KitchenAid 720-0709C User manual

FREESTANDING OUTDOOR GRILL
InstallationInstructionsandUse&CareGuide
For questions about features, operation/performance, parts, accessories or service, call: 1-877-373-2301
or visit our website at www.Kitchenaidgrills.com
ASADOR AUTÓNOMO PARA EXTERIORES
Instrucciones deinstalación yManualdeuso ycuidado
Para consultas respecto a características, funcionamiento, rendimiento, piezas, accesorios o servicio técnico, llame al: 1-877-373-2301
o visite nuestro sitio de internet en www.Kitchenaidgrills.com
GRIL D'EXTÉRIEUR AUTOPORTANT
Instructionsd’installation etGuided’utilisation etd’entretien
Pour des questions à propos des caractéristiques, du fonctionnement/rendement, des pièces, des accessoires ou du service,
composer le : 1-877-373-2301
ou visiter notre site web www.Kitchenaidgrills.com
Table of Contents/Índice/Table des matières................................................................................. 2
720-0709C (LP) 730-0709C(NG) 19000395A0

OUTDOOR GRILL SAFETY…………………………………2
INSTALLATION REQUIREMENTS…………………….…..5
Tools and Parts…..………………………………………5
Location requirements……………………………….….5
Product Dimensions……………………………………..6
Gas Supply Requirements………………………………6
Gas Connection Requirements…………………………7
PACKAGE CONTENTS LIST ………………………………8
REPLACEMENT PARTS…………………………………….9
INSTALLATION INSTRUCTIONS…………………..……..12
Freestanding Outdoor Grill Installation………………12
Make Gas Connection…………………………...…….15
GAS CONVERSION…………………………………............16
Tools and Parts for Gas Conversion……………….....16
Conversion from LP Gas to Natural Gas……………...17
Check and Adjust the burners…………………………20
TABLE OF CONTENTS
OUTDOOR GRILL USE…………………………………………21
Using Your Outdoor Grill…………………………....……….21
TIPS FOR OUTDOOR GRILLING……………..………………24
Cooking Methods…………………………………………….24
Grilling Chart………………………………………………….24
OUT DOOR GRILL CARE…………………………...…………25
Replacing the Igniter Battery………………………………..27
General Cleaning……………………………………….……27
TROUBLE SHOOTING...........................................................29
ASSISTANCE……………………………………………………29
WARRANTY……………………………………………………...30
2
SEGURIDAD DEL ASADOR PARA EXTERIORE……......32
REQUISITOS DE INSTALACIÓN ……………………….....34
Herramientas y piezas ………...…………………………34
Requisitos de ubicación …………………………………34
Medidas del producto …………………………………...35
Requisitos del suministro de gas …………………........35
Requisitos para la conexión de gas …………………....36
LISTA DE CONTENIDO DEL PAQUETE…………..…...…37
PIEZAS DE REPUESTO ……………………………………38
INSTRUCCIONES DE INSTALACIÓN ……………………41
Instalación del asador autónomo para exteriores ……42
Conexión del suministro de gas ………………………..44
CONVERSIONES DE GAS …………………………………45
Herramientas y piezas para la conversión de gas …...45
Conversión de gas LP a gas natural …………………..46
Revise y regule los quemadores …………………….....49
ÍNDICE
USO DEL ASADOR PARA EXTERIORES …………………..50
Cómo usar el asador para exteriores ………………....…..50
CONSEJOS PARA ASAR AL AIRE LIBRE ……………...…..54
Métodos de cocción …………………………………….. ...54
Cuadro para asar …………………………………………....55
CUIDADO DEL ASADOR PARA EXTERIORES ……………57
Cómo reemplazar la batería del encendedor ………….....57
Limpieza general …………………………………………….57
SOLUCIÓN DE PROBLEMAS...............................................59
ASISTENCIA…………………………………………………….59
GARANTÍA …………………………………………………........60
SÉCURITÉ DU GRIL D'EXTÉRIEUR ………..……………62
EXIGENCES D’INSTALLATION ……………..……………64
Outils et pièces ……………...………………..………….64
Exigences d'emplacement …………………..………….64
Dimensions du produit ………………………….…….....65
Spécifications de l'alimentation en gaz ……………….66
Exigences concernant le raccordement au gaz………67
LISTE DU CONTENU DE L'EMBALLAGE………………..68
PIÈCES DE RECHANGE …………………………………..69
CONSIGNES D’INSTALLATION…………………….…….73
Installation du gril d’extérieur autoportant ……………73
Raccordement au gaz …………………………...………76
CONVERSIONS POUR CHANGEMENT DE GAZ ……....78
Outils et pièces pour conversion de gaz ……………...78
Conversion de propane à gaz naturel …………………78
Contrôle et réglage des brûleurs ………………….…....81
TABLE DES MATIÈRES
UTILISATION DU GRIL D’EXTÉRIEUR ………………….......82
Utilisation du gril d’extérieur ………………………….…….82
CONSEILS POUR L'UTILISATION DU GRIL
D'EXTÉRIEUR .......................................................................85
Méthodes de cuisson ……………………………………….85
Tableau de cuisson au gril ………………………………….86
ENTRETIEN DU GRIL D’EXTÉRIEUR ………………….……89
Remplacement de la pile de l’allumeur …………………...89
Nettoyage général ……………………………………...……89
DÉPANNAGE..........................................................................91
ASISTANCE……………………………………………………...91
GARANTIE………………………………………………….........92

