KitchenAid KBCO24LS - 24 in. Undercounter Wine Cellar User manual

BEVERAGE CENTER
OVERLAY MODEL
Use & Care Guide
For questions about features, operation/performance, parts, accessories, or service, call: 1-800-422-1230 or visit our website at...
www.kitchenaid.com
In Canada, call: 1-800-807-6777, or visit our website at...
www.KitchenAid.ca
REFRIGERADOR PARA BEBIDAS
MODELO RECUBIERTO
Manual de uso y cuidado
Para consultas respecto a características, operación/desempeño, partes, accesorios o servicio, llame al: 1-800-422-1230
o visite nuestra página de internet...
www.kitchenaid.com
En Canadá, llame al: 1-800-807-6777 o visite nuestra página de internet...
www.KitchenAid.ca
RÉFRIGÉRATEUR POUR BOISSONS
MODÈLE OVERLAY
Guide d’utilisation et d’entretien
Au Canada, pour assistance, installation ou service, composez le 1-800-807-6777 ou visitez notre site web à...
www.KitchenAid.ca
Table of Contents/Índice/Table des matières..................................................................2
2300277C / 8336411962300

2
TABLE OF CONTENTS
BEVERAGE CENTER SAFETY ................................................................... 3
Proper Disposal of Your Old
Refrigerated Appliance ............................................................................. 3
INSTALLATION INSTRUCTIONS ............................................................... 4
Tools and Parts......................................................................................... 4
Custom Overlay Frame............................................................................. 4
Location Requirements............................................................................. 5
Electrical Requirements............................................................................ 5
Unpack the Beverage Center ................................................................... 5
Install Custom Overlay Frame .................................................................. 6
Door Closing ............................................................................................. 7
Base Grille................................................................................................. 8
BEVERAGE CENTER USE .......................................................................... 8
Normal Sounds ......................................................................................... 8
Using the Control...................................................................................... 8
Beverage/Wine Racks .............................................................................. 9
Stocking the Beverage Center ................................................................. 9
Lighting the Beverage Center................................................................... 9
BEVERAGE CENTER CARE ..................................................................... 10
Cleaning.................................................................................................. 10
Changing the Light Bulb......................................................................... 10
Vacation and Moving Care ..................................................................... 10
TROUBLESHOOTING ............................................................................... 11
ASSISTANCE OR SERVICE...................................................................... 12
In the U.S.A............................................................................................. 12
In Canada................................................................................................ 12
Accessories............................................................................................. 12
WARRANTY ............................................................................................... 13
ÍNDICE
SEGURIDAD DEL REFRIGERADOR PARA BEBIDAS............................14
Cómo deshacerse adecuadamente de su aparato refrigerado viejo .... 14
INSTRUCCIONES DE INSTALACIÓN......................................................15
Piezas y herramientas.............................................................................15
Marco recubierto a la medida.................................................................15
Requisitos de ubicación .........................................................................16
Requisitos eléctricos...............................................................................16
Desempaque del refrigerador para bebidas ..........................................17
Cómo instalar el marco recubierto a la medida .....................................17
Cómo cerrar la puerta.............................................................................19
Rejilla de la base .....................................................................................19
USO DEL REFRIGERADOR PARA BEBIDAS..........................................19
Sonidos normales ...................................................................................19
Uso del control........................................................................................20
Portabebidas/portabotellas.................................................................... 20
Cómo almacenar en el refrigerador para bebidas ................................. 21
Cómo iluminar el refrigerador para bebidas .......................................... 21
CUIDADO DEL REFRIGERADOR PARA BEBIDAS................................ 21
Limpieza.................................................................................................. 21
Cómo cambiar el foco ............................................................................ 22
Cuidado durante las vacaciones y mudanzas ....................................... 22
SOLUCIÓN DE PROBLEMAS................................................................... 23
AYUDA O SERVICIO TÉCNICO................................................................ 24
En los EE.UU........................................................................................... 24
En Canadá .............................................................................................. 24
Accesorios .............................................................................................. 24
GARANTÍA ................................................................................................. 25
TABLE DES MATIÈRES
SÉCURITÉ DU RÉFRIGÉRATEUR POUR BOISSONS ...........................27
Mise au rebut de votre vieil appareil réfrigéré ........................................27
INSTRUCTIONS D’INSTALLATION .........................................................28
Outillage et pièces ..................................................................................28
Cadre décoratif personnalisé .................................................................28
Exigences d'emplacement .....................................................................29
Spécifications électriques.......................................................................29
Déballage du réfrigérateur pour boissons..............................................30
Installation du cadre décoratif personnalisé ..........................................30
Fermeture de la porte .............................................................................32
Grille de la base ......................................................................................32
UTILISATION DU RÉFRIGÉRATEUR POUR BOISSONS.......................32
Sons normaux.........................................................................................32
Utilisation de la commande....................................................................33
Grilles pour le remisage des boissons et du vin .................................... 33
Stockage dans le réfrigérateur pour boissons ....................................... 34
Éclairage du réfrigérateur pour boissons............................................... 34
ENTRETIEN DU RÉFRIGÉRATEUR POUR BOISSONS......................... 34
Nettoyage ............................................................................................... 34
Changement de l'ampoule d'éclairage .................................................. 35
Précautions à prendre pour les vacances et
avant un déménagement........................................................................ 35
DÉPANNAGE ............................................................................................. 36
ASSISTANCE OU SERVICE...................................................................... 37
Aux États-Unis........................................................................................ 37
Au Canada .............................................................................................. 37
Accessoires............................................................................................. 37
GARANTIE.................................................................................................. 38

3
BEVERAGE CENTER SAFETY
Proper Disposal of Your Old
Refrigerated Appliance
IMPORTANT: Child entrapment and suffocation are not problems
of the past. Junked or abandoned beverage centers are still
dangerous – even if they will sit for “just a few days.” If you are
getting rid of your old beverage center, please follow these
instructions to help prevent accidents.
Before You Throw Away Your Old Refrigerated Appliance:
■Take off the door.
■Leave the racks and shelves in place so that children may not
easily climb inside.
You can be killed or seriously injured if you don't immediately
You can be killed or seriously injured if you don't follow
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”
These words mean:
follow instructions.
instructions.
DANGER
WARNING
IMPORTANT SAFETY INSTRUCTIONS
WARNING:
To reduce the risk of fire, electric shock, or injury when using your beverage center, follow these basic
SAVE THESE INSTRUCTIONS
■ Plug into a grounded 3 prong outlet.
■ Do not remove ground prong.
■ Do not use an adapter.
■ Do not use an extension cord.
■ Disconnect power before servicing.
■ Replace all parts and panels before operating.
■ Remove door or drawer(s) from your old refrigerated
appliance.
■ Use nonflammable cleaner.
■ Keep flammable materials and vapors, such as gasoline,
away from beverage center.
■ Use two or more people to move and install beverage
center.
precautions:
WARNING
Suffocation Hazard
Remove door or drawer(s) from your old refrigerated
appliance.
Failure to do so can result in death or brain damage.

