CABINET PARTS
1
For Models: KBRS22KVWH00, KBRS22KVBL00, KBRS22KVSS00
(White) (Black) (Stainless Stainless)
10−08 Litho In U.S.A. (mat) (eeb) Part No. W10234665 Rev. A
REFRIGERATOR

CABINET PARTS
2
For Models: KBRS22KVWH00, KBRS22KVBL00, KBRS22KVSS00
(White) (Black) (Stainless Stainless)
W10234665
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
W10137649 Use & Care Guide
W10212714 Energy Guide
W10168777 Tech Sheet
2 Cabinet (Not a
Serviceable Part)
3 Plug, Button (3)
M0310729 White
M0310731 Black
4 B5759649 Gasket
5
12580304KVF Roller Foot
Assembly
6 67003868 Foot Brake
7 67006642 Pin, Center Hinge
8 67006611 Bolt, Adjusting
(Front Roller)
9 67006521 Screw
10 Cover, Right Hinge
67001014 White
67001012 Black
11 67006380 Screw
12 67006473 Screw
13 67005064 Label, Fill Tube
14 67006303 Screw
15 Hinge, Center (2)
67006960 White
67007043 Black
16
12566606ED Hinge, Top
17 Cover, Corner
67003484 White
67003485 Black
18
W10157973 Clip, Drain Tube
19
W10208641 Bracket, Foot
20 67006564 Screw (8)
21
12575101WD Back, MC
22 Grille Assembly
(Includes Clips)
67007004 White
67006954 Black
23 67001098 Cover, Fill Tube
24
W10164397 Tube, Drain
25 67006425 Screw
26 67003796 Insulation, Sound
27 67001097 Cover, Water Valve
28 12479901 Plate, Cover
29 67006662 Screw

FREEZER LINER PARTS
3
For Models: KBRS22KVWH00, KBRS22KVBL00, KBRS22KVSS00
(White) (Black) (Stainless Stainless)
W10234665

FREEZER LINER PARTS
4
For Models: KBRS22KVWH00, KBRS22KVBL00, KBRS22KVSS00
(White) (Black) (Stainless Stainless)
W10234665
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Seviceable Part)
2 67001291 Gasket, Foam
3 12002497 Gear (2)
(Includes RT & LT)
4 67003905 Cover, Light
5 67004017 Shaft
6
Y12570701 Socket, Light
8 67006473 Screw (8)
9 A0282812 Bulb, Light
10 67001035 Housing, Light
11 67005872 Cover, Evaporator
12 67006425 Screw (7)
13 Bracket, Door
W10122147 Left
W10122148 Right
14 67003906 Housing, Lighting
15 10623002 Clip, Evap. Motor
16 67005653 Switch, Light
17 67006530 Screw
18 Cradle, Basket
W10187668 Left
W10187667 Right
19
W10120018 Slide, Drawer
20 67003731 Gasket, Bottom
21 Adapter, Slide
W10149390 Left
W10149391 Right
22
W10175909 Grille, Fz Air
23
W10167023 Shroud, Evap.Fan
24 2169142 Blade, Fan
(Evaporator)
25
W10150583 Grommet
26
W10199049 Motor, Evaporator
27 D7753903 Funnel, Drain
28 M0500703 Seal
29 B8381501 Gasket
30 12002355 Thermistor
31 67003924 Cover, Thermistor
32 67006406 Screw (6)
Following Parts Not Illustrated
67006095 Harness, Lights
(Freezer)

FREEZER DOOR PARTS
5
For Models: KBRS22KVWH00, KBRS22KVBL00, KBRS22KVSS00
(White) (Black) (Stainless Stainless)
W10234665
Illus. Part
No. No. DESCRIPTION
1 Door, Freezer
13092244WQ White
13092244BQ Black
13092210SQ Stainless
2 Handle, Door
W10119642 White
W10119643 Black
W10119644 Stainless
3 67006113 Mount, Handle
4 Gasket, Door
W10164036 White
W10164037 Black
5 67006901 Screw

