KitchenAid W10117506B Manual

OUTDOOR BUILT-IN SEAR BURNER
Installation Instructions and Use & Care Guide
For questions about features, operation/performance, parts, accessories or service, call: 1-800-422-1230
or visit our website at www.kitchenaid.com
In Canada, call for assistance, installation and service, call: 1-800-807-6777
or visit our website at www.KitchenAid.ca
BRÛLEUR À INFRAROUGE ENCASTRÉ
POUR USAGE EXTÉRIEUR
Instructions d’installation et Guide d’utilisation et d’entretien
Au Canada, pour assistance, installation ou service composez le 1-800-807-6777 ou visitez notre site web à...
www.KitchenAid.ca
Table of Contents/Table des matières.............................................................................4
IMPORTANT:
Save for local electrical inspector's use.
Installer: Leave installation instructions with the homeowner.
Homeowner: Keep installation instructions for future reference.
IMPORTANT :
À conserver pour consultation par l'inspecteur local des installations électriques.
Installateur : Remettre les instructions d'installation au propriétaire.
Propriétaire : Conserver les instructions d'installation pour référence ultérieure.
Models/Modèles KBEU121TSS KBEU121VSS
W10200235A

2
OUTDOOR BUILT-IN SEAR BURNER SAFETY
You can be killed or seriously injured if you don't immediately
You can be killed or seriously injured if you don't follow
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”
These words mean:
follow instructions.
instructions.
DANGER
WARNING
WARNING
1. Do not store or use gasoline or other
flammable liquids or vapors in the
vicinity of this or any other appliance.
2. An LP cylinder not connected for use
shall not be stored in the vicinity of
this or any other appliance.
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odor continues, keep away from the
appliance and immediately call your
gas supplier or your fire department.
DANGER
State of California Proposition 65 Warnings:
WARNING: This product contains a chemical known to the State of California to cause cancer.
WARNING: This product contains a chemical known to the State of California to cause birth defects or other reproductive harm.
In the State of Massachusetts, the following installation instructions apply:
■ Installations and repairs must be performed by a qualified or licensed contractor, plumber, or gasfitter qualified or licensed by
the State of Massachusetts.
■ If using a ball valve, it shall be a T-handle type.
■ A flexible gas connector, when used, must not exceed 3 feet.

3
IMPORTANT: This sear burner is manufactured for outdoor use only. For sear burners that are to be used at elevations above
2000 ft (609.6 m) orifice conversion is required. See “Gas Supply Requirements” section. It is the responsibility of the installer to comply
with the minimum installation clearances specified on the model/serial rating plate. The model/serial rating plate can be found on the
right-hand side panel.
Copies of the standards listed may be obtained from:
National Fire Protection Association
One Batterymarch Park
Quincy, Massachusetts 02269
CSA International
8501 East Pleasant Valley Rd.
Cleveland, Ohio 44131-5575
SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
WARNING: To reduce the risk of fire, electrical shock,
injury to persons, or damage when using the outdoor cooking
gas appliance, follow basic precautions, including the
following:
■ Do not install portable or built-in outdoor cooking gas
appliances in or on a recreational vehicle, portable trailer,
boat or in any other moving installation.
■ Always maintain minimum clearances from combustible
construction, see “Location Requirements” section.
■ The outdoor cooking gas appliance shall not be located
under overhead unprotected combustible construction.
■ This outdoor cooking gas appliance shall be used only
outdoors and shall not be used in a building, garage, or any
other enclosed area.
■ Keep any electrical supply cord and fuel supply hose away
from any heated surfaces.
■ Keep outdoor cooking gas appliance area clear and free
from combustible materials, gasoline and other flammable
vapors and liquids.
■ Do not obstruct the flow of combustion and ventilation air.
Keep the ventilation openings of the cylinder enclosure free
and clear from debris.
■ Inspect the gas cylinder supply hose before each use of the
outdoor cooking gas appliance. If the hose shows
excessive abrasion or wear, or is cut, it MUST be replaced
before using the outdoor cooking gas appliance. Contact
your dealer and use only replacement hoses specified for
use with the outdoor cooking gas appliance.
■ Visually check the burner flames. They should be blue.
Slight yellow tipping is normal for LP gas.
■ Check and clean burner/venturi tube for insects and insect
nest. A clogged tube can lead to fire under the outdoor
cooking gas appliance.
■ The LP gas supply cylinder to be used must be:
- constructed and marked in accordance with the
Specification for LP Gas Cylinders of the U.S. Department
of Transportation (DOT) or the National Standard of
Canada, CAN/CSA-B339, Cylinders, Spheres, and Tubes
for Transportation of Dangerous Goods; and Commission.
- provided with a listed overfilling prevention device.
- provided with a cylinder connection device compatible
with the connection for outdoor cooking gas appliances.
■ Always check connections for leaks each time you connect
and disconnect the LP gas supply cylinder. See
“Installation Instructions” section.
■ When the outdoor cooking gas appliance is not in use, the
gas must be turned off at the supply cylinder.
■ Storage of an outdoor cooking gas appliance indoors is
permissible only if the cylinder is disconnected and
removed from the outdoor cooking gas appliance.
■ Cylinders must be stored outdoors and out of the reach of
children and must not be stored in a building, garage, or
any other enclosed area.
■ The pressure regulator and hose assembly supplied with
the outdoor cooking gas appliance must be used. A
replacement pressure regulator and hose assembly
specific to your model is available from your outdoor
cooking gas appliance dealer.
■ Gas cylinder must include a collar to protect the cylinder
valve.
■ For appliances designed to use a CGA791 Connection:
Place a dust cap on cylinder valve outlet whenever the
cylinder is not in use. Only install the type of dust cap on
the cylinder valve outlet that is provided with the cylinder
valve. Other types of caps or plugs may result in leakage
of propane.
If the following information is not followed exactly, a fire
causing death or serious injury may occur.
■ Do not store a spare LP gas cylinder under or near this
outdoor cooking gas appliance.
■ Never fill the cylinder beyond 80 percent full.

