OVEN PARTS
1
For Models: KEBK101SBL04, KEBK101SWH04, KEBK101SSS04
(Black) (White) (Stainless)
5−09 Litho in U.S.A. (amd)(bay) Part No. W10269261 Rev. A
30" BUILT−IN ELECTRIC
SINGLE OVEN

OVEN PARTS
2
For Models: KEBK101SBL04, KEBK101SWH04, KEBK101SSS04
(Black) (White) (Stainless)
W10269261
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature Parts
Installation
Instructions
8304336 English
8304571 French
W10162179 Use & Care Guide
Tech Sheet
W10220952 English
W10220953 French
8304335 Easy Set Guide
Safer Cooking Tips
9762761 English
W10065852 French
2
W10153090 Bracket, Base
3 Hinge Receiver
4455606 Right
4455605 Left
4
W10105790 Bumper, Door (2)
5 8303829 Exhaust,Vent Slope
6
W10181196 Divider, Vent
Center
7
W10204470 Top Chassis
8 4449809 Screw
9 4452158 Tube, Vent
10
W10169756 Lens, Light
11
W10009940 Oven Light,
Assembly
12
W10169757 Bulb, Light
13 3400832 Screw (2)
14
W10115861 Frame, Front
15 8304493 Gasket, Door
16 3196176 Screw
17 4449040 Screw
18 3400893 Screw (6)
19 4451478 Support, Insulation
20
W10169348 Thermostat,
Bracket
21 Mounting Rail,Side
Right
8303675BL Black
8303675WH White
Left
8303676BL Black
8303676WH White
22
W10195935 Latch, Mortorized
23 4449743 Screw
24 4448444 Mounting Grommet,
Rail (6)
25 4455641 Side, Chassis
26 8304303 Back, Chassis
27 Liner, Oven
(Not serviceable)
28 8304452 Thermal Fuse 105C
29
W10131825 Sensor
31 8303516 Base, Chassis
32 8304478 Retainer, Gasket
33 8303517 Cover, Back
34 Trim, Bottom Vent
8303705BL Black
8303705WH White
W10216230 Stainless
FOLLOWING PARTS
NOT ILLUSTRATED
INSULATION
8303965 Insulation, Wrap
8303967 Insulation, Back

CONTROL PANEL PARTS
3
For Models: KEBK101SBL04, KEBK101SWH04, KEBK101SSS04
(Black) (White) (Stainless)
W10269261
Illus. Part
No. No. DESCRIPTION
1 Panel, Control
8303716BL Black
8303716WH White
W10216219 Stainless
2 8303687 Support Appliance
Manager
4 8304331 Control Panel,
Glass Touch
5
W10118733 User Interface
6 8303719 Backer, Control
7 8303887 Bracket,Enclosure
8 4449154 Screw
9 3400832 Screw
10
W10119143 Appliance Manager
11 8304441 Resistor, Drop

OVEN DOOR PARTS
4
For Models: KEBK101SBL04, KEBK101SWH04, KEBK101SSS04
(Black) (White) (Stainless)
W10269261
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 8303737BL Door Liner
2
W10174285 Hinge, Door (2)
3 3196183 Screw
4
8304581BL Vent, Door Top
5 Bracket, Door
8304377 Right
8304378 Left
6 8303746 Door, Top Bracket
7 8303731 Glass, Inner
8 4449743 Screw
9
8303745BL Frame, Door Side
10 8304523 Seal
11
8304360BL Bracket, Handle
12 Door Glass,
Assembly
8303993 Black
8303995 White
W10237350 Stainless
13 Door Handle
8303774BL Black
8303774WH White
8303774SS Stainless
15 Badge
8304603BL Black
8304603WH White
8304603SS Stainless
16 8304522 Bumper, Glass
17 Cover, Door Hinge
W10137044 Right
W10137043 Left

INTERNAL OVEN PARTS
5
For Models: KEBK101SBL04, KEBK101SWH04, KEBK101SSS04
(Black) (White) (Stainless)
W10269261
Illus. Part
No. No. DESCRIPTION
1 9760774 Element, Broil
2
W10179152 Rack, Oven
3 9760768 Element, Bake
4 4455037 Tray, Bake
5 4449154 Screw
6 4450039 Cover, Bake Tray
7 4449809 Screw
8 8304602 Element, Broil
Shield

TOP VENTING PARTS
6
For Models: KEBK101SBL04, KEBK101SWH04, KEBK101SSS04
(Black) (White) (Stainless)
W10269261
Illus. Part
No. No. DESCRIPTION
1 8304219 Cover, Top
2 8304643 Duct, Air Outlet
3 4449809 Screw
4 8303972 Blower, 60mm
6 8285593 Connector, Cover
7
W10111628 Transformr,Control
9 4449868 Block, Terminal
10 3400080 Screw
11 8303684 Vent, Control
Panel
12 Side, Control Top
8303518 Right
8304255 Left
13 8303520 Back, Control

OPTIONAL PARTS
7
For Models: KEBK101SBL04, KEBK101SWH04, KEBK101SSS04
(Black) (White) (Stainless)
W10269261
Illus. Part
No. No. DESCRIPTION
PAINT, TOUCH−UP (1/2oz.)
72017 White
261869 Cord Brown
72032 Black
PAINT, SPRAY
350930 White
261900 Citrine White
830864 Black
ADHESIVE
591014 Adhesive
Loctite (1/3 oz.)
482338 Sealer, Silastic
(3 oz.)
WIRING HARNESS PARTS
W10143473 Harness, Latch
Door
W10155291 Connector, Flex
W10171561 Harness, Main
8304051 Communication,
Harness
98997 Clip
8304438 Conduit, Single
4450800 Screw, Ground
Miscellaneous
4448950 Screw, Install (4)
