KitchenAid KCO211L User manual

Countertop Oven
KCO211L
KCO211
W11384127A.indb 1 10/17/2019 9:02:35 AM

2| PARTS AND FEATURES
Cookies
Start
Start
Pizza
Roast
Bagel
Toast
Bake
Broil
Reheat
PARTS AND FEATURES
PARTS AND ACCESSORIES
Chrome-plated
Steel Oven Rack
Cool down surface for
removable Oven Rack
Toughened
Glass Window
Door Handle
Removable
Crumb Tray
Chrome-plated
Steel Broiling
Rack
High-contrast
LCD Display
Preheating
Shade Slices
Frozen
F
C
Hrs
Min
Start
Cancel
Frozen
Cookies
Pizza
Roast
Bagel
Toast
Bake
Broil
Reheat
Keep Warm
Temperature / Timer Knob*Mode Knob: Cooking
mode selector
*Adjust the time by 1 minute for the rst hour and then by 5 minutes for the next hour. Adjust
by 5 °F or 1 °C temperature, depending on the unit selected. Rotate and press to select
desired shade and number of slices while using the Toast or Bagel mode.
Preheating
Shade Slices
Frozen
F
C
Hrs
Min
Frozen Icon
Fahrenheit Icon
Hours Icon
Minutes Icon
Slices Icon
Preheating Icon
Shade Icon
Shade Number
Graphic
NOTE: Press and hold the Frozen button for 3 seconds to switch between the temperature
units Fahrenheit (°F) and Celsius (°C).
Celsius Icon
Enamel-coated
Pan
Start: Start selected
cooking mode
Cancel: Stops
selected
cooking mode
Frozen: Push for
frozen food items
W11384127A.indb 2 10/17/2019 9:02:36 AM

ENGLISH
COUNTERTOP OVEN SAFETY | 3
COUNTERTOP OVEN SAFETY
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always
be followed, including the following:
1. Read all instructions.
2. Do not touch hot surfaces. Use handles or knobs.
3. To protect against risk of electrical shock, do not put cord, plugs, or any parts of
the Countertop Oven in water or other liquid.
4. The appliance is not to be used by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction.
5. Close supervision is necessary when any appliance is used by or near children.
6. Unplug from outlet when not in use and before cleaning. Allow to cool before
putting on or taking off parts.
7. Do not operate any appliance with a damaged cord or plug, or after the
appliance malfunctions, or is dropped or damaged in any manner. Return
appliance to the nearest Authorized Service Facility for examination, repair, or
adjustment.
8. The use of accessory attachments not recommended by the appliance
manufacturer may cause injuries.
9. Do not let cord hang over edge of table or counter, or touch hot surfaces.
10. This appliance is not intended to be operated by means of an external timer or a
separate remote-control system.
11. The temperature of accessible surfaces may be high when the appliance is
operating.
12. Do not place on or near a hot gas or electric burner, or in a heated oven.
13. Extreme caution must be used when moving an appliance containing hot oil or
other hot liquids.
W11384127A.indb 3 10/17/2019 9:02:36 AM

4| COUNTERTOP OVEN SAFETY
14. Bread may burn. Therefore toasters must not be used near or below curtains and
other combustible materials.
15. Use extreme caution when removing Broiling Rack, Multipurpose Pan, Oven
Rack, or disposing of hot grease.
16. Oversize foods or metal utensils must not be inserted in a Countertop Oven as
they may create a re or risk of electric shock.
17. A re may occur if Countertop Oven is covered or touching ammable material,
including curtains, draperies, walls and the like, when in operation. Do not store
any item on top of the appliance when in operation.
18. Do not clean with metal scouring pads. Pieces can break off the pad and touch
electrical parts, creating a risk of electric shock.
19. Extreme caution should be exercised when using containers constructed of
materials other than metal or glass.
20. Do not store any materials, other than manufacturer’s recommended
accessories, in this Countertop Oven when not in use.
21. Do not place any of the following materials in the Countertop Oven: paper,
cardboard, plastic, or anything similar.
22. Do not cover crumb drawer or any part of the Countertop Oven with metal foil.
This will cause overheating of the oven.
23. To disconnect, turn the Countertop Oven “off” by pressing Cancel button, then
remove plug from wall outlet.
24. Do not use the appliance outdoors.
25. Do not use appliance for other than intended use.
26. This appliance is intended to be used in household and similar application such
as:
- staff kitchen areas in shops, ofces and others working environments;
- farm houses;
- by clients in hotels, motels and other residential type environments;
- bed and breakfast type environments.
CAUTION: Hot surface.
(This alert symbol is required to comply with Mexican regulations.)
SAVE THESE INSTRUCTIONS
This product is designed for household use only.
COUNTERTOP OVEN SAFETY
W11384127A.indb 4 10/17/2019 9:02:36 AM

