KitchenAid KBFC42FTS - 42" Bottom Mount Refrigerator User manual

BOTTOM-MOUNT
BUILT-IN REFRIGERATOR
Installation Guide
IMPORTANT: READ AND SAVE THESE INSTRUCTIONS. INSTALLATION REQUIRES 2 OR MORE PEOPLE.
REFRIGERADOR EMPOTRADO
CON MONTAJE INFERIOR
Manual de instalación
IMPORTANTE: LEA Y GUARDE ESTAS INSTRUCCIONES. LA INSTALACIÓN REQUIERE DE 2 O MÁS PERSONAS.
RÉFRIGÉRATEUR ENCASTRÉ AVEC
CONGÉLATEUR EN DESSOUS
Guide d’installation
IMPORTANT : LIRE ET CONSERVER CES INSTRUCTIONS. L’INSTALLATION NÉCESSITE L’INTERVENTION DE 2 PERSONNES OU PLUS.
Table of Contents/Índice/Table des matières..................................................................2
W10291425A

2
TABLE OF CONTENTS
REFRIGERATOR SAFETY........................................................................... 3
MODELS....................................................................................................... 4
INSTALLATION REQUIREMENTS ............................................................. 5
Tools and Parts......................................................................................... 5
Location Requirements............................................................................. 5
Electrical Requirements............................................................................ 6
Water Supply Requirements..................................................................... 7
Tipping Radius .......................................................................................... 8
Product Dimensions ................................................................................. 8
Door Swing Dimensions ........................................................................... 9
Overlay Series Door Panel & Cabinetry Clearance
(36" [91.4 cm] Models)............................................................................10
Overlay Series Door Panel & Cabinetry Clearance
(42" [106.7 cm] Models)..........................................................................12
Overlay Series Custom Panels ...............................................................14
Custom Overlay Panel Dimensions........................................................14
Classic, Architect®, and Overlay Series Factory Panels and Kits
(36" [91.4 cm] Models)............................................................................16
Classic Series Custom Panels (36" [91.4 cm] Models).......................... 16
Classic and Architect® Series Custom Side Panels ............................... 17
Overlay Series Custom Side Panels....................................................... 18
INSTALLATION INSTRUCTIONS............................................................. 20
Unpack the Refrigerator ......................................................................... 20
Reduce Tipping Radius .......................................................................... 20
Move the Refrigerator into House .......................................................... 20
Install Anti-Tip Boards ............................................................................ 21
Connect the Water Supply ..................................................................... 21
Plug in Refrigerator................................................................................. 23
Move Refrigerator to Final Location....................................................... 23
Level and Align Refrigerator ................................................................... 23
Install Overlay and Classic Series Custom Panels ................................ 24
Adjust Door(s) ......................................................................................... 25
Install Side Panel .................................................................................... 27
Install Base Grille .................................................................................... 27
Complete Installation.............................................................................. 28
ÍNDICE
SEGURIDAD DEL REFRIGERADOR........................................................30
MODELOS..................................................................................................31
REQUISITOS DE INSTALACIÓN..............................................................32
Piezas y herramientas.............................................................................32
Requisitos de ubicación .........................................................................32
Requisitos eléctricos...............................................................................34
Requisitos del suministro de agua .........................................................34
Arco de vuelco ........................................................................................35
Medidas del producto.............................................................................35
Medidas de oscilación de la puerta........................................................36
Espacio para el panel de la puerta de la serie Overlay
y para los gabinetes (modelos de 36" [91,4 cm])...................................37
Espacio para el panel de la puerta de la serie Overlay y
para los gabinetes (modelos de 42" [106,7 cm])....................................39
Paneles a la medida de la Serie Overlay ................................................41
Dimensiones del panel recubierto a la medida ......................................41
Paneles y juegos de fábrica para las Series Classic, Architect®
y Overlay (modelos de 36" [91,4 cm]) ....................................................43
Paneles a la medida para la Serie Classic
(modelos de 36" [91,4 cm])..................................................................... 43
Paneles laterales a la medida para las Series Classic y Architect®........ 45
Paneles laterales a la medida para la Serie Overlay .............................. 45
INSTRUCCIONES DE INSTALACIÓN...................................................... 47
Desempaque el refrigerador................................................................... 47
Cómo reducir el arco de vuelco ............................................................. 47
Cómo hacer entrar el refrigerador en la casa ........................................ 48
Cómo instalar los tableros antivuelco .................................................... 48
Conexión del suministro de agua........................................................... 49
Cómo enchufar el refrigerador ............................................................... 50
Cómo mover el refrigerador a su ubicación final ................................... 51
Nivelación y alineamiento del refrigerador............................................. 51
Cómo instalar los paneles a la medida para
las Series Overlay y Classic.................................................................... 52
Cómo ajustar la(s) puerta(s).................................................................... 53
Cómo instalar el panel lateral ................................................................. 55
Cómo instalar la rejilla de la base........................................................... 56
Cómo terminar la instalación.................................................................. 56
TABLE DES MATIÈRES
SÉCURITÉ DU RÉFRIGÉRATEUR ...........................................................58
MODÈLES ..................................................................................................59
EXIGENCES D’INSTALLATION................................................................60
Outillage et pièces ..................................................................................60
Exigences d’emplacement .....................................................................60
Spécifications électriques ......................................................................62
Spécifications de l’alimentation en eau..................................................62
Rayon de basculement...........................................................................63
Dimensions du produit............................................................................63
Dimensions pour le pivotement des portes ...........................................64
Série Overlay - Panneau de porte et placard –
dimensions et espace libre (modèles de 36" [91,4 cm]) ........................65
Série Overlay - Panneau de porte et placard –
dimensions et espace libre (modèles de 42" [106,7 cm]) ......................67
Panneaux personnalisés de la série Overlay..........................................69
Panneaux personnalisés - Dimensions ..................................................69
Ensembles de panneaux d'origine de la série Classic, Architect®
et Overlay (modèles de 36" [91,4 cm]) ...................................................71
Panneaux personnalisés de la série Classic
(modèles de 36" [91.4 cm]).................................................................... 71
Panneaux latéraux personnalisés des séries Classic et Architect®....... 72
Panneaux latéraux personnalisés de la série Overlay............................ 73
INSTRUCTIONS D’INSTALLATION ......................................................... 75
Déballage du réfrigérateur...................................................................... 75
Réduction du rayon de basculement ..................................................... 75
Faire entrer le réfrigérateur dans le domicile.......................................... 75
Installation de planches antibasculement.............................................. 76
Raccordement à l'alimentation en eau................................................... 76
Brancher le réfrigérateur......................................................................... 78
Déplacement du réfrigérateur à l'emplacement final............................. 78
Réglage de l'aplomb et alignement du réfrigérateur.............................. 78
Installation des panneaux personnalisés des séries Overlay et Classic 79
Ajustement de la (des) porte(s)............................................................... 80
Installation du panneau latéral................................................................ 82
Installation de la grille de la base ........................................................... 83
Achever l’installation............................................................................... 83