OUTDOOR GRILL SAFETY
IMPORTANT: This grill is manufactured for outdoor use only. For grills that are to be used at elevations above 2,000ft (609.6 m)
orifice conversion is required. See “ Gas Supply Requirements” section. It is the responsibility of the installer to comply with the
minimum installation clearances specified on the model/serial rating plate. The model/serial rating plate for freestanding models
can be found on the inside cabinet door.
3
DANGER
If you smell gas:
1.Shut off gas to the appliance.
2.Extinguish any open flame.
3.Open lid.
4.If odor continues, keep away from the
appliance and immediately call your gas
supplier or your fire department
WARNING
1. Do not store or use gasoline or other
flammable liquids or vapors in the vicinity
of this or any other appliance.
2. An LP cylinder not connected for use
shall not be stored in the vicinity of this or
any other appliance.
State of California Proposition 65 Warnings:
WARNING: This product contains one or more chemicals known to the State of California to cause cancer.
WARNING: This product contains one or more chemicals known to the State of California to cause birth defects or other
reproductive harm.
In the State of Massachusetts, the following installation instructions apply:
Installations and repairs must be performed by a qualified or licensed contractor, plumber, or gasfitter qualified or licensed
by the State of Massachusetts.
If using a ball valve, it shall be a T-handle type.
A flexible gas connector, when used, must not exceed 3 feet.

IMPORTANT SAFETY INSTRUCTIONS
WARNING: To reduce the risk of fire, electrical shock,
Injury to persons, or damage when using the outdoor cooking
gas appliance, follow basic precautions, including the following:
Do not install portable or built-in outdoor cooking gas
appliances in or on a recreational vehicle, portable
trailer, boat or in any other moving installation.
Always maintain minimum clearances from
combustible construction, see “Location
Requirements”section.
The outdoor cooking gas appliance shall not be located
under overhead unprotected combustible construction.
This outdoor cooking gas appliance shall be used only
outdoors and shall not be used in a building, garage, or
any other enclosed area.
Keep any electrical supply cord and fuel supply hose
away from any heated surfaces.
Keep outdoor cooking gas appliance area clear and
free from combustible material, gasoline and other
flammable vapors and liquids.
Do not obstruct the flow of combustion and ventilation
air. Keep the ventilation openings of the cylinder
enclosure free and clear from debris.
Open the cabinet door and Inspect the gas cylinder supply
hose before each use of the outdoor cooking gas appliance.
If the hose shows excessive abrasion or wear, or is cut, it
MUST be replaced before using the outdoor cooking gas
appliance. Contact your dealer and use only replacement
hoses specified for use with the outdoor
cooking gas appliance.
Visually check the burner flames.
They should be blue. Slight
yellow tipping is normal for
LP gas. The flames should
Be approximately 1" (2.5 cm) high.
Check and clean burner/venturi tube for insects and
insect nest. A clogged tube can lead to fire under the
outdoor cooking gas appliance.
The LP gas supply cylinder to be used must be:
- constructed and marked in accordance with the
Specification for LP Gas cylinders of the U.S.
Department of Transportation (DOT) or the
National Standard of Canada, CAN/CSA-b339,
Cylinders, Spheres, and Tubes for Transportation
of Dangerous Goods; and Commission.
- provided with a listed overfilling prevention device.
- provided with a cylinder connection device
compatible with the connection for outdoor cooking
gas appliances.
Always check connections for leaks each time you
connect and disconnect the LP gas supply cylinder.
See “Installation Instructions”section.
When the outdoor cooking gas appliance is not in
use, the gas must be turned off at the supply cylinder.
Storage of an outdoor cooking gas appliance indoors
is permissible only if the cylinder is disconnected
and removed from the outdoor cooking gas appliance.
Cylinders must be stored outdoors and out of the
reach of children and must not be stored in a
building, garage, or any other enclosed area.
The pressure regulator and hose assembly supplied
with the outdoor cooking gas appliance must be
used. A replacement pressure regulator and hose
assembly specific to your model is available from
your outdoor cooking gas appliance dealer.
Gas cylinder must include a collar to protect the
cylinder valve.
For appliances designed to use a CGA791
Connection: Place a dust cap on cylinder valve
outlet whenever the cylinder is not in use. Only
install the type of dust cap on the cylinder valve
outlet that is provided with the cylinder valve. Other
types of caps or plugs may result in leakage of
propane.
If the following information is not followed
exactly, a fire causing death or serious injury may occur.
Do not store a spare LP gas cylinder under or near
this outdoor cooking gas appliance.
Never fill the cylinder beyond 80 percent full.
SAVE THESE INSTRUCTIONS
4

