OVEN PARTS
1
For Models: KEMS308SBL02, KEMS308SWH02, KEMS308SSS02
(Black) (White) (Stainless)
8−08 Litho in U.S.A. (amd) (eeb) Part No. W10207237 Rev. A
30" BUILT−IN ELECTRIC
COMBO OVEN
THERMAL CONVECTION

OVEN PARTS
2
For Models: KEMS308SBL02, KEMS308SWH02, KEMS308SSS02
(Black) (White) (Stainless)
W10207237
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature Parts
8304337 Installation
Instructions
Use & Care Guide
W10162223 Combo, Lower
W10162181 Microwave
Tech Sheet
W10185205 English
W10185206 French
Easy Set Guide
8304338 Oven
8304375 Microwave
Safer Cooking Tips
9762761 English
W10065852 French
2
W10153090 Bracket, Base
3 Hinge Receiver
4455606 Right
4455605 Left
4
W10105790 Bumper, Door (2)
5 8303829 Exhaust,Vent Slope
6
W10181196 Divider,
Center Vent
7
W10204470 Top Chassis
8 4449809 Screw
9 4452158 Tube, Vent
10
W10169756 Lens, Light
11
W10009940 Oven Light
Assembly
12
W10169757 Bulb, Light
13 3400832 Screw (2)
14 8304627 Frame, Front
15 8304493 Gasket, Door
16 3196176 Screw
17 4449040 Screw
18 3400893 Screw
19 4451478 Support, Insulation
20 4450038 Screw (2)
21 Mounting Rail,Side
Right
8303679BL Black
8303679WH White
Left
8303680BL Black
8303680WH White
22 8303692 Latch, Motorized
23 4449743 Screw
24 4449748 Screw
25 4455641 Side, Chassis
26 8304303 Back, Chassis
27 Liner, Oven
(Not serviceable)
28 8304452 Thermal Fuse
29
W10131825 Sensor
30 8303685 Vent, Center
31 8303516 Base, Chassis
32 8304478 Retainer, Gasket
33 8303517 Cover, Back
34 Trim, Bottom Vent
8303705BL Black
8303705WH White
W10165443 Stainless
35 4448444 Grommet,
Mounting Rail
36
W10169348 Bracket,
Thermostat
FOLLOWING PARTS
NOT ILLUSTRATED
INSULATION
8303965 Insulation, Wrap
8303967 Insulation, Back

CONTROL PANEL PARTS
3
For Models: KEMS308SBL02, KEMS308SWH02, KEMS308SSS02
(Black) (White) (Stainless)
W10207237
Illus. Part
No. No. DESCRIPTION
1 Panel, Control
8303716BL Black
8303716WH White
W10165445 Stainless
2 8304441 Resistor, Drop
3 8303797 Bracket, Glass
Touch
4 8303882 Keyboard,
Glass Touch
5
W10118734 User Interface,
Oven
6 8303719 Backer, Control
7 8303887 Bracket,Enclosure
8 4449154 Screw
9 3400832 Screw
10
W10119143 Appliance Manager
11
W10118735 User Interface,
Microwave

OVEN DOOR PARTS
4
For Models: KEMS308SBL02, KEMS308SWH02, KEMS308SSS02
(Black) (White) (Stainless)
W10207237
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 8303737BL Door Liner
2
W10174285 Hinge, Door (2)
3 3196183 Screw
4
8304581BL Vent, Door Top
5 Bracket, Door
8304377 Right
8304378 Left
6 Cover, Hinge
W10137044 Right
W10137043 Left
7 8303731 Glass, Inner
8 4449154 Screw
10 8304523 Seal
11
8304360BL Bracket, Handle
12 Door Glass,
Assembly
Lower Includes #17
8303993 Black
8303995 White
8303991 Stainless
13 Door Handle
8303774BL Black
8303774WH White
8303774SS Stainless
15
8303745BL Frame, Door Side
16 8303746 Door, Top Bracket
17 Badge
8304603BL Black
8304603WH White
8304603SS Stainless
18 8304522 Bumper, Glass

INTERNAL OVEN PARTS
5
For Models: KEMS308SBL02, KEMS308SWH02, KEMS308SSS02
(Black) (White) (Stainless)
W10207237
Illus. Part
No. No. DESCRIPTION
1 9760774 Element, Broil
2 8304602 Shield,
Broil Element
5 8303841 Rack, Oven
6 8303839 Oven Rack
(Sliding)
7 9760768 Element, Bake
8 4455037 Tray, Bake
9 4449154 Screw
10 4450039 Cover, Bake Tray
11 4449809 Screw
12
8303962BU Cover, Fan
13 9760769 Element
Convection
14 9755543 Jack, Meat Probe
15 9755542 Probe, Meat
16
W10116351 Blade, Fan
17
W10116349 Nut
18
W10196895 Motor,
Convection Fan
19 9755547 Washer, Lock
20 9755546 Nut, Hidden

