KingsBottle KBU-56 SERIES User manual
www.kingsbottle.com
USER MANUAL
KBU-55, KBU-56, KBU-328 SERIES BEVERAGE COOLER
—- CAREL CONTROLLER —-
COMPRESSOR BEVERAGE COOLER
!
PLEASE NOTE: !
EVERY TIME THE UNIT IS POWERED ON, THERE WILL BE A 6 MINUTE DELAY FOR THE COMPRESSOR TO START.!
www.kingsbottle.com! 2
CONGRATULATIONS#
Congratulations and thank you for choosing
our KingsBottle beverage coolers . We are
sure you will find your new appliance a
pleasure to use . Before installing and
operating the beverage cooler, we
recommend that you read through this
manual which provides a description of your
beverage cooler and its functions .#
To avoid the risks that are always present
when you use an electric appliance, it is
important that the appliance is installed
correctly and that you read the safety
instructions carefully to avoid misuse and
hazards .#
We recommend that you keep this
instruction booklet for future reference and
pass it on to any future owners .#
After unpacking the appliance, please
inspect it to verify it is not damaged. If in
doubt, do not use the appliance but contact
us or your local customer care centre#
CONTENTS
TABLE OF CONTENTS
CHAPTER
CONTENTS
PAGE
Part I
Important Safety & Pre-Use Instructions
3
Part II
Diagram & Description of Beverage Cooler
4
Part III
Installation Instructions!
5-6
Part IV
Operating Your Beverage Cooler
7-8
Part V
Layout & Storage
9
Part VI
Care and Maintenance
10
Part VII
Troubleshooting Guide
11
Part VIII
Technical Data
12
Part IX
Warranty Information
12
COMPRESSOR BEVERAGE COOLER
www.kingsbottle.com! 3
PART I IMPORTANT SAFETY INSTRUCTIONS
Please read this user manual carefully and store in a handy
place for later reference . The symbols you will see in this
booklet have these meanings:#
This symbol indicates information concerning your personal safety
This symbol indicates information on how to avoid damaging the
appliance
This symbol indicates tips and information about use of the
appliance
This symbol indicates tips and information about economical and
ecological use of the appliance
TO REDUCE THE RISK OF FIRE, ELECTRICAL SHOCK,
OR INJURY WHEN USING YOUR APPLIANCE, FOLLOW
THESE BASIC PRECAUTIONS:
1. Read all instructions before using the beverage cooler.
2. DANGER or WARNING: Risk of child entrapment.
Child entrapment and suffocation are not only problems of the
past. Junked or abandoned appliances are still dangerous…
even if they will “just sit in the garage for a few days”.
3. Before you throw away your old beverage cooler:
•Take off the door.
•Leave the Shelves in pieces so that children may not
climb inside easily.
4. Never allow children to operate, play with, or crawl inside
the appliance.
1. The beverage cooler must be plugged into its own
dedicated 110-115V, 50/60Hz AC electrical outlet .
2. The plug must be accessible when the cooler is in
position.
3. It is essential the power point is properly grounded .
Consult a qualified electrician if you are unsure .
4. Don’t use extension cords or adapter plugs with this
cooler .
5. If the power cord is damaged, have it replaced by a
qualified service technician .
6. Unplug the cooler before cleaning it, or changing the light
bulb to avoid electric shock .
7. Never clean appliance parts with flammable fluids. The
fumes can create a fire hazard or explosion.
8. Never unplug the cooler by pulling the electrical cord as
this may damage it. Grip the plug firmly and pull straight
out .
9. Choose a location for your cooler that isn’t too cold . The
ambient room temperature should be above 50°F .
10. Stand your cooler in a dry place – avoid areas of high
moisture or humidity .
11. Don’t put the cooler in frosty or unprotected areas like a
garage or on the verandah .
12. Keep the cooler out of direct sunlight .
13. Don’t locate the cooler near stoves, fires or heaters .
14. Do not store in the vicinity of any other appliance. Do not
store near gasoline or any other flammable vapors. The
fumes can create a fire hazard or explosion.
15. When installed correctly, your cooler should:
•Have adequate space at the back and sides for air
circulation. (See Page 5)
•Be aligned to the surrounding cupboards .
•Have doors that will self-close from a partially open
position
16. Please inspect and clean the filter in front venting grill
every month. Failure to clean will void the warranty and
increase the running costs.
BEFORE USING YOUR BEVERAGE COOLER
1. Remove the exterior and interior packing.
2. Before connecting the beverage cooler to the power
source, let it stand upright for approximately 24 hours.
This will reduce the possibility of a malfunction in the
cooling system from handling during transportation.
3. Clean the interior surface with lukewarm water using a
soft cloth.
0LEASE¬READ¬THE¬USER¬MANUAL¬CAREFULLY¬AND¬STORE¬IN¬A¬HANDY¬
place for later reference.
The symbols you will see in this booklet have these meanings:
WARNING
6FGQQWK@MJGLBGA?RCQGLDMPK?RGMLAMLACPLGLEWMSPNCPQML?JQ?DCRW
CAUTION
6FGQQWK@MJGLBGA?RCQGLDMPK?RGMLMLFMURM?TMGBB?K?EGLERFC
?NNJG?LAC
TIPS & INFORMATION
6FGQQWK@MJGLBGA?RCQRGNQ?LBGLDMPK?RGML?@MSRSQCMDRFC?NNJG?LAC
ENVIRONMENTAL TIPS
6FGQQWK@MJGLBGA?RCQRGNQ?LBGLDMPK?RGML?@MSRCAMLMKGA?J?LB
CAMJMEGA?JSQCMDRFC?NNJG?LAC
Meanings of symbols used in this manual are shown below:
6FGQQWK@MJGLBGA?RCQLCTCPRMBMRFGQ
6FGQQWK@MJGLBGA?RCQ?JU?WQBMRFGQ
WARNING
s¬¬)F¬PRESSURISED¬AEROSOL¬CONTAINERS¬BEAR¬THE¬WORD¬
‘flammable’ and/or a small flame symbol,
do not store them inside any refrigerator or
freezer. If you do so you may cause an explosion.
s¬¬7HEN¬YOU¬DISPOSE¬OF¬YOUR¬OLD¬REFRIGERATORS¬AND¬FREEZERS¬
remove any doors. Children can suffocate if they get
trapped inside.
s¬¬4HIS¬APPLIANCE¬CONTAINS¬INSULATION¬FORMED¬WITH¬mAMMABLE¬
blowing gases. Avoid safety hazards by carefully
disposing of this appliance.
WARNING
The refrigerator must be plugged into its own
dedicated 220-240V, 50Hz AC electrical outlet.
The plug must be accessible when the refrigerator is
in position.
It is essential the power point is properly earthed to
ground.Consult a qualified electrician if you are unsure.
Don’t use extension cords or adapter plugs with this
refrigerator.
If the power cord is damaged, have it replaced by a
qualified service technician.
Unplug the refrigerator before cleaning it, or changing
the light bulb to avoid electric shock.
Never unplug the refrigerator by pulling the electrical
cord as this may damage it. Grip the plug firmly and
pull straight out.
Choose a location for your refrigerator that isn’t too cold.
The ambient room temperature should be above 10°C.
Stand your refrigerator in a dry place – avoid areas
of high moisture or humidity.
Don’t put the refrigerator in frosty or unprotected areas
like a garage or on the verandah.
Keep the refrigerator out of direct sunlight.
Don’t locate the refrigerator near stoves, fires or heaters.
When installed correctly, your refrigerator should:
– Have adequate space at the back and sides
for air circulation (refer to page 9).
– Be aligned to the surrounding cupboards.
– Have doors that will self-close from a partially
open position.
WARNING
4#4'(4+)'4#069#40+0)
This appliance may contain a small quantity of environmentally
friendly, but flammable, non-synthetic R600a refrigerant:
s¬¬%NSURE¬THAT¬THE¬TUBING¬OF¬THE¬REFRIGERANT¬CIRCUIT¬IS¬NOT¬
damaged during transportation and installation.
s¬4HE¬ROOM¬FOR¬INSTALLING¬APPLIANCE¬MUST¬BE¬AT¬LEAST¬M¬PER¬
8g of refrigerant. The amount of refrigerant charged in the
appliance can be found on the rating plate on the appliance.
s¬+EEP¬VENTILATION¬OPENINGS¬IN¬THE¬APPLIANCE¬ENCLOSURE¬OR¬
in the built-in structure, clear of obstruction.
s¬$O¬NOT¬USE¬MECHANICAL¬DEVICES¬OR¬OTHER¬MEANS¬TO¬
accelerate the defrosting process, other than those
recommended by the manufacturer.
s¬4HE¬ROOM¬FOR¬INSTALLING¬APPLIANCE¬MUST¬BE¬AT¬LEAST¬M3
per 8g of refrigerant. The amount of refrigerant charged
in the appliance can be found on the rating plate on
the appliance.
