Kingfisher MEAP43 User manual

EN 42.7 cm3Petrol
Earth Auger
MEAP43
5063022059833
TTK1048AUG
5059340890265
V30923_5063022059833_MAND1_2223
Page Size: A5
EAN: 5063022059833
Impala Ref: PRJ29166
KNG: KNG -3074 -1
210/10/22
Korey 308/ 11/22 Mohit 411/11/22 Mohit 519 /11/2 2 Mohit 627/09/23 John
EN ORIGINAL INSTRUCTIONS
IMPORTANT - These instructions are for your safety.
Please read through them thoroughly prior to handling
the product and retain them for future reference.
5063022059833_MNL_EN_V06.indd 15063022059833_MNL_EN_V06.indd 1 27 Sep 2023 17:06:0427 Sep 2023 17:06:04

2
EN Parts
EN You will need
x1
01. x1
EN Contents
EN
Product description 3
Safety 5
Technical specication 18
Before you start 20
Use 23
Functions & Settings 25
Operation 28
Care and maintenance 30
Guarantee 37
02. x1
03. x1
5063022059833_MNL_EN_V06.indd 25063022059833_MNL_EN_V06.indd 2 27 Sep 2023 17:06:0427 Sep 2023 17:06:04

3
EN Product description
8
9
10
7
14
15
16
18
19
6
1
17
22a 3
45
13
11
12
20 21 22 23 24 25
5063022059833_MNL_EN_V06.indd 35063022059833_MNL_EN_V06.indd 3 27 Sep 2023 17:06:0527 Sep 2023 17:06:05

4
1. Left handle bar
2. Fixing knob
 a. Airltercover
 b. Airlter*
3. Chokelever
4. Recoil starter handle
5. Startercover
6. Fuel tank cap
7. Ignition switch (ON/OFF)
8. Throttle trigger
9. Right handle bar
10. Gear box
11. Spindle
12. Fuel tank
 a. Fuellter*
13. Primer
 a. Carburettor*
 b. Adjustingscrew*
14.Airvents
15. Spark plug connector
 b. Sparkplug*
16. Throttle wire
17. Mufer
18. Drilling tool (Ø150 mm)
 a. Mountingbolt*
 b. R-Clip*
19. Drilling tool (Ø100 mm)
 a. Mountingbolt*
 b. R-Clip*
20. Fuel mixing bottle
21. Hex key (T25)
22. Hex key (T30)
23. Spanner (8 / 10 mm)
24. Spark plug wrench
25.Screwdriver
NOTE:Partsmarkedwith*arenotshowninthisoverview.Pleaserefertothe
respectivesectionintheinstructionmanual.
5063022059833_MNL_EN_V06.indd 45063022059833_MNL_EN_V06.indd 4 27 Sep 2023 17:06:0527 Sep 2023 17:06:05

5
EN Safety
Petrol powered earth auger safety warnings
IMPORTANT Read carefully before use.
Keep for future reference.
WARNING! Your safety and the safety of others
isveryimportant.Ofcourse,itisnotpracticalor
possible to warn you about all the hazards associated
with operating or maintaining this product. At all times
you must use your own good judgment.
1. This product is not intended for use by persons (including
children)withreducedphysical,sensoryormentalcapabilities,
orlackofexperienceandknowledge,unlesstheyhavebeen
givensupervisionorinstructionconcerninguseoftheproductby
a person responsible for their safety;
2. Childrenshouldbesupervisedtoensurethattheydonotplay
with the product.
3. Anearthaugerisahigh-torque,gasoline-poweredtool,special
safetyprecautionsmustbeobservedtoreducetheriskof
personal injury.
General warning
1. This product is dangerous if used carelessly or incorrectly and
cancauseseriousorevenfatalinjuries.
2. Arsttimeusershouldhavepracticalinstructionintheuse
oftheproductandprotectiveequipmentfromanexperienced
operator.
3. The product is designed to be operated by only one person.
4. Theproductshouldonlybeoperatedbythosewhohaveread
and understood all safety and operating instructions in this
manual.
5063022059833_MNL_EN_V06.indd 55063022059833_MNL_EN_V06.indd 5 27 Sep 2023 17:06:0527 Sep 2023 17:06:05