TOP VENTING PARTS
6
For Models: KEMS308SBL02, KEMS308SWH02, KEMS308SSS02
(Black) (White) (Stainless)
W10207237
Illus. Part
No. No. DESCRIPTION
1 4449154 Screw
2 4454949 Holder, Fuse
3 4449809 Screw
4 8303972 Blower
6 8304643 Duct, Air Outlet
7 9762053 Transformer,
Control
8 8285593 Cover, Connector
9 4449868 Block, Terminal
10
W10017410 Fuse
11 8304509 Chassis,
Back Combo
12 Side, Combo
8304546 Right
8303539 Left
13 8303537 Back, Control
14 8303519 Cover, Top Rear
15
7103P027−60 Nut,
Terminal Block
16 8304569 Support,
Microwave Module
17 3400080 Screw

CABINET AND STIRRER PARTS
7
For Models: KEMS308SBL02, KEMS308SWH02, KEMS308SSS02
(Black) (White) (Stainless)
W10207237

CABINET AND STIRRER PARTS
8
For Models: KEMS308SBL02, KEMS308SWH02, KEMS308SSS02
(Black) (White) (Stainless)
W10207237
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 W10120227 Control, Electric
2 8205669 Support
3
W10130892 Plate, Air
4
W10130901 Insulation, Side
Left
5
W10120471 Cover, Side Left
6
W10120223 Thermostat
7
W10120224 Element,
Convection
8 4375418 Fan
9
W10120233 Nut, Speed
10
W10130891 Holder
11
W10120220 Noise Filter
12
W10120228 Control, Electric
Converter
13
W10130909 Bracket, Support
14
W10131249 Screw
15 8205692 Transformer
16 4375427 Actuator
17 4375321 Fuse
18 4375231 Block, Fuse
19
W10130897 Bracket, Support
20 8205653 Filter, Noise
21 8205654 Thermostat
22
W10120113 Magnetron
23
W10130895 Plate, Air
24 4375319 Spring, Lamp
25 8205685 Spring
26 8205658 Housing, Lamp
27 4375348 Lamp
28
W10120222 Thermostat
29
W10131248 Switch
30 8205683 Holder, Switch
31 4375320 Reflector
32 4375318 Lens, Lamp
33
W10120231 Clip. Spring
34
W10120477 Top Vent
36 Trim, Side
W10120473 Right
W10120475 Left
37
W10120469 Bushing
38
W10130905 Bracket, Support
39 8205708 Bracket, Support
40 8205682 Shaft, Turntable
Turntable
41 8205681 Cover, Motor
Turntable
42
W10120234 Cover
43 4375252 Gasket, Shaft
44 8205655 Motor, Turntable
45 4375202 Screw
46 8205707 Support
47
W10120478 Hinge, Door
48
W10130903 Cover, Plate
49
W10130904 Cover, Rear
50 8205680 Cover, Side Right
51
W10120221 Convection, Motor
Assmebly
52 8205721 Blower Assembly
53
W10130907 Cover, Inverter
54
W10120229 Inverter
55
W10130906 Holder, Inverter
56
W10130890 Screw
57
W10130908 Baffle, Air
58
W10130899 Plate, Air
59
W10120235 Rod, Release
60
W10120225 Sensor
61 8205685 Spring
64 8205683 Interlock
65
W10130900 Insulation
66 8205704 Spring
67
W10130902 Insulation
68 8205689 Spring
69 8205688 Arm
70 8205686 Support
71
W10120236 Arm
72
W10120470 Pin, Damper
73 8205690 Sensor
74
W10130898 Duct, Magnetron

INTERNAL MICROWAVE PARTS
9
For Models: KEMS308SBL02, KEMS308SWH02, KEMS308SSS02
(Black) (White) (Stainless)
W10207237
Illus. Part
No. No. DESCRIPTION
1 W10120480 Crisp Plate
2
W10120484 Steamer
4
W10120486 Plate, Baking
5
W10120483 Rack
6 8205676 Turntable
7 8205678 Ring
8 8205677 Drive, Turn Table
9
W10120481 Handle, Pan
10
W10120226 Grill Heater
11
W10120230 Cover, Plates (2)
12
W10120232 Bracket, Mounting

MICROWAVE DOOR PARTS
10
For Models: KEMS308SBL02, KEMS308SWH02, KEMS308SSS02
(Black) (White) (Stainless)
W10207237
Illus. Part
No. No. DESCRIPTION
1 8304588BL Cap, Screw
2 4449809 Screw
3
W10120487 Door, Microwave
4 4449154 Screw (4)
5 8303033 Bracket, Door
6 Glass Assembly
8304027 Black
8304028 White
8304026 Stainless
7 Handle, Door
8303774BL Black
8303774WH White
8303774SS Stainless
8
W10143304 Screw

OPTIONAL PARTS
11
For Models: KEMS308SBL02, KEMS308SWH02, KEMS308SSS02
(Black) (White) (Stainless)
W10207237
Illus. Part
No. No. DESCRIPTION
PAINT, TOUCH−UP (1/2oz.)
72017 White
261869 Cord Brown
72032 Black
PAINT, SPRAY
350930 White
261900 Citrine White
830864 Black
ADHESIVE
591014 Adhesive
Loctite (1/3 oz.)
482338 Sealer, Silastic
(3 oz.)
FOLLOWING PARTS
NOT ILLUSTRATED
WIRING HARNESS PARTS
W10143473 Harness,
Door Latch
8304052 Harness,
Communication
4452400 Lead, Ground
4449809 Screw
W10171567 Harness, Main
4450800 Screw, Ground
4449809 Screw
8304440 Conduit, Combo
Miscellaneous
4448950 Screw, Install (4)
