KISANKRAFT KK-WPP-10 User manual

KisanKraft®
Warranty Certificate
(DEALER COPY)
This warranty is null & void, if you fail to register the warranty with
KisanKraft by sending the KisanKraft Copy with dealer’s stamp.
KisanKraft Limited (formerly known as KisanKraft Machine Tools P Ltd)
: www.kisankraft.com
: [e-mail]
: +91.80.22178200
Page 1 of 44
Product
Centrifugal Water
Pump For
Agriculture
KisanKraft
Invoice Date
Brand
KisanKraft
KisanKraft
Invoice No.
Model
KK-WPP-10
KK-WPP-15
KK-WPP-21
KK-WPP-31
KK-WPP-2535
KK-WPP-50080
WARRANTY
PERIOD
6-MONTHS
FOR THE SPECIFIED PERIOD FROM THE DATE
OF SALE OR DELIVERY WHICHEVER IS
EARLIER.
Dealer’s
Invoice Date
Dealer’s Invoice
No.
Buyer’s Info (Name, Address, Phone, etc.):
Dealer’s Stamp (Address, Phone, TIN, etc.):
Buyer’s Sign
Dealer’s Sign
What is covered: KisanKraft Limited and its manufacturers warrant this product to be
free from defects in material or workmanship. All parts defective in material and
workmanship are covered.
This warranty will only cover defects arising under normal usage.
This warranty is limited to repair or replacement by KisanKraft Limited or its
manufacturers at the premises of Authorized Dealers, of such parts as appear to
KisanKraft or its manufacturers, upon inspection, to be defective in material and/or
workmanship. KisanKraft or its manufacturers make no warranty with respect to trade
accessories not manufactured or sold by them.
What is not covered: The warranty shall become null and void and neither KisanKraft
Limited nor any of its manufacturers, nor its authorized dealers assumes any
responsibility, if the failure was caused by the following:
(1) Operation of product with incorrect fuel or lubricants, (2) Incorrect usage of machine
or misuse, (3) Lack of maintenance, (4) Negligence, (5) Accident or physical damage,
(6) Repairs made by unauthorized parties and/or with unauthorized parts, (7) Improper
set up, adjustments, tampering or altered products

KisanKraft®
Warranty Certificate
(DEALER COPY)
This warranty is null & void, if you fail to register the warranty with
KisanKraft by sending the KisanKraft Copy with dealer’s stamp.
KisanKraft Limited (formerly known as KisanKraft Machine Tools P Ltd)
: www.kisankraft.com
: [e-mail]
: +91.80.22178200
Page 2 of 44
Important: (1) Normal maintenance and adjustments to the product is the responsibility
of the customer. (2) Normal wear and tear is not covered under warranty
(3) Rubber/plastic parts and consumables such as blades, clutch and clutch-bell, spark-
plugs, nylon line, air-filters, fuel-filters, oil seals etc. are not covered under the warranty.
No Warranty On Electrical Motor / Electrical Parts / Battery Etc.
Incidental / Consequential Loss: KisanKraft Limited or its manufacturers will not be
liable for general damages, including bodily injuries, or for incidental or consequential
damages including, but not limited to, loss of use, loss of profits, loss of production,
expense of substitute equipment or other commercial loss or damage.
Limitation of Liability: This limited warranty is in lieu of all other express warranties,
obligations, or liabilities. Any implied warranties, obligations or liabilities, including, but
not limited to, any implied warranty of merchantability shall be limited in duration to the
applicable warranty period. Any action for breach of any warranties hereunder,
including, but not limited to, any implied warranty of merchantability must be brought
within the applicable warranty period.
Modifications of Warranty: No agent, representative, dealer, or employee of
KisanKraft Limited or any of its manufacturers has the authority to increase or alter the
obligations of this warranty.
Assignment / Transfer of warranty: The warranty cannot be assigned and shall not
transfer if the product is resold by the first buyer. The above warranties are extended to
the first end user (original purchaser), and no warranty is made, nor authorized to be
made assignable on resale by the first end user.
What you must do to obtain limited warranty service: To obtain performance of any
obligation under this warranty for failure during the applicable warranty period, deliver
the defective product, to the nearest Authorized Dealer. KisanKraft Limited, its
manufacturers and its dealers reserve the right to inspect the claimed defective part(s)
to determine if the malfunction is the result of a defect covered by this warranty. Please
note that the decision of KisanKraft Limited with respect to any warranty claim is final.
Receipt is required for availing warranty services
Jurisdiction: All disputes are subject to Bangalore court’s jurisdiction.
Our
Products
ChainsawsBrush Cutters and AccessoriesHarvesters
Engines and Water PumpsHand ToolsGardenTools
Cultivators and AccessoriesSprayers and Accessories
Transplanter and Post Hole Digger Milking Machines

