KingShield ACOMN User manual

Installation/Operating
Instructions for the
Carbon Monoxide Alarm
Model Ref: ACOMN
• AC/DC operated carbon onoxide alar
• Insect proof
• Test / Hush button
• High and stable sensitivity
• With quick fix ounting brackets for easy installation and si ple AC connector for easy installation
• Inter-connectable with up to 40 units
• Fitting and battery ta per-resist feature
• LED operation indicator
• Low-battery and battery issing warning indicator
• Auto reset after the CO clear
WHAT IS CARBON MONOXIDE?
Carbon Monoxide is a colourless, odorless and tasteless poison gas that can be fatal when
inhaled. CO binds to the hemoglobin in the blood and inhibits its capacity to carry oxygen. CO
kills hundreds of people each year and injures many more because it is difficult to detect with the
human senses. In high concentrations, CO can kill in minutes.
SOURCES OF CARBON MONOXIDE?
Inside your home, appliances used for heating and cooking are the most likely source of CO.
Vehicles running in attached garages can also produce dangerous levels of CO. CO can be
produced when burning any fossil fuel, such as gasoline, propane, natural gas, oil and wood. It
can be produced by any fuel-burning appliance that is malfunctioning, improperly installed, or not
ventilated correctly, such as:
• Cars, fires, gas ranges/stoves, gas clothes dryers, water heaters, portable fuel burning space
heaters and generators, fireplaces, wood-burning stoves and certain swimming pool heaters.
• Blocked chimneys or flues, back drafts and changes in air pressure, corroded or disconnected
vent pipes, loose or cracked fire exchangers.
• Vehicles and other combustion engines running in an open or closed garage, attached or near
the home.
• Burning charcoal or fuel in grills and BB s in an enclosed area.
Than you for purchasing a KingShield Carbon Monoxide Alarm
from GreenBroo Electrical. This alarm must be installed by a
competent person, using the following installation instructions.
KEEP THESE INSTRUCTIONS SAFE FOR FUTURE REFERENCE
SAFETY INFORMATION
ACOMN Instr ctions 15.10.13:Layo t 1 29/10/13 12:41 Page 1

The following conditions can result in transient CO situations:
• Excessive spillage or reverse venting of fuel-burning appliances caused by outdoor ambient
conditions, such as, wind direction and/or velocity, including high gusts of wind, heavy air in
the vent pipes (Cold/humid air with extended periods between cycles).
• Negative pressure resulting from the use of exhaust fans.
• Simultaneous operation of several fuel-burning appliances competing for limited internal air.
• Vent pipe connections vibrating loose from clothes dryers, fires or water heaters.
• Obstructions in, or unconventional vent pipe designs which can amplify the above situations.
• Extended operation of unvented fuel-burning devices (range, oven, fireplaces, etc.).
• Certain household materials such as cleaning fluids, polishes, paints and cooking operations
may affect the reliability of the alarm.
• Vehicle idling in an open or closed garage, or near a home.
To be safe, know the possible sources of CO in your home. Keep fuel-burning appliances and their
chimneys and vents in good working condition. Learn the early symptoms of exposure, and if you
suspect CO poisoning, move outside to fresh air and get emergency help.
Your first line of defence is an annual inspection and regular aintenance of your appliance. Contact a
licensed contractor or call your local utility co pany for assistance.
SYMPTOMS OF CO POISONING
35 ppm The maximum allowable concentration for continuous exposure for
healthy adults in any 8 hour period.
200 ppm Slight headaches, fatigue, dizziness, nausea after 2-3 hours.
400 ppm Frontal headaches within 1-2 hours, life threatening after 3hours.
800 ppm Dizziness, nausea and convulsions within 45 minutes. Unconsciousness
within 2hours and death within 3hours.
1600 ppm Headache, dizziness and nausea within 20 minutes. Death within 1hour.
6400 ppm Headache, dizziness and nausea within 1-2 minutes.
Death in less than 20 minutes
* PPM = parts per illion
The following symptoms related to CO POISONING and are to be discussed with all members of
the household:
Mild Exposure: Slight headache, nausea, vomiting, fatigue (often described as “flu-like”
symptoms).
Medium Exposure: Severe throbbing headache, drowsiness, confusion, fast heart rate.
Extreme Exposure: Unconsciousness, convulsions, cardio respiratory failure, death.
Many cases of reported Carbon Monoxide Poisoning indicates that while victims are aware they
are not well, they become so disoriented they are unable to save themselves by either leaving the
building or calling for assistance. Young children and household pets are typically the first
affected.
ACOMN Instr ctions 15.10.13:Layo t 1 29/10/13 12:41 Page 2