ENGLISH
COUNTERTOP OVEN SAFETY | 5
ELECTRICAL REQUIREMENTS
WARNING
Electrical Shock Hazard
Plug into a grounded 3 prong
outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions
can result in death, fire, or
electrical shock.
Voltage: 120 VAC
Frequency: 60 Hz
Wattage: 1800 Watts
NOTE: If the plug does not fit in the outlet,
contact a qualified electrician or service
technician. Do not modify the plug in any
way. Do not use an adapter.
Do not use an extension cord. If the power
supply cord is too short, have a qualified
electrician or service technician to install an
outlet near the appliance.
The cord should be arranged so that it will
not drape over the countertop or tabletop
where it can be pulled on by children or
tripped over unintentionally.
COUNTERTOP OVEN SAFETY
W11384127A.indb 5 10/17/2019 9:02:36 AM

6| COUNTERTOP OVEN FUNCTIONS
GETTING STARTED
NOTE: Upon first use, the Countertop Oven may produce light smoke. This is normal.
PREPARING THE COUNTERTOP OVEN FOR USE
Start
Cancel
Frozen
Preheating
Shade Slices
Frozen
F
C
Hrs
Min
4" (10 cm)
4" (10 cm)
4" (10 cm)
Cookies
KeepWarm
Pizza
Roast
Bagel
Toast
Bake
Broil
Reheat
1. Place the Countertop Oven on a dry, flat, level surface
such as a countertop or table.
2. Be sure the sides, back, and top of the oven are
at least 4” (10 cm) away from any walls, cabinets, or
objects on the counter or table.
3. Remove all accessories and wash in warm, sudsy
water. Dry thoroughly before placing in the Oven.
4. Remove all packaging materials, if present.
OVEN RACK POSITION SELECTION
Bagel
Pizza
Roast
Cookies
Start
Bagel
Pizza
Roast
Cookies
Start
Follow below guidelines to position the Oven Rack:
1. (Top): Use for broiling most meats, toast and cookies.
2. (Bottom): Optimal for most baking and cooking
operations. This position is suitable for cooking taller
food items.
2
1
Your Countertop Oven features 9 cooking modes specially designed for a variety of cooking
tasks. Memory settings allow you to customize the time and temperature in each mode to
t your specic needs. Your Countertop Oven will remember all your settings for the next
use (until unplugged). Frozen modes (available on certain cooking modes) allow you to take
countertop cooking to a whole new level.
Refer to the detailed explanations and tips for each cooking mode below, or see quick guide
charts for cooking or toasting mode options.
COUNTERTOP OVEN FUNCTIONS
TOASTING MODES
Toast Mode In Toast mode, the oven distributes power between the
top and bottom heating elements to deliver fast and even
toasting. Use the Toast mode for bread, toaster pastries,
frozen wafes.
If reheating pastries, use the Reheat mode.
Tips:
• Place oven rack in position 1. Place bread in the center
of the oven rack.
• Bread slices do not need to be ipped during the
toasting cycle.
• Select the Frozen option to allow frozen bread or similar
items extra time to thaw while cooking.
Cookies
Pizza
Roast
Bagel
Toast
Bake
Broil
Reheat
Keep Warm
W11384127A.indb 6 10/17/2019 9:02:37 AM

ENGLISH
COUNTERTOP OVEN FUNCTIONS | 7
Mode Rack
Position
Preset
Shade
Shade Range
(Light to Dark) Preset Slices Range (# of slices)
Toast 1 4 1 - 8 2 1 - 6
Bagel 1 4 1 - 8 2 1 - 6
TOASTING MODES CHART
COUNTERTOP OVEN FUNCTIONS
Bagel Mode In Bagel mode, the oven distributes power between the
top and bottom heating elements to nicely brown the top
of cut bagels while gently warming the outside.
Tips:
• Place bagels directly on the oven rack with the cut sides
facing UP.
• Bagels do not need to be ipped during the Bagel cycle.
• Select the Frozen option to allow frozen bagels extra
time to thaw while cooking.
Cookies
Pizza
Roast
Bagel
Toast
Bake
Broil
Reheat
Keep Warm
COOKING MODES
Pizza Mode In Pizza mode, your oven distributes power to the top and
bottom heating elements to maintain the desired oven
temperature.
Frozen mode:
Pizza setting will default to Frozen mode. You may use the
Frozen button to provide extra time for frozen pizzas to
cook, or deselect it when cooking freshly prepared pizzas.
Tips:
• For frozen pizzas, it is recommended to follow time and
temperature directions included on the food packaging.
• Thick crust, self-rising, or deep-dish pizzas will require
longer cooking times. Use a 12” (30 cm) non stick pan
for fresh or deep-dish pizzas to maintain shape and keep
sauce contained.
Cookies Mode In Cookies mode, your oven distributes power to the top
and bottom heating elements to maintain the desired oven
temperature.
Tips:
• Cookies will cook faster and more efciently because
their surface area is relatively small.
• Keep heat loss to a minimum by opening the oven door
only when necessary.
Cookies
Pizza
Roast
Bagel
Toast
Bake
Broil
Reheat
Keep Warm
Cookies
Pizza
Roast
Bagel
Toast
Bake
Broil
Reheat
Keep Warm
W11384127A.indb 7 10/17/2019 9:02:37 AM