6
5. Read all instructions carefully. When using petrol powered
products,alwaysfollowstatedsafetyprecautionstoreducethe
risk of serious personal injury and/or damage to the product.
6. Keepyourworkareafreefrompets,animals,childrenand
bystanders.
7. Neverusethemachineinsideahomeorgarage,EVENIFdoors
andwindowsareopen.Runningthisproductinaconnedor
badlyventilatedareacanresultindeathduetoasphyxiationor
carbon monoxide poisoning. The product is for outdoor use only.
8. Take extreme care in wet and freezing weather conditions. Do
notworkinrain,windyorstormyweather.
9. Doalwaysvisuallychecktheproductbeforeuse.
10. Do not attempt to tackle any job that you are not adequately
trained for.
11. Do not allow other persons to be near when starting or drilling
with the product.
12. Keep bystanders and animals at least 5 metres (15’) out of the
work area.
13. Do not operate the product if it has faulty safety equipment or
damaged parts!
14. Do not modify the product under any circumstances.
Modicationscanresultinseriouspersonalinjuryordeath.
15. Ensure yourself that there are neither water or gas pipes nor
electric lines installed underground in the working area.
16. Ensure yourself that there are no loose objects lying around in
the working area.
17. Donotstartdrillinguntilyouhaveaclearworkarea,secure
footing,andaplannedemergencyevacuationpath.
18. Allproductservicing&maintenance,otherthantheitemslisted
intheusermanual,safetyandmaintenanceinstructions,should
beperformedbyanauthorisedservicecentre.
19. National regulation can restrict the use of the product.
Clothing and protective equipment
1. Dosecurelonghairsothatitisaboveshoulderlevel.
2. Donotwearloosettingclothingorjewelleryasthiscouldbe
drawnintothemotor,caughtbyrotatingdrillingtools.
5063022059833_MNL_EN_V06.indd 65063022059833_MNL_EN_V06.indd 6 27 Sep 2023 17:06:0527 Sep 2023 17:06:05

7
3. Do wear a face and breathing mask. The use of this product
cangeneratedust,mistsandfumescontainingchemicalsknown
to cause respiratory damage.
4. Dousesafetysteeltoecappedfootwear,sturdycutretardant
snug-ttingprotectiveclothing,protectivegloves,eyeand
hearingprotectiondevices.
5. Keeprstaidkitathand.
Preparation
1. Do not operate the product when barefoot or wearing open
sandals.
2. Donotwearlooseclothing,longhairopenlyorloosejewellery
like necklaces etc. when operating the machine. They might be
caught by rotating parts and cause serious injuries.
WARNING!Petrolishighlyammable.
• Storefuelincontainersspecicallydesignedfor
this purpose.
• Refuel outdoors only and do not smoke while
refuelling.
• Addfuelbeforestartingtheengine.Neverremove
the fuel tank cap or add petrol while the engine is
running or when the engine is hot.
• Ifpetrolisspilt,donotattempttostarttheengine
butmovetheproductawayfromtheareaof
spillageandavoidcreatinganysourceofignition
untilpetrolvapourshavedissipated.
• Replace all fuel tank and container caps securely.
3. Replace faulty silencers.
4. Beforeusing,alwaysvisuallyinspecttoseethatthedrillingtool,
locking bolt and R-clip are not worn or damaged. Replace worn
ordamageddrillingtoolsandboltsinsetstopreservebalance.
CAUTION! Do not touch rotating drilling tool.
5063022059833_MNL_EN_V06.indd 75063022059833_MNL_EN_V06.indd 7 27 Sep 2023 17:06:0527 Sep 2023 17:06:05

