Kings Brand Furniture D1005-T User manual

NOTE TO CUSTOMERS:
For ease and speed of assembly we recommend that before you commence each step of the
assembly that you identify all the parts required to complete that step.
We recommend that where possible you allow sufficient space to assemble the item as close
as possible to the place where it will be once assembled.
For the protection of your furniture we recommend that the product is placed on protected
surfaces during assembly to prevent any damage.
During assembly do not over tighten the screws or bolts, as this may damage the product.
Please ensure you retain all the product packaging until the item is completely assembled.
Periodically check all fitting and re-tighten as necessary.
Never allow any liquids to remain on your furniture as absorption can cause the wood to warp
or finish to de-laminate.
It is recommended that this item should be assembled by two adults.
ASSEMBLY INSTRUCTIONS
MODEL #D1005-T DINING TABLE
PAGE 1 OF 4

PAGE 2 OF 4
ASSEMBLY INSTRUCTIONS ITEM #D1005-T DINING TABLE
PARTS IDENTIFICATION
A- Table Top ( Carton A) 1 pc
B- Table Leg ( Carton B) 4 pcs
HARDWARE IDENTIFICATION
1- JCBB M8 x 60mm
2- Spring Washer M8
3- Flat Washer M8
NOTE: Quantities shown are for one table.
WARNING: Do Not over Tighten the bolts and screw.
8 pcs
8 pcs
8 pcs
STEP 1
4- Allen Key M5 1 pc
OPEN
Unlock the Catch Lock
LOCK
Relock the Catch Lock
Ø8mm
2 3/8 ”

PAGE 3 OF 4
ASSEMBLY INSTRUCTIONS ITEM #D1005-T DINING TABLE
STEP 3
STEP 2
X8
3
2
1
4
A
B

PAGE 4 OF 4
ASSEMBLY INSTRUCTIONS ITEM #D1005-T DINING TABLE
STEP 5
STEP 4
OPEN
Unlock the Catch Lock
LOCK
Relock the Catch Lock
OPEN
Unlock the Catch Lock
LOCK
Relock the Catch Lock