4
INSTALLATION INSTRUCTIONS
Tools and Parts
TOOLS NEEDED:
Gather the required tools and parts before starting installation.
Read and follow the instructions provided with any tools listed
here.
PARTS NEEDED:
Custom Overlay Frame—See “Overlay Frame—Rear View.”
Hardware (Optional)
PARTS SUPPLIED:
Custom Overlay Frame
If you plan to install a custom overlay frame, you will need to
create the frame yourself or consult a qualified cabinetmaker or
carpenter. See dimension drawings for frame specifications.
IMPORTANT:
■The thickness of the overlay frame must be ³⁄₄" (1.91 cm).
■Overlay frame must not weigh more than 10 lbs (4.54 kg).
■Overlay frames weighing more than recommended may
cause damage to your appliance.
Overlay Frame Dimensions—Rear View
Create the custom overlay frame using the dimensions shown.
Install Overlay Hooks
Using a Phillips screwdriver and eight flat-head screws, attach the
overlay hooks to the back of the overlay frame. See “Overlay
Frame–Rear View” for overlay hook locations.
Door Hinge Holes
■The views of the top and bottom hinge pin hole show a right-
hand hinge. Mirror the image for a left-hand hinge.
■We recommend using a C-clamp and two pieces of scrap
wood (front and back) to help reinforce the overlay frame
when drilling the hinge pin holes.
1. Using a ¹⁄₂" Brad point doweling drill bit, drill a ¹⁄₂" (1.27 cm)
deep hole into the top of the overlay frame for the top hinge
pin as shown.
Top View
■Hand drill or electric drill
(properly grounded)
■¹⁄₂" Brad point doweling
drill bit
■Phillips screwdriver
■Scissors
■Masking tape
■Tape measure
■Petroleum jelly
■Flat-head screws (8)
■Round-head screws (8)
■Overlay plates (2)
■Overlay hooks (4)
A. Overlay hook locations
2 ¹⁵⁄₁₆ "
(7.5 cm)
3 ³⁄₄ "
(9.53 cm)
1 ⁵⁄₁₆ "
(3.33 cm)
1
⁵⁄₁₆ "
(3.33 cm)
4 ¹³⁄₃₂ "
(11.2 cm)
2 ¹⁄₂ "
(6.4 cm)
A
23 ³⁄₄ "
(60.33 cm)
29
⁷⁄₈ "
(75.88 cm)
A. Overlay hooks (4)
A. Radius 5.0
A
¹⁄₂"
(1.2 cm)
¹⁷⁄₃₂"
(1.35 mm)
A
Back Surface
Front Surface

5
2. Drill a ¹⁄₂" (1.27 cm) deep hole in the bottom of the overlay
frame for the bottom hinge pin as shown.
Bottom View
Location Requirements
To ensure proper ventilation for your beverage center, allow for a
¹⁄₄" (6.35 mm) space on each side and at the top. When installing
your beverage center next to a fixed wall, leave 2¹⁄₂" (6.35 cm)
minimum clearance on the hinge side to allow for the door to
swing open.
NOTE: It is recommended that you do not install the beverage
center near an oven, radiator, or other heat source. Do not install
in a location where the temperature will fall below 55°F (13°C). For
best performance, do not install the beverage center behind a
cabinet door or block the base grille.
Electrical Requirements
Before you move your beverage center into its final location, it is
important to make sure you have the proper electrical connection.
Recommended grounding method
A 115 Volt, 60 Hz., AC only, 15– or 20–amp fused, grounded
electrical supply is required. It is recommended that a separate
circuit serving only your beverage center be provided. Use an
outlet that cannot be turned off by a switch. Do not use an
extension cord.
NOTE: Before performing any type of installation, cleaning, or
removing a light bulb, unplug beverage center or disconnect
power.
Unpack the Beverage Center
Remove the Packaging
■Remove tape and glue residue from surfaces before turning
on the beverage center. Rub a small amount of liquid dish
soap over the adhesive with your fingers. Wipe with warm
water and dry.
■Do not use sharp instruments, rubbing alcohol, flammable
fluids, or abrasive cleaners to remove tape or glue. These
products can damage the surface of your beverage center.
For more information, see “Beverage Center Safety.”
■Dispose of/recycle all packaging materials.
A. Radius 5.0
¹⁄₂"
(1.2 cm)
¹⁷⁄₃₂"
(1.35 mm)
A
Front Surface
Back Surface
WARNING
Explosion Hazard
Keep flammable materials and vapors, such as
gasoline, away from beverage center.
Failure to do so can result in death, explosion, or fire.
2¹⁄₂" (6.35 cm)
¹⁄₄" (6.35 mm)
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING
WARNING
Excessive Weight Hazard
Use two or more people to move and install
beverage center.
Failure to do so can result in back or other injury.
When MovingYour Beverage Center:
Your beverage center is heavy. When moving the appliance
for cleaning and service, be sure to cover the floor with
cardboard or hardboard to avoid floor damage. Always pull
the appliance straight out when moving it. Do not wiggle or
“walk” the appliance when trying to move it, as floor
damage could occur.

6
Clean Before Using
After you remove all of the packaging materials, clean the inside of
your beverage center before using it. See the cleaning instructions
in “Beverage Center Care.”
Install Custom Overlay Frame
IMPORTANT:
■Create custom overlay frame according to the specifications
in the “Custom Overlay Frame” section.
■KitchenAid is not responsible for the removal or addition of
molding or decorative panels that would not allow access to
the appliance for service.
Remove the Door
IMPORTANT: Do not remove the grease from the washer, top
spacer or top hinge pin. Be sure to set aside the top hinge, top
spacer and washer for later use.
1. Using a Phillips screwdriver, remove the three screws from the
top hinge. Remove the top hinge.
2. Remove the three screws from the top spacer. Remove the
top spacer and washer.
3. Open the door. Lift the front of the door up, pulling straight out
to remove as shown.
Attach the Overlay Frame
NOTE: If the overlay hooks are not installed, see “Custom Overlay
Frame” for overlay hook locations.
1. Position the overlay frame ¹⁄₂" (1.27 cm) higher than the door.
Be sure to position the overlay hooks to the pilot holes.
2. Insert the overlay hooks into the top of the holes in the door.
Push against the overlay frame to force the overlay hooks
deeper into the door. Pull the overlay frame straight down to
secure the overlay hooks to the door.
3. Using a Phillips screwdriver, attach the overlay plates to the
bottom of the overlay frame and door as shown.
A. Screws (3)
B. Top hinge
C. Washer
D. Top spacer
E. Door
Important information to know about glass shelves
and covers:
Do not clean glass shelves or covers with warm water when
they are cold. Shelves and covers may break if exposed to
sudden temperature changes or impact, such as bumping.
Tempered glass is designed to shatter into many small,
pebble-size pieces. This is normal. Glass shelves and covers
are heavy. Use both hands when removing them to avoid
dropping.
C
D
E
A
B
A. Overlay frame
B. Door
C. Overlay plates (2)
D. Round-head screws (8)
ACDB