8
5. Operationofthisproductmaycreatesparksthatcanstartres
arounddryvegetation.Asparkarrestormayberequired.
6. Theoperatorshouldcontactlocalreagenciesforlawor
regulationsrelatingtorepreventionrequirements.
Operation
1. Keep the handles clean and dry at all times; It is particularly
importanttokeepthemfreeofmoisture,pitch,oil,fuelmix,
greaseorresininorderforyoutomaintainarmgripand
properly control your product.
2. Donotoperatetheengineinaconnedspacewheredangerous
carbon monoxide fumes can collect.
3. Usetheproductonlyindaylightoringoodarticiallight.
4. Donotoperatetheproductwhilebeingtired,illorunder
inuenceofalcoholordrugs.
5. Do not lean against the machine during drilling.
6. Always beware of the rotating drilling tool.
7. OnlyusetheproductOUTSIDEandfarawayfromwindows,
doors,andvents.
8. The use of the product not according with the required
dimensions is forbidden.
9. The use of the product not being suitable for the intended or not
beingcertiedisforbidden.
10. Striking a hard object in the earth with the rotary drilling tool
and the resulting slowing or stopping of the auger creates
reactiveforces.Thetransferofrotational(reactive)forcescan
cause the auger gear box and handles to rotate suddenly in a
counterclockwise direction and can result in loss of control or
cause the handle frame to hit the operator or throw him to the
ground,resultinginseriousinjury.
11. The use of this machine may be hazardous. If the drilling tool
comesincontactwithyourbody,itcouldcauseimpact,cutor
entanglement.
12. Use your product only for drilling holes in soil with drilling tools.
13. Caution in slippery conditions - slip hazard - risk of injury. When
working,robustandnon-slipfootwear.Slides/stumble/traps
are a major cause of serious injury.
5063022059833_MNL_EN_V06.indd 85063022059833_MNL_EN_V06.indd 8 27 Sep 2023 17:06:0527 Sep 2023 17:06:05

9
14. The hand-held earth auger is not allowed to be used on the
slope;Whenusedonaslope,theoperatormayeasilylosehis
balance and fall down.
15. Working on icy or slippery ground is forbidden!
16. Avoidusingtheproductinbadweatherconditionsespecially
when there is a risk of lightning.
17. Do not alter or tamper with any sealed adjustments for the
engine speed control.
18. Do not tamper or disable any product’s safety systems or
features.
19. Ensure and regularly check that all starting interlocks and
operator presence controls are properly functioning.
20. Stop the product according to instructions in this manual before
leavingtheoperator’spositionandparkitinasafelocation.
21. Avoidsettingdownahotunitontodry,ammablematerial,or
touchingthehotmufer.
22. Start the engine carefully according to instructions and with feet
well away from the drilling tool.
23. Keep hands and feet away from the drilling tool at all times and
especially when starting the engine.
24. Incaseofanysituationmentionedbelow,stoptheengineand
disconnectthesparkplugconnector,makesurethatallmoving
partshavecometoacompletestopand:
• beforeclearingblockages,
• beforechecking,cleaningorworkingontheproduct,
• after striking a foreign object. Inspect the product for damage
andmakerepairsbeforerestartingandoperatingtheproduct,
• iftheproductstartstovibrateabnormally(checkimmediately).
> inspect for damage
> replace or repair any damaged parts
> check for and tighten any loose parts
• wheneveryouleavetheproduct,
• before refuelling.
25. Duringoperation,thegearbox,muferandthepartsaroundit
reach extremely high temperatures. Keep these hot parts away
fromyourbody.Otherwiseyoucouldreceiveseriousburns.
5063022059833_MNL_EN_V06.indd 95063022059833_MNL_EN_V06.indd 9 27 Sep 2023 17:06:0527 Sep 2023 17:06:05

