KitchenAid KSSC42FMS03 User manual

1
CABINET PARTS
For Model: KSSC42FMS03
(Stainless Steel)
10−06 Litho In U.S.A. (dmm) Part No. W10114552
42" BUILT IN
REFRIGERATOR

2
CABINET PARTS
For Model: KSSC42FMS03
(Stainless Steel)
W10114552
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature Parts
2320531 Use & Care Guide
2307363 Energy Label
2320619 Service & Wiring
Sheet
2306337 Icemaker and
Ingredient Care
Care Center
Service Sheet
2302865 Service Sheet,
Main Control
2309069 Installation
Instructions
2 Cabinet (Not A
Serviceable Part)
3 2320650 Clamp, Tube
4 1112023 Roller, Front &
Rear (4)
5 Support, Leveler
Assembly
2004506 Refrigerator Side
2004505 Freezer Side
6 2005006 Grommet, Wiring
7 2005007 Grommet,
Flexible
8 2186494B Cap, Water Filter
9 2006442 Mounting Stud,
Grill
10 2005004 Grommet, Crossover
Tube
11 2005783 Cam, Door Closer
12 2209022 Housing, Water
Filter
14 3400525 Screw
15 2255709 Filter, Water
16 489399 Screw
17 3400230 Screw, Door Stop
18 2257644 Hinge (Top)
19 2307582 Bracket, Mount
(Water Filter)
20 489464 Screw
21 2004994 Lock, Adjustable
Bushing
22 2300082 Bushing
23 2209090 Clamp, Filter
Housing
24 Spring, Door
Closure
2221242 Right Side
2004517 Left Side
25 486194 Screw
26 2005008 Retaining Ring,
Adjustable Bushing
27 2320677 Wire clip (5)
28 2006342 Gap, Cover
Assembly (Bottom)
29 Hinge (Bottom)
2006780 Freezer Side
2006779 Refrigerator Side
30 2302876 Bushing,
Adjustable
31 8533913 Screw
32 2209025B Skirt−Grille,
Bottom
33 Extension Arm,
Door Closer
2266882 Right
2266881 Left
34 2209428B Grille Bottom,
Front
35 2005921 Screw
36 Bracket, Support
Base (Front)
2006616 Left
2006556 Right
37 1157158 Screw
38 2006617 Bracket, Support
Base (Rear) (2)
39 2006346 Washer
40 2266880 Bushing,
Extension Arm
41 1163283 Screw
43 488500 Screw
44 Switch, Rocker Arm
1118894 Refrigerator Door
Side
1115373 Freezer Door Side
45 2215938 Cover, Switch (2)
46 487415 Screw
47 Bracket, Cover
2221097 Right
2221096 Left
48 2215612 Cover, Rear
49 488937 Clamp, Tube

3
CABINET TRIM PARTS
For Model: KSSC42FMS03
(Stainless Steel)
W10114552
Illus. Part
No. No. DESCRIPTION
1 Cabinet, Trim
(Right Side)
2222552S Stainless Steel
3 Screw
8281250 Stainless Steel
4 2316687 Cabinet, Trim
(Bottom)
5 486194 Screw
6 2313992 Cabinet, Trim Top
7 Cabinet Trim
(Left Side)
2222553S Stainless Steel
9 2005925 Seal−Trim, Side
10 489464 Screw

4
FREEZER SHELF PARTS
For Model: KSSC42FMS03
(Stainless Steel)
W10114552
Illus. Part
No. No. DESCRIPTION
1 2302868 Wire Shelf
2 2266934 Front, Ice
Compartment
3 2302883 Shelf, Fixed (2)
4 2259082 Basket
5 2256270 Front, Basket
6 Slide, Basket
2259317 Right Side
2259318 Left Side
7 486194 Screw
8 2266955 Spacer
10 2266931 Ice Bucket
18 2302871 Cover, Shelf

