Kinze 3000 User manual

This manual applies to: Model: 3000 Rigid Frame Planters
Serial Number: 643579 and later
Record serial number of your planter and date purchased:
Model Number __________________________________
Serial Number ___________________________________
Date Purchased__________________________________
Monitor Serial Number _______________________________________________
Measured Pulses Per Mile/Km (Radar Distance Sensor) ____________________
Measured Pulses Per Mile/ Km (Magnetic Distance Sensor) _________________
SERIAL NUMBER
The serial number plate is located on the planter frame as shown below. The serial number provides important information
about your planter and is needed to obtain correct replacement parts. Always provide model number and serial number
to your Kinze Dealer when ordering parts or when contacting Kinze Manufacturing, Inc.
Kinze
®, the Kinze®logo, Double Frame ®, and Interplant ®are registered trademarks of Kinze Manufacturing, Inc.
MODEL 3000
RIGID FRAME PLANTER
(Mechanical Seed Metering)
OPERATOR MANUAL
M0188-01 Rev. 9/17
Prior to 2009 production 2009 production and later
Serial number plate
Serial number plate
3000
2013 production and later
Serial number plate

TM
Model 3000M0188-01
Rev. 4/14
Predelivery/Delivery Checklist

TM
Model 3000M0188-01
Rev. 6/11
Predelivery/Delivery Checklist
TO THE DEALER
Predelivery service includes assembly, lubrication, adjustment, and test. This service makes sure planter is delivered to
the retail customer/end user ready for field use.
PREDELIVERY CHECKLIST
Use the following checklist and inspect planter after it is completely assembled. Check off each item found satisfactory
or after proper adjustment is made.
Row units properly spaced and optional attachments correctly assembled.
All grease fittings in place and lubricated.
All working parts are moving freely. Bolts are tight and cotter pins are spread.
All drive chains properly tensioned and aligned.
Check for oil leaks and proper hydraulic operation.
Hydraulic hoses are routed correctly to prevent damage to hoses.
Inflate tires to specified air pressure. Tighten wheel lug bolts to specified torque.
All safety decals correctly located and legible as shown in Parts Manual. Replace if damaged.
All reflective decals and SMV sign correctly located as shown in Parts Manual and visible when the planter is in
transport position.
Safety/warning lights correctly installed and working properly.
Paint all parts scratched in shipment or assembly.
All safety lockup devices are on planter and correctly located.
Seed meters performance checked on test stand.
Auxiliary safety chain properly installed and hardware torqued to specification.
This planter has been thoroughly checked and to the best of my knowledge is ready for delivery to the retail
customer/end user.
(Signature Of Set-Up Person/Dealer Name/Date)
RETAIL CUSTOMER/END USER
Name Delivery Date
Street Address Model No. 3000 Serial No.
City, State/Province Dealer Name
ZIP/Postal Code Dealer No.

M0188-01Model 3000
Rev. 4/14
TM
Predelivery/Delivery Checklist
DELIVERY CHECKLIST
Use the following checklist when planter is delivered as a reminder of very important information which should be conveyed
to the retail customer/end user. Check off each item as it is fully explained to the customer.
Life expectancy of this or any other machine is dependent on regular lubrication as directed in the Operator Manual.
All applicable safety precautions.
Along with retail customer/end user, check reflective decals and SMV sign are clearly visible with planter in transport
position and attached to tractor. Check safety/warning lights are in working condition. Tell retail customer/end user
to check federal, state/provincial, and local regulations before towing or transporting on a road or highway.
Give Operator Manual, Parts Manual, and all Instruction Sheets to the customer and explain all operating adjustments.
Read warranty to customer.
Complete Warranty and Delivery Report form.
To the best of my knowledge this machine has been delivered ready for field use and retail customer/end user
has been fully informed as to proper care and operation.
(Signature Of Delivery Person/Dealer Name/Date)
AFTER DELIVERY CHECKLIST
The following is a list of items we suggest to check during the first season of use of the equipment.
Check planter performance with retail customer/end user.
Review importance of proper maintenance and adherence to all safety precautions with retail customer/end user.
Check for parts that may need to be adjusted or replaced.
Check all safety decals, reflective decals, and SMV sign are correctly located as shown in the Parts Manual and that
decals are legible. Replace if damaged or missing.
Check safety/warning lights are working properly.
(Signature Of Follow-Up Person/Dealer Name/Date)
All registrations must be submitted online at “business.kinze.com”within 5 business days of delivery.
Retain a copy of this form for auditing purposes.
Tear Along Perforation