10
26. Neverpickuporcarryaproductwhiletheengineisrunning.
27. Nevertouchtheexhaust,exhaustguardorcoolingnswhenthe
engine is hot.
28. Nevercarelesslytouchhotpartsoftheproduct,youcanburn
yourself.Whiletheproductisinoperationorshortlythereafter,
itspartssuchastheexhaustpipe,engine,gearboxandother
surfaces are extremely hot! Pay attention to the markings on the
product.
29. Makesurethattheairventsofthecombustionengineareclear.
Keeptheairventsfreeofdust,dirtparticles,gasesandfumes.
30. Neverstartorruntheengineindoors.Theexhaustfumesare
dangerous,containingcarbonmonoxide,anodourlessand
deadlygas.Operatethisproductonlyinwellventilatedoutdoor
areas.
Maintenance and storage
1. Follow the maintenance and repair instructions for this product.
Nevercarryoutanymodicationsoftheproduct.Neverchange
the preset rotary speed or the engine and product settings.
Informationaboutmaintenanceandrepairisprovidedinthis
user manual.
2. Keepallnuts,boltsandscrewstighttobesuretheproductisin
safe working condition.
3. Impropermaintenance,usingnon-genuineparts,orremoving/
modifying safety components may lead to malfunction / failure of
the product and injury of operators. Many accidents are caused
by poorly maintained products.
4. Neverstoretheproductwithpetrolinthetankinsideabuilding
wherefumescanreachanopenameorspark.
5. Toreducetherehazard,keeptheengine,silencerandpetrol
storageareafreeofgrass,leaves,orexcessivegreaseto
reducetherehazard.
6. Allow the engine to cool before storing in any enclosure. Clean
and maintain the product before storage.
7. Ifthefueltankhastobedrained,thisshouldbedoneoutdoors.
8. Wearstrongworkgloveswhenremovingandre-assemblingthe
drilling tools.
5063022059833_MNL_EN_V06.indd 105063022059833_MNL_EN_V06.indd 10 27 Sep 2023 17:06:0527 Sep 2023 17:06:05

11
9. Replace worn or damaged parts for safety. Use only the genuine
replacement parts and spare parts.
10. Ensure that only replace the recommended drilling tool with the
correct type.
Fuel handling
1. Beforerefuelling,stoptheengine,disconnectthesparkplug
connectorandlettheproductcool.Fuelandfuelvapoursare
highlyammable.Takecarewhenhandlingfuel.Neversmoke
whenyouarerefuellingtheproduct.Donotrefueltheproduct,if
thereisanopenreinthevicinity!
2. Alwaysusesuitableaidssuchasfunnelsandllernecks.Do
not spill any fuel on the product or its exhaust system. There is a
riskofignition.However,iffuelshouldbespilled,thenyoumust
removeitcarefullyfromallpartsoftheproduct.Anyresidue
whichmaybepresentmustbecompletelyremoved,beforethe
product is operated!
3. Neverrefuelindoors.Exhaustgasesandfuelfumesare
noxious.
4. Neverusetheproductinenvironmentswherethereisariskof
explosion. Fuel fumes can ignite.
5. Neverbreatheinanyfuelfumes,whenyouarerefuelling
theproduct.Neverllthetankinenclosedspaces,suchas
basements or sheds. There is a risk of poisoning and explosion!
6. Avoidskincontactwithpetrol.
7. Donoteatordrink,whileyouarerefuellingtheproduct.Ifyou
haveswallowedpetroloroil,orifpetroloroilhasgotintoyour
eyes,thenseekmedicaladviceimmediately.
8. Closethefueltankcapimmediatelyafterllingthefueltank.
Make sure that it is properly closed.
9. Neverusetheproductwithoutanairlter.
10. Fuelvapourpressuremaybuildupinsidethefueltank
dependingonthefuelused,weatherconditionsandthetank
ventingsystem.Toreducetheriskofburnsandotherpersonal
injuries,removethefuelcapcarefullytoallowanypressurebuild
up to release slowly.
11. Beawareofrerisks,explosionandinhalationrisks.
5063022059833_MNL_EN_V06.indd 115063022059833_MNL_EN_V06.indd 11 27 Sep 2023 17:06:0527 Sep 2023 17:06:05