8| COUNTERTOP OVEN FUNCTIONS
COUNTERTOP OVEN FUNCTIONS
Bake Mode
In Bake mode, your oven distributes power to the top and
bottom heating elements to maintain the desired oven
temperature.
Tip:
• Food may nish cooking up to 30% faster. Check baked
goods such as cakes, mufns, and pastries before the
expected nish time to avoid overcooking.
Cookies
Pizza
Roast
Bagel
Toast
Bake
Broil
Reheat
Keep Warm
Broil Mode Broiling uses direct radiant heat to cook food from above.
Your oven will distribute power to the top two heating
elements. To deliver efcient broiling, the bottom elements
will run then shut off after the oven preheats.
Tips:
• For best results, use the 9” x 13” (23 cm x 33 cm)
multipurpose pan and rack. It is designed to drain juices
and help avoid spatter and smoke.
• For proper draining, do not cover the rack with foil.
Instead, the bottom of the multipurpose pan may be
lined with aluminum foil for easier cleaning.
Cookies
Pizza
Roast
Bagel
Toast
Bake
Broil
Reheat
Keep Warm
Roast Mode
In Roast mode, your oven distributes power to the top and
bottom heating elements to maintain the desired oven
temperature.
Cookies
Pizza
Roast
Bagel
Toast
Bake
Broil
Reheat
Keep Warm
Keep Warm Mode
In Keep Warm mode, your oven distributes power to
the bottom elements to keep food warm before serving.
Tip:
• The preset temperature is 170°F (76°C), but you may
wish to adjust this depending on the item being warmed.
Cookies
Pizza
Roast
Bagel
Toast
Bake
Broil
Reheat
Keep Warm
Reheat Mode
Your oven distributes power to the top and bottom
elements to bring food to serving temperature.
Tip:
• The preset suggested temperature is 300°F (148°C),
but you may need to adjust this depending on the item
being reheated. Reheating too long may overcook or dry
out food.
Cookies
Pizza
Roast
Bagel
Toast
Bake
Broil
Reheat
Keep Warm
W11384127A.indb 8 10/17/2019 9:02:38 AM

ENGLISH
USING THE COUNTERTOP OVEN | 9
COUNTERTOP OVEN FUNCTIONS
NOTE: The Countertop Oven will automatically preheat when, Pizza, Cookies, Bake, Broil,
Roast modes are selected.
If you choose to start cooking directly and skip preheating, press the Start button twice and the
timer will start without preheating the Countertop Oven.
Mode Rack
No.
Preset Temp.
(°F / °C)
Temp. Range
(°F / °C)
Preset
Time (Mins)
Recommended
Foods
Pizza 1 - 2 400°F (204°C) 150–450°F
(66 °C - 232 °C) 17 Fresh and frozen Pizza
Cookies 1 375°F (191°C) 150–450°F
(66 °C - 232 °C) 10 Cookie Dough
Bake 1 - 2 350°F (176°C) 150–450°F
(66 °C - 232 °C 30 Cakes, breads, casseroles, mufns
Broil* 1 - 2 450°F (232°C) 350°F (176°C)
450°F (232°C) 8Chops, sh, seafood, browning
Roast 2 350°F (176°C) 150–450°F
(66 °C - 232 °C) 60 Chicken, meat and vegetables
Keep
Warm 1 - 2 170°F (76°C) 150–200°F
(66 °C - 93 °C) 60 Keeps food warm
Reheat 1 - 2 300°F (148°C) 150–450°F
(66 °C - 232 °C) 15 Leftovers
COOKING MODES CHART
* Broil mode allows temperatures of 350°F (176°C) and 450°F (232°C) only.
ADJUSTING THE RACK POSITION
1
Bagel
Pizza
Roast
Toast
Bake
Broil
Reheat
Cookies
Start
Cancel
Frozen
Preheating
Shade Slices
Frozen
F
C
Hrs
Min
KeepWarm
To adjust the Oven Rack position, Open the door of
oven and slide the Oven Rack out completely.
2
Bagel
Pizza
Roast
Toast
Bake
Broil
Reheat
Cookies
Start
Cancel
Frozen
Preheating
Shade Slices
Frozen
F
C
Hrs
Min
KeepWarm
Align the sides of the oven rack with the grooves for
the desired position (1 or 2) and slide the Oven Rack
straight in.
USING THE COUNTERTOP OVEN
W11384127A.indb 9 10/17/2019 9:02:38 AM