5
REFRIGERATOR LINER PARTS
For Model: KSSC42FMS03
(Stainless Steel)
W10114552

6
REFRIGERATOR LINER PARTS
For Model: KSSC42FMS03
(Stainless Steel)
W10114552
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Serviceable Part)
2 2306010 Thermistor
3 2208970 Air Duct
4 2209204 Clip, Thermistor
5 2259077 Ladder, Shelf (2)
6 520965 Screw Support,
Ladder (4)
7 2006475 Screw
8 486194 Screw
10 2302986 Lid−Baffle,
Meat Pan
11 2320635 Baffle Air
12 2171846 Release Valve
13 2310205 Air Baffle,
Jumper Harness
14 488357 Screw
15 486194 Screw
17 2221296 Air Baffle
Assembly
20 2302937 Thermistor
21 2309222 Diffuser Assembly
22 2317105 Cover, Thermistor
23 2188820 Thermistor
24 2302992 Spacer, Air Baffle
25 2309087 Cover, Diffuser
27 2259412 Seal, Air Duct
(Round Hole)
28 2259398 Seal, Air Duct
(Square Hole)

7
CONTROL PANEL PARTS
For Model: KSSC42FMS03
(Stainless Steel)
W10114552
Illus. Part
No. No. DESCRIPTION
1 2302772 Control Box
2 2303938 Insert, Control
Box
3 2302913 Circuit Board,
Housing Control
4 2310197 Control Box
Wire Harness
6 2221121 Support, Control
Bracket
7 489006 Screw
9 2306086 Display Assembly,
Ingredient Care
Center
11 2162085 Socket, Light (2)
12 2255743 Light Bulb (2)
13 486194 Screw
14 8281185 Screw
15 2257519 Overlay
16 2302717 Shield, Light

8
TOP GRILLE AND UNIT COVER PARTS
For Model: KSSC42FMS03
(Stainless Steel)
W10114552
Illus. Part
No. No. DESCRIPTION
1 Panel, Decorator
2257411S Stainless steel
2 2259320 Cover, Unit
3 487415 Screw
4 2256466 Back Panel
5 2320678 Cover−Unit, Front
6 2005292 Nameplate
7 2215910 Grommet
9 2004333 Nut
11 2254759 Bracket, Louver
12 Grille, Louver
2254761S Stainless steel
13 488879 Screw
14 487415 Screw
15 2310194 Wire Assembly,
RC/FC Light Switch
16 489348 Clamp

REFRIGERATOR SHELF PARTS
9
For Model: KSSC42FMS03
(Stainless Steel)
W10114552

REFRIGERATOR SHELF PARTS
10
For Model: KSSC42FMS03
(Stainless Steel)
W10114552
Illus. Part
No. No. DESCRIPTION
1 2222592 Shelf Assembly
5 2179404 Rack, Wine
6 2221071 Egg Bin
9 2302842 Glass, Meat Pan
Assembly
10 2302835 Glass, Crisper
Assembly
13 2257582 Trim, Glass (Rear)
14 2252412 Crisper Pan (2)
17 Slide, Meat Pan
2302955 Right Side
2302954 Left Side
18 Trim, Glass−Front
(Not Serviced
Seperately)
19 2256254 Trim, Glass (Rear)
21 2256248 Front, Crisper Pan
23 2256250 Trim, Glass (Side)
(Meat Pan)
24 2252255 Trim, Glass (Side)
(Crisper Pan)
25 Spacer, Crisper
2256222 Right Side (2)
2256223 Left Side (2)
27 Slide, Crisper
2302957 Right Side
2302956 Left Side
28 Spacer, Meat Pan
2256244 Right Side (2)
2256243 Left Side (2)
29 Screw
8533929 Right Side
8533928 Left Side
30 2256369 Meat Pan Assy
31 2256366 Front, Meat Pan