12
12. Donotsmokewhileoperatingtheproduct,handlingfuelornear
fuel.
13. Ensure the spark plug lead is secured; a loose lead may cause
electrical arcing that could ignite combustible fumes and cause
areorexplosion.
14. Check regularly for leaks from the fuel cap and fuel lines.
15. Dousecautionwhenhandlingfuel.Toavoidanyaccidental
res,movetheproductatleast3metres(10’)fromthefuelling
point before starting the engine.
16. Tightenthefueltankcapthoroughlyafterrellingthefueltank.
17. Donotoperatetheproductifitisleakingfuel.Donotremovethe
fuel tank cap while the engine is running.
18. Useonlyanapprovedcontainerforthispurpose.
19. Donotstorecansoffuelorrellthefueltankinanyplacewhere
thereisaboiler,stove,woodre,electricalsparks,welding
sparks,orothersourcesofheatorrewhichmightignitethe
fuel.
20. Ifanyfuelspillageoccursduringrefuelling,useadryragtowipe
upspillsandallowremainingfueltoevaporatebeforeturningthe
engine on again.
21. Ifyouhavespiltfuelonyourselforonyourclothes,changeyour
clothes and wash any part of your body that has come in contact
with fuel before turning the engine on again.
22. Iffuelisignited,putouttherewithadrypowderre
extinguisher.
23. Ifthefueltankisdrained,thisshouldbedoneoutdoors.
Causes and operator prevention of kickback
Kickback may occur when the nose or tip of the drilling tool touches
anobject,orwhenthewireorundergrowtharetrappedinthecut.
Either of these reactions may cause you to lose control of the
machine which could result in serious personal injury. Do not rely
exclusivelyuponthesafetydevicesbuiltintoyourmachine.Asa
productuser,youshouldtakeseveralstepstokeepyourdrillingjobs
free from accident or injury.
5063022059833_MNL_EN_V06.indd 125063022059833_MNL_EN_V06.indd 12 27 Sep 2023 17:06:0527 Sep 2023 17:06:05

13
Kickback is the result of tool misuse and/or incorrect operating
proceduresorconditionsandcanbeavoidedbytakingproper
precautionsasgivenbelow:
1. In case of kickback (rebound), release the throttle trigger
immediately and hold the product handle with both hands
to avoid losing control of the machine and causing danger.
2. Maintain a rm grip, with thumbs and ngers encircling
the product handles, with both hands on the machine and
position your body and arm to allow you to resist kickback
forces. Kickbackforcescanbecontrolledbytheoperator,if
proper precautions are taken. Do not let go of the product.
3. Only use replacement drilling tool specied by the
manufacturer. Incorrect replacement drilling tools may cause
drill breakage and/or kickback.
4. Ensure yourself that there are no loose objects lying
around in the working area.
5. Eliminate high grass, bushes etc. from the immediate
working area. They might be winded up by the rotating drilling
tool and block it.
6. Take especially care, if the ground contains many stones
or roots. An unattended stalling of the drilling tool might easily
cause an accident.
Vibration and noise reduction
To reduce the impact of noise and vibration emission, limit the
time of operation, use low-vibration and low-noise operating
modes as well as wear personal protective equipment.
Long-term exposure to noise can result in permanent hearing
impairment. So always use approved hearing protection.
Takethefollowingpointsintoaccounttominimizethevibrationand
noise exposure risks:
1. Duringaworkingday,youshalltakefrequentandadequate
breakstopreventdamagefromvibrationanddamagetothe
ears.
5063022059833_MNL_EN_V06.indd 135063022059833_MNL_EN_V06.indd 13 27 Sep 2023 17:06:0527 Sep 2023 17:06:05