10 | USING THE COUNTERTOP OVEN
SETTING A COOKING OR TOASTING MODE
1
Bagel
Pizza
Roast
Cookies
Start
Bagel
Pizza
Roast
Cookies
Start
Make sure there will be enough clearance between
the top of the food item and the top elements. If
necessary, adjust the Oven Rack position between 1 or
2. Close the door.
WARNING
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death, fire, or
electrical shock.
2
Cookies
Pizza
Roast
Bagel
Toast
Bake
Broil
Reheat
Keep Warm
Plug into a grounded outlet. Turn the Mode knob to
select the desired cooking or toasting mode.
The preset temperature will be shown for a selected
cooking mode.
Shade and slices will be shown if selected Bagel or
Toast mode.
2
1
USING THE COUNTERTOP OVEN
PREHEATING
Preheating your Countertop Oven is important for consistent and even results. Once you
select your desired cooking mode and any other settings, and press START, and your oven will
saturate the walls and cooking racks above the oven’s set temperature to remove cold spots
that draw heat away from food. This also helps the oven stay at the desired temperature when
the door is opened for short periods of time.
During preheating, the light ring around the Start button will be on, and the Preheat indicator
will show on the LCD. Once the oven has reached the set temperature, a tone will sound to let
you know you can insert food and begin cooking. Preheating is NOT necessary in all cooking
modes.
To skip the Preheat and start the timer directly, push the START button a second time.
FROZEN MODE
The Frozen option adds additional cycle time to the selected cooking mode to allow for
thawing which helps in proper cooking of frozen food items. The additional time varies
depending on the selected cooking mode.
NOTE: The Frozen option is NOT available on Broil, Roast, Reheat, or Keep Warm cooking
mode.
W11384127A.indb 10 10/17/2019 9:02:39 AM

ENGLISH
USING THE COUNTERTOP OVEN | 11
3
Start
Cancel
Frozen
Preheating
Shade Slices
Frozen
F
C
Hrs
Min
Bagel
Pizza
Roast
Toast
Bake
Broil
Reheat
Cookies
Start
Cancel
Frozen
Preheating
Shade Slices
Frozen
F
C
Hrs
Min
Keep Warm
For Cooking mode: Rotate Temperature/Timer Knob
to adjust preset temperature. Press Knob to show
preset time and if needed, rotate Knob to adjust
cooking time.
(See “Cooking Modes”chart for temperature ranges.)
4
Bagel
Pizza
Roast
Toast
Bake
Broil
Reheat
Cookies
Start
Cancel
Frozen
Preheating
Shade Slices
Frozen
F
C
Hrs
Min
Keep Warm
Start
Cancel
Frozen
Preheating
Slices
Frozen
F
C
Hrs
Min
Shade
For Toast and Bagel modes: The shade icon starts
ashing. If desired, rotate Temperature/Timer Knob
to adjust shade. Press Knob to select slices. The slices
icon will starts ashing. If desired, rotate knob to
adjust number of slices.
(See “Toasting Modes” chart for shade and slices.)
5
Start
Cancel
Frozen
Preheating
Shade Slices
Frozen
F
C
Hrs
Min
Push the FROZEN button, if desired to add additional
cycle time to the selected cooking mode to allow
for thawing and proper cooking. The additional time
varies depending on the selected cooking mode.
Note: The Frozen option is NOT available on Broil,
Roast, Reheat, or Keep Warm modes.
6
Bagel
Pizza
Roast
Toast
Bake
Broil
Reheat
Cookies
Start
Cancel
Frozen
Preheating
Shade Slices
Frozen
F
C
Hrs
Min
Keep Warm
For Cooking modes: Press START to preheat the
oven. To skip preheat and start the timer directly, press
START button again.
NOTE: In Broil mode, the bottom elements will be on
until oven reaches set temperature.
For Toasting modes: Press START to begin the
toasting process and the timer will start to countdown.
NOTE: Preheating is NOT available on Keep Warm, Reheat, Toast, or Bagel modes.
7
Bagel
Pizza
Roast
Toast
Bake
Broil
Reheat
Cookies
Start
Cancel
Frozen
Preheating
Shade Slices
Frozen
F
C
Hrs
Min
KeepWarm
Bagel
Pizza
Roast
Toast
Bake
Broil
Reheat
Cookies
Start
Cancel
Frozen
Preheating
Shade Slices
Frozen
F
C
Hrs
Min
KeepWarm
For Cooking modes: A chime sounds when preheat
is complete. The display will change to show the time
counting down. Open the oven door and place the
food on the rack. Then, close the door.
Rotate temperature/ timer knob to adjust time, if
needed.
8
Preheating
Shade Slices
Frozen
F
C
Hrs
Min
Start
Cancel
Frozen
When the cooking cycle is complete, a chime will
sound.
NOTE: Always use oven mitts when removing pans or racks.
USING THE COUNTERTOP OVEN
FOR DETAILED INFORMATION ON USING THE COUNTERTOP OVEN
Visit www.kitchenaid.com/quickstart for additional instructions with videos, inspiring recipes,
and tips on how to use your Countertop Oven.
W11384127A.indb 11 10/17/2019 9:02:41 AM

