Undercounter Dishwasher
®
PRODUCT MODEL SERIES OVERALL DIMENSIONS
CABINET OPENING DIMENSIONS
KUDC02IR
KUDI02CR
KUDI02FR
KUDI02IR
KUDJ02CR
KUDK02CR
KUDL02FR
KUDL02IR
KUDP02CR
KUDP02FR
KUDP02IR
KUDP02SR
KUDS02FR
KUDS02SR
KUDU02FR
KUDW02FR
Electrical: 120-volt, 60 Hz, AC-only, 15 or
20 amp electrical supply. Use copper wire only. A
time-delay fuse or circuit breaker and separate
circuit is recommended.
Water: A hot water line with 20-120 psi
(138-862 kPa) water pressure. Water temperature
must be minimum 120°F (49°C) at dishwasher.
Use 3/8" O.D. copper tubing with compression
fitting or flexible stainless steel braided fill line
(1/2" minimum plastic tubing is not
recommended). Use a 90° elbow with 3/8" N.P.T.
external pipe threads on one end to connect to
water inlet valve. Do not solder within 6" (15.2 cm)
from water inlet valve.
Drain: Use the new drain hose supplied with your
dishwasher. If this is not long enough, use a new
drain hose with a maximum length of 12 feet
(3.7 m) that meets all current AHAM/IAPMO test
standards, is resistant to heat and detergent, and
fits the 1" (2.5 cm) drain connector of the
dishwasher.
Connect drain hose to waste tee or disposer inlet
above drain trap in house plumbing and 20"
(50.8 cm) minimum above the floor. It is
recommended that the drain hose either be looped
up and securely fastened to the underside of the
counter, or be connected to an air gap.
Use an air gap if the drain hose is connected to
house plumbing lower than 20" (50.8 cm) above
subfloor or floor.
Use 1/2" minimum I.D. drain line fittings
Corner installation: Allow 2" (5,1 cm)
minimum between corner wall and dishwasher
opening.
Do not install dishwasher over carpeted floor.
A side panel kit is available from your dealer for
installing your dishwasher at the end of a cabinet.
Because Whirlpool Corporation policy includes a continuous commitment to improve our
products, we reserve the right to change materials and specifications without notice.
Dimensions are for planning purposes only. For complete details, see Installation
Instructions packed with product. Specifications subject to change without notice.
Ref. 8573157
08-22-05
23-7/8" (60.6 cm)
SIDE VIEW REAR VIEW
24-7/8" (63.2 cm)
3/4" (1.9 cm)
insulation –
may be
compressed
(not used on
all models)
24-1/2" (62.2 cm)* front vent
21" (53.3 cm)
33-7/8"
(86 cm) min.
with wheels
removed
9"
(22.9 cm) 10"
(25.4 cm)
6" ***
(15.2 cm)
6" ***
(15.2 cm)
3-1/4"
(8.3 cm)
2-3/4"
(7 cm)
34"
(86.4 cm)
min.*
2"
(5.1 cm)
2"
(5.1 cm)
All surfaces must be free
from intrusions
2"
(5.1 cm)
3-1/4"
(8.3 cm)
3-1/4"
(8.3 cm)
2-3/4"
(7 cm)
3-1/4"
(8.3 cm)
24" (61 cm)
min.
24" (61 cm)
**
Cut holes in shaded area of cabinet walls or floor as specified below:
water line – 1/2" (1.3 cm)
drain line – 1-1/2" (3.8 cm)
direct wire – 3/4" (1.9 cm)
power supply cord – 1-1/2" (3.8 cm)
* Measured from the lowest point on the underside of countertop. May be
reduced to 33-7/8" (86 cm) by removing wheels from dishwasher.
** Minimum, measured from narrowest point of opening.
*** May be increased to 6-5/8" (16.6 cm) if height of opening is 34-1/2"
(87.6 cm) at its lowest point.
5-1/2"
(14 cm)
3-1/2"
(8.9 cm)