14
2. Only use the product as intended by its design and these
instructions.
3. Ensure that the product is in good condition and well maintained.
4. Use correct attachments for the product and ensure they are in
good condition.
5. Keep tight grip on the handles/gripping surface.
6. Maintain this product in accordance with these instructions and
keep it well lubricated (where appropriate).
7. Planyourworkscheduletospreadanyhighvibrationtooluse
across a longer period of time.
8. Prolongeduseoftheproductexposestheusertovibrationsthat
cancausearangeofconditionscollectivelyknownashand-arm
vibrationsyndrome(HAVS)e.g.ngersgoingwhite;aswellas
specicdiseasessuchascarpaltunnelsyndrome.Toreduce
thisriskwhenusingtheproduct,alwayswearprotectivegloves
and keep your hands warm.
Emergency
Familiarise yourself with the use of this product by means of
this instruction manual. Memorise the safety directions and
follow them to the letter. This will help to prevent risks and
hazards.
1. Always be alert when using this product, so that you can
recognize and handle risks early. Fastinterventioncan
preventseriousinjuryanddamagetoproperty.
2. Stop the engine and disconnect the spark plug connector
if there are malfunctions. Havetheproductcheckedbya
qualiedprofessionalandrepaired,ifnecessary,beforeyou
operate it again.
3. In case of re stop the engine and disconnect the spark
plug connector. Takere-extinguishingmeasuresimmediately
if the product switch is no longer accessible.
5063022059833_MNL_EN_V06.indd 145063022059833_MNL_EN_V06.indd 14 27 Sep 2023 17:06:0527 Sep 2023 17:06:05

15
WARNING!Neverusewatertoextinguishaproduct
onre.Burningfuelmustbeextinguishedwithspecial
extinguishing agents! We recommend that you keep
asuitablereextinguisherwithinreachinyourwork
area!
Residual risks
Even if you are operating this product in accordance with all
the safety requirements, potential risks of injury and damage
remain. The following dangers can arise in connection with the
structure and design of this product:
1. Healthdefectsresultingfromvibrationemissioniftheproductis
beingusedoverlongperiodsoftimeornotadequatelymanaged
and properly maintained.
2. Injuries and damage to property due to broken application tools
or the sudden impact of hidden objects during use.
3. Dangerofinjuryandpropertydamagecausedbyyingobjects,
such as stones and other objects thrown out during drilling.
4. Burns,iftouchinghotsurfaces.
5. Risk of kickback. Kickback may occur when the drilling tool is
suddenly blocked and the slip clutch begins to come to a sudden
twist of the body.
WARNING! This product produces an
electromagneticeldduringoperation!Thiseld
mayundersomecircumstancesinterferewithactive
orpassivemedicalimplants!Toreducetheriskof
seriousorfatalinjury,werecommendpersonswith
medical implants to consult their doctor and the
medical implant manufacturer before operating this
product!
5063022059833_MNL_EN_V06.indd 155063022059833_MNL_EN_V06.indd 15 27 Sep 2023 17:06:0527 Sep 2023 17:06:05

16
Symbols
Ontheproduct,theratinglabelandwithintheseinstructionsyouwillndamongothersthefollowing
symbolsandabbreviations.Familiariseyourselfwiththemtoreducehazardslikepersonalinjuriesand
damage to property.
kW Kilowatt ml Millilitre
cm3Cubic centimetre g/kWh Gram per kilowatt per hour
/min or min-1 Per minute kg/h Kilogram per hour
mm Millimetre °C Degree Celsius
cm Centimetre dB(A) Decibel (A-rated)
kg Kilogram m/s2Metres per second squared
LLitre
yyWxx Manufacturing date code; year of manufacturing (20yy) and week of manufacturing
(Wxx)
Lock/to tighten or secure. Unlock/to loosen.
CAUTION!
WARNING!
DANGER!
CAUTION / WARNING!
Read the instruction manual.
NOTE:
Wearahelmet,safetygogglesandhearingprotection.
Wear respiratory protection.
Wearprotectivegloves.
Wearprotective,slip-resistantfootwear.
Wearsturdycutretardantsnug-ttingprotectiveclothing.
Use appropriate protection for foot-leg and hand-arm.
5063022059833_MNL_EN_V06.indd 165063022059833_MNL_EN_V06.indd 16 27 Sep 2023 17:06:0527 Sep 2023 17:06:05