4
TABLE OF CONTENTS
OUTDOOR BUILT-IN SEAR BURNER SAFETY...........................2
INSTALLATION REQUIREMENTS................................................5
Tools and Parts ............................................................................5
Location Requirements................................................................6
Product Dimensions.....................................................................6
Cabinet Dimensions.....................................................................6
Electrical Requirements ...............................................................9
Gas Supply Requirements.........................................................10
Gas Connection Requirements - For Models Equipped
for LP Gas ..................................................................................10
Gas Connection Requirements - For Models Equipped
for Natural Gas ...........................................................................12
INSTALLATION INSTRUCTIONS................................................13
Built-in Outdoor Sear Burner Installation...................................13
Install Tank Tray for 20 lb LP Gas Fuel Tank - For Models
Equipped for Use with a 20 lb LP Tank.....................................13
GAS CONVERSIONS....................................................................17
For Models Equipped for Use with a 20 lb LP gas Tank...........17
Tools and Parts for Gas Conversion..........................................17
Conversion to a Local LP Gas Supply.......................................17
Conversion from LP Gas to Natural Gas ...................................18
Check and Adjust the Burners...................................................20
USING YOUR OUTDOOR SEAR BURNER.................................20
Lighting the Infrared Sear Burner...............................................21
Using Your Infrared Sear Burner................................................21
OUTDOOR SEAR BURNER CARE..............................................22
General Cleaning........................................................................22
TROUBLESHOOTING ..................................................................23
ASSISTANCE OR SERVICE.........................................................23
In the U.S.A. ...............................................................................23
Accessories................................................................................23
In Canada ...................................................................................24
WARRANTY ..................................................................................24
TABLE DES MATIÈRES
SÉCURITÉ DU BRÛLEUR À INFRAROUGE
ENCASTRÉ D'EXTÉRIEUR..........................................................27
EXIGENCES D'INSTALLATION...................................................29
Outillage et pièces......................................................................29
Exigences d'emplacement.........................................................30
Dimensions du produit...............................................................30
Dimensions du placard ..............................................................30
Spécifications électriques ..........................................................33
Spécifications de l'alimentation en gaz .....................................34
Exigences concernant le raccordement au gaz - Pour les
modèles équipés pour le propane .............................................35
Exigences concernant le raccordement au gaz - Pour les
modèles équipés pour le gaz naturel ........................................36
INSTRUCTIONS D’INSTALLATION.............................................37
Installation du brûleur à infrarouge d'extérieur encastré...........37
Installation du chariot de bouteille de gaz
propane de 20 lb - Pour les modèles équipés pour
l'utilisation d'une bouteille de gaz propane de 20 lb .................37
CONVERSIONS DE GAZ..............................................................41
Pour les modèles équipés pour l'utilisation d'une
bouteille de gaz propane de 20 lb .............................................41
Outillage et pièces pour conversion de gaz ..............................41
Conversion au gaz propane local ..............................................42
Conversion de gaz propane à gaz naturel.................................43
Contrôle et réglage des brûleurs................................................44
UTILISATION DU BRÛLEUR À INFRAROUGE
D'EXTÉRIEUR...............................................................................45
Allumage du brûleur à infrarouge...............................................45
Utilisation du brûleur à infrarouge..............................................46
ENTRETIEN DU BRÛLEUR À INFRAROUGE
D'EXTÉRIEUR...............................................................................47
Nettoyage général ......................................................................47
DÉPANNAGE.................................................................................48
ASSISTANCE OU SERVICE.........................................................49
Accessoires ................................................................................49
GARANTIE.....................................................................................50

5
INSTALLATION REQUIREMENTS
Tools and Parts
Gather the required tools and parts before starting installation. Read and follow the instructions provided with any tools listed here.
20 lb LP Gas Models
Tools Needed
Parts Supplied
■Gas pressure regulator/hose assembly set for 11" WCP LP
gas (attached to manifold)
■1 single-prong plug/5,000 mAmp transformer assembly
■Convertible regulator set for 4" WCP Natural gas
■Orifices for Natural gas conversion
■LP gas fuel tank tray
Parts Needed
■20 lb LP gas fuel tank - approximately 18" (45.7 cm) height
and 12" (30.5 cm) diameter
Natural Gas Models
Tools Needed
Parts Needed
■Gas line shutoff valve
■½" male pipe thread nipple for connection to pressure
regulator
■LP gas-resistant pipe-joint compound
■CSA design-certified outdoor flexible stainless steel
appliance connector (4-5 ft [1.2-1.5 m]) or rigid gas supply
line as needed.
Parts Supplied
■Convertible regulator set for 4" WCP Natural gas.
■Single-prong plug/5,000 mAmp transformer assembly
■Tape measure
■Small, flat-blade screwdriver
■Flat-blade screwdriver
■#2 and #3 Phillips screwdriver
■Level
■Wrench or pliers
■Pipe wrench
■Scissors or cutting pliers
(to remove tiedowns)
■Noncorrosive leak-
detection solution
■Tape measure
■Small, flat-blade screwdriver
■Flat-blade screwdriver
■#2 and #3 Phillips screwdriver
■Level
■Wrench or pliers
■Pipe wrench
■Scissors or cutting pliers
(to remove tiedowns)
■Noncorrosive leak-
detection solution