+/2146#065#('6;+05647%6+105
5#('6;
0LEASE¬READ¬THE¬USER¬MANUAL¬CAREFULLY¬AND¬STORE¬IN¬A¬HANDY¬
place for later reference.
The symbols you will see in this booklet have these meanings:
WARNING
6FGQQWK@MJGLBGA?RCQGLDMPK?RGMLAMLACPLGLEWMSPNCPQML?JQ?DCRW
CAUTION
6FGQQWK@MJGLBGA?RCQGLDMPK?RGMLMLFMURM?TMGBB?K?EGLERFC
?NNJG?LAC
TIPS & INFORMATION
6FGQQWK@MJGLBGA?RCQRGNQ?LBGLDMPK?RGML?@MSRSQCMDRFC?NNJG?LAC
ENVIRONMENTAL TIPS
6FGQQWK@MJGLBGA?RCQRGNQ?LBGLDMPK?RGML?@MSRCAMLMKGA?J?LB
CAMJMEGA?JSQCMDRFC?NNJG?LAC
Meanings of symbols used in this manual are shown below:
6FGQQWK@MJGLBGA?RCQLCTCPRMBMRFGQ
6FGQQWK@MJGLBGA?RCQ?JU?WQBMRFGQ
WARNING
s¬¬)F¬PRESSURISED¬AEROSOL¬CONTAINERS¬BEAR¬THE¬WORD¬
‘flammable’ and/or a small flame symbol,
do not store them inside any refrigerator or
freezer. If you do so you may cause an explosion.
s¬¬7HEN¬YOU¬DISPOSE¬OF¬YOUR¬OLD¬REFRIGERATORS¬AND¬FREEZERS¬
remove any doors. Children can suffocate if they get
trapped inside.
s¬¬4HIS¬APPLIANCE¬CONTAINS¬INSULATION¬FORMED¬WITH¬mAMMABLE¬
blowing gases. Avoid safety hazards by carefully
disposing of this appliance.
WARNING
The refrigerator must be plugged into its own
dedicated 220-240V, 50Hz AC electrical outlet.
The plug must be accessible when the refrigerator is
in position.
It is essential the power point is properly earthed to
ground.Consult a qualified electrician if you are unsure.
Don’t use extension cords or adapter plugs with this
refrigerator.
If the power cord is damaged, have it replaced by a
qualified service technician.
Unplug the refrigerator before cleaning it, or changing
the light bulb to avoid electric shock.
Never unplug the refrigerator by pulling the electrical
cord as this may damage it. Grip the plug firmly and
pull straight out.
Choose a location for your refrigerator that isn’t too cold.
The ambient room temperature should be above 10°C.
Stand your refrigerator in a dry place – avoid areas
of high moisture or humidity.
Don’t put the refrigerator in frosty or unprotected areas
like a garage or on the verandah.
Keep the refrigerator out of direct sunlight.
Don’t locate the refrigerator near stoves, fires or heaters.
When installed correctly, your refrigerator should:
– Have adequate space at the back and sides
for air circulation (refer to page 9).
– Be aligned to the surrounding cupboards.
– Have doors that will self-close from a partially
open position.
WARNING
4#4'(4+)'4#069#40+0)
This appliance may contain a small quantity of environmentally
friendly, but flammable, non-synthetic R600a refrigerant:
s¬¬%NSURE¬THAT¬THE¬TUBING¬OF¬THE¬REFRIGERANT¬CIRCUIT¬IS¬NOT¬
damaged during transportation and installation.
s¬4HE¬ROOM¬FOR¬INSTALLING¬APPLIANCE¬MUST¬BE¬AT¬LEAST¬M¬PER¬
8g of refrigerant. The amount of refrigerant charged in the
appliance can be found on the rating plate on the appliance.
s¬+EEP¬VENTILATION¬OPENINGS¬IN¬THE¬APPLIANCE¬ENCLOSURE¬OR¬
in the built-in structure, clear of obstruction.
s¬$O¬NOT¬USE¬MECHANICAL¬DEVICES¬OR¬OTHER¬MEANS¬TO¬
accelerate the defrosting process, other than those
recommended by the manufacturer.
s¬4HE¬ROOM¬FOR¬INSTALLING¬APPLIANCE¬MUST¬BE¬AT¬LEAST¬M3
per 8g of refrigerant. The amount of refrigerant charged
in the appliance can be found on the rating plate on
the appliance.
+/2146#065#('6;+05647%6+105
5#('6;
0LEASE¬READ¬THE¬USER¬MANUAL¬CAREFULLY¬AND¬STORE¬IN¬A¬HANDY¬
place for later reference.
The symbols you will see in this booklet have these meanings:
WARNING
6FGQQWK@MJGLBGA?RCQGLDMPK?RGMLAMLACPLGLEWMSPNCPQML?JQ?DCRW
CAUTION
6FGQQWK@MJGLBGA?RCQGLDMPK?RGMLMLFMURM?TMGBB?K?EGLERFC
?NNJG?LAC
TIPS & INFORMATION
6FGQQWK@MJGLBGA?RCQRGNQ?LBGLDMPK?RGML?@MSRSQCMDRFC?NNJG?LAC
ENVIRONMENTAL TIPS
6FGQQWK@MJGLBGA?RCQRGNQ?LBGLDMPK?RGML?@MSRCAMLMKGA?J?LB
CAMJMEGA?JSQCMDRFC?NNJG?LAC
Meanings of symbols used in this manual are shown below:
6FGQQWK@MJGLBGA?RCQLCTCPRMBMRFGQ
6FGQQWK@MJGLBGA?RCQ?JU?WQBMRFGQ
WARNING
s¬¬)F¬PRESSURISED¬AEROSOL¬CONTAINERS¬BEAR¬THE¬WORD¬
‘flammable’ and/or a small flame symbol,
do not store them inside any refrigerator or
freezer. If you do so you may cause an explosion.
s¬¬7HEN¬YOU¬DISPOSE¬OF¬YOUR¬OLD¬REFRIGERATORS¬AND¬FREEZERS¬
remove any doors. Children can suffocate if they get
trapped inside.
s¬¬4HIS¬APPLIANCE¬CONTAINS¬INSULATION¬FORMED¬WITH¬mAMMABLE¬
blowing gases. Avoid safety hazards by carefully
disposing of this appliance.
WARNING
The refrigerator must be plugged into its own
dedicated 220-240V, 50Hz AC electrical outlet.
The plug must be accessible when the refrigerator is
in position.
It is essential the power point is properly earthed to
ground.Consult a qualified electrician if you are unsure.
Don’t use extension cords or adapter plugs with this
refrigerator.
If the power cord is damaged, have it replaced by a
qualified service technician.
Unplug the refrigerator before cleaning it, or changing
the light bulb to avoid electric shock.
Never unplug the refrigerator by pulling the electrical
cord as this may damage it. Grip the plug firmly and
pull straight out.
Choose a location for your refrigerator that isn’t too cold.
The ambient room temperature should be above 10°C.
Stand your refrigerator in a dry place – avoid areas
of high moisture or humidity.
Don’t put the refrigerator in frosty or unprotected areas
like a garage or on the verandah.
Keep the refrigerator out of direct sunlight.
Don’t locate the refrigerator near stoves, fires or heaters.
When installed correctly, your refrigerator should:
– Have adequate space at the back and sides
for air circulation (refer to page 9).
– Be aligned to the surrounding cupboards.
– Have doors that will self-close from a partially
open position.