12 | TIPS FOR GREAT RESULTS
TIPS FOR GREAT RESULTS
• Check food cooking progress through the
clear, tempered glass door window. Your
Countertop Oven wiII perform better and
be more energy efcient if you open the
door less often.
• If top of food item browns too fast,
lower the oven rack position or reduce
temperature. If bottom of food item
browns too fast, raise rack position or
reduce temperature.
• Remove all plastic and/or paper wrappers
from foods before cooking.
• Use only loosely covered oven-safe
containers. Airtight containers may cause
food to boil over or splatter.
• Although more energy efcient and faster
than traditional ovens, countertop oven
surfaces can become hot during cooking.
Touch only the door handle and knobs
during oven operation.
• Do not place items on top or near
Countertop Oven while in use. Only use
the included cooling rack to gently cool
food on the top of this oven.
• Replace cardboard, glass, or plastic lids
with aluminum foil for use in the
Countertop Oven.
• The nonstick multipurpose pan included
with the Countertop Oven is suitable
for items such as cookies, rolls, biscuits,
nachos, and pork chops.
• A variety of standard baking dishes, such
as a 9" (23 cm) round or square cake pan,
a 6-cup (1.5 L) mufn pan, small baking
sheets, and 1 and 2 qt (0.95 mL and 1.9 L)
round, square, and rectangular casserole
dishes, may be used. The door must
close completely.
• Choose bakeware made of metal, ovensafe
glass, ceramic, or silicone.
• Use lowest oven rack position when
using deep, oven-safe glass or ceramic
containers and allow at least 1" (2.5 cm)
clearance between the top of the container
and the upper cooking elements.
• Do not use glass lids. If a cover is desired,
use a loosely tted sheet of aluminum foil
shiny side up or down.
• Many convenience foods are packaged in
nonmetallic containers only suitable for
use in microwave ovens. Check package
directions to determine whether the
container is suitable for use in a regular
oven.
COUNTERTOP OVEN USE TIPS
Are guesstimates for Toast Mode OK?
Experience will teach you how much time
to use for toasting various kinds of bread.
Frozen, dark, or whole-grain breads require
a longer time. Rye breads are the most
susceptible to over-toasting and spot
charring. Fresh, soft, or white breads require
a shorter time.
For foods that melt
When cooking small pieces of food or foods
that will melt, use the multipurpose pan.
This will keep food from falling onto the
cooking elements.
To minimize cleanup
Spray the multipurpose pan with nonstick
cooking spray for easier cleanup when
cooking wet or sticky foods. Wash pan
thoroughly after each use to avoid buildup
of cooking spray.
Size limits for food and cooking
containers
For best results, food and/or oven-safe
containers (see “Food Cooking Tips”
section) must t into the Countertop Oven
without touching the cooking elements or
inside walls of the Countertop Oven. The
door must close completely. This allows air
to circulate around the food, helping ensure
consistent cooking temperature.
For extended use
When cooking for a long time at high
temperatures, you may detect a slight
odor from the Countertop Oven insulation
materials. This is normal.
FOOD COOKING TIPS
CHOOSING BAKEWARE FOR COUNTERTOP OVEN USE
W11384127A.indb 12 10/17/2019 9:02:41 AM

ENGLISH
CARE AND CLEANING | 13
CARE AND CLEANING
REMOVING AND CLEANING THE CRUMB TRAY
1
Bagel
Pizza
Roast
Toast
Bake
Broil
Reheat
Cookies
Start
Cancel
Frozen
Preheating
Shade Slices
Frozen
F
C
Hrs
Min
KeepWarm
Unplug your Countertop Oven from the outlet.
To remove the crumb tray, open the door, grasp the
crumb tray handle and slide straight out.
2 Empty and wash in warm, sudsy water, if needed. Dry
with a soft cloth. Open the door and slide it back into
place.
FOR DETAILED INFORMATION ON CLEANING THE COUNTERTOP OVEN
Visit www.kitchenaid.com/quickstart for additional instructions with videos, inspiring recipes,
and tips on how to clean your Countertop Oven.
INTERIOR:
• For easy cleaning, the inside walls of
the Countertop Oven feature a nonstick
coating. Remove heavy spatter after
use with a nylon or polyester mesh pad,
sponge, or cloth dampened with warm
water. Dry with a paper towel or soft, dry
cloth.
IMPORTANT: Do not use cleaning agents,
cleansers, or metal scouring pads on the
inner oven coating, as they may reduce its
effectiveness. The nonstick coating inside
the oven is scratch-resistant.
• Handwashing is recommended for
racks and pan. Remove all items from
the Countertop Oven. Wash the oven
rack, broiling rack, and multipurpose
pan in warm, sudsy water. Rinse and dry
thoroughly.
NOTE: The oven rack, multipurpose pan,
and broiling rack are dishwasher safe, but
hand washing is recommended.
EXTERIOR:
• Do not use abrasive cleaners or metal
scouring pads. They could scratch the
surface.
• For painted surfaces: Wipe the outside of
the Countertop Oven with a clean, damp
cloth and dry thoroughly.
• For stainless steel surfaces: Wipe the
outside of the Countertop Oven with a
clean, damp cloth and dry thoroughly.
A non abrasive liquid cleaner may be
used for stubborn stains. KitchenAid®
recommends the use of affresh®stainless
steel cleaner for all stainless steel surfaces.
The affresh®cooktop cleaner and scrubbing
pads are also recommended for cleaning
the toughest baked-on residue on stainless
steel and glass surfaces. Ensure all surfaces
are completely dry before using your oven.
Please visit www.affresh.com to learn more.
CLEANING YOUR COUNTERTOP OVEN
NOTE: Unplug your Countertop Oven from the outlet before cleaning. Allow Countertop Oven
and accessories to cool completely before cleaning.
W11384127A.indb 13 10/17/2019 9:02:42 AM