6
Location Requirements
Select a location that provides minimum exposure to wind and
traffic paths. The location should be away from strong draft
areas.
Do not obstruct flow of combustion and ventilation air.
Clearance to combustible construction for built-in outdoor sear
burners:
■A minimum of 24" (58 cm) must be maintained between the
sides and back and any combustible construction.
■A zero clearance may be maintained below the cooking
surface and any combustible construction.
Ignition
A grounded, 3-prong outdoor GFI outlet is to be located inside
the island cabinet and to the left of the sear burner is required.
See “Electrical Requirements” section.
Product Dimensions
Built-In Outdoor Sear Burner Enclosure
This built-in outdoor sear burner is for installation in a built-in
enclosure constructed of combustible and non-combustible
materials. Some types of non-combustible materials could be
brick, firewall or steel. Some types of combustible materials
could be wood or laminate.
The enclosure for the built-in outdoor sear burner is to be a
minimum of 11" (28.0 cm) high x 23" (58.4 cm) deep x
14" (35.6 cm) wide.
Cabinet Dimensions
Counter or support surfaces must be level.
The installation of this sear burner must conform with local codes
or, in the absence of local codes, with either the National Fuel
Gas Code, ANSI Z223.1/NPFA 54, Natural Gas and Propane
Installation Code, CSA B149.1, or Propane Storage and Handling
Code, B149.2.
Copies of the standards listed may be obtained from:
CSA International
8501 East Pleasant Valley Rd.
Cleveland, Ohio 44131-5575
NOTE: The outdoor sear burner drops into the enclosure opening
and is supported by its side flanges. No bottom support is
needed.
A. 13" (33.0 cm)
B. 10⁵⁄₈" (27.0 cm)
C. 17" (43.2 cm)
D. 26³⁄₈" (67.0 cm)
E. 25³⁄₈" (64.5 cm)
F. Manif old pi p e
G. 2¹⁄₂" (6.4 cm)
H. 22³⁄₄" (57.8 cm)
B
A
D
E
F
G
H
B
C

7
The dimension chart and illustration below include cutout dimensions and minimum spacing requirements for all built-in outdoor
products. The illustration is for reference. The design of your cabinet layout can be personalized, but the dimensions for the cutouts and
minimum spacing must be followed.
C
E
D
HA
G
K
KF
K
B
J
D
E
20⁵⁄₈" (52.4 cm)
1¹⁄₂"
(3.8 cm) min.
3" (7.6 cm) min.
to open hood
2¹⁄₂" (6.4 cm) min.
12" (30.5 cm) min.
to any accessory
12" min.
to any
accessory
20⁷⁄₈" (53.0 cm)
9¹⁄₈"
(23.2 cm)
5"
(12.7 cm) min.
C
M
L
K
K
Grills or
Refreshment Centers
Side
or
Sear
Burners
Warming
Drawer Access Doors
Refrigerator
or
Ice Maker
Utility
or
Trash
Drawer
Minimum Spacing Requirement Between Cutouts - Dimension K
Between 2 or more sets of Access Doors adjacent to each other:
K = 14" (35.6 cm) when 2 adjacent doors are opened to 90 degrees
K = 8" (20.3 cm) when 1 of the adjacent doors is opened to 90 degrees
Between a set of Access Doors and a Trash Drawer, Utility Drawer, Warming Drawer, Refrigerator, or Ice Maker:
K = 8" (20.3 cm) when 1 of the adjacent doors is opened to 90 degrees
Between a Trash Drawer, Utility Drawer, or Warming Drawer:
K = 3" (7.6 cm)
Cabinet Height and Depth Dimensions
Dimension A Minimum Dimension B Minimum
With outdoor refrigerator 37" (94.0 cm) 26" (66.0 cm)
Grill with insulated jacket 36½" (92.7 cm) 27" (68.6 cm)
Grill without insulated jacket 35½" (90.2 cm) 26" (66.0 cm)

8
*Dimension L is the minimum mounting surface area around the opening for mounting the optional door or drawers.
Cutout Dimensions - Built-in Grill
Grill Size Dimension C Dimension D Dimension E
27" (68.6 cm) 29⁵⁄₈" (75.2 cm) 10¾" (27.3 cm) 22⁷⁄₈" (58.1 cm)
36" (91.4 cm) 38⁵⁄₈" (98.1 cm) 10¾" (27.3 cm) 22⁷⁄₈" (58.1 cm)
48" (121.9 cm) 50⁵⁄₈" (128.6 cm) 10¾" (27.3 cm) 22⁷⁄₈" (58.1 cm)
Cutout Dimensions - Built-in Grill with Insulated Jacket
Grill Size Dimension C Dimension D Dimension E
27" (68.6 cm) 33" (83.8 cm) 11¾" (29.8 cm) 24" (61.0 cm)
36" (91.4 cm) 42" (106.7 cm) 11¾" (29.8 cm) 24" (61.0 cm)
48" (121.9 cm) 54" (137.2 cm) 11¾" (29.8 cm) 24" (61.0 cm)
Cutout Dimensions - Built-in Side Burner
Burner Position Dimension C Dimension D Dimension E
Front to Back 13½" (34.3 cm) 10¾" (27.3 cm) 22⁵⁄₈" (57.5 cm)
Side by Side 24½" (62.2 cm) 10¾" (27.3 cm) 16⁷⁄₈" (42.9 cm)
Cutout Dimensions - Built-in Sear Burner
Dimension C Dimension D Dimension E
13½" (34.3 cm) 10⁵⁄₈" (27.0 cm) 22¹¹⁄₁₆" (57.6 cm)
Cutout Dimensions - Built-in Refreshment Center
Dimension C Dimension D Dimension E
30½" (77.5 cm) 10¾" (27.3 cm) 23" (58.4 cm)
Cutout Dimensions - Built-in Access Doors
Door Size Dimension F Dimension L*
18" (45.7 cm) 16³⁄₁₆" (41.1 cm) 1½" (3.8 cm)
27" (68.6 cm) 25¹⁄₈" (63.8 cm) 1½" (3.8 cm)
30" (76.2 cm) 28¹⁄₈" (71.4 cm) 1½" (3.8 cm)
36" (91.4 cm) 34¹⁄₈" (86.7 cm) 1½" (3.8 cm)
48" (121.9 cm) 46¹⁄₈" (117.2 cm) 1½" (3.8 cm)
Cutout Dimensions - Outdoor Refrigerator
Dimension G Dimension H
24" (61.0 cm) 35¼" (89.5 cm)
Cutout Dimensions - Outdoor Ice Maker
Dimension G Dimension H
18" (45.7 cm) 34" (86.4 cm) min. to 34½" (87.6 cm) max.

