Kist Vue HM-6000 User manual

Thank you for purchasing our product. The following is our product warranty information and keep this manual
for future reference. Please read these safety instructions completely before operation. This product is a
device for recording driving images and is supposed to be installed inside of your motor vehicle to record
front, side and rear scenes. The product is designed to help a driver to drive safety and the purpose of the
audio and video recordings is to help collecting evidence of accidents, but has no legal validity.
At www. ibisview.co.kr, you can update and get online service of this product.
Our internet site will be update frequency, and support newest information.
-This manual's pictures are just for the understanding, so it is not always same as real products and it image
possible to change.
-The information in this manual may change without prior notice due to technical changes
Or upgrades. Check for updates periodically to ensure full knowledge of both the warranty service and
responsibility scope.
-We shall not be held responsible for damage causes by errors or date ross of this product,
as well as any damages or losses derived from the device not operating normally.
-The product is designed to record, store play and analyze videos caused by impacts and car accidents or
as recorded by user's discretion. However, it is not assured that the products will record video in every
instance
-Under circumstances where the impact is too weak, the vibration sensor may not be able to detect the
impact, which induces that the system will be unable to automatically start recording the event file.
-We cannot guarantee any product defects if you have used other kinds of storage medium than our
designated ones during the warrant period.
-The guarantee does not cover product defect claims related to user's careless fault, product disassemble,
power defects and natural disaster.
-All hardware, software, designs and logo of the product is copyrighted by the manufacturer of the product.
Copy, disassembly, remake and distribution without the manufacturer's written consent is strictly prohibited
and will be enforced by all legal rights held by the manufacturer.
Before use

-please be aware that ejecting the SD card before the LED is turned off may not be able to save the very
last recording file.
-please format the SD card 1 or 2 times by every month.
-We recommend change SD card when 6months past after normal power supply, or one year past after
ACC power supply (cigar jack of the vehicle)
-Please You must format when you see the saved video at smart phone.
-If you install rare camera, please connect to main body first and connect to power supply.
-If your car is Hybrid.
please take off your power when you finished driving.
*If you take off the SD card from black box by force, do not format the SD card 1 or 2 times by month,
or save another file on SD card, then please format the SD card.
*If your SD card has ERROR sign even after the format, please check the memory's lock switch or change
your SD card.
* In summer season, please do not over 70℃. It is possible to have chance of fire.
Also please do not too much below temperature. If it is below than their limited temperature, then
automatically shut down and reset for protect their system.
•please do not connect power all day long, it is possible to out of battery, fire, or short life of the product.
•We do not have any responsibility about this.
Caution

-We recommended only commodity SD card which included the products. We do not have any
responsibility to the error by using the non-commodity products.
-SD card is expendables. So please check their status and change when you need.
-Please format the SD disk about 1 or 2 times each month, and save important film to another
drive like HDD.
-If you format the SD card and put them on the product, then they have another folder appear
and record new film.
-please disconnected power and then take off the SD card from the body. If you take off the SD card
from the body with connected power, the last file will not record and cannot restoration.
-please check the LED light off on the body before the take-off SD card from the body.
-We use micro SD card for easily use on the smartphone. It is very small and sensitive, please be carefu
l to carry and handle of this.
-If you use for normal power supply, We recommended change your SD card every 6 months.
How to use SD memory card

Before use
1. Caution
2. preparation before to start.
-specifications
-characteristic
- component
- parts name
3.Operation
3-1 buttons 3-12 Smartphone viewers
3-2 LCD MENU 3-13 Microphones
3-3 LED lamp 3-14 Antitheft LED System
3-4 LCD Video-out 3-15 Firmware update
3-5 Power on/off 3-16 Memory storage time
3-6 Formats 3-17 Memory adapters
3-7 Protection discharge system 3-18 Save folder and folder
3-8 Parking record and motion perception 3-19 rear cameras
3-9 Video Memory
3-10 Manual function storage system
3-11 Smart Alarm
Contents
0

Contents
0
4. Memory format
How to memory format
5. Viewer program
Install
About player
6.Product installation
Install
Appendix
-Product warranty

