KitchenAid KBFC42FSS User manual

42" (106.7 CM) BOTTOM-MOUNT
BUILT-IN REFRIGERATOR
Installation Guide
IMPORTANT: READ AND SAVE THESE INSTRUCTIONS. INSTALLATION REQUIRES 2 OR MORE PEOPLE.
REFRIGERADOR EMPOTRADO CON MONTAJE
INFERIOR DE 42" (106,7 CM)
Manual de instalación
IMPORTANTE: LEA Y GUARDE ESTAS INSTRUCCIONES. LA INSTALACIÓN REQUIERE DE 2 O MÁS PERSONAS.
RÉFRIGÉRATEUR ENCASTRÉ DE 42" (106,7 CM)
AVEC CONGÉLATEUR EN DESSOUS
Guide d’Installation
IMPORTANT : LIRE ET CONSERVER CES INSTRUCTIONS. L’INSTALLATION NÉCESSITE L’INTERVENTION DE 2 PERSONNES OU PLUS.
Table of Contents/Índice/Table des matières..................................................................2
2309309

2
TABLE OF CONTENTS
REFRIGERATOR SAFETY........................................................................... 3
MODELS....................................................................................................... 4
INSTALLATION REQUIREMENTS ............................................................. 4
Tools and Parts......................................................................................... 4
Location Requirements............................................................................. 5
Electrical Requirements............................................................................ 6
Water Supply Requirements..................................................................... 6
Tipping Radius .......................................................................................... 6
Product Dimensions ................................................................................. 7
Door Swing Dimensions ........................................................................... 7
Handle and Door Clearances ...................................................................8
Overlay Series Custom Panels ............................................................... 10
Custom Overlay Panel Dimensions........................................................10
Architect® Series Custom Side Panels....................................................11
Overlay Series Custom Side Panels.......................................................12
INSTALLATION INSTRUCTIONS............................................................. 13
Unpack the Refrigerator ......................................................................... 13
Reduce Tipping Radius .......................................................................... 13
Move the Refrigerator into House .......................................................... 13
Install Anti-Tip Boards ............................................................................ 14
Connect the Water Supply ..................................................................... 14
Plug in Refrigerator................................................................................. 15
Move Refrigerator to Final Location....................................................... 15
Lower Leveling Legs............................................................................... 16
Install Overlay Series Custom Panels .................................................... 16
Level and Align Refrigerator ................................................................... 17
Adjust Doors ........................................................................................... 17
Install Side Panel .................................................................................... 18
Install Base Grille .................................................................................... 19
Complete Installation.............................................................................. 19
Water System Preparation ..................................................................... 19
ÍNDICE
SEGURIDAD DEL REFRIGERADOR........................................................20
MODELOS..................................................................................................21
REQUISITOS DE INSTALACIÓN..............................................................21
Piezas y herramientas.............................................................................21
Requisitos de ubicación .........................................................................22
Requisitos eléctricos...............................................................................23
Requisitos del suministro de agua .........................................................23
Arco de vuelco ........................................................................................24
Medidas del producto.............................................................................24
Medidas de oscilación de la puerta........................................................25
Espacios para la agarradera y la puerta.................................................26
Paneles a la medida de la Serie Overlay ................................................28
Dimensiones del panel recubierto a la medida ......................................29
Paneles laterales a la medida para la Serie Architect®...........................30
Paneles laterales a la medida para la Serie Overlay ..............................30
INSTRUCCIONES DE INSTALACIÓN...................................................... 31
Desempaque el refrigerador................................................................... 31
Cómo reducir el arco de vuelco ............................................................. 32
Cómo hacer entrar el refrigerador en la casa ........................................ 32
Cómo instalar los tableros antivuelco .................................................... 32
Conexión del suministro de agua........................................................... 33
Cómo enchufar el refrigerador ............................................................... 34
Ubicación final del refrigerador .............................................................. 34
Baje las patas niveladoras...................................................................... 35
Cómo instalar los paneles a la medida para la Serie Overlay ............... 35
Nivelación y alineamiento del refrigerador............................................. 36
Cómo ajustar las puertas ....................................................................... 36
Cómo instalar el panel lateral ................................................................. 38
Cómo instalar la rejilla de la base........................................................... 38
Cómo terminar la instalación.................................................................. 39
Preparación del sistema de agua........................................................... 39
TABLE DES MATIÈRES
SÉCURITÉ DU RÉFRIGÉRATEUR ...........................................................40
MODÈLES ..................................................................................................41
EXIGENCES D’INSTALLATION................................................................41
Outillage et pièces ..................................................................................41
Exigences d’emplacement .....................................................................42
Spécifications électriques ......................................................................43
Spécifications de l’alimentation en eau.................................................. 43
Rayon de basculement...........................................................................44
Dimensions du produit............................................................................44
Dimensions pour le pivotement des portes ...........................................45
Dégagements pour les poignées et portes ............................................46
Panneaux personnalisés de la série Overlay..........................................48
Panneaux personnalisés - Dimensions ..................................................49
Panneaux latéraux personnalisés de la Série Architect®....................... 50
Panneaux latéraux personnalisés des Séries Overlay ...........................50
INSTRUCTIONS D’INSTALLATION ......................................................... 51
Déballage du réfrigérateur...................................................................... 51
Réduction du rayon de basculement ..................................................... 52
Faire entrer le réfrigérateur dans le domicile.......................................... 52
Installation de planches antibasculement.............................................. 52
Raccordement à la canalisation d'eau................................................... 53
Brancher le réfrigérateur......................................................................... 54
Déplacement du réfrigérateur à l'emplacement final............................. 54
Déploiement des pieds de nivellement .................................................. 55
Installation des panneaux personnalisés de la Série Overlay................ 55
Alignement et aplomb du réfrigérateur .................................................. 56
Ajustement des portes............................................................................ 56
Installation du panneau latéral................................................................ 58
Installation de la grille de la base ........................................................... 58
Achever l’installation............................................................................... 59
Préparation du système d’eau ............................................................... 59

3
REFRIGERATOR SAFETY
You can be killed or seriously injured if you don't immediately
You can be killed or seriously injured if you don't follow
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”
These words mean:
follow instructions.
instructions.
DANGER
WARNING
WARNING
Tip Over Hazard
Refrigerator is top heavy and tips easily when not
completely installed.
Keep doors taped closed until refrigerator is
completely installed.
Use two or more people to move and install
refrigerator.
Failure to do so can result in death or serious injury.

