KitchenAid Architect Series II KSSC36QTS User instructions

Side by Side Refrigerator
PRODUCT MODEL NUMBERS PRODUCT DIMENSIONS
CABINET OPENING DIMENSIONS
Electrical: A 115 Volt, 60 Hz., AC only 15- or 20-
amp fused, grounded electrical supply is required.
It is recommended that a separate circuit serving
only your refrigerator be provided. Use an outlet
that cannot be turned off by a switch. Do not use
an extension cord.
Water Supply: A cold water supply with water
pressure of between 30 and 120 psi (207 and
827 kPa) is required to operate the water dispenser
and ice maker. If you have questions about your
water pressure, call a licensed, qualified plumber.
If a reverse osmosis water filtration system is
connected to your cold water supply, the water
pressure to the reverse osmosis system needs to
be a minimum of 40 to 60 psi (276 to 414 kPa).
Do not install the refrigerator near an oven, radiator,
or other heat source, nor in a location where the
temperature will fall below 55°F (13°C).
Because Whirlpool Corporation policy includes a continuous commitment to improve
our products, we reserve the right to change materials and specifications without notice. Dimensions are for planning purposes only. For complete details, see Installation Instructions packed with product. Specifications subject to change without notice. Ref. W10379133
4/04/11
KSSC36FT
KSSC36QT
KSSC42FT
KSSC42QT
KSSC42QV
KSSC48FT
KSSC48QT
KSSC48QV
KSSO36FT
KSSO36QT
KSSO42FT
KSSO42QT
KSSO48FT
KSSO48QT
KSSS36FT
KSSS36QT
KSSS42FT
KSSS42QT
KSSS48FT
KSSS48QT
NOTE:Flooring under refrigerator must be at same level as
the room. Face of cabinetry must be plumb.
Model Width A (as shown above)
36
42
48
35¹⁄₂" (90.2 cm) to 35³⁄₄"(90.8 cm)
41¹⁄₂" (105.4 cm) to 41³⁄₄" (106.1 cm)
47¹⁄₂" (120.7 cm) to 47³⁄₄" (121.3 cm)
80" - 90"
(203-229 cm) 4"
6"
83¹⁄₂" (212.1 cm) min.
84³⁄₄" (215 cm) max.
to bottom of solid soffit
24"
(60.96 cm) min.
1"
(2.54 cm)
77"
(196 cm)
6"
(15.2 cm)
6"
(15.2 cm)
A
Width
(see chart following)
(10.2 cm)
(15.2 cm)
*When leveling legs are fully extended to
1¹⁄₄" (3.2 cm) below rollers, add 1¹⁄₈" (2.9 cm)
to the height dimensions.
Model Width A
36
42
48
35" (88.9 cm)
41" (104.1 cm)
47" (119.4 cm)
25³⁄₈"
(64.5 cm)
23¹⁄₂"
(59.7 cm)
84" (213.4 cm)
Power Cord
*83³⁄₈"
(211.8 cm)
*3¹⁄₂" (8.9 cm)
25³⁄₈"
(64.5 cm)
A
Model Width A (Trim edge to trim edge)
36
42
48
36¹⁄₄" (92.1 cm)
42¹⁄₄" (107.3 cm)
48¹⁄₄" (122.6 cm)
*83³⁄₈"
(211.8 cm)
A
(see chart following)
■Height dimensions are shown with the
leveling legs extended to 1/8" (3 mm)
below the rollers.
■The power cord is 84" (213 cm) long.
■The water line attached to the back of
the refrigerator is 5' (1.5 m) long.
DOOR SWING DIMENSIONS
TOP VIEW
FRONT VIEW
SIDE VIEW
36" (91.4 cm) Models
130˚
130˚
90˚
90˚
110˚
110˚
44³⁄₈"
(112.7 cm)
39"
(99.1 cm)
14³⁄₈"
(36.5 cm)
10⁷⁄₈"
(27.6 cm)
35¹⁄₂"
(90.2 cm)
38⁷⁄₈"
(
98.7 cm)
42" (106.7 cm) Models
48" (121.9 cm) Models
130˚
130˚
90˚
90˚
110˚
110˚
47⁷⁄₈"
(121.6 cm)
41¹⁄₂"
(105.4 cm)
16⁷⁄₈"
(42.9 cm)
12⁵⁄₈"
(32.1 cm)
37¹⁄₄"
(94.6 cm)
41³⁄₈"
(105.1 cm)
130˚
130˚
90˚
90˚
110˚
110˚
51³⁄₈"
(130.5 cm)
44"
19¹⁄₄"
(48.9 cm)
14³⁄₈"
(36.5 cm)
39"
(99.1 cm)
43⁷⁄₈"
(
111.4 cm)
(111.8 cm)
