KitchenAid Vertigo Integrated Series User manual

Thanks for choosing
This story begins with
a cool glimpse of light
which easily burns into
a creative mind.
A story of timeless
moments of a serious
passion prepared to
become a delicious
art creation.
QuickReference Guide

Product Type:
Installation Guide
Produkttyp:
Installationsanleitung
Type de produit :
Consignes d'installation
Product Type:
Installatiegids
Nome Prodotto:
Guida di installazione
Produkttype:
Installationsvejledning
Tuotetyyppi:
Asennusopas
Produkttype:
Installasjonsveiledning
Produkttyp:
Installationsguide
KitchenAid
Vertigo

4

5
INDEX EN
1
1.1
1.2
IMPORTANT INSTRUCTIONS
Important safety instructions......................................................................................................................................
Children safety..................................................................................................................................................................
6
6
6
2
2.1
2.2
2.3
2.4
2.5
TECHNICAL REQUIREMENTS
Appliance features and installation requirements................................................................................................
Installation niche features: Integrated Series, 90cm Models.............................................................................
Installation niche features:Integrated Series, 60cm Column Models..............................................................
Installation niche features: Classic Series, 90cm Models...................................................................................
Installation niche features:Classic Series, 60cm Column Models....................................................................
6
6
7
7
9
10
3
3.1
3.2
3.3
3.4
PREPARING TO INSTALLATION
Transport to installation site and unpacking...........................................................................................................
Electrical and Water connection..................................................................................................................................
Energy: Alternatives and Home Automation...........................................................................................................
Levelling.............................................................................................................................................................................
11
11
11
12
13
4
4.1
4.2
4.3
4.4
4.5
4.6
4.7
PANELS MOUNTING
Decorative door and Bottom-Drawer panels layout.............................................................................................
Decorative panels layout for Fridge with one Bottom-Drawer (1T/0T)..........................................................
Decorative panels layout for Fridge column with glass door (0F)...................................................................
Panels Dimensions One Bottom - Drawer (1T models).......................................................................................
Panels Dimensions Column Models (0F models).......................................................................................
Mounting the handles....................................................................................................................................................
Mounting panels to the door and the drawer...........................................................................................................
13
13
15
16
17
18
19
19
5
5.1
5.2
5.3
5.4
INSTALLATION
Built-in installation of single appliance....................................................................................................................
Built-in installation of two or more appliances......................................................................................................
Free-standing installation two or more appliances..............................................................................................
Maximum cabinet depth over “Integrated” refrigerator with single door panel..........................................
21
21
21
23
24
6
6.1
6.3
6.4
6.5
COMPLETING THE INSTALLATION
Anti-tipping safety assembly........................................................................................................................................
Ventilation..........................................................................................................................................................................
Post installation control................................................................................................................................................
Start Up..............................................................................................................................................................................
25
25
26
27
27

6
1.1 Important safely instruction
Symbols used in the Guide:
Note
Tips for the correct use of the appliance
Important
Directions to avoid appliance damage
Warning
directions to prevent injury
1.2 Children safety
If this appliance is replacing an existing appliance
which must be removed or disposed of, make sure
that it does not become a dangerous trap for children
by cutting its power supply cable and rendering it
impossible to close the door.
Use the same caution at the end of the lifespan of the
new appliance.
Important!
Dimensions in parentheses are in inches.
Weights in parentheses are in pounds.
Temperatures in parentheses are
in Fahrenheit degrees.
1.IMPORTANT INSTRUCTIONS
Appliance
dimensions
Integrated
Series 60cm
w: 599 mm (23 5/8”)
h: 2050 mm (80 3/4”)
d: 615 mm (24 1/4”) 0F
Series 90cm
w: 899 mm (35 3/8”)
h: 2050 mm (80 3/4”)
d: 610 mm (24”) 1T
Appliance
dimensions
Classic
Series 60cm
w: 599 mm (23 5/8”)
h: 2050 mm (80 3/4”)
p: 640 mm (25 1/4”) 0F
Series 90cm
w: 899 mm (35 3/8”)
h: 2050 mm (80 3/4”)
d: 635 mm (25”) 1T
Weight with
packaging Series 60cm up to 200 kg (441 lb)
Series 90cm
up to 240 kg (529 lb)
Voltage Europe Version:
AC 220-240V 50 Hz
North America Version:
110V 60Hz
Power supply
cable Europe Version:
Schuko 16 A plug
Potable water
supply pressure from 0.05 MPa to 0.5 MPa
(0.5 Bar - 5 Bar)
Water supply tube 3/4” female attachment
Provided
installation
accessories
- Customized panels
mounting Kit
- Anti-tipping Kit (B04000200)
- Lateral connecting kit
(KCLIT/KCLIH)
- 4 mm (1/8”) allen wrench
Additional
equipment
necessary
- Phillips head screwdriver
- wood and percussion drill
- 2.5 mm (1/8”) bit for wood
- 8 mm (3/8”) bit for walls
- 17 mm (3/4”) wrench
2.1 Appliance features and installation
requirements
2. TECHNICAL REQUIREMENTS

