Kingsman Marquis SOLACE User manual

SOLACE/SKYLINE
Installation Instructions
Model Numbers: MQHBZDV3636, MQHBZDV4236, MQRB4236, MQRB4236T, HBZDV4736
Stock #’s: MQHBZDV3636N, MQHBZDV3636LP, MQHBZDV4236N, MQRB4236N, MQHBZDV4236LP,
MQHBZDV3636NE, MQHBZDV3636LPE, MQHBZDV4236NE, MQRB4236NE, MQHBZDV4236LPE
Certified to: ANSI Z21.88-2014 • CSA 2.33-2014ZERO CLEARANCE VENTED GAS FIREPLACE HEATER
Stock #’s: MQRB4236NT, MQRB4236LPT, MQRB4236NTE, MQRB4236LPTE
HBZDV4736N, HBZDV4736LP,HBZDV4736NE, HBZDV4736LPE
Certified to: ANSI Z21.50-2014 • CSA 2.22-2014 ZERO CLEARANCE VENTED GAS FIREPLACE
A Division of R-Co. Inc.
2340 Logan Avenue
Winnipeg, Manitoba, Canada R2R 2V3
Ph: [phone]
Printed in Canada July 20, 2018
Part # 36MQ-MAN14
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
For Propane Horizontal installations the venting
must be a minimum of one foot vertical off the
flue before going horizontal.
This appliance may be installed in an
aftermarket, permanently located,
manufactured home (USA only) or mobile
home, where not prohibited by local codes.
This appliance is only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with
other gases, unless a certified kit is used.

Pre-installation Questions and Answers
About curing of the paint
Your stove or fireplace has been painted with the highest quality silicone stove paint. This paint dries quickly in 15-20
minutes when first applied at the factory. However, due to the high temperature silicone components, the paint will cure
when heat is applied to the appliance as it is first used. The following information applies to the curing process to get the
paint fully hard and durable.
Fire the appliance four successive times for 10 minutes each firing and a 5 minute cool down between each. Be aware
during log and firebox paint curing that a white deposit may be developing on the inside of the glass doors. It is important
to remove this white deposit from the glass doors using a fireplace glass cleaner.
Babies, small children, pregnant women and pets should leave the area during the cure phase.
Ventilate well, open doors and windows.
Do not touch during curing.
Why does my fireplace or stove give off odour?
It is normal for your fireplace to give off some odor at first. This is due to the curing of the paint, adhesives, silicones and
any undetected oil from the manufacturing process as well as the finishing materials used with the installations (e.g.
marble, tile and the adhesives used to adhere this product to the walls can react with heat and cause odours).
It is recommended that you burn your gas fireplace or stove for a minimum of four hours at a time with the fan off (if a fan
is present) after the curing of the paint has been completed. These odours can last upward to 40 hours of burn time; keep
burning at a minimum of four hours per use until odours dissipate.
Noise coming from the fireplace?
Noise is caused by the expansion and contraction of metal as the appliance heats up and cools down. This is normal and
is similar to the sounds produced by a furnace or heating duct. This noise does not affect the operation or longevity of
your fireplace.
It is also normal for the fan to make some noise when it comes on. This noise can be reduced somewhat by turning down
the speed of the fan with the variable speed control. Be aware, however, that this will reduce the volume of heated air
circulated into the room by the fan.
Note to the Installer:
Be sure appliance is working properly and its operation (including remote control operation, if included) is fully explained
to and understood by the customer.
Operating Instructions
1. Be sure to read and understand all the instructions in this manual before operation of appliance.
2. Ensure all wiring is correct and properly enclosed to prevent possible shock.
3. Check for gas leaks.
4. Make sure the glass door is properly installed before operation. Never operate the appliance with the glass door
removed.
5. Make sure venting and termination cap are installed and unobstructed.
6. If brick or porcelain liners are used, ensure they are installed.
7. Verify that the pilot can be seen when lighting the appliance. If not, the log or rock placement is incorrect.
8. If the unit is turned off, you must wait a minimum of 60 seconds before re-lighting it.
2