14 | TROUBLESHOOTING
• Is the Countertop Oven plugged into
a grounded 3 prong outlet?
Plug the Countertop Oven into a grounded
3 prong outlet.
• Is the fuse in the circuit to the Countertop
Oven in working order?
If you have a circuit breaker box, make sure
the circuit is closed. Try unplugging the
Countertop Oven, then plug it back in.
• Upper cooking elements visibly glow, but
bottom cooking elements do not.
The upper cooking elements use higher
power for better browning performance.
The lower cooking elements are on,
but may not visibly glow like the upper
cooking elements. This is normal and your
Countertop Oven is working properly.
• If the problem cannot be corrected:
See the “Warranty and Service” sections.
Do not return the Countertop Oven to the
retailer – retailers do not provide service.
• If the wrong temperature unit is
displayed:
Press and hold the Frozen button for
3 seconds to switch between Fahrenheit
(°F) and Celsius (°C) temperature units.
• If “E1 or E2” ashes on the display and
a chime sounds:
The NTC Sensor may not be working.
This issue can not be corrected. Please see
the “Warranty and Service” sections.
WARNING
Electrical Shock Hazard
Plug into a grounded 3 prong
outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions
can result in death, fire, or
electrical shock.
TROUBLESHOOTING
IF YOUR COUNTERTOP OVEN MALFUNCTIONS OR FAILS TO OPERATE
W11384127A.indb 14 10/17/2019 9:02:42 AM

ENGLISH
WARRANTY AND SERVICE | 15
WARRANTY AND SERVICE
KITCHENAID®COUNTERTOP OVEN WARRANTY FOR THE 50 UNITED
STATES, THE DISTRICT OF COLUMBIA, PUERTO RICO, AND CANADA
This warranty extends to the purchaser and any succeeding owner for Countertop Ovens
operated in the 50 United States, the District of Columbia, Puerto Rico, and Canada.
Length of Warranty: One Year Full Warranty from date of purchase.
KitchenAid Will Pay
for Your Choice of: Hassle-Free Replacement of your Countertop Oven. See the next page for details on how to arrange for service, or call the Customer
eXperience Center toll-free at 1-800-541-6390.
OR
The replacement parts and repair labor costs to correct defects
in materials and workmanship. Service must be provided by an
Authorized KitchenAid Service Center.
KitchenAid Will
Not Pay for: A. Repairs when your Countertop Oven is used in other than normal single family home use.
B. Damage resulting from accident, alteration, misuse or abuse.
C. Any shipping or handling costs to deliver your
Countertop Oven to an Authorized Service Center.
D. Replacement parts or repair labor costs for Countertop Oven
attachments operated outside the 50 United States, District of
Columbia, Puerto Rico, and Canada.
DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF REMEDIES
IMPLIED WARRANTIES, INCLUDING TO THE EXTENT APPLICABLE WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE EXCLUDED TO THE
EXTENT LEGALLY PERMISSIBLE. ANY IMPLIED WARRANTIES THAT MAY BE IMPOSED
BY LAW ARE LIMITED TO ONE YEAR, OR THE SHORTEST PERIOD ALLOWED BY LAW.
SOME STATES AND PROVINCES DO NOT ALLOW LIMITATIONS OR EXCLUSIONS ON
HOW LONG AN IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS LASTS, SO THE
ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU.
IF THIS PRODUCT FAILS TO WORK AS WARRANTED, CUSTOMER’S SOLE AND EXCLUSIVE
REMEDY SHALL BE REPAIR OR REPLACEMENT ACCORDING TO THE TERMS OF THIS
LIMITED WARRANTY. KITCHENAID AND KITCHENAID CANADA DO NOT ASSUME ANY
RESPONSIBILITY FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES. This warranty gives
you specic legal rights and you may also have other rights which vary from state to state or
province to province.
W11384127A.indb 15 10/17/2019 9:02:42 AM