Installation Requirements
Tools and Parts
Gather these required tools and parts before starting installation.
Read and follow the instructions provided with any tools listed
here.
Location Requirements
Parts Supplied
Gas pressure regulator/hose assembly set for 11”WCP LP
gas
Right side shelf
Left side shelf
“AA”Battery (5)
Warming rack
Cooking grid
Grease box
Door hinges
Flame tamers
Natural gas orifice for sear side burner
5
Tools needed
Phillip screwdriver
Wrench or pliers
Pipe wrench
Scissors or cutting pliers (to
remove tiedowns)
Noncorrosive leak-detection
solution
Parts Needed
20 lb LP gas fuel tank-approximately 18” (45.7cm) height.
Parts Needed for Conversion to Natural Gas
Natural gas conversion kit Part Number 710-0003. See
“Assistance” section to order. The conversion kit includes:
Natural gas regulator 4" W.C. (marked “Natural Gas
Regulator”)
10 ft (3.0 m) Natural gas hose with quick connector
5.9" (150 mm) Natural gas regulator hose
6 mm nut driver
6 mm wrench
Hex key
Gas line shutoff valve
1/2" male pipe thread nipple for connection to pressure
regulator.
LP gas-resistant pipe-joint compound
CSA design-certified outdoor flexible stainless steel
appliance connector (4-5 ft [1.2-1.5 m]) or rigid gas supply
line as needed.
Select a location that provides minimum exposure to wind
and traffic paths. The location should be away from strong
draft areas.
Do not obstruct flow of combustion and ventilation air.
Clearance to combustible construction for grill:
A minimum of 24” (61 cm) must be maintained between
the front of the grill hood, sides and back of the grill
and any combustible construction.
A 24” (61 cm) minimum clearance must also be
maintained below the cooking surface, and the grill
shall not be used under overhead combustible
construction.
Rotisserie (accessory)*
If you equip your grill with a rotisserie, a 6" (15.2 cm)
minimum clearance is needed for the rotisserie motor.
A grounded, 3-prong outlet located to the left of the grill is
required.
*See “Assistance” section to order.

Product Dimension
A. Model/Serial number plate
Gas Supply Requirements
Observe all governing codes and ordinances.
IMPORTANT: This installation must conform with all local
codes and ordinances. In the absence of local codes,
installation must conform with either the National Fuel Gas
Code, ANSI Z223.1/NFPA54, Natural Gas and Propane
Installation Code, CSA B149.1, Propane Storage And Handling
Code, B149.2, or the Standard for Recreational Vehicles, ANSI
A119.2/NFPA 1192 and CSA Z240 RV Series Recreational
Vehicle Code as applicable.
IMPORTANT: Grill must be connected to a regulated gas
supply. Refer to the model/serial rating plate for information on
the type of gas that can be used. If this information does not
agree with the type of gas available, check with your local gas
supplier.
Gas Conversion:
No attempt shall be made to convert the grill from the gas
specified on the model/serial rating plate for use with a different
gas type without consulting the serving gas supplier. The
conversion kit supplied with grill must be used. See “Gas
Conversions” section for instructions.
Gas Pressure Regulator
The gas pressure regulator supplied with this grill must be used.
The inlet (supply) pressure to the regulator should be as follows
for proper operation:
LP Gas:
Operating pressure: 11" (27.9 cm) WCP
Inlet (supply) pressure: 11" to 14" (27.9 cm to 35.5 cm) WCP
Natural Gas:
Operating pressure: 4" (10.2 cm) WCP
Inlet (supply) pressure: 7" to 14" (17.8 cm to 35.5 cm) WCP
maximum.
Contact local gas supplier if you are not sure about the inlet
(supply) pressure.
A
6
The model/serial number rating plate is located on the
inside of the right cabinet door. See the following
illustration.