WARNING
4#4'(4+)'4#069#40+0)
This appliance may contain a small quantity of environmentally
friendly, but flammable, non-synthetic R600a refrigerant:
s¬¬%NSURE¬THAT¬THE¬TUBING¬OF¬THE¬REFRIGERANT¬CIRCUIT¬IS¬NOT¬
damaged during transportation and installation.
s¬4HE¬ROOM¬FOR¬INSTALLING¬APPLIANCE¬MUST¬BE¬AT¬LEAST¬M¬PER¬
8g of refrigerant. The amount of refrigerant charged in the
appliance can be found on the rating plate on the appliance.
s¬+EEP¬VENTILATION¬OPENINGS¬IN¬THE¬APPLIANCE¬ENCLOSURE¬OR¬
in the built-in structure, clear of obstruction.
s¬$O¬NOT¬USE¬MECHANICAL¬DEVICES¬OR¬OTHER¬MEANS¬TO¬
accelerate the defrosting process, other than those
recommended by the manufacturer.
s¬4HE¬ROOM¬FOR¬INSTALLING¬APPLIANCE¬MUST¬BE¬AT¬LEAST¬M3
per 8g of refrigerant. The amount of refrigerant charged
in the appliance can be found on the rating plate on
the appliance.
+/2146#065#('6;+05647%6+105
5#('6;
0LEASE¬READ¬THE¬USER¬MANUAL¬CAREFULLY¬AND¬STORE¬IN¬A¬HANDY¬
place for later reference.
The symbols you will see in this booklet have these meanings:
WARNING
6FGQQWK@MJGLBGA?RCQGLDMPK?RGMLAMLACPLGLEWMSPNCPQML?JQ?DCRW
CAUTION
6FGQQWK@MJGLBGA?RCQGLDMPK?RGMLMLFMURM?TMGBB?K?EGLERFC
?NNJG?LAC
TIPS & INFORMATION
6FGQQWK@MJGLBGA?RCQRGNQ?LBGLDMPK?RGML?@MSRSQCMDRFC?NNJG?LAC
ENVIRONMENTAL TIPS
6FGQQWK@MJGLBGA?RCQRGNQ?LBGLDMPK?RGML?@MSRCAMLMKGA?J?LB
CAMJMEGA?JSQCMDRFC?NNJG?LAC
Meanings of symbols used in this manual are shown below:
6FGQQWK@MJGLBGA?RCQLCTCPRMBMRFGQ
6FGQQWK@MJGLBGA?RCQ?JU?WQBMRFGQ
WARNING
s¬¬)F¬PRESSURISED¬AEROSOL¬CONTAINERS¬BEAR¬THE¬WORD¬
‘flammable’ and/or a small flame symbol,
do not store them inside any refrigerator or
freezer. If you do so you may cause an explosion.
s¬¬7HEN¬YOU¬DISPOSE¬OF¬YOUR¬OLD¬REFRIGERATORS¬AND¬FREEZERS¬
remove any doors. Children can suffocate if they get
trapped inside.
s¬¬4HIS¬APPLIANCE¬CONTAINS¬INSULATION¬FORMED¬WITH¬mAMMABLE¬
blowing gases. Avoid safety hazards by carefully
disposing of this appliance.
WARNING
The refrigerator must be plugged into its own
dedicated 220-240V, 50Hz AC electrical outlet.
The plug must be accessible when the refrigerator is
in position.
It is essential the power point is properly earthed to
ground.Consult a qualified electrician if you are unsure.
Don’t use extension cords or adapter plugs with this
refrigerator.
If the power cord is damaged, have it replaced by a
qualified service technician.
Unplug the refrigerator before cleaning it, or changing
the light bulb to avoid electric shock.
Never unplug the refrigerator by pulling the electrical
cord as this may damage it. Grip the plug firmly and
pull straight out.
Choose a location for your refrigerator that isn’t too cold.
The ambient room temperature should be above 10°C.
Stand your refrigerator in a dry place – avoid areas
of high moisture or humidity.
Don’t put the refrigerator in frosty or unprotected areas
like a garage or on the verandah.
Keep the refrigerator out of direct sunlight.
Don’t locate the refrigerator near stoves, fires or heaters.
When installed correctly, your refrigerator should:
– Have adequate space at the back and sides
for air circulation (refer to page 9).
– Be aligned to the surrounding cupboards.
– Have doors that will self-close from a partially
open position.
WARNING
4#4'(4+)'4#069#40+0)
This appliance may contain a small quantity of environmentally
friendly, but flammable, non-synthetic R600a refrigerant:
s¬¬%NSURE¬THAT¬THE¬TUBING¬OF¬THE¬REFRIGERANT¬CIRCUIT¬IS¬NOT¬
damaged during transportation and installation.
s¬4HE¬ROOM¬FOR¬INSTALLING¬APPLIANCE¬MUST¬BE¬AT¬LEAST¬M¬PER¬
8g of refrigerant. The amount of refrigerant charged in the
appliance can be found on the rating plate on the appliance.
s¬+EEP¬VENTILATION¬OPENINGS¬IN¬THE¬APPLIANCE¬ENCLOSURE¬OR¬
in the built-in structure, clear of obstruction.
s¬$O¬NOT¬USE¬MECHANICAL¬DEVICES¬OR¬OTHER¬MEANS¬TO¬
accelerate the defrosting process, other than those
recommended by the manufacturer.
s¬4HE¬ROOM¬FOR¬INSTALLING¬APPLIANCE¬MUST¬BE¬AT¬LEAST¬M3
per 8g of refrigerant. The amount of refrigerant charged
in the appliance can be found on the rating plate on
the appliance.
+/2146#065#('6;+05647%6+105
5#('6;
0LEASE¬READ¬THE¬USER¬MANUAL¬CAREFULLY¬AND¬STORE¬IN¬A¬HANDY¬
place for later reference.
The symbols you will see in this booklet have these meanings:
WARNING
6FGQQWK@MJGLBGA?RCQGLDMPK?RGMLAMLACPLGLEWMSPNCPQML?JQ?DCRW
CAUTION
6FGQQWK@MJGLBGA?RCQGLDMPK?RGMLMLFMURM?TMGBB?K?EGLERFC
?NNJG?LAC
TIPS & INFORMATION
6FGQQWK@MJGLBGA?RCQRGNQ?LBGLDMPK?RGML?@MSRSQCMDRFC?NNJG?LAC
ENVIRONMENTAL TIPS
6FGQQWK@MJGLBGA?RCQRGNQ?LBGLDMPK?RGML?@MSRCAMLMKGA?J?LB
CAMJMEGA?JSQCMDRFC?NNJG?LAC
Meanings of symbols used in this manual are shown below:
6FGQQWK@MJGLBGA?RCQLCTCPRMBMRFGQ
6FGQQWK@MJGLBGA?RCQ?JU?WQBMRFGQ
WARNING
s¬¬)F¬PRESSURISED¬AEROSOL¬CONTAINERS¬BEAR¬THE¬WORD¬
‘flammable’ and/or a small flame symbol,
do not store them inside any refrigerator or
freezer. If you do so you may cause an explosion.
s¬¬7HEN¬YOU¬DISPOSE¬OF¬YOUR¬OLD¬REFRIGERATORS¬AND¬FREEZERS¬
remove any doors. Children can suffocate if they get
trapped inside.
s¬¬4HIS¬APPLIANCE¬CONTAINS¬INSULATION¬FORMED¬WITH¬mAMMABLE¬
blowing gases. Avoid safety hazards by carefully
disposing of this appliance.
WARNING
The refrigerator must be plugged into its own
dedicated 220-240V, 50Hz AC electrical outlet.
The plug must be accessible when the refrigerator is
in position.
It is essential the power point is properly earthed to
ground.Consult a qualified electrician if you are unsure.
Don’t use extension cords or adapter plugs with this
refrigerator.
If the power cord is damaged, have it replaced by a
qualified service technician.
Unplug the refrigerator before cleaning it, or changing
the light bulb to avoid electric shock.
Never unplug the refrigerator by pulling the electrical
cord as this may damage it. Grip the plug firmly and
pull straight out.
Choose a location for your refrigerator that isn’t too cold.
The ambient room temperature should be above 10°C.
Stand your refrigerator in a dry place – avoid areas
of high moisture or humidity.
Don’t put the refrigerator in frosty or unprotected areas
like a garage or on the verandah.
Keep the refrigerator out of direct sunlight.
Don’t locate the refrigerator near stoves, fires or heaters.
When installed correctly, your refrigerator should:
– Have adequate space at the back and sides
for air circulation (refer to page 9).
– Be aligned to the surrounding cupboards.
– Have doors that will self-close from a partially
open position.
