KitchenAid KBRA20EMBT User manual

Kitchen_kid _
BOTTOM-MOUNT REFRIGERATOR
For questions about features, operation/performance, par_s accessories or service, call: 1-800-422-1230
In Canada, call for assistance 1-800-461-5681, for installation and service, call: 1-800-807-6777 or visit our website at...
www.kitchenaid.com or www.KitchenAid.ca
P P P
REFRIGERATEUR SUPERPOS E
( :_,I. <)11_:d I. [ I _'.._al_oi_eli <II........
Au Canada, pour assistance composez le 1-800-461-5681, pour installation ou service composez le 1-800-807-6777 ou visitez notre site web &...
www.KitchenAid.ca
Table of Contents/Table des matieres ............................................................................. 2
12642709SP/2225031A

TABLE OF CONTENTS
REFRIGERATOR SAFETY .......................................................... 3
Proper Disposal of Your Old Refrigerator .................................... 3
REFRIGERATOR INSTALLATION ................................................. 4
Unpacking .................................................................................... 4
Location Requirements ................................................................ 4
Electrical Requirements ............................................................... 5
Water Supply Connection ............................................................ 5
Base Grille .................................................................................... 6
Refrigerator Doors ........................................................................ 7
Door Closing and Alignment ...................................................... 11
Water System Preparation ......................................................... 11
Factory Trim Kit.......................................................................... 12
Normal Sounds .......................................................................... 13
REFRIGERATOR USE .................................................................. 14
Ensuring Proper Air Circulation .................................................. 14
Using the Controls ..................................................................... 14
Adjusting Control Settings ......................................................... 14
Water Dispenser ......................................................................... 15
Interior Water Filtration System ................................................. 15
Ice Maker .................................................................................... 15
REFRIGERATOR FEATURES ...................................................... 16
Refrigerator Shelves ................................................................... 16
Meat Drawer and Cover ............................................................. 16
Crisper and Crisper Cover ......................................................... 17
Crisper Humidity Control ........................................................... 17
Utility or Egg Bin......................................................................... 17
FREEZER FEATURES .................................................................. 17
Freezer Baskets .......................................................................... 17
Ice Shelf ...................................................................................... 18
DOOR FEATURES ........................................................................ 18
Door Retainer ............................................................................. 18
Door Bins.................................................................................... 18
Utility Compartment ................................................................... 18
REFRIGERATOR CARE ............................................................... 19
Cleaning ...................................................................................... 19
Changing the Light Bulb ............................................................ 19
Power Interruptions .................................................................... 20
Vacation and Moving Care ......................................................... 20
TROUBLESHOOTING .................................................................. 20
ASSISTANCE OR SERVICE ......................................................... 22
In the U.S.A ................................................................................ 22
In Canada ................................................................................... 23
Accessories ................................................................................ 23
WATER FILTER CERTIFICATIONS ............................................. 23
PERFORMANCE DATA SHEETS ............................................. 24
WARRANTY .............................................................................. 25
TABLE DES MATIERES
SI_CURITI_ DU RI_FRIGI_RATEUR ........................................... 27
Mise au rebut de votre vieux refrigerateur ................................. 27
INSTALLATION DU RI_FRIGI_RATEUR ...................................... 28
Deballage .................................................................................... 28
Emplacement d'installation ........................................................ 28
Specifications electriques .......................................................... 29
Raccordement de la canalisation d'eau .................................... 29
Grille de la base .......................................................................... 30
Portes du refrigerateur ............................................................... 31
Fermeture et alignement des portes .......................................... 35
Preparation du systeme d'eau ................................................... 35
Ensemble decoratif de I'usine .................................................... 36
Sons normaux ............................................................................ 37
UTILISATION DU RI_FRIGI_RATEUR .......................................... 38
Pour s'assurer d'une circulation d'air appropriee ...................... 38
Utilisation des commandes ........................................................ 38
Ajustement des reglages de commande ................................... 39
Distributeur d'eau ....................................................................... 39
Systeme de filtration d'eau interieur .......................................... 39
Machine a gla(_ons ..................................................................... 40
CARACTI_RISTIQUES BU RI_FRIGI_RATEUR ........................... 40
Tablettes du refrigGrateur ........................................................... 40
Tiroira viande et couvercle ........................................................ 41
Bac a legumes et couvercle ....................................................... 41
Reglage de I'humidite darts le bac a legumes ........................... 42
Casier utilitaire ou oeufrier .......................................................... 42
CARACTI_RISTIQUES BU CONGI_LATEUR ............................... 42
Paniers de congelateur .............................................................. 42
Tablette a gla_ons ...................................................................... 43
CARACTI_RISTIQUES BE LA PORTE ......................................... 43
Dispositif de retenue de la porte ................................................ 43
Balconnets dans la porte ........................................................... 43
Compartiment utilitaire ............................................................... 43
ENTRETIEN BU RI_FRIGI_RATEUR ............................................ 44
Nettoyage ................................................................................... 44
Remplacement de I'ampoule d'eclairage .................................. 44
Pannes de courant ..................................................................... 45
Entretien avant les vacances ou Iors d'un demenagement .......45
DCPANNAGE ................................................................................. 46
ASSISTANCE OU SERVICE ......................................................... 49
Accessoires ................................................................................ 49
FEUILLES DE DONNI_ES SUR LE PRODUIT .......................... 50
GARANTIE ................................................................................. 51

REFRIGERATOR SAFETY
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance, Always read and obey all
safety messages,
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word "DANGER" or
"WARNING," These words mean:
You can be killed or seriously injured if you don't
immediately follow instructions.
You can be killed or seriously injured if you don't
follow instructions.
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you
what can happen if the instructions are not followed.
IMPORTANT SAFETY INSTRUCTIONS
WARNING: To reduce the risk of fire, electric shock, or injury when using your refrigerator, follow these basic
precautions:
• Plug into a grounded 3 prong outlet.
• Do not remove ground prong.
• Do not use an adapter.
• Do not use an extension cord.
• Disconnect power before servicing.
• Use nonflammable cleaner.
• Keep flammable materials and vapors, such as
gasoline, away from refrigerator.
• Use two or more people to move and install
refrigerator.
• Disconnect power before installing ice maker (on
Replace all panels before operating, ice maker kit ready models only).
Remove doors from your old refrigerator.
SAVE THESE INSTRUCTIONS
Proper Disposal of
Your Old Refrigerator
Before you throw away your old refrigerator or freezer:
• Take off the doors.
• Leave the shelves in place so that children may not easily
climb inside.
Suffocation Hazard
Remove doors from your old refrigerator.
Failure to do so can result in death or
brain damage.
IMPORTANT: Child entrapment and suffocation are not problems
of the past. Junked or abandoned refrigerators are still dangerous
- even if they will sit for "just a few days." If you are getting rid of
your old refrigerator, please follow these instructions to help
prevent accidents.