KisanKraft®
Centrifugal Water Pump For
Agriculture
KK-WPP-10 /15 /21 /31 /2535 /50080
: www.kisankraft.com
: [e-mail]
: +91.80. 22178200
Page 3 of 44
User Manual
KisanKraft Limited
(Formerly known as KisanKraft Machine Tools Pvt Ltd)
Sri Huchhanna Tower, #4,1st Main,7-A Cross, Maruthi Layout, Dasarahalli,
HAF Post, Hebbal, Bangalore 560024,Karnataka,INDIA
♦Bangalore (HO) ♦Ahmedabad ♦Bhopal ♦Bhubaneswar ♦Coimbatore ♦
♦Jammu ♦Guwahati ♦Jaipur ♦Hubli ♦Hyderabad ♦
♦Karnal ♦Kolkata ♦Lucknow ♦Pune ♦Raipur ♦Shimla ♦

KisanKraft®
Centrifugal Water Pump For
Agriculture
KK-WPP-10 /15 /21 /31 /2535 /50080
: www.kisankraft.com
: [e-mail]
: +91.80. 22178200
Page 4 of 44
Contents
BEFORE GETTING STARTED............................................................................7
SAFETY INSTRUCTIONS ..................................................................................7
OPERATION ...................................................................................................7
PREPARATION BEFORE OPERATION:...........................................................7
STARTING THE ENGINE ...............................................................................8
USE.............................................................................................................8
STOPPING THE ENGINE...............................................................................8
MAINTENANCE ..............................................................................................8
STORAGE .......................................................................................................9
TROUBLESHOOTING ......................................................................................9
TECHNICAL SPECIFICATIONS ........................................................................10
WATER PUMP PARTS DIAGRAM & LIST-KK-WPP-10/15 ...............................13
PUMP PARTS DIAGRAM & LIST-KK-WPP-21/31............................................14
USER MANUAL-4-STROKE PETROL ENGINE ..................................................17
ENGINE PARTS DIAGRAM & LIST (KK-PE4-103) ............................................27

KisanKraft®
Warranty Certificate
(CUSTOMER COPY)
This warranty is null & void, if you fail to register the warranty with
KisanKraft by sending the KisanKraft Copy with dealer’s stamp.
KisanKraft Limited (formerly known as KisanKraft Machine Tools P Ltd)
: www.kisankraft.com
: [e-mail]
: +91.80. 22178200
Page 5of 44
Product
Centrifugal Water
Pump For
Agriculture
KisanKraft
Invoice Date
Brand
KisanKraft
KisanKraft
Invoice No.
Model
KK-WPP-10
KK-WPP-15
KK-WPP-21
KK-WPP-31
KK-WPP-2535
KK-WPP-50080
WARRANTY
PERIOD
6-MONTHS
FOR THE SPECIFIED PERIOD FROM THE
DATE OF SALE OR DELIVERY WHICHEVER IS
EARLIER.
Dealer’s
Invoice Date
Dealer’s Invoice
No.
Buyer’s Info (Name, Address, Phone, etc.):
Dealer’s Stamp (Address, Phone, TIN, etc.):
Buyer’s Sign
Dealer’s Sign
What is covered: KisanKraft Limited and its manufacturers warrant this product to be
free from defects in material or workmanship. All parts defective in material and
workmanship are covered.
This warranty will only cover defects arising under normal usage.
This warranty is limited to repair or replacement by KisanKraft Limited or its
manufacturers at the premises of Authorized Dealers, of such parts as appear to
KisanKraft or its manufacturers, upon inspection, to be defective in material and/or
workmanship. KisanKraft or its manufacturers make no warranty with respect to trade
accessories not manufactured or sold by them.
What is not covered: The warranty shall become null and void and neither KisanKraft
Limited nor any of its manufacturers, nor its authorized dealers assumes any
responsibility, if the failure was caused by the following:
(1) Operation of product with incorrect fuel or lubricants, (2) Incorrect usage of
machine or misuse, (3) Lack of maintenance, (4) Negligence, (5) Accident or physical
damage, (6) Repairs made by unauthorized parties and/or with unauthorized parts, (7)
Improper set up, adjustments, tampering or altered products