Table of Contents
Pre-installation Questions and Answers…………………………………...................................
2
Operating Instructions………………………………………………………..................................
2
Table of Contents……………………………………………………………..................................
3
Safety Screen Installation……………………………………………………………………………
4
Mobile Home/Manufactured Housing Installation…………………….......................................
5
Warnings, Installations, and Operations…………………………………...................................
6-7
Installation Requirements for the Commonwealth of Massachusetts…..................................
7
MQHBZDV3636
Locating your Appliance.............................................................................
8
Fireplace Dimensions.................................................................................
8
Framing for your Gas Fireplace..................................................................
9
Framing and Facing Requirements.............................................................
10
Installing Clean View Kit (CVCK)................................................................
11
Clearance to Combustibles.........................................................................
12
Parts List.....................................................................................................
12-13
Kingsman Fireplace Venting Parts..............................................................
13
MQHBZDV4236/MQRB4236
Locating your Appliance.............................................................................
14
Fireplace Dimensions.................................................................................
14
Framing for your Gas Fireplace..................................................................
15
Framing and Facing Requirements.............................................................
16
Installing Clean View Kit (CVCK)................................................................
17
Clearance to Combustibles.........................................................................
17
Parts List.....................................................................................................
18-19
Kingsman Fireplace Venting Parts.............................................................
19
HBZDV4736
Locating your Appliance.............................................................................
20
Fireplace Dimensions.................................................................................
20
Framing for your Gas Fireplace..................................................................
21
Framing and Facing Requirements.............................................................
22
Installing Clean View Kit (CVCK)................................................................
23
Clearance to Combustibles.........................................................................
23
Parts List.....................................................................................................
24-25
Kingsman Fireplace Venting Parts..............................................................
26
Clearance, Mantels & Surrounds.............................................................................................
26-27
Dimensions & Installations of Wall Mount Surrounds..............................................................
28
Fan Installation........................................................................................................................
29
Split Receptacle- Fan Speed Control Outside of Fireplace.....................................................
30
Installing MQRB4236 Liner Panels..........................................................................................
31
Brick Installation………………………………………………………………………………………
32
Installation of HB Porcelain Liners - HB36PL/HB42PL/HB47PL.............................................
33
Gas Line Installation................................................................................................................
34
Millivolt System, Lighting, and Burner Control.........................................................................
35
Trouble Shooting The Gas Control System.............................................................................
36
Burner System Removal for MQHB36/42/47...........................................................................
37
Burner System Maintenance...................................................................................................
38
Conversion Kit Instructions – PART A ...................................................................................
39-40
Gas Conversion for Top Convertible Pilot (Series 019065X) – PART B.................................
41
Gas Conversion for Modulator – PART C................................................................................
42
IPI Electronic Ignition System..................................................................................................
43-47
IPI Lighting Instructions...........................................................................................................
48
Door and Glass Information.....................................................................................................
49
Log Placement - LOGF36........................................................................................................
49-50
Pilot Shield RSP1 / RSP2……………………………………………………………………………
51
MQROCK1/MQRSP2 Setup for Models MQHBZDV3636/MQHBZDV4236............................
52-53
MQROCK1/MQRSP1 Setup for Models HBZDV4736............................................................
54-55
Accessories Available for Skyline & ZDVRB3622 Ribbon Burner Units..................................
56-57
ULK2 Universal Light Kit (Optional Accent Lighting Kit)..........................................................
58-59
Vent Termination.....................................................................................................................
60
General Vent Installation Information......................................................................................
61
Venting Table...........................................................................................................................
62
Installation Of Side Wall Venting.............................................................................................
63
Vertical Venting........................................................................................................................
64
Glass Safety / Termination Cap Safety- All Units....................................................................
65
Approved for Power Vent PVH58…………………………………………………………………..
66
PVH58 Power Vent Parts List……………………………………………………………………….
67
Limited Lifetime Warranty........................................................................................................
68
3

Safety Screen Installation Z Series
Screen with Side & Horizontal Angles
Hook Lower Clip onto glass door frame.
Press down and push upper clip under top glass door frame.
Contents of Kit:
[1] Safety Screen
[2] Side Angles
[2] Horizontal Angles
[12-16] DT Screws (Depending on screen size)
Assembly: Attach components with supplied
screws as shown.
⚠WARNING:
Wait until unit is COMPLETELY
cool before touching glass or
attempting to install or remove
Child Safety Screens.
To install screens
hook bottom clip
onto glass door
frame, then press
down and push
upper clip under
top glass door
frame, then
release. Clip will
hook onto frame.
To remove
Safety
Screens
WAIT UNTIL
FIREPLACE IS
COMPLETELY
COOL.
Press down on
upper clips and
remove screen
from fireplace
glass door.
TOP VIEW
Upper Clip
Lower Clip
Upper Clip
NOTE: Screens are symmetrical from top to bottom.
CLIPS
Upper Clip
SIDE VIEW
Fireplace with
Screen
4

Mobile Home/Manufactured Housing Installation
This Direct Vent System Appliance must be installed in accordance with the manufacturer’s installation instructions and the
Manufactured Home Construction and Safety Standard Title 24 CFR, Part 3280, or the current Standard for Fire Safety Criteria for
Manufactured Home Installations, Sites, and Communities ANSI/NFPA 501A, and with CAN/CSA Z240 MH Mobile Home Standard in
Canada.
THE VENTED GAS FIREPLACE HEATERS (ANSI Z21.88-2009) IN THIS MANUAL MAY BE INSTALLED IN MANUFACTURED
(MOBILE)HOMES AFTER FIRST SALE IN THE USA.
THE VENTED GAS FIREPLACE HEATERS (ANSI Z21.88-2009) IN THIS MANUAL MAY BE INSTALLED IN MANUFACTURED
(MOBILE) HOMES IN CANADA.
Please follow the current ANSI/NFPA 70 National Electrical Code in the USA and CAN/CSA C22.1 Canadian National
Electrical Code in Canada.
An appliance must be grounded to the steel chassis of the home with 8 ga. copper wire using a serrated or star washer to
penetrate paint or protective coating to insure grounding.
Use carriage bolt at the attachment point (see diagram above) to secure the appliance to the floor.
For required venting components see venting installation in appropriate section of this manual.
Certified for installation in a bedroom or bed/sitting room. In Canada must be installed with listed millivolt thermostat. In USA see local
codes.
Warning: Do not compromise the structural integrity of the manufactured home wall, floor
or ceiling, during installation of appliance or venting.
5