3
REFRIGERATOR SAFETY
You can be killed or seriously injured if you don't immediately
You can be killed or seriously injured if you don't follow
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”
These words mean:
follow instructions.
instructions.
DANGER
WARNING
WARNING
Tip Over Hazard
Refrigerator is top heavy and tips easily when not
completely installed.
Keep doors taped closed until refrigerator is
completely installed.
Use two or more people to move and install
refrigerator.
Failure to do so can result in death or serious injury.

4
MODELS
Architect®Series (36" [91.4 cm] Models)
Features wraparound styling that complements the contoured
door handles. This series provides a warm commercial-looking
built-in refrigerator.
KBRC36FTS KBLC36FTS
Classic Series (36" [91.4 cm] Models)
Features traditional style trim, factory-installed, to provide a
“framed” look. This series requires the installation of custom panels
that are not included.
KBRS36FTB KBRS36FTX KBLS36FTB
KBLS36FTX
Overlay Series (36" [91.4 cm] Models)
Features factory-installed, overlay style trim, to provide a
“frameless” look. This series requires the installation of custom
panels, handles, and standoffs.
KBRO36FTX KBLO36FTX
Architect®Series (42" [106.7 cm] Models)
Features wraparound styling that complements the contoured door
handles. This series provides a warm commercial-looking built-in
refrigerator.
KBFC42FTS

5
INSTALLATION
REQUIREMENTS
Tools and Parts
IMPORTANT:
■Installer: Leave Installation Instructions with the homeowner.
■Homeowner: Keep Installation Instructions for future
reference. Save these Installation Instructions for the local
electrical inspector’s use.
TOOLS NEEDED:
Gather the required tools and parts before starting installation.
Read and follow the instructions provided with any tools listed
here.
PARTS NEEDED:
■Six #8 x 3" (7.6 cm) wood screws (longer screws may be needed)
■One or two 2" x 4" x 32" (5 cm x 10 cm x 81 cm) wood board(s)
■Order factory panels, make custom panels or consult a
qualified cabinetmaker or carpenter to make the panels.
Classic Series: Order factory panels, make custom panels, or
consult a qualified cabinetmaker or carpenter to make the
panels. See “Installation Requirements” for more information.
Overlay Series: Make custom panels, or consult a qualified
cabinetmaker or carpenter to make the panels. See
“Installation Requirements” for more information.
Architect®Series is shipped complete.
■If you are connecting the water line directly to copper tubing
and not to a shutoff valve, you need a ferrule, a union, and a
¹⁄₄" compression fitting.
Location Requirements
The refrigerator can be recessed in an opening between cabinets
or installed at the end of a cabinet run using a side panel to
enclose the refrigerator.
IMPORTANT:
■Observe all governing codes and ordinances.
■It is recommended that you do not install the refrigerator near
an oven, radiator, or other heat source.
■Do not install in a location where the temperature will fall
below 55°F (13°C).
■Floor must support the refrigerator weight, more than 600 lbs
(272 kg), door panels and contents of the refrigerator.
■Ceiling height must allow for side tipping radius. See “Tipping
Radius.”
■Location should permit door to open fully. See “Door Swing
Dimensions.”
■Location must permit top grille removal. See “Opening
Dimensions.”
Opening Dimensions
■To avoid tipping during use, the solid soffit must be within 1"
(2.5 cm) maximum above the refrigerator. If the solid soffit is
higher than 1" (2.5 cm) or one is not available, then the
refrigerator must be braced.
If the anti-tip boards are needed, they must be attached to the
rear wall studs 80" to 90" (203 to 229 cm) above the floor. See
“Install Anti-Tip Boards” for more information.
Overlay Series (42" [106.7 cm] Models)
Features factory-installed, overlay style trim, to provide a
“frameless” look. This series requires the installation of custom
panels, handles, and standoffs.
KBFO42FTX
■Cordless drill ■Torx®† T15 and T27 screwdrivers
■Drill bits ■¹¹⁄₃₂" nut driver
■Two adjustable
wrenches ■³⁄₈", ¹⁄₄", and ¹⁄₂" open-end wrenches
■Phillips screwdriver ■⁵⁄₃₂" Allen wrench
■Small level ■¹⁄₄" and ⁵⁄₁₆" socket drivers
■Appliance dolly ■Tape measure
■Utility knife
†®TORX is a registered trademark of Textron Innovations Inc.
WARNING
Explosion Hazard
Keep flammable materials and vapors, such as
gasoline, away from refrigerator.
Failure to do so can result in death, explosion, or fire.