4
INSTALLATION REQUIREMENTS
Tools and Parts
IMPORTANT:
■Installer: Leave Installation Instructions with the homeowner.
■Homeowner: Keep Installation Instructions for future
reference. Save these Installation Instructions for the local
electrical inspector’s use.
TOOLS NEEDED:
Gather the required tools and parts before starting installation.
Read and follow the instructions provided with any tools listed
here.
PARTS NEEDED:
■Six #8 x 3" (7.6 cm) wood screws (longer screws may be needed)
■One or two 2" x 4" x 32" (5 cm x 10 cm x 81 cm) wood board(s)
■Order factory panels, make custom panels or consult a
qualified cabinetmaker or carpenter to make the panels.
Overlay Series: Make custom panels, or consult a qualified
cabinetmaker or carpenter to make the panels. See “Design
Specifications” for more information.
Architect®and Pro Line®Series are shipped complete.
■If you are connecting the water line directly to copper tubing
and not to a shutoff valve, you need a ferrule, a union, and a
¹⁄₄" (6.35 mm) compression fitting.
MODELS
Architect®Series
Features wraparound styling that complements the contoured door
handles. This series provides a warm commercial-looking built-in
refrigerator.
KBFC42FSS
Overlay Series
Features factory-installed, overlay style trim, to provide a
“frameless” look. This series requires the installation of custom
panels, handles, and standoffs.
KBFO42FSX
■Hand drill or electric drill
(properly grounded) ■Torx®† T27 screwdriver
■Drill bits ■¹¹⁄₃₂" nut driver
■Two adjustable wrenches ■³⁄₈",¹⁄₄", and ¹⁄₂" open-end
wrenches
■Phillips screwdriver ■⁵⁄₃₂" Allen wrench
■Small level ■¹⁄₄" and ⁵⁄₁₆" socket drivers
■Appliance dolly ■Tape measure
†®TORX is a registered trademark of Textron Innovations Inc.

5
Location Requirements
The refrigerator can be recessed in an opening between cabinets
or installed at the end of a cabinet run using a side panel to
enclose the refrigerator.
IMPORTANT:
■Observe all governing codes and ordinances.
■It is recommended that you do not install the refrigerator
near an oven, radiator, or other heat source.
■Do not install in a location where the temperature will fall
below 55°F (13°C).
■Floor must support the refrigerator weight, more than
600 lbs (272 kg), door panels and contents of the
refrigerator.
■Ceiling height must allow for side tipping radius. See
“Tipping Radius.”
■Location should permit door to open fully. See “Door
Swing Dimensions.”
■Location must permit top grille removal. See “Opening
Dimensions.”
Opening Dimensions
■The solid soffit must be within 1" (2.5 cm) maximum above the
refrigerator. If the solid soffit is higher than 1" (2.5 cm) or one is
not available, then the refrigerator must be braced to prevent
tipping during use.
If the anti-tip boards are needed, they must be attached to the
rear wall studs 80" to 90" (203 - 229 cm) above the floor. See
“Install Anti-Tip Boards” for more information.
NOTE: A clearance of ¹⁄₂" (1.3 cm) must be maintained in front
of the refrigerator’s side trim in order for the top grille to be
removed.
■A grounded 3 prong electrical outlet should be placed within
4" (10.2 cm) of the right side cabinets or end panel. See
“Electrical Requirements” for additional information.
■The water shutoff should be located in the base cabinet on
either side of the refrigerator or some other easily accessible
area. If the water shutoff valve is not in the cabinets, the
plumbing for the water line can come through the floor or the
back wall. See “Water Supply Requirements” for more specific
information.
NOTE: Flooring under refrigerator must be at same level as the
room.
WARNING
Explosion Hazard
Keep flammable materials and vapors, such as
gasoline, away from refrigerator.
Failure to do so can result in death, explosion, or fire.
¹⁄₂"
(1.3 cm)
41¹⁄₂"to 41³⁄₄"
(105.4 cm to 106.0 cm)
80" - 90"
(203-229 cm) 4"
(10.2 cm)
6"
(15.2 cm)
83¹⁄₂" (212.1 cm) min.
84³⁄₄" (215 cm) max.
to bottom of solid soffit
24"
(61 cm) min.
1"
(2.5 cm)
77"
(196 cm)
6"
(15.2 cm)
6"
(15.2 cm)