KisanKraft®
Warranty Certificate
(CUSTOMER COPY)
This warranty is null & void, if you fail to register the warranty with
KisanKraft by sending the KisanKraft Copy with dealer’s stamp.
KisanKraft Limited (formerly known as KisanKraft Machine Tools P Ltd)
: www.kisankraft.com
: [e-mail]
: +91.80. 22178200
Page 6 of 44
Important: (1) Normal maintenance and adjustments to the product is the
responsibility of thecustomer. (2) Normal wear and tear is not covered under warranty.
(3) Rubber/plastic parts and consumables such as blades, clutch and clutch-bell,
spark-plugs, nylon line, air-filters, fuel-filters, oil seals etc. are not covered under the
warranty.
No Warranty On Electrical Motor / Electrical Parts / Battery Etc.
Incidental / Consequential Loss: KisanKraft Limited or its manufacturers will not be
liable for general damages, including bodily injuries, or for incidental or consequential
damages including, but not limited to, loss of use, loss of profits, loss of production,
expense of substitute equipment or other commercial loss or damage.
Limitation of Liability: This limited warranty is in lieu of all other express warranties,
obligations, or liabilities. Any implied warranties, obligations or liabilities, including, but
not limited to, any implied warranty of merchantability shall be limited in duration to the
applicable warranty period. Any action for breach of any warranty hereunder,
including, but not limited to, any implied warranty of merchantability must be brought
within the applicable warranty period.
Modifications of Warranty: No agent, representative, dealer, or employee of
KisanKraft Limited or any of its manufacturers has the authority to increase or alter the
obligations of this warranty.
Assignment / Transfer of warranty: The warranty cannot be assigned and shall not
transfer if the product is resold by the first buyer. The above warranties are extended
to the first end user (original purchaser), and no warranty is made, nor authorized to
be made assignable on resale by the first end user.
What you must do to obtain limited warranty service: To obtain performance of
any obligation under this warranty for failure during the applicable warranty period,
deliver the defective product, to the nearest Authorized Dealer. KisanKraft Limited, its
manufacturers and its dealers reserve the right to inspect the claimed defective part(s)
to determine if the malfunction isthe result of a defect covered by this warranty. Please
note that the decision of KisanKraft Limited with respect to any warranty claim is final.
Receipt is required for availing warranty services
Jurisdiction: All disputes are subject to Bangalore court’s jurisdiction.
Our
Products
ChainsawsBrush Cutters and AccessoriesHarvesters
Engines and Water PumpsHand ToolsGardenTools
Cultivators and AccessoriesSprayers and Accessories
Transplanter and Post Hole Digger Milking Machines