7
Install the Door
IMPORTANT: To ensure proper operation, be sure to grease the
top hinge, top spacer and washer with petroleum jelly.
1. Using a Phillips screwdriver and three screws, attach the top
spacer to the door.
2. Using petroleum jelly, grease the bottom spacer hole and the
bottom hinge pin. Align the washer with the bottom spacer
hole.
3. Slowly lower the door straight and evenly onto the bottom
hinge pin. Be sure the washer stays in place. Close the door.
Be sure the door properly aligns to the cabinet.
NOTE: Provide additional support for the door when moving
the hinges. Do not depend on the door magnets to hold the
door in place while you are working.
4. Using masking tape, secure the door to the cabinet before
installing the top spacer as shown.
5. Place the washer on the top spacer and align the holes.
Grease the top hinge pin, top spacer and washer with
petroleum jelly. Insert the top hinge pin into the washer and
top spacer.
6. Using a Phillips screwdriver and three screws, attach the top
hinge to the cabinet as shown.
7. Remove the masking tape from the door.
Door Closing
Door Closing
Your beverage center has four leveling legs. If your beverage
center seems unsteady or you want the door to close more easily,
adjust the beverage center’s tilt using the instructions below.
1. Plug into a grounded 3 prong outlet.
2. Move the beverage center into its final location.
3. Turn the leveling legs to the right to lower the beverage center
or turn the leveling legs to the left to raise it. It may take
several turns of the leveling legs to adjust the tilt of the
beverage center.
NOTE: Having someone push against the top of the beverage
center takes some weight off the leveling legs. This makes it
easier to adjust the leveling legs.
4. Make sure that the door closes as easily as you like. If not, tilt
the beverage center slightly more to the rear by turning both
front leveling screws to the left. It may take several more turns,
and you should turn both leveling legs the same amount.
A. Top spacer
B. Masking tape
A. Screws (3)
B. Top hinge
C. Washer
D. Top spacer
E. Door
F. Overlay frame
A
B
C
D
E
A
B
F
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING
WARNING
Excessive Weight Hazard
Use two or more people to move and install
beverage center.
Failure to do so can result in back or other injury.

8
Base Grille
Tools Needed: Phillips screwdriver
Remove the Base Grille
1. Open the beverage center door.
2. Using a Phillips screwdriver, remove the two screws. Push
both tabs in toward the center to release the base grille from
the beverage center.
3. Remove the base grille.
Replace the Base Grille
1. Open the beverage center door.
2. Position the base grille so that both tabs align and the base
grille snaps into place. Replace the two screws. Tighten the
screws.
BEVERAGE CENTER USE
Normal Sounds
Your new beverage center may make sounds that your old one
didn’t make. Because the sounds are new to you, you might be
concerned about them. Most of the new sounds are normal. Hard
surfaces, such as the flooring and surrounding structures, can
make the sounds seem louder. The following describes the kinds
of sounds and what may be making them.
■Your beverage center is designed to run more efficiently to
keep your food items at the desired temperatures and to
minimize energy usage. The high efficiency compressor and
fans may cause your beverage center to run longer than your
old one. You may also hear a pulsating or high-pitched sound
from the compressor or fans adjusting to optimize
performance.
■Rattling noises may come from the flow of refrigerant or items
stored inside the beverage center.
■As each cycle ends, you may hear a gurgling sound due to the
refrigerant flowing in your beverage center.
■You may hear water running into the drain pan when the
beverage center is defrosting.
■You may hear clicking sounds when the beverage center
starts or stops running.
Using the Control
For your convenience, your beverage center control is preset at
the factory. When you first install your beverage center, make sure
that the control is still preset to the mid-setting as shown.
Adjusting Controls
The mid-setting indicated in the previous section should be
correct for normal usage. The control is set correctly when
beverages are as cold as you like.
If you need to adjust the temperature, wait at least 24 hours
between adjustments and then recheck the temperature.
To make the beverage center colder, adjust the control to the next
higher setting. To make the beverage center less cold, adjust the
control to the next lower setting.
Temperature Separator (Temperature Display)
The temperature separator displays the current temperatures
(Fahrenheit or Celsius) for the upper, middle and lower zones
(compartments) of the beverage center. To adjust the temperature
settings, see “Adjusting Controls” earlier in this section.
A. Tabs
B. Screws
BAA
A. Dimmer
B. Upper zone display
C. Middle zone display
D. Lower zone display
E. Fahrenheit/Celsius
Dimmer Upper Middle Lower
AB C DE
F

9
Beverage/Wine Racks
To Remove and Replace the Racks
1. Pull the rack forward until it stops. Push in on the tabs to
release the rack. Continue pulling the rack forward and lift it
up and out of the rack supports.
2. Replace the rack by inserting the rack into the supports and
sliding it toward the rear of the beverage center.
To Remove and Replace the Bottom Rack
1. Lift the rack (front and back) up and pull straight out to
remove.
2. Replace the rack by pushing it straight back and over the
stop. Continue pushing the rack straight back and evenly until
it is in place.
Stocking the Beverage Center
NOTE: For optimum beverage and wine storage, place white
wines at the top of the beverage center in the wine rack. Place red
wines at the bottom.
To Stock the Beverage Center
1. Start stocking the beverage center with the bottom display
rack.
2. Starting on the left-hand side, place the first bottle of wine on
the bottom of the rack with the neck of the bottle facing the
back of the beverage center.
3. Place the next bottle on its side with the neck of the bottle
facing the front of the beverage center.
4. Alternate in this manner until the display rack is full.
5. Pull the next rack forward.
6. Starting on the left-hand side, place the first bottle on the rack
with the neck of the bottle facing forward.
7. Place the next bottle on the shelf with the neck of the bottle
facing the rear of the beverage center.
8. Continue alternating in this manner until the rack is full.
9. Slide the rack into place and continue stocking each
remaining rack as described above.
10. Place juices, sodas or other canned beverages on the glass
shelves.
Lighting the Beverage Center
The beverage center has an interior light that comes on anytime
the door is opened. You may also turn the light on at any time by
opening the door and pressing the exterior switch located beside
the temperature control knob on the base grille.
NOTE: Leaving the light on for an extended period of time will
slightly increase the temperature of the beverage center.
A. Tabs
A
A