6
Electrical Requirements
Before you move your refrigerator into its final location, it is
important to make sure you have the proper electrical connection.
Recommended Grounding Method
A 115 Volt, 60 Hz., AC only 15- or 20-amp fused, grounded
electrical supply is required. It is recommended that a separate
circuit serving only your refrigerator be provided. Use an outlet
that cannot be turned off by a switch. Do not use an
extension cord.
IMPORTANT: If this product is connected to a GFCI (Ground Fault
Circuit Interrupter) protected outlet, nuisance tripping of the
power supply may occur, resulting in loss of cooling. Food quality
and flavor may be affected. If nuisance tripping has occurred, and
if the condition of the food appears poor, dispose of it.
NOTE: Before performing any type of installation, cleaning, or
removing a light bulb, remove the top grille and turn the master
power switch to OFF or disconnect power at the circuit breaker
box.
When you are finished, turn ON the master power switch or
reconnect power at the circuit breaker box. Then reset the control
to the desired setting.
Water Supply Requirements
■All installations must meet local plumbing code requirements.
■The water shutoff should be located in the base cabinet on
either side of the refrigerator or some other easily accessible
area. The right-hand side is recommended. The access hole
through the cabinet must be within ¹⁄₂" (12.7 mm) of the rear
wall.
NOTE: If the water shut off valve is in the back wall behind the
refrigerator, it must be at an angle so that the tube is not
kinked when the refrigerator is pushed into its final position.
■If the water shutoff valve is not in the cabinets, the plumbing
for the water line can come through the floor. A ¹⁄₂" (12.7 mm)
hole for plumbing should be drilled at least 6" (15.2 cm) from
the right or left hand side cabinet or panel. On the floor, the
hole should be no more than 1" (2.54 cm) away from the back
wall. See “Connect the Water Supply.”
■If additional tubing is needed, use copper tubing and check
for leaks. Install the copper tubing only in areas where the
household temperatures will remain above freezing.
■Do not use a piercing-type or ³⁄₁₆" (4.76 mm) saddle valve
which reduces water flow and clogs more easily.
NOTE: Your refrigerator dealer has a kit available with a ¹⁄₄"
(6.35 mm) saddle-type shutoff valve, a union, and copper
tubing. Before purchasing, make sure a saddle-type valve
complies with your local plumbing codes.
Water Pressure
A cold water supply with water pressure between 30 and 120 psi
(207 - 827 kPa) is required to operate the water dispenser and ice
maker. If you have questions about your water pressure, call a
licensed, qualified plumber.
Reverse Osmosis Water Supply
IMPORTANT: The pressure of the water supply coming out of a
reverse osmosis system going to the water inlet valve of the
refrigerator needs to be between 30 and 120 psi (207 - 827 kPa).
If a reverse osmosis water filtration system is connected to your
cold water supply, the water pressure to the reverse osmosis
system needs to be a minimum of 40 to 60 psi (276 - 414 kPa).
If the water pressure to the reverse osmosis system is less than
40 to 60 psi (276 - 414 kPa):
■Check to see whether the sediment filter in the reverse
osmosis system is blocked. Replace the filter if necessary.
■Allow the storage tank on the reverse osmosis system to refill
after heavy usage.
■If your refrigerator has a water filter cartridge, it may further
reduce the water pressure when used in conjunction with a
reverse osmosis system. Remove the water filter cartridge.
If you have questions about your water pressure, call a licensed,
qualified plumber.
Tipping Radius
Be sure there is adequate ceiling height to stand the refrigerator
upright when it is moved into place.
■The dolly wheel height must be added to the tipping radius
when a dolly is used.
■If needed, the tipping radius can be reduced. See “Reduce
Tipping Radius.”
Side Tipping Radius
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING
24"
(60.96 cm) min.
1"
(2.54 cm) 6"
(15.2 cm)
6"
(15.2 cm)
6"
(15.2 cm)
A. Tip this side only
93"
(236.2 cm)
A

7
Product Dimensions
Side View
■The depth from the front of the top grille to the back of the
refrigerator cabinet is 25³⁄₈" (64.4 cm).
■The power cord is 84" (213 cm) long.
■The water line attached to the back of the refrigerator is 5 ft
(1.5 m) long. Height dimensions are shown with leveling legs
extended ¹⁄₈" (3 mm) below the rollers.
*When leveling legs are fully extended to 1¹⁄₄" (3.2 cm) below
rollers, add 1¹⁄₈" (2.9 cm) to the height dimensions.
Top View
Front View
■Width dimensions were measured from trim edge to trim
edge.
■Height dimensions are shown with leveling legs extended ¹⁄₈"
(3 mm) below the rollers.
*When leveling legs are fully extended to 1¹⁄₄" (3.2 cm) below
rollers, add 1¹⁄₈" (2.9 cm) to the height dimensions.
Door Swing Dimensions
The location must permit the door to open to a minimum of 90°.
Allow 4¹⁄₂" (11.4 cm) minimum space between the side of the
refrigerator and a corner wall.
NOTE: More clearance may be required if you are using overlay
panels or custom handles.
To adjust the door swing, see “Adjust Door Swing.”
42" (106.7 cm) Models
25³⁄₈"
(64.4 cm)
23¹⁄₂"
(60 cm)
84" (213 cm)
Power Cord
*83³⁄₈"
(211.8 cm)
*3¹⁄₂" (9 cm)
25³⁄₈"
(64.5 cm)
41¹⁄₄"
(105 cm)
42¹⁄₄" (107.3 cm)
*83³⁄₈"
(211.8 cm)
110˚
90˚
130˚
110˚
90˚
13¹⁄₂"
(34.3 cm)
40⁷⁄₁₆"
(102.7 cm)
43⁷⁄₁₆"
(110.3 cm)
44¹⁄₄"
(112.3 cm)
130˚

8
Handle and Door Clearances
If you are installing custom panels, the panels must allow certain clearances for the handles and for the door to swing open. First,
determine the types of handles you will be using and the door stop setting. Then, choose the appropriate scale drawing to use as a
template for creating the panels.
NOTE: For Overlay Series models, rout the
hinge side of the custom door panels to a
radius that is equal to at least half the
thickness of the panel if a 130˚ door swing is
desired. See “Adjust Doors.”
Spacer Panel
1/4" (6.35 mm)
3/4" (1.9 cm)
1" (2.5 cm)
1/2" (1.3 cm)
1"
11/4"
11/2"
1"
(2.5 cm)
1
(3.2 cm)
1/4"
1
(3.8 cm)
1/2"
1/2"
Refrigerator
Side Trim
Door
Hinge
Backer Panel
Overlay Panel
Door Swing 110˚
Actual Size
Refrigerator to
Cabinetry Clearance
(2.5 cm)
(3.2 cm)
(3.8 cm)
(1.3 cm)
NOTE: Allow ¹⁄₂"
(1.3 cm) clearance
between overlay
panel and cabinetry.
Cabinetry
3/4"
(1.9 cm)