WARNING
4#4'(4+)'4#069#40+0)
This appliance may contain a small quantity of environmentally
friendly, but flammable, non-synthetic R600a refrigerant:
s¬¬%NSURE¬THAT¬THE¬TUBING¬OF¬THE¬REFRIGERANT¬CIRCUIT¬IS¬NOT¬
damaged during transportation and installation.
s¬4HE¬ROOM¬FOR¬INSTALLING¬APPLIANCE¬MUST¬BE¬AT¬LEAST¬M¬PER¬
8g of refrigerant. The amount of refrigerant charged in the
appliance can be found on the rating plate on the appliance.
s¬+EEP¬VENTILATION¬OPENINGS¬IN¬THE¬APPLIANCE¬ENCLOSURE¬OR¬
in the built-in structure, clear of obstruction.
s¬$O¬NOT¬USE¬MECHANICAL¬DEVICES¬OR¬OTHER¬MEANS¬TO¬
accelerate the defrosting process, other than those
recommended by the manufacturer.
s¬4HE¬ROOM¬FOR¬INSTALLING¬APPLIANCE¬MUST¬BE¬AT¬LEAST¬M3
per 8g of refrigerant. The amount of refrigerant charged
in the appliance can be found on the rating plate on
the appliance.
+/2146#065#('6;+05647%6+105
5#('6;
0LEASE¬READ¬THE¬USER¬MANUAL¬CAREFULLY¬AND¬STORE¬IN¬A¬HANDY¬
place for later reference.
The symbols you will see in this booklet have these meanings:
WARNING
6FGQQWK@MJGLBGA?RCQGLDMPK?RGMLAMLACPLGLEWMSPNCPQML?JQ?DCRW
CAUTION
6FGQQWK@MJGLBGA?RCQGLDMPK?RGMLMLFMURM?TMGBB?K?EGLERFC
?NNJG?LAC
TIPS & INFORMATION
6FGQQWK@MJGLBGA?RCQRGNQ?LBGLDMPK?RGML?@MSRSQCMDRFC?NNJG?LAC
ENVIRONMENTAL TIPS
6FGQQWK@MJGLBGA?RCQRGNQ?LBGLDMPK?RGML?@MSRCAMLMKGA?J?LB
CAMJMEGA?JSQCMDRFC?NNJG?LAC
Meanings of symbols used in this manual are shown below:
6FGQQWK@MJGLBGA?RCQLCTCPRMBMRFGQ
6FGQQWK@MJGLBGA?RCQ?JU?WQBMRFGQ
WARNING
s¬¬)F¬PRESSURISED¬AEROSOL¬CONTAINERS¬BEAR¬THE¬WORD¬
‘flammable’ and/or a small flame symbol,
do not store them inside any refrigerator or
freezer. If you do so you may cause an explosion.
s¬¬7HEN¬YOU¬DISPOSE¬OF¬YOUR¬OLD¬REFRIGERATORS¬AND¬FREEZERS¬
remove any doors. Children can suffocate if they get
trapped inside.
s¬¬4HIS¬APPLIANCE¬CONTAINS¬INSULATION¬FORMED¬WITH¬mAMMABLE¬
blowing gases. Avoid safety hazards by carefully
disposing of this appliance.
WARNING
The refrigerator must be plugged into its own
dedicated 220-240V, 50Hz AC electrical outlet.
The plug must be accessible when the refrigerator is
in position.
It is essential the power point is properly earthed to
ground.Consult a qualified electrician if you are unsure.
Don’t use extension cords or adapter plugs with this
refrigerator.
If the power cord is damaged, have it replaced by a
qualified service technician.
Unplug the refrigerator before cleaning it, or changing
the light bulb to avoid electric shock.
Never unplug the refrigerator by pulling the electrical
cord as this may damage it. Grip the plug firmly and
pull straight out.
Choose a location for your refrigerator that isn’t too cold.
The ambient room temperature should be above 10°C.
Stand your refrigerator in a dry place – avoid areas
of high moisture or humidity.
Don’t put the refrigerator in frosty or unprotected areas
like a garage or on the verandah.
Keep the refrigerator out of direct sunlight.
Don’t locate the refrigerator near stoves, fires or heaters.
When installed correctly, your refrigerator should:
– Have adequate space at the back and sides
for air circulation (refer to page 9).
– Be aligned to the surrounding cupboards.
– Have doors that will self-close from a partially
open position.
WARNING
4#4'(4+)'4#069#40+0)
This appliance may contain a small quantity of environmentally
friendly, but flammable, non-synthetic R600a refrigerant:
s¬¬%NSURE¬THAT¬THE¬TUBING¬OF¬THE¬REFRIGERANT¬CIRCUIT¬IS¬NOT¬
damaged during transportation and installation.
s¬4HE¬ROOM¬FOR¬INSTALLING¬APPLIANCE¬MUST¬BE¬AT¬LEAST¬M¬PER¬
8g of refrigerant. The amount of refrigerant charged in the
appliance can be found on the rating plate on the appliance.
s¬+EEP¬VENTILATION¬OPENINGS¬IN¬THE¬APPLIANCE¬ENCLOSURE¬OR¬
in the built-in structure, clear of obstruction.
s¬$O¬NOT¬USE¬MECHANICAL¬DEVICES¬OR¬OTHER¬MEANS¬TO¬
accelerate the defrosting process, other than those
recommended by the manufacturer.
s¬4HE¬ROOM¬FOR¬INSTALLING¬APPLIANCE¬MUST¬BE¬AT¬LEAST¬M3
per 8g of refrigerant. The amount of refrigerant charged
in the appliance can be found on the rating plate on
the appliance.
+/2146#065#('6;+05647%6+105
5#('6;
SAFETY
!
www.kingsbottle.com! 4
PART II"" DIAGRAM & DESCRIPTION OF BEVERAGE COOLER
FEATURES
Heated Glass Manual Control#
3 Modes: STRONG/OFF/WEAK
Heated Glass Manual Control#
3 Modes: STRONG/OFF/WEAK
Heated Glass Manual Control#
3 Modes: STRONG/OFF/WEAK
www.kingsbottle.com! 5
PART III"INSTALLATION INSTRUCTIONS
INSTALLATION
Installing Unit Into Under Counter
✦The unit is designed to be fully built Into
cabinets.
✦If the unit is on hardwood floor, we recommend
a rubber mat under the unit and some
polystyrene or sound proofing material on rear
wall of the opening to help deaden the noise.
✦Leave at least a 0.40-0.6” (10-15 mm) shadow
line around the unit and 2” (50mm) minimum at
rear to allow for the door swings and electrical
plug.
✦Place the unit out of sunlight, direct weather and
away from heating appliances.
✦Make sure that installation allows for the unit to
be removed, if required, as the condenser will
need periodic cleaning and to allow for servicing
if necessary.
4
2-IMPORTANT SAFETY INSTRUCTIONS
WARNING To reduce the risk of fire, electrical shock, or injury when
using your appliance, follow these basic precautions:
Read all instructions before using the bar fridge
Do not attempt to touch any working or electrical parts during operation, apart from main control panel.
Never allow children to operate, play with, or crawl inside the appliance.
Never clean appliance parts with flammable fluids.
Don’t clean S/Steel parts with any citrus style cleaners, special SS cleaner or hot water is best
Do not store or use gasoline or any other flammable vapors in the vicinity or any other appliance. The fumes
can create a fire hazard or explosion.
-Save these instructions-
3-INSTALLATION INSTRUCTIONS
Installation diagram for the built-in models
Installing unit into cavity
*Unit is designed to be Fully Built Into cavity, no ventilation
is required.
*If units on hardwood floor we recommend a rubber mat
under unit and some polystyrene or sound proofing material
on rear cavity wall to help a little deaden noise.
*Leave at least a 10-15mm ‘shadow line’ around unit and
50mm at rear minimum to allow for door swings and
electrical plug.
*Just use common sense, place out of sunlight, direct
weather and away from heating appliances.
*Make sure that installation allows for unit to be removed if
required, as condenser will need periodic cleaning and also
to allow for servicing in the event of break down.
4
2-IMPORTANT SAFETY INSTRUCTIONS
WARNING To reduce the risk of fire, electrical shock, or injury when
using your appliance, follow these basic precautions:
Read all instructions before using the bar fridge
Do not attempt to touch any working or electrical parts during operation, apart from main control panel.
Never allow children to operate, play with, or crawl inside the appliance.
Never clean appliance parts with flammable fluids.