REFRIGERATOR
INSTALLATION
Excessive Weight Hazard
Use two or more people to move and install
refrigerator.
Failure to do so can result in back or other injury.
Removing packaging materials
•Remove tape and glue residue from surfaces before turning
on the refrigerator. Rub a small amount of liquid dish soap
over the adhesive with your fingers. Wipe with warm water
and dry.
Do not use sharp instruments, rubbing alcohol, flammable
fluids, or abrasive cleaners to remove tape or glue. These
products can damage the surface of your refrigerator. For
more information, see the "Refrigerator Safety" section.
On some models, shelves, bins, door shelf rails, and other
feature parts may be packaged in the Interior FeaturePak.
Follow the instructions contained in the package for proper
assembly.
Depending on your model, to remove the protective
(transparent) film that is on the nameplate, which is located
on the freezer handle, use your fingernail and peel off the film,
starting from one side and peeling to the other.
IMPORTANT: Do not remove the white foam air return insert that
is located behind the control panel on the ceiling of the
refrigerator (on some models). The insert is part of the refrigerator
and not part of the packing material. If the insert is removed, ice
may migrate down from the freezer and cause icicles to form.
When Moving Your Refrigerator:
Your refrigerator is heavy= When moving the refrigerator
for cleaning or service, be sure to protect the floor=
Always pulI the refrigerator straight out when moving it=
Do not wiggle or "walk" the refrigerator when trying to move
it, as floor damage could occur=
Cleaning before use
After you remove all of the package materials, clean the inside of
your refrigerator before using it. See the cleaning instructions in
the "Refrigerator Care" section.
_mportant information to know about glass shemves
and covers:
Do not cIean glass shelves or covers with warm water when
they are cold. Shelves and covers may break if exposed to
sudden temperature changes or impact, such as bumping=
For your protection, tempered gIass is designed to shatter
into many small, pebble-size pieces. This is normal= GIass
shelves and covers are heavy= Use special care when re-
moving them to avoid impact from dropping=
E×pJosion Hazard
Keep flammabJe materiaJs and vapors, such as
gasoline, away from refrigerator.
Failure to do so can resuJt in death, explosion,
or fire.
Your refrigerator does not require clearance on the top, back,
or sides, but many factors such as subflooring or floor
covering may affect your installation opening. Measure
carefully.
• If you are installing your refrigerator next to a fixed wall, leave
2Y8in. (5.4 cm) minimum on each side (depending on your
model) to allow for the door to swing open.
2_"(5.4 cm)
• If your refrigerator has an ice maker, make sure you leave
some extra space at the back for the water line connections.
NOTE: Do not install the refrigerator near an oven, radiator, or
other heat source, nor in a location where the temperature will fall
below 55°F (13°C).

• .........
EJectrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in
death, fire, or eJectricaJ shock.
Before you move your refrigerator into its final location, it is
important to make sure you have the proper electrical
connection:
Recommended grounding method
A 115 Volt, 60 Hz., AC only 15 or 20 ampere fused, grounded
electrical supply is required. It is recommended that a separate
circuit serving only your refrigerator be provided. Use an outlet
that cannot be turned off by a switch. Do not use an
extension cord.
NOTE: Before performing any type of installation, cleaning, or
removing a light bulb, turn the control (Thermostat, Refrigerator
or Freezer Control depending on the model) to OFF and then
disconnect the refrigerator from the electrical source. When you
are finished, reconnect the refrigerator to the electrical source
and reset the control (Thermostat, Refrigerator or Freezer Control
depending on the model) to the desired setting.
Read all directions carefully before you begin.
IMPORTANT."
• If operating the refrigerator before installing the water
connection, turn ice maker to the OFF position (arm up) to
prevent operation without water.
• All installations must be in accordance with local plumbing
code requirements.
• Use copper tubing and check for leaks.
• Install copper tubing only in areas where temperatures will
remain above freezing.
• It may take up to 24 hours for your ice maker to begin
producing ice.
Tools required:
• Flat-blade screwdriver • Center punch
• _/2in. open-end wrench or • Bucket
adjustable wrench
•Y4in. and %6in. drill bit • Towel
• Hand drill or electric drill • Gloves
(properly grounded)
• Hammer
NOTE: Your refrigerator dealer has a kit available with a 1/4in.
(6.35 ram) saddle-type shutoff valve, a union, and copper tubing.
Before purchasing, make sure a saddle-type valve complies with
your local plumbing codes. Do not use a piercing-type or 3/_6in.
(4.76 mm) saddle valve which reduces water flow and clogs more
easily.
Cold Water Supply
The ice maker water valve contains a flow washer which is used
as a water pressure regulator. The ice maker needs to be
connected to a cold water line with water pressure between
20 and 120 psi (140-827 kPa). If a problem occurs, call your utility
company.
Connecting to Water Line
1.
2.
3=
Unplug refrigerator or disconnect power.
Turn OFF main water supply. Turn ON nearest faucet long
enough to clear line of water.
Find a _/2in. to 1V4in. (12.7 mm to 3.18 mm) vertical COLD
water pipe near the refrigerator.
NOTE: Horizontal pipe will work, but the following procedure
must be followed: Drill on the top side of the pipe, not the
bottom. This will help keep water away from the drill. This
also keeps normal sediment from collecting in the valve.