TM
Model 3000M0188-01
Rev. 9/17 i
Table of Contents
OVERVIEW
To the Owner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Warranty .....................................1-3
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
General Safety Rules. . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
Safety Instructions, Signs, and Decals ..............1-7
MACHINE OPERATION
Initial Preparation...............................2-1
Tractor Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Tractor Preparation and Hookup ...................2-2
Cylinder Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Hydraulic Hose Information .......................2-5
Hydraulic Lift Operation . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
Safety lockups .................................2-8
Level Planter ..................................2-8
Interplant Self-Leveling Hitch Extension .............2-8
Transporting Planter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
Contact Drive Spring Adjustment...................2-9
Seed Rate Transmission Adjustment . . . . . . . . . . . . . . . 2-10
Standard and Half Rate (2 to 1) Drives .............2-10
Shear Protection ..............................2-11
Wrap Spring Wrench ...........................2-12
Tire Scraper ..................................2-12
Hydraulic Row Marker Operation..................2-13
Row Marker Speed Adjustment . . . . . . . . . . . . . . . . . . . 2-14
Row Marker Adjustments. . . . . . . . . . . . . . . . . . . . . . . . 2-15
Ridge Planting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-16
Planting Speed ...............................2-16
Field Test ....................................2-17
Check Seed Population .........................2-17
Determining Pounds Per Acre (Brush-Type Meter) ....2-18
Determining Bushels Per Acre. . . . . . . . . . . . . . . . . . . . 2-18
Water Tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-19
ROW UNIT OPERATION
Planting Depth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
“V” Closing Wheel Adjustment (Rubber or Cast Iron) ...3-1
Closing Wheel Shield
(Rubber or Cast Iron “V” Closing Wheels) . . . . . . . . . . 3-2
Drag Closing Attachment. . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Covering Discs/Single Press Wheel Adjustment .......3-3
Brush-Type Seed Meter . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
Finger Pickup Seed Meter . . . . . . . . . . . . . . . . . . . . . . . . 3-5
Additives .....................................3-6
Seed Meter Cleanout. . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6
Seed Hopper ..................................3-7
Seed Meter Drive Release. . . . . . . . . . . . . . . . . . . . . . . . 3-7
Row Unit Extension Brackets. . . . . . . . . . . . . . . . . . . . . . 3-7
Row Unit Chain Routing. . . . . . . . . . . . . . . . . . . . . . . . . . 3-8
Quick Adjustable Down Force Springs Option ........3-9
Frame Mounted Coulter (Pull Row Only) . . . . . . . . . . . . 3-10
Residue Wheels (for Frame Mounted Coulter). . . . . . . . 3-10
Row Unit Mounted Disc Furrower (Pull Row Only) ....3-11
Row Unit Mounted Bed Leveler (Pull Row Only) ......3-11
Row Unit Mounted Residue Wheel ................3-12
Row Unit Mounted No Till Coulter .................3-14
Coulter Mounted Residue Wheels . . . . . . . . . . . . . . . . . 3-14
Granular Chemical Hopper and Drive ..............3-15
Spring Tooth Incorporator .......................3-15
Granular Chemical Banding Options . . . . . . . . . . . . . . . 3-16
Granular Chemical Bander Shield . . . . . . . . . . . . . . . . . 3-16
Interplant Push Row Unit Lockups . . . . . . . . . . . . . . . . . 3-17
Interplant Push Row Unit Clutch Sprocket. . . . . . . . . . . 3-19
FERTILIZER
Double Disc Fertilizer Opener .....................4-1
Notched Single Disc Openers (Style A & B) ..........4-2
Residue Wheel Attachment for Notched Single Disc
Fertilizer Opener .............................4-4
Depth/Gauge Wheel Attachment for Notched Single Disc
Fertilizer Opener .............................4-4
HD Single Disc Fertilizer Opener...................4-5
Dry Fertilizer Attachment . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
Granular Chemical Application Field Check ..........4-8
Liquid Fertilizer Attachment ......................4-10
RATE CHARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
MONITOR OPERATION
KPM I Electronic Seed Monitor ....................6-1
KPM II Stack-Mode Electronic Seed Monitor. . . . . . . . . . 6-7
KPM III Electronic Seed MonItor Ver. 3.01. . . . . . . . . . . 6-35
LUBRICATION AND MAINTENANCE
Lubrication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1
Lubrication Symbols ............................7-1
Sealed Bearings ...............................7-1
Wrap Spring Wrench Assembly . . . . . . . . . . . . . . . . . . . . 7-1
Drive Chains ..................................7-2
Bushings .....................................7-4
Interplant Push Row Unit Lockups. . . . . . . . . . . . . . . . . . 7-5
Liquid Fertilizer Piston Pump .....................7-5

