1
CABINET PARTS
For Models: KSSP48MFW05, KSSP48MFS05, KSSP48MFB05
(White) (Stainless Steel) (Black)
7−97 Litho In U.S.A. (mek) Part No. 4394758
48" BUILT IN
REFRIGERATOR

2
CABINET PARTS
For Models: KSSP48MFW05, KSSP48MFS05, KSSP48MFB05
(White) (Stainless Steel) (Black)
4394758
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Cabinet (Not A
Serviceable Part)
3 2005004 Grommet, Tube
Crossover
4 1112023 Roller, Front &
Rear (4)
5 Support, Leveler
Assembly
2004506 Refrigerator Side
2004505 Freezer Side
6 2005006 Grommet, Wiring
7 2005007 Grommet,
Flexible
9 2004852 Mounting Stud,
Grill
11 1112849 Cap, Grommet
13 1113122 Grommet, Wiring
14 2004913 Wiring Harness,
Cabinet
16 488946 Tube, Clamp
17 2004993 Screw, Door Stop
18 Hinge (Top)
2001976 Left Side
2001975 Right Side
19 2000770 Shim, Hinge
Top
20 1112805 Guard, Wiring
21 2004994 Lock, Adjustable
Bushing
22 2002903 Bushing
24 Spring, Door
Closure
2004566 Refrigerator Side
2004567 Freezer Side
25 486194 Screw
26 2005008 Retaining Ring,
Adjustable Bushing
27 1113227 Fastener (3)
28 2004867 Gap, Cover
Assembly (Bottom)
29 Hinge (Bottom)
2004539 Freezer Side
2004507 Refrigerator Side
30 2004992 Bushing,
Adjustable
31 2001415 Screw
33 2004516 Linkage, Door
Closure
34 Grille Base,
Front
2004535 White
2004532 Stainless Steel
and Black Models
35 489238 Screw
36 2004512 Cover, Rear
37 1113123 Grommet, Wiring
39 2004595 Cup, Wiring
40 2004565 Bushing, Door
Closure
41 1163283 Screw
42 2150347 Union
43 2001415 Screw (4)

3
CABINET TRIM PARTS
For Models: KSSP48MFW05, KSSP48MFS05, KSSP48MFB05
(White) (Stainless Steel) (Black)
4394758
Illus. Part
No. No. DESCRIPTION
1 Cabinet, Trim (2)
2004668 White
2004553 Black
2004621 Stainless Steel
2 2003857 Screw
3 1163283 Screw
4 2004538 Cabinet, Trim
(Bottom)
5 486194 Screw
6 2003647 Cabinet, Trim Top

FREEZER LINER PARTS
4
For Models: KSSP48MFW05, KSSP48MFS05, KSSP48MFB05
(White) (Stainless Steel) (Black)
4394758
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Serviceable Part)
2 1113649 Bracket, Light
3 1113650 Lens
4 1112613 Light, Socket
5 548049 Light, Bulb
6 538533 Support Clip,
Icemaker (2)
7 2000193 Grommet, Screw (2)
8 488552 Screw
12 486194 Screw
13 1112591 Spacer, Control
Panel (3)
14 842534 Clip, Air Duct (4)
16 1112260 Support,
Evaporator
17 2004068 Stud, Shelf (20)
18 487559 Screw

5
REFRIGERATOR LINER PARTS
For Models: KSSP48MFW05, KSSP48MFS05, KSSP48MFB05
(White) (Stainless Steel) (Black)
4394758

6
REFRIGERATOR LINER PARTS
For Models: KSSP48MFW05, KSSP48MFS05, KSSP48MFB05
(White) (Stainless Steel) (Black)
4394758
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Serviceable Part)
2 1112591 Spacer, Control
Panel (3)
5 2001117 Ladder, Shelf (2)
6 520965 Screw Support,
Ladder (8)
7 488357 Screw
8 486194 Screw
9 1112257 Hole Plug
10 2003579 Meat Pan, Air
Duct Cover
11 2000337 Meat Pan, Air Duct
12 2003299 Inlay, Control
Meat Pan
13 2001326 Seal, Air Duct
14 1112218 Damper Control,
Meat Pan
15 2003811 Control Knob,
Meat Pan
16 2003841 Retainer, Knob
17 2000343 Air Baffle
Assembly
20 2001073 Wiring Harness,
Air Baffle
21 2001146 Seal
22 1116793 Cover, Thermistor
23 1116959 Thermistor
25 2003578 Air Baffle Cover
26 2003577 Guard, Air Return