9
*Dimension L is the minimum mounting surface area around the opening for mounting the optional door or drawers.
Built-in Outdoor Grill Enclosure Ventilation for LP Gas:
An enclosure for an LP gas fuel tank is to be ventilated by
openings at both the top and lower levels of the enclosure.
If converting to LP gas these vents are to be in the enclosure:
An enclosure for use with an LP gas fuel tank for built-in
installation is to have at least one ventilation opening on an
exposed exterior side located within 5" (12.7 cm) of the top is to
be a minimum of 20 in.2(129.0 cm2). One ventilation opening
within 1" (2.5 cm) of the bottom of the enclosure and the bottom
opening is to be a minimum of 10 in.2(64.5 cm2). All vent
openings are to be unobstructed. Every opening is to be a
minimum of ¹⁄₈" (0.32 cm) wide.
Electrical Requirements
If codes permit and a separate ground wire is used, it is
recommended that a qualified electrician determine that the
ground path is adequate.
Check with a qualified electrician if you are not sure whether the
infrared sear burner is properly grounded.
A 120-volt, 60-Hz, AC-only, 15-amp, fused electrical supply is
required.
It is recommended that a separate circuit servicing only this sear
burner be provided.
■To avoid electrical shock, do not immerse cord or plugs in
water or other liquid.
■Unplug from the outlet when not in use and before
cleaning. Allow to cool before putting on or taking off
parts.
■Do not operate any outdoor cooking gas appliance with a
damaged cord, damaged plug, or after the appliance
malfunctions or has been damaged in any manner.
Contact the manufacturer for repair.
■Do not let the cord hang over the edge of a table or touch
hot surfaces.
■Do not use an outdoor cooking appliance for purposes
other than intended.
■When connecting, first connect plug to the outdoor
cooking gas appliance then plug appliance into the outlet.
■Use only a Ground Fault Interrupter (GFI) protected circuit
with this outdoor cooking gas appliance.
■Do not remove the ground prong or use with an adapter
of 2 prongs.
The model/serial number rating plate is located on the right-hand
side panel. See the following illustration.
Cutout Dimensions - Built-in Warming Drawer
Warming Drawer Size Dimension J
24" (61.0 cm) 22½" (57.2 cm)
Cutout Dimensions - Built-in Utility Drawer and Built-in Trash Drawer
Dimension M Dimension L*
12¼" (31.1 cm) 1½" (3.8 cm)
10 in.
2
(64.5 cm
2
) min.
ventilation both sides
5" (12.7 cm) max.
1" (2.5 cm) max.
20 in.
2
(129.0 cm
2
) min.
ventilation both sides
5" (12.7 cm) max.
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING
A. Model/serial number plate
A

10
Recommended Ground Method
The outdoor infrared sear burner, when installed, must be
electrically grounded in accordance with local codes or, in the
absence of local codes, with the National Electrical Code ANSI/
NFPA 70, or Canadian Electrical Code, CSA C22.1.
Copies of the standards listed above may be obtained from:
CSA International
8501 East Pleasant Valley Rd.
Cleveland, Ohio 44131-5575
National Fire Protection Association
One Batterymarch Park
Quincy, Massachusetts 02269
Gas Supply Requirements
Observe all governing codes and ordinances.
IMPORTANT: This installation must conform with all local codes
and ordinances. In the absence of local codes, installation must
conform with American National Standard, National Fuel Gas
Code ANSI Z223.1 - latest edition or CAN/CGA B149.1 - latest
edition.
IMPORTANT: The infrared sear burner must be connected to a
regulated gas supply.
Refer to the model/serial rating plate for information on the type
of gas that can be used. If this information does not agree with
the type of gas available, check with your local gas supplier.
Gas Conversion:
No attempt shall be made to convert the infrared sear burner
from the gas specified on the model/serial rating plate for use
with a different gas type without consulting the serving gas
supplier. The conversion kit supplied with the sear burner must
be used. See “Gas Conversions” section for instructions.
Gas Pressure Regulator
The gas pressure regulator supplied with this infrared sear burner
must be used. The inlet (supply) pressure to the regulator should
be as follows for proper operation:
LP Gas:
Set pressure: 11" (27.9 cm) WCP
Inlet (supply) pressure: 11" to 14" (27.9 cm to 35.5 cm) WCP
Natural Gas:
Set pressure: 4" (10.2 cm) WCP
Inlet (supply) pressure: 7" to 14" (17.8 cm to 35.5 cm)
WCP maximum.
Contact local gas supplier if you are not sure about the inlet
(supply) pressure.
Burner Requirements for High Altitude
Input ratings shown on the model/serial rating plate are for
elevations up to 2,000 ft (609.6 m).
For elevations above 2,000 ft (609.6 m), ratings are reduced at a
rate of 4% for each 1,000 ft (304.8 m) above sea level. Orifice
conversion is required. See “Assistance or Service” section to
order.
Gas Supply Line Pressure Testing
Testing above ½ psi (3.5 kPa) or 14" (35.5 cm) WCP (gauge):
The sear burner and its individual shutoff valve must be
disconnected from the gas supply piping system during any
pressure testing of that system at test pressures greater than
½ psi (3.5 kPa).
Testing below ½ psi (3.5 kPa) or 14" (35.5 cm) WCP (gauge) or
lower:
The sear burner must be isolated from the gas supply piping
system by closing its individual manual shutoff valve during any
pressure testing of the gas supply piping system at test
pressures equal to or less than ½ psi (3.5 kPa).
Gas Connection Requirements
For Models Equipped for LP Gas
20 lb LP Gas Fuel Tank
This sear burner is equipped for use with a 20 lb LP gas fuel tank
(fuel tank not supplied). A gas pressure regulator/hose assembly
is supplied.
It is also design-certified by CSA International for local LP gas
supply or for Natural gas with appropriate conversion.
A. 3 prong ground plug
B. 3-prong polarized type outdoor GFI outlet
C. Ground prong
A
B
C
WARNING
Explosion Hazard
Use a new CSA International approved “outdoor”
gas supply line.
Securely tighten all gas connections.
If connected to LP, have a qualified person make sure
gas pressure does not exceed 11” (28 cm) water
column.
Examples of a qualified person include:
licensed heating personnel,
authorized gas company personnel, and
authorized service personnel.
Failure to do so can result in death, explosion, or fire.
A. Gas pressure regulator/hose assembly
A