KisanKraft®
Centrifugal Water Pump For
Agriculture
KK-WPP-10 /15 /21 /31 /2535 /50080
: www.kisankraft.com
: [e-mail]
: +91.80. 22178200
Page 7 of 44
BEFORE GETTING STARTED
Thank you for your purchase and use of our products. In order to avoid accidents or injury,
please read this manual carefully before using the machine. After reading, preserve it for
further reference.
This Water pump is characterized by light weight, simple structure high efficiency,
convenient use and flexible movement. It can be used for agricultural irrigation, drainage
construction and pumping, especially widely used in recurrent irrigation of small area for
agricultural production at present.
SAFETY INSTRUCTIONS
1. Read the operation manual carefully before starting the engine in order to avoid
any accident and damage.
2. Please do not use this engine inside an enclosed area. Ensure adequate
ventilation while Engine is in operation.
3. To prevent fire hazard, please keep the Engine in operation at least 1-meter (3
feet) away from Combustible or Inflammable materials, buildings and equipment.
4. When refueling you must STOP the Engine. Please do not smoke near Engine.
Wipe the spilled fuel after refueling.
CAUTION: Spilled fuel is a fire hazard.
5. Always place the engine horizontally. Do NOT tilt the Engine more than 21
degrees Overturning or inclining the engine may cause oil spillage and result in
fire hazard.
6. Do NOT cover the Engine when in operation.
7. Children are strictly not allowed near the engine operation area.
OPERATION
PREPARATION BEFORE OPERATION:
1. Connect the suction pipe:
•Place the filter into the empennage of the suction pipe with the tie-in.
•Place another end into the input with the tie-in.
2. Connect the discharging pipe:
Place the discharging pipe into the output with the tie-in.
3. Check the oil:
•Check the oil lever in the case that the engine is off and horizontal.
4. Check the fuel level:
•Open the crankcase cover to check the fuel level. Please addfuel when the lever
is low.
5. Check the air cleaner:
•Disconnect the papilionaceous (flower petal like) nut washer and air cleaner filter.
•Check whether the foam filter element is dirty or air logged. Clean it if necessary.
•Newly equip the air cleaner and operate the engine until it is well equipped.

KisanKraft®
Centrifugal Water Pump For
Agriculture
KK-WPP-10 /15 /21 /31 /2535 /50080
: www.kisankraft.com
: [e-mail]
: +91.80. 22178200
Page 8 of 44
•It would accelerate the abrasion if the dust or the pollutant is absorbed into the
engine through carburetor.
6. Check the water pump:
•Check whether the water is added into the pump.
•The pump must be fully filled with water before operating.
•Operate the pump until the water is added so as to protect the air proof from the
overheating in lasting operation without water.
STARTING THE ENGINE
1. Keep the fuel valve to “ON” position.
2. Shut down the throttle (throttle may be partly closing or open when the engine is
warm or in the case of high temperature).
3. Keep the switch in the ON position.
4. Slowly move the regulating handle to the left.
5. Pull the start handgrip when feeling the resistance, then drawback swiftly.
USE
The use of the water pump:
1. Gradually open the throttle when the engine’s warm.
2. Set a scheduled rotation speed.
STOPPING THE ENGINE
1. Move the regulating handle to the right.
2. Keep the switch in the “OFF” position.
3. Turn off the fuel valve.
MAINTENANCE
Oil:
Change the oil and quickly discharge the oil when the engine is hot. Replace the oil for the
first time after 50 hours of cumulative operation. After that, replace the oil per 500 hours
operation. The specific procedure is as follows:
•Disconnect the oil cap and drain plug, then discharge the oil, newly equip the
drain plug and screw it down.
•Add the clean oil to the appointed oil level.
Air cleaner filter:
Air flow in the carburetor is reduced if air cleaner is dirty. In order to clean it:
•Move the papilionaceous nut, and disconnect the air cleaner filter cover and the
foam filter element with apyrous cleaning and then air dry it.
•Dip the foam filter element into the clean oil and extrude the additional oil.
Newly equip the foam filter element and air cleaner filter.
Spark plug:
It would be kept 0.7-0.8 mm between the spark plug and no carbon so as to assure the
normal running

KisanKraft®
Centrifugal Water Pump For
Agriculture
KK-WPP-10 /15 /21 /31 /2535 /50080
: www.kisankraft.com
: [e-mail]
: +91.80. 22178200
Page 9 of 44
STORAGE
Cool the engine and keep the fuel valve in the “OFF” position before moving or storing
indoors to avoid the burning or fire.
1. Keep the storage place dry and less dust.
2. Clean the inner parts of the engine.
3. Replace the oil after completely discharging the fuel tank and the carburetor.
4. Disconnect the spark plug to infuse 2-3 grams of oil into the cylinder and rotate
the engine 3-4 times and then equip the spark plug.
5. Cover the pump cover to avoid dust.
TROUBLESHOOTING
Problem
Probable cause
Action to be taken
The Engine can’t be
started
Refer the Engine manual
Refer the Engine manual
The pump cannot pump
water
The water infused is not
enough
Fill the pump with enough
water.
The filter is air –logged.
Clear the air from the filter.
The tie-in is not firmly
equipped ,
Suction pile is leaking.
Ensure proper suction
Packing is proper and leak
free.
The pipe is damaged.
Replace the pipe.
Whether the head lift is too
high
Never exceed the rated
max. Lift, if so lower the
head lift.
Insufficient flux
Any block with impeller or
strainer
Remove the blockage in
the strainer
Gas leakage in inlet pipe
Fix any leakage in the pipe
Damage in impeller
Replace the impeller

