OVEN PARTS
1
For Model: KDRP707RSS01
(Stainless Steel)
5−07 Litho in U.S.A. (cre) Part No. 8186471
30" KITCHENAID
FREE STANDING RANGE
DUAL FUEL STEAM

OVEN PARTS
2
For Model: KDRP707RSS01
(Stainless Steel)
8186471
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature Parts
9758978 Installation
Instructions
9763071 Use & Care Guide
9758979 Tech Sheet
9759441 Conversion
Instructions
3191638 Safer Cooking Tips
9759133 Safer Cooking Tips
9762575 Cook Book
2 4449809 Screw, 8−18 x 3/8
3 4449743 Screw, 8−32 X 3/8
4 9758595 Retainer, Gasket
5 9761101 Pump, Drain (120v)
(Includes Clamps)
6 4450118 Nut,(U−Type Clip)
7 9758832 Top, Chassis
8 4448520 Bumper, Door
9 4452158 Tube, Vent
10 4452163 Lens, Light
11 4448972 Oven Light Assy
4449748 Screw
12 4452164 Bulb, Light
13 Hinge Receiver
4455605 Left Hand
4455606 Right Hand
14 9762237 Frame, Front
15 4455382 Gasket, Door
16 4452152 Bracket, Mounting
17 4452260 Spacer, Foam
18 9758598 Boiler
19 4451478 Support, Insulation
20 9761145 Reservoir
(Includes Clamps)
21 4455510 Bracket, Support
22 9762243 Gasket, Sensor
23 9761107 Sensor, Level
24 9760889 Latch, Motorized
25 4455641 Side, Chassis
26 9758830 Back, Chassis
27 Liner, Oven
(Not serviceable)
29 4455636 Sensor
30 4449154 Screw, 8−32 x .440
31 4449040 Screw, 8−18 x 3/8
33 9758597 Orifice, Boiler
34 9758596 Cover, Orifice
Boiler
35 9762138 Hose, (Blue)
(Pump to Outlet)
36 9762139 Hose (Gray)
(Boiler to Pump)
37 4450249 Thermostat (TOD)
(150c) SPST
38 9761154 Hose (Green)
(Boil’r to Resv’r)
39 9761147 Clamp
40 9761146 Clamp
41 9762844 Screw
43 4455649 Base, Chassis
50 9758583 Cover, Back
56 4448982 Button, Plug
FOLLOWING PARTS
NOT ILLUSTRATED
INSULATION
4449316 Insulation, Wrap
4450365 Insulation, Back

OVEN DOOR PARTS
3
For Model: KDRP707RSS01
(Stainless Steel)
8186471
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 4455618 Door Liner
2 Hinge, Door
9760577 R.Side
9760578 L.Side
3 4449259 Glass, Inner
4 4451722 Insulation, Door
5 4457132 Retainer, Glass
7 4449263 Glass, Inner
8 4449743 Screw, 8−32 x 3/8
9 9759634 Retainer, Glass
11 9759635 Spacer, Glass
12 4452316 Assy, Door Glass
13 4455851 Door Handle
14 Bracket, Handle
4455803 Right Hand
4455804 Left Hand
15 8302092 Bracket(2nd Glass)
16 3400832 Screw, 8−18 x 3/8
19 4457103 Shield, Top Heat
20 4449809 Screw, 8−18 x 3/8
21 4452326 Seal, Door Top
22 4457114 Heat Shield (Btm)
24 3196184 Screw, 8−32 x .548
25 8302094 Bracket(3rd Glass)

INTERNAL OVEN PARTS
4
For Model: KDRP707RSS01
(Stainless Steel)
8186471
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
2 4456103 Element, Broil
3 4457277 Grill, Broiler
4 4457276 Pan, Broiler
5 3181534 Rack, Roasting
6 4452807 Rack, Oven
7 4452155 Element, Hidden
Bake
9 4451583 Motor, Convection
10 4452226 Blade, Fan
11 4448418 Cover, Fan
12 4452227 Nut
13 9762242 Element,
Convection
14 4455037 Tray, Hidden
Bake
15 4450039 Cover, Access
16 4449154 Screw, 8−32 x .440
17 4449809 Screw, 8−18 x 3/8

CONTROL PANEL PARTS
5
For Model: KDRP707RSS01
(Stainless Steel)
8186471
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 9758959 Panel, Control
(Inc.Nuts,Clamps)
2 4453000 Bracket, Display
3 9758961 Bracket, Display
Mounting
4 3196537 Screw, 8−18 x 3/8
5 9761103 Control, Zodiac
6 3196184 Screw, 6−19 x 1
7 4455806 Glass,
Control Panel
8 9758960 Module, Display
9 2004333 Palnut
10 2005292 Nameplate
11 9758967 Face, Control
Panel
12 4455192 Bezel, Knob
13 4454970 Knob, Control
14 4455115 Knob, Temp/Time
15 9758966 Knob, Selector
16 4457218 Switch, Cancel
4457278 Jumper
17 4452997 Switch, Enter
18 9758974 Button, Drain
19 9761600 Water, Inlet
(Inc.Nuts,Clamps)
20 9761146 Clamp
21 4457218 Switch, Cancel
(Drain Pump)
23 9761149 Hose(Red)W/Clamps
(Inlet to Resrv’r)
24 9761151 Hose(Clear)W/Clmps
(Inlet to Valve)
25 4452842 Switch, Oven Light
26 4457152 Bezel, Temp Knob
27 4159450 Screw
28 9762136 Fitting, Drain
(Includes Clamp)
29 9762671 Clamp