11
The 20 lb LP gas fuel tank must be mounted and secured.
Door Style Tank Tray
1. Open cabinet doors.
2. Pull out the tank tray.
3. Place the 20 lb LP gas fuel tank bottom collar into the
mounting hole in the tank tray.
4. Tighten the locking screw against the bottom collar of the
20 lb LP gas fuel tank to secure.
5. Slide tank tray back into the cabinet.
6. Close cabinet doors.
Local LP Gas Supply Conversion
Conversion must be made by a qualified gas technician. The
qualified gas technician shall provide the gas supply to the
selected sear burner location in accordance with the National
Fuel Gas Code ANSI Z223.1/NFPA 54 - latest edition, and local
codes. For conversion to local LP, the convertible regulator in the
conversion kit supplied with the sear burner must be used.
IMPORTANT: The gas installation must conform with local
codes, or in the absence of local codes, with the National Fuel
Gas Code, ANSI Z223.1/NFPA 54 - latest edition. The qualified
LP gas technician shall provide the LP gas supply to the selected
sear burner location in accordance with the National Fuel Gas
Code, ANSI Z223.1/NFPA 54 and local codes.
Follow instructions for converting to local LP gas in the “Gas
Conversions” section.
The gas supply line shall be equipped with an approved shutoff
valve. This valve should be located in the same area as the sear
burner and should be in a location that allows ease of opening
and closing. Do not block access to the shutoff valve. The valve
is for turning on or shutting off gas to the sear burner.
Natural Gas Conversion
Conversion must be made by a qualified gas technician. The
qualified Natural gas technician shall provide the Natural gas
supply to the selected sear burner location in accordance with
the National Fuel Gas Code ANSI Z223.1/NFPA 54 - latest
edition, and local codes. For conversion to Natural gas, the
Natural gas conversion kit supplied with the sear burner must be
used.
IMPORTANT: The gas installation must conform with local
codes, or in the absence of local codes, with the National Fuel
Gas Code, ANSI Z223.1/NFPA 54 - latest edition.
To convert to Natural gas, the Natural Gas Conversion Kit
supplied with the sear burner must be used. Follow instructions
for converting to Natural gas in the “Gas Conversions” section.
The gas supply line shall be equipped with an approved shutoff
valve. This valve should be located in the same area as the sear
burner and should be in a location that allows ease of opening
and closing. Do not block access to the shutoff valve. The valve
is for turning on or shutting off gas to the sear burner.
Tank tray
A. Locking screw
B. Mounting hole
C. Bottom collar
A. New CSA International approved
“outdoor” flexible gas supply line
B. Rear of sear burner
C. To local LP gas supply
A
B C
B
C
A
A. Gas supply line
B. Shutoff valve “open” position
C. To sear burner
A. New CSA International approved
“outdoor” flexible gas supply line
B. Rear of sear burner
C. To Natural gas supply
A. Gas supply line
B. Shutoff valve “open” position
C. To sear burner
A
B
C
B
C
A
A
B
C

12
Gas Connection Requirements
For Models Equipped for Natural Gas
Natural Gas
Built-in sear burner models are equipped for use with Natural
gas. They are design-certified by CSA International for LP
(propane or butane) gases with appropriate conversion.
Built-in models are set for Natural gas use and have a pressure
regulator with ½" female pipe threads.
The supply line shall be equipped with an approved shutoff valve.
This valve should be located in the same area as the sear burner
and should be in a location that allows ease of opening and
closing. Do not block access to the shutoff valve. The valve is for
turning on or shutting off gas to the sear burner.
LP Gas Conversion Using a Local LP Gas Supply
Conversion must be made by a qualified person. A qualified
Natural gas technician shall provide the LP gas supply to the
selected sear burner location in accordance with the National
Fuel Gas Code ANSI Z223.1/NFPA 54 - latest edition, and local
codes.
To convert to LP gas, the LP Gas Conversion Kit Part Number
W10118099 must be used. Follow instructions included with kit.
LP Gas Conversion Using a 20 lb LP Gas Fuel Tank
To convert to LP gas, the LP Gas Conversion Kit Part Number
W10118099 must be used. Follow instructions included with kit.
A 20 lb LP gas fuel tank must be purchased separately.
A. Sear burner gas pipe
B. New CSA International approved
“outdoor” flexible gas supply line
C. Rear of sear burner
D. To Natural gas supply
A. Gas supply line
B. Shutoff valve “open” position
C. To sear burner
A
B
C
D
A
B
C
A. Sear burner gas pipe
B. New CSA International approved
“outdoor” flexible gas supply line
C. Rear of sear burner
D. To local LP gas supply
A
B
C
D