M0188-01Model 3000
ii Rev. 9/17
TM
Table of Contents
Crankcase Oil Level. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-5
Wheel Bearings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-5
Grease Fittings ................................7-6
Mounting Bolts and Hardware ....................7-10
Tire Pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-12
Model 3000 Operating Tire Pressure . . . . . . . . . . . . . . . 7-12
Chain Tension Adjustment . . . . . . . . . . . . . . . . . . . . . . . 7-13
Finger Pickup Seed Meter Inspection/Adjustment. . . . . 7-14
Finger Pickup Seed Meter Cleaning ...............7-15
Brush-Type Seed Meter Maintenance ..............7-16
Drag Closing Attachment .......................7-19
Gauge Wheel Adjustment .......................7-19
Gauge Wheel Arm Bushing and/or
Seal Replacement. . . . . . . . . . . . . . . . . . . . . . . . . . . 7-20
Gauge Wheel Arm Pivot Spindle Replacement . . . . . . . 7-20
15" Seed Opener Disc Blade/Bearing Assembly ......7-21
Seed Tube Guard/Inner Scraper ..................7-22
Frame Mounted Coulter ........................7-23
Residue Wheels
(For Use With Frame Mounted Coulter) ..........7-23
Row Unit Mounted Disc Furrower .................7-24
Row Unit Mounted Bed Leveler . . . . . . . . . . . . . . . . . . . 7-25
Row Unit Mounted Residue Wheel ................7-25
Row Unit Mounted No Till Coulter .................7-26
Coulter Mounted Residue Wheels . . . . . . . . . . . . . . . . . 7-26
Granular Chemical Attachment ...................7-27
Spring Tooth Incorporator .......................7-27
Row Marker Sequencing/Flow Control
Valve Inspection ............................7-28
Row Marker Bearing Lubrication or Replacement . . . . . 7-29
Wheel Bearing Repack or Replacement ............7-30
Fertilizer Check Valve Cleaning and Repair..........7-30
Piston Pump Storage. . . . . . . . . . . . . . . . . . . . . . . . . . . 7-31
Preparing Planter for Storage ....................7-31
Electrical Wiring Diagram for Light Package .........7-32
Hydraulic Hose Life ............................7-33
Hydraulic System Schematic . . . . . . . . . . . . . . . . . . . . . 7-34
Hydraulic System Schematic
(with Interplant Self-Leveling Hitch)..............7-35
TROUBLESHOOTING
Closing Wheel Troubleshooting ....................8-1
KPM I/KPM II Stack-Mode Electronic Seed Monitors
Troubleshooting .......................8-1
Lift Circuit Operation Troubleshooting ...............8-2
Piston Pump Troubleshooting .....................8-3
Row Marker Operation Troubleshooting. . . . . . . . . . . . . . 8-4
Seed Meter (Brush-Type) Troubleshooting. . . . . . . . . . . . 8-5
Seed Meter (Finger Pickup) Troubleshooting. . . . . . . . . . 8-6

TM
Model 3000M0188-01
Rev. 9/17 1-1
Kinze Manufacturing, Inc. would like to thank you for your patronage. We appreciate your confidence in Kinze farm
machinery.Your Kinze planter has been carefully designed to provide dependable operation in return for your investment.
This manual has been prepared to aid you in planter operation and maintenance. It should be considered a
permanent part of the machine and remain with the machine when you sell it.
It is the responsibility of the user to read and understand this Operator Manual before operating this equipment. It
is the user’s responsibility to inspect and service the machine routinely as directed in this Operator Manual. We have
attempted to cover all areas of safety, operation, lubrication and maintenance; however, there may be times when special
care must be taken to fit your conditions.
Throughout this manual the symbol and the words DANGER, WARNING, and CAUTION are used to call atten-
tion to safety information that if not followed, will or could result in death or injury. NOTICE and NOTE are used to call
your attention to important information. The definition of each of these terms follows:
To the Owner
Indicates an imminently hazardous
situation that, if not avoided, will
result in death or serious injury. This
signal word is to be limited to the most
extreme situations, typically for machine
components which, for functional
purposes, cannot be guarded.
DANGER
Indicates a potentially hazardous
situation that, if not avoided, could result
in death or serious injury, and includes
hazards that are exposed when guards
are removed. It may also be used to alert
against unsafe practices.
WARNING
Indicates a potentially hazardous
situation that, if not avoided, may result
in minor or moderate injury. It may also
be used to alert against unsafe practices.
CAUTION
Used to address safety practices not
related to personal injury.
NOTICE

M0188-01Model 3000
1-2 Rev. 9/17
TM
Improperly operating or working on
this equipment could result in death
or serious injury. Read and follow all
instructions in Operator Manual before
operating or working on this equipment.
WARNING
Some photos in this manual may show
safety covers, shields, or lockup devices
removed for visual clarity. NEVER
OPERATOR OR WORK ON machine
without all safety covers, shields, and
lockup device in place as required.
WARNING
NOTE: Photos in this manual may be of prototype machines. Production machines may vary in appearance.
NOTE: Some photos and illustrations in this manual show optional attachments installed. Contact your Kinze
Dealer for purchase of optional attachments.