20 lb LP Gas Fuel Tank
This grill is equipped for use with a 20 lb LP gas fuel tank (fuel
tank not supplied). A gas pressure regulator/hose assembly is
supplied.
Any brand of 20 lb LP gas fuel tank is acceptable for use with the
grill, provided that it is compatible with the grill’s retention means
(tank tray included).
It is also design-certified by CSA International for local LP gas
supply or for Natural gas with appropriate conversion.
The 20 lb LP gas fuel tank must be mounted and secured.
Door style Tank Tray
1. Open cabinet doors.
2. Slide the tank tray locking bracket
counterclockwise 90˚and pull out the tray.
Burner Requirements for High Altitude
Input ratings shown on the model/serial rating plate are for
elevations up to 2,000 ft (609.6 m).
For elevations above 2,000 ft (609.6 m), ratings are reduced at a
rate of 4% for each 1,000 ft (304.8 m) above sea level. Orifice
conversion is required. See “Assistance” section to order.
Gas Supply Line Pressure Testing
Testing above 1/2 psi (3.5 kPa) or 14" (35.5 cm) WCP (gauge):
The grill and its individual shutoff valve must be disconnected
from the gas supply piping system during any pressure testing of
that system at test pressures greater than 1/2 psi (3.5 kPa).
Testing below 1/2 psi (3.5 kPa) or 14" (35.5 cm) WCP (gauge)
or lower:
The grill must be isolated from the gas supply piping system by
closing its individual manual shutoff valve during any pressure
testing of the gas supply piping system at test pressures equal to
or less than 1/2 psi (3.5 kPa).
A. Gas pressure regulator/hose assembly
A
7
3. Place the 20 lb LP gas fuel tank bottom collar into
the mounting hole in the tank tray.
4. Tighten the locking screw against the bottom collar
of the Natural Gas Conversion 20 lb LP gas fuel tank to
secure.
A. Tank tray locking bracket
A
5. Slide the drawer with the 20 lb LP gas fuel tank back into the
cabinet. Turn the tank tray locking bracket clockwise 90˚
to tighten.
A
A. Tank tray locking bracket
Gas Connection Requirements
A. Locking screw
B. Mounting hole
C. Bottom collar
A
C
B
Natural Gas Conversion
Conversion must be made by a qualified gas technician. The
qualified Natural gas technician shall provide the Natural gas
supply to the selected grill location in accordance with the
National Fuel Gas Code ANSI Z223.1/NFPA 54 - latest edition,
and local codes. For conversion to Natural gas, the Natural
Gas Conversion Kit supplied with the grill (on some models) or
the Natural Gas Conversion Kit Part Number 710-0003 must
be used. See “Assistance” section for information on ordering.
IMPORTANT: The gas installation must conform with local
codes, or in the absence of local codes, with the National Fuel
Gas Code, ANSI Z223.1/NFPA 54 - latest edition.
Follow instructions for converting to Natural gas in the “Gas
Conversions” section of this manual or the instructions
supplied with Natural Gas Conversion Kit Part Number 710-
0003.
The gas supply line shall be equipped with an approved
shutoff valve. This valve should be located in the same area as
the grill and should be in a location that allows ease of opening
and closing. Do not block access to the shutoff valve. The
valve is for turning on or shutting off gas to the grill.
A. Gas supply line
B. Shutoff valve “open” position
C. To grill

A. Firebox assembly-—1pc
D. Grease cup—1pc
C. Right side shelf—1pc
E. Warming rack—1pc
H. Flame Tamer—5pcs
F. Cooking grid—3pcs
G. Battery—5pc
B. Left side shelf—1pc
I. Side Cooking grid—1pcs
PACKAGE CONTENTS LIST
8

Replacement Parts
9
65
64
66
67
68
69
70
71 72
73
74
77
76 78
75 79
80
53
23
14
15
16
17
56
51
52
55
57
58
59
60
61
62
63
01
02
03
04 02
06
05
07
34
35
36
37
38
40
39
41
08
09
10
12
13
11
18
19
20
21
24
25
26
27
28
29
30
31
32
33
44
45
42
43
46
47
43
48
49
54
50
22
81a
81b
81c
81d
81e
81g
81f
81
NG Conversion Kit