6
NOTE: A clearance of ¹⁄₂" (1.3 cm) must be maintained in front
of the refrigerator’s side trim in order for the top grille to be
removed.
■A grounded 3 prong electrical outlet should be placed within
4" (10.2 cm) of the right side cabinets or end panel. See
“Electrical Requirements” for additional information.
■The water shutoff should be located in the base cabinet on
either side of the refrigerator or some other easily accessible
area. If the water shutoff valve is not in the cabinets, the
plumbing for the water line can come through the floor or the
back wall. See “Water Supply Requirements” for more specific
information.
NOTE: Flooring under refrigerator must be at same level as the
room.
Electrical Requirements
Before you move your refrigerator into its final location, it is
important to make sure you have the proper electrical connection.
Recommended Grounding Method
A 115 Volt, 60 Hz., AC only, 15- or 20-amp fused, grounded
electrical supply is required. It is recommended that a separate
circuit serving only your refrigerator be provided. Use an outlet
that cannot be turned off by a switch. Do not use an
extension cord.
IMPORTANT: If this product is connected to a GFCI (Ground Fault
Circuit Interrupter) protected outlet, nuisance tripping of the
power supply may occur, resulting in loss of cooling. Food quality
and flavor may be affected. If nuisance tripping has occurred, and
if the condition of the food appears poor, dispose of it.
NOTE: Before performing any type of installation, cleaning, or
removing a light bulb, remove the top grille and turn the master
power switch to OFF or disconnect power at the circuit breaker
box.
When you are finished, turn ON the master power switch or
reconnect power at the circuit breaker box. Then reset the control
to the desired setting.
Model Width A (as shown above)
36
42 35¹⁄₂" (90.2 cm) 41¹⁄₂" (105.4 cm)
¹⁄₂"
(1.3 cm)
80" - 90"
(203-229 cm) 4"
(10.2 cm)
6"
(15.2 cm)
83¹⁄₂" (212.1 cm) min.
84³⁄₄" (215 cm) max.
to bottom of solid soffit
24"
(60.96 cm) min.
1"
(2.54 cm)
77"
(196 cm)
6"
(15.2 cm)
6"
(15.2 cm)
A
Width
(see chart following)
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING

7
Water Supply Requirements
■All installations must meet local plumbing code requirements.
■The water shutoff should be located in the base cabinet on
either side of the refrigerator or some other easily accessible
area. The right-hand side is recommended. The access hole
through the cabinet must be within ¹⁄₂" (12.7 mm) of the rear
wall.
NOTE: If the water shutoff valve is in the back wall behind the
refrigerator, it must be at an angle so that the tube is not
kinked when the refrigerator is pushed into its final location.
■If the water shutoff valve is not in the cabinets, the plumbing
for the water line can come through the floor. A ¹⁄₂" (12.7 mm)
hole for plumbing should be drilled at least 6" (15.2 cm) from
the right or left hand side cabinet or panel. On the floor, the
hole should be no more than 1" (2.54 cm) away from the back
wall. See “Connect the Water Supply.”
■If additional tubing is needed, use copper tubing and check
for leaks. Install the copper tubing only in areas where the
household temperatures will remain above freezing.
■Do not use a piercing-type or ³⁄₁₆" (4.76 mm) saddle valve
which reduces water flow and clogs more easily.
NOTE: Your refrigerator dealer has a kit available with a ¹⁄₄"
(6.35 mm) saddle-type shutoff valve, a union, and copper
tubing. Before purchasing, make sure a saddle-type valve
complies with your local plumbing codes.
Water Pressure
A cold water supply with water pressure between 30 and 120 psi
(207 and 827 kPa) is required to operate the water dispenser and
ice maker. If you have questions about your water pressure, call a
licensed, qualified plumber.
Reverse Osmosis Water Supply
IMPORTANT: The pressure of the water supply coming out of a
reverse osmosis system going to the water inlet valve of the
refrigerator needs to be between 30 and 120 psi
(207 and 827 kPa).
If a reverse osmosis water filtration system is connected to your
cold water supply, the water pressure to the reverse osmosis
system needs to be a minimum of 40 to 60 psi (276 to 414 kPa).
If the water pressure to the reverse osmosis system is less than
40 to 60 psi (276 to 414 kPa):
■Check to see whether the sediment filter in the reverse
osmosis system is blocked. Replace the filter if necessary.
■Allow the storage tank on the reverse osmosis system to refill
after heavy usage.
■If your refrigerator has a water filter cartridge, it may further
reduce the water pressure when used in conjunction with a
reverse osmosis system. Remove the water filter cartridge.
If you have questions about your water pressure, call a licensed,
qualified plumber.
24"
(60.96 cm) min.
1"
(2.54 cm) 6"
(15.2 cm)
6"
(15.2 cm)
6"
(15.2 cm)