4. Todeterminethelengthofcoppertubingyouwillneed,
measurefromconnectiononlowerleftrearofrefrigeratorto
waterpipe.Add7ft.(2.1m)toallowformovingrefrigerator
forcleaning.Use1/4in,(6.35mm)O.D.(outsidediameter)
coppertubing.Besurebothendsofcoppertubingarecut
square.
5. Useahammerandcenterpunchtomarkdrillinglocationon
waterpipe.Usingagroundeddrill,drilla1/4in.holeinthecold
waterpipeyouhaveselected.
%
........t ..................................................................... 1
!i"
34
5
6
7
1. Cold Water Pipe
2. Pipe Clamp
3. Copper Tubing
4. Compression Nut
5. Compression Sleeve
6. Shutoff Valve
7. Packing Nut
6. Fasten shutoff valve to cold water pipe with pipe clamp. Be
sure outlet end is solidly in the 1/4in. drilled hole in the water
pipe and that rubber washer is under the pipe clamp. Tighten
packing nut, Tighten the pipe clamp screws carefully and
evenly so rubber washer makes a watertight seal, Do not
overtighten or you may crush the copper tubing, especially if
soft (coiled) copper tubing is used, Now you are ready to
connect the copper tubing.
7. Slip compression sleeve and compression nut on copper
tubing as shown, Insert end of tubing into outlet end squarely
as far as it will go, Screw compression nut onto outlet end
with adjustable wrench. Do not overtighten.
8. Place the free end of the tubing into a bucket or sink, Turn ON
main water supply and flush out tubing until water is clear.
Turn OFF shutoff valve on the water pipe, Check for leaks,
Coil copper tubing.
Connecting to Refrigerator
1= Remove plastic cap from water valve inlet port. Attach the
copper tube to the valve inlet using a compression nut and
sleeve as shown, Tighten the compression nut. Do not
overtighten. Confirm copper tubing is secure by pulling on
copper tubing.
2. Create a service loop using extreme care to avoid kinks.
Secure copper tubing to refrigerator cabinet with a "P"
clamp.
1. Copper Tubing
2. "P" Clamp
3. Compression Nut
4. Compression Sleeve
5. Water Valve Inlet Port
3. Turn on water supply to refrigerator and check for leaks.
Correct any leaks,
4. Plug in refrigerator or reconnect power.
5. Push refrigerator into opening.
Removing the base grille
1. Grasp the grille with both hands.
2. Pull up on the bottom and tilt it toward you,
3. Pull down to release the top of the grille.
Replacing the base grille
1. See markings on inside of base grille for proper placement.
2. Snap the top of the grille into place first.
3. Press down and in on the bottom of the grille until it snaps
into place,

Handle Removal (Architect ®Series)
(Graphics are included later in this section.)
1. Using a %2in. Allen wrench, loosen the 2 set screws located
on the side of each handle.
2. Pull handle straight out from the door. Make sure you keep
screws for reattaching handles.
Handle Removal (Panel Series}
IMPORTANT:
• Remove door from refrigerator before removing handle.
• You must remove handles to remove decorator panels or to
reverse the door swing.
1. Using a Phillips screwdriver, remove top door cap.
2. Tap bottom edge of refrigerator door handle upward with a
rubber mallet.
3. Handle will slide up approximately 3/4in. (19.05 mm) and
release from door.
Handle Replacement (Panel Series}
1. Make sure bottom door cap is installed.
2. Align handle notches with metal mounting tabs on side of
door. Slide handle down until it locks.
3. Tap top of handle with a rubber mallet to ensure snug fit.
4. Using a Phillips screwdriver, reinstall top door cap.
Freezer Drawer Removal
(Graphics are included later in this section.)
1. Open freezer drawer to full extension.
2. Remove all articles from baskets.
3. Slide top wire basket out to full extension and lift out to
remove.
4. Remove the bottom wire basket by pressing the release
button on each side and lifting the basket from the rail guides.
l /
/
/
/
/
/
/
/
1..........................................................................................................................................._ ,/
/
/
/
/
1. Release button
5=
6=
Remove the Phillips screw (on some models) from each side
of drawer rail assembly (see Graphic 6-1).
NOTE: Do not remove hex-head screws from rail assembly.
Lift front handle of freezer drawer to disengage drawer rail
hooks from interior rail assembly. Lift drawer out.
Freezer Drawer Replacement
IMPORTANT: Two individuals may be required to complete this
procedure.
1. Extend both interior rail assemblies to full length on each side
of cabinet.
2. Locate notches in both interior rail extensions (see
Graphic 6-2).
3. Align tabs on outside edge of drawer rail assemblies with
notches in both rail extensions.
4. Insert tabs into notches (see Graphic 6-3).
5. Replace the Phillips screws (on some models) on both rail
extensions (see Graphic 6-1).
6. Replace bottom basket by placing basket into rail guides.
7. Slide top basket into upper compartment.
Door and Hinge Removal
IMPORTANT:
• Before you begin, turn the refrigerator control OFF, unplug
refrigerator or disconnect power. Remove food and any
adjustable door or utility bins from doors.
• All graphics referenced in the following instructions are
included later in this section after "Final Steps."
_s" Hex-Head Top Hinge Screw
Tools Needed: %6in., % in., ¼ in. hex-head socket wrench, No. 2
Phillips screwdriver, and a flat-head screwdriver.
1. Keep the refrigerator door closed until you are ready to lift it
free from the cabinet.
NOTE: Provide additional support for the refrigerator door
while the hinges are being moved. Do not depend on the door
gasket magnets to hold the door in place while you are
working.
2. Remove the parts for the top hinge as shown in Top Hinge
Graphic. Lift the refrigerator door free from the cabinet.
3. Remove the parts for the bottom hinge as shown in the
Bottom Hinge Graphic.