13
INSTALLATION INSTRUCTIONS
Built-in Outdoor Sear Burner Installation
■Unpack sear burner. Remove all packaging materials and
remove sear burner from carton.
■Place sear burner into outdoor enclosure, but leave enough
room in back to connect to gas supply and electrical single
prong plug-in.
Install Tank Tray for 20 lb LP Gas Fuel Tank
For Models Equipped for Use with a 20 lb LP Tank
1. Position the tank tray for 20 lb LP gas fuel tank in the island
cabinet.
2. Square the tank tray mounting brackets and mark the
mounting hole locations in the island base.
3. Remove the top nuts (4) from the tank tray assembly and lift
the tank tray off of the mounting brackets.
4. Install the tank tray mounting brackets to the base or floor of
the island using the proper size and type of mounting
hardware (not supplied). Tighten mounting hardware.
5. Pre-adjust each of the bottom nuts on the mounting brackets
to 3" (7.6 cm) from the base of the island to the top of the
nuts.
6. Remount the tank tray back onto the mounting brackets.
Replace the 4 top nuts but do not tighten.
Dimension A Dimension B
Sear Burner 8³⁄₃₂" (20.6 cm) 16³⁄₁₆" (41.1 cm)
WARNING
Excessive Weight Hazard
Use two or more people to move and install
built-in sear burner.
Failure to do so can result in back or other injury.
B
2¹⁄₄"
(5.7 cm)
18³⁄₈"
(46.7 cm)
20⁵⁄₈"
(52.4 cm)
A
centerline of
tank tray
A. Top nut
B. Tank tray
C. Bottom nut
D. Bolt
E. Mounting bracket
A. Screw (Use proper screw for island floor material.)
B. Lock washer
C. Flat washer
A. 20 lb LP gas fuel tank
B. Tank tray for 20 lb gas fuel tank
C. Top nut (do not tighten)
D. Mounting bracket
A
B
C
D
E
A
B
C
3"
(7.6 cm)
A
D
C
B

14
7. The tank tray for the 20 lb LP gas fuel tank must be adjusted
so that the bottom of the tank tray is ¹⁄₈" (0.32 cm) above the
cabinet door opening and is level. The top nut on each of the
mounting brackets is to be loose. Turn the bottom nuts
counterclockwise to raise the tank tray and turn the bottom
nuts clockwise to lower the tank tray. When the tank tray is
level and slides in and out without touching the cabinet door
opening at the bottom or top with the 20 lb LP gas fuel tank
installed, tighten the top nuts against the adjustment flange.
NOTE: A bracket or shelf (not supplied) that is large enough
to keep a second 20 lb LP gas fuel tank from being stored in
the storage area under the sear burner is required to be
mounted inside the island.
Make Gas Connection
Gas Connection to a 20 lb LP Gas Fuel Tank
If converting to local LP or Natural gas, follow the instructions in
the “Gas Conversions” section.
IMPORTANT: A 20 lb LP gas fuel tank must be purchased
separately.
IMPORTANT: The gas pressure regulator/hose assembly
supplied with the sear burner must be used. Replacement gas
pressure regulator/hose assembly specific to your model, is
available from your outdoor sear burner dealer.
To Install the 20 lb LP Gas Fuel Tank:
1. Open cabinet doors.
2. Pull out the tank tray.
3. Place the 20 lb LP gas fuel tank bottom collar into the
mounting hole in the tank tray.
4. Tighten the locking screw against the bottom collar of the
20 lb LP gas fuel tank to secure.
5. Screw the gas pressure regulator/hose assembly to the 20 lb
LP gas fuel tank as shown. (To disconnect, turn off the gas
supply to the 20 lb LP gas fuel tank, then unscrew the gas
pressure regulator/hose assembly from the 20 lb LP gas fuel
tank as shown.)
6. Turn on the gas supply. Wait a few minutes for gas to move
through the gas line.
7. Test all connections by brushing on an approved
noncorrosive leak-detection solution. Bubbles will show a
leak. Correct any leak found.
8. Slide tank tray back into the cabinet.
9. Go to “Plug in Sear Burner” in this section.
A. Top nut loosened
B. Top nut tightened
AB
WARNING
Explosion Hazard
Use a new CSA International approved “outdoor”
gas supply line.
Securely tighten all gas connections.
If connected to LP, have a qualified person make sure
gas pressure does not exceed 11” (28 cm) water
column.
Examples of a qualified person include:
licensed heating personnel,
authorized gas company personnel, and
authorized service personnel.
Failure to do so can result in death, explosion, or fire.
Tank tray
A. Locking screw
B. Mounting hole
C. Bottom collar
A. 20 lb LP gas fuel tank
B. Gas pressure regulator/hose assembly
A
B C
A
B
connect
disconnect

15
Gas Connection to Natural Gas or Local LP Gas
This installation must conform with local codes and ordinances.
In the absence of local codes, installations must conform with
either the National Fuel Gas Code ANSI Z223.1 - latest edition, or
CAN/CGA-B149.1 Natural Gas and Propane installation code.
Copies of the standards listed above may be obtained from:
CSA International
8501 East Pleasant Valley Rd.
Cleveland, Ohio 44131-5575
National Fire Protection Association
One Batterymarch Park
Quincy, Massachusetts 02269
1. Make gas connections.
A combination of pipe fittings must be used to connect the
sear burner to the existing gas line.
■If local codes permit, use an outdoor flexible stainless
steel tubing gas connector, design-certified by CSA
International, to connect the sear burner to the rigid gas
supply line. A ⁵⁄₈" diameter line is recommended. Using a
wrench to tighten, connect the gas supply to the sear
burner. Use pipe-joint compound on all non-flared male
threads. Do not kink or damage the flexible connector
when moving the sear burner.
■Pipe-joint compounds suitable for use with LP gas must
be used. Do not use TEFLON®† tape.
2. Open the manual shutoff valve in the gas supply line. The
valve is open when the handle is parallel to the gas pipe.
3. Test all connections by brushing on an approved
noncorrosive leak-detection solution. Bubbles will show a
leak. Correct any leak found.
Plug in Sear Burner
NOTE: This built-in outdoor sear burner comes with a large
5000 mAmp power transformer/plug assembly for the sear
burner igniters. Follow the instructions for plugging in and
mounting the power transformer. Keep any electrical supply cord
away from any heated surfaces.
1. Plug the single-prong plug into the receptacle on the left
underside of the sear burner.
2. Locate or build a non-combustible surface inside the island
cabinet to mount the power transformer. It must be to the left
side of the sear burner at a minimum of 3" (7.6 cm) from the
side and 4" (10.2 cm) below the bottom of the sear burner.
3. Mount the power transformer to the mounting surface using
4 #8 screws (not supplied) that are the proper type and length
for the transformer and the mounting surface. It must be
mounted with the wire for the single-prong plug upward or
toward the sear burner.
NOTE: The cord must be properly mounted with a cord
retention device so that its 3-prong plug will not touch the
ground when it is unplugged.
A. New CSA International approved
“outdoor” flexible gas supply line
B. Rear of sear burner
C. To Natural gas or Local LP gas supply
WARNING
Explosion Hazard
Use a new CSA International approved “outdoor”
gas supply line.
Securely tighten all gas connections.
If connected to LP, have a qualified person make sure
gas pressure does not exceed 11” (28 cm) water
column.
Examples of a qualified person include:
licensed heating personnel,
authorized gas company personnel, and
authorized service personnel.
Failure to do so can result in death, explosion, or fire.
†®TEFLON is a registered trademark of E.I. Du Pont De Nemours and Company.
B
C
A
A. Closed valve
B. Open valve
A. Single-prong plug
A
B
A