16 | WARRANTY AND SERVICE
®/™ ©2019 All rights reserved. KITCHENAID and the design of the stand mixer
are trademarks in the U.S. and elsewhere. Used under license in Canada.
WARRANTY AND SERVICE
HASSLE-FREE REPLACEMENT WARRANTY—50 UNITED STATES, DISTRICT
OF COLUMBIA, AND PUERTO RICO
We’re so condent the quality of our
products meets the exacting standards of
KitchenAid that, if your Countertop Oven
should fail within the rst year of ownership,
KitchenAid will arrange to deliver an identical
or comparable replacement to your door
free of charge and arrange to have your
original Countertop Oven returned to us. Your
replacement unit will also be covered by our
one year limited warranty.
If your Countertop Oven should fail within the
rst year of ownership, simply call our toll-free
Customer eXperience Center at
1-800-541-6390 Monday through Friday.
Please have your original sales receipt
available when you call. Proof of purchase
will be required to initiate the claim. Give the
consultant your complete shipping address
(no P.O. Box numbers, please).
When you receive your replacement
Countertop Oven, use the carton, packing
materials, and prepaid shipping label to pack
up your original Countertop Oven and send it
back to KitchenAid.
HASSLE-FREE REPLACEMENT WARRANTY—CANADA
We’re so condent the quality of our
products meets the exacting standards of the
KitchenAid brand that, if your Countertop
Oven should fail within the rst year of
ownership, we will replace your Countertop
Oven with an identical or comparable
replacement. Your replacement unit will also
be covered by our one year limited warranty.
If your Countertop Oven should fail within the
rst year of ownership, simply call our toll-free
Customer eXperience Center at
1-800-807-6777 Monday through Friday.
Please have your original sales receipt
available when you call. Proof of purchase
will be required to initiate the claim. Give the
consultant your complete shipping address.
When you receive your replacement
Countertop Oven, use the carton, packing
materials, and prepaid shipping label to pack
up your original Countertop Oven and send it
back to KitchenAid.
ARRANGING FOR SERVICE AFTER THE WARRANTY EXPIRES,
OR ORDERING ACCESSORIES AND REPLACEMENT PARTS
In the United States and Puerto Rico:
For service information, or to order
accessories or replacement parts, call
toll-free at 1-800-541-6390 or write to:
Customer eXperience Center,
KitchenAid Small Appliances,
P.O. Box 218, St. Joseph, MI 49085-0218
Outside the United States and Puerto Rico:
Consult your local KitchenAid dealer or the
store where you purchased the Countertop
Oven for information on how to obtain
service.
For service information in Canada:
Call toll-free 1-800-807-6777.
For service information in Mexico:
Call toll-free 01-800-0022-767.
W11384127A.indb 16 10/17/2019 9:02:42 AM

PIÈCES ET CARACTÉRISTIQUES | 17
FRANÇAIS
Cookies
Start
Start
Pizza
Roast
Bagel
Toast
Bake
Broil
Reheat
PIÈCES ET CARACTÉRISTIQUES
PIÈCES ET ACCESSOIRES
Grille en acier
chromé du four
Surface de
refroidissement pour
grille amovible du four
Hublot en
verre trempé
Poignée
deporte
Ramasse-
miettes
amovible
Grille de cuisson
au gril en acier
chromé
Affichage ACL
à fort contraste
Preheating
Shade Slices
Frozen
F
C
Hrs
Min
Start
Cancel
Frozen
Cookies
Pizza
Roast
Bagel
Toast
Bake
Broil
Reheat
Keep Warm
Bouton de la
température/minuterie*
Bouton Mode:
Sélecteur du mode de
cuisson
*Ajuster la durée de cuisson de 1 minute pour la première heure, puis de 5 minutes pour la
durée subséquente. Ajuster la température à 5°F ou 1°C, en fonction de l’unité sélectionnée.
Tourner et appuyer sur le bouton pour sélectionner le degré de brunissement souhaité et le
nombre de tranches en utilisant le mode Toast (toastage) ou Bagel.
Preheating
Shade Slices
Frozen
F
C
Hrs
Min
Icône Produits surgelés
Icône Fahrenheit
Icône Heures
Icône Minutes
Icône Tranches
Icône Préchauffage
Icône Degré de
brunissement
Graphique du degré
de brunissement
REMARQUE : Maintenir le bouton Frozen (surgelé) enfoncé pendant 3 secondes pour passer
des unités de température Fahrenheit (°F) aux unités de température Celsius (°C) et vice versa.
Icône Celsius
Poêle émaillée
Start (mise en marche): démarre
le mode de cuisson sélectionné.
Cancel
(annulation):
arrête le mode
de cuisson
sélectionné.
Frozen (produits surgelés):
appuyer sur ce bouton pour
les produits surgelés.
W11384127A.indb 17 10/17/2019 9:02:43 AM

18 | SÉCURITÉ DU FOUR GRILLE-PAIN
SÉCURITÉ DU FOUR GRILLE-PAIN
CONSIGNES DE SÉCURITÉ
IMPORTANTES
Lors de l’utilisation d’appareils électriques, il faut toujours observer certaines
précautions élémentaires de sécurité, y compris les suivantes:
1. Lire toutes les instructions.
2. Ne pas toucher les surfaces chaudes. Utiliser les poignées ou les boutons.
3. Pour éviter toute décharge électrique, ne pas mettre le cordon, les prises ou un
composant du four grille-pain dans l’eau ou tout autre liquide.
4. Cet appareil ne convient pas à une utilisation par des personnes (y compris des
enfants) à capacités physiques, sensorielles ou mentales réduites, ou possédant
un manque d’expérience et de connaissances, à moins qu’elles ne soient
placées sous supervision ou qu’elles aient reçu des instructions.
5. Une surveillance attentive s’impose lorsqu’un appareil ménager est utilisé par
ouà proximité d’enfants.
6. Débrancher la prise lorsque l’appareil n’est pas utilisé et avant le nettoyage.
Attendre que l’appareil ait refroidi avant d’installer ou de retirer des pièces.
7. Ne pas faire fonctionner un appareil si le cordon ou la prise est endommagé,
si l’appareil ne fonctionne pas correctement, s’il tombe ou s’il est endommagé
d’une quelconque façon. Retourner l’appareil au centre de dépannage agréé le
plus proche pour examen, réparation ou réglage.
8. L’utilisation d’accessoires non recommandés par le fabricant de l’appareil peut
causer des blessures.
9. Ne pas laisser le cordon pendre sur le côté d’une table ou d’un comptoir, ou toucher
une surface chaude.
10. Cet appareil n’est pas conçu pour être utilisé à l’aide d’une minuterie externe ou
d’un système de commande à distance séparé.
W11384127A.indb 18 10/17/2019 9:02:43 AM