Don’t clean S/Steel parts with any citrus style cleaners, special SS cleaner or hot water is best
Do not store or use gasoline or any other flammable vapors in the vicinity or any other appliance. The fumes
can create a fire hazard or explosion.
-Save these instructions-
3-INSTALLATION INSTRUCTIONS
Installation diagram for the built-in models
Installing unit into cavity
*Unit is designed to be Fully Built Into cavity, no ventilation
is required.
*If units on hardwood floor we recommend a rubber mat
under unit and some polystyrene or sound proofing material
on rear cavity wall to help a little deaden noise.
*Leave at least a 10-15mm ‘shadow line’ around unit and
50mm at rear minimum to allow for door swings and
electrical plug.
*Just use common sense, place out of sunlight, direct
weather and away from heating appliances.
*Make sure that installation allows for unit to be removed if
required, as condenser will need periodic cleaning and also
to allow for servicing in the event of break down.
24.43”
33.13”
22.26”
23.44”
21.47”
32.31”
36.05”
34.08”
22.06”
35.46”
21.47”
33.88”
4
2-IMPORTANT SAFETY INSTRUCTIONS
WARNING To reduce the risk of fire, electrical shock, or injury when
using your appliance, follow these basic precautions:
Read all instructions before using the bar fridge
Do not attempt to touch any working or electrical parts during operation, apart from main control panel.
Never allow children to operate, play with, or crawl inside the appliance.
Never clean appliance parts with flammable fluids.
Don’t clean S/Steel parts with any citrus style cleaners, special SS cleaner or hot water is best
Do not store or use gasoline or any other flammable vapors in the vicinity or any other appliance. The fumes
can create a fire hazard or explosion.
-Save these instructions-
3-INSTALLATION INSTRUCTIONS
Installation diagram for the built-in models
Installing unit into cavity
*Unit is designed to be Fully Built Into cavity, no ventilation
is required.
*If units on hardwood floor we recommend a rubber mat
under unit and some polystyrene or sound proofing material
on rear cavity wall to help a little deaden noise.
*Leave at least a 10-15mm ‘shadow line’ around unit and
50mm at rear minimum to allow for door swings and
electrical plug.
*Just use common sense, place out of sunlight, direct
weather and away from heating appliances.
*Make sure that installation allows for unit to be removed if
required, as condenser will need periodic cleaning and also
to allow for servicing in the event of break down.
34.08”
22.06”
53.19”
52.60”
21.47”
33.88”
KBU-55
KBU-56
KBU-328
www.kingsbottle.com! 6
PART III"INSTALLATION INSTRUCTIONS
INSTALLATION
INSTALLING YOUR BEVERAGE COOLER
1. Move the unit into its final position .
2. If the unit is not tilting back, minor adjustments can be made to the leveling legs.
3. Compare the alignment of the appliance to the surrounding cupboard . The top of the appliance should be level from side to side
(see diagram below) .
4. If the unit now rocks from one corner to the opposite rear corner, this means that the floor is uneven. You may need to put some
packing under the ridge to the rear of the appliance . You could use thin pieces of solid material such as thin board, vinyl floor tiles or
laminate .
5. You may now need to fine tune the installation by repeating steps 2, 3 and 4 .
6. Wipe off any dust that has accumulated during shipping and clean following the directions in Part VI ( Care & Maintenance)
7. Plug the appliance into the power point. Don’t use a double adaptor or extension cord .
8. It is recommended that you let the unit for rest an hour or two before you put any beverages in it . This will confirm that it is operating
correctly and make the conditions appropriate for beverage storage .
Congratulations! You have successfully installed your beverage cooler.
DOOR LOCK
This unit comes with an optional key lock. The keys are located inside the plastic bag that contains the user manual. To lock the door,
simply reverse the operation making sure the metal pin is engaged completely. Then remove the key and place it in a secure place for
safekeeping. To unlock the door, insert the key into the lock and turn counterclockwise.
#&'37#6'8'06+.#6+10#4170&;1744'(4+)'4#614
Before you move your appliance into the place where it
will operate, check that it will have adequate clearance.
Clearance is required for air circulation and too little
clearance may affect the performance of your appliance.
We recommend minimum clearances of:
s¬MM¬ON¬EACH¬SIDE
s¬MM¬ABOVE¬THE¬REFRIGERATOR
s¬MM¬MINIMUMMM¬MAXIMUM¬BEHIND¬THE¬REFRIGERATOR
NOTE:
Doors are designed to sit proud of cabinetry (not flush).
The clearances shown above are the recommended
minimum clearances. The clearance at the rear must not
exceed 75mm.
+056#..+0);1744'(4+)'4#61414(4''<'4
The appliance should arrive with the front levelling feet
wound up. The appliance may need to be tilted backward
at the top by about 10-15mm from vertical (see diagram
below). This will allow the door to gravitate to the closed
position. The complete closure of the door seal is reliant on
manually pushing the door closed to provide a consistent
door seal.
CAUTION
The rollers are designed for forward or backward movement
only.They are not castors. Moving the refrigerator sideways
may damage your floor and the rollers.
+056#..+0);1740'9#22.+#0%'
1. Move the appliance into its final position.
2. If the appliance is not tilting back as described earlier,
minor adjustments can be made to the two front
levelling legs by turning the feet in an anticlockwise
direction (below). This will increase the height of
the feet. If you have difficulty turning the foot, have
someone tilt the appliance back to gain better access.
If it is not tilted back enough and the levelling legs are
fully extended, additional packing might be required
(see note 4 for appropriate materials).
3. Compare the alignment of the appliance to the
surrounding cupboard. The top of the appliance should
be level from side to side (see diagram below). If
you need to adjust the level, use the levelling feet as
detailed in step 2.
4. If the appliance now rocks from one corner to the
opposite rear corner, this means that the floor is uneven.
You may need to put some packing under the ridge to
the rear of the appliance. You could use thin pieces of
solid material such as thin board, vinyl floor tiles
or laminate.
5. You may now need to fine tune the installation by
repeating steps 2, 3 and 4.
6. Wipe off any dust that has accumulated during shipping
and clean following the directions on page 17.
¬ 0LUG¬THE¬APPLIANCE¬INTO¬THE¬POWER¬POINT¬$ONT¬USE¬A¬
double adaptor or extension cord.
8. It is recommended that you let the appliance for an hour
or two (three hours for a freezer) before you put any
food in it. This will confirm that it is operating correctly
and make the conditions appropriate for food storage.
Congratulations! You have successfully installed your
refrigerator/freezer.
10 –15mm
Height adjustable
front rollers
+056#..#6+10
50mm (75mm max)
30mm
30mm
Recommended
airspace
CABINET
DOOR
COMPRESSOR BEVERAGE COOLER
www.kingsbottle.com! 7
OPERATION
PART IV"OPERATING YOUR REFRIGERATOR
This KingsBottle Refrigerator series comes with the worlds best quality controller from CAREL. Before using your Refrigerator, please read these
instructions carefully .
LEDS AND ASSOCIATED FUNCTIONS:
!
1. COMPRESSOR
2. FAN
3. DEFROST
4. ALARM
5. FIGURE
DISPLAY:
1. Increase the value;
2. Holding the button for at least 3
seconds, powers the unit ON or OFF.
1.Decrease the value;
2. Holding the button for half a second
turns the interior light ON or OFF.
1. Use SET after selecting values with the
up and down arrows
2. alarm mute button.
UP/POWER
DOWN/LIGHT
SET/MUTE
KEYBOARD:
HEATED GLASS FUNCTION
Electrically glass doors are coated with a transparent conductive film on the glass.
With the power on, the glass heats to prevent the"formation of water droplets on the
outer surface. The heated function starts and stops"when the compressor operates,
unit has 3 x"modes (Strong / Off / Weak) so you can adjust if needed as some places
are higher in humidity and more subject to condensation."Surface temperature is only
80-93F (27-34°C) , it must be kept away from rain and weather.
ADJUST TEMPERATURE
1. Press the “SET / MUTE” button for more than 3
seconds until the display shows the code ST ( st )
2. Use the “UP” and “DOWN” buttons to adjust the
temperature.
3. Press SET / MUTE button to save the setting. If no button is
pressed for 5 seconds, the changes of setting will be saved
automatically and the DISPLAY will show the actual
temperature..
www.kingsbottle.com! 8
""ON
Compressor
activation
request
""OFF
OPERATION
COMPRESSOR BEVERAGE COOLER
NOTE: The desired temperatures may fluctuate depending on whether the interior light is ON or OFF, the ambient temperature, the
location of unit and the orientation of the bottles. The display is just a guide, be guided by how cold your drinks are at consumption.