NOTE: The alarm may not fully safeguard against high risk groups with specific medical conditions.
Installation of your CO alarm is only one step in your safety plan. Educate yourself and family to the
sources and symptoms of CO poisoning and how to use your carbon monoxide alarm:
• Test your CO alarm weekly.
• Replace the battery when required.
• Buy appliances accepted by a recognised testing laboratory.
• Install the appliances properly, following the manufacturer’s instructions.
• Have installations done by professionals.
• Have your appliances checked regularly by a qualified serviceman.
• Clean chimneys and flues yearly.
• Make regular visual inspections of all fuel-burning appliances.
• Check appliances for excessive rust and scaling.
• Do not barbecue indoors, or in an attached garage.
• Open windows when a fireplace or wood burning stove is in use.
• Be aware of CO poisoning symptoms.
DO NOT:
• Burn charcoal inside your home, RV, camper, tent or cabin.
• Install, convert or service fuel burning appliances without proper knowledge, skill and expertise.
• Use a gas range, oven or clothes dryer for heating.
• Operate unvented gas burning appliances using kerosene or natural gas in closed room.
• Operate gasoline powered engines in doors or in confined areas.
• Ignore a safety device when it shuts an appliance off.
• Ignore any warning from your alarm.
Typical Single-Story Home
For minimum protection you should fit an alarm in the bedrooms or in the hallway of sleeping
areas. Place it as near to the sleeping areas as possible and ensure the alarm is audible when the
bedrooms are occupied.
IMPORTANT SAFEGUARDS
ALARM PLACEMENT
Single-Story Residence
ACOMN Instr ctions 15.10.13:Layo t 1 29/10/13 12:41 Page 3

Typical Multi-Story or Split Level Home
For minimum protection, you should fit at least one alarm on each floor/level.
Note: For maximum protection an alarm should be fitted in or near every room that contains a
fuel-burning appliance such as any central heating boilers, gas fires, room heaters, water heaters,
cookers, grills etc.
Apparatus located in the same room as a fuel-burning appliance:
If the apparatus is located on a wall:
a) It should be located close to the ceiling;
b) It should be located at a height greater than the height of any door or window
A ceiling mounted apparatus should be at least 300mm from any wall, and for a wall mounted apparatus
it should be at least 150mm from the ceiling.
The apparatus should be at a horizontal distance of between 1M and 3M from the potential source.
If there is a partition in a room, the apparatus should be located on the same side of the partition as the
potential source.
Carbon Monoxide alarms in rooms with sloped ceilings should be located at the high side of the room.
CAUTION: CO alarms can only sense CO that reaches the unit’s sensor. It’s possible that CO may be
present in other areas without reaching the alarm.
This carbon monoxide alarm is designed to detector carbon monoxide gas from ANY source of
combustion. It is NOT designed to detect smoke, fire or any other gas.
Apparatus located in sleeping rooms and in rooms remote from a fuel burning appliance:
Carbon Monoxide has a similar density to warm air and alarms can be fitted in various locations.
Apparatus located in sleeping rooms and in rooms remote from the fuel-burning appliance should
be located relatively close to the breathing zone of the occupants.
Improper location can affect the sensitive electronic components in this alarm. To avoid causing
damage to the unit, to provide optimum performance, and to prevent unnecessary nuisance
alarms:
Two-Story
Residence
Maximum Protection
Minimum Protection
ACOMN Instr ctions 15.10.13:Layo t 1 29/10/13 12:41 Page 4