8
Tipping Radius
Be sure there is adequate ceiling height to stand the refrigerator
upright when it is moved into place.
■The dolly wheel height must be added to the tipping radius
when a dolly is used.
■If needed, the tipping radius can be reduced. See “Reduce
Tipping Radius.”
Side Tipping Radius (36" [91.4 cm] Models)
Side Tipping Radius (42" [106.7 cm] Models)
Product Dimensions
Side View
■The depth from the front of the top grille to the back of the
refrigerator cabinet is 25³⁄₈" (64.5 cm).
■The power cord is 84" (213 cm) long.
■The water line attached to the back of the refrigerator is 5 ft
(1.5 m) long. Height dimensions are shown with leveling legs
extended ¹⁄₈" (3 mm) below the rollers.
*When leveling legs are fully extended to 1¹⁄₄" (3.2 cm) below
rollers, add 1¹⁄₈" (2.9 cm) to the height dimensions.
Top View
36" (91.4 cm) Models
42" (106.7 cm) Models
Front View
■Width dimensions were measured from trim edge to trim
edge.
■Height dimensions are shown with leveling legs extended ¹⁄₈"
(3 mm) below the rollers.
A. Tip this side only.
A. Tip this side only.
90¹⁄₂"
(229.9 cm)
A
93"
(236.2 cm)
A
A
23¹⁄₂"
(59.7 cm)
84" (213.4 cm)
Power Cord
*83³⁄₈"
(211.8 cm)
*3¹⁄₂" (8.9 cm)
25³⁄₈"
(64.5 cm)
35¹⁄₄"
(89.5 cm)
25³⁄₈"
(64.5 cm)
41¹⁄₄"
(105 cm)

9
36" (91.4 cm) Models
*When leveling legs are fully extended to 1¹⁄₄" (3.2 cm) below
rollers, add 1¹⁄₈" (2.9 cm) to the height dimensions.
42" (106.7 cm) Models
*When leveling legs are fully extended to 1¹⁄₄" (3.2 cm) below
rollers, add 1¹⁄₈" (2.9 cm) to the height dimensions.
Door Swing Dimensions
The location must permit the door to open to a minimum of 90°.
Allow 4¹⁄₂" (11.4 cm) minimum space between the side of the
refrigerator and a corner wall.
NOTE: More clearance may be required if you are using overlay
panels or custom handles.
To adjust the door swing, see “Adjust Door Swing.”
36" (91.4 cm) Models
42" (106.7 cm) Models
36¹⁄₄" (92 cm)
*83³⁄₈"
(211.8 cm)
42¹⁄₄" (107.3 cm)
*83³⁄₈"
(211.8 cm)
110˚
90˚
23"
(58 cm)
max.
51"
(130 cm)
59"
(150 cm)
130˚
110˚
90˚
130˚
110˚
90˚
13¹⁄₂"
(34.3 cm)
max.
40⁷⁄₁₆"
(102.7 cm)
44¹⁄₄"
(112.3 cm)
130˚

10
Overlay Series Door Panel & Cabinetry Clearance (36" [91.4 cm] Models)
The custom door panels and adjacent cabinetry must be designed so that there is sufficient clearance for the doors to swing open. If
the refrigerator is to be installed close to the wall, see “Door Swing 90°” on next page.
When the doors are closed the refrigerator will extend beyond the face of the adjacent cabinetry to some degree.
NOTE: For Overlay Series models, rout the
hinge side of the custom door panels to a
radius that is equal to at least half the
thickness of the panel if a 130˚ door swing is
desired. See “Adjust Doors.”
Spacer Panel
1/4" (6.35 mm)
3/4" (1.9 cm)
1" (2.5 cm)
1/2" (1.3 cm)
1"
11/4"
11/2"
1"
(2.5 cm)
1
(3.2 cm)
1/4"
1
(3.8 cm)
1/2"
1/2"
Refrigerator
Side Trim
Door
Hinge
Backer Panel
Overlay Panel
Door Swing 110˚
Actual Size
Refrigerator to
Cabinetry Clearance
(2.5 cm)
(3.2 cm)
(3.8 cm)
(1.3 cm)
NOTE: Allow ¹⁄₂"
(1.3 cm) clearance
between overlay
panel and cabinetry.
Cabinetry
3/4"
(1.9 cm)