10
BEVERAGE CENTER CARE
Cleaning
Clean the beverage center about once a month to avoid buildup
of odors. Wipe up spills immediately.
To clean your beverage center:
1. Unplug beverage center or disconnect power.
2. Remove all racks and shelves from inside the beverage center.
3. Hand wash, rinse, and dry removable parts and interior
surfaces thoroughly. Use a clean sponge or soft cloth and a
mild detergent in warm water.
■To avoid damaging wood trim pieces, do not immerse the
entire rack into water when cleaning.
■Do not use abrasive or harsh cleaners such as window
sprays, scouring cleansers, flammable fluids, cleaning
waxes, concentrated detergents, bleaches or cleansers
containing petroleum products on plastic parts, interior
and door liners or gaskets. Do not use paper towels,
scouring pads, or other harsh cleaning tools. These can
scratch or damage materials.
■To help remove odors, you can wash interior walls with a
mixture of warm water and baking soda (2 tbs to 1 qt
[26 g to 0.95 L] of water).
4. Wash stainless steel and painted metal exteriors with a clean
sponge or soft cloth and a mild detergent in warm water. Do
not use abrasive or harsh cleaners, or cleaners containing
chlorine. These can scratch or damage materials. Dry
thoroughly with a soft cloth.
NOTE: To keep your stainless steel beverage center looking
like new and to remove minor scuffs or marks, it is suggested
that you use the manufacturer’s approved Stainless Steel
Cleaner and Polish. To order the cleaner, see “Accessories.”
IMPORTANT: This cleaner is for stainless steel parts only!
Do not allow the Stainless Steel Cleaner and Polish to come
into contact with any plastic parts such as the trim pieces,
dispenser covers or door gaskets. If unintentional contact
does occur, clean plastic part with a sponge and mild
detergent in warm water. Dry thoroughly with a soft cloth.
5. Replace the racks and shelves.
6. Clean the condenser coils regularly. They are located behind
the base grille. Coils may need to be cleaned as often as every
other month. This may help save energy.
■Remove the base grille. See “Base Grille.”
■Use a vacuum cleaner with an extended attachment to
clean the condenser coils when they are dusty or dirty.
■Replace the base grille.
7. Plug in beverage center or reconnect power.
Changing the Light Bulb
NOTE: Not all appliance bulbs will fit your beverage center. Be
sure to replace the bulb with one of the same size, shape, and
wattage.
To change the light bulb:
1. Unplug beverage center or disconnect power.
2. Using a Phillips screwdriver, remove the screw located at the
back of the light shield. Pull the light shield back to remove the
tabs from the appliance. Remove the light shield.
3. Replace the bulb.
4. Reinstall the light shield by inserting the tabs. Align the holes
and insert the screw. Tighten the screw.
5. Plug in beverage center or reconnect power.
Vacation and Moving Care
Vacations
If you choose to turn the beverage center off before you leave,
follow these steps.
1. Remove all wine bottles from the beverage center.
2. Unplug the beverage center.
3. Clean the beverage center. See “Cleaning.”
4. Tape a rubber or wood block to the top of the door to prop it
open far enough for air to get in. This stops odor and mold
from building up.
Moving
When you are moving your beverage center to a new home, follow
these steps to prepare it for the move.
1. Remove all wine bottles from the beverage center.
2. Unplug the beverage center.
3. Clean, wipe, and dry it thoroughly.
4. Take out all removable parts, wrap them well, and tape them
together so they don’t shift and rattle during the move.
5. Tape the doors shut and tape the power cord to the beverage
center.
When you get to your new home, put everything back and refer to
the “Installation Instructions” section for preparation instructions.
WARNING
Explosion Hazard
Use nonflammable cleaner.
Failure to do so can result in death, explosion, or fire.
A. Light shield
B. Tabs
C. Screw
A
B
C

11
TROUBLESHOOTING
Try the solutions suggested here first in order to avoid the cost of an unnecessary service call.
Your beverage center will not operate
■Is the power supply cord unplugged? Plug into a grounded
3 prong outlet.
■Has a household fuse blown, or has a circuit breaker
tripped? Replace the fuse or reset the circuit.
■Is the Beverage Center Control turned to the OFF
position? See “Using the Control.”
The lights do not work
■Is a light bulb loose in the socket? Unplug beverage center
or disconnect power. Gently remove the bulb and reinsert.
Plug in beverage center or reconnect power.
■Has a light bulb burned out? Replace with an appliance bulb
of the same wattage, size, and shape. See “Changing the
Light Bulb.”
The motor seems to run too much
■Is the temperature outside hotter than normal? Expect the
motor to run longer under warm conditions. At normal
temperatures, expect your motor to run about 40% to 80% of
the time. Under warmer conditions, expect it to run even more
of the time.
■Is the door opened often? Expect the motor to run longer
when this occurs. In order to conserve energy, try to get
everything you need out of the beverage center at once, keep
wine bottles positioned label side up so that they are easy to
find, and close the door as soon as the wine is removed.
■Is the control set correctly for the surrounding conditions?
See “Using the Control.”
■Is the door closed completely? Push the door firmly shut. If
it will not shut all the way, see “The door will not close
completely” later in this section.
■Are the condenser coils dirty? This obstructs air transfer and
makes the motor work harder. Clean the condenser coils. See
“Cleaning.”
Temperature is too warm
■Is the door opened often? Be aware that the beverage
center will warm when this occurs. In order to keep the
beverage center cool, try to get everything you need out of the
beverage center at once, keep wine bottles positioned label
side up so that they are easy to find, and close the door as
soon as the wine is removed.
■Is the control set correctly for the surrounding conditions?
See “Using the Control.”
■Is the base grille blocked? For best performance, do not
install the beverage center behind a cabinet door or block the
base grille.
There is interior moisture buildup
■Is the door opened often? To avoid humidity buildup, try to
get everything you need out of the beverage center at once,
keep wine bottles positioned label side up so that they are
easy to find, and close the door as soon as the wine is
removed. When the door is opened, humidity from the room
air enters the beverage center. The more often the door is
opened, the faster humidity builds up, especially when the
room itself is very humid.
■Is it humid? It is normal for moisture to build up inside the
beverage center when the air is humid.
■Is the control set correctly for the surrounding conditions?
See “Using the Control.”
The door is difficult to open
■Is the gasket dirty or sticky? Clean the gasket and the
surface that it touches. Rub a thin coat of paraffin wax on the
gasket following cleaning.
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING
WARNING
Explosion Hazard
Use nonflammable cleaner.
Failure to do so can result in death, explosion, or fire.