Door Reversal (on some Architect _ Series models)
IMPORTANT:
• Stainless steel refrigerator doors are not reversible.
• If you want to reverse your non-stainless steel doors so they
open from the opposite side, follow these steps. Ifyou are not
reversing the doors, see "Door and Hinge Replacement."
• You must first remove the handle from panel series
refrigerator doors to reverse the door swing.
Door Stop Screw Door HandTeSeat Screw Front
F/at Head Handle Screw Cabinet Hinge Hole Plug
Cabinet
1. Remove the hinge screws from handle side and move them
to opposite side (see Graphic 1-1).
2. Remove cabinet hinge hole plugs from cabinet top with flat
blade screwdriver tip wrapped in masking tape and move
them to opposite side hinge holes as shown (see
Graphic 1-2).
Refrigerator door
1. Remove refrigerator handle assembly including the mounting
posts and screws. Keep all parts together (see Graphic 2).
2. Remove door handle seal screw front. Move to opposite side
of refrigerator door as shown (see Graphic 5).
3. Remove door stop from bottom edge of refrigerator door.
Move to opposite side of refrigerator door as shown (see
Graphic 3).
4. Attach door handle mounting posts to opposite side of the
door.
5. Position refrigerator handle over mounting posts as shown
(see Graphic 2). Drive two set screws in sides of handle.
6. Tighten all screws. Set aside door until hinges and freezer
compartment door are in place.
Door Reversal (Panel Series)
(Graphics are included later in this section.)
1. Remove cabinet hinge hole plugs with flat blade of
screwdriver wrapped in masking tape. Move to opposite side
of cabinet (see Graphic 1-2).
2. Remove the hinge screws. Move to the opposite side of
cabinet (see Graphic 1-1).
3. Using a Phillips screwdriver, remove the door stop and door
cap located on the bottom edge of the refrigerator
compartment (see Graphic 4).
4. Using a Phillips screwdriver, remove top door cap.
5. Remove 1/4in. hex-head screws from top door extension.
Reverse top door extension so notched corner turns in
toward interior of door (see Graphic 2).
6. Remove side door trim and handle trim by tapping bottom
edges upward with a soft rubber mallet. Trim will slide up and
release from door (see Graphic 3).
7. Replace bottom door cap and install door stop on opposite
side of door.
8. Using the alternate side door trim, shipped with the
refrigerator, align notches on trim with metal mounting tabs
on side of door. Slide trim down until it locks into place. Tap
top of trim with rubber mallet to ensure snug fit.
9. Install handle by aligning handle notches with metal mounting
tabs on side of door. Slide handle down until it locks. Tap top
of handle with rubber mallet to ensure snug fit.
10. Using a Phillips screwdriver, install top door cap.
Door and Hinge Replacement
NOTE: When reversing panel series door, use alternate top hinge
shipped with refrigerator.
1. Replace the parts for the bottom hinge as shown. Tighten
screws. Replace the refrigerator door.
NOTE: Provide additional support for the refrigerator door
while the hinges are being moved. Do not depend on the door
gasket magnets to hold the door in place while you are
working.
2. Assemble the parts for the top hinge as shown (see Top
Hinge Graphic). Do not tighten screws completely.
3. Line up the door so that the bottom of the refrigerator door
aligns evenly with the top of the freezer drawer. Tighten all
screws.
Final Steps
1. Check all holes to make sure that hole plugs and screws are
in place. Reinstall top hinge cover (see Top Hinge Graphic).
2. Plug in refrigerator or reconnect power.
3. Reset the controls (see "Using the Controls" section).
4. Return all removable door parts to doors and food to product.

Architect ®Series
1.Hinge Cover Screw
2. Top Hinge Cover
3. %6" Hex°Head Hinge Screws
4. Top Hinge
Bottom Hinge
1. Shim
2. Center Hinge
3. Hinge Screws
1, 3/3_"Set Screw
il
I I
1. Cabinet Hinge Hole Plugs
iiiiiiiiiiiiiiiii
iiiiiiiiiiiiiiiii
Front View
J
I2
1. Door Stop Screws
2. Door Stop
@
Side View
_1
r_
_L_,_ o
1. Hinge Screws
!
!
/
Door Handle
Seal Screw
Front
/

Panel Series
1. 1/4"Hex-Head Screws
2. Top Door Extension
1. Handle Trim
2. Side Door Trim
12
1. Bottom Door Cap
2. Door Stop
iiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiii
" iiiiiiiiiiiiiiiiiiiii
iiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiii
' iiiiiiiiiiiiiiiiiiiii
iiiiiiiiiiiiiiiiiiiii
iiiiiiiiiiiiiiiiiiiii
(Some Modets)
10

Door Closing
Your refrigerator has two front adjustable rollers which are at the
base of the refrigerator on either side. If your refrigerator seems
unsteady or you want the doors to close easier, adjust the
refrigerator's tilt using the instructions below:
1. Plug into a grounded 3 prong outlet.
2. Move the refrigerator into its final position.
3. Remove the base grille and the bottom hinge covers (see
"Base Grille" section). The two roller adjustment screws are
part of the front roller assemblies.
4. Use a screwdriver or % in. hex driver to adjust the roller
adjustment screws. Turn the roller adjustment screw to the
right to raise that side of the refrigerator or turn the roller
adjustment screw to the left to lower that side. It may take
several turns of the roller adjustment screws to adjust the tilt
of the refrigerator.
NOTE: Having someone push against the top of the
refrigerator takes some weight off the roller adjustment
screws and rollers. This makes it easier to adjust the screws.
Please read before using the water system.
Immediately after installation, follow the steps below to make
sure that the water system is properly cleaned.
1. Turn off the ice maker by opening the freezer door and lifting
up the wire shutoff arm as shown.
2. Install the interior water filter cartridge. The interior water filter
mounting bracket is located on the top right side of the
refrigerator compartment.
NOTE: Do not use with water that is microbiologically
unsafe or of unknown quality without adequate
disinfection before or after the system.
Remove blue bypass cap and retain for later use.
Carefully remove the interior water filter cartridge from its
packaging. Remove the sealing label from end of filter
and insert into filter head.
• Gently rotate filter clockwise until filter stops, and snap
filter cover closed.
1.Roller Adjustment Screw
2. Stabilizing Foot
5. Open both doors again and check to make sure that they
close as easily as you like. If not, tilt the refrigerator slightly
more to the rear by turning both roller adjustment screws to
the right. It may take several more turns, and you should turn
both roller adjustment screws the same amount.
6. Lower the stabilizing foot by turning it clockwise until it is
firmly against floor.
NOTE: Drawer freezer models have a stabilizing foot on each
side which must be lowered by turning clockwise.
7. Replace the base grille.
3.
4.
5.
Flush the water system by dispensing and discarding 2 to 3
gal. (8 to 12 L) of water. Cleaning the system will take
approximately 6 to 7 minutes and will help clear air from the
line. Additional flushing may be required in some households.
NOTE: As air is cleared from the system, water may spurt out
of the dispenser.
Inspect the filter system for water leaks. Ifyou see water
leaks, see the "Troubleshooting" section.
Turn on the ice maker by opening the freezer door and
lowering the wire shutoff arm as shown. Please refer to the
"Ice Maker" section for further instructions on the operation
of your ice maker.
• Allow 24 hours to produce the first batch of ice.
• Discard the first three batches of ice produced.
11