17
Do not expose the product to rain or wet conditions.
Openamesintheworkarea,aroundtheproductandinthevicinityofammable
materials are prohibited!
Do not smoke intheworkarea,aroundtheproductandinthevicinityofammable
materials!
Risk of re / ammable materials
Hotsurface,donottouch!Hightemperaturesontheproduct’ssurfacesandstructural
partsthatcouldcauseburns,iftheyaretouched.Theproductcanalsostayhotfora
longer period of time after operation!
Thisproductproducesnoxiousexhaustfumes.Iftheproductisusedimproperly,these
fumescanleadtopoisoning,alossofconsciousnessordeath!
Noxious exhaust fumes; do not operate or start the product in indoor rooms!
Keep hands and feet away.
40:1 Only use petrol/oil mixture with a ratio of 40:1. Do not use any other mixture ratio.
Alwaysswitchtheproductoffandletitcooldown,beforerefuellingit.
Choke - CLOSE position
Choke - OPEN position
Switchtheengineoffwhileyouarerellingthetanks!
Fuelisammable,keepreaway.Donotaddfuelwithrunningengine.
Contact with electrical cables or wires can cause serious injury or death as a result of
electrical shock.
Riskofkickback!Alwaysholdtheproductrmlywithbothhands!Strikingsomething
hardintheearth,suchasarockorgravel,maycausethedrillingtooltoslowdown
suddenlyorstop.Insuchasituation,someoralloftherotationalforce(reactiveforce)
is transferred to the gear box and handle frame of the earth auger which can cause the
auger gear box and handles to rotate suddenly in a anticlockwise direction.
DO NOT lean on the machine! Beware of rotating blade! Serious injury!
5063022059833_MNL_EN_V06.indd 175063022059833_MNL_EN_V06.indd 17 27 Sep 2023 17:06:0527 Sep 2023 17:06:05

18
Objects thrown by the product could hit the user or other bystanders. Always ensure
that other people and pets remain at a safe distance from the product when it is in
operation.Ingeneral,childrenmustnotcomeneartheareawheretheproductis.
Stoptheengineanddisconnectthesparkplugconnectorbeforeassembly,cleaning,
adjustments,maintenance,storageandtransportation.
Drilling tool continues to rotate after the product is switched off. Wait until all machine
componentshavecompletelystoppedbeforetouchingtheproduct.
Pay special attention when working on the drilling tool!
Engine manual start; recoil starter.
Press the primer 10 times.
113
Guaranteedsoundpowerlevelvaluein113dB.
WEEE symbol. Waste electrical products should not be disposed of with household
waste. Please recycle where facilities exist. Check with your Local Authority or local
storeforrecyclingadvice.
TheproductcomplieswiththeapplicableEuropeandirectivesandanevaluation
methodofconformityforthesedirectiveswasdone.
This product complies with conformity requirements of the applicable UK Regulations.
Rating label explanation
Petrol earth auger: MEAP43 Petrol earth auger: TTK1048AUG
M = MAC Allister TT = TITAN
EA = Earth Auger K = Petrol products
P = Petrol 1048 = Sequential code
43 = Engine displacement (cm3) AUG = Earth auger
ENTechnicalspecications
General
> Dimensions : approx. 550 x 285 x 1115 mm
> Machine mass (without drilling tool,
empty tanks and in normal operating conguration) : approx. 9 kg
> Machine mass (with drilling tool, empty tanks and
in normal operating conguration) : 12 kg
> Fuel tank capacity : 850 ml
5063022059833_MNL_EN_V06.indd 185063022059833_MNL_EN_V06.indd 18 27 Sep 2023 17:06:0627 Sep 2023 17:06:06