SÉCURITÉ DU FOUR GRILLE-PAIN | 19
FRANÇAIS
11. La température des surfaces accessibles peut être élevée lorsque l’appareil est en
marche.
12. Ne pas placer sur ou près d’un brûleur électrique ou à gaz chaud, ou dans un
four chaud.
13. Prendre d’extrêmes précautions lorsqu’on déplace un appareil ménager contenant
de l’huile chaude ou d’autres liquides chauds.
14. Le pain peut brûler, il ne faut donc pas utiliser le grille-pain près ou sous des
matériaux combustibles, comme des rideaux.
15. La plus grande prudence s’impose lorsqu’on déplace la grille de cuisson au gril,
le plat multifonction, la grille du four ou que l’on déverse de la graisse chaude.
16. On ne doit insérer ni aliments surdimensionnés, ni ustensiles en aluminium dans
le four grille-pain car ils peuvent présenter un risque d‘incendie ou de décharge
électrique.
17. Lorsque le four grille-pain est en cours de fonctionnement, un incendie peut se produire
si le four grille-pain est recouvert par un matériau inammable ou en contact avec
celui-ci, notamment des rideaux, draperies, parois et autres objets assimilés. Ne pas
entreposer d’objet sur le dessus de l’appareil pendant son fonctionnement.
18. Ne pas nettoyer avec des tampons à récurer métalliques. Des morceaux pourraient se
détacher et toucher les pièces électriques, créant un risque de décharge électrique.
19. La plus grande prudence s’impose lors de l’utilisation de récipients conçus à
base de matériaux autres que le métal ou le verre.
20. Ne pas placer dans ce four pendant son fonctionnement des articles autres que
les accessoires recommandés par le fabricant.
21. Ne placer aucun des articles suivants dans le four grille-pain: papier, carton,
plastique ou autres éléments semblables.
22. Ne pas couvrir le ramasse-miettes ou toute partie du four avec du papier aluminium.
Ceci entraînera la surchauffe du four.
23. Pour déconnecter l’appareil, éteindre le four grille-pain en appuyant sur le bouton
Cancel (annulation), puis débrancher la che de la prise murale.
24. Ne pas utiliser à l’extérieur.
25. Ne pas utiliser l’appareil pour un autre usage que celui pour lequel il est conçu.
26. Cet appareil est destiné à un usage domestique et à d’autres usages similaires
comme :
- coins cuisine réservés au personnel des boutiques, des bureaux ou d’autres
environnements professionnels;
- maisons d’hôtes;
- ainsi que par les clients d’hôtel, de motels et d’autres installations
d’hébergement comme les;
- de gîtes touristiques.
ATTENTION: Surface chaude.
(Ce symbole d’alerte est requis pour se conformer à la
réglementation mexicaine.)
CONSERVER CES INSTRUCTIONS
Ce produit est conçu uniquement pour un usage domestique.
SÉCURITÉ DU FOUR GRILLE-PAIN
W11384127A.indb 19 10/17/2019 9:02:43 AM

20 | SÉCURITÉ DU FOUR GRILLE-PAIN
SPÉCIFICATIONS ÉLECTRIQUES
AVERTISSEMENT
Risque de choc électrique
Brancher sur une prise à 3 alvéoles
reliée à la terre.
Ne pas enlever la broche de liaison
à la terre.
Ne pas utiliser un adaptateur.
Ne pas utiliser un câble de
rallonge.
Le non-respect de ces instructions
peut causer un décès, un incendie
ou un choc électrique.
Tension: 120 VCA
Fréquence: 60Hz
Puissance : 1800 W
REMARQUE: Si cette fiche ne convient
pas à la prise, contacter un électricien ou
un technicien qualifié. Ne pas modifier
la prise de quelque manière que ce soit.
Nepas utiliser d’adaptateur.
Ne pas utiliser de rallonge. Si le cordon
d’alimentation électrique est trop court,
faire installer une prise près de l’appareil
électroménager par un électricien ou un
technicien qualifié.
Le cordon doit être disposé de sorte qu’il ne
pende pas par-dessus le comptoir ou la table
de cuisine, où des enfants pourraient tirer
dessus ou trébucher dessus involontairement.
SÉCURITÉ DU FOUR GRILLE-PAIN
W11384127A.indb 20 10/17/2019 9:02:43 AM