There may be an occasion when you will need to remove the
factory-installed trim kit, such as moving the refrigerator to a new
home or installing custom-made decorator panels. Please read
all instructions carefully before removing the trim kit and
decorator panels.
..................i
2½"(6.35 cm)clearance
2. Raised Decorator Panel
3. Raised Drawer Panel
Removing the Door Panel
IMPORTANT:
• Door must be removed from refrigerator before removing
handle.
• Top trim must be removed from refrigerator before removing
door panel.
1. Remove the refrigerator handle:
• Using a Phillips screwdriver, remove top door cap.
• Tap bottom edge of refrigerator door handle upward with
a rubber mallet.
• Handle will slide up approximately 3/4in. (19.05 mm) and
release from door.
2. Remove the door panel:
• Slide out decorator panel and filler board.
• Store panel and filler board carefully to prevent
scratching.
Replacing the Door Panel
1. Replace the refrigerator door panel:
• Carefully slide the _/4in. (6.35 mm), maximum thickness,
decorator panel in grooves provided by bottom door cap
and side trim.
• Slide the filler board into place behind the decorator
panel, if necessary.
2. Attach the handle and trim.
3. Reinstall refrigerator door.
Removing and Replacing Freezer Drawer Panel
NOTE: You do not need to remove the freezer drawer to remove
or replace the decorator panel.
1. Pull freezer drawer out to access handle screws.
2. Using a Phillips screwdriver, remove handle screws and lift off
handle.
3. Slide decorator panel and filler board up through handle
opening.
4. Replace decorator panels by reversing directions.
Care of Decorator Panels
1.
2.
Clean panels with stainless steel cleaner and polish or mild
soap and water with a clean, soft, damp cloth.
Rinse panels thoroughly and blot dry using a dry, soft cloth or
chamois.
NOTE: Do not use paper towels or cleaners which contain
solvents such as ammonia. They can damage the surface of
the panels.
Installing Custom Wood Panels
Ifyou plan to install custom wood decorator panels, you will need
to create the panels yourself or consult your cabinetmaker or
carpenter. See dimensional drawings for wood panel inserts.
Flat panels:
You can create a custom flat panel a maximum of _/4in. (6.35 mm)
thick to replace your decorator panels. Flat wood panels less
than _/4in. (6.35 mm) thick are not recommended.
Raised panels:
A raised panel design can be created by screwing or gluing wood
panels to _/4in. (6.35 mm) backing or by using 3/4in. (19.05 mm)
stock with routed edges. Allow 2_Ain. (6.35 cm) minimum
clearance between raised edge of panel and handle.
Weight requirements for raised panel inserts:
• Refrigerator door panel should not exceed 30 Ibs. (14 kg).
• Freezer drawer panels should not exceed 15 Ibs. (7 kg)
combined weight.
12

Dimensions for Custom Wood Panels
20 cu. ft. Refrigerator door
355/8"
•<_ (90.5 cm) -_
36111o"
(91.6 cm)
42"
(106.7 cm)
231/4"
(59.1 cm)
!
Dimensions for Routing Handle Side of Raised Door Panels
(End View)
1
'/4" (6 mm) max./
min. 2
1.Handle
2. Door panel
Dimensions for Routing Door Panel (Side View)
3/4"
(19 mm)
rnin.
1.........................
(6 mm) max.
1. Door panel
_ , m._/ ¸ • _id_
Your new refrigerator may make sounds that your old one didn't
make. Because the sounds are new to you, you might be
concerned about them. Most of the new sounds are normal. Hard
surfaces, such as the floor, walls, and cabinets, can make the
sounds seem louder. The following describes the kinds of sounds
and what may be making them.
• If your product is equipped with an ice maker, you will hear a
buzzing sound when the water valve opens to fill the ice
maker for each cycle.
Your refrigerator is designed to run more efficiently to keep
your food items at the desired temperatures and to minimize
energy usage. The high efficiency compressor and fans may
cause your refrigerator to run longer than your old one. You
may also hear a pulsating or high-pitched sound from the
compressor or fans adjusting to optimize performance.
• You may hear the evaporator fan motor circulating air through
the refrigerator and freezer compartments. The fan speed
may increase as you open the doors or add warm food.
• Rattling noises may come from the flow of refrigerant, the
water line, or items stored on top of the refrigerator.
• Water dripping on the defrost heater during a defrost cycle
may cause a sizzling sound.
• As each cycle ends, you may hear a gurgling sound due to
the refrigerant flowing in your refrigerator.
• Contraction and expansion of the inside walls may cause a
popping noise.
• You may hear air being forced over the condenser by the
condenser fan.
• You may hear water running into the drain pan during the
defrost cycle.
13

REFRIGERATOR USE
In order to ensure proper temperatures, you need to permit
airflow between the refrigerator and freezer sections. As shown in
the illustration, cool air enters the freezer section through vents in
the rear and top. The air flows forward through the freezer section
and recirculates under the freezer floor. Cool air enters the
refrigerator section through the top, flows down and across
shelves to the doors and recirculates to return air vents at the
bottom.
Do not block any of these vents with food packages. If the vents
are blocked, airflow will be prevented and temperature and
moisture problems may occur.
IMPORTANT: Because air circulates between both sections, any
odors formed in one section will transfer to the other. You must
thoroughly clean both sections to eliminate odors. To prevent
odor transfer and drying out of food, wrap or cover foods tightly.
For your convenience, your refrigerator and freezer controls are
preset at the factory. When you first install your refrigerator, make
sure that the controls in the refrigerator and freezer
compartments are still preset to the mid-settings as shown.
Mid-setting "4"
IMPORTANT:
• To turn your refrigerator off, turn the freezer control to the
word OFF or until the word OFF appears. Neither
compartment will cool when the freezer control is set to OFR
The refrigerator control adjusts the refrigerator compartment
temperature. The freezer control adjusts the freezer
compartment temperature. Settings to the left of the mid-
setting make the temperature less cold. Settings to the right
of the mid-setting make the temperature colder.
Wait 24 hours before you put food into the refrigerator. If you
add food before the refrigerator has cooled completely, your
food may spoil.
NOTE: Adjusting the Refrigerator and Freezer Controls to a
higher (colder) than recommended setting will not cool the
compartments any faster.
The preset settings should be correct for normal household
use. The controls are set correctly when milk or juice is as
cold as you like and when ice cream is firm.
If the temperature is too warm or too cold in the refrigerator or
freezer, first check the air vents to be sure they are not
blocked before adjusting the controls.
Give the refrigerator time to cool down completely before adding
food. It is best to wait 24 hours before you put food into the
refrigerator. The settings indicated in the previous section should
be correct for normal household refrigerator usage. The controls
are set correctly when milk or juice is as cold as you like and
when ice cream is firm.
If you need to adjust temperatures in the refrigerator or freezer,
use the settings listed in the chart below as a guide. Always
remember to wait at least 24 hours between adjustments.
CONDITION/REASON: RECOMMENDED
ADJUSTMENT:
REFRIGERATOR too warm Turn REFRIGERATOR
• Door opened often Control to next higher
number, wait 24
• Large amount of food added hours, then recheck
• Room temperature very warm
FREEZER too warm/ice not made
fast enough
• Door opened often
• Large amount of food added
• Very cold room temperature
(can't cycle often enough)
• Heavy ice usage
Turn FREEZER
Control to next higher
number, wait 24
hours, then recheck
REFRIGERATOR too cold
• Control not set correctly for your
conditions
Turn REFRIGERATOR
Control to next lower
number, wait 24
hours, then recheck
FREEZER too cold Turn FREEZER
• Control not set correctly for your Control to next lower
conditions number, wait 24
hours, then recheck
14

