
BASE
FIXED CLAMP
QUICK VISE SCREW ASS'Y
NUT
CLAMPING HALF NUT BODY
WASHER
SPRING WASHER
RD. HD. SCREW
COTTER PIN
CLAMPING HALF NUT
WASHER
SPRING WASHER
THREADED SHAFT
CAP SCREW
MOBILE CLAMP
LIMITING STOPPER
CAP SCREW
HEX. NUT
HEX. BOLT
HOLLOW SHAFT
CAP SCREW
WASHER
SPRING WASHER
TORSION SPRING
HEX. NUT
HOUSING
BRUSH CAP
CARBON BRUSH SET(2)
BRUSH HOLDER
WASHER
SPRING WASHER
PAN HD. SCREW
FIELD COIL
TERMINAL
TAPPING SCREW
FAN PROTECTOR
BALL BEARING
ARMATURE
LOCK PIN
SPRING
RETAINING RING/SHAFT
BALL BEARING
CAP SCREW
RUBBER CYLINDER
MAIN ARM
PAN HD. SCREW
Description Française
PIED EN CAOUTCHOUC
SOCLE
PLAQUE ETAU FIXE
TIGE VISSEE A RELACHEMENT ASS.
ECROU
ATTACHEMENT EN DEMI-ECROU
RONDELLE
RONDELLE A RESSORT
VIS A TETE RONDE
GOUPILLE
LEVIER DEMI-ECROU
RONDELLE
RONDELLE A RESSORT
TIGE DE PIVOTEMENT FILETEE
BOULON A TETE CYLINDRIQUE
PLAQUE-ETAU MOBILE
LIMITE D'ARRET
BOULON ATETE CYLINDRIQUE
ECROU HEXAGONAL
BOULON HEXAGONAL
TIGE CREUSE
BOULON A TETE CYLINDRIQUE
RONDELLE
RONDELLE A RESSORT
RESSORT A TORSION
ECROU HEXAGONAL
BOITIER DU MOTEUR
CAPUCHON DES BALAIS
JEU DE BROSSE AU CARBONE(2)
PORTE-BALAIS
RONDELLE
RONDELLE A RESSORT
VIS A TETE BOMBEE
BOBINE D'ENTRAINEMENT
TERMINAL
VIS AUTOTARAUDEUSE
PROTECTEUR DU VENTILATEUR
ROULEMENT A BILLES
ARMATURE
TIGE DE VERROUILLAGE
RESSORT
ANNEAU DE RETENU/TIGE
ROULEMENT A BILLES
BOULON A TETE CYLINDRIQUE
CYLINDRE EN CAOUTCHOUC
BRAS SUPPORT
VIS A TETE BOMBEE
Price/Prix
$3.74
$44.68
$13.63
$50.54
$1.61
$16.04
$1.73
$1.67
$1.78
$1.55
$13.05
$1.67
$1.55
$10.29
$2.13
$12.25
$3.97
$2.47
$1.61
$5.23
$5.00
$2.24
$1.55
$1.55
$15.70
$1.78
$43.64
$3.28
$16.04
$9.14
$1.67
$1.55
$1.78
$91.83
$2.24
$3.05
$5.00
$12.59
$114.83
$4.77
$4.31
$1.55
$11.44
$2.76
$2.01
$64.00
$1.73
Pricing subject to change without prior notice. / Prix sujet à changement sans préavis.
Qty./Qté.
4
1
1
1
1
1
3
3
3
1
1
2
2
1
2
1
1
1
2
1
1
1
1
1
1
1
1
2
1
2
9
8
4
1
2
2
1
2
1
1
1
1
1
1
1
1
4

Parts Pricing List / Liste de Prix des Pièces 8342
Diag.
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
64
65
66
67
68
69
70
71
72
73
74
76
77
78
79
80
81
82
83
84
85
86
87
Order # Com.
4983420480
4983420490
4983420500
4983420510
4983420520
4983420530
4983420540
4983420550
4983420560
KCOW-43214
4983420580
4983420590
4983420600
4983420610
4983420620
4983420640
4983420650
4983420660
4983420670
4983420680
4983420690
4983420700
4983420710
4983420720
4983420730
4983420740
4983420760
4983420770
4983420780
4983420790
4983420800
4983420810
4983420820
4983420830
4983420840
4983420850
4983420860
4983420870
498342MBIL
English Description
ARBOR
O-RING
HELICAL GEAR
BALL BEARING
BEARING HOLDER
FIXED GUARD
SPACER BUSHING
31/2" INNER FLANGE
WHEEL BUSHING
ABRASIVE WHEEL
31/2" OUTER FLANGE
SMALL FLANGE
CAP SCREW
MOBILE GUARD (OUTSIDE)
LOCK KNOB
SCREW
POWER CORD
LEFT HANDLE
RTYPE TERMINAL
RUBBER SLEEVE
TAPPING SCREW
CORD CLIP
RIGHT HANDLE
RUBBER GRIP
RUBBER GRIP
TRIGGER SWITCH
HEX. KEY
LOCKING VISE BLOCK
KEY
SCREW
SAFETY SWITCH BUTTON
BACK KNOB
RUBBER CUSHION
SPRING PIN
SPRING PIN
SPARK DEFLECTOR
PAN HD. SCREW
TAPPING SCREW
BILINGUAL MANUAL 8342
Description Française
ARBRE
ANNEAU EN CAOUTCHOUC
ENGRENAGE HELICOIDALE
ROULEMENT A BILLES
PORTE-ROULEMENT
PROTEGE-MEULE FIXE
BAGUE D'ESPACEMENT
RONDELLE DE L'ARBRE INT. 3 1/2"
BAGUE POUR LAME
MEULE À TRONÇONNER
RONDELLE DE L'ARBRE EXT. 3 1/2"
RONDELLE DE L'ARBRE (PETITE)
BOULON A TETE CYLINDRIQUE
PROTEGE-MEULE MOBILE (EXT)
BOUTON DE VERROUILLAGE
VIS
CORDON D'ALIMENTATION
POIGNEE GAUCHE
TERMINAL TYPE R
MANCHON EN CAOUTCHOUC
VIS AUTOTARAUDEUSE
ATTACHE CORDON
POIGNEE DROITE
POIGNEE ANTI-DERAPPANTE
POIGNEE ANTI-DERAPPANTE
INTERRUPTEUR A GACHETTE
CLE HEXAGONALE
BLOC DE VERROUILLAGE DE L'ETAU
CLE DE RETENUE
VIS
BOUTON DE SECURITE (INTERR.)
BOUTON ARRIERE
AMORTISSEUR EN CAOUTCHOUC
GOUPILLE A RESSORT
GOUPILLE A RESSORT
DEFLECTEUR D'ETINCELLES
VIS A TETE BOMBEE
VIS AUTOTARAUDEUSE
MANUEL BILINGUE 8342
Price/Prix
$27.31
$1.55
$27.43
$12.59
$14.20
$38.70
$3.74
$10.06
$3.05
-
$10.06
$5.23
$1.90
$27.43
$3.16
$2.01
$17.19
$16.96
$1.67
$3.39
$1.67
$2.24
$16.96
$8.45
$8.45
$25.01
$3.05
$6.73
$1.90
$1.90
$2.59
$3.28
$2.59
$2.13
$1.90
$4.89
$1.55
$1.67
$15.00
Pricing subject to change without prior notice. / Prix sujet à changement sans préavis.
Qty./Qté.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
8
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