9
1
/ 4 " (6.35 mm)
3
/ 4 " (1.9 cm)
1" (2.5 cm)
1
/ 2 " (1.3 cm)
3
/ 4 "
1"
1
1
/ 4 "
1
1
/ 2 "
1
/ 2 "
Refrigerator
Side Trim
Door Backer Panel Overlay Panel
Hinge
Door Swing 90˚
Actual Size
Refrigerator to
Cabinetry Clearance
(1.9 cm)
(2.5 cm)
(3.8 cm)
(1.3 cm)
(3.2 cm)
Spacer Panel
Cabinetry
1
/ 2 "
3
/ 4 "
1"
(1.3 cm)
(1.9 cm)
(2.5 cm)

10
Overlay Series Custom Panels
Custom overlay panels allow you to blend the exterior of your
refrigerator into the overall kitchen décor and to use custom
handles for additional design flexibility.
The custom panels must have backer panels attached in order to
mount them to the refrigerator. It is most common to work with
three panels, as shown in the following graphic: a decorative
overlay panel, a ¹/₈" (3.18 mm) spacer panel or spacer strips and a
¹/₄" (6.35 mm) backer panel.
In some cases, your cabinet manufacturer may choose to work
with one panel routed for the different dimensions. Follow these
panel dimension and placement instructions to be sure that the
custom overlay panels will fit properly.
IMPORTANT:
■The weight of the refrigerator door overlay panel cannot
exceed 35 lbs (15.9 kg).
■The weight of the freezer drawer overlay panel cannot exceed
30 lbs (13.5 kg).
■The weight of the top grille overlay panel cannot exceed
10 lbs (4.5 kg).
To minimize panel weight, you may use 2" (5.08 cm) spacer strips
around the perimeter in place of full-sheet solid spacer panels.
The spacer strips must be set in at least 1" (2.54 cm) from the top,
bottom and side edges of the backer panel. If you use spacer
strips, it is also recommended that you use two 2" (5.08 cm) strips
horizontally centered for added support.
Custom Overlay Panel Dimensions
Overlay Panel Spacer Panel
Backer Panel
5/8" to 3/4"
(15.88 to
19.05 mm) 1/8"
(3.18 mm)
1/4"
(6.35 mm)
1" minimum
(2.54 cm)
Door/Grille Trim
Spacer Panel
Offset Dimension
1/8"
(3.18 mm)
Custom Overlay Panels Custom Backer Panels
Spacer Panels
NOTE: Spacer panels must be at least 1" (2.54 cm) from the top, bottom, and side edges of the backer panel.
403 / 8"
(102.6 cm)
20"
(50.8 cm) 20" (50.8 cm)
403 / 8"
(102.6 cm)
71 / 4"
(18.4 cm)
511 / 4"
(130.2 cm) 511
/ 4"
(130.2 cm)
201
/ 4"
(51.4 cm)
TOP GRILLE PANEL
Maximum Weight: 10 lbs (4.5 kg)
FREEZER DOOR PANEL
Maximum Weight: 30 lbs (13.6 kg)
REFRIGERATOR
DOOR PANEL
Maximum Weight:
35 lbs (15.9 kg)
REFRIGERATOR
DOOR PANEL
Maximum Weight:
35 lbs (15.9 kg)
395 / 8"
(100.6 cm)
61 / 4"
(15.9 cm)
Bottom Offset
1
/ 2" (1.27 cm)
493 / 16"
(124.93 cm)
197 / 8"
(50.48 cm)
195 / 8"
(49.85 cm)
40"
(101.6 cm)
Bottom
Offset
1
/ 2"
(1.27 cm)
493 / 16"
(124.93 cm)
Bottom
Offset
1
/ 2"
(1.27 cm)
Offset all sides
3
/ 16" (4.7 mm)
Center
Backer
Panel
left to
right
Exterior
Panel
extends
above
door.
Side Offset
3
/ 8" (9.5 mm)
195 / 8"
(49.85 cm)
Side
Offset
3
/ 16"
(4.7 mm)
Side
Offset
3
/ 16"
(4.7 mm)