.
Caution
1
Do not connect power all day long. If you connect long time
without started engine, it is possible to discharge. Please
disconnect power cord when you stopped car long time.
When the Summer season or Winter season, it is be careful on
the car's temperature.
please check the temperature and using at ideal temperature.
(14-158℉)
-Foreign substance
SD card is very sensitive by flooding, fire, and impact. If SD
card on damage, it cannot record.
-Do not disassemble and remodel
Please do not any disassemble and remodeling. It is possible
to trouble of your products.
And it cannotreceive any A/S for this cause
주의사항

Caution
1
-Do not close any metal city on the body.
The product included GPS antenna. If metal city put around
the body, it is possible to make low reception on GPS signal.
- Satellite time
When you start car, it will be take time for searching GPS
signal. It is affected on weather and around environment.
- Status
If you feel any smell or unusual function on body, please
check at A/S.
-SD card
please do not remove SD card during the working black box. It is
possible to make error on body and SD card.

Caution
1
When you need the film for any accident or any purpose, please
move the file to another computer or source and save. If you just
leave on SD card, it will be erase by passing time.
-If you want to install black box on your car, please visit installation
center. We do not responsibility on accident which is cause of this
point.

specifications
2
camera
lenz CMOS
record
infinite 1minete
illumination 0.1 LUX event before and after 10 seconds
angle 140 motion before and after 10 seconds
pixels 3Mpixels Parking
watch LED method Parking mode flashing
record
Encoding
speed H.264
etc
POWER DC 12V~24V
resolution 1280x720p GPS External(option)
frame 5~30f/s preservation
temperature -20℃ ∼ 80℃
record method infinite,event,motion,manual Working
temperature -10℃ ∼ 70℃
event
sensor Acceleration sensor G-sensor size 102X55X13mm
Record
method Micro SD CARD 2GB~32GB PC operating system Window XP,VISTA,7
BACK-UP
power Lithum- polymer 10second delay time viewer
program Exclusive player
Media player
preperration before to start

.
2
-HD 1280X720P high quality resolution
-a 3.0 megapixel camera
-Paring Recording system; after parking, system will change
to parking mode automatically. And if you star to move,
parking mode automatically change to driving mode.
product feature
-Motion sensor
: it is when the parking mode, system sensor some moving
object and people, then they start recording
-Driving mode recording and Event mode recording
: when driving, they recording everything or when event appear,
then emergency recording.
-Prevention of thefts: When parking, front LED light flaking automatically. That is help to protect from
thefts at the parking lot.
preperration before to start
-2.8” TFT LCD(Touch method)

.
2
-Voice recording option.
: Normally, the product record voice and film. But if you do not
want to record voice, then you can press button on the
product.
-Simple format system
: At standby mode, If you press middle button about 3 seconds on
the product, the SD card will format and become initialization.
-Battery protection
: If your car power voltage below 11.9V, then product power turn off
automatically.
-Power on/off
: If you press power button one time, then it will be standby
mode and stop the recording. However, if you press one more
time, it is turn to driving record mode automatically.
-Smartphone viewer
: If you want to see the film on your smartphone, then take off
the micro SD card from body and play on your smartphone
easily by exclusive viewer.
preperration before to start
product feature

.
2
-Overwrite
: If memory is full, then the product overwrites sources from
the oldest film.
Manual recording
: As occasion demands, manual recording can be start if you press
button.
-Power warranty
: The product included back up battery, and they will keep
about before and after 10seconds film when immediately
power off.
-Simple GPS
: If you have support which included GPS, then you can use
simple GPS system.
-Free volt power
: all kind of vehicle can be use power freely. (DC 12V-DC24V)
preperration before to start
product feature

.
2
-firmware update
: We supported firmware update by SD CARD
Viewer program
: We offer viewer program which can be see front view and
rare view at once.
- Temperature protection
: If your car temperature is over or below limited temperature, power will be turn off
automatically for protect our product.
preperration before to start
product feature

2
Car adaptor
Body
Manual
Micro SD CARD Micro SD adaptor
Rear camera
※Components will be possible to different between picture and real component, and it
is possible to change temporarily.
GPS supporter, SD card reader, AV cable is not included, and you can buy at the store.
preperration before to start
Componants

2Preparation Before Use
parts name
Operation
Status LED
Rear
CAM
DC12V~24V
GPS Port
MicroSD Slot
2.8” TFT LCD Touch
Screen
Mute Button
Manual
Recording
Lcd on/off
power ON/OFF
Camera
Security LED