11
FREEZER LINER AND AIR FLOW PARTS
For Model: KSSC42FMS03
(Stainless Steel)
W10114552

12
FREEZER LINER AND AIR FLOW PARTS
For Model: KSSC42FMS03
(Stainless Steel)
W10114552
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 2259385 Fan Motor
2 2302850 Support, Air Duct
3 2169142 Fan Blade
4 2223733 Retainer,
Fan Motor
5 2302817 Gasket, Cover
6 2223986 Grommet
7 486194 Screw
8 2259464 Wedge, Air Duct
(Right)
9 488500 Screw, Ground
10 2162085 Socket, Light (2)
11 2221070 Clamp, Nylon
12 2255743 Light Bulb
13 8281185 Screw
14 2182120 Scroll, Fan
15 2259465 Wedge, Air Duct
(Left)
16 2302777 Seal, Light Socket
17 2306043 Assembly, Air Duct
18 2266801 Deflector, Air
Ice Maker
19 Block, Fan Scroll
2209480 Right
2209066 Left
20 2302925 Bracket, Vent Tube
21 Liner (Not
Serviceable Part)
22 2302932 Tube, Vent
23 2259025 Cover, Air Outlet
24 2259367 Light Shield
25 2314043 Cover, Evaporator
26 486194 Screw
27 8281163 Screw
28 2317827 Block,
Return Air
29 2309283 Deflector,
Air Duct
30 1112260 Support,
Evaporator
31 2196483 Stud, Shelf (20)
32 8281158 Screw
33 Evaporator,
Cover Rail
2221107 Left Side
2259355 Right Side
34 2220904 Gasket (2)
Evaporator Cover
39 2188820 Thermistor
40 2209204 Clip, Thermistor
41 1116793 Cover, Thermistor
42 2006475 Screw
44 2257571 Bracket, Light
46 2259032 Ladder, Shelf
47 2259445 Screw Support (3)
56 2259064 Cover, Fill Tube
Heater

REFRIGERATOR DOOR PARTS
13
For Model: KSSC42FMS03
(Stainless Steel)
W10114552

REFRIGERATOR DOOR PARTS
14
For Model: KSSC42FMS03
(Stainless Steel)
W10114552
Illus. Part
No. No. DESCRIPTION
1 2252330 Refrigerator Door
(Includes
Item #9)
3 2266854 Hinge Assembly,
Top
4 2256381 Spacer−Door,
Top
5 489282 Screw
6 2302878 Hinge Assembly,
Bottom
7 2222796 Rail, Lid
8 2222982 Gasket,
Utility Bin
9 2222811 Door Gasket,
Magnetic
10 Door Skin
2306156 Stainless Steel
11 Handle, Door
2005290 Stainless Steel
12 308544 Screw
13 2257637 Door, Spacer
Bottom
14 2258951 Door Brace, Corner
15 Screw
8281250 Stainless Steel
16 2005326 Filler, Door
17 2005433 Spacer, Door (Top)
18 2005030 Spacer, Door
(Hinge Side)
19 2004934 Spacer, Door
(Bottom)
20 2306398 Plate, Door−Handle
21 End Cap
2222919 Right Side
2222920 Left Side
25 2222922 Bin, Utility
(Center)
26 2222925 Door, Utility Bin
27 2222773 Door Shelf (3)
28 2165792 Butter Tray
30 2222770 Shelf, Gallon
Door
32 2309060 Spacer, Door
(Handle Side)

FREEZER DOOR PARTS
15
For Model: KSSC42FMS03
(Stainless Steel)
W10114552

FREEZER DOOR PARTS
16
For Model: KSSC42FMS03
(Stainless Steel)
W10114552
Illus. Part
No. No. DESCRIPTION
1 2252327 Freezer Door
(Includes #14)
2 Skin, Door
2306160 Stainless Steel
3 2306398 Plate, Door−Handle
6 2302879 Hinge, Bottom
7 489282 Screw
8 2266854 Hinge, Top
9 2256381 Spacer−Door,
Top
11 2258951 Brace, Door−Corner
14 2222814 Door Gasket,
Magnetic
15 486194 Screw (34)
16 Handle, Door
2005290 Stainless Steel
18 2257637 Door, Spacer
20 Screw
8281250 Stainless Steel
21 2005433 Spacer, Top
23 2004932 Spacer, Door
Bottom
24 2005030 Spacer, Hinge Side
25 308544 Screw
27 2309060 Spacer, Handle
Side
28 2222776 Shelf Bin (6)
34 2005325 Filler, Door