19
> Petrol type :#92,unleaded
> Engine oil type : 2-stroke engine oil
> Mixture ratio petrol/oil : 40:1
> Specic fuel consumption at max. engine power : 490 g/kWh
> Fuel consumption at max. engine power :0,6kg/h
Engine
> Engine model : 1E40F-5
> Engine type :aircooled,2-strokeengine
> Engine displacement : 42.7 cm3
> Engine idling speed : 3000±400 min-1
> Maximum operating engine speed : 10500 min-1
> Maximum engine power : 1.25 kW
> Spark plug type : L8RTF
> Spark plug gap : 0.6-0.7 mm
Drilling tool
> Drilling diameter :Ø100mm,Ø150mm
> Drilling depth : 800 mm
> Max. drilling speed : 350 r/min
Sound level
> Sound pressure level LpA : 105.6 dB(A)
> Uncertainty KpA : 3 dB(A)
> Sound power level LWA : 109.4 dB(A)
> Uncertainty KWA : 3 dB(A)
> Guaranteed sound power level LWA : 113 dB(A)
Hand arm vibration level
> Handle arm vibration ahW : left/right: 11.00/10.94 m/s2
> Uncertainty K : 1.5 m/s2
ThesoundvalueshavebeendeterminedaccordingtonoisetestcodegiveninENISO12100,usingthe
basic standards ISO 22868.
Wearhearingprotection,especiallywhensoundpressureisover80dB(A).
Thedeclaredvibrationvaluehasbeenmeasuredinaccordancewithastandardtestmethod(accordingto
ENISO22867)andmaybeusedforcomparingoneproductwithanother.Thedeclaredvibrationvaluemay
alsobeusedtoevaluatetheexposurefortheusercausedbyvibrationinadvance.
WARNING!Dependingontheactualuseoftheproductthevibrationvaluescan
differ from the declared total! Adopt proper measures to protect yourself against
vibrationexposures.Takethewholeworkprocessincludingtimestheproductis
running under no load or switched off into consideration.
Proper measures include among others regular maintenance and care of the
productandapplicationtools,keepinghandswarm,periodicalbreaksand
proper planning of work processes.
5063022059833_MNL_EN_V06.indd 195063022059833_MNL_EN_V06.indd 19 27 Sep 2023 17:06:0627 Sep 2023 17:06:06

20
EN Before you start
Unpacking
NOTE:Theproductisheavy,askanotherpersonforassistanceifrequired.
1. Unpackallpartsandlaythemonaat,stablesurface.
2. Removeallpackingmaterialsandshippingdevices,ifapplicable.
3. Makesurethedeliverycontentsarecompleteandfreeofanydamage.Ifyoundthatpartsaremissing
or show damage do not use the product but contact your dealer. Using an incomplete or damaged
product represents a hazard to people and property.
4. Ensurethatyouhavealltheaccessoriesandtoolsneededforassemblyandoperation.Thisalso
includessuitablepersonalprotectiveequipment.
WARNING! The product and the packaging are not children’s toys! Children
mustnotplaywithplasticbags,sheetsandsmallparts!Thereisadangerof
choking and suffocation!
You will need
(items not supplied)
Suitablepersonalprotectiveequipment
Petrol and engine oil
Fuelfunnelwithlter
Fuel collecting container
Lubrication oil/grease
(items supplied)
Drilling tool (Ø150 mm) (18)
Drilling tool (Ø100 mm) (19)
Fuel mixing bottle (20)
Hex key (T25) (21)
Hex key (T30) (22)
Spanner (8 / 10 mm) (23)
Spark plug wrench (24)
Screwdriver(25)
Assembly
WARNING! The product must be fully assembled before operation! Do not use
a product that is only partly assembled or assembled with damaged parts!
Followtheassemblyinstructionsstep-by-stepandusethepicturesprovidedas
avisualguidetoeasilyassembletheproduct!
Disconnect the spark plug connector (15) from the spark plug (15a)! Reconnect
it after assembly.
NOTE: Takecareofsmallpartsthatareremovedduringassemblyorwhen
makingadjustments.Keepthemsecuretoavoidloss.
Fitting the drilling tool
NOTE:Twodrillingtoolsareprovidedwithdifferentdrillingdiameter.Ensurethat
the required drilling tool (18/19) is correctly assembled before each use.
Re-assemble it if necessary.
5063022059833_MNL_EN_V06.indd 205063022059833_MNL_EN_V06.indd 20 27 Sep 2023 17:06:0627 Sep 2023 17:06:06