12
The door will not close completely
■Are the racks or shelves out of position? Put the racks or
shelves back into their correct positions. See “Beverage
Center Use” for more information.
■Is the gasket sticking? Clean the gasket and the surface that
it touches. Rub a thin coat of paraffin wax on the gasket
following cleaning.
ASSISTANCE OR SERVICE
Before calling for assistance or service, please check
“Troubleshooting.” It may save you the cost of a service call. If you
still need help, follow the instructions below.
When calling, please know the purchase date and the complete
model and serial number of your appliance. This information will
help us to better respond to your request.
If you need replacement parts
If you need to order replacement parts, we recommend that you
only use factory specified replacement parts. Factory specified
replacement parts will fit right and work right because they are
made with the same precision used to build every new
KITCHENAID®appliance.
To locate factory specified replacement parts in your area, call us
or your nearest designated service center.
In the U.S.A.
Call the KitchenAid Customer eXperience Center
toll free: 1-800-422-1230.
Our consultants provide assistance with:
■Features and specifications on our full line of appliances.
■Installation information.
■Use and maintenance procedures.
■Accessory and repair parts sales.
■Specialized customer assistance (Spanish speaking, hearing
impaired, limited vision, etc.).
■Referrals to local dealers, repair parts distributors, and service
companies. KitchenAid designated service technicians are
trained to fulfill the product warranty and provide after-
warranty service, anywhere in the United States.
To locate the KitchenAid designated service company in your
area, you can also look in your telephone directory Yellow Pages.
For further assistance
If you need further assistance, you can write to KitchenAid with
any questions or concerns at:
KitchenAid Brand Home Appliances
Customer eXperience Center
553 Benson Road
Benton Harbor, MI 49022-2692
Please include a daytime phone number in your correspondence.
In Canada
Call the KitchenAid Canada Customer eXperience Centre toll free:
1-800-807-6777.
Our consultants provide assistance with:
■Features and specifications on our full line of appliances.
■Use and maintenance procedures.
■Accessory and repair parts sales.
■Referrals to local dealers, repair parts distributors, and
services companies. KitchenAid Canada designated service
technicians are trained to fulfill the product warranty and
provide after-warranty service, anywhere in Canada.
For further assistance
If you need further assistance, you can write to KitchenAid
Canada with any questions or concerns at:
KitchenAid Canada
Customer eXperience Centre
200 – 6750 Century Ave.
Mississauga, Ontario L5N 0B7
Please include a daytime phone number in your correspondence.
Accessories
To order accessories, call 1-800-442-9991 and ask for the
appropriate part number listed below or contact your authorized
KitchenAid dealer. In Canada, call 1-800-807-6777.
Stainless Steel Cleaner and Polish
Order Part #4396095
WARNING
Explosion Hazard
Use nonflammable cleaner.
Failure to do so can result in death, explosion, or fire.

13
KITCHENAID®REFRIGERATOR WARRANTY
LIMITED WARRANTY
For one year from the date of purchase, when this major appliance is operated and maintained according to instructions attached to or
furnished with the product, KitchenAid brand of Whirlpool Corporation or Whirlpool Canada LP (hereafter “KitchenAid”) will pay for
factory specified parts and repair labor to correct defects in materials or workmanship that existed when this major appliance was
purchased. Service must be provided by a KitchenAid designated service company. YOUR SOLE AND EXCLUSIVE REMEDY UNDER
THIS LIMITED WARRANTY SHALL BE PRODUCT REPAIR AS PROVIDED HEREIN. This limited warranty is valid only in the United States
or Canada and applies only when the major appliance is used in the country in which it was purchased. Proof of original purchase date is
required to obtain service under this limited warranty.
SECOND THROUGH FIFTH YEAR LIMITED WARRANTY ON CAVITY LINER AND SEALED REFRIGERATION SYSTEM PARTS
In the second through fifth year from the date of purchase, when this major appliance is operated and maintained according to
instructions attached to or furnished with the product, KitchenAid will pay for replacement or repair of the refrigerator/freezer cavity liner
(including labor costs) if the part cracks due to defects in materials or workmanship that existed when this major appliance was
purchased. Also, in the second through fifth year from the date of purchase, when this major appliance is operated and maintained
according to instructions attached to or furnished with the product, KitchenAid will pay for factory specified parts and repair labor for the
following components to correct defects in materials or workmanship in the sealed refrigeration system that existed when this major
appliance was purchased: compressor, evaporator, condenser, dryer, and connecting tubing.
ITEMS EXCLUDED FROM WARRANTY
This limited warranty does not cover:
1. Replacement parts or repair labor if this major appliance is used for other than normal, single-family household use or when it is
used in a manner that is inconsistent to published user or operator instructions and/or installation instructions.
2. Service calls to correct the installation of your major appliance, to instruct you on how to use your major appliance, to replace or
repair house fuses, or to correct house wiring or plumbing.
3. Service calls to repair or replace appliance light bulbs, air filters or water filters. Consumable parts are excluded from warranty
coverage.
4. Damage resulting from accident, alteration, misuse, abuse, fire, flood, acts of God, improper installation, installation not in
accordance with electrical or plumbing codes, or use of products not approved by KitchenAid.
5. Cosmetic damage, including scratches, dents, chips or other damage to the finish of your major appliance, unless such damage
results from defects in materials or workmanship and is reported to KitchenAid within 30 days from the date of purchase.
6. Any food or medicine loss due to refrigerator or freezer product failures.
7. Pickup and delivery. This major appliance is intended to be repaired in your home.
8. Repairs to parts or systems resulting from unauthorized modifications made to the appliance.
9. Expenses for travel and transportation for product service if your major appliance is located in a remote area where service by an
authorized KitchenAid servicer is not available.
10. The removal and reinstallation of your major appliance if it is installed in an inaccessible location or is not installed in accordance
with KitchenAid's published installation instructions.
11. Replacement parts or repair labor on major appliances with original model/serial numbers that have been removed, altered or
cannot be easily determined.
DISCLAIMER OF IMPLIED WARRANTIES
IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR IMPLIED WARRANTY OF FITNESS FOR A
PARTICULAR PURPOSE, ARE LIMITED TO ONE YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW. Some states and provinces do
not allow limitations on the duration of implied warranties of merchantability or fitness, so this limitation may not apply to you. This
warranty gives you specific legal rights, and you also may have other rights that vary from state to state or province to province.
LIMITATION OF REMEDIES; EXCLUSION OF INCIDENTAL AND CONSEQUENTIAL DAMAGES
YOUR SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE PRODUCT REPAIR AS PROVIDED HEREIN.
KITCHENAID SHALL NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES. Some states and provinces do not allow the
exclusion or limitation of incidental or consequential damages, so these limitations and exclusions may not apply to you. This warranty
gives you specific legal rights, and you also may have other rights that vary from state to state or province to province.
If outside the 50 United States and Canada, contact your authorized KitchenAid dealer to determine if another warranty applies.
If you think you need repair service, first see the “Troubleshooting” section of the Use & Care Guide. If you are unable to resolve the
problem after checking “Troubleshooting,” additional help can be found by checking the “Assistance or Service” section or by calling
KitchenAid. In the U.S.A., call 1-800-422-1230. In Canada, call 1-800-807-6777.5/08
Keep this book and your sales slip together for future
reference. You must provide proof of purchase or installation
date for in-warranty service.
Write down the following information about your major appliance
to better help you obtain assistance or service if you ever need it.
You will need to know your complete model number and serial
number. You can find this information on the model and serial
number label located on the product.
Dealer name____________________________________________________
Address ________________________________________________________
Phone number__________________________________________________
Model number __________________________________________________
Serial number __________________________________________________
Purchase date __________________________________________________