REFRIGERATOR LINER PARTS
6
For Models: KBRS22KVWH00, KBRS22KVBL00, KBRS22KVSS00
(White) (Black) (Stainless Stainless)
W10234665
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Liner (Not A
Serviceable Part)
2
Y67003896 Bracket, Control
and Lights
3
W10212326 Overlay
4
W10185585 Module, Control
5
W10207861 Board, Control
6 C3680310 Switch, Light
7 67003897 Cover, Light
8 67003901 Housing, Light
9 A0282812 Bulb, Light (2)
10
Y12570701 Socket, Light (2)
11 67003900 Insert,
Damper Cover
12 67006602 Screw (2)
13 67003899 Cover, Damper
14 67006604 Insulation
15
W10127429 Control, Damper
(Includes Harness)
16 12002355 Thermistor
Following Parts Not Illustrated
67005644 Harness, Controls
(Refrigerator)

REFRIGERATOR DOOR PARTS
7
For Models: KBRS22KVWH00, KBRS22KVBL00, KBRS22KVSS00
(White) (Black) (Stainless Stainless)
W10234665

REFRIGERATOR DOOR PARTS
8
For Models: KBRS22KVWH00, KBRS22KVBL00, KBRS22KVSS00
(White) (Black) (Stainless Stainless)
W10234665
Illus. Part
No. No. DESCRIPTION
1 Door, Refrigerator
12658583WQ White
12658583BQ Black
13023839SQ Stainless
2 67006901 Screw (2)
3 67003819 Door, Dairy
(Includes #4)
4 67001279 Tray, Dairy
5 67005672 Bucket, Medium (3)
6 Plug, Handle Hole
67001130 White
67001131 Black
7 Plug, Button
10712401 White
67004838 Black
8 Gasket, Door
W10164034 White
W10131327 Black
9 Handle, Door
W10119642 White
W10119643 Black
W10119644 Stainless
10
12567321SP Gripper, Bucket(4)
11 Closure, Door
67003638 White
67003639 Black
12
W10046670 Nameplate
14 12690502 Retainer, Door
15 67006287 Screw
16 Bushing, Door
67004977 White
67004978 Black
17 Stop, Door
67003779 White
67003780 Black
18
12643911SP Bucket, Short
19 67005626 Caddy, Can
20 67006113 Mount, Handle

UNIT PARTS
9
For Models: KBRS22KVWH00, KBRS22KVBL00, KBRS22KVSS00
(White) (Black) (Stainless Stainless)
W10234665

UNIT PARTS
10
For Models: KBRS22KVWH00, KBRS22KVBL00, KBRS22KVSS00
(White) (Black) (Stainless Stainless)
W10234665
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 67006433 Screw
2 12825802 Blade, Fan
3 12591404 Basepan
4 67006425 Screw
5 67005491 Block, Consenser
6
W10183706 Discharge Tube
7
W10171661 Harness, Evap.
Heater
8 67004713 Drain Pan
9 61004743 Grommet (3)
10 67001794 Heater, Defrost
11
W10136415 Clip, Capacitor
12
W10136414 Start Device
13 61003210 Gasket
14
W10165425 Thermostat,
Defrost
15
W10137529 Grommet (4)
16 67006573 Screw
17
W10169124 Grommet (4)
18
W10135027 Condenser
19 67006432 Screw
20 67001080 Tray, Drip
21 67006737 Screw
22 67003719 Evaporator
23 Dam
67001084 Right Side
67001083 Left Side
24 67004432 Motor, Fan
25 10428101 Clip, Heater
26 13060202 Harness, Unit
with Power Cord
27
W10143759 Drier
28
W10130129 Compressor
(Includes Items
11,12,15,17, & 27)
29 2264017 Capacitor
30 67006434 Axle, Roller
31 12575309 Shroud
32 67004953 Screw
33 67004954 Screw
34 10547003 Clip, Drier
35 67005149 Roller
36 10623002 Clip, Evap
37 67005680 Grommet (2)
38 67004969 Box, HV
39 67005418 Spacer, HV
40
12782036SP Board, HV
41 67005938 Harness, HV
42 67006550 Screw (2)
43 67005421 Cover, HV
44 67006615 Screw, HV
Cover
Following Parts Not Illustrated
and Optional Parts Not Included
978025 Valve, Access
(1/4")
978026 Valve, Access
(5/16")
978027 Valve, Access
(3/8")
978028 Valve, Access
(1/2")
978029 Valve, Access
(5/8")
978030 Valve, Access
(3/4")
876764 Valve, Access
(3/16")
REFRIGERANT CHARGE
5.0 Ozs.
(R−134A)