REFRIGERATOR CONTROL PANEL PARTS
7
For Models: KSSP48MFW05, KSSP48MFS05, KSSP48MFB05
(White) (Stainless Steel) (Black)
4394758
Illus. Part
No. No. DESCRIPTION
1 1112642 Control Panel
2 2003303 Inlay, Control
Panel
3 2004005 Circuit Board
4 2003842 Control Knob
5 2003841 Retainer, Knob
6 1118894 Switch, Rocker Arm
7 1113137 Seal, Control
Panel
8 489260 Screw (3)
9 2000153 Hole Plug (3)
10 1113775 Shield, Control
Panel
11 1112613 Socket, Light (2)
12 548049 Light Bulb (2)
13 486194 Screw
14 2003758 Wire, Light
15 2001141 Channel, Wiring
16 1115375 Clip, Wiring (2)

8
FREEZER CONTROL PANEL PARTS
For Models: KSSP48MFW05, KSSP48MFS05, KSSP48MFB05
(White) (Stainless Steel) (Black)
4394758
Illus. Part
No. No. DESCRIPTION
1 1113627 Control Panel
2 2003309 Inlay, Control
Panel
3 1113466 Thermostat &
Barrier Assembly
4 488974 Screw (2)
5 1115373 Switch, Rocker Arm
6 1113136 Seal, Control
Panel
8 489260 Screw (3)
9 2000153 Hole Plug (3)
10 1113769 Shield, Control
Panel
11 1112613 Socket, Light
12 486194 Screw
13 548049 Light Bulb
14 2001974 Channel, Wiring
16 2182112 Knob, Thermostat
17 1115375 Clip, Wiring

REFRIGERATOR SHELF PARTS
9
For Models: KSSP48MFW05, KSSP48MFS05, KSSP48MFB05
(White) (Stainless Steel) (Black)
4394758

REFRIGERATOR SHELF PARTS
10
For Models: KSSP48MFW05, KSSP48MFS05, KSSP48MFB05
(White) (Stainless Steel) (Black)
4394758
Illus. Part
No. No. DESCRIPTION
1 2174404 Frame, Shelf
2 2003377 Glass, Shelf
3 1112006 Reflector, Shelf
4 1113792 Gasket, Glass (2)
5 2179375 Rack, Wine
6 2169933 Egg Bin
7 2003327 Frame, Assembly
Meat Pan
8 2164373 Egg Carrier
9 1112247 Cover, Crisper
10 2003380 Glass, Crisper
(Includes #9)
11 2000742 Meat Pan,
Connector
12 2169935 Cover
14 2003317 Crisper Pan (2)
15 2174388 Roller
16 2174478 Eyelet, Roller
17 489211 Screw
20 2003322 Meat Pan
23 2002181 Retainer, Glass
25 2003411 Crisper Spacer,
Right Side (2)
27 1113169 Stop, Roller
28 2003410 Crisper Spacer,
Left Side (2)
29 486194 Screw

11
FREEZER SHELF PARTS
For Models: KSSP48MFW05, KSSP48MFS05, KSSP48MFB05
(White) (Stainless Steel) (Black)
4394758
Illus. Part
No. No. DESCRIPTION
1 2003144 Solid Shelf
2 2003135 Front, Ice
Compartment
3 1113638 Shelf, Fixed (2)
1112052 Shelf, Deep
4 2001626 Basket
5 2003114 Trim, Basket
6 Slide, Basket
2000061 Right Side
2000062 Left Side
7 486194 Screw
8 2003046 Hole Plug, Front
9 2003047 Hole Plug, Rear
10 2003045 Front Cover
Slide, Container
11 Slide, Container
2002720 Right Side
2002721 Left Side
12 2002727 Ice Container
13 1113169 Stop, Roller
14 2174478 Eyelet, Roller
15 2174388 Roller
16 489211 Screw
17 488886 Screw