Operation Guide
3
3-1. Getting Familiar with Function Buttons (in Recording Mode)
Press button ③for less than 1.5 seconds to turn off the LCD, and press the button again to turn on the LCD.
Press and hold button ③to turn off the black box function, stop recording and video output, and bring up the Menu screen.
Press and hold the button again to resume the black box and display the image on the screen.
Press button ②for less than 1.5 seconds to start manual recording, and forcefully save a 20-second video clip (10 seconds for
Front View; 10 seconds for Rear View).
Press and hold button ②for more than 1.5 seconds to change Video Output mode on the LCD screen.
PIP screen mode is shown on the initial screen by default.
Press the button to switch between Front View and Rear View in order.
Press button ①to mute the sound and stop audio recording. Press the button again to resume audio recording.
Press and hold button ①to disable the speaker. Press and hold the button again to re-enable the speaker.
②
③
①

Operation Guide
3
3-1. Getting Familiar with Function Buttons (in Menu Mode)
Press button ①to move to the next menu item. If the current item is the last item, the first item will be displayed.
Press and hold button ①to run the selected menu item.
Move to the previous menu item by pressing button ②for less than 1.5 seconds. If the current item is the first item, the
last item will be displayed.
Press and hold button ②for more than 1.5 seconds to format the SD card to FAT32.
Press button ③for less than 1.5 seconds to turn off the LCD. The LCD will be turned on if the button is pressed again.
To resume video recording, press and hold button ③for more than 1.5 seconds.
①
②
③

The items (All-Time, Impact, Parking, Forcefully Recorded File Replay) selected from the Main menu are displayed on the LCD screen when
entering Video Replay mode. A maximum of four files can be displayed on the screen. If the number of files is greater than 4, files will be
listed on the screen by page after being divided by 4.
If there is no file in the selected folder, the LCD will read "No File" for one second prior to displaying the Main menu.
Press button ①for less than 1.5 seconds in File List mode to move to the next file. If the current file is the last file, the fist file will be
displayed.
Press and hold button ①for more than 1.5 seconds in File List mode to replay the selected file. If the file is the last file, the first file will
be displayed.
Press button ②for less than 1.5 seconds in File List mode to move to the previous file. If the file is the last file, the last file will be
displayed.
Press and hold button ②for more than 1.5 seconds in File List mode to move to the Main menu screen.
Press button ③for less than 1.5 seconds in File List mode to turn the LCD off. Repeatedly pressing the button will turn the LCD on.
Press and hold button ③for more than 1.5 seconds in File List mode to move to the Main menu screen.
Press button ①for less than 1.5 seconds in File Replay mode to replay the next file. If the current file is the last file, the first file will be
replayed.
Press button ②for less than 1.5 seconds in File Replay mode to replay the previous file. If the current file is the first file, the last file will
be replayed.
Press and hold button ②for more than 1.5 seconds in File Replay mode to switch between Front View and Rear View channels.
Press button ③for less than 1.5 seconds in File List mode to turn the LCD off. Briefly pressing the button again will turn the LCD on.
Press and hold button ③for more than 1.5 seconds in File Replay mode to stop replaying video.
Operation Guide
3
①
②
③
3-1. Getting Familiar with Function Buttons (Play Mode)

Operation Guide
3
3-2. Getting Familiar with the Menus –Main Menu Screen
※ Lightly touch the LCD screen in Black Box Recording mode to bring up the Menu mode.
1. View Video: To show and play all-time, event recording, parking motion recording, and manual recording file lists.
2. Start Recording: Press the Recording Start button to start black box recording. Be aware that recording is paused in Menu
mode.
3. Set Time: To move you to the screen used for setting time, including year, month, date, hour, minute, etc.
4. Preferences: To move you to the screen used for setting recording conditions and formatting.

Operation Guide
3
3-2. Getting Familiar with the Menus –View Video
All-Time Recording: To show files that have been recorded at one-minute intervals and saved at all times.
Impact Recording: To show file lists including event files or files created at the time of impact.
Parking Monitoring: To show file lists including motion-recorded files at the time of parking.
Forceful Recording: To show file lists including manually recorded files.
※Select a file list or press the Play button to play the video. Holding down the LCD screen for more than one second while pla ying
the video will take you to the List screen.
※ You can switch between the front and rear view by holding down button ②for a while. (3-2 button function: Refer to Replay
mode)