TM
Model 3000M0188-01
Rev. 6/11 1-3
The Kinze Limited Warranty for your new machine is stated on the retail purchaser’s copy of the Warranty And Delivery
Receipt form. Additional copies of the Limited Warranty can be obtained through your Kinze Dealer.
Warranty, within the warranty period, is provided as part of Kinze’s support program for registered Kinze products which
have been operated and maintained as described in this manual. Evidence of equipment abuse or modification beyond
original factory specifications will void the warranty. Normal maintenance, service and repair is not covered by Kinze
warranty.
To register your Kinze product for warranty, a Warranty And Delivery Receipt form must be completed by the Kinze
Dealer and signed by the retail purchaser, with copies to the Dealer, and to the retail purchaser. Registration must be
completed and submitted to Kinze Manufacturing, Inc. within 5 business days of delivery of the Kinze product to the retail
purchaser. Kinze Manufacturing, Inc. reserves the right to refuse warranty on serial numbered products which have not
been properly registered.
If service or replacement of failed parts which are covered by the Limited Warranty are required, it is the user’s responsibility
to deliver the machine along with the retail purchaser’s copy of the Warranty And Delivery Receipt to the Kinze Dealer
for service. Kinze warranty does not include cost of travel time, mileage, hauling or labor. Any prior arrangement made
between the Dealer and the retail purchaser in which the Dealer agrees to absorb all or part of this expense should be
considered a courtesy to the retail purchaser.
Kinze warranty does not include cost of travel time, mileage, hauling or labor.
Warranty
3000 Double Frame with Interplant, liquid fertilizer, and dry chemical options

M0188-01Model 3000
1-4 Rev. 7/15
TM
Specifications
GENERAL INFORMATION
This manual covers all production years of the Model 3000 planter. Contact your Kinze dealer for additional options which
may be available for your specific model year planter.
Information in this manual was current at time of printing.However, due to Kinze’s ongoing product improvement, production
changes may cause your machine to appear slightly different in detail. Kinze Manufacturing, Inc. reserves the right to
change specifications or design without notice and without incurring obligation to install the same on machines previously
manufactured. To obtain the most recent version of your publication, please contact your Kinze dealer.
Right hand (R.H.) and left hand (L.H.), as used throughout this manual, are determined by facing in the direction the
machine will travel when in use, unless otherwise stated.
TOOLS REQUIRED
Hardware Size / Tool Required
/" = /"/" = /"
(nut for /" hardware uses /" tool)
/" = 1/" 1/" = 1/"
/" = /"/" = /"/" = 1/" 1/" = 2/"
/" = /"/" = /" 1" = 1/"

TM
Model 3000M0188-01
Rev. 7/15 1-5
SPECIFICATIONS
Planter Size 4 Row 30" 6 Row 30" 8 Row 30"
Single Frame Length 11'4" (3.5M) 11'4" (3.5M) 11'4" (3.5M)
Double Frame Length 13'8" (4.2M) 13'8" (4.2M) 13'8" (4.2M)
Width 12'8" (3.9M) 17'8" (5.4M) 21'10" (6.7M)
Single Frame Weight* 2538 lb
(1151.22 kg)
3864 lb
(1752.68 kg)
4874 lb
(2210.81 kg)
Double Frame Weight* 2948 lb
(1337.19 kg)
4398 lb
(1994.90 kg)
5548 lb
(2516.53 kg)
* Base machine weights include planter frame including row markers, drive components, tires and wheels, hydraulic
cylinders, transport safety chain and Kinze pull row units (closing wheel arms less wheels) with seed hopper and lid
and dual quick adjustable down force springs.
Axle Weight Empty** N/A N/A 4950 lb
(2245.2 kg)
Tongue Weight Empty** N/A N/A 1,310 lb
(594.2 kg)
**Weight based off a typical configuration of a complete machine.
Seed Capacity 1.90 bu. (Mechanical / Hopper)
Transport/Field Tire 7.50" x 20" 8 ply rib implement tires with center groove ............Inflate to 40 psi (275.7 kPa)
Contact Drive Tire 4.10" x 6" ...................................................................................Inflate to 50 psi (344.7 kPa)
Field Lift Master / slave rephasing cylinders
Row Markers Hydraulic alternating sequence valve (dual valve optional), single fold, depth bands.
TRACTOR HYDRAULIC REQUIREMENTS
Configuration Requirements Description
Base machine with mechanical
meters and row markers 1 SCV 10 gpm (38 L/min) #1 SCV: Planter lift and row marker auto sequencing
Base machine with mechanical
meters and row marker dual valve
conversion
2 SCV 10 gpm
(38 L/min)
#1 SCV: Planter lift
#2 SCV: Row markers with optional dual valve
Specifications