Remember units go into defrost mode and this will show a higher display, it’s only for short periods and doesn’t have time to effect drink
temperature. In general once unit has settled it will keep products within 5°F ( 2°C ) of the set temp easily in temperatures up to and
beyond 100°F ( 38°C ) . #
1. In the event of a power interruption, all previous temperature settings will be automatically saved and each compartment will return to the
previous temperature setting.
2. If the unit is unplugged, loses power, or is turned off, you must wait over 6 minutes before restarting. Within this 6 minutes, compressor
protect itself and will not start even power ON again
3. When you use the beverage cooler. for the first time or restart the beverage cooler after having been shut off for a long time, there will be a
few degrees variance between the temperature you select and the one indicated on the LED readout for the first few hours of operation.
After a few hours of operation, the temperature will normalize to the displayed temperature.
ALARM CODE
DESCRIPTION
LO
low temperature alarm
HI
high temperature alarm
E0
probe 1 error=control
E1
probe 2 error=defrost
E3
enter defrost status d12 twice continuously
dF
defrost running
dor
open door alarm
EE
unit parameter error
EF
operating parameter erro
TABLE OF ALARMS
0LEASE¬READ¬THE¬USER¬MANUAL¬CAREFULLY¬AND¬STORE¬IN¬A¬HANDY¬
place for later reference.
The symbols you will see in this booklet have these meanings:
WARNING
6FGQQWK@MJGLBGA?RCQGLDMPK?RGMLAMLACPLGLEWMSPNCPQML?JQ?DCRW
CAUTION
6FGQQWK@MJGLBGA?RCQGLDMPK?RGMLMLFMURM?TMGBB?K?EGLERFC
?NNJG?LAC
TIPS & INFORMATION
6FGQQWK@MJGLBGA?RCQRGNQ?LBGLDMPK?RGML?@MSRSQCMDRFC?NNJG?LAC
ENVIRONMENTAL TIPS
6FGQQWK@MJGLBGA?RCQRGNQ?LBGLDMPK?RGML?@MSRCAMLMKGA?J?LB
CAMJMEGA?JSQCMDRFC?NNJG?LAC
Meanings of symbols used in this manual are shown below:
6FGQQWK@MJGLBGA?RCQLCTCPRMBMRFGQ
6FGQQWK@MJGLBGA?RCQ?JU?WQBMRFGQ
WARNING
s¬¬)F¬PRESSURISED¬AEROSOL¬CONTAINERS¬BEAR¬THE¬WORD¬
‘flammable’ and/or a small flame symbol,
do not store them inside any refrigerator or
freezer. If you do so you may cause an explosion.
s¬¬7HEN¬YOU¬DISPOSE¬OF¬YOUR¬OLD¬REFRIGERATORS¬AND¬FREEZERS¬
remove any doors. Children can suffocate if they get
trapped inside.
s¬¬4HIS¬APPLIANCE¬CONTAINS¬INSULATION¬FORMED¬WITH¬mAMMABLE¬
blowing gases. Avoid safety hazards by carefully
disposing of this appliance.
WARNING
The refrigerator must be plugged into its own
dedicated 220-240V, 50Hz AC electrical outlet.
The plug must be accessible when the refrigerator is
in position.
It is essential the power point is properly earthed to
ground.Consult a qualified electrician if you are unsure.
Don’t use extension cords or adapter plugs with this
refrigerator.
If the power cord is damaged, have it replaced by a
qualified service technician.
Unplug the refrigerator before cleaning it, or changing
the light bulb to avoid electric shock.
Never unplug the refrigerator by pulling the electrical
cord as this may damage it. Grip the plug firmly and
pull straight out.
Choose a location for your refrigerator that isn’t too cold.
The ambient room temperature should be above 10°C.
Stand your refrigerator in a dry place – avoid areas
of high moisture or humidity.
Don’t put the refrigerator in frosty or unprotected areas
like a garage or on the verandah.
Keep the refrigerator out of direct sunlight.
Don’t locate the refrigerator near stoves, fires or heaters.
When installed correctly, your refrigerator should:
– Have adequate space at the back and sides
for air circulation (refer to page 9).
– Be aligned to the surrounding cupboards.
– Have doors that will self-close from a partially
open position.
WARNING
4#4'(4+)'4#069#40+0)
This appliance may contain a small quantity of environmentally
friendly, but flammable, non-synthetic R600a refrigerant:
s¬¬%NSURE¬THAT¬THE¬TUBING¬OF¬THE¬REFRIGERANT¬CIRCUIT¬IS¬NOT¬
damaged during transportation and installation.
s¬4HE¬ROOM¬FOR¬INSTALLING¬APPLIANCE¬MUST¬BE¬AT¬LEAST¬M¬PER¬
8g of refrigerant. The amount of refrigerant charged in the
appliance can be found on the rating plate on the appliance.
s¬+EEP¬VENTILATION¬OPENINGS¬IN¬THE¬APPLIANCE¬ENCLOSURE¬OR¬
in the built-in structure, clear of obstruction.
s¬$O¬NOT¬USE¬MECHANICAL¬DEVICES¬OR¬OTHER¬MEANS¬TO¬
accelerate the defrosting process, other than those
recommended by the manufacturer.
s¬4HE¬ROOM¬FOR¬INSTALLING¬APPLIANCE¬MUST¬BE¬AT¬LEAST¬M3
per 8g of refrigerant. The amount of refrigerant charged
in the appliance can be found on the rating plate on
the appliance.
+/2146#065#('6;+05647%6+105
5#('6;
www.kingsbottle.com! 9
YOUR CABINET WAS DESIGNED TO STORE A MAXIMUM NUMBER OF BOTTLES SECURELY. WE RECOMMEND THAT YOU
OBSERVE THE TIPS BELOW TO OPTIMIZE LOADING.
1. Disperse your bottles even so as not to concentrate weight in any one area. Also, be careful that your bottles do not touch either the
back of the cabinet or the step at the bottom.
2. Also make sure that bottles are not all grouped together either at the top or bottom of the cabinet.
3. A cooler that is full and has nice allowance for air movement will work more efficiently.
4. Never try to adjust shelf with bottles still on it.
How to use your shelving
•You can put the beer bottles on the shelving any way you like, lay down or upright.
•Max Weight per shelf: 55 lbs ( 25kgs )
•To adjust shelving, clips can be moved, place ‘top’ part of clip in first then force bottom part up. If clips seem loose, remove and
‘expand the width of opening on clip, this will allow it to fit better.
PART V"" LAYOUT AND STORAGE
STORAGE
PLEASE NOTE
Before modifying your cabinet’s original configuration in any way, be sure to ask your dealer for advice.
Important safety instructions . . . . . . . . . . . . . 3
Bar refrigerator with ice box features . . . . . . . . . 4
Bar refrigerator without ice box features . . . . . . . 5
Single door all refrigerator features . . . . . . . . . 6
Bar freezer features . . . . . . . . . . . . . . . . 7
Single door all freezer features . . . . . . . . . . . 8
Installing your new appliance . . . . . . . . . . . . 9
Ventilation around your appliance. . . . . . . . . 9
Installing your refrigerator . . . . . . . . . . . 9-10
Initial start-up . . . . . . . . . . . . . . . . . . . 10
Manual controls . . . . . . . . . . . . . . . . . . 10
Controlling the temperature. . . . . . . . . . . . 10
Using your appliance – Ice box models . . . . . . . . 11
Making ice . . . . . . . . . . . . . . . . . . 11
De-icing the ice box . . . . . . . . . . . . . . . 11
Freezer operation . . . . . . . . . . . . . . . . . 12
Reversing the ice box door opening direction . . . . . 13
Reversing the door opening direction WIM1000 &
WFM0700 . . . . . . . . . . . . . . . . . . . . 14
Reversing the door opening direction WIM1200,
WRM1300, WRM2400, WFM0900 & WFM1800 .15
Care and maintenance . . . . . . . . . . . . . . . .