SHELF PARTS
11
For Models: KBRS22KVWH00, KBRS22KVBL00, KBRS22KVSS00
(White) (Black) (Stainless Stainless)
W10234665

SHELF PARTS
12
For Models: KBRS22KVWH00, KBRS22KVBL00, KBRS22KVSS00
(White) (Black) (Stainless Stainless)
W10234665
Illus. Part
No. No. DESCRIPTION
1 67001057 Rail, Center
Crisper
2 67005732 Trim, Crisper
3 67005864 Slide, Humidity
Control (2)
4
W10201223 Basket, Freezer
(Upper)
5
W10150038 Basket, Freezer
(Lower)
6 12463310 Shelf, Glide
Out (2)
7 67006360 Screw
8
W10205416 Divider,
Lower Basket
10
W10171557 Divider,
Upper Basket
11 67006400 Screw
12 12463509 Shelf, Sta (2)
16 67002633 Pan, Crisper (2)
17 67001059 Brace, Crisper (2)
18 67001056 Frame, Crisper (2)
19 67006878 Glass, Crisper (2)
20 67001073 Ladder, Center
21 67001317 Ladder, Side (2)
23 67005928 Pan, Pantry
24 67001913 Trim, Pantry
25 67002002 Slide, Pantry
26 67002003 Bar, Pantry
27 67002004 Tunnel, Pantry
28 67002005 Gasket, Pantry
29 Support, Pantry
67001721 LH
67001722 RH
30 67001716 Ladder, Hook
31 67001719 Track, Deli

ICEMAKER PARTS
13
For Models: KBRS22KVWH00, KBRS22KVBL00, KBRS22KVSS00
(White) (Black) (Stainless Stainless)
W10234665
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Mold & Heater
Assembly
(Not Available −−
Order D7824706Q)
2 67004028 Arm, Shutoff
3 628356 Cup, Fill
4 627843 Ejector
5 2182124 Ice Stripper
6 2195914 Support & Motor
Assembly
7 2315522 Retainer,
Thermostat
8 Thermostat
(Not Available −−
Order D7824706Q)
9 681249 Screw
10
W10171529 Pan, Ice
11 67004101 Bracket,
Tube Support
12 67006531 Valve, Dual
Water Inlet
13 A3223101 Insert, Tube
14 67003729 Tubing, Plastic
15
W10146389 Harness, Icemaker
16 625910 Bracket
17 681390 Screw
18 67004710 Cover
19 Module Assembly
(Not Available −−
Order D7824706Q)
20 67006287 Screw
21 67005603 Funnel, Fill Tube
100
D7824706Q Complete Ice Maker

OPTIONAL PARTS
14
For Models: KBRS22KVWH00, KBRS22KVBL00, KBRS22KVSS00
(White) (Black) (Stainless Stainless)
W10234665
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
PAINT, TOUCH−UP (1/2oz.)
72017 White
72032 Black
4392901 Biscuit
PAINT, PRESSURIZED SPRAY
(12 oz.)
350942 Primer, White
350930 White
350939 Black
4392901 Biscuit
Important: The spray paint is
not to be used where the paint
may make contact with the door
gaskets.
PAINT, BULK (1 qt.)
799344 White (Uncut)
799344 Black (Uncut)
4392900 Biscuit (Uncut)
Miscellaneous
212643 Sealer, Gum
(4 Feet)
479502 Tape, Vinyl
(3/4 x 108")
505587 Sealer, Mastic
(1 Qt.)
503695 Cork, Sealer
(1/4 Pound)
542638 Grease, Silicone
(1/2 Oz.)
542639 Cement,
Alumilastic
(1−1/4 Oz.)
799833 Kit, Evaporator
Repair
(Aluminum Epoxy)
833938 Kit, Terminal
Connector
TORX SCREW WRENCH
1117510 Torx Key
ACCESSORIES
2217192 Cleaner,
Stainless Steel