Where not to install the apparatus
The apparatus should not be installed:
• In an enclosed space (for example in a cupboard or behind a curtain).
• Where it can be obstructed (for example by furniture).
• Directly above a sink.
• Next to a door or window.
• Next to an extractor fan.
• Next to an air vent or other similar ventilation openings.
• In an area where the temperature may drop below -10oC or exceed 40oC, unless it is designed to
do so.
• Where dirt and dust may block the sensor.
• In a damp or humid location.
• In the immediate vicinity of the cooking appliance.
WARNING: This CO alarm is designed for indoor use only. Do not expose to rain or moisture. It
will not protect against the risk of CO poisoning when the battery has drained. DO NOT open or
tamper with the alarm as this could cause malfunction.
This CO alarm can be installed either on the ceiling or the wall using the fixings provided.
DANGER: ELECTRIC SHOCK HA ARD
Turn off power at the main fuse box or circuit
breaker by removing the fuse or switching the circuit breaker to the OFF position. Do not tamper
with this alarm.
WARNING: This CO alarm is mains powered and requires wiring by a qualified electrician in
accordance with the current regulations for electrical installations. The circuit used to power the
CO alarm must be a dedicated permanent supply that cannot be switched off accidentally by the
normal user. Before installing ensure the electrical supply is isolated.
1. From the back of the CO alarm, remove the mounting plate by turning it counterclockwise.
(To later engage tamper-resist feature, twist out and set aside one of the pins moulded into
plate. Both pins are exactly the same).
2. Gently pull household wires through centre hole of plate.
3. Secure plate to ceiling or wall with mounting screws.
4. With a three way connector block, connect the brown wire from the connector plug to brown/red
household wire.
5. Connect blue wire from connector plug to blue/black household wire.
HOW TO INSTALL
ACOMN Instr ctions 15.10.13:Layo t 1 29/10/13 12:41 Page 5

INTERCONNECTING ALARM
OPERATING YOUR CO ALARM
Note: If this will be used as a single-station CO alarm, cover the yellow wire with electrical tape and
tuck it into the junction box.
7. Lift open battery pocket door.
8. Connect new 9V battery connector inside battery pocket. Be sure battery is securely
connected. CO alarm may beep briefly when battery installed.
9. Close battery pocket door, snapping it into place.
10. Attach connector plug to pins on back of CO alarm. Plug will only fit one way and will snap
into place.
11. Gently tug the connector to be sure it is attached securely.
12. Position CO alarm to mounting plate and turn clockwise to lock in place. To engage the
tamper-resist feature, insert the pin into the notch on the edge of CO alarm after the alarm is
properly positioned in the mounting plate.
Note: CO alarm will not mount to the plate if the battery is not installed.
13. Turn on power at main fuse box or circuit breaker.
14. Push test/silence button to test the alarm. See ‘TESTING’ section of these instructions for
more information.
For interconnecting line, only use 1.0mm2to 1.5mm2minimum solid or stranded wire. When being
interconnected, the maximum wire length between any two alarms is 1500 feet for 1.0mm2or 4000
feet for 1.5mm2(20 OHMS loop resistance).
This CO alarm can be interconnected with up to as many as 40 smoke, heat or carbon monoxide
alarms. Do not connect to any other type or model of alarm other than KingShield models.
This CO alarm is powered by 220-240VAC50Hz with 9V DC Battery back-up.
Inter connection voltage is 9V DC.
NORMAL OPERATION
When the CO alarm is under normal working operation in the clean air, the green LED will be on
when mains power is correctly connected and is also an indication that your alarm is in normal
function. The green LED will flash every one minute when mains power is cut off.
ALARM CONDITION
When the unit detects dangerous levels of CO, the Red LED flashes rapidly and the alarm sounds
loudly (repeating 4beeps and a pause). This will continue as long as there is a dangerous level of
ACOMN Instr ctions 15.10.13:Layo t 1 29/10/13 12:41 Page 6