16
4. Gently slide the sear burner completely into the outdoor
enclosure.
5. Plug 3-prong power cord plug into a grounded 3-prong GFI
outlet.
■To avoid electrical shock, do not immerse cord or plugs in
water or other liquid.
■Unplug from the outlet when not in use and before
cleaning. Allow to cool before putting on or taking off
parts.
■Do not operate any outdoor cooking gas appliance with a
damaged cord, damaged plug, or after the appliance
malfunctions or has been damaged in any manner.
Contact the manufacturer for repair.
■Do not let the cord hang over the edge of a table or touch
hot surfaces.
■Do not use an outdoor cooking appliance for purposes
other than intended.
■When connecting, first connect plug to the outdoor
cooking gas appliance then plug appliance into the outlet.
■Use only a Ground Fault Interrupter (GFI) protected circuit
with this outdoor cooking gas appliance.
■Do not remove the ground prong or use with an adapter
of 2 prongs.
Assemble Cooking Area
1. Lift off cover and grate and set aside.
2. Remove packing from around burners.
3. Reinstall grate.
4. Dispose of/recycle all packaging materials.
5. Gently slide sear burner completely into outdoor enclosure.
6. Go to the “Check and Adjust the Burners” section.
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING
A. Cover
B. Grate
B
A

17
GAS CONVERSIONS
For Models Equipped for Use with a 20 lb LP gas Tank
NOTE: Models that are equipped for Natural gas require Gas Conversion Kit Part Number W10118099 for conversion to LP gas. Use
the conversion instructions included in the kit. See “Assistance or Service” section for information on ordering.
Tools and Parts for Gas Conversion
Gather the required tools and parts before starting installation.
Read and follow the instructions provided with any tools listed
here.
Tools needed
Parts supplied
■Brass connector
■Convertible regulator 4" W.C. Natural, 11" W.C. LP
■Natural gas orifices
IMPORTANT: Gas conversions must be done by a qualified
installer. Before proceeding with conversion, shut off the gas
supply to the appliance prior to disconnecting the electrical
power.
This kit is designed for use from sea level up to 2000 ft elevation.
For higher elevations contact KitchenAid at 1-800-422-1230 in
the U.S.A. or call 1-800-607-6777 in Canada.
Conversion to a Local LP Gas Supply
Installation of the regulator
1. Turn off the main gas supply valve.
2. Unplug sear burner or disconnect power.
3. Disconnect 20 lb LP gas fuel tank (if present).
4. Turn off all burner control valves.
5. Remove rear cover and 2 screws.
6. Use adjustable wrench to remove LP hose regulator from
brass elbow. Use adjustable wrench to remove brass elbow.
7. Apply pipe sealant to the threads of the brass connector. Use
pipe thread sealant that is certified for use with LP gas.
8. Use adjustable wrench to install brass connector (supplied) to
manifold fitting.
NOTE: The arrow on the regulator must be pointing toward
the brass connector.
■Phillips screwdriver
■Pipe wrench
■Adjustable wrench
■10 mm socket and wrench
or 10 mm nut driver
■Thin flat-blade screwdriver
■Pliers
■Pipe thread sealant
certified for LP gas
WARNING
Explosion Hazard
Use a new CSA International approved “outdoor”
gas supply line.
Securely tighten all gas connections.
If connected to LP, have a qualified person make sure
gas pressure does not exceed 11” (28 cm) water
column.
Examples of a qualified person include:
licensed heating personnel,
authorized gas company personnel, and
authorized service personnel.
Failure to do so can result in death, explosion, or fire.
A. Manifold
B. Brass elbow
C. Rear of sear burner
D. Gas pressure regulator/hose assembly
B
A
C
D

18
9. Use pipe wrench to install the convertible regulator. Brass
cap will be facing up when tight.
10. To set the appliance regulator for LP gas, use adjustable
wrench to remove the brass cap on the convertible regulator.
11. Examine the stem on the brass cap. The letters “NAT” should
be showing on the end of the plastic stem farthest away from
the brass cap.
12. Remove stem from cap, turn it over and snap stem back into
the cap so the letters “LP” are at the end of the stem farthest
away from the brass cap.
13. Use adjustable wrench to reinstall cap onto regulator.
Make Sear Burner Connections
Connect Local LP Gas Supply
1. Use pipe wrench to connect certified ½" (1.3 cm) gas supply
pipe to inlet side of regulator from Fixed LP gas supply
according to local codes requirements. Use pipe thread
sealant that is certified for use with LP gas at connections
where required. There must be a certified manual shutoff
valve in the gas supply line near the sear burner for easy
access.
2. Turn on the gas supply to the sear burner.
3. Test all connections by brushing on an approved
noncorrosive leak-detection solution. Bubbles will show a
leak. Correct any leaks found.
Record Conversion
In the last page of the Use and Care Guide, write “Converted to
Local LP Gas Supply.” Also record the conversion date and the
technician/company that performed the conversion.
Conversion from LP Gas to Natural Gas
Installation of the regulator
1. Turn off the main gas supply valve.
2. Unplug sear burner or disconnect power.
3. Disconnect 20 lb LP gas fuel tank (if present).
4. Turn off all burner control valves.
5. Remove rear cover and 2 screws.
6. Use adjustable wrench to remove LP hose regulator from
brass elbow. Use adjustable wrench to remove brass elbow.
7. Apply pipe sealant to the threads of the brass connector. Use
pipe thread sealant that is certified for use with LP gas.
8. Use adjustable wrench to install brass connector (supplied) to
manifold fitting.
NOTE: The arrow on the regulator must be pointing toward
the brass connector.
A. Brass connector
B. Convertible regulator
A
B
LP
A. Manifold
B. Brass elbow
C. Rear of sear burner
D. Gas pressure regulator/hose assembly
B
A
C
D