M0188-01Model 3000
1-6 Rev. 6/11
TMTM
1. Read and understand instructions provided in this manual
and warning labels. Review these instructions frequently!
2. This machine is designed and built with your safety in mind.
Do not make any alterations or changes to this machine. Any
alteration to design or construction may create safety hazards.
3. A large portion of farm accidents happen from fatigue
or carelessness. Safe and careful operation of tractor and
planter will help prevent accidents.
4. Never allow planter to be operated by anyone unfamiliar
with operation of all functions of the unit. Operators must
read and thoroughly understand all instructions given in this
manual before operating or working on equipment.
5. Be aware of bystanders, particularly children! Always look
around to make sure it is safe to start tow vehicle engine or
move planter. This is particularly important with higher noise
levels and quiet cabs, as you may not hear people shouting.
6. Make sure planter weight does not exceed towing capacity
of tractor, or bridge and road limits. This is critical to maintain
safe control and prevent death or injury, or property and
equipment damage.
7. Never ride or allow others to ride on planter.
8. Store planter in an area away from human activity. DO
NOT permit children to play on or around the stored unit.
9. Keep hands, feet, and clothing away from moving parts. Do
not wear loose-fitting clothing which may catch in moving parts.
10. Always wear protective clothing, shoes, gloves, hearing,
and eye protection applicable for the situation.
11. Do not allow anyone to stand between tongue or hitch
and towing vehicle when backing up to planter.
13. Prevent electrocution, other injuries, or property and
equipment damage. Watch for obstructions such as wires,
tree limbs, etc. when operating machine. Be aware of
clearances during turns and when folding/unfolding planter.
14. Reinstall all guards removed for maintenance activities.
Never leave guards off during operation.
15. Use of aftermarket hydraulic, electric, or PTO drives may
create serious safety hazards to you and people nearby. If you
install such drives, follow all appropriate safety standards and
practices to protect you and others near this planter from injury.
16. Follow all federal, state/provincial, and local
regulations when towing farm equipment on a public
highway. Use safety chain (not an elastic or nylon/plastic
tow strap) to retain connection between towing and
towed machines in the event of primary attaching system
separation.
17. Make sure all safety/warning lights, SMV sign, and
reflective decals are in place and working properly
before transporting the machine on public roads.
18. Limit towing speed to 15 MPH (24.14 km/h). Tow
only with farm tractor of a minimum 90 HP. Allow for unit
length when making turns.
19. Reduce speed prior to turns to avoid the risk of
overturning. Always drive at a safe speed relative to
local conditions and ensure your speed is slow enough
for a safe emergency stop.
20. Chemical application is often an integral part of
planting. Follow label instructions for proper chemical
mixing, handling and container disposal methods.
21. Be familiar with safety procedures for immediate
first aid should you accidentally contact chemical
substances.
22. Use the proper protective clothing and safety
equipment when handling chemicals.
23. Chemicals are supplied with Material Safety Data
Sheets (MSDS) that provide full information about the
chemical, its effects on exposure, and first aid needs
in the event of an emergency. Keep your MSDS file
up-to-date and available for first responders in case of
emergency.
24. When servicing ground engaging components such
as opening disks and firming points, use special care to
avoid points and edges worn sharp during use.
25. Use professional help if you are unfamiliar with
working on hydraulic systems. Pressurized hydraulic
fluid can penetrate body tissue and result in death,
serious infection, or other injuries.
26. Disposing of waste improperly can threaten the
enviroment. To dispose of your equipment properly
contact your local environmental or recyling center.
Never pour waste onto the ground, down a drain, or into
any water source.
When disposing of waste such as oil, use leakproof
containers. Be sure to use containers that do not
resemble food or beverage which may mislead someone
into consuming them. Dispose of oil per your local,
regional requirements.
When disposing of any fertilizer chemicals used, contact
the supplier of the chemicals.
Model 3000 planter consists of 85% recyclable metals,
10% recyclable plastic and rubber, and 5% waste.
General Safety Rules

TM
Model 3000M0188-01
Rev. 9/17 1-7
Safety Instructions, Signs, and Decals
Following are some common hazard warnings associated with this equipment. Pay close attention to all safety,
operating, and maintenance information in this manual and decals applied to your equipment.
Contacting or coming close to power
lines or other high energy sources will
cause death or serious injury.
Keep away from power lines or high
energy sources at all times.
DANGER
Loss of control can cause death or
serious injury, or damage to property
and equipment. Tow only with farm
tractor weight rated and configured for
this equipment. Use safety chains and
transport as specified in the Operator
and Parts Manual.
WARNING
Improperly operating or working on
this equipment could result in death
or serious injury. Read and follow all
instructions in Operator Manual before
operating or working on this equipment.
WARNING
Contact with rotating driveline will cause
death or serious injury. Keep away at all
times when operating.
Never operate without all guards and
equipment shields properly installed.
WARNING
Explosive separation of rim and tire
parts can cause death or serious injury.
Overinflation, rim and tire servicing,
improper use of rims and tires, or worn
or improperly maintained tires could
result in a tire explosion.
WARNING

M0188-01Model 3000
1-8 Rev. 9/17
TM
Safety signs and decals are placed on the machine to warn of hazards and provide important operating and maintenance
instructions. Information on these signs are for your personal safety and the safety of those around you. FOLLOW ALL
SAFETY INSTRUCTIONS!
• Keep signs clean so they can be easily seen. Wash with soap and water or cleaning solution as required.
• Replace safety signs if damaged, painted over, or missing.
• Check reflective decals and SMV sign periodically. Replace if they show any loss of reflective properties.
• When replacing decals, clean machine surface thoroughly with soap and water or cleaning solution to
remove all dirt and grease.
NOTE: Safety sign and decal locations are shown in the Parts Manual for this machine.
NOTE: Style and locations of SMV sign, reflective decals, and safety/warning lights conform to ANSI/ASABE
S279.14 JUL 2008 and ANSI/ASABE S276.6 JAN 2005.
Safety Signs And Decals
All safety/warning lights, reflective
decals, and SMV sign must be in place
and visible before transporting machine
on public roads or death, serious injury,
and damage to property and equipment
may result. Check federal, state/
provincial, and local regulations before
transporting equipment on public roads.
WARNING
Safety Instructions, Signs, and Decals