11
Allow a minimum of 4¹⁄₂" (11.4 cm) of space between the side of the refrigerator and a corner wall. More clearance may be needed if
thicker custom panels or custom handles are used. Do not overlook baseboards.
1/4" (6.35 mm)
3/4" (1.9 cm)
1" (2.5 cm)
1/2" (1.3 cm)
3/4"
1"
11/4"
11/2"
1/2"
Refrigerator
Side Trim
Door Backer Panel Overlay Panel
Hinge
Door Swing 90˚
Actual Size
Refrigerator to
Cabinetry Clearance
(1.9 cm)
(2.5 cm)
(3.8 cm)
(1.3 cm)
(3.2 cm)
Spacer Panel
Cabinetry
1/2"
3/4"
1"
(1.3 cm)
(1.9 cm)
(2.5 cm)
90˚ Door
Stop Position

12
Overlay Series Door Panel & Cabinetry Clearance (42" [106.7 cm] Models)
The custom door panels and adjacent cabinetry must be designed so that there is sufficient clearance for the doors to swing open. If
the refrigerator is to be installed close to the wall, see “Door Swing 90°” on next page.
When the doors are closed the refrigerator will extend beyond the face of the adjacent cabinetry to some degree.
NOTE: For Overlay Series models, rout the
hinge side of the custom door panels to a
radius that is equal to at least half the
thickness of the panel if a 130˚ door swing is
desired. See “Adjust Doors.”
Spacer Panel
1/4" (6.35 mm)
3/4" (1.9 cm)
1" (2.5 cm)
1/2" (1.3 cm)
1"
11/4"
11/2"
1"
(2.5 cm)
1
(3.2 cm)
1/4"
1
(3.8 cm)
1/2"
1/2"
Refrigerator
Side Trim
Door
Hinge
Backer Panel
Overlay Panel
Door Swing 110˚
Actual Size
Refrigerator to
Cabinetry Clearance
(2.5 cm)
(3.2 cm)
(3.8 cm)
(1.3 cm)
NOTE: Allow ¹⁄₂"
(1.3 cm) clearance
between overlay
panel and cabinetry.
Cabinetry
3/4"
(1.9 cm)

13
Allow a minimum of 4¹⁄₂" (11.4 cm) of space between the side of the refrigerator and a corner wall. More clearance may be needed if
thicker custom panels or custom handles are used. Do not overlook baseboards.
1/4" (6.35 mm)
3/4" (1.9 cm)
1" (2.5 cm)
1/2" (1.3 cm)
3/4"
1"
11/4"
11/2"
1/2"
Refrigerator
Side Trim
Door Backer Panel Overlay Panel
Hinge
Door Swing 90˚
Actual Size
Refrigerator to
Cabinetry Clearance
(1.9 cm)
(2.5 cm)
(3.8 cm)
(1.3 cm)
(3.2 cm)
Spacer Panel
Cabinetry
1/2"
3/4"
1"
(1.3 cm)
(1.9 cm)
(2.5 cm)
90˚ Door
Stop Position

14
Overlay Series Custom Panels
Custom overlay panels allow you to blend the exterior of your
refrigerator into the overall kitchen décor and to use custom
handles for additional design flexibility.
The custom panels must have backer panels attached in order to
mount them to the refrigerator. It is most common to work with
three panels, as shown in the following graphic: a decorative
overlay panel, a ¹/₈" (3.18 mm) spacer panel or spacer strips and a
¹/₄" (6.35 mm) backer panel.
In some cases, your cabinet manufacturer may choose to work
with one panel routed for the different dimensions. Follow these
panel dimension and placement instructions to be sure that the
custom overlay panels will fit properly.
IMPORTANT:
■For 36" (91.4 cm) models, the refrigerator door overlay panel
cannot exceed 50 lbs (23 kg) and the freezer drawer overlay
panel cannot exceed 20 lbs (9.1 kg).
■For 42" (106.7 cm) models, the refrigerator door overlay panel
cannot exceed 30 lbs (13.5 kg) and the freezer drawer overlay
panel cannot exceed 25 lbs (11.4 kg).
■The weight of the top grille overlay panel cannot exceed
10 lbs (4.5 kg) for both models.
To minimize panel weight, you may use 2" (5.08 cm) spacer strips
around the perimeter in place of full-sheet solid spacer panels.
The spacer strips must be set in at least 1" (2.54 cm) from the top,
bottom and side edges of the backer panel. If you use spacer
strips, it is also recommended that you use two 2" (5.08 cm) strips
horizontally centered for added support.
Custom Overlay Panel Dimensions
Overlay Panel Spacer Panel
Backer Panel
5/8" to 3/4"
(15.88 to
19.05 mm) 1/8"
(3.18 mm)
1/4"
(6.35 mm)
1" minimum
(2.54 cm)
Door/Grille Trim
Spacer Panel
Offset Dimension
1/8"
(3.18 mm)
Overlay Panel
Backer Panel
Custom Overlay Panels (36" [91.4 cm] Models) Custom Backer Panels (36" [91.4 cm] Models)
34³⁄₄"
(88.27 cm)
7¹⁄₄"
(18.42 cm)
34³⁄₄"
(88.27 cm)
34³⁄₄"
(88.27 cm)
51¹⁄₈"
(129.86 cm)
20³⁄₄"
(52.71 cm)
TOP GRILLE PANEL
Maximum Weight: 10 lbs (4.5 kg)
FREEZER DOOR PANEL
Maximum Weight: 20 lbs (9.1 kg)
REFRIGERATOR DOOR PANEL
Maximum Weight: 50 lbs (23 kg)
33³⁄₄"
(85.73 cm)
6³⁄₁₆"
(15.72 cm)
Bottom Offset
³⁄₈" (9.5 mm)
49¹⁄₈"
(124.78 cm)
20³⁄₁₆"
(51.28 cm)
34¹⁄₄"
(87.00 cm)
34¹⁄₄"
(87.00 cm)
Bottom Offset
⁷⁄₁₆" (11.1 mm)
Bottom Offset
¹⁄₄" (6.35 mm)
Center
Backer
Panel
left to
right
Center
Backer
Panel
left to
right
Center
Backer
Panel
left to
right