11Bottom panel5811Tempered glass fix panel29
Part List
Part
Number Part (description) Warranty Coverage Quantity Part
Number Part description) Warranty Coverage Quantity
1 Main lid 3 1 30 Tempered glass 1 1
2 Main lid screw 1 2 31 Control knob bezel 1 6
3 Temperature gauge seat 1 1 32 Control knob 1 6
4 Temperature gauge 1 1 33 Light switch 1 1
5 Main lid handle seat, left 1 1 34 Sear burner lid 1 1
6 Main lid handle seat, right 1 1 35 Sear burner lid handle 1 1
7 Main lid handle tube 1 1 36 Sear burner lid hinge 1 2
8 Warming rack 1 1 37 Sear burner cooking grid 3 1
9 Cooking grid with hole 3 3 38 Sear burner 1 1
10 Flame tamer 1 5 39 Sear burner grease tray 1 1
11 Burner Pin assenbly 1 5 40 Sear burner igniter wire 1 1
12 Main burner 10 5 41 Sear burner bowl
assembly 11
13 Main burner igniter wire A 1 1 42 Side shelf, left 1 1
14 Main burner igniter wire B 1 1 43 Hooks 1 6
15 Main burner igniter wire C 1 1 44 Side shelf end cap, left 1 1
16 Main burner igniter wire D 1 1 45 Side shelf front panel, left 1 3
17 Main burner igniter wire E 1 1 46 Side shelf, right 1 1
18 Main lid bracket, right 1 1 47 Side shelf end cap, right 1 1
19 Main lid bracket, left 1 1 48 Side shelf control panel,
right 13
20 Main burner bowl
assembly
Non-
replaceable 1 49 Back panel 1 1
21 Front baffle 1 1 50 Rubber grommet 1 1
22 Main gas valve 1 5 51 Firebox support 1 1
23 Searing gas valve 1 1 52 Heat shield, left 1 1
24 Main manifold 1 1 53 Electronic igniter modular 1 1
25 Regulator LP 1 1 54 Side panel, right 1 1
26 Control panel light 1 1 55 Heat shield, right 1 1
27 Main control panel 1 1 56 Grease box 1 1
28 Logo 1 1 57 Clapboard 1 1
10

1
PVC cover
11
Gas tank tray slide
bracket, left
75
Part
Number Part (description) Warranty Coverage Quantity Part Number Part (description) Warranty Coverage Quantity
59 Swivel caster with brake 1 1 76 Gas tank tray slide 1 1
60 Swivel caster 1 1 77 Tank bolt 1 1
61 Casters 1 2 78 Gas tank tray slide bracket, right 1 1
62 Lighting rod 1 1 79 Gas tank tray 1 1
63 Lighting rod cover 1 1 80 Electronic igniter modular cover 1 1
64 Door, right 3 1 81 NG conversion Kit NG conversion kit sold
separately as a set
65 Door, left 3 1 81a NG regulator assembly for NG unit 1
66 Door handle tube 1 2 81b NG Gas Hose with Quick
Connector assembly for NG unit 1
67 Door handle seat 1 4 81c 6mm Nut Driver 1
68 Side panel, left 1 1 81d Hex Wrench 1
69 Center panel 1 1 81e 6mm Wrench 1
70 Cart frame 1 1 81f Flat Washer 2
71 Door magnet 1 2 81g Truss Head Screw with Lock 2
72 Battery box 1 1 Preassembly hardware pack 1
73 Door hinge 1 4 NG orifice pack 1
74 Tank tray block piece 1 1 Manual 1
11

INSTALLATION INSTRUCTIONS
Freestanding Outdoor Grill Installation
Unpack Grill
1. Remove all packaging materials and remove grill from the
shipping base.
2. Move grill close to desired outdoor location.
3. Open the grill hood.
Remove Packaging Material Inside the Grill
4. Remove the grill grates (F).
5. Remove warming rack (E) on brackets as
shown.
F
E
Attach right side shelf
IMPORTANT: This step is meant to help with the
installation, but do not depend solely on the two
screws to hold the weight of the side shelf.
1. Unpack right side shelf (C).
2. Loosen and remove 3 screws on left side shelf.
3. Loosen but do not remove the 2 screws on the side panel (A),
remove the screw lock on the main control panel (B).
A
B
4. Align slots on the side shelf with the loosened screws. Hook
the side shelf onto the two loosened screws and let the shelf
slide down so the screws are in the narrow neck of the slots.
1. Use a utility knife to cut straps and packing tape to open
box from top and remove the boxes.
2. Remove the warming shelf and grill grates from inside the
grill and remove the package inside the firebox.
3. Remove foam block and wrap from inside the grill.
12