11
3-Piece Grille Overlay Panel Configuration
3-Piece Door Overlay Panel Configuration
1-Piece Overlay Panel Configuration
In some cases, your cabinet manufacturer may choose to work
with one panel routed for the different dimensions. Follow these
panel dimesions and placement instructions to be sure that the
custom overlay panels will fit properly.
Architect® Series Custom Side Panels
Custom side panels may be needed when not enough space is
available to have cabinets on both sides of the refrigerator or
when the refrigerator is placed and the end of a cabinet run. You
may choose an Inset, Flush, or Recessed Inset panel installation.
Refrigerator and Side Trim Dimensions
The width and height of a side panel are determined by the type of
installation you are planning.
NOTES:
■The dimensions shown are actual product dimensions and
may not reflect the needed panel installation dimensions.
■The side panel should be a minimum of ¹⁄₂" (1.27 cm) thick
to prevent warping.
■If the opening depth is 25" (63.5 cm) or more, you may
want to install a support board on the rear wall.
Refrigerator
Side Trim
Inset Installation Dimensions
1. Measure the distance from point A (as shown) to the back
wall. Add ⁷⁄₃₂" (5.6 mm) to this measurement to allow the side
panel to fit into the trim.
2. If the panel is more than ¹⁄₄" (6.35 mm) thick, route the front
edge to allow the side panel to fit into the trim.
Flush Installation Dimensions
1. Measure the distance from point A (as shown) to the back
wall.
2. Attach the support board with a screw or adhesive that is
compatible with aluminum and wood.
Top View Side View
A. ¹₂ " (1.27 cm) Decorative
overlay panel
B.
¹₈ " (3.18 mm) Spacer panel
C.
¹₄ " (6.25 mm) Backer panel
A. Offset dimension
B.
¹₄ " (6.25 mm) Backer panel
C.
¹₈ " (3.18 mm) Spacer panel
D.
³₄ " (1.92 cm) Decorative overlay panel
1"
(2.54 cm)
¹⁄₂"
(1.27 cm)
A
B
C
1"
(2.54 cm)
DA C
B
24¹⁄₈"
(61.3 cm)
23¹⁄₂"
(59.7 cm)
23¹¹⁄₁₆"
(60.3 cm)
¹¹⁄₆₄"
(4.5 mm)
¹⁄₄"
(6.35 mm)
³⁄₁₆"
(4.7 mm)
⁷⁄₃₂"
(5.5 mm)
¹³⁄₃₂" (10 mm) ⁵⁄₈"
(15.7 mm)
A
A

12
Recessed Inset Installation Dimensions
1. Measure the distance from point A (as shown) to back wall.
2. Route the front edge of the support board or attach a ¹⁄₄"
(6.35 mm) board to hold the panel in the cabinet side trim.
Overlay Series Custom Side Panels
Custom side panels may be needed when not enough space is
available to have cabinets on both sides of the refrigerator or
when the refrigerator is placed and the end of a cabinet run. You
may choose an Inset or Recessed Inset panel installation.
Refrigerator and Side Trim Dimensions
The width and height of a side panel are determined by the type of
installation you are planning.
NOTES:
■The dimensions shown are actual product dimensions and
may not reflect the needed installation dimensions.
■The side panel should be a minimum of ¹⁄₂" (1.27 cm) thick
to prevent warping.
■If the opening depth is 25" (63.5 cm) or more, you may
want to install a support board on the rear wall.
Refrigerator
Side Trim
Inset Installation Dimensions
1. Measure the distance from point A (as shown) to the back
wall. Add ¹⁄₃₂" (0.8 mm) to this measurement to allow the side
panel to fit into the trim.
2. If the panel is more than ³⁄₈" (9.5 mm) thick, route the front
edge to allow the side panel to fit into the trim.
Recessed Inset Installation Dimensions
1. Measure the distance from point A (as shown) to back wall.
2. Route the front edge of the support board or attach a ³⁄₈"
(9.5 mm) board to hold the panel in the cabinet side trim.
A
23 ³⁄₈"
(59.40 cm)
Overlay
³⁄₁₆"
(4.5 mm)
³⁄₈"
(9.7 mm)
¹⁄₁₆"
(1.5 mm)
¹⁄₈"
(3.2 mm)
A
A

13
INSTALLATION INSTRUCTIONS
Unpack the Refrigerator
IMPORTANT:
■Do not remove the protective film until the refrigerator is in its
operating position.
■All four leveling legs must contact the floor to support and
stabilize the full weight of the refrigerator.
■Keep the cardboard shipping piece or plywood under the
refrigerator until it is installed in the operating position.
1. Remove and save the literature package and parts bag taped
to the refrigerator door. Remove the four brackets (two on
each side) that attach the shipping base to the refrigerator
bottom.
NOTE: Do not remove tape and door bracing until the
refrigerator is in its final position.
2. If necessary, reduce the tipping radius. See “Tipping Radius”
for ceiling height requirements or “Reduce Tipping Radius” for
step-by-step instructions. If you do not need to reduce the
tipping radius, proceed to “Move the Refrigerator into House.”
Reduce Tipping Radius
(if required)
Before bringing the refrigerator into the home, be sure there is
adequate ceiling height to stand the refrigerator upright. See
“Tipping Radius” in the “Design Specifications” section for more
information.
If you do not have adequate ceiling height to stand the refrigerator
upright, the tipping radius can be reduced by removing the top
grille and side trims (see the following chart).
Architect®and Overlay Series
1. Grasp both ends of the top grille.
2. Push the top grille straight up; then pull straight out. Lay the
grille on a soft surface.
3. Remove the six screws attaching each cabinet side trim to the
refrigerator and remove the side trims.
Move the Refrigerator into House
1. Place an appliance dolly under the left side of the refrigerator
as shown. Be sure to protect the side trims and handles. Place
the corner posts from the packing materials over the trims and
handles as appropriate. Slowly tighten the strap.
NOTE: Pass the dolly strap under the handles for the
Architect® Series.
Model Reduced Tipping Radius
42 88¹⁄₂" (224.8 cm)
WARNING
Tip Over Hazard
Refrigerator is top heavy and tips easily when not
completely installed.
Keep doors taped closed until refrigerator is
completely installed.
Use two or more people to move and install
refrigerator.
Failure to do so can result in death or serious injury.
A. Top grille
B. Cabinet side trim
B BA
WARNING
Tip Over Hazard
Refrigerator is top heavy and tips easily when not
completely installed.
Keep doors taped closed until refrigerator is
completely installed.
Use two or more people to move and install
refrigerator.
Failure to do so can result in death or serious injury.