TOP GRILLE AND UNIT COVER PARTS
12
For Models: KSSP48MFW05, KSSP48MFS05, KSSP48MFB05
(White) (Stainless Steel) (Black)
4394758
Illus. Part
No. No. DESCRIPTION
1 Top Grille
Assembly
2003718 White
2003715 Black
2004957 Stainless Steel
2 2004946 Cover, Unit
3 486194 Screw
4 2002484 Grille, Bracket
5 2001415 Screw
6 Decortive Panel
Assembly
2003727 White
2003724 Black
2004960 Stainless Steel
7 2003480 Guard, Compressor
Wiring
8 2003483 Guard, Water
Valve Wiring
9 Panel, Decorative
Acrylic
4318657 White
4318649 Black
4378763 Stainless Steel

REFRIGERATOR DOOR PARTS
13
For Models: KSSP48MFW05, KSSP48MFS05, KSSP48MFB05
(White) (Stainless Steel) (Black)
4394758

REFRIGERATOR DOOR PARTS
14
For Models: KSSP48MFW05, KSSP48MFS05, KSSP48MFB05
(White) (Stainless Steel) (Black)
4394758
Illus. Part
No. No. DESCRIPTION
1 2003872 Refrigerator
Door Panel
(Includes
Insulation)
2 939101 Screw Anchor (8)
3 2004521 Hinge Assembly,
Top
4 2004520 Spacer−Door,
Top
5 489282 Screw
6 2004523 Hinge Assembly,
Bottom
7 1112533 Gasket Retainer,
Side (2)
8 1112542 Gasket Retainer,
Top & Bottom
9 2001049 Door Gasket,
Magnetic
10 Panel, Decorative
4318654 White
4318646 Black
4378762 Stainless Steel
11 Handle, Door
2003680 White
2003679 Black
2004636 Stainless Steel
12 2001230 Washer
13 2004549 Door, Spacer
Bottom
15 Screw
2001208 White
487052 Stainless Steel
16 Trim (Top)
2005015 White
2005012 Black
2005018 Stainless Steel
18 Trim (Side)
2003676 White
2003675 Black
2004634 Stainless Steel
19 Trim (Bottom)
2003668 White
2003665 Black
2004630 Stainless Steel
20 1113950 Panel, Interior
Door
21 1113949 Ladder, Shelf (2)
22 1113948 Retainer, Shelf
Ladder (2)
23 1112514 Back Up Plate (8)
24 486194 Screw
25 1113955 Gasket
26 2003465 Door, Utility Bin
27 2003132 Door Shelf (4)
28 2165792 Butter Tray
29 2004881 Retaining Ring,
Door−Closure

FREEZER DOOR PARTS
15
For Models: KSSP48MFW05, KSSP48MFS05, KSSP48MFB05
(White) (Stainless Steel) (Black)
4394758

FREEZER DOOR PARTS
16
For Models: KSSP48MFW05, KSSP48MFS05, KSSP48MFB05
(White) (Stainless Steel) (Black)
4394758
Illus. Part
No. No. DESCRIPTION
1 2003878 Freezer Door
Panel (Includes
Insulation)
3 2001230 Washer
4 2004881 Retaining Ring,
Door−Closure
6 2004524 Hinge, Bottom
7 489282 Screw
8 2004521 Hinge, Top
9 2004520 Spacer−Door,
Top
12 1112533 Gasket Retainer,
Side (2)
13 1112539 Gasket Retainer,
Top & Bottom
14 2000878 Door Gasket,
Magnetic
15 486194 Screw (34)
16 Handle, Door
2003682 White
2003681 Black
2004637 Stainless Steel
18 2004549 Door, Spacer
20 Screw
2001208 White
487052 Stainless Steel
21 Trim (Top)
2005024 White
2005021 Black
2005027 Stainless Steel
23 Trim (Bottom)
2004671 White
2004562 Black
2004633 Stainless Steel
24 Trim (Side)
2003678 White
2003677 Black
2004635 Stainless Steel
26 2000179 Panel, Interior
Door
28 2003129 Shelf Bin (2)
33 939101 Screw Anchor
35 Panel, Decorative
4210790 White
4210535 Black
4378750 Stainless Steel
37 2005054 Insulation