Attach Left Side Shelf
1. Unpack left side shelf (B).
2. Loosen but do not remove the 2 screws on the side
panel (A). Remove the 3 screws on the side panel (B).
Remove the screw on main control panel (C).
IMPORTANT: This step is meant to help with the
installation, but do not depend solely on the two
screws to hold the weight of the side
shelf.
A
B
C
13
5. Attach the top of the side shelf to the grill firebox
by inserting three screws into the side shelf
from inside the grill firebox and tighten. See (A) below.
6. Attach the bottom of the side shelf to the side panel of
the grill by tightening the two screws inserted in the
keyhole slots in Step 3. See (B) below.
7. Attach the side shelf to the control panel by inserting
screw which was removed from step 3 and tighten,
A
B
C
3. Align the bottom keyhole slots on the side shelf with
the loosened screws. Hook the side shelf onto the two
loosened screws and let the shelf slide down so the
screws are in the narrow neck of the slots.
A
B
C
4. Attach the top of the side shelf to the searing side burner
side by inserting three screws from side shelf side and
tighten. See (B) below.
5. Attach the bottom of the side shelf to the side panel of
the grill by tightening the two screws inserted in the
keyhole slots in Step 2. See (A) below.
6. Attach the side shelf to the control panel by
inserting the screw which was removed from step 3
and tighten. See (C) below.
see (C) below.

Spare Parts Assembly
1. Unpack the searing burner grease cup, 5 flame tamer (H), 3
cooking grid (F), warming rack (E), and searing side burner
cooking grid (I).
2. Put the flame tamers on the indentations in firebox.
3. Then put on the cooking grid and warming rack
and searing side burner grids.
4. Open the cart door and place the grease cup between the
grease cup bracket.
5. Slide out battery box cover which is located on cart central
panel left side. Put 4 batteries which are packed in manual bag,
into battery box. Reinstall the battery box.
Igniter Battery Assembly
1. Unscrew igniter button cap counterclockwise to remove.
2. Place the battery in, negative end first, and screw the
igniter button cap clockwise.
Grease cup
F
E
I
H
Battery box
Battery box
cover
A.
“ AA ” sized battery
B. Igniter cap
Cover your grill
Allow grill to cool down and cover grill when not in use.
14
Sering burner grease cup

Make Gas Connection
NOTE: If grill is to be converted to Natural gas, follow
instructions in the “Gas Conversions” section.
20 lb LP Gas Fuel Tank
To Connect the 20 lb LP Gas Fuel Tank:
1. Check that the 20 lb LP gas fuel tank is in the “Off”
position. If not, turn the valve clockwise until it stops.
2. Check that the 20 lb LP gas fuel tank valve has the proper
type-1 external male thread connections per ANSI Z21.81.
3. Check that the burner control knobs are in the “Off”
position.
4. Remove any debris and inspect the valve connections,
port, and gas pressure regulator/hose assembly for damage.
NOTE: Always keep the LP cylinder at 90°(upright)
orientation to provide vapor withdrawal.
5. Using your hand, turn the gas pressure regulator/hose
assembly clockwise to connect to the 20 lb LP gas fuel tank
as shown.
Hand tighten only. Use of a wrench could damage the quick
coupling nut.
A. Gas pressure regulator/hose assembly
B. 20 lb LP gas fuel tank
A
B
Make sure that the cylinder valve connection device
properly mates with the connection device attached to the
inlet of the pressure regulator.
6. Open the tank valve fully by turning the valve
counterclockwise. Wait a few minutes for gas to move
through the gas line.
7. Before lighting the grill, test all connections by brushing
on an approved noncorrosive leak-detection solution.
Bubbles will show a leak.
8. If a leak is found, turn the tank valve off and do not use
the grill. Contact a qualified gas technician to make repairs.
9. Go to “Check and Adjust the Burners” section.
LP Gas:
IMPORTANT: A 20 lb LP gas fuel tank must be purchased
separately.
IMPORTANT: The gas pressure regulator/hose assembly
supplied with the grill must be used. Replacement gas pressure
regulator/hose assembly specific to your model is available from
your outdoor grill dealer.
Door Style Tank Tray
1. Open cabinet doors.
2. Slide the tank tray locking bracket counterclockwise 90º
and pull out the tray.
A. Tank tray locking bracket
A
3. Place the 20 lb LP gas fuel tank bottom collar into the
mounting hole in the tank tray.
4. Tighten the locking screw against the bottom collar of
the 20 lb LP gas fuel tank to secure.
A
B
C
A. Locking screw
B. Mounting hole
C. Bottom collar 15

