KitchenAid KEBK206SWH02 User manual

OVEN PARTS
1
For Models:KEBK206SWH02
(White)
2−09 Litho in U.S.A. (amd) (psw) Part No. W10250488 Rev. A
30" BUILT−IN ELECTRIC
DOUBLE OVEN

OVEN PARTS
2
For Models:KEBK206SWH02
(White)
W10250488
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature Parts
8304336 Installation
Instructions
W10162179 Use & Care Guide
Tech Sheet
W10220954 English
W10220955 French
8304335 Easy Set Guide
Safer Cooking Tips
9762761 English
W10065852 French
2
W10153090 Bracket, Base
3 Hinge Receiver
4455606 Right
4455605 Left
4
W10105790 Bumper, Door
5 8303829 Exhaust,Vent Slope
6
W10181196 Divider,
Center Vent
7
W10204470 Top Chassis
8 4449809 Screw
9 4452158 Tube, Vent
10
W10169756 Lens, Light
11
W10009940 Assembly,
Oven Light
12
W10169757 Bulb, Light
13 3400832 Screw (2)
14
W10115861 Frame, Front
15 8304493 Gasket, Door
16 3196176 Screw
17 4449040 Screw
18 4449154 Screw
19 4451478 Support, Insulation
20 4450038 Screw (2)
21 Side,Mounting Rail
8303677WH Right
8303678WH Left
22
W10195935 Latch, Mortorized
23 4449743 Screw
24 4448444 Grommet,
Mounting Rail
25 4455641 Side, Chassis
26 8304303 Back, Chassis
27 Liner, Oven
(Not serviceable)
28 8304452 Thermal Fuse
29
W10131825 Sensor
30 8303685 Vent, Center
31 8303516 Base, Chassis
32 8304478 Retainer, Gasket
33 8303517 Cover, Back
34
8303705WH Trim, Bottom Vent
35
W10169348 Bracket,
Thermostat
FOLLOWING PARTS
NOT ILLUSTRATED
INSULATION
8303965 Insulation, Wrap
8303967 Insulation, Back

CONTROL PANEL PARTS
3
For Models:KEBK206SWH02
(White)
W10250488
Illus. Part
No. No. DESCRIPTION
1 8303716WH Panel, Control
2 8303687 Support,
Appliance Manager
4 8304333 Control Panel,
Glass Touch
5
W10172472 User Inferface
6 8303719 Backer, Control
7 8303887 Bracket,Enclosure
8 4449154 Screw
9 3400832 Screw
10
W10119142 Appliance Manager
11 8304441 Resistor, Drop

OVEN DOOR PARTS
4
For Models:KEBK206SWH02
(White)
W10250488
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 8303737BL Door Liner
2
W10174285 Hinge, Door
3 3196183 Screw
4
8304581BL Vent, Door Top
5 Bracket, Door
8304377 Right
8304378 Left
6 Cover, Hinge
W10137044 Right
W10137043 Left
7 8303731 Glass, Inner
8 4449743 Screw
10 8304523 Seal
11
8304360BL Bracket, Handle
12 8303995 Door Glass, Assy
Lower Includes #17
8303996 Door Glass, Assy
Upper No Nameplate
13
8303774WH Door Handle
15
8303745BL Frame, Door Side
16 8303746 Bracket,
Top Door
17
8304603WH Nameplate
18 8304522 Bumper, Glass

INTERNAL OVEN PARTS
5
For Models:KEBK206SWH02
(White)
W10250488
Illus. Part
No. No. DESCRIPTION
1 9760774 Element, Broil
2 8304602 Sheild,
Broil, Element
3
W10179152 Rack, Oven
4 9760768 Element, Bake
5 4455037 Tray, Bake
6 4449154 Screw
7 4450039 Cover, Bake Tray
8 4449809 Screw

TOP VENTING PARTS
6
For Models:KEBK206SWH02
(White)
W10250488
Illus. Part
No. No. DESCRIPTION
1 9752759 Relay
2 8304643 Duct, Air Outlet
3 4449809 Screw
4 8303972 Blower, 60mm
6 8285593 Connector, Cover
7
W10111628 Transformer,
Control
9 4449868 Block, Terminal
10 3400080 Screw
11 8303684 Vent, Control
Panel
12 Side, Control Top
8303518 Right
8304255 Left
13 8303520 Back, Control
14 8304219 Cover, Top
15
7103P027−60 Nut,
Terminal Block

OPTIONAL PARTS
7
For Models:KEBK206SWH02
(White)
W10250488
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
PAINT, TOUCH−UP (1/2oz.)
72017 White
261869 Cord Brown
72032 Black
PAINT, SPRAY
350930 White
261900 Citrine White
830864 Black
ADHESIVE
591014 Adhesive
Loctite (1/3 oz.)
482338 Sealer, Silastic
(3 oz.)
WIRING HARNESS PARTS
W10143473 Harness,
Door Latch
W10171562 Harness, Main
8304051 Harness,
Commnication
8304439 Conduit, Double
4450800 Screw,Ground
98997 Clip
W10155291 Connector, Flex
Miscellaneous
4448950 Screw, Install (4)