Changing the light bulb . . . . . . . . . . . . . 16
General information . . . . . . . . . . . . . . . . 17
Cleaning the appliance . . . . . . . . . . . . . 17
Safety . . . . . . . . . . . . . . . . . . . . . 17
Switching off your appliance . . . . . . . . . . . 17
Troubleshooting . . . . . . . . . . . . . . . . . . 18
Warranty . . . . . . . . . . . . . . . . . . . . . 19
Congratulations and thank you for choosing our
refrigerator/freezer. We are sure you will find your new
appliance a pleasure to use. Before you use the appliance,
we recommend that you read through the relevant sections
of this manual, which provides a description of your
appliance and its functions.
To avoid the risks that are always present when you use
an electric appliance, it is important that the appliance is
installed correctly and that you read the safety instructions
carefully to avoid misuse and hazards.
We recommend that you keep this instruction booklet
for future reference and pass it on to any future owners.
After unpacking the appliance, please check it is not
damaged. If in doubt, do not use the appliance but contact
your local customer care centre.
TIPS & INFORMATION
+/2146#06h%*'%-(14#0;&#/#)'514/#4-5 If you find
the refrigerator is damaged or marked, you must report it
within 7 days if you wish to claim for damage/marks
under the manufacturers warranty. This does not affect
your statutory rights.
ENVIRONMENTAL TIPS
+0(14/#6+1010&+5215#.(1475'45
s¬¬-OST¬OF¬THE¬PACKING¬MATERIALS¬ARE¬RECYCLABLE¬0LEASE¬
dispose of those materials through your local recycling
depot or by placing them in appropriate collection
containers.
s¬¬)F¬YOU¬WISH¬TO¬DISCARD¬THIS¬PRODUCT¬PLEASE¬CONTACT¬
your local authorities and ask for the correct method
of disposal.
%106'065%10)4#67.#6+105
%106'065
7
DOOR LOCK
This unit comes with locks on all doors for preventative security.
The keys are located inside the plastic bag that contains the User Manual. To unlock the door, insert the key
into the lock and turn counterclockwise.
To lock the door, sim ply reverse the operation making sure the metal pin is engaged completely. Then remove
the key and place it is a secure place for safekeeping, one near fridge and one inside in safe location.
5-LAYOUT AND STORAGE
Yo ur c abine t was d es igned t o stor e a m axim um num ber of bottles in total security. We recommend that you observe the
tips below to optimize loading.
-Spread your bottles out as evenly as possible over the shelves, so that weight is not concentrated in one point, Also
make sure your bottles do not touch the back of the cabinet wall, or the step at bottom.
-Make sure that bottles are not all grouped together at the top or bottom of the cabinet.
-A fridge that is full and has nice allowance for air movement will work more efficiently.
-Never try to adjust shelf with bottles still on it.
PLEASE NOTE
Before modifying your cabinet’s original configuration in any way, be sure to ask your dealer for advice.
How to use your shelving
You can put the beer bott les on the shelving any way you like, lay down or upright.
Max Weight per shelf: 25kgs
To adjust shelving, clips can be m oved, place ‘top’ part of clip in first then force bottom part up.
If clips seem loose, remove and ‘expand the width of opening on clip, this will allow it to fit better.
!
www.kingsbottle.com! 10
CLEANING YOUR BEVERAGE COOLER
BEFORE CLEANING: Turn off the power, unplug the appliance, and remove all items including all shelves.
•Wash the inside surfaces with warm water and baking soda solution. The solution should be about 2 tablespoons of baking soda with a
quart of water.
•Wash the shelves with a mild detergent solution.
•Wring excess water out of the sponge or cloth when cleaning area of the controls, or any electrical parts.
•Wash the outside cabinet with warm water and mild liquid detergent. Rinse well and wipe dry with a clean soft cloth.
•After installation, we recommend that owners apply a thin layer of Olive Oil with a clean rag, to all exposed Stainless Steel
areas. This should then be polished in and buffed off with another clean rag to a non-oily finish. This process will aid protection against
dirt and other corrosive contaminants, by providing a temporary food-safe shield. The Olive Oil layer also makes later polishing and
removal of fingerprints easier. This process should be repeated frequently every 3-4 months. ALL stainless steel can rust, it is a myth that
stainless steel doesn’t rust.
POWER FAILURE
Most power failures are corrected within a few hours and should not affect the temperature of your appliance if you minimize the number of
times the door is opened. If the power is going to be off for a longer period of time, you need to take the proper steps to protect your
contents.
VACATION TIME
Short vacations: You may leave the beverage cooler operating during vacations of less than three weeks.
Long vacations: If the appliance will not be used for several months, remove all items and turn off the appliance. Clean and dry the interior
thoroughly. To prevent mold growth, leave the door open slightly, blocking it open if necessary.
MOVING YOUR BEVERAGE COOLER
1. Remove all items.
2. Securely tape down all loose items (shelves) inside your appliance.
3. Turn the adjustable leg up to the base to avoid damage.
4. Tape the door shut.
5. Be sure the appliance stays secure in the upright position during transportation. Also protect the outside of the appliance with a
blanket or similar item.
ENERGY SAVING TIPS
1. The beverage cooler should be located in the coolest area of the room, away from heat producing appliances, and away from direct
sunlight. Ventilation at rear also helps a lot with energy usage, so create a positive air flow where possible, although with this range they
are designed to be fully built in.
2. When you are not using fridge during weekdays etc. it is recommended to set the temp at a higher level, so set at 46°F ( 8°C ) during
periods of non usage, this will not only mean less run time, it also still keeps drinks at a temp that won’t be spoiled. It saves energy also
which these days is a growing concern for most households.
3. Keep the cooler stocked, an empty cooler will run longer, believe it or not.
0LEASE¬READ¬THE¬USER¬MANUAL¬CAREFULLY¬AND¬STORE¬IN¬A¬HANDY¬
place for later reference.
The symbols you will see in this booklet have these meanings:
WARNING
6FGQQWK@MJGLBGA?RCQGLDMPK?RGMLAMLACPLGLEWMSPNCPQML?JQ?DCRW
CAUTION
6FGQQWK@MJGLBGA?RCQGLDMPK?RGMLMLFMURM?TMGBB?K?EGLERFC
?NNJG?LAC
TIPS & INFORMATION
6FGQQWK@MJGLBGA?RCQRGNQ?LBGLDMPK?RGML?@MSRSQCMDRFC?NNJG?LAC
ENVIRONMENTAL TIPS
6FGQQWK@MJGLBGA?RCQRGNQ?LBGLDMPK?RGML?@MSRCAMLMKGA?J?LB
CAMJMEGA?JSQCMDRFC?NNJG?LAC
Meanings of symbols used in this manual are shown below:
6FGQQWK@MJGLBGA?RCQLCTCPRMBMRFGQ
6FGQQWK@MJGLBGA?RCQ?JU?WQBMRFGQ
WARNING
s¬¬)F¬PRESSURISED¬AEROSOL¬CONTAINERS¬BEAR¬THE¬WORD¬
‘flammable’ and/or a small flame symbol,
do not store them inside any refrigerator or
freezer. If you do so you may cause an explosion.
s¬¬7HEN¬YOU¬DISPOSE¬OF¬YOUR¬OLD¬REFRIGERATORS¬AND¬FREEZERS¬
remove any doors. Children can suffocate if they get
trapped inside.
s¬¬4HIS¬APPLIANCE¬CONTAINS¬INSULATION¬FORMED¬WITH¬mAMMABLE¬
blowing gases. Avoid safety hazards by carefully
disposing of this appliance.
WARNING
The refrigerator must be plugged into its own
dedicated 220-240V, 50Hz AC electrical outlet.
The plug must be accessible when the refrigerator is
in position.
It is essential the power point is properly earthed to
ground.Consult a qualified electrician if you are unsure.
Don’t use extension cords or adapter plugs with this
refrigerator.
If the power cord is damaged, have it replaced by a
qualified service technician.
Unplug the refrigerator before cleaning it, or changing
the light bulb to avoid electric shock.
Never unplug the refrigerator by pulling the electrical
cord as this may damage it. Grip the plug firmly and
pull straight out.
Choose a location for your refrigerator that isn’t too cold.
The ambient room temperature should be above 10°C.
Stand your refrigerator in a dry place – avoid areas
of high moisture or humidity.
Don’t put the refrigerator in frosty or unprotected areas
like a garage or on the verandah.
Keep the refrigerator out of direct sunlight.
Don’t locate the refrigerator near stoves, fires or heaters.
When installed correctly, your refrigerator should:
– Have adequate space at the back and sides
for air circulation (refer to page 9).
– Be aligned to the surrounding cupboards.