To Disconnect the 20 lb LP Gas Fuel Tank:
1. Check that the burner control knobs are in the “Off” position
and the grill is cool.
2. Check that the 20 lb LP gas fuel tank is in the “Off” position. If
not, turn the valve clockwise until it stops.
3. Using your hand, turn the gas pressure regulator/hose
assembly counterclockwise to disconnect to the 20 lb LP gas fuel
tank as shown.
Hand loosen only. Use of a wrench could damage the quick
coupling nut.
A. Gas pressure regulator/hose assembly
B. 20 lb LP gas fuel tank
AB
4. Place dust cap on cylinder valve outlet whenever the cylinder is
not in use. Only install the type of dust cap on the valve outlet that
is provided with the cylinder valve. Other types of caps or plugs
may result in leakage of propane.
16
GAS CONVERSION
Tools and Parts for Gas Conversion
Gather the required tools and parts before starting installation.
Read and follow the instructions provided with any tools listed
here.
Parts supplied
Natural gas orifices
Parts needed
Natural gas conversion kit Part Number 710-0003. See
“Assistance” section to order. The conversion kit includes:
Natural gas regulator 4" W.C. (marked “Natural Gas
Regulator”)
10 ft (3.0 m) Natural gas hose with quick connector
5.9" (150 mm) Natural gas regulator hose
6 mm nut driver
6 mm wrench
Hex key
IMPORTANT: Gas conversions must be done by a qualified
installer. Before proceeding with conversion, shut off the gas supply
to the appliance.
Tools needed
Phillip screwdriver
Pipe Wrench
Adjustable wrench
6 mm socket and
wrench or 6 mm nut driver
Thin flat-blade
screwdriver
Pliers
Pipe thread sealant
certified for LP gas
WARNING
Explosion Hazard
Use a new CSA International approved “outdoor”
gas supply line.
Securely tighten all gas connections.
Failure to do so can result in death, explosion, or fire.
Install a shut-off valve.

1. A combination of pipe fittings must be used to connect the grill
to the existing gas line.
The 10 ft (3.0 m) PVC flexible gas supply hose design
certified by CSA must be used.
Pipe-joint compounds suitable for use with Natural gas
must be used. Do not use Teflon®+ tape.
There must be a certified manual shut-off valve in the gas
supply line near the grill for easy access.
2. Connect the brass connector on one end of the 10 ft (3.0 m)
PVC flexible gas supply hose to the Natural gas pressure
regulator.
3. Connect the quick connector on the other end of the
10 ft (3.0 m) PVC flexible gas supply hose to the rigid Natural
gas supply pipe.
6. Use an adjustable wrench to install the Natural gas
regulator hose to the manifold and secure. Attach the
Natural gas regulator to the side panel inside the grill cart
with the two screws that are pre-assembled on the
regulator.
Conversion from LP Gas to
Natural Gas
1. Turn off the main gas supply valve.
2. Disconnect 20 lb LP gas fuel tank (if present).
3. Turn off all burner control valves.
4. Remove the 20 lb LP gas fuel tank (if present) from the grill cart.
5. Use an adjustable wrench to remove the LP regulator from the
manifold.
Installation of the regulator
Make Gas Connection
† ®Teflon is a registered trademark of E.I. Du Pont De Nemours
and Company.
A. Manifold
B. Left side panel
C.10 ft. (3.0 m) PVC gas hose
D. Natural gas pressure regulator/hose assembly
A
C
D
B
17

Change Grill Main Burner Valve Orifices
3. Use a 6 mm socket and wrench or 6 mm nut driver to remove
the brass orifice from the end of gas valve. The main burner
orifice is located behind the LP orifice, so no additional orifice
needs to be installed.
A. Main burner orifice
IMPORTANT: Check that the orifice is properly installed inside of the
burner opening.
4. Reinsert the burner and reattach using the screw and cotter clip
previously removed. Repeat the procedure for each main burner.
5. Position the igniters so they are 1/4" (6.0 mm) away from each
burner.
1. Remove the grates and flame tamers.
2. Remove 1 screw and cotter clip that hold the burner in place. Set
the screw and clip aside. Remove the burner from the grill by lifting
the burner out.
Change the Sear Burner Orifices
1. Remove the 2 screws securing the igniter and remove
the igniter from the side burner.
2. Remove the searing side burner screws. Set the screws
and cover aside.
18
A
B
A. Screw
B. Cotter Clip
orifice orifice
A