UPPER UNIT PARTS
17
For Model: KSSC42FMS03
(Stainless Steel)
W10114552

UPPER UNIT PARTS
18
For Model: KSSC42FMS03
(Stainless Steel)
W10114552
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 2304175 Inverter Box
2 489373 Screw, Compressor
Mounting (4)
3 2223393 Compressor
(Includes Items
6, 9 & 21)
(Also Order
876765 Tube Kit)
4 2257354 Housing, Control
Board
5 2215641 Bracket, Fan Motor
6 1100826 Grommet, Mounting
7 2266803 Shroud, Condenser
(Right)
8 2302969 Bracket, Switch
9 2215676 Terminal Cover
10 2302973 Shroud, Condenser
(Left)
11 2307028 Control Board
12 2203075 Spacer (5)
13 2256328 Bracket, Inverter
Box
14 8281149 Screw
15 486194 Screw
16 2259307 Condenser
17 943447 Grommet (4)
18 2310243 Jumper, Wire
19 487522 Screw
20 2155774 Wire Tie
21 2317982 Drier
22 2310207 Wire Assembly
(Condenser Fan)
23 2206036 Motor, Fan
24 2190685 Blade, Fan
25 2003169 Orifice, Fan
26 2259302 Tube, Transition
(Drier)
27 8281160 Screw
28 2259340 Tube, Transition
(Heat Loop)
29 486692 Speed Nut
30 2259349 Housing, Power
Supply
31 2259350 Power Supply,
Ingredient Care
Center
32 2000645 Sleeve,
Condenser
34 2194319 Process, Tube
35 486194 Screw
36 2209495 Cover, Fan
37 2259092 Cover, Condenser
38 2307907 Grommet, Edge
39 2310251 Service Cord
41 549193 Clamp, Cord
42 2266802 Switch, Power
Disconnect
43 487294 Screw, Ground
45 2310217 Wiring Harness,
Unit Compartment
Following Parts Not Illustrated
and Optional Parts Not Included
978025 Valve, Access
(1/4")
978026 Valve, Access
(5/16")
978027 Valve, Access
(3/8")
978028 Valve, Access
(1/2")
978029 Valve, Access
(5/8")
978030 Valve, Access
(3/4")
876764 Valve, Access
(3/16")
REFRIGERANT CHARGE
7.50 oz.
(R−134A)

LOWER UNIT AND TUBE PARTS
19
For Model: KSSC42FMS03
(Stainless Steel)
W10114552

LOWER UNIT AND TUBE PARTS
20
For Model: KSSC42FMS03
(Stainless Steel)
W10114552
Illus. Part
No. No. DESCRIPTION
1 2317087 Defrost Bi−Metal
2 2317088 Wire Harness
(Includes Item 1)
3 486194 Screw
4 2215508 Bracket
6 2259303 Suction Tube
7 8281163 Screw
8 2259304 Tube, Connect
(Drier/Restrictor)
9 2320615 Drain Pan &
Heater Assembly
10 2316683 Cover, Wiring
11 2316684 Cover, Box
13 2259353 Tube, Discharge
14 2188820 Thermistor
16 2306093 Evaporator
17 2306388 Heater, Defrost
18 1113048 Clamp, Heater (2)
19 2316794 Seal,
Return Air
20 2220832 Gasket, Evaporator
21 2155774 Wire Tie
22 2215691 Clip, Heat
Exchanger
23 9791833 Clip
26 2320554 Support, Drain Pan