14
SEGURIDAD DEL REFRIGERADOR PARA BEBIDAS
Cómo deshacerse adecuadamente de su
aparato refrigerado viejo
IMPORTANTE: El atrapamiento y asfixia de niños no es un
problema del pasado. Los refrigeradores para bebidas tirados y
abandonados son un peligro, aún si van a quedar ahí “por unos
pocos días”. Si Ud. está por deshacerse de su refrigerador para
bebidas viejo, por favor siga las instrucciones que se dan a
continuación para prevenir accidentes.
Antes de descartar su viejo aparato refrigerado:
■Saque la puerta.
■Deje las rejillas y los estantes en su lugar así los niños no
pueden meterse adentro con facilidad.
Si no sigue las instrucciones de inmediato, usted puede
morir o sufrir una lesión grave.
Si no sigue las instrucciones, usted puede morir o sufrir
una lesión grave.
Todos los mensajes de seguridad le dirán el peligro potencial, le dirán cómo reducir las posibilidades de sufrir una lesión y lo que
puede suceder si no se siguen las instrucciones.
Su seguridad y la seguridad de los demás es muy importante.
Hemos incluido muchos mensajes importantes de seguridad en este manual y en su electrodoméstico. Lea y obedezca siempre
todos los mensajes de seguridad.
ADVERTENCIA
PELIGRO
Este es el símbolo de advertencia de seguridad.
Este símbolo le llama la atención sobre peligros potenciales que pueden ocasionar la muerte o una lesión a
usted y a los demás.
Todos los mensajes de seguridad irán a continuación del símbolo de advertencia de seguridad y de la palabra
“PELIGRO” o “ADVERTENCIA”. Estas palabras significan:
INSTRUCCIONES IMPORTANTES DE SEGURIDAD
ADVERTENCIA:
Para reducir el riesgo de incendio, choque eléctrico, o lesiones personales al usar su refrigerador para
GUARDE ESTAS INSTRUCCIONES
■ Conecte a un contacto de pared de conexión a tierra de
3 terminales.
■ No quite la terminal de conexión a tierra.
■ No use un adaptador.
■ No use un cable eléctrico de extensión.
■ Desconecte el suministro de energía antes de darle servicio.
■ Vuelva a colocar todos los componentes y paneles antes de
hacerlo funcionar.
■ Remueva la puerta o el(los) cajón(cajones) de su aparato
refrigerado viejo.
■ Use un limpiador no inflamable.
■ Mantenga los materiales y vapores inflamables, tales como
gasolina, alejados del refrigerador para bebidas.
■ Use dos o más personas para mover e instalar el
refrigerador para bebidas.
bebidas, siga estas precauciones básicas:
ADVERTENCIA
Peligro de Asfixia
Remueva la puerta o el(los) cajón(cajones) de su
aparato refrigerado viejo.
No seguir esta instrucción puede ocasionar la muerte
o daño al cerebro.

15
INSTRUCCIONES DE INSTALACIÓN
Piezas y herramientas
HERRAMIENTAS NECESARIAS:
Reúna las herramientas y piezas necesarias antes de comenzar la
instalación.
Lea y siga las instrucciones provistas con cualquiera de las
herramientas enlistadas aquí.
PIEZAS NECESARIAS:
Marco recubierto a la medida - Vea “Marco recubierto - Vista
posterior”.
Herrajes (opcionales)
PIEZAS SUMINISTRADAS:
Marco recubierto a la medida
Si va a instalar un marco recubierto a la medida, deberá hacer el
marco usted mismo o consultar con un carpintero o fabricante de
armarios calificado. Para obtener información acerca de las
especificaciones del marco, vea los gráficos dimensionales.
IMPORTANTE:
■El grosor del marco recubierto debe ser de ³⁄₄" (1,91 cm).
■El marco recubierto no debe pesar más de 10 lbs
(4,54 kg).
■Los marcos recubiertos que pesan más de lo
recomendado pueden dañar su electrodoméstico.
Medidas del marco de revestimiento - Vista posterior
Cree su marco recubierto a la medida utilizando las medidas que
se muestran.
Cómo instalar los ganchos recubiertos
Con un destornillador Phillips y ocho tornillos de cabeza plana
ajuste los ganchos recubiertos a la parte posterior del marco
recubierto. Consulte “Marco recubierto - Vista posterior” para ver
las ubicaciones de los ganchos recubiertos.
■Taladro manual o
eléctrico (debidamente
conectado a tierra)
■Broca de barrena con
punta para cabillas de ½"
■Destornillador Phillips
■Tijeras
■Cinta adhesiva protectora
■Cinta para medir
■Petrolato
■Tornillos de cabeza
plana (8)
■Tornillos de cabeza
redonda (8)
■Placas del revestimiento (2)
■Ganchos del revestimiento (4)
A. Ubicaciones de los ganchos recubiertos
A. Ganchos recubiertos (4)
2 ¹⁵⁄₁₆ "
(7,5 cm)
3 ³⁄₄ "
(9,53 cm)
1 ⁵⁄₁₆ "
(3,33 cm)
1
⁵⁄₁₆ "
(3,33 cm)
4 ¹³⁄₃₂ "
(11,2 cm)
2 ¹⁄₂ "
(6,4 cm)
A
23 ³⁄₄ "
(60,33 cm)
29
⁷⁄₈ "
(75,88 cm)
A