CO present. Should the CO levels return to normal, the unit will stop beeping.
CO LEVEL RESPONSE TIME
(PPM) (MIN)
50 60-90
100 10-40
300 <3
WARNING: This product may not alarm at low carbon monoxide levels. Individuals with medical
problems may consider using warning devices which provide audible concentrations under 30
ppm.
HUSH FEATURE
The hush feature is for your convenience only and will not correct a CO problem. Always check
your home for a potential problem after any alarm. Failure to do so could result in injury or death.
NEVER remove the battery from your CO Alarm to silence the horn. Use the silence feature as
removing the battery stops your protection! See ‘WHAT TO DO IF ALARM SOUNDS’ section for
details on responding to an alarm.
The hush feature is intended to temporarily silence your alarm while you correct the problem - it
will not correct a CO problem. While the alarm is silenced, it will continue to monitor the air for
CO. when the CO reaches alarm levels the alarm will sound - repeating the horn pattern: 4beeps,
a pause, 4beeps, etc.
Press and hold the test/silence button until the horn is silent. The initial silence cycle will last
approximately 4minutes.
Note: After the initial 4minute silence cycle, the alarm re-evaluates present CO levels and
responds accordingly. If CO levels remain potentially dangerous or start rising higher the alarm
will start sounding again.
While the detector is silenced:
LOW BATTERY SIGNAL
The alarm indicates a low battery with a ‘chirp’ once every minute. This warning should last for
up to 30 days if untouched.
Note: With normal use the battery will last for 3year minimum. However, battery life will be
reduced if a fault occurs with the battery.
UNIT MALFUNCTION
Your CO alarm performs an internal self-diagnosis to make sure that it is functioning properly.
If the CO Alarm... This means...
Is silent for only 4
mins, then starts
sounding loudly
again (4beeps,
pause, 4beeps etc)
CO levels are still
potentially
dangerous.
Remains silent after
you pressed the
test/silence button
CO levels are
dropping.
ACOMN Instr ctions 15.10.13:Layo t 1 29/10/13 12:41 Page 7

If the unit has detected an error, there is a failure warning. The horn sounds 3short ‘chirps’ every
minute. Push and hold Test/Hush buton, Red LED is on. Release Test/Hush button, Red LED is off.
In case of the above failure warning happening, the CO alarm should be replaced to a new one.
If your CO alarm is beeping, and you are not sure if it is a CO alarm or a malfunction alert then
reset the alarm, open windows for ventilation and turn off fuel-burning appliance (like kerosene or
oil heaters, furnaces, wood-burning stoves, water heaters or other fossil-fuel burning appliances).
END OF LIFE WARNING
The horn sounds 2short ‘chirps’ following with 1long ‘chirp’ every minute. In case of the above
warning happened, the CO alarm is at the end of its life, and the CO alarm should be replaced to
a new one.
Never ignore a CO unit’s alarm. A true alarm is an indication of a potentially dangerous level of
carbon monoxide before an emergency, before most people would experience symptoms of carbon
monoxide poisoning, giving you time to resolve the problem calmly.
• Test your CO Alarm once a week. If the CO Alarm ever fails to test correctly, have it replaced
immediately. If the CO Alarm is not working properly, it cannot alert you to a problem.
• DO NOT stand close to the alarm when it is sounding. Exposure at close range may be harmful
to your hearing. When testing, step away when alarm starts sounding.
1. Push and hold the Test/Silence button on the cover until the LED flashes.
The alarm horn will sound 4beeps, a pause, then 4beeps. The red light will flash. The alarm
sequence should last 5-6 seconds.
2. If the alarm does not sound, give the alarm a clean using a vacuum cleaner to ensure it is
clean and dust free. Then install fresh 9V batteries and test the alarm again. If the unit still
does not alarm, replace it immediately.
WARNING:
• DO NOT try fixing the alarm yourself - this will invalidate your warranty.
TESTING
ACOMN Instr ctions 15.10.13:Layo t 1 29/10/13 12:41 Page 8