TM
Model 3000M0188-01
Rev. 9/17 2-1
Machine Operation
INITIAL PREPARATION
1. Torque transport wheel "- 18 lug bolts to 90 ft-lb (122 N-m).
2. Inflate transport/ground drive tires to 40 psi (275.7 kPa).
3. Inflate contact drive tires to 50 psi (344.7 kPa).
Following information is general in nature to aid in preparation of tractor and planter for use, and to provide general
operating procedures. Operator experience, familiarity with the machine, and the following information should combine
for efficient planter operation and good working habits.
Contact drive
Transport/ground drive
Improperly operating or working on
this equipment could result in death
or serious injury. Read and follow all
instructions in Operator Manual before
operating or working on this equipment.
WARNING
Loose transport wheel lug bolts can
result in wheel separation from planter
and cause death, serious injury, and
damage to property and equipment.
Torque transport wheel "- 18 lug bolts
to 180 ft-lb (244 N-m) before operating
planter for the first time and periodically
after.
WARNING
Explosive separation of rim and tire
parts can cause death or serious injury.
Overinflation, rim and tire servicing,
improper use of rims and tires, or worn
or improperly maintained tires could
result in a tire explosion.
WARNING

M0188-01Model 3000
TM
Machine Operation
2-2 Rev. 9/17
TRACTOR REQUIREMENTS
Consult your dealer for information on horsepower requirements and tractor compatibility. Requirements vary with
planter options, tillage, and terrain.
A 12 volt DC electrical system is required for all 3000 series planters.
One dual remote hydraulic outlet (SCV) is required for machines equipped with a standard single valve hydraulic system.
Two dual remote hydraulic outlets (SCV) are required for machines equipped with the optional dual valve hydraulic system.
TRACTOR PREPARATION AND HOOKUP
1. Adjust tractor drawbar 13 to 17 inches (33 to 43 cm) above
ground. Adjust drawbar so hitch pin hole is directly below center
line of PTO shaft. Make sure drawbar is in a stationary position.
2. Back tractor to planter and connect with a minimum ¾" (19 mm)
diameter hitch pin. Secure with a locking or cotter pin.
NOTE: DO NOT install safety chain using clevis mounting
hardware. Safety chain MUST be installed separately.
3. Provided transport safety chain must be used to keep planter
and tractor connected in case of a hitch pin/drawbar failure.
Attach safety chain at an unused clevis mounting hole on the
planter hitch. Torque hardware to 840 ft-lb (1138.8 N-m).
Drawbar and safety chain connection
All Hydraulic Requirements: Minimum
Pressure 2350 PSI (16202.6 kPa);
Maximum Pressure 3000 PSI (20684.2 kPa).
Check tractor hydraulics to ensure that
maximum pressure cannot be exceeded.
NOTICE

TM
Model 3000M0188-01
Rev. 9/17 2-3
Machine Operation
4. Connect hydraulic hoses to tractor ports in a sequence familiar and comfortable to the operator.
NOTE: If tractor is equipped with an adjustable flow outlet (SCV), set to full flow position.
5. Connect ASABE Standards 7 terminal connector for safety/warning lights on planter to ASABE Standards
receptacle on tractor. If your tractor is not equipped with an ASABE Standards receptacle, check with your tractor
manufacturer for availability. Check warning lights on planter work in conjunction with warning lights on tractor.
6. Raise jack stand and remount horizontally on storage bracket.
Jack stand installed Jack stand stored
Pressurized hydraulic fluid can penetrate
body tissue and result in death, serious
infection, or other injuries. Fluid injected
under skin must be IMMEDIATELY
removed by a surgeon familiar with this
type of injury. Make sure connections
are tight and hoses and fittings are
not damaged before applying system
pressure. Leaks can be invisible. Keep
away from suspected leaks. Relieve
pressure before searching for leaks or
performing any system maintenance.
WARNING
Wipe hose ends to remove any dirt
before connecting couplers to tractor
ports or contamination may cause
equipment failure.
NOTICE