If you did not flush the water system when the refrigerator was
first installed, dispense water into a container until you draw and
discard 2 to 3 gal. (8 to 12 L) or for approximately 6 to 7 minutes
after the water begins dispensing. The water you draw and
discard rinses the pipes. Allow several hours for the refrigerator
to cool down and chill water.
Dispensing Water
1. Hold a container under the dispenser while pressing the
button.
2. Release the button to stop dispensing.
NOTE: Dispense enough water every week to maintain a fresh
supply.
3. Remove the sealing label from end of new filter and insert into
filter head. Gently rotate filter clockwise until filter stops, and
snap filter cover closed.
NOTE: Do not use with water that is microbiologically
unsafe or of unknown quality without adequate
disinfection before or after the system.
4.
5.
Flush the water system by dispensing and discarding 2 to 3
gal. (8 to 12 L) of water. Cleaning the system will take
approximately 6 to 7 minutes and will help clear air from the
line. Additional flushing may be required in some households.
NOTE: As air is cleared from the system, water may spurt out
of the dispenser.
Inspect the filter system for water leaks. Ifyou see water
leaks, see the "Troubleshooting" section.
IMPORTANT:
• You can run the water dispenser without a water filter
cartridge, but your water will not be filtered. If you choose this
option, replace filter with blue bypass cap.
• The interior water filter mounting bracket is located on the
upper right side of the refrigerator.
• The interior water filter cartridge should be replaced every 6
months or earlier if the flow of water to your water dispenser
or ice maker decreases noticeably.
Replacing the interior water filter cartridge
1. Turn used filter counterclockwise until it releases from filter
head.
2. Drain water from filter into the sink, and dispose. Wipe up
excess water in filter cover.
Turning the Ice Maker On/Off
NOTE: Do not force the wire shutoff arm up or down.
• To turn the ice maker on, simply lower the wire shutoff arm.
NOTE: Your ice maker has an automatic shutoff. As ice is
made, the ice cubes will fill the ice storage bin and the ice
cubes will raise the wire shutoff arm to the OFF (arm up)
position.
• To manually turn the ice maker off, lift the wire shutoff arm to
the OFF (arm up) position and listen for the click to make sure
the ice maker will not continue to operate.
Increasing Ice Production Rate
The ice maker should produce approximately 8 to 12 batches of
ice in a 24-hour period. If ice is not being made fast enough, turn
the Freezer Control toward a higher (colder) number in half
number steps. (For example, if the control is at 3, move it to
between 3 and 4.) Wait 24 hours and, if necessary, gradually turn
the Freezer Control to the highest setting, waiting 24 hours
between each increase.
REMEMBER:
• Allow 24 hours to produce the first batch of ice. Discard the
first three batches of ice produced.
The quality of your ice will be only as good as the quality of
the water supplied to your ice maker. Avoid connecting the
ice maker to a softened water supply. Water softener
chemicals (such as salt) can damage parts of the ice maker
and lead to poor quality ice. If a softened water supply cannot
be avoided, make sure the water softener is operating
properly and is well maintained.
Do not store anything on top of the ice maker or in the ice
storage bin.
15

REFRIGERATOR
FEATURES
Your model may have some or all of these features. Features that
can be purchased separately as product accessories are labeled
with the word "Accessory." Not all accessories will fit all models.
If you are interested in purchasing one of the accessories, please
call the toll-free number on the cover or in the "Assistance or
Service" section.
_mportant information to know about gmassshelves
and covers:
Do not clean glass shelves or covers with warm water when
they are cold. Shelves and covers may break if exposed to
sudden temperature changes or impact, such as bumping.
For your protection, tempered glass is designed to shatter
into many small, pebble-size pieces. This is normak Glass
shelves and covers are heavy. Use special care when re-
moving them to avoid impact from dropping.
The shelves in your refrigerator are adjustable to meet your
individual storage needs. Your model may have glass or wire
shelves.
Storing similar food items together in your refrigerator and
adjusting the shelves to fit different heights of items will make
finding the exact item you want easier. It will also reduce the
amount of time the refrigerator door is open, and save energy.
Slide-out Shelves (on some models)
• To slide out shelf, carefully pull front of shelf toward you.
• To slide in shelf, push shelf in until it stops.
To remove and replace a shelf in a metal frame:
1. Pull the shelf forward to the stop.
2. Tilt the front of the shelf up and lift it slightly as you pull the
shelf from the frame.
3. Replace the shelf by guiding it back into the slots on the
frame and pushing the shelf in past the stop.
Shelves and Shelf Frames
To remove and replace a shelf/frame:
1. Remove the shelf/frame by tilting it up at the front and lifting it
out of the shelf supports.
2. Replace the shelf/frame by guiding the rear shelf hooks into
the shelf supports. Tilt the front of the shelf up until rear shelf
hooks drop into the shelf supports.
3. Lower the front of the shelf and check to make sure that the
shelf is securely in position.
To remove and replace the meat drawer:
1. Remove the meat drawer by sliding it out to the stop. Lift the
front of meat drawer with one hand while supporting the
bottom of drawer with other hand. Slide drawer out the rest of
the way.
2. Replace the meat drawer by guiding it into the meat cover
supports and pushing it in until it stops.
To remove and replace the meat drawer cover:
1. Remove the meat drawer. Remove the cover by tilting up the
front of the cover and lifting at the back. Pull the cover
straight out.
2. Replace the cover by guiding the rear hooks into the shelf
supports. Tilt the cover up at the front until the rear hooks
drop into the slots.
3. Lower the front of the cover to a level position and replace the
meat drawer.
Meat Storage Guide
Store most meat in original wrapping as long as it is airtight and
moisture-proof. Rewrap if necessary. See the following chart for
storage times. When storing meat longer than the times given,
freeze the meat.
Fresh fish or shellfish .................. use same day as purchased
Chicken, ground beef, variety meats (liver) ............... 1-2 days
Cold cuts, steaks/roasts ........................................... 3-5 days
Cured meats ............................................................ 7-10 days
Leftovers - Cover leftovers with plastic wrap, aluminum foil, or
plastic containers with tight lids.
16