Your alarm will alert you to potentially hazardous CO concentrations in your home when
maintained properly. To maintain your alarm and keep it in proper working order, it is
recommended that you:
1. Test your alarm at least once a week.
2. Clean your CO alarm regularly to prevent dust build up. See the ‘CLEANING’ section of these
instructions.
3. The sensor in this alarm has a limited lifetime. See label on alarm for replacement date.
Always turn off the power supply to the CO alarm before replacing the battery. The unit requires
one standard 9V battery. The expected life of normal carbon-zinc 9V battery is one year maximum
under normal operation. The expected life of normal alkaline 9V battery is three years under
normal operation.
WARNING:
• Do not use any other type of battery, this unit uses 9V standard battery only.
• Do not use rechargeable batteries.
• An explosion will occur if the battery is incorrectly replaced.
1. Turn off AC power supply to the alarm.
2. Remove the tamperproof tab if fitted between the mounting plate and the alarm. Turn the alarm
counterclockwise to detach it from the mounting plate.
TESTING WITH CARBON MONOXIDE
MAINTAINING YOUR CO ALARM
REPLACING THE BATTERY
The unit checks for CO every 4seconds and as soon as it detects CO it flashes the red light (as per
Table A) to confirm that it is detecting CO gas.
The unit can be tested with CO by using a CO aerosal test spray can.
Follow the instructions on the kit. When it senses the CO, it will have a Pre-Alarming status, please
refer to Table A for all detailed alarming indicators:
CO Level
(ppm)
Pre-Alarming status:
(Red LED only without beep)
Response Time
(MIN)
Alarming
Red LED Indicator Alarming Horn
0ppm Off N/A Off Off
50 ppm 2Flashes / 4Seconds 60-90 4Flashes / 4Seconds 4Beeps / 4Seconds
100 ppm 3Flashes / 4Seconds 10-40 4Flashes / 4Seconds 4Beeps / 4Seconds
300 ppm 4Flashes / 4Seconds <3 4Flashes / 4Seconds 4Beeps / 4Seconds
CO Alarm Response
Table A
ACOMN Instr ctions 15.10.13:Layo t 1 29/10/13 12:41 Page 9

3. Gently pull the alarm down.
4. Remove battery from the compartment.
5. Insert a new 9-volt battery to the connector. NOTING THE POLARITY OF CONNECTIONS.
Ensure the metal tab is fully depressed when the battery has been fitted.
6. Using the Test/Silence button, test the alarm to verify 9V DC battery back-up. See ‘TESTING’
section of these instructions.
7. Reattach the CO alarm to the mounting plate by turning the alarm clockwise until it snaps into
place. Insert the tamperproof tab back into the notch on the edge of the alarm after the alarm
is properly positioned in the mounting plate.
8. Turn the power supply back on and test the alarm using the test/silence button. See ‘TESTING’
section of these instructions.
Note: If the unit fails to operate when being tested, please refer to the ‘TROUBLESHOOTING’
section of these instructions.
CO Alarm Replacement
CO Alarms don’t last indefinitely. CO Alarms are sophisticated electronic devices. Although the
alarm and it’s component parts have undergone stringent tests, and are designed to be very
reliable, it is possible that parts can fail. Therefore you should test your CO Alarm weekly. The CO
Alarm must be replaced in 3years or by the recommended replacement date, see label on the
underside of the unit.
Clean the CO alarm at least once a month to remove dust, dirt or debris.
Using the soft brush or wand attachment to a vacuum cleaner, clean all
sides and the cover of the alarm. Be sure all the vents are free from debris.
If necessary, use a damp cloth to clean the alarm cover.
IMPORTANT: Do not attempt to remove the cover to clean inside the
alarm as this will void your warranty.
CLEANING
WHAT TO DO IF ALARM SOUNDS
If your ACOMN initiates an alarm signal it is recommended that the following actions are taken in
the order given.
1. Keep calm and open all doors and windows to increase the rate of ventilation. Stop using all
fuel-burning appliances and ensure, if possible that they are turned off.
2. If the apparatus continues to operate, even after being reset (where appropriate) then evacuate
the premises. Leave the doors and windows open, and only re-enter the building to operate
periodically any reset facility until the alarm has stopped extreme care should be taken to
minimise personal risk. In multi-occupancy and multi-storey premises, ensure that all the
occupants are alerted to the risk.
3. Get medical help for anyone suffering the effects of carbon monoxide poisoning, and advise
that carbon monoxide inhalation is suspected.
4. Telephone the appropriate appliance servicing and/or maintenance agency or, when necessary,
the relevant fuel supplier on their emergency number, so that the source of carbon monoxide
emissions can be identified and corrected. Unless the reason for the alarm is obviously
ACOMN Instr ctions 15.10.13:Layo t 1 29/10/13 12:41 Page 10