15
3-Piece Grille Overlay Panel Configuration 3-Piece Door Overlay Panel Configuration
1-Piece Overlay Panel Configuration
In some cases, your cabinet manufacturer may choose to work
with one panel routed for the different dimensions. Follow these
panel dimensions and placement instructions to be sure that the
custom overlay panels will fit properly.
Custom Overlay Panels (42" [106.7 cm] Models) Custom Backer Panels (42" [106.7 cm] Models)
Spacer Panels (All models)
NOTE: Spacer panels must be at least 1" (2.54 cm) from the top, bottom, and side edges of the backer panel.
40 ⁷⁄₁₆ "
(102.7 cm)
20"
(50.8 cm) 20" (50.8 cm)
40 ⁷⁄₁₆ "
(102.7 cm)
7 ¹⁄₄ "
(18.4 cm)
51 ¹⁄₄ "
(130.2 cm) 51
¹⁄₄ "
(130.2 cm)
20
¹⁄₄ "
(51.4 cm)
TOP GRILLE PANEL
Maximum Weight: 10 lbs (4.5 kg)
FREEZER DOOR PANEL
Maximum Weight: 25 lbs (11.4 kg)
REFRIGERATOR
DOOR PANEL
Maximum Weight:
30 lbs (13.5 kg)
REFRIGERATOR
DOOR PANEL
Maximum Weight:
30 lbs (13.5 kg)
395 / 8"
(100.6 cm)
61 / 4"
(15.9 cm)
Bottom Offset
1
/ 2" (1.27 cm)
493 / 16"
(124.93 cm)
197 / 8"
(50.48 cm)
195 / 8"
(49.85 cm)
40"
(101.6 cm)
Bottom
Offset
1
/ 2"
(1.27 cm)
493 / 16"
(124.93 cm)
Bottom
Offset
1
/ 2"
(1.27 cm)
Offset all sides
3
/ 16" (4.7 mm)
Exterior
Panel
extends
above
door.
Side Offset
3
/ 8" (9.5 mm)
195 / 8"
(49.85 cm)
Side
Offset
3
/ 16"
(4.7 mm)
Side
Offset
3
/ 16"
(4.7 mm)
Top View Side View
A. Offset dimension
B.
¹₄ " (6.25 mm) Backer panel
C.
¹₈ " (3.18 mm) Spacer panel
D.
³₄ " (1.92 cm) Decorative
overlay panel
1"
(2.54 cm)
D
C
B
A
A. Offset dimension
B.
¹₄ " (6.25 mm) Backer panel
C.
¹₈ " (3.18 mm) Spacer panel
D.
³₄ " (1.92 cm) Decorative overlay panel
1"
(2.54 cm)
DA C
B

16
Classic, Architect®, and Overlay Series
Factory Panels and Kits
(36" [91.4 cm] Models)
All factory parts are available through your KitchenAid dealer or by
calling KitchenAid Parts and Accessories at 1-800-442-9991. In
Canada, call 1-800-807-6777.
Factory Door Panel Kits
Three kits containing colored acrylic or stainless steel door and
top grille panels are available. Follow the kit instructions for
installing the panels.
NOTE: Panel kits are not required for factory-installed stainless
steel panel models.
Architect®Series 72" (183 cm) Top Grille Panel Kit
A 72" (183 cm) wide Top Grille Panel Kit is available. This kit allows
2 units (one left-hand swing and one right-hand) to be installed
side by side with a single grille.
Extended Door Handle Kits
Use extended door handles when additional finger clearance is
needed between the door handles and custom panel. Follow the
kit instructions for installing the door handles.
Classic Series Custom Panels
(36" [91.4 cm] Models)
If you plan to install custom wood panels, you will need to create
the panels yourself or consult a qualified cabinetmaker or
carpenter. See dimension drawings for panel specifications.
IMPORTANT: Panels weighing more than recommended may
cause damage to your refrigerator.
NOTE: Dimensions shown have a (±)¹⁄₁₆" (1.5 mm) tolerance.
Panels that are more than ¹⁄₄" (6.35 mm) thick must be routed. If
panels are less than ¹⁄₄" (6.35 mm) thick, install a filler panel
between the door and the decorative panel.
Top Grille Panel
The top panel should not weigh more than 10 lbs (4.5 kg).
Refrigerator and Freezer Panels
The freezer panel should not weigh more than 20 lbs (9.1 kg). The
refrigerator panel should not weigh more than 50 lbs (22 kg).
Color 36" (91.4 cm)
White #W10163652
Black #W10163654
Stainless Steel #W10163656
Color 72" (183 cm)
Stainless Steel (Architect®Series) #W10153554
Color Left-Hand Swing Right-Hand
Swing
White (Classic
Series) #4396119 #8171424
Black (Classic
Series) #4396116 #8171427
Stainless Steel
(Classic Series) #4396118 #8171425
Matte Aluminum
Etched (Classic
Series)
#4396120 #8171423
Matte Aluminum
(Overlay Series) #4396718
34¹⁄₂"
(87.63 cm)
7¹⁄₄"
(18.4 cm)
34¹⁄₄"
(87 cm)
34¹⁄₄"
(87 cm)
49"
(124.5 cm)
20¹⁄₈"
(51.1 cm)