16
Orificios de la bisagra de la puerta
■Las vistas del orificio de la espiga de la bisagra superior e
inferior ilustran una bisagra del lado derecho. Refleje la
imagen para una bisagra del lado izquierdo.
■Recomendamos usar una abrazadera en C y dos piezas de
madera de deshecho (adelante y atrás) para ayudar a reforzar
el marco recubierto cuando taladre los orificios de la espiga
de la bisagra.
1. Con una broca de barrena para cabillas de ½", taladre un
orificio de ½" (1,27 cm) de profundidad en la parte superior
del marco recubierto para la espiga de la bisagra superior,
como se muestra.
Vista superior
2. Taladre un orificio de ½" (1,27 cm) de profundidad en la parte
inferior del marco recubierto para la espiga de la bisagra
inferior, como se muestra.
Vista inferior
Requisitos de ubicación
Para asegurarse la ventilación adecuada del refrigerador para
bebidas, deje un espacio de ¹/₄" (6,35 mm) a cada lado y por
encima. Si Ud. instala el refrigerador para bebidas próximo a una
pared fija, deje como mínimo 2¹/₂" (6,35 cm) del lado de la bisagra
para permitir que la puerta abra bien.
NOTA: No se recomienda instalar el refrigerador para bebidas
cerca de un horno, radiador u otra fuente de calor. No la instale en
un lugar donde la temperatura puede ser menor de 55°F (13°C).
Para obtener un óptimo funcionamiento, no instale el refrigerador
para bebidas detrás de la puerta de un armario ni bloquee la rejilla
de la base.
Requisitos eléctricos
Antes de mover el refrigerador para bebidas a su ubicación final,
es importante asegurarse de que tiene la conexión eléctrica
adecuada.
Método de conexión a tierra recomendado
Se requiere una fuente de energía eléctrica de 115 Voltios, 60 Hz.,
CA solamente y con fusibles de 15 ó 20 amperios, debidamente
conectada a tierra. Se recomienda que use un circuito separado
sólo para su refrigerador para bebidas. Use un tomacorriente que
no se pueda apagar con un interruptor. No use un cable eléctrico
de extensión.
NOTA: Antes de realizar cualquier tipo de instalación, limpieza o
de quitar un foco de luz, desenchufe el refrigerador para bebidas
o desconecte el suministro de energía.
A. Radio de 5,0
A. Radio de 5,0
¹⁄₂"
(1,2 cm)
¹⁷⁄₃₂"
(1,35 mm)
A
Superficie trasera
Superficie frontal
¹⁄₂"
(1,2 cm)
¹⁷⁄₃₂"
(1,35 mm)
A
Superficie frontal
Superficie trasera
ADVERTENCIA
Peligro de Explosión
Mantenga los materiales y vapores inflamables,
tales como gasolina, alejados del refrigerador para
bebidas.
No seguir esta instrucción puede ocasionar la muerte,
explosión, o incendio.
2¹⁄₂" (6,35 cm)
¹⁄₄" (6,35 mm)
ADVERTENCIA
Peligro de Choque Eléctrico
Conecte a un contacto de pared de conexión a tierra de
3 terminales.
No quite la terminal de conexión a tierra.
No use un adaptador.
No use un cable eléctrico de extensión.
No seguir estas instrucciones puede ocasionar
la muerte, incendio o choque eléctrico.

17
Desempaque del refrigerador para bebidas
Cómo quitar los materiales de empaque
■Quite los residuos de cinta y goma de las superficies antes de
encender el refrigerador para bebidas. Frote un poco de
detergente líquido para vajillas sobre el adhesivo con los
dedos. Limpie con agua tibia y seque.
■No use instrumentos filosos, alcohol para fricciones, líquidos
inflamables o productos de limpieza abrasivos para eliminar
los restos de cinta o goma. Estos productos pueden dañar la
superficie de su refrigerador para bebidas. Para obtener más
información, vea “Seguridad del refrigerador para bebidas”.
■Deshágase de todos los materiales de embalaje o recíclelos.
Limpieza antes del uso
Una vez que usted haya quitado todos los materiales de
empaque, limpie el interior de su refrigerador para bebidas antes
de usarlo. Vea las instrucciones de limpieza en “Cuidado del
refrigerador para bebidas”.
Cómo instalar el marco recubierto
alamedida
IMPORTANTE:
■Cree un marco recubierto a la medida de acuerdo con las
especificaciones en la sección “Marco recubierto a la
medida”.
■KitchenAid no es responsable de la remoción o adición de
marcos o paneles decorativos que pudieran impedir darle
servicio al electrodoméstico.
Cómo quitar la puerta
IMPORTANTE: No quite la grasa de la arandela, del espaciador
superior o de la espiga de la bisagra superior. Asegúrese de
apartar la bisagra superior, el espaciador superior y la arandela
para su uso posterior.
1. Quite con un destornillador Phillips los tres tornillos de la
bisagra superior. Saque la bisagra superior.
2. Quite los tres tornillos del espaciador superior. Quite el
espaciador superior y la arandela.
3. Abra la puerta. Levante la parte frontal de la puerta,
empujando directamente hacia fuera para quitarla como se
muestra.
ADVERTENCIA
Peligro de Peso Excesivo
Use dos o más personas para mover e instalar
el refrigerador para bebidas.
No seguir esta instrucción puede ocasionar una
lesión en la espalda u otro tipo de lesiones.
Cuando mueva su refrigerador para bebidas:
Su refrigerador para bebidas es muy pesado. Cuando
mueva el electrodoméstico para limpiarlo y darle servicio,
cerciórese de cubrir el piso con cartón o madera para evitar
daños en el mismo. Al mover el electrodoméstico, siempre
tire directamente hacia afuera. No menee el
electrodoméstico de lado a lado ni lo haga “caminar”
cuando lo trate de mover ya que podría dañar el piso.
Información importante para saber acerca de los estantes
y tapas de vidrio:
No limpie los estantes y tapas de vidrio con agua caliente
mientras están fríos. Los estantes y tapas pueden romperse
si se exponen a cambios bruscos de temperatura o impacto,
como sería un golpe brusco. El vidrio templado se ha
diseñado para hacerse añicos. Esto es normal. Los estantes
y tapas de vidrio son muy pesados. Use ambas manos al
sacarlos para evitar que se caigan.
A. Tornillos (3)
B. Bisagra superior
C. Arandela
D. Espaciador superior
E. Puerta
C
D
E
A
B

18
Cómo fijar el marco recubierto
NOTA: Si los ganchos recubiertos no están instalados, consulte
“Marco recubierto a la medida” para ver las ubicaciones de los
ganchos recubiertos.
1. Ubique el marco recubierto ¹⁄₂" (1,27 cm) por encima de la
puerta. Asegúrese de ubicar los ganchos de revestimiento en
los orificios piloto.
2. Inserte los ganchos de revestimiento en la parte superior de
los orificios de la puerta. Empuje contra el marco recubierto
para forzar los ganchos recubiertos aún más dentro la puerta.
Jale el marco recubierto directamente hacia abajo para
asegurar los ganchos recubiertos en la puerta.
3. Ajuste con un destornillador Phillips las placas recubiertas a la
parte inferior del marco recubierto y de la puerta, como se
muestra.
Cómo instalar la puerta
IMPORTANTE: Para asegurar el funcionamiento adecuado,
asegúrese de engrasar la bisagra superior, el espaciador superior
y la arandela con petrolato.
1. Ajuste el espaciador superior a la puerta con un destornillador
Phillips y tres tornillos.
2. Engrase con petrolato el orificio del espaciador inferior y la
espiga de la bisagra inferior. Alinee la arandela con el orificio
del espaciador inferior.
3. Lentamente baje la puerta en forma derecha y pareja hasta la
espiga de la bisagra inferior. Asegúrese de que la arandela se
mantenga en su lugar. Cierre la puerta. Asegúrese de que la
puerta esté correctamente alineada con la carcasa.
NOTA: Provea un soporte adicional para la puerta cuando
mueve las bisagras. No se confíe en que los imanes de la
puerta van a sostener la puerta en su lugar mientras trabaja.
4. Asegure la puerta a la carcasa con cinta adhesiva protectora
antes de instalar el espaciador superior, como se muestra.
5. Ubique la arandela en el espaciador superior y alinee los
orificios. Engrase la espiga de la bisagra superior, el
espaciador superior y la arandela con petrolato. Inserte la
espiga de la bisagra superior en la arandela y el espaciador
superior.
6. Ajuste la bisagra superior a la carcasa con un destornillador
Phillips y tres tornillos, como se muestra.
7. Quite la cinta adhesiva protectora de la puerta.
A. Marco recubierto
B. Puerta
C. Placas recubiertas (2)
D. Tornillos de cabeza redonda (8)
ACDB
A. Espaciador superior
B. Cinta adhesiva protectora
A. Tornillos (3)
B. Bisagra superior
C. Arandela
D. Espaciador superior
E. Puerta
F. Marco recubierto
A
B
C
D
E
A
B
F