KisanKraft®
Centrifugal Water Pump For
Agriculture
KK-WPP-10 /15 /21 /31 /2535 /50080
: www.kisankraft.com
: [e-mail]
: +91.80. 22178200
Page 10 of 44
TECHNICAL SPECIFICATIONS
Model
KK-WPP-10
KK-WPP-15
KK-WPP-2535
Rated power
1.15 kW
Displacement
98 cc
Engine Type
4-stroke
Engine Model
KK-PE4-103
Rated rotation speed
(rpm)
3600
Fuel Used
Petrol
Fuel Tank Capacity
1.3 liter
Oil- For Engine
350 ml (20W40 grade)
Net Weight
11 kg
12 kg
11.5 kg
Fuel Consumption
700 ml /hour
Inlet / Outlet Port
(Diameter)
25x25 mm
(1x1”)
38x38 mm
(1.5x1.5”)
25x25 mm
(1x1”)
Suction (vertical)
3m (depth)
4m (depth)
3m (depth)
Delivery (horizontal)
20 m
20 m
35 m
Max flow
58 L/M
200L/M
133L/M
Head lift
8 m
15 m
35 m
Output capacity
8000 Liter/hour
12000 Liter/hour
7000 Liter/hour

KisanKraft®
Centrifugal Water Pump For
Agriculture
KK-WPP-10 /15 /21 /31 /2535 /50080
: www.kisankraft.com
: [e-mail]
: +91.80. 22178200
Page 11 of 44
Model
KK-WPP-50080
Rated power
4 kW(5.4 hp)
Displacement
212 cc
Engine Type
4-stroke
Bore X Stroke
70X55 mm
Engine Model
KK-PE4-170
Rated rotation speed
(rpm)
3600
Fuel Used
Petrol
Fuel Tank Capacity
3.6 L
Oil- For Engine
0.6 L
Net Weight
25 kgs
Diameter of Suction
Pipe
50 mm (2”)
Diameter of Delivery
Pipe
2x 40mm (1.5”)+1x50mm(2”)
Suction (vertical)
5 m
Max flow
5 L/s
Head lift
80 m

KisanKraft®
Centrifugal Water Pump For
Agriculture
KK-WPP-10 /15 /21 /31 /2535 /50080
: www.kisankraft.com
: [e-mail]
: +91.80. 22178200
Page 12 of 44
Model
KK-WPP-21
KK-WPP-31
Type
Self-priming
Inlet/Outlet size(mm)
50
80
Max lift(m)
30
Suction(m)
5~8
Engine model
KK-PE4-163
KK-PE4-203
Engine type
OHV,Single-cylinder,4-stroke,forced air cooling
Displacement
163cc
196cc
Rated power
2.3 kW (3 hp)
3 kW (4 hp)
RPM
3600
Max. torque
10N.m/2500rpm
11N.m/2500rpm
Max discharge capacity
(Liters per Hour)
36,000
60,000
Fuel tank capacity
3.6L
Engine oil capacity
0.6L
N.W/G.W (kgs)
25/27
28/30
Dimension
490x395x450
515x410x460

KisanKraft®
Centrifugal Water Pump For
Agriculture
KK-WPP-10 /15 /21 /31 /2535 /50080
: www.kisankraft.com
: [e-mail]
: +91.80. 22178200
Page 13 of 44
WATER PUMP PARTS DIAGRAM & LIST-KK-WPP-10/15