17
Top Grille Panel – Routing Requirements
If the custom panels are thicker than ¹⁄₄" (6.35mm), the top and
bottom edges of the top panel should be edge routed ¹⁄₂"
(1.27 cm) and ³⁄₈" (9.5 mm), respectively. Both ends should be
edge routed ⁷⁄₈" (2.2 cm) as shown.
NOTE: When creating a panel with face detail, the offsets will be
hidden and must be accounted for in order to center the detail in
the top grille.
Door Panel – Routing Requirements
If the custom panels are thicker than ¹⁄₄" (6.35 mm), then all edges
of the panels must be routed. If the standard handle is used, rout
the entire handle side of both panels 3¹⁄₄" (8.25 cm) to allow for
finger clearance. Then rout the hinge side of the refrigerator panel
1" (2.54 cm). Rout both sides of the freezer panel 1" (2.54 cm).
Standard Handle – Top View
If an extended handle kit is used, rout the handle side ¹⁄₄"
(6.35 mm). All other routing dimensions would remain the same as
the standard handle. Make sure your product location will allow
doors with extended handles to be opened to 90 degrees. See
“Door Swing Dimensions.”
For more information on ordering extended handles, see “Classic
Series Factory Panels and Kits.”
NOTE: For both types of handles, rout the top and bottom edges
of the refrigerator panel ¹⁄₂" (1.27 cm). Rout the bottom of the
freezer panel ¹⁄₂" (1.27 cm).
Door Panel - Side View
Extended Handle - Top View
Classic and Architect® Series
Custom Side Panels
Custom side panels may be needed when not enough space is
available to have cabinets on both sides of the refrigerator or
when the refrigerator is placed and the end of a cabinet run. You
may choose an Inset, Flush, or Recessed Inset panel installation.
Refrigerator and Side Trim Dimensions
The width and height of a side panel are determined by the type of
installation you are planning.
NOTES:
■The dimensions shown are actual product dimensions and
may not reflect the needed panel installation dimensions.
■The side panel should be a minimum of ¹⁄₂" (1.27 cm) thick
to avoid warping.
■If the opening depth is 25" (63.5 cm) or more, you may
want to install a support board on the rear wall.
¹⁄₄"
(6.35 mm)
max.
⁷⁄₈"
(2.2 cm)
Top
Grille
¹⁄₄"
(6.35 mm)
max.
⁷⁄₈"
(2.2 cm)
Top
Grille
¹⁄₂"
(1.3 cm)
min.
¹⁄₄"
(6.35 mm) max.
Top
Bottom
³⁄₈"
(9.5 mm)
min.
¹⁄₄"
(6.35 mm) max.
Center face
detail between
offsets
2" (5 cm)
min.
¹⁄₄" (6.35 mm) max.
3¹⁄₄"
(8.25 cm)
min.
Door
Panel
Handle
1"
(2.54 cm)
Door
Panel
Hinge Side
¹⁄₂" (1.3 cm)
min.
¹⁄₄"
(6.35 mm)
max.
Panel
¹⁄₄"
(6.35 mm)
Door
Panel
Handle
1"
(2.54 cm)
Door
Panel
Hinge Side
1"
(2.54 cm)
max