TROUBLE SHOOTING
spurious, do not use the fuel-burning appliances again, until they have been checked and cleared
for use by a competent person to national regulations.
Trouble Shooting Guide
PROBLEM... THIS MEANS... YOU SHOULD...
The horn sounds 1short
‘chirp’ every minute Low battery warning Install new 9V battery
The horn sounds 3quick
‘chirps’ every minute
Malfunction signal. CO Alarm
needs to be replaced.
The CO alarm should be replaced
to a new one.
The horn sounds 2quick ‘chirps’
following with 1long ‘chirp’
Malfunction signal. CO Alarm
needs to be replaced
The CO alarm should be replaced
to a new one.
CO Alarm goes back into alarm 4
minutes after you press the
Test/Hush button.
CO levels indicate a potentially
dangerous situation.
IF YOU ARE FEELING SYMPTOMS
OF CO POISONING EVACUATE
your home and call the Fire
Department. If not, press the
Test/Hush button again and keep
ventilating your home.
CO Alarm sounds frequently even
though no high levels of CO are
revealed in an investigation.
The CO Alarm may be improperly
located. Refer to
‘CO ALARM PLACEMENT’
Relocate your alarm. If frequent
alarms continue, have home
rechecked for potential CO
problems. You may be experiencing
an intermittent CO problem.
This apparatus is designed to protect individuals from the acute effects of carbon monoxide
exposure. It will not fully safeguard individuals with specific medical conditions. If in doubt
consult a medical practitioner.
ACOMN Instr ctions 15.10.13:Layo t 1 29/10/13 12:41 Page 11

TECHNICAL DATA
ALARM RANGE
GUARANTEE
Your KingShield Alarm is guaranteed for 3years from the date of manufacture.
This does not affect your statutory rights.
Operating Temp: 5°C to 38°C
Electrical Rating: 220-240V AC 50Hz & 9V DC Battery Backup
Battery Backup: In event of a power loss the battery will give operation
for 3yrs under normal operating conditions.
Operation Current: <60mA operation (mains)
Alarm Sound Level: 85Db at 1M
Alarm Level: 50ppm (Between 60-90 min)
100ppm (Between 10-40 min) 300ppm (<3min)
Humidity Rating: 15% - 90% relative
Interconnect ty’s: Up to 40 GreenBrook Smoke/Heat/CO alarms can inter-connect.
Please note: This alarm can only be inter-connected with other GreenBrook alarms.
Conforms to: BS EN 50270:2006, BS EN 50291:2010, BS EN 61000-6-3:2007
Recommended replacement batteries - Alkaline type 9V battery
Interconnection voltage: 9V DC
Issue no: 703405
PLEASE KEEP THESE INSTRUCTIONS SAFE
FOR FUTURE REFERENCE
WEST ROAD . HARLOW
ESSEX . CM20 2BG . UK
sa le s@ gr ee nb ro ok .c o. uk
WW W.GREE NB RO OK.CO .U K
Our range of Alarms -
Mains Ionisation Smoke
Alarm Model: ASIM
Mains Photoelectric
Smoke Alarm Model: ASPM
Mains Carbon Monoxide
Alarm Model: ACOMN
Mains Heat Alarm
Model: AHPM
ACOMN Instr ctions 15.10.13:Layo t 1 29/10/13 12:41 Page 12