KisanKraft®
Centrifugal Water Pump For
Agriculture
KK-WPP-10 /15 /21 /31 /2535 /50080
: www.kisankraft.com
: [e-mail]
: +91.80. 22178200
Page 14 of 44
Part No
Part Name
Part No
Part Name
1.
Gasket bump(Paper)A
19.
Bolt M6x16
2.
Connecting Board of bump
20.
Bolt M6x85
3.
Bolt M8x18
21.
Rubber Gasket, Inlet And
Outlet Pipe
4.
Washer 10
22.
Inlet And Outlet Pipe
5.
Gasket bump(Paper)B
23.
Flange Nut Inlet And Outlet
Pipe
6.
Handrail
24.
Hoop
7.
Bottom Cover Of bump
25.
Upper bump Body
8.
Seal
26.
O Ring
9.
Washer 6
27.
Rubber Plug
10.
Bolt M6x20
28.
Bolt M8x14
11.
Impeller
29.
Taper Filter
12.
Packing bump Body
30.
Frame Assy
13.
O Ring
31.
Bottom Rubber
14.
Turbine
32.
Bolt M8x14
15.
bump Body
33.
Bolt M6x14
16.
Bolt M6x50
34.
Nut M8
17.
Single-Direction Valve
35.
Spring Washer 8
18.
Upper Corer Of bump Body
36.
Washer 8
PUMP PARTS DIAGRAM & LIST-KK-WPP-21/31
Pump Set Contents

KisanKraft®
Centrifugal Water Pump For
Agriculture
KK-WPP-10 /15 /21 /31 /2535 /50080
: www.kisankraft.com
: [e-mail]
: +91.80. 22178200
Page 15 of 44
SL-No
KK-No
KK-Name
Qty
1
E1-01
Pump body
1
2
E1-02
Pump Cover
1
3
E1-03
Triangle flange
1
4
E1-04
Pump Elbow
1
5
E1-05
Impeller
1
6
E1-06
Turbine
1
7
E1-07
rubber gasket, Triangle flange
1
8
E1-08
Rectangular rubber gasket
1
9
E1-09
Rubber Plug
2
10
E1-10
O-Ring(Rubber Plug)
2
11
E1-11
O-ring(Turbine)
1
12
E1-12
Rubber gasket(Bolt)
5
13
E1-13
Water Seal assy
1
14
E1-14
Bolt M8x55 Flanged Hex
4
15
E1-15
Bolt M8x25 Flanged Hex(SPL)
4
16
E1-16
N/A
1
17
E1-17
Washer 8-Plain
4
18
E1-18
O-Ring(Pump body)
1
19
E1-19
Bolt M8x20 Hex
7
20
E1-20
Bolt M8x25 Hex
5

KisanKraft®
Centrifugal Water Pump For
Agriculture
KK-WPP-10 /15 /21 /31 /2535 /50080
: www.kisankraft.com
: [e-mail]
: +91.80. 22178200
Page 16 of 44
Frame
SL-No
KK-No
KK-Name
Qty
1
E2-01
Frame assembly
1
2
E2-02
Rubber Bedding
4
3
E2-03
Clamp(Hose)
3
4
E2-04
Inlet and outlet pipe
1
5
E2-05
Flange nut
1
6
E2-06
Rubber gasket, inlet and outlet pipe
1
7
E2-07
Filter
1
8
***
N/A
1
9
E2-09
Bolt M6x12 Flanged Hex
4
10
E2-10
N/A
4
11
E2-11
Nut M8 Flange
2
12
E2-12
Bolt M8x45 Flanged Hex
4
13
E2-13
N/A
2

KisanKraft®
4-STROKE PETROL ENGINE
: www.kisankraft.com
: [e-mail]
: +91.80. 22178200
Page 17 of 44
USER MANUAL-4-STROKE PETROL ENGINE
BEFORE GETTING STARTED
Thank you for your purchase and use of our products. In order to avoid accidents or injury,
please read this manual carefully before using the machine. After reading, preserve it for
further reference. This manual is a part of the gasoline engine and should be transferred
when the machine is resold.