18
Refrigerator
Side Trim
Inset Installation Dimensions
1. Measure the distance from point A (as shown) to the back
wall. Add ⁷⁄₃₂" (5.6 mm) to this measurement to allow the side
panel to fit into the trim.
2. If the panel is more than ¹⁄₄" (6.35 mm) thick, rout the front
edge to allow the side panel to fit into the trim.
Flush Installation Dimensions
1. Measure the distance from point A (as shown) to the back
wall.
2. Attach the support board with a screw or adhesive that is
compatible with aluminum and wood.
Recessed Inset Installation Dimensions
1. Measure the distance from point A (as shown) to back wall.
2. Rout the front edge of the support board or attach a ¹⁄₄"
(6.35 mm) board to hold the panel in the cabinet side trim.
Overlay Series Custom Side Panels
Custom side panels may be needed when not enough space is
available to have cabinets on both sides of the refrigerator or
when the refrigerator is placed and the end of a cabinet run. You
may choose an Inset or Recessed Inset panel installation.
Refrigerator and Side Trim Dimensions
The width and height of a side panel are determined by the type of
installation you are planning.
NOTES:
■The dimensions shown are actual product dimensions and
may not reflect the needed installation dimensions.
■The side panel should be a minimum of ¹⁄₂" (1.27 cm) thick
to avoid warping.
■If the opening depth is 25" (63.5 cm) or more, you may
want to install a support board on the rear wall.
Refrigerator (36" [91.4 cm] Models)
24¹⁄₈"
(61.3 cm)
23¹⁄₂"
(59.7 cm)
23¹¹⁄₁₆"
(60.3 cm)
¹¹⁄₆₄"
(4.5 mm)
¹⁄₄"
(6.35 mm)
³⁄₁₆"
(4.7 mm)
⁷⁄₃₂"
(5.5 mm)
¹³⁄₃₂" (10 mm) ⁵⁄₈"
(15.7 mm)
A
A
A
23¹¹⁄₁₆"
(60.16 cm)
Overlay

19
Refrigerator (42" [106.7 cm] Models)
Side Trim (36" [91.4 cm] Models)
Side Trim (42" [106.7 cm] Models)
Inset Installation Dimensions
36" [91.4 cm] Models
1. Measure the distance from point A (as shown) to the back
wall. Add ¹⁄₃₂" (0.8 mm) to this measurement to allow the side
panel to fit into the trim.
2. If the panel is more than ³⁄₈" (9.5 mm) thick, rout the front edge
to allow the side panel to fit into the trim
42" [106.7 cm] Models
1. Measure the distance from point A (as shown) to the back
wall. Add ¹⁄₃₂" (0.8 mm) to this measurement to allow the side
panel to fit into the trim.
2. If the panel is more than ³⁄₈" (9.5 mm) thick, rout the front edge
to allow the side panel to fit into the trim
Recessed Inset Installation Dimensions
36" [91.4 cm] Models
1. Measure the distance from point A (as shown) to back wall.
2. Rout the front edge of the support board or attach a ³⁄₈"
(9.5 mm) board to hold the panel in the cabinet side trim.
42" [106.7 cm] Models
1. Measure the distance from point A (as shown) to back wall.
2. Rout the front edge of the support board or attach a ³⁄₈"
(9.5 mm) board to hold the panel in the cabinet side trim.
23³⁄₈"
(59.40 cm)
Overlay
³⁄₁₆"
(4.5 mm)
³⁄₈"
(9.7 mm)
¹⁄₁₆"
(1.5 mm)
³⁄₃₂"
(2.38 mm)
³⁄₁₆"
(4.5 mm)
³⁄₈"
(9.7 mm)
¹⁄₁₆"
(1.5 mm)
¹⁄₈"
(3.2 mm)
A
A
A
A

20
INSTALLATION INSTRUCTIONS
Unpack the Refrigerator
IMPORTANT:
■Do not remove the film until the refrigerator is in its operating
position.
■All four leveling legs must contact the floor to support and
stabilize the full weight of the refrigerator.
■Keep the cardboard shipping piece or plywood under the
refrigerator until it is installed in the operating position.
1. Remove and save the literature package bag taped to the side
of the refrigerator and the parts bag behind the grille. Remove
the four brackets (two on each side) that attach the shipping
base to the refrigerator bottom.
NOTE: Do not remove tape and door bracing until the
refrigerator is in its final position.
2. If necessary, reduce the tipping radius. See “Tipping Radius”
for ceiling height requirements or “Reduce Tipping Radius” for
step-by-step instructions. If you do not need to reduce the
tipping radius, proceed to “Move the Refrigerator into House.”
Reduce Tipping Radius
(if required)
Before bringing the refrigerator into the home, be sure there is
adequate ceiling height to stand the refrigerator upright. See
“Tipping Radius” in the “Installation Requirements” section for
more information.
If you do not have adequate ceiling height to stand the refrigerator
upright, the tipping radius can be reduced by removing the top
grille and side trims (see the following chart).
1. Grasp both ends of the top grille.
2. Push the top grille straight up; then pull straight out. Lay the
grille on a soft surface.
3. Remove the six screws attaching each cabinet side trim to the
refrigerator and remove the side trims.
Move the Refrigerator into House
1. Place an appliance dolly under the left side of the refrigerator
as shown. Be sure to protect the side trims and handles. Place
the corner posts from the packing materials over the trims and
handles as appropriate. Slowly tighten the strap.
NOTE: Pass the dolly strap under the handles.
36" (91.4 cm) Models
Model Reduced Tipping Radius
36 88" (223.5 cm)
42 88¹⁄₂" (224.8 cm)
WARNING
Tip Over Hazard
Refrigerator is top heavy and tips easily when not
completely installed.
Keep doors taped closed until refrigerator is
completely installed.
Use two or more people to move and install
refrigerator.
Failure to do so can result in death or serious injury.
A. Top grille
B. Cabinet side trim
B BA
WARNING
Tip Over Hazard
Refrigerator is top heavy and tips easily when not
completely installed.
Keep doors taped closed until refrigerator is
completely installed.
Use two or more people to move and install
refrigerator.
Failure to do so can result in death or serious injury.