M0188-01Model 3000
TM
Machine Operation
2-4 Rev. 2/14
CYLINDER INFORMATION
Row Marker Cylinder
(4 Row 30"/36"/38"
and 6 Row 30")
Row Marker Cylinder
(6 Row 36"/38" and
8 Row 30")
Lift Assist Cylinder
(6 Row 30"/36"/38"
and 8 Row 30")
Slave Lift Cylinder Master Lift Cylinder
Intended Use Double Acting
Applications
Double Acting
Applications
Double Acting
Applications
Double Acting
Applications
Double Acting
Applications
Piston Ductile Iron Ductile Iron Ductile Iron Ductile Iron Ductile Iron
Gland Ductile Iron Ductile Iron Ductile Iron Ductile Iron Ductile Iron
Tube ST 52 DOM Tubing ST 52 DOM Tubing ST 52 DOM Tubing ST 52 DOM Tubing ST 52 DOM Tubing
Rod 1045 Nitro Rod 1045 Nitro Rod 1045 Nitro Rod 1045 Nitro Rod 1045 Nitro Rod
End Mounts U-Brackets Sleeve End Mount Sleeve Tunnion
Mount
Sleeve Tunnion
Mount
Sleeve Tunnion
Mount
Tube Seal Buna O-Ring with
Polytemp Back-up
Buna O-Ring with
Polytemp Back-up
Buna O-Ring with
Polytemp Back-up
Buna O-Ring with
Polytemp Back-up
Buna O-Ring with
Polytemp Back-up
Rod Seal Polyester Alloy
U-cup
Polyester Alloy
U-cup
Polyester Alloy
U-cup
Polyester Alloy
U-cup
Polyester Alloy
U-cup
Rod Wiper Polyester Alloy Snap
In
Polyester Alloy Snap
In
Polyester Alloy Snap
In
Polyester Alloy Snap
In
Polyester Alloy Snap
In
Piston Seal T-Seal HNBR T-seal HNBR T-Seal HNBR T-Seal HNBR T-Seal HNBR
Specifications
Product
Category
Hydraulic Cylinder Hydraulic Cylinder Hydraulic Cylinder Hydraulic Cylinder Hydraulic Cylinder
Maximum
Stroke
8" (20.32 cm) 20.062" (50.96 cm) 8" (20.32 cm) 8" (20.32 cm) 8" (20.32 cm)
Working
Pressure
2350-3000 PSI
(16202.68-20684.27 KPa)
2350-3000 PSI
(16202.68-20684.27 KPa)
2350-3000 PSI
(16202.68-20684.27 KPa)
2350-3000 PSI
(16202.68-20684.27 KPa)
2350-3000 PSI
(16202.68-20684.27 KPa)
Bore Size 2" (5.08 cm) 2" (5.08 cm) 2.5" (6.35 cm) 3.25" (8.255 cm) 3.5" (8.89 cm)
Shaft
Diameter 1" (2.54 cm) 1" (2.54 cm) 1.25" (3.175 cm) 1.25" (3.175 cm) 1.25" (3.175 cm)
Cylinder
Configuration
Simple Simple Simple Simple Simple
Cylinder
Action Double Double Double Double Double
Material Steel, Ductile Iron Steel, Ductile Iron Steel, Ductile Iron Steel, Ductile Iron Steel, Ductile Iron
Mounting
Method
U-Bracket Sleeve Sleeve Trunnion
Mount
Sleeve Trunnion
Mount
Sleeve Trunnion
Mount
Mount
Location End Cap End Cap End Cap End Cap End Cap
Cylinder
Style Welded Welded Welded Welded Welded

TM
Model 3000M0188-01
Rev. 2/14 2-5
Machine Operation
HYDRAULIC HOSE INFORMATION
Part Number
A3135 A1076 A1102 A1170 A1138 A1018
Description
Hose Assembly,
" x 100"
Hose Assembly,
" x 30"
Hose Assembly,
¼" x 95"
Hose Assembly,
¼" x 90"
Hose Assembly,
¼" x 29"
Hose Assembly,
" x 40"
Product
Category Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose
Product Form Hose; Assembly Hose; Assembly Hose; Assembly Hose; Assembly Hose; Assembly Hose; Assembly
I.D. " (9.525 mm) " (9.525 mm) " (9.525 mm) ¼" (6.35 mm) ¼" (6.35 mm) " (9.525 mm)
O.D.
.63" (16.002 mm) .63" (16.002 mm) .63" (16.002 mm) .53" (13.462 mm) .53" (13.462 mm) .63" (16.002 mm)
Minimum Bend
Radius 2" (5.08 cm) 2" (5.08 cm) 2" (5.08 cm) 4" (10.16 cm) 4" (10.16 cm) 2" (5.08 cm)
Working
Pressure
3250 PSI
(22407.96 kPa)
3250 PSI
(22407.96 kPa)
3250 PSI
(22407.96 kPa)
3275 PSI
(22580.33 kPa)
3275 PSI
(22580.33 kPa)
3250 PSI
(22407.96 kPa)
Temperature
Range
-40°F - +212°F
(-40°C - +100°C)
-40°F - +212°F
(-40°C - +100°C)
-40°F - +212°F
(-40°C - +100°C)
-40°F - +212°F
(-40°C - +100°C)
-40°F - +212°F
(-40°C - +100°C)
-40°F - +212°F
(-40°C - +100°C)
Material Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Specialized
Construction
High Tensile
Steel Wire
High tensile
steel wire
High tensile
steel wire
High tensile
steel wire
High tensile
steel wire
High tensile
steel wire
Media Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid
Application
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Part Number
A1020 A3113 A1105 A1168 A3115 A1000
Description
Hose Assembly,
" x 48"
Hose Assembly,
" x 84"
Hose Assembly,
¼" x 125"
Hose Assembly,
¼" x 120"
Hose Assembly,
" x 146"
Hose Assembly,
" x 15"
Product
Category Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose
Product Form Hose; Assembly Hose; Assembly Hose; Assembly Hose; Assembly Hose; Assembly Hose; Assembly
I.D. " (9.525 mm) " (9.525 mm) ¼" (6.35 mm) ¼" (6.35 mm) " (9.525 mm) " (9.525 mm)
O.D.
.63" (16.002 mm) .63" (16.002 mm) .53" (13.462 mm) .53" (13.462 mm) .63" (16.002 mm) .63" (16.002 mm)
Minimum Bend
Radius 2" (5.08 cm) 2" (5.08 cm) 4" (10.16 cm) 4" (10.16 cm) 2" (5.08 cm) 2" (5.08 cm)
Working
Pressure
3250 PSI
(22407.96 kPa)
3250 PSI
(22407.96 kPa)
3275 PSI
(22580.33 kPa)
3275 PSI
(22580.33 kPa)
3250 PSI
(22407.96 kPa)
3250 PSI
(22407.96 kPa)
Temperature
Range
-40°F - +212°F
(-40°C - +100°C)
-40°F - +212°F
(-40°C - +100°C)
-40°F - +212°F
(-40°C - +100°C)
-40°F - +212°F
(-40°C - +100°C)
-40°F - +212°F
(-40°C - +100°C)
-40°F - +212°F
(-40°C - +100°C)
Material Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Specialized
Construction
High tensile
steel wire
High tensile
steel wire
High tensile
steel wire
High tensile
steel wire
High tensile
steel wire
High tensile
steel wire
Media Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid
Application
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction

M0188-01Model 3000
TM
Machine Operation
2-6 Rev. 2/14
Hydraulic Hose Information (Continued)
Part Number
A1086 A3119 A3175 A1019 A1079 A1090
Description
Hose Assembly,
" x 28"
Hose Assembly,
" x 36"
Hose Assembly,
" x 38"
Hose Assembly,
" x 44"
Hose Assembly,
" x 24"
Hose Assembly,
" x 162"
Product
Category Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose
Product Form Hose; Assembly Hose; Assembly Hose; Assembly Hose; Assembly Hose; Assembly Hose; Assembly
I.D. " (9.525 mm) " (9.525 mm) " (9.525 mm) " (9.525 mm) " (9.525 mm) " (9.525 mm)
O.D.
.63" (16.002 mm) .63" (16.002 mm) .63" (16.002 mm) .63" (16.002 mm) .63" (16.002 mm) .63" (16.002 mm)
Minimum Bend
Radius 2" (5.08 cm) 2" (5.08 cm) 2" (5.08 cm) 2" (5.08 cm) 2" (5.08 cm) 2" (5.08 cm)
Working
Pressure
3250 PSI
(22407.96 kPa)
3250 PSI
(22407.96 kPa)
3250 PSI
(22407.96 kPa)
3250 PSI
(22407.96 kPa)
3250 PSI
(22407.96 kPa)
3250 PSI
(22407.96 kPa)
Temperature
Range
-40°F - +212°F
(-40°C - +100°C)
-40°F - +212°F
(-40°C - +100°C)
-40°F - +212°F
(-40°C - +100°C)
-40°F - +212°F
(-40°C - +100°C)
-40°F - +212°F
(-40°C - +100°C)
-40°F - +212°F
(-40°C - +100°C)
Material Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Specialized
Construction
High tensile
steel wire
High tensile
steel wire
High tensile
steel wire
High tensile
steel wire
High tensile
steel wire
High tensile
steel wire
Media Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid
Application
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Part Number
A3114 A1021 A1055 A1039
Description
Hose Assembly,
" x 156"
Hose Assembly,
" x 56"
Hose Assembly,
" x 66"
Hose Assembly,
" x 76"
Product
Category Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose
Product Form Hose; Assembly Hose; Assembly Hose; Assembly Hose; Assembly
I.D. " (9.525 mm) " (9.525 mm) " (9.525 mm) " (9.525 mm)
O.D.
.63" (16.002 mm) .63" (16.002 mm) .63" (16.002 mm) .63" (16.002 mm)
Minimum Bend
Radius 2" (5.08 cm) 2" (5.08 cm) 2" (5.08 cm) 2" (5.08 cm)
Working
Pressure
3250 PSI
(22407.96 kPa)
3250 PSI
(22407.96 kPa)
3250 PSI
(22407.96 kPa)
3250 PSI
(22407.96 kPa)
Temperature
Range
-40°F - +212°F
(-40°C - +100°C)
-40°F - +212°F
(-40°C - +100°C)
-40°F - +212°F
(-40°C - +100°C)
-40°F - +212°F
(-40°C - +100°C)
Material Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Specialized
Construction
High tensile
steel wire
High tensile
steel wire
High tensile
steel wire
High tensile
steel wire
Media Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid
Application
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