19
Cómo cerrar la puerta
Cómo cerrar la puerta
Su refrigerador para bebidas tiene cuatro patas niveladoras. Si su
refrigerador para bebidas parece inestable o usted quiere que la
puerta se cierre con mayor facilidad, ajuste la inclinación del
refrigerador para bebidas usando las instrucciones a
continuación.
1. Conecte a un contacto de pared de conexión a tierra de
3terminales.
2. Mueva el refrigerador para bebidas hacia su posición final.
3. Gire las patas niveladoras hacia la derecha para bajar el
refrigerador para bebidas o gírelas hacia la izquierda para
levantarlo. Puede precisar darle varias vueltas a las patas
niveladoras para ajustar la inclinación del refrigerador para
bebidas.
NOTA: Para quitar un poco de peso de las patas niveladoras,
haga que alguien empuje la parte superior del refrigerador
para bebidas. Esto facilita el ajuste de las patas niveladoras.
4. Verifique para asegurarse de que se cierra con la facilidad que
usted desea. De lo contrario, incline el refrigerador para
bebidas ligeramente más hacia la parte posterior, girando
ambos tornillos reguladores frontales hacia la izquierda.
Puede tomar varias vueltas más, y usted deberá girar ambas
patas niveladoras la misma cantidad de veces.
Rejilla de la base
Herramienta necesaria: Destornillador Phillips
Quite la rejilla de la base
1. Abra la puerta del refrigerador para bebidas.
2. Saque los dos tornillos con un destornillador Phillips. Empuje
ambas lengüetas hacia el centro para liberar la rejilla de la
base del refrigerador para bebidas.
3. Quite la rejilla de la base.
Vuelva a colocar la rejilla de la base
1. Abra la puerta del refrigerador para bebidas.
2. Coloque la rejilla de la base de manera que ambas lengüetas
estén alineadas y la rejilla de la base encaje en su lugar.
Vuelva a colocar los dos tornillos. Apriete los tornillos.
USO DEL REFRIGERADOR
PARA BEBIDAS
Sonidos normales
Su nuevo refrigerador para bebidas puede hacer ruidos que su
viejo refrigerador para bebidas no hacía. Como estos sonidos son
nuevos para Ud., puede ser que se preocupe. La mayoría de los
sonidos nuevos son normales. Las superficies duras tales como
el piso y las estructuras circundantes pueden hacer que los
sonidos parezcan más fuertes. A continuación se describen los
tipos de sonidos y qué puede causarlos.
■Su refrigerador para bebidas está diseñado para funcionar
con más eficiencia para conservar sus alimentos a la
temperatura deseada y para reducir al mínimo el uso de
energía. El compresor y los ventiladores de alta eficiencia
pueden causar que su nuevo refrigerador para bebidas
funcione por períodos de tiempo más largos que su
refrigerador para bebidas viejo. También puede escuchar un
sonido pulsante o agudo del compresor o los ventiladores que
se ajustan para un funcionamiento óptimo.
■Las vibraciones pueden producirse por el flujo de líquido
refrigerante o artículos guardados dentro del refrigerador para
bebidas.
■Al final de cada ciclo, Ud. puede escuchar un gorgoteo
debido al flujo de líquido refrigerante en su refrigerador para
bebidas.
■Ud. puede escuchar agua corriendo hacia la bandeja
recolectora cuando el refrigerador para bebidas se está
descongelando.
■Es posible que escuche sonidos de chasquido cuando el
refrigerador para bebidas comienza o deja de funcionar.
ADVERTENCIA
Peligro de Choque Eléctrico
Conecte a un contacto de pared de conexión a tierra de
3 terminales.
No quite la terminal de conexión a tierra.
No use un adaptador.
No use un cable eléctrico de extensión.
No seguir estas instrucciones puede ocasionar
la muerte, incendio o choque eléctrico.
ADVERTENCIA
Peligro de Peso Excesivo
Use dos o más personas para mover e instalar
el refrigerador para bebidas.
No seguir esta instrucción puede ocasionar una
lesión en la espalda u otro tipo de lesiones.
A. Lengüetas
B. Tornillos
BAA

20
Uso del control
Para su comodidad, el control de su refrigerador para bebidas ha
sido prefijado de fábrica. Al instalar su refrigerador para bebidas
por primera vez, cerciórese de que el control aún esté prefijado en
el ajuste medio, como se ilustra.
Cómo ajustar los controles
El ajuste medio indicado en la sección previa debe estar correcto
para el uso normal. El control está fijado correctamente cuando
las bebidas están tan frías como a usted le gusta.
Si necesita ajustar la temperatura, espere por lo menos 24 horas
entre un ajuste y otro, y después vuelva a verificar la temperatura.
Para hacer que el refrigerador para bebidas esté más frío, coloque
el control en el siguiente ajuste más alto. Para hacer que el
refrigerador para bebidas esté menos frío, coloque el control en el
siguiente ajuste más bajo.
Separador de temperatura (Pantalla de temperatura)
El separador de temperatura muestra las temperaturas actuales
(en Fahrenheit o centígrados) para las zonas (compartimientos)
superior, media e inferior del refrigerador para bebidas. Para
regular los ajustes de temperatura, vea “Cómo ajustar los
controles” anteriormente en esta sección.
Portabebidas/portabotellas
Para quitar y volver a colocar los estantes
1. Jale el estante hacia adelante hasta que se detenga. Empuje
las lengüetas para liberar el estante. Continúe jalando el
estante hacia delante y levántelo fuera de los soportes del
mismo.
2. Vuelva a colocar el estante insertándolo en los soportes y
deslizándolo hacia atrás del refrigerador para bebidas.
Para quitar y volver a colocar el estante inferior
1. Levante el estante (por la parte frontal y trasera) y jálelo
derecho hacia afuera para quitarla.
2. Vuelva a colocar la rejilla empujando derecho hacia atrás,
pasando el tope. Continúe empujando la rejilla derecho hacia
atrás y uniformemente hasta que quede en su lugar.
A. Reductor de luz
B. Pantalla de la zona superior
C. Pantalla de la zona media
D. Pantalla de la zona inferior
E. Fahrenheit/centígrados
Dimmer Upper Middle Lower
AB C DE
F
A. Lengüetas
A
A