14
2. Place pieces of the shipping carton on the floor when rolling
the dolly and refrigerator into the house. Move the refrigerator
close to the built-in opening.
3. Place top of cardboard carton or plywood under refrigerator.
Remove dolly.
4. Do not remove protective film or cover.
5. If necessary, reassemble the trim and top grille after the dolly
has been removed from the refrigerator.
Install Anti-Tip Boards
IMPORTANT:
■The solid soffit must be within 1" (2.5 cm) maximum above the
refrigerator. If the solid soffit is higher than 1" (2.5 cm) or one is
not available, prevent the refrigerator from tipping during use.
■It is recommended that board(s) be installed before the
refrigerator is installed.
■Board(s) must be long enough to fully cover the width of the
compressor cover.
■Locate the board(s) so the bottom surface(s) of the board(s)
is(are) 84" (213 cm) from the floor.
■During installation, raise the refrigerator up so there is ¹⁄₄"
(6.35 mm) maximum between the top of the refrigerator and
the bottom of the anti-tip board(s). Do not crush the
condenser cover when raising the rear leveling legs.
To Install Anti-tip Boards
1. Mark the stud locations on rear wall 80" to 90" (203 cm to
229 cm) above floor.
2. Securely attach one or two 2" x 4" x 32" (5 cm x 10 cm x
81 cm) boards to wall studs behind refrigerator. Use six
#8 x 3" (7.6 cm) (or longer) wood screws. The wood screws
must be screwed into the studs at least 1½" (3.8 cm). The
board(s) must overlap the compressor cover.
Connect the Water Supply
Read all directions before you begin.
IMPORTANT: If you turn the refrigerator on before the water line is
connected, turn the ice maker OFF.
Style 1 - Shutoff Valve Connection
NOTE: If your water line connection does not look like Style 1, see
“Style 2 - Copper Line Connection.”
1. Unplug refrigerator or disconnect power supply.
IMPORTANT: Before attaching the tubing to shutoff valve, flush
the main water supply line to remove particles and air in the water
line. Allow enough flow so that water becomes clear. Flushing the
water line may prevent clogged filters and/or water valves.
2. Remove the shipping tape from the gray, coiled water tubing
on the rear of the refrigerator.
3. Thread the provided nut onto the shutoff valve as shown.
4. Turn shutoff valve ON.
5. Check for leaks. Tighten any nuts or connections (including
connections at the valve) that leak.
6. Plug in the refrigerator or reconnect power.
7. Flush the water system. See “Water System Preparation.”
NOTE: Allow 24 hours to produce the first batch of ice. Discard
the first three batches of ice produced. Allow 3 days to completely
fill ice container.
Style 2 - Copper Line Connection
Connecting to Water Line
NOTE: If existing water line meets the “Water System
Requirements,” see “Connecting to Refrigerator.”
1. Unplug refrigerator or disconnect power.
2. Turn OFF main water supply. Turn ON nearest faucet long
enough to clear line of water.
3. Locate a ½" to 1¹⁄₄" (1.25 cm to 3.18 cm) vertical cold water
pipe near the refrigerator.
IMPORTANT:
■Make sure it is a cold water pipe.
■Horizontal pipe will work, but drill on the top side of the
pipe, not the bottom. This will help keep water away from
the drill and normal sediment from collecting in the valve.
4. Determine the length of copper tubing you need. Measure
from the connection on the lower left rear of refrigerator to the
water pipe. Add 7 ft (2.1 m) to allow for cleaning. Use ¹⁄₄"
(6.35 mm) O.D. (outside diameter) copper tubing. Be sure both
ends of copper tubing are cut square.
A. Center board ¹⁄₄ " (6.35 mm) max. above refrigerator
B. Two 2" x 4" x 32" (5 cm x 10 cm x 81 cm) boards
C. Attach to studs with six #8 x 3" (7.6 cm) screws
D. Compressor cover
BA
C
2" (5 cm)
D
A. Bulb
B. Nut
C. Water tubing
A
B
C

15
5. Using a grounded drill, drill a ¹⁄₄" (6.35 mm) hole in the cold
water pipe you have selected.
6. Fasten the shutoff valve to the cold water pipe with the pipe
clamp. Be sure the outlet end is solidly in the ¹⁄₄" (6.35 mm)
drilled hole in the water pipe and that the washer is under the
pipe clamp. Tighten the packing nut. Tighten the pipe clamp
screws slowly and evenly so washer makes a watertight seal.
Do not overtighten, or you may crush the copper tubing.
7. Slip the compression sleeve and compression nut on the
copper tubing as shown. Insert the end of the tubing into the
outlet end squarely as far as it will go. Screw compression nut
onto outlet end with adjustable wrench. Do not overtighten the
clamp or the sleeve. This will crush the copper tubing.
IMPORTANT: Before attaching the tubing to shutoff valve, flush
the main water supply line to remove particles and air in the water
line. Allow enough flow so that water becomes clear. Flushing the
water line may prevent clogged filters and/or water valves.
8. Turn off the shutoff valve on the water pipe. Coil the copper
tubing.
9. Check for leaks around the saddle valve.
Connecting to Refrigerator
1. Unplug the refrigerator or disconnect power.
2. Remove the shipping tape from the gray, coiled water tubing
on the rear of the refrigerator.
3. Measure the distance from the shutoff valve to the opening in
which the refrigerator will be located. Tubing must be
extended from the shutoff valve into the refrigerator opening
following specific guidelines. See “Water Supply
Requirements.”
4. A ¹⁄₄" x ¹⁄₄" (6.35 mm to 6.35 mm) coupling is needed in order
to connect the water tubing to an existing household water
line. Thread the provided nut onto the coupling on the end of
the copper tubing.
5. Turn shutoff valve ON.
6. Check for leaks. Tighten any nuts or connections (including
connections at the valve) that leak.
7. Plug in the refrigerator or reconnect power.
8. Flush the water system. See “Water System Preparation.”
NOTE: Allow 24 hours to produce the first batch of ice. Discard
the first three batches of ice produced. Allow 3 days to completely
fill ice container.
Plug in Refrigerator
1. Set control switch at top of cabinet to the OFF position.
2. Plug into a grounded 3 prong outlet.
Move Refrigerator to Final Location
IMPORTANT: To prevent floor damage, make sure levelers are
raised (not touching floor) and refrigerator is on rollers before
moving.
1. Place top of cardboard carton or plywood under refrigerator.
Remove dolly.
2. Do not remove protective film or cover.
3. Move the refrigerator straight back and evenly into the
opening. Be sure that cabinet side trims are not interfering
with door opening. Be sure that water tubing is not kinked and
the power supply cord is on top of the refrigerator.
A. Cold water pipe
B. Pipe clamp
C. Copper tubing
D. Compression nut
E. Compression sleeve
F. Shutoff valve
G. Packing nut
A. Water tubing
B. Nut
C. Bulb
D. Coupling (purchased)
E. Ferrule (purchased)
F. Nut (purchased)
G. Household water line (as
connected in previous section)
A
B
C
DEF
G
A B C D E F G
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING
WARNING
Tip Over Hazard
Refrigerator is top heavy and tips easily when not
completely installed.
Keep doors taped closed until refrigerator is
completely installed.
Use two or more people to move and install
refrigerator.
Failure to do so can result in death or serious injury.