( i_i_ _ ei_..... :_C _'_" C __T_ '_
To remove and replace the crisper(s):
1. Slide crisper(s) straight out to the stop. Lift the front of the
crisper(s) and slide out the rest of the way.
2. Replace the crisper(s) by sliding back in fully past the drawer
stop.
To remove the crisper(s) cover:
1. Remove crisper(s),
2. Holding the glass insert firmly with one hand, press up in
center of glass insert until it rises above the plastic frame.
Carefully, slide the glass insert forward to remove.
3. Lift the cover frame up and remove it.
Depending on your model, you may have a one, two or three
piece bin. Eggs may be stored in the egg tray or loose in the bin.
NOTE: Store eggs in a covered container for long-term storage. If
your model does not have an egg storage bin, store eggs in their
original carton on an interior shelf.
FREEZER FEATURES
Your model may have some or all of these features. Features that
can be purchased separately as product accessories are labeled
with the word "Accessory." Not all accessories will fit all models.
If you are interested in purchasing one of the accessories, please
call the toll-free number on the cover or in the "Assistance or
Service" section.
To replace crisper(s) cover:
NOTE: Before reinstalling the cover, make sure the
U-shaped reinforcement bar is reinstalled in the front edge of the
crisper cover.
1. Fit back of cover frame into supports on side walls of the
refrigerator and lower the front of the cover frame into place.
2. Slide rear of glass insert into cover frame and lower front into
place.
/ ........... J ..........
You can control the amount of humidity in the moisture-sealed
crisper. Adjust the control to any setting between LOW and
HIGH.
LOW (open) lets moist air out of the crisper for best storage of
fruits and vegetables with skins.
•Fruit: Wash, let dry and store in refrigerator in plastic bag or
crisper. Do not wash or hull berries until they are ready to use.
Sort and keep berries in original container in crisper, or store
in a loosely closed paper bag on a refrigerator shelf.
• Vegetables with skins: Place in plastic bags or plastic
container and store in crisper.
HIGH (closed) keeps moist air in the crisper for best storage of
fresh, leafy vegetables.
• Leafy vegetables: Wash in cold water, drain and trim or tear
off bruised and discolored areas. Place in plastic bag or
plastic container and store in crisper.
To Remove and Replace Wire Baskets :
Upper basket
1. Remove all items from basket. Remove basket by pulling
basket out to its full extension and lift out.
2. Replace basket by sliding into upper molded railing. Make
sure that rear of basket hooks behind rail catch.
Upper basket divider
• The upper basket divider separates ice making from frozen
food storage and it prevents ice from falling behind the
basket assemblies.
• The upper basket divider is designed to be non-removable
and should remain in the refrigerator
Lower basket
1. Remove all items from basket. Remove basket by lifting
basket from rail guides.
2. Replace basket by placing into rail guides.
17

Lower basket divider
The lower basket divider is designed to be non-removable and it
should remain in the refrigerator.
To install and remove ice shelf:
1. Slide rear L-shaped groove of shelf down over rear wall
screw, Push rack back until screw is stopped in L-shaped
groove.
2. Place front groove over front wall screw and push down until
shelf is secured.
3. To remove, perform above steps in reverse order.
DOOR FEATURES
Your model may have some or all of these features. Features that
can be purchased separately as product accessories are labeled
with the word "Accessory." Not all accessories will fit all models,
If you are interested in purchasing one of the accessories, please
call the toll-free number on the cover or in the "Assistance or
Service" section.
To remove and replace the door retainer:.
1. Remove the retainer by lifting it up and pulling it straight out,
2. Replace the retainer by sliding it in above the support and
pushing it down until it stops.
To remove and replace the bins:
1. Remove the bin by lifting it up and pulling it straight out.
2. Replace the bin by sliding it in above the desired support and
pushing it down until it stops.
To remove and replace the utility compartment:
1. Remove the utility compartment by lifting it up and pulling it
straight out.
2. Replace the utility compartment by sliding it in above the
desired support and pushing it down until it stops.
18