7
2.2 Installation niche features:
Integrated Series, 90cm Models
A - area to be left clear for the anti-tipping brackets
E- area to be left clear for the power supply cable
W- and water supply hose
Minimum Niche Height
2064 mm (81 1/4”)
Minimum Niche Width
90cm: 900 mm (35 1/2”)
Minimum Niche Depth
650 mm (25 5/8”)
Door Swing Clearance
90cm: 1485 mm (58 1/2”)
Door Opening Angle
105°
Width
90cm: 899 mm (35 3/8”)
Height
2050 mm (80 3/4”) + 25 mm (1”)
Depth with door (without panel)
610 mm (24”)
Minimum distance from the wall (hinge side)
with door at 105° and 90°, with 18mm (3/4”)
panel and handle h=58mm (2 1/4”).
90cm: 160 mm (6 1/4”)
Dimensions in parentheses are in inches.
EN
105°
992 (39”)
220 (8 ⅝”)
90°
992 (39”)
1485 (58 ½”)
15 (¼”)
1485 (58 ½”)
610 (24”)
560 (22”)
1293 (50 ⅞” )
474
(18 ⅝”)
231 (9
⅛”
) +
25 (1”)
500 (19 ¾”)
248 (9
¾”
)
+ 25 (1”)
20 (¾”)15 (⅝”)
721 (28 ⅜”) +25 (1”)
2050 (80 ¾”) +25 (1”)
min 2064 (81 ¼”)
A A
E W E W
140 (5 ½”) 140 (5 ½”)
100 (4”) 100 (4”)
900 (35 ½”)
610 (24”)
560 (22”)
1293 (50 ⅞” )
474
(18 ⅝”)
231 (9
⅛”
) +
25 (1”)
500 (19 ¾”)
248 (9
¾”
)
+ 25 (1”)
20 (¾”)15 (⅝”)
721 (28 ⅜”) +25 (1”)
2050 (80 ¾”) +25 (1”)
min 2064 (81 ¼”)
A A
E W E W
140 (5 ½”) 140 (5 ½”)
100 (4”) 100 (4”)
900 (35 ½”)

8
2.3 Installation niche features:
Integrated Series, 60cm Column
Models
A - area to be left clear for the anti-tipping brackets
E- area to be left clear for the power supply cable
W- and water supply hose
Minimum Niche Height
2064 mm (81 1/4”)
Minimum Niche Width
60cm: 600 mm (23 3/4”)
Minimum Niche Depth
650 mm (25 5/8”)
Door Swing Clearance
60cm: 1175 mm (46 7/8”)
Door Opening Angle
105°
Width
60cm: 599 mm (23 5/8”)
Height
2050 mm (80 3/4”) + 25 mm (1”)
Depth with door (without panel)
615 mm (24 1/4”)
Minimum distance from the wall (hinge side)
with door at 105° and 90°, with 18mm (3/4”)
panel and handle h=58mm (2 1/4”).
60cm: 90 mm (3 1/2”)
Dimensions in parentheses are in inches.
2. TECHNICAL REQUIREMENTS
615 (24 ¼” )
565 (22 ¼” )
1808 (71 ¼” )
231 (9
⅛”
) +
25 (1”)
233 (9
¼”
)
+ 25 (1”)
15 (⅝”)
2050 (80 ¾”) +25 (1”)
min 2064 (81 ¼”)
A A
E W E W
140 (5 ½”) 140 (5 ½”)
100 (4”)
100 (4”)
600 (23 ¾”)
522 (20 ½”)
105°
150 (5 ⅞”)
90°
1190 (46 ⅞”) 1190 (46 ⅞”)
15 (6 ¼”)
565 (22 ¼”)

9
EN
2.4 Installation niche features:
Classic Series, 90cm Models
A - area to be left clear for the anti-tipping brackets
E- area to be left clear for the power supply cable
W- and water supply hose
Minimum Niche Height
2064 mm (81 1/4”)
Minimum Niche Width
90cm: 900 mm (35 1/2”)
Minimum Niche Depth
650 mm (25 5/8”)
Door Swing Clearance
90cm: 1475 mm (58 1/8”)
Door Opening Angle
105°
Width
90cm: 899 mm (35 3/8”)
Height
2050 mm (80 3/4”) + 25 mm (1”)
Depth with door
635 mm (25”)
Minimum distance from the wall (hinge side)
90cm: 230 mm (9”)
Dimensions in parentheses are in inches.
min 2064 (81 ¼”)
A A
E W E W
140 (5 ½”)140 (5 ½”)
100 (4”) 100 (4”)
900 (35 ½”)
635 (25”)
560 (22”)
693 (27 ¼”)
2050 (80 ¾”) +25 (1”)
1308 (51 ½”)587 (23 ⅛”)
146 (5 ¾”)
+ 25(1”)
9 ( ⅜”)
732 (28 ⅞”)+25 (1”)
1016 (40”)
105°
560 (22”)
75 (3”)
635 (25”)
230 (9”)
1475 (58 ⅛”)
25 (1”)
90°
58 (2 ¼”)
1475 (58 ⅛”)

10
2.5 Installation niche features:
Classic Series, 60cm Column Models
A - area to be left clear for the anti-tipping brackets
E- area to be left clear for the power supply cable
W- and water supply hose
Minimum Niche Height
2064 mm (81 1/4”)
Minimum Niche Width
60cm: 600 mm (23 3/4”)
Minimum Niche Depth
650 mm (25 5/8”)
Door Swing Clearance
60cm: 1180 mm (46 1/2”)
Door Opening Angle
105°
Width
60cm: 599 mm (23 5/8”)
Height
2050 mm (80 3/4”) + 25 mm (1”)
Depth with door
640 mm (25 1/4”)
Minimum distance from the wall (hinge side)
60cm: 160 mm (6 1/4”)
Dimensions in parentheses are in inches.
2. TECHNICAL REQUIREMENTS
640 (25 ¼” )
565 (22 ¼” )
698 (27 ½”)
2050 (80 ¾”) +25 (1”)
1904 (75”)
146 (5 ¾”)
+ 25(1”)
min 2064 (81 ¼”)
A A
E W E W
140 (5 ½”) 140 (5 ½”)
100 (4”)
100 (4”)
600 (23 ¾”)
105°
160 (6 ¼”)
90°
1180 (46 ½”)
25 (1”)
1180 (46 ½”)