– Have doors that will self-close from a partially
open position.
WARNING
4#4'(4+)'4#069#40+0)
This appliance may contain a small quantity of environmentally
friendly, but flammable, non-synthetic R600a refrigerant:
s¬¬%NSURE¬THAT¬THE¬TUBING¬OF¬THE¬REFRIGERANT¬CIRCUIT¬IS¬NOT¬
damaged during transportation and installation.
s¬4HE¬ROOM¬FOR¬INSTALLING¬APPLIANCE¬MUST¬BE¬AT¬LEAST¬M¬PER¬
8g of refrigerant. The amount of refrigerant charged in the
appliance can be found on the rating plate on the appliance.
s¬+EEP¬VENTILATION¬OPENINGS¬IN¬THE¬APPLIANCE¬ENCLOSURE¬OR¬
in the built-in structure, clear of obstruction.
s¬$O¬NOT¬USE¬MECHANICAL¬DEVICES¬OR¬OTHER¬MEANS¬TO¬
accelerate the defrosting process, other than those
recommended by the manufacturer.
s¬4HE¬ROOM¬FOR¬INSTALLING¬APPLIANCE¬MUST¬BE¬AT¬LEAST¬M3
per 8g of refrigerant. The amount of refrigerant charged
in the appliance can be found on the rating plate on
the appliance.
+/2146#065#('6;+05647%6+105
5#('6;
PART VI"CARE AND MAINTENANCE
MAINTENANCE
COMPRESSOR BEVERAGE COOLER
www.kingsbottle.com! 11
TROUBLESHOOTING GUIDE
PROBLEM
POSSIBLE CAUSE
Solution
Cooler does not
operate
1. Not plugged in
2. The appliance is turned OFF at the control panel
3. The circuit breaker tripped or a fuse has blown out
Press ON/OFF
Check and make sure the power plug is well connected
Ask for help
Wine cooler is not cold
enough; can not
cooling down to preset
temp.
Compressor does not start
ask for help, check the connection of compressor
Compressor self-protected and stop operating
Ambient temperature is too high and over 38C degree
Air venting is not smooth, check the air duct and make sure it is not blocked
Fan operates slowly or faulty and stop operating.
Door is not closed completely, or door open for long time
Compressor or its components faulty
Fans stop working or low speed operating
Ask for help, power on the cooler, check the fan whether the voltage is normal or not. If
the voltage is normal, the fan should be damage
Evaporator ice up
Turn OFF the cooler for one hour, sometimes need also open the door, ice on
evaporator will melt. Then turn ON and check again.
Door is not well closed
Check the door lock, shelves, or other objects, make sure door is well closed.
Check the sealing rubber, make sure door is well sealed.
Check the door hinges, make sure they are not loose
Condenser is dusty
Wash and clean the condenser
Cooling system faulty (Gas leakage or blockage)
Ask for help
Compressor start and
stop frequently
The door gasket does not seal properly.
Use hair dryer to blow hot air and make the door seal smooth.
The sensor connection is wrong.
According to the wiring diagram and make the correct connection of sensor
The sensor is faulty.
Replace with new sensor
The door is opened too often.
Reduce the times / frequency of door opening.
The light does not
work.
Not plugged in, or the light button is “OFF”.
Light itself faulty.
Check and make sure the light button is ON, or ask for help.
The Cooler seems to
make too much noise.
The stand feet is not leveling, vibrations lead to noise
Adjust the stand feet and assure they are on level.
Pipe hit other objects and lead to noise
Adjust the position of pipe slightly
At the moment of compressor shut down or start, it is normal for the
noise from the vibration generated by the internal moving parts due to
inertial motion.
nothing is necessary
The ratting noise may come from the flow of the refrigerator, which is
normal. As each cycle ends, you may hear gurgling sounds
nothing is necessary
The door will not close
properly.
Door is blocked by the door lock, shelves, or other objects.
Remove the barrier
Door sealing rubber is deformed
Repair or replace the rubber seal
Door hinges are not loose.
Adjust and fasten the hinges.
Ice up
Outlet / suction outlet blockage
Remove the barrier
Fans stop working or low speed operating
Ask for help, power on the cooler, check the fan whether the voltage is normal or not. If
the voltage is normal, the fan should be damage
The door gasket does not seal properly;
or door is opened too often
Use hair dryer to blow hot air and make the door seal smooth.
Gas leakage or cooling system blockage
Ask for help
External cabinet seems
too hot
Ambient temperature is too high, or direct sunshine
Using conditions need to be improved
Front grill outlet / suction outlet blockage
Remove the barrier
Fans stop working or low speed operating
Ask for help, power on the cooler, check the fan whether the voltage is normal or not. If
the voltage is normal, the fan should be damage
Water drop on glass
door
Ambient humidity is high
Use a soft cloth to clean the water
Door is opened too often
Reduce the times / frequency of door opening.
The door gasket does not seal properly
Use hair dryer to blow hot air and make the door seal smooth.
Condensation is forming on outside of glass door
Have you turned the ‘Heated Door Function’ ON? located next to the temperature
controller. You shouldn’t have condensation on glass with these models if this function
is ON.
PART VII"TROUBLESHOOTING GUIDE
!
www.kingsbottle.com! 12
PART VIII"TECHNICAL DATA
TECHNICAL DATA
MODEL NO.
KBU-55
KBU-56
KBU-328
VOLUME
4.34 CF (123 Liter)
7.42 CF (210 Liter)
11.12 CF (315 Liter)
TYPE OF COOLING
compressor with air-circulated fan
cooling
compressor with air-circulated fan
cooling
compressor with air-circulated
fan cooling
CLIMATE TYPE
N / ST
N / ST
N / ST
ELECTRICITY PROTECTION
GRADE
I
I
I
NOMINAL VOLTAGE/
FREQUENCY
110-115V/50-60HZ
110-115V/50-60HZ
110-115V/50-60HZ
RATED POWER(W)
170W
210W
270W
AMBIENT TEMPERATURE
32 - 100 °F
32 - 100 °F
32 - 100 °F
TEMPERATURE RANGE
34-46 °F
34-46 °F
34-46 °F
Range of inside cabinet
humidity
>50%RH
>50%RH
>50%RH
NET WEIGHT
132.3Lbs (60Kgs)
165.3Lbs (75kgs)
264.6Lbs (120kgs)
GROSS WEIGHT
143.3Lbs (65Kgs)
180.7Lbs (82kgs)
286.6Lbs (130kgs)
DIMENSION
23.4”W x 21.5”D x 32.3”H
(595W x545D x820H mm)
35.4”W x 21.5”D x 33.9”H (900W
x545D x860H mm)
52.6”W x 21.5”D x 33.9”H
(1335W X 545D X 860H mm)
PART IX"WARRANTY INFORMATION
COMPRESSOR BEVERAGE COOLER
!
Please speak to your retailer before calling BTO AMERICA LIMITED (also known as KingsBottle USA) if you did not purchase your refrigerator directly from
BTO AMERICA LIMITED
Limited warranty – If your refrigerator is not operating properly, KingsBottle reserves the right to repair or replace the refrigerator. KingsBottle may request
the consumer to contact a local refrigeration company to service the refrigerator. All cost for labor and materials is covered for 2 year from the date of receipt.
If KingsBottle deems the unit not repairable, KingsBottle will use the value of your original order toward a replacement. For customer service, please contact
The limited warranty does not cover: Damage due to such things as accident, misuse, abuse, mishandling, neglect, unauthorized repair or any other
cause beyond the control of the seller whether similar or dissimilar to the foregoing. Purchaser understands and acknowledges that the goods sold here are
WINE & BEVERAGE COOLERS, which house beer and other wine s. Purchaser assumes all the risk of using these units, including risk of spoilage, humidity
variations, temperature variations, leaks, fires, water damage, mold, mildew, dryness and similar perils that may occur.
SPECIAL NOTE: Warranty is only honored for the unit which is purchased and used in United States of America. And, if your product was purchased at
any 3rd party retailer and not directly from KingsBottle, we do not offer an extended warranty policy. You MUST contact the retailer of purchase directly.
In the event your retailer does not offer an extended warranty plan, we recommend you contact a third party warranty provider. However, regardless of
point of purchase, all KingsBottle coolers are backed by a TWO YEAR manufacturer's warranty from date of sale.#
This manual suits for next models
2
Table of contents
Other KingsBottle Accessories manuals