UPPER UNIT PARTS
17
For Models: KSSP48MFW05, KSSP48MFS05, KSSP48MFB05
(White) (Stainless Steel) (Black)
4394758

UPPER UNIT PARTS
18
For Models: KSSP48MFW05, KSSP48MFS05, KSSP48MFB05
(White) (Stainless Steel) (Black)
4394758
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 2003398 Assembly, Unit
Base
2 2163787 Clip, Compressor
Mounting (4)
3 2183420 Compressor
(Includes Items
7, 8, 9, 11,
12 & 21)
(Also Order
876765 Tube Kit)
4 680975 Washer
5 2003389 Bushing, Foam
6 2163786 Grommet, Mounting
7 2172890 Wire Assembly
8 2176858 Overload
(Includes Relay)
9 2162358 Terminal Cover
11 Relay
(See Overload)
12 2169137 Capacitor
14 486899 Screw
15 487869 Screw
16 2003392 Condenser
17 943447 Grommet (4)
18 1113019 Clamp (4)
19 487522 Screw
20 851095 Wire Tie (2)
21 2164492 Drier
23 2169135 Motor, Fan
24 1108179 Blade, Fan
25 2003169 Orifice, Fan
27 489099 Screw (3)
29 486692 Speed Nut
30 2162044 Defrost Timer
31 488911 Screw
32 2000645 Sleeve,
Condenser
34 2003011 Process, Tube
35 486194 Screw
36 2003174 Cover, Fan
37 2003355 Cover, Condenser
38 2003263 Air Vane
39 2003381 Service Cord
41 1113162 Clamp, Cord (2)
42 1113229 Switch, Power
Disconnect
43 488879 Screw, Ground
44 653035 Clip, Cord Plug
45 2003356 Wiring Harness,
Unit Compartment
Following Parts Not Illustrated
and Optional Parts Not Included
978025 Valve, Access
(1/4")
978026 Valve, Access
(5/16")
978027 Valve, Access
(3/8")
978028 Valve, Access
(1/2")
978029 Valve, Access
(5/8")
978030 Valve, Access
(3/4")
876764 Valve, Access
(3/16")
REFRIGERANT CHARGE
7.5 oz.
(R−134A)

LOWER UNIT AND TUBE PARTS
19
For Models: KSSP48MFW05, KSSP48MFS05, KSSP48MFB05
(White) (Stainless Steel) (Black)
4394758

LOWER UNIT AND TUBE PARTS
20
For Models: KSSP48MFW05, KSSP48MFS05, KSSP48MFB05
(White) (Stainless Steel) (Black)
4394758
Illus. Part
No. No. DESCRIPTION
1 2000528 Defrost Bi−Metal
2 1113043 Clamp, Bi−Metal
3 486194 Screw
4 2003271 Sleeve
5 2002171 Sleeve
6 2002999 Condenser
Inlet Tube
7 2003484 Sleeve
8 2003015 Tube, Connect
(Drier)
9 2004545 Heater, Drain Pan
10 1113062 Hanger, Heater
12 2002448 Sleeve
13 2002995 Tube, Discharge
14 2003272 Sleeve
15 2003003 Heat Exchanger
16 2002966 Evaporator
17 2001608 Heater, Defrost
18 1113048 Clamp, Heater (2)
19 1108431 Clamp, Heater (2)
20 1112844 Gasket, Evaporator
21 857547 Wire Tie
23 851095 Strap
25 2001264 Drain Pan
26 Bracket, Drain Pan
1113206 Left
1113207 Right
27 513942 Dampener