Adjust High Flame Setting Screw
2. Use a flat-blade screwdriver to turn the high flame
setscrew counterclockwise approximate 90 degree.
3. Lift the searing side burner out of the grill.
4. Use 6 mm socket wrench or 6 mm nut driver to remove the
orifice. Replace with the Natural gas orifice.
IMPORTANT: Check that the orifice is properly installed inside of the
valve.
5. Reinstall the searing side burner Make sure that the igniter is out
of the way to allow proper positioning of burner. Use Phillips
screwdriver to attach the mounting screws.
6. Use Phillips screwdriver to reattach the igniter and searing side
burner plate.
7. Reinstall searing side burner cover. Use Phillips screwdriver to
attach mounting screws.
8. Open the manual shutoff valve in the gas supply line. The valve is
open when the handle is parallel to the gas pipe.
9. Test all connections using an approved noncorrosive
leak-detection solution. Bubbles will show a leak. Correct
any leak found.
When converting from LP to Natural gas, you will need to adjust
the high flame setting screw for ideal burner flame height.
1. Remove each control knob for the main burners and side burner
3. Check that burner operates at the new high flame setting.
It may be necessary to adjust the screw setting slightly more to
get the ideal burner flame height.
orifice orifice
19
A. Closed valve
B. Open valve
In the last page of the Use and Care Guide, writer “ Converted
to Natural Gas.” Also record the conversion date and the
technician/company that performed the conversion.
Note: Place LP gas parts in plastic parts bag for future use and
keep with pack containing literature.
1. The appliance nameplate is located inside the grill cabinet
on the left –hand cabinet side. With a permanent marker,
check the box next to “Natural gas” and mark through “LP-
Propane.”
Record Conversion

Check and Adjust the Burners
The burners are tested and factory-set for most efficient operation.
However, variations in gas supply and other conditions may make
minor adjustments to air shutter or low flame setting necessary.
It is recommended that a qualified person make burner adjustments.
Checking and adjusting the grill burner flames requires removing
the grates and flame tamers.
A. Clip
6. If flame is yellow (not enough air), turn air shutter adjustment
screw counterclockwise.
If flame is noisy or lifts away from burner (too much air), turn air
shutter adjustment screw clockwise.
Adjustment should be made clockwise or counter clockwise from
1/8” (3.2 mm) to ¼” (6.4 mm).
7. Replace gas burner, sear plates and grates.
8. Light grill using information in the “Outdoor Grill Use” section.
See “Burner Flame Characteristics
A. Air shutter adjustment screw
A
If flame goes out on the “LOW” setting, the low flame setting
must be adjusted.
1. Turn off the valve and wait until grill and burners are cold.
2. Remove grill grates and flame tamers.
3. Light grill using information in the “Outdoor Grill Use” section.
4. Turn burner to its lowest setting.
5. Remove each control knob for the main burners and side
burner by loosening the setscrew with the hex key.
6. Hold valve stem with pliers and insert a small flat-blade
screwdriver into the shaft.
7. Watch the flame and slowly turn the screwdriver
counterclockwise.
8. Adjust flame to minimum stable flame.
A. Valve stem
B. Small flat-blade screwdriver
C. Pliers
A
B
C
The flames of the grill burners and side burners (on some models)
should be blue and stable with no excessive noise or lifting (LP gas
flames will have a slightly yellow tip). A yellow flame indicates not
enough air. If flame is noisy or lifts away from the burner, there is
too much air. Some yellow tips on flames when the burner is set to
HIGH setting are acceptable as long as no carbon or soot deposits
appear. The flames should be approximately 1" (2.5 cm) high.
Burner Flame Characteristics
Low Flame Adjustment
9. Replace the control knob and turn off the burner.
10. Repeat steps 3 through 9 for each burner if needed.
11. Replace the flame tamers and grates after the burners have
cooled.
Check that burners are not blocked by dirt, debris, insect nests,
etc., and clean as necessary. If they are clean, adjust air shutters
as needed.
IMPORTANT: Before adjusting air shutters, let burners cold
down completely. To Adjust:
1. Light grill using information in the “Outdoor Grill Use” section.
2. Observe flame to determine which burners need adjustment
and how the flame is acting.
3. Turn off the valve and wait until grill and burners cold
completely.
4. Remove grill grates and flame tamers.
5. Remove the 1 screw and cotter pin that hold the burner in
place. Remove gas burner from the grill.
A
20
