KitchenAid KSCS25MSMS User instructions

Cabinet Depth, Side by Side Refrigerator
®
PRODUCT MODEL NUMBERS OVERALL DIMENSIONS
CABINET OPENING DIMENSIONS
DOOR SWING DIMENSIONS
Electrical: A 115 Volt, 60 Hz., AC only 15- or 20-
amp fused, grounded electrical supply is required.
It is recommended that a separate circuit serving
only your refrigerator be provided. Use an outlet
that cannot be turned off by a switch. Do not use
an extension cord.
Water Supply: A cold water supply with water
pressure of between 30 and 120 psi (207 - 827 kPa)
is required to operate the water dispenser and ice
maker. If you have questions about your water
pressure, call a licensed, qualified plumber.
If a reverse osmosis water filtration system is
connected to your cold water supply, the water
pressure to the reverse osmosis system needs to
be a minimum of 40 to 60 psi (276 - 414 kPa).
The cabinet depth refrigerator can be installed into
a recessed opening, at the end of cabinets or as a
freestanding refrigerator.
Do not install the refrigerator near an oven, radiator,
or other heat source, nor in a location where the
temperature will fall below 55°F.
Because Whirlpool Corporation policy includes a continuous commitment to improve
our products, we reserve the right to change materials and specifications without notice.
Dimensions are for planning purposes only. For complete details, see Installation
Instructions packed with product. Specifications subject to change without notice.
Ref. 2318477
06-27-06
KSCS25MS
36"
(91.5 cm)
13¹⁄₄"
(34 cm)
16¹⁄₂"
(42 cm)
A
13⁵⁄₈"
(34.5 cm)
41³⁄₄"
(106 cm)
2⁵⁄₈"
(6.6 cm)
¹⁄₂"
(12.7 mm)
17"
(43.0 cm)
0"
(0.1 mm)
45¹⁄₂"
(115.6 cm
)
90˚
150˚
A. Dimensions may vary based on the model
24"
(61.0 cm)
27¹⁄₂"
(69.7 cm)
30¹⁄₈"
(76.4 cm) max.
35⁵⁄₈"
(90.5 cm)
A
15⁵⁄₈"
(39.6 cm)
19¹⁄₂"
(49.5 cm) 2⁵⁄₈"
(6.7 cm) max.
³⁄₈"
(95.3 mm)
21¹⁄₄"
(54.1 cm)
66"
(167.7 cm)
3⁵⁄₈" (9.2 cm)
C
AB
35¹¹⁄₁₆"
(90.6 cm)
A
3⁵⁄₈"
(9.2 cm)
Model size Door Height "A" "B" "C" "D"
23 cu.ft. (654 L) 64 7/8" (164.8 cm) 68 3/4" (174.6 cm) 68 7/8" (175.0 cm) 68 1/2" (174.0 cm)
25 cu.ft. (694 L) 67 3/4" (172.1 cm) 71 3/4" (182.2 cm) 71 7/8" (182.5 cm) 71 1/2" (181.6 cm)
Height "A" Height "A"
Model size Standard Cabinet Full-overlay*
23 cu.ft. (654 L) 69" (175.3 cm) 69 1/8" (175.6 cm)
25 cu.ft. (694 L) 72" (182.9 cm) 72 1/8" (183.2 cm)
■Height dimensions are shown with the
leveling legs extended to the minimum
height of 1/4" (6.35 mm) below the
refrigerator.
When leveling legs are fully extended
to 1" (25 mm) below the refrigerator,
add 3/4" (19 mm) to the height
dimensions.
■The power cord is 66" (167.7 cm) long.
■The water line attached to the back of
the refrigerator is 78" (198.1 cm) long.
■Height dimensions are shown with the leveling legs
extended to the minimum height of 1/4" (6.35 mm) below
the refrigerator.
NOTE: When leveling legs are fully extended to 1"
(25 mm) below the refrigerator, add 3/4" (19 mm) to the
height dimensions.
■Minimum fixed wall position is 13-1/4" (34 cm) from the
freezer door and 16-1/2" (42 cm) from the refrigerator door.
*For full-overlay cabinet doors with a trim kit, the opening height
must be adjusted as shown.
A
BC
D