KisanKraft®
4-STROKE PETROL ENGINE
: www.kisankraft.com
: [e-mail]
: +91.80. 22178200
Page 18 of 44
SAFETY LABELS
DANGER
Indicates a hazard, if not avoided, can result in human injury or
death.
WARNING
Indicates a hazard, if not avoided, could result in human injury
and/or property damage.
CAUTION
Indicates a hazard, if not avoided, might result in slight injury
and/or property damage.
Please read and understand this owner’s manual before
operation of the engine to avoid accidents by familiarizing
yourself with your engine’s controls and safe operation
procedures.
SAFETY INSTRUCTIONS
1. Please perform some pre-operation checks before operation to avoid human
injury and equipment damage.
2. Keep the engine in good ventilated places at least 1 meter away from buildings
and other equipment’s during operation and keep the flammable substances
away from the engine to avoid fire.
3. Keep children and pets away from the operation area.
4. Make sure that the person who operates the engine receives proper instruction.
5. Keep the flammable substances (gasoline, matches) away from the operating
engine.
6. As gasoline is extremely flammable and explosive under certain conditions,
please refuel in a well-ventilated area with the engine stopped.
7. Do not fill above the shoulder of the fuel strainer.
8. Make sure the fuel cover is tightened.
9. Make sure that any spilled fuel has been wiped off before starting the engine.
10. Do not smoke or allow flames or sparks where the engine is refueled or where
gasoline is stored.
11. Exhaust contains poisonous carbon monoxide, a colorless and odorless gas.
Breathing exhaust can cause loss of consciousness and may lead to death. Do
not operate the engine without good ventilation or in enclosed room.
12. If you run the engine in an area that is confined, or even partially enclosed, the
air you breathe could contain a dangerous amount of exhaust gas. Provide
adequate ventilation so as to keep exhaust gas from accumulation.
13. Place the engine on flat (level) surface, tilting angle of the engine should not be
more than 20º, otherwise it will lead to fuel spilling out.
14. Do not cover the engine so as to avoid fire occurrence.
15. The muffler becomes very hot during and immediately after operation. Be careful
not to touch the muffler while it is hot. Let the engine cool down before storing the
engine indoor.

KisanKraft®
4-STROKE PETROL ENGINE
: www.kisankraft.com
: [e-mail]
: +91.80. 22178200
Page 19 of 44
PRE-OPERATION CHECKS
Check the Oil Level
Lubricating oil:
•Engine lubricant oil is a major factor affecting engine performance and service
life.
•The use of the lubricating oil free of cleaning agent or the lubricating oil for the
two-stroke engine will shorten the life of the gasoline engine.
•The operating temperature range recommended for the gasoline engine is -
5℃~40℃.
•Use 4-stroke motor lubricant oil. 20W-40 is recommended in general, at all
temperature use. Other viscosities shown in the chart may be used when the
average temperature in your area is within the indicated range.
Ambient temperature
•Before checking engine lubricant oil, place the engine on level surface
•Turn out the oil filler cap and clean the dipstick with a clean cloth.
•Insert the dipstick back into the oil filler hole without turning it in.
•If oil level is below the lower mark of the dipstick, fill oil to the upper level of the
dipstick.
•Reinstall the oil filler cap properly.
Upper level
Dipstick
Lower level

KisanKraft®
4-STROKE PETROL ENGINE
: www.kisankraft.com
: [e-mail]
: +91.80. 22178200
Page 20 of 44
Engine oil alert system (optional function):
The oil alert system is designed to prevent engine damage caused by insufficient oil in the
crankcase. When the oil level in the crankcase falls below the safe limit, the oil alert
system will automatically stop the engine even if the engine switch remains at the ON
position. If the engine stops and cannot be restarted, check the engine oil level before
troubleshooting in other areas.
(1) Drain plug
(2) Engine switch
(3) Lower level
Fuel Level
•Check the fuel gauge, and refill the tank if the fuel level is low. Do not fill above
the shoulder of the fuel strainer. The fuel 90# gasoline is recommended.
•Unleaded gasoline produces less engine and spark plug fouling and extends
exhaust system life.
•Never use stale or contaminated gasoline or oil/gasoline mixture. Avoid dirt,
rubbish and water from getting into the fuel tank.
•If spark knock or pinging occurs at a steady engine speed under normal load,
change brands of gasoline. If spark knock or pinging persists, see an authorized
dealer.
WARNING:
•Running the engine with persistent spark knock or pinging can cause engine
damage.
•If persistent spark knocks or pinging is caused by improper usage of the unit,
the Distributor’s Limited Warranty does not cover parts damaged by that.
(1) Fuel tank
(2) Fill in hole
(3) Red line level