TOP VENTING PARTS
6
For Model: KDRP707RSS01
(Stainless Steel)
8186471
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 9758955 Vent, Exhaust
2 9758954 Vent−Top
3 9759837 Blower 60MM
4 9758953 Vent−Bottom
5 6610122 Transformer, Light
6 8300642 Transformer,
Control
7 4449809 Screw, 8−18 x 3/8
8 9758956 Bracket, Blower
9 9758999 Fuse−Thermo
105c 15a/120vac
11 4449868 Block, Terminal
14 4452442 Side, Control Top
24 9761155 Control, Taurus
(Appliance Mngr)
25 8302143 Suppressor
26 9758985 Control, Steam
27 4450800 Screw, 8−32 x 3/8

7
COOKTOP PARTS
For Model: KDRP707RSS01
(Stainless Steel)
8186471
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 9760697 Cooktop
2 4455849 Burner Head (4)
3 3368921 Screw, 7−18 x 3/4
4 4455243 Cap, Burner (4)
5 4456622 Orifice Holder (4)
(Incl.Orifice &
Ignitor)
3400843 Screw
6 3177991 Screw, 8−18 x 1/4
7 4457331 Grate, Burner (2)
8 4457150 Grate, Filler
9 4454961 Trim, Island
10 4455031 Support,
Backsplash
11 4454959 Trim, Backsplash
12 3400837 Screw, 8−18 x 3/8
13 9782116 Ignitor
15 4455109 Plate, Simmer

8
BURNER BOX AND MANIFOLD PARTS
For Model: KDRP707RSS01
(Stainless Steel)
8186471
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 4457272 Tubing, Gas
Burner − RF
2 4457273 Tubing, Gas
Burner − RR
3 4457274 Tubing, Gas
Burner − LF
4 4457275 Tubing, Gas
Burner − LR
6 3400843 Screw, 8−18 x 3/8
7 4457267 Manifold
8 4456818 Valve, Burner (4)
9 3186217 Bolt,Gas Valve (4)
10 4457173 Burner Switch &
Harness Assembly
11 9759091 Pressure Regulator
12 9762134 Box, Burner
13 3192439 Seal, Switch
14 4449809 Screw, 8−18 x 3/8
15 Side, Burner Box
8285607 Right Side
8285606 Left Side
16 4457315 Support, Rear
17 9758986 Support, Cooktop
18 3192811 Bracket, Burner
19 3177991 Screw, 8−18 x 1/4
20 9758964 Bracket, Valve
21 4455645 Tube, Manifold
22 9762133 Cover, Manifold
23 Adaptr,Compression
4453116 1/2" Male
4453115 1/2" Female
24 4453036 Cover, Burner
Box
25 8522426 Module, Spark
26 9761102 Valve, Overflow
27 3196184 Screw, 8−32
28 9761150 Hose (White)
(Valve to Resrv’r)
29 9761147 Clamp
30 3191387 Seal, Switch
31 4453191 Seal, Panel

9
CHASSIS PARTS
For Model: KDRP707RSS01
(Stainless Steel)
8186471
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 4452802 Vent, Bottom
Lower
2 4449809 Screw, 8−18 x 3/8
5 4452800 Deflector, Center
7 9761913 Vent, Center
4453323 Gasket
3400805 Screw (4)
8 3196537 Screw, 8−18 x 3/8
9 9759092 Bracket, Mounting
Regulator
10 9759117 Foot
11 3400518 Screw,
5/16−12 x 5/8
12 4455644 Gusset
13 4455643 Support, Channel
14
W10015710 Brace, Rear
15 Trim, Front
4452804 Right Side
4453205 Left Side
16 3196537 Screw, 8−18 x 3/8
17 Side Chassis
9761934 Right Side
9761933 Left Side
18 9759118 Plate
19 9762142 Tray, Drip
20 3400805 Screw, 8−18 x 3/8

OPTIONAL PARTS
10
For Model: KDRP707RSS01
(Stainless Steel)
8186471
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
ADHESIVE
591014 Adhesive
Loctite (1/3 oz.)
482338 Sealer, Silastic
(3 oz.)
4453192 Seal, Ribbon
Cable
4453191 Seal, Access
Panel
SPLICING WIRES−−25FT.
LENGTH
242828 Wire (12 Ga.
150 c Black)
242820 Wire (14 Ga.
150 c Black)
242821 Wire (14 Ga.
150 c Blue)
242822 Wire (14 Ga.
150 c Brown)
242830 Wire (14 Ga.
200 c Brown)
242823 Wire (14 Ga.
150 c Green)
242824 Wire (14 Ga.
150 c Orange)
242829 Wire (12 Ga.
150 c Red)
242825 Wire (14 Ga.
150 c Red)
242831 Wire (14 Ga.
200 c Red)
242826 Wire (14 Ga.
150 c White)
242827 Wire (14 Ga.
150 c Yellow)
242832 Wire (14 Ga.
200 c Yellow)
WIRING HARNESS PARTS
9763620 Harness, Sensor
9758951 Harness, Wire
(Main)
3196896 Clip, Wire
4456549 Harness, Wire
(Spark Module)
4456628 Harness, Wire
(Ignitor 39")
4456627 Harness, Wire
(Ignitor 28")
4456626 Harness, Wire
(Ignitor 15")
9761098 Harness, Signal
3191506 Bushing, Conduit
1129449 Bushing
8301668 Conduit
4449809 Screw
112432 Nut
4450800 Screw, Ground
Miscellaneous
8301282 Conv. Kit (LP)
4453141 Bracket,
Anti−Tip (1")
4453202 Bracket,
Anti−Tip (1 3/4")
4396920 S.Steel Cleaner