REFRIGERATOR CARE
Explosion Hazard
Use nonflammable cleaner,
Failure to do so can result in death, explosion,
or fire.
Both the refrigerator and freezer sections defrost automatically.
However, clean both sections about once a month to prevent
odors from building up. Wipe up spills immediately.
Cleaning your refrigerator
1. Unplug refrigerator or disconnect power.
2. Remove all removable parts from inside, such as shelves,
crispers, etc.
3. Hand wash, rinse, and dry removable parts and interior
surfaces thoroughly. Use a clean sponge or soft cloth and a
mild detergent in warm water.
• Do not use abrasive or harsh cleaners such as window
sprays, scouring cleansers, flammable fluids, cleaning
waxes, concentrated detergents, bleaches or cleansers
containing petroleum products on plastic parts, interior
and door liners or gaskets. Do not use paper towels,
scouring pads, or other harsh cleaning tools, These can
scratch or damage materials.
• To help remove odors, you can wash interior walls with a
mixture of warm water and baking soda (2 tbs. to 1 qt.
[26 g to .95 L] of water),
4. Wash stainless steel and painted metal exteriors with a clean
sponge or soft cloth and a mild detergent in warm water. Do
not use abrasive or harsh cleaners. Dry thoroughly with a soft
cloth. For additional protection against damage to painted
metal exteriors, apply appliance wax (or auto paste wax) with
a clean, soft cloth, Do not wax plastic parts.
NOTE: To keep your Stainless Steel refrigerator looking like
new and to remove minor scuffs or marks, it is suggested that
you use the manufacturer's approved Stainless Steel Cleaner
& Polish.
IMPORTANT: This cleaner is for Stainless Steel parts only!
Do not allow the Stainless Steel Cleaner & Polish to come into
contact with any plastic parts such as the trim pieces,
dispenser covers or door gaskets. If accidental contact does
occur, clean plastic part with a sponge and mild detergent in
warm water. Dry thoroughly with a soft cloth. To order the
cleaner, see the "Accessories" section.
5,
6,
There is no need for routine condenser cleaning in normal
home operating environments. If the environment is
particularly greasy or dusty, or there is significant pet traffic in
the home, the condenser should be cleaned every two to
three months to ensure maximum efficiency.
If you need to clean the condenser:
• Remove the base grille (see "Base Grille" or "Door
Removal" section).
• Use a vacuum with a soft brush to clean the grille, the
open areas behind the grille and the front surface area of
the condenser.
• Replace the base grille when finished.
Plug in refrigerator or reconnect power.
NOTE: Not all appliance bulbs will fit your refrigerator. Be sure to
replace the bulb with one of the same size, shape, and wattage.
Changing the Refrigerator Light Bulb
1. Unplug refrigerator or disconnect power.
2. Remove screw from light shield. Make sure you keep screw
for reattaching.
3. Slide shield toward back of compartment to release from light
assembly.
4. Replace burned-out bulb(s) with an appliance light bulb no
greater than 40 watts.
5. Replace light bulb cover by inserting tabs on light shield into
liner holes on each side of light assembly. Slide shield toward
front of unit until it locks into place.
NOTE: Do not force shield beyond locking point; doing so
may damage light shield.
6. Replace screw.
7. Plug in refrigerator or reconnect power.
Changing the Freezer Light Bulb
1. Unplug refrigerator or disconnect power.
NOTE: May need to remove upper freezer shelf or basket to
access light assembly.
2. Squeeze and pull rear of light shield cover toward you to
release tabs and pull down.
3. Replace burned-out bulb with appliance bulb no greater than
40 watts.
4. Insert front tabs of light cover into liner and snap back portion
over light assembly.
5. Plug in refrigerator or reconnect power.
19

If the power will be out for 24 hours or less, keep both refrigerator
doors closed to help food stay cold and frozen.
If the power will be out for more than 24 hours, do one of the
following:
• Remove all frozen food and store it in a frozen food locker.
• Place 2 Ibs. (907 g) of dry ice in the freezer for every cubic
foot (28 L) of freezer space. This will keep the food frozen for
two to four days.
• If neither a food locker nor dry ice is available, consume or
can perishable food at once.
REMEMBER: A full freezer stays cold longer than a partially filled
one. A freezer full of meat stays cold longer than a freezer full of
baked goods. If you see that food contains ice crystals, it may be
refrozen, although the quality and flavor may be affected. If the
condition of the food is poor, dispose of it.
Vacations
If you choose to leave the refrigerator on while you're
away:
1. Use up any perishables and freeze other items.
2. If your refrigerator has an automatic ice maker:
• Raise wire shutoff arm to OFF (up) position or move the
switch to the OFF (right) setting.
• Shut off water supply to the ice maker.
3. Empty the ice bin.
If you choose to turn the refrigerator off before you leave:
1. Remove all food from the refrigerator.
2. If your refrigerator has an automatic ice maker:
• Turn off the water supply to the ice maker at least one day
ahead of time.
• When the last load of ice drops, raise the wire shutoff arm
to the OFF (up) position or move the switch to the OFF
(right) setting.
3. Depending on your model, turn the Thermostat Control or
Refrigerator Control to OFR See the "Using the Control(s)"
section.
4. Clean refrigerator, wipe it, and dry well.
5. Tape rubber or wood blocks to the tops of both doors to prop
them open far enough for air to get in. This stops odor and
mold from building up.
Moving
When you are moving your refrigerator to a new home, follow
these steps to prepare it for the move.
1. If your refrigerator has an automatic ice maker:
• Turn off the water supply to the ice maker at least one day
ahead of time.
• Disconnect the water line from the back of the
refrigerator.
• When the last load of ice drops, raise the wire shutoff arm
to the OFF (up) position or move the switch to the OFF
(right) setting.
2. Remove all food from the refrigerator and pack all frozen food
in dry ice.
3. Empty the ice bin.
4. Depending on your model, turn the Thermostat Control or
Refrigerator Control to OFR See the "Using the Control(s)"
section.
5. Unplug the refrigerator.
6. Empty water from the defrost pan.
7. Clean, wipe, and dry thoroughly.
8. Take out all removable parts, wrap them well, and tape them
together so they don't shift and rattle during the move.
9. Depending on the model, raise the front of the refrigerator so
it rolls more easily OR screw in the leveling legs so they don't
scrape the floor. See the "Door Closing" or "Leveling Your
Refrigerator" section.
10. Tape the doors shut and the power cord to the refrigerator
cabinet.
When you get to your new home, put everything back and refer to
the "Refrigerator Installation" section for preparation instructions.
Also, if your refrigerator has an automatic ice maker, remember to
reconnect the water supply to the refrigerator.
TROUBLESHOOTING
Trythe solutions suggested here first in order to avoid the
cost of an unnecessary service call.
Your refrigerator will not operate
•Is the power cord unplugged? Plug into agrounded 3 prong
outlet.
•Has ahousehold fuse or circuit breaker tripped? Replace
the fuse or reset the circuit breaker.
•Is the Refrigerator Control turned to the OFF position?
See the "Using the Control(s)" section.
• Is the refrigerator defrosting? Recheck to see if the
refrigerator is operating in 30 minutes. Your refrigerator will
regularly run an automatic defrost cycle.
The lights do not work
•Is the power cord unplugged? Plug into agrounded 3 prong
outlet.
•Is alight bulb loose in the socket or burned out? See the
"Changing the Light Bulb(s)" section.
There is water in the defrost drain pan
•Is the refrigerator defrosting? The water will evaporate. It is
normal for water to drip into the defrost pan.
•Is it more humid than normal? When it is humid, expect that
the water in the defrost pan will take longer to evaporate.
The motor seems to run too much
Is the room temperature hotter than normal? The motor
will run longer under warm conditions. At normal room
temperatures, your motor will run about 40% to 80% of the
time. Under warmer conditions, it will run even more.
Has a large amount of food just been added to the
refrigerator? Adding a large amount of food warms the
refrigerator. The motor normally will run longer to cool the
refrigerator back down.
20