16
Lower Leveling Legs
NOTE: All four leveling legs must contact the floor to support and
stabilize the full weight of refrigerator. Rollers are for moving
refrigerator and not for permanent support.
Use a ⁵⁄₁₆" socket wrench to turn the leveling bolts clockwise to
lower the 4 leveling legs until refrigerator weight is supported by
leveling legs. The rollers should be off the floor. To avoid cabinet
damage, do not apply more than 50 inch-pounds (58 cm - kg) of
torque to the leveling legs.
Install Overlay Series Custom Panels
IMPORTANT:
■Install the custom handles prior to installing the panels on
the refrigerator. For more information on KitchenAid
custom handle selection, refer to the KitchenAid Catalog,
visit www.kitchenaid.com, or call 1-800-422-1230.
In Canada, visit www.KitchenAid.ca, or call
1-800-807-6777.
■Create custom door overlay panels according to the
specifications in the “Overlay Series Custom Panels”
section.
■KitchenAid is not responsible for the removal or addition of
molding or decorative panels that would prevent the
refrigerator from being serviced.
Door Panel Installation
1. Remove all tape and door bracing from the refrigerator door
and freezer drawer.
2. Open the refrigerator doors and freezer drawer and remove
the trims and corner caps on each door as shown.
3. Slide the custom panels into the trims on the refrigerator door
and freezer drawer, making sure that the backer panel fits into
the hinge side trims.
A. Panels
4. Reinstall the trims and corner caps.
5. Remove the protective skin from the screw covers. Snap the
screw covers into the handle trim section.
Top Grille Panel
1. Grasp both ends of the top grille.
2. Push straight up; then pull straight out. Place the top grille
panel-side down on a soft working surface.
A. Rear leveling legs
B. Front leveling legs
A. Corner caps
B. Refrigerator door trims
C. Freezer drawer trim
A B
A
B
B
A
B
A
C
AA
A. Top grille
B. Cabinet side trims
AA
B BA

17
3. Remove one end cap by loosening the nuts and sliding the
end cap off.
4. Slide the custom panel into the top grille channel and reattach
the end cap.
5. Replace the top grille in the cabinet side trims and pull the
panel down slightly to lock it into place.
Level and Align Refrigerator
NOTE: Leveling legs can be extended a maximum of 1¹⁄₄"
(3.18 cm) below the rollers. Adjustments may have to be done in
increments to keep from damaging the cab trim. Rotating the
leveling bolts clockwise extends the leveling legs and raises the
product.
1. Continue adjusting leveling legs to raise the refrigerator to the
anti-tip position. See “Install Anti-tip Boards.”
2. Level/align the refrigerator from left to right by using leveling
bolts to adjust the front (and rear) leveling legs.
3. Level the product from front to back and align with the
cabinetry face.
4. Be sure that all four leveling legs contact the floor and support
the full weight of the refrigerator.
5. Make final check to ensure the refrigerator is level and aligned
and is in the proper anti-tip position.
Adjust Doors
Door Height Adjustment
Use the following steps to adjust the door height, up or down,
after the refrigerator has been leveled.
NOTE: Adjust the right door to the position of the left door first. If
it is necessary to adjust the left door, you must make sure that the
hinged center rail located on the left-hand door does not drag
when closing the door.
1. Open the freezer drawer. Remove the locking plate screw from
the bottom side of the refrigerator door hinge using a
¹⁄₄" open-end wrench.
2. Remove the locking plate as shown.
3. Turn the bushing located underneath the bottom of the hinge
using a ¹⁄₂" open-end wrench. Turning the bushing to the left
will lower the door. Turning the bushing right will raise the
door.
4. After adjusting, check the doors to make sure they are even at
the top and bottom. If the doors are not even, continue to turn
the bushing to adjust the door.
5. Replace the locking plate.
■Turn the bushing slightly to align the hinge and locking
plate screw holes.
■Replace and tighten the locking plate screw.
6. Make final check to make sure the doors are aligned and
even.
Door Swing Adjustment
1. Check that the refrigerator door can open freely. If the door
opens too wide, you will have to adjust the door stop position.
2. Grasp both ends of the top grille.
A. Bottom rail
B. Nuts
C. End cap
D. Top rail
A. Custom panel
A. Top grille
B. Cabinet side trims
A. Rear leveling bolt
B. Front leveling bolt
C
B
A
D
A
B BA
A B
A
B
A. Bushing
B. Locking plate
C. Locking plate screw
BCA