19
9. Use pipe wrench to install the convertible regulator. Brass
cap will be facing up when tight.
10. To make sure the regulator is set for Natural gas, use
adjustable wrench to remove brass cap on appliance
regulator.
11. Examine the stem on the brass cap. If the letters “NAT” are
not showing on the end of the plastic stem farthest away from
the brass cap, remove stem from cap, turn it over and snap
stem back into the cap so the letters “NAT” are at the end of
the stem farthest away from the brass cap.
12. Reinstall cap onto convertible regulator.
Change the Sear burner orifices
1. Remove the sear burner cover screws. Set the screws and
cover aside.
2. Remove the burner igniter mounting screws.
3. Loosen the sear burner plate, located next to the igniter.
4. Remove the sear burner mounting screws.
5. Lift the sear burner out of the grill.
6. Use 6 mm socket wrench or 6 mm nut driver to remove the
orifice. Install the new 2.34 mm orifice supplied.
NOTE: The number 2.34 is stamped on the orifice for
identification.
7. Reinstall sear burner. Make sure that the igniter is out of the
way to allow proper positioning of burner. Use Phillips
screwdriver to attach the mounting screws.
8. Use Phillips screwdriver to reattach the igniter and sear
burner plate.
9. Reinstall sear burner cover. Use Phillips screwdriver to attach
mounting screws.
Hook up to Natural gas and Leak Test
1. Use pipe wrench to connect certified ¹⁄₂" (1.3 cm) gas supply
pipe to inlet side of regulator from Natural gas supply
according to local codes requirements. Use pipe thread
sealant that is certified for use with LP gas at connections
where required. There must be a certified manual shutoff
valve in the gas supply line near the sear burner for easy
access.
2. Turn on the gas supply to the sear burner.
3. Test all connections using an approved noncorrosive leak-
detection solution. Bubbles will show a leak. Correct any leak
found.
Record Conversion
1. The appliance nameplate is located inside the grill cabinet on
the right-hand cabinet side. With a permanent marker, check
the box next to “Natural gas” and mark through “LP -
Propane.”
In the last page of the Use and Care Guide, write “Converted to
Natural Gas.” Also record the conversion date and the
technician/company that performed the conversion.
NOTE: Place LP gas parts in plastic parts bag for future use and
keep with pack containing literature.
A. Brass elbow
B. Convertible regulator
A. Sear burner cover screws
A. Burner igniter mounting screws
A
B
NAT
A
A
A
A. Sear burner mounting screws
A

20
Check and Adjust the Burners
The burners are tested and factory-set for most efficient
operation. However, variations in gas supply and other conditions
may make minor adjustments to low flame setting necessary.
It is recommended that a qualified person make burner
adjustments.
NOTE: The burner flame of the infrared burner is not visible
because it heats the ceramic burner from the bottom through the
ports in the ceramic. A minimal height of flame may be present
through the ports in the ceramic. The ceramic plate will start to
turn red after 30 seconds to 1 minute.
Low Flame Adjustment
If flame goes out on the “LO” setting, the low flame setting must
be adjusted.
1. Turn off the valve and wait until burner is cool.
2. Remove grate.
3. Light sear burner using information in the “Outdoor Sear
Burner Use” section.
4. Turn burner to its lowest setting and remove knob.
5. Hold valve stem with pliers and insert a small flat-blade
screwdriver into the shaft.
6. Watch the flame and slowly turn the screwdriver
counterclockwise.
7. Adjust flame to minimum stable flame.
8. Replace the control knob and turn off the burner.
9. Replace grate after the burner has cooled.
USING YOUR OUTDOOR SEAR BURNER
Inspect the 20 lb LP Gas Fuel Tank Supply Hose
Inspect the gas pressure regulator/hose assembly before each
use.
1. Open the cabinet door and slide 20 lb LP gas fuel tank out.
2. Inspect the entire gas pressure regulator/hose assembly for
cuts, abrasions, or excessive wear.
3. If necessary, replace the gas pressure regulator/hose
assembly before using the sear burner.
Contact the dealer and use only replacement hoses specified for
use with the sear burner.
Prepare the Gas Supply
1. Remove outdoor sear burner cover.
2. Make sure the control knobs are all turned to the OFF
position.
Turn the Gas Supply On
1. For outdoor sear burners using a 20 lb LP gas fuel tank:
Slowly open the tank valve.
NOTE: If flow limiting device activates, your sear burner may
not light. If your sear burner does light, the flames will be low
and will not heat properly. Turn 20 lb LP gas fuel tank valve
and all control knobs off and wait 30 seconds. After shutting
off the 20 lb LP gas fuel tank, very slowly open tank valve and
wait 5 seconds before lighting.
2. For outdoor sear burners using gas supply source other than
20 lb LP gas fuel tank:
Open the manual shutoff valve in the gas supply line. The
valve is open when the handle is parallel to the gas pipe.
¹⁄₄" (0.64 cm)
approximate flame
height on all
burner ports
A. Valve stem
B. Small flat-blade screwdriver
C. Pliers
A
BC
A. Gas pressure regulator/hose assembly
A
