KitchenAid Architect Series II KDRS807SSS User manual

30" Freestanding and Slide-In Dual Fuel Range
®
PRODUCT MODEL NUMBERS PRODUCT DIMENSIONS
KDRS807S KDSS907S
Because Whirlpool Corporation policy includes a continuous commitment to improve
our products, we reserve the right to change materials and specifications without notice.
Dimensions are for planning purposes only. For complete details, see Installation
Instructions packed with product. Specifications subject to change without notice.
The cooktop sides of the slide-in range fit over the
cutout edge of your countertop.
If you have a square finish (flat) countertop and the
opening width is 30" (76.2 cm), no countertop
preparation is required.
Formed front-edged countertops must have molded
edge shaved flat 3/8" (1.0 cm) from each front corner
of opening.
Tile countertops may need trim cut back
3/8" (1.0 cm) from each front corner and/or rounded
edge flattened.
If countertop opening width is greater than
30" (76.2 cm), adjust the 3/8" (1.0 cm) dimension.
Countertop must be level. Place level on countertop,
first side to side; then front to back. If countertop is
not level, range will not be level. Range must be level
for satisfactory baking conditions.
Gas supply: Provide a gas supply line of 3/4"
(1.9 cm) rigid pipe to the range location. A smaller
size pipe on longer runs may result in insufficient
gas supply. Pipe-joint compounds that resist the
action of LP gas must be used. Do not use
TEFLON®tape. With LP gas, piping or tubing size
can be 1/2" (1.3 cm) minimum. Usually, LP gas
suppliers determine the size and materials used in
the system. If local codes permit, a new CSA
design-certified, 4' - 5' (122 - 152.4 cm) long,
1/2" (1.3 cm) or 3/4" (1.9 cm) I.D., flexible metal
appliance connector may be used for connecting
range to the gas supply line. A 1/2" (1.3 cm) male
pipe thread is needed for connection to the female
pipe threads of the inlet to the appliance pressure
regulator. The supply line must be equipped with a
manual shutoff valve. This valve should be located
in the same room but external to the range. It
should be in a location that allows ease of opening
and closing.
Electrical: When a 4-wire or 3-wire, single phase
120/240 volt, 60 Hz, AC only electrical supply is
available, a 50-amp maximum circuit protection is
required. When a 4-wire or 3-wire single phase
120/208 volt 60 Hz, AC only electrical supply is
available, a 40-amp maximum circuit protection is
required, fused on both sides of the line. A separate
circuit is recommended. A time-delay fuse or circuit
breaker is recommended.
Ref. W10154991
06-24-08
Freestanding Range Slide-in Range
30"
(76.2 cm)
30"
(76.2 cm)
30-9/16"
(77.6 cm)
5-3/4"
(14.6 cm)
36" (91.4 cm)
cooktop trim
height with
levelinglegs
screwed all
the way in*
35-5/8" (90.5 cm)
height to underside
of cooktop edge
with levelinglegs
screwed all
the way in*
41-3/4"
(106 cm)
overall height
with leveling
legs screwed
all the way in*
Model/serial number
plate (located on the
right-hand side
oven door trim)
27-1/4"
(69.2 cm) max.
from handle to
standoff at
back of range**
27-1/4"
(69.2 cm) max.
from handle to
standoff at
back of range**
23" (58.4 cm)
countertop
notch to rear
of countertop
Model/serial
number plate
(located on the
right-hand side
oven door trim)
30"
(76.2 cm)
30 ¾"
(78.1 cm)
³⁄₈"
(1.0 cm)
*Range can be raised approximately 1"
(2.5 cm) by adjusting the leveling legs.
**When installed in a 24" (61 cm) base cabinet
with 25" (63.5 cm) countertop; front of oven
door protrudes 1" (2.5 cm) beyond 24"
(61 cm) base cabinet.
*Range can be raised approximately 1"
(2.5 cm) by adjusting the leveling legs.
**When installed in a 24" (61 cm) base cabinet
with 25" (63.5 cm) countertop; front of oven
door protrudes 1-3/4" (4.4 cm) beyond
24" (61 cm) base cabinet.
SLIDE-IN COUNTERTOP PREPARATION
INSTALLATION CLEARANCES
18" (45.7 cm)
upper cabinet
to countertop
18" (45.7 cm)
upper cabinet
to countertop
13" (33 cm) upper
cabinet depth
13" (33 cm) max.
upper cabinet depth
30" (76.2 cm) min.
openingwidth
30" (76.2 cm) min.
openingwidth
For minimum
clearance to top
of the cooktop,
see NOTE.
For minimum
clearance to top
of the cooktop,
see NOTE.
30" (76.2 cm)
min. opening
width
30" (76.2 cm)
min. opening
width
This shaded area
recommended for
installation of
rigid gas pipe.
This shaded area
recommended
for installation
of outlet or
junction box.
This shaded area
recommended
for installation
of outlet or
junction box.
Available
area for
gas and
electric
installation.
8"
(20.3 cm)
6"
(15.2 cm)
6"
(15.2 cm)
8"
(20.3 cm)
7" (17.8 cm)
7" (17.8 cm)
1-1/2"
(3.8 cm)
1-1/2"
(3.8 cm)
4-1/2"
(11.4 cm)
4-1/2"
(11.4 cm)
4-1/2"
(11.4 cm)
4-1/2"
(11.4 cm)
5" (12.7 cm) min.
clearance from
both sides of the
range to the side
wall or other
combustible
material.
5" (12.7 cm) min.
clearance from
both sides of the
range to the side
wall or other
combustible
material.
Cabinet door
or hinge
should not
extend into
the cutout.
Cabinet door
or hinge
should not
extend into
the cutout.
3/4" (1.9 cm)
radius both corners
22-15/16" (58.3 cm)
openingdepth
This shaded area
recommended for
installation of
rigid gas pipe. Available
area for
gas and
electric
installation.
segnaRnI-edilSsegnaRgnidnatseerF
NOTE:
24" (61 cm) minimum when bottom of
wood or metal cabinet is protected by
not less than 1/4" (0.64 cm) flame
retardant millboard covered with not
less than No. 28 MSG sheet steel,
0.015" (0.4 mm) stainless steel,
0.024" (0.6 mm) aluminum or 0.020"
(0.5 mm) copper.
30" (76.2 cm) minimum clearance
between the top of the cooking
platform and the bottom of an
unprotected wood or metal cabinet.
If installing a range hood or
microwave hood combination above
the range, follow the range hood or
microwave hood combination
installation instructions for
dimensional clearances above the
cooktop surface.