18
3. Push the top grille straight up; then pull straight out. Lay the
grille on a soft surface.
4. The door stop is located on the top hinge.
5. Remove the 2 door stop screws.
■To remove the outer screw (“A”):
With the door closed, firmly press the L-shaped bracket
towards the center of the refrigerator until the screw is
exposed.
■To remove the inner screw (“B”):
Open the door 90° and the L-shaped bracket will expose
the screw.
6. Reverse or rotate the door stop to the desired position as
shown below.
NOTE: For Overlay Series models, rout the hinge side of the
custom door panels to a radius that is equal to at least half the
thickness of the panel if a 130° door swing is desired.
7. Replace the door stop screws and tighten.
8. Check that the door can open freely.
Install Side Panel
If the built-in area depth is 25" (63.5 cm) or more, the side panels
can be installed inside the side trim or attached to the outside of
the side trim.
IMPORTANT: KitchenAid is not responsible for the removal or
addition of molding or decorative panels that would prevent the
refrigerator from being serviced.
1. For the inside side trim piece, slide the front edge of the
routed side panel into the trim piece.
2. Nail the rear edge of the panel to the support board.
A. Top grille
B. Cabinet side trims
A. Door stop screw “A”
B. Door stop screw “B”
C. Door stop
A. Door stop screw “A”
B. Door stop screw “B”
B BA
B
A
C
A
B
130° 110°
90° 90°
Left-hand as shown; Right-hand reversed
A. Support board
B. Side trim piece
A
B

19
Install Base Grille
There are two pieces to the base grille to allow for a custom fit: the
base grille itself and the skirt. The skirt can be added to the base
grille in order to extend it all the way to the floor.
1. To see if the skirt is needed, place the base grille into position.
Do not attach the base grille to the appliance. Measure the
distance between the bottom of the base grille and the floor.
The gap must be a minimum of ¹⁄₂" (1.27 cm) in order to add
the skirt.
NOTE: If the gap measures less than ¹⁄₂" (1.27 cm), skip
steps 3 and 4 of the instructions, and install the base grille
only.
2. Remove the protective film from the base grille.
3. Snap the skirt onto the base grille.
4. Trim the skirt by scoring the proper “V” groove with a utility
knife. Break the skirt at the score line.
5. Using the two screws, attach the base grille assembly to the
appliance as shown.
6. Install the water filter and rotate it one-quarter turn to the right.
It may be hard to turn. The cap should be in the horizontal
position.
Complete Installation
1. Turn the water supply line valve to the “Open” position.
2. Turn the refrigerator switch to the ON position. See “Power
On/Off Switch” in the Use & Care Guide for instructions. Wait
a few minutes. Check the water line connections for leaks.
3. Remove all boxes, parts packages and packing materials from
the interior of the refrigerator. See the “Cleaning” section in
the Use & Care Guide for instructions. Remove the protective
film and cardboard from the grille and doors or door frame,
depending on your model.
4. Install the shelves and bins in the refrigerator and freezer
compartments.
5. The controls are preset at the factory to the midpoint setting.
Check to be sure that the compressor is operating properly
and that all the lights are working.
6. If construction will continue after the refrigerator has been
installed, set the controls to OFF.
To get the most efficient use from your new built-in refrigerator,
read your Use & Care Guide. Keep Installation Instructions and
Use & Care Guide near the built-in refrigerator for easy reference.
Water System Preparation
Please read before using the water system.
Immediately after installation, follow the steps below to make sure
that the water system is properly cleaned.
1. Turn off the ice maker. Slide the ice maker ON/OFF control,
located on the left-hand side of the ice bin, to the OFF (down)
position as shown.
NOTES:
■If your model has a base grille filter system, make sure the
base grille filter is properly installed and the cap is in the
horizontal position.
■Do not use with water that is microbiologically unsafe or
of unknown quality without adequate disinfection before
or after the system. Systems certified for cyst reduction
may be used on disinfected waters that may contain
filterable cysts.
2. Turn on the ice maker. Slide the ice maker ON/OFF control,
located on the left-hand side of the ice bin, to the ON (up)
position. Please refer to “Ice Maker and Storage Bin” for
further instructions on the operation of your ice maker.
■Allow 24 hours to produce the first batch of ice.
■Discard the first three batches of ice produced.
A. Base grille
B. Skirt
A. “V” groove
A. Screws (2)
A
B
A
A
A. ON/OFF control
A

20
SEGURIDAD DEL REFRIGERADOR
Si no sigue las instrucciones de inmediato, usted puede
morir o sufrir una lesión grave.
Si no sigue las instrucciones, usted puede morir o sufrir
una lesión grave.
Todos los mensajes de seguridad le dirán el peligro potencial, le dirán cómo reducir las posibilidades de sufrir una lesión y lo que
puede suceder si no se siguen las instrucciones.
Su seguridad y la seguridad de los demás es muy importante.
Hemos incluido muchos mensajes importantes de seguridad en este manual y en su electrodoméstico. Lea y obedezca siempre
todos los mensajes de seguridad.
ADVERTENCIA
PELIGRO
Este es el símbolo de advertencia de seguridad.
Este símbolo le llama la atención sobre peligros potenciales que pueden ocasionar la muerte o una lesión a
usted y a los demás.
Todos los mensajes de seguridad irán a continuación del símbolo de advertencia de seguridad y de la palabra
“PELIGRO”o “ADVERTENCIA”. Estas palabras significan:
ADVERTENCIA
Peligro de Vuelco
El refrigerador puede volcarse cuando estásiendo
instalado debido a que la parte superior es pesada.
Mantenga las puertas cerradas con cinta hasta que el
refrigerador estécompletamente instalado.
Use dos o más personas para mover e instalar el
refrigerador.
No seguir estas instrucciones puede ocasionar
la muerte o herida seria.
