TOP AND CABINET PARTS
1
For Models: KHWS02RWH3, KHWS02RMT3
(White) (Meteorite)
7−06 Printed in U.S.A. (drd) Part No. 8181484
AUTOMATIC
WASHER

TOP AND CABINET PARTS
2
For Models: KHWS02RWH3, KHWS02RMT3
(White) (Meteorite)
8181484
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature Parts
8182751 Use & Care Guide
8182142 DVD−Instruction
8182658 Quick Start Guide
8182208 Tech Sheet
2 Top
(Includes
Illus. 35)
8182772 White
8182773 Meteorite
3 Cabinet
8182609 White
8182145 Meteorite
4 Panel, Front
8182605 White
8182146 Meteorite
5 Toe Panel
8181643 White
8182148 Meteorite
6 8181636 Foot, Leveling
7 8181763 Bracket, Spring
8 8183008 Brace, Side Panel
9 8181635 Pan, Bottom
10 8182698 Panel, Rear
11 8182661 Brace, Transport
12 Bolt, Shipping
8182797 Upper
8182798 Lower
13 Hose, Water Inlet
8182795 Blue Coupler
8182792 Red Coupler
14 8183009 Cord, Power
15 8181690 Strain Relief
16 8182607 Brace, Rear
17 8182701 Clip, Drain Hose
18 8181737 Hose, Drain
(Outer)
19 8181738 Connector,
Drain Hose
20 8181752 Clamp, Hose
21 8181632 Brace, Top
22 8183019 Filter,
Interference
23 8181695 Switch, Pressure
24 8181739 Hose, Pressure
Switch
25 8181691 Screw
26 8182700 Cover, Transport
27 8181768 Storage, Hose
28 8181828 Screw
29 8182830 Microswitch (2)
30 8182699 Grommet,
31 8182201 Screw, 3 x 8 mm
32 8182702 Clip, Outer Hose
Holder
33 8182639 Sound Absorber,
Toe Panel
34 8182640 Sound Absorber,
Bottom
35 8182775 Sound Absorber,
Top
36 8182776 Sound Absorber,
Bottom Rear Panel
37 8182777 Sound Absorber,
Rear Panel−
Middle (2)
38 8182778 Sound Absorber,
Cabinet (2)
Following Parts Not Illustrated
8182109 Harness Channel

DOOR AND LATCH PARTS
3
For Models: KHWS02RWH3, KHWS02RMT3
(White) (Meteorite)
8181484

DOOR AND LATCH PARTS
4
For Models: KHWS02RWH3, KHWS02RMT3
(White) (Meteorite)
8181484
Illus. Part
No. No. DESCRIPTION
5 8182119 Bellow
6 8182210 Clamp, Bellow
(Rear)
7 8182634 Lock, Door
8 8181760 Screw
9 8181651 Hook, Door
10 8181758 Screw
14 8182211 Clamp, Bellow
(Front)
15 8181659 Clamp, Support
16 8181650 Clamp, Glass
17 8181785 Screw
18 8182153 Foam, Door Handle
20 8182151 Door Frame Asm
21 8181655 Glass, Door
22 8182678 Door,
Back Support
23 8181843 Hinge, Door
24 8181660 Screw
25 8181661 Screw
26 8181718 Tube, Dispenser
to Bellow
27 Trim, Upper Left
8182592 White
8182155 Meteorite
28 Cover, Hinge
(Outer)
8182595 White
8182627 Meteorite
29 Cover, Hinge
(Inner)
8182596 White
8182154 Meteorite
30 Trim, Lower
8182594 White
8182157 Meteorite
31 Handle, Door
8182591 White
8182152 Meteorite
32 8182779 Clip, Trim
33 Trim, Upper Right
8182593 White
8182156 Meteorite
34 8181759 Screw

CONTROL PANEL PARTS
5
For Models: KHWS02RWH3, KHWS02RMT3
(White) (Meteorite)
8181484

CONTROL PANEL PARTS
6
For Models: KHWS02RWH3, KHWS02RMT3
(White) (Meteorite)
8181484
Illus. Part
No. No. DESCRIPTION
1 Panel, Control
8182597 White
8182626 Meteorite
2 8182150 User Interface
3 Button, Power
8182601 White
8182177 Meteorite
4 8182183 Pal−nut
5 Button Set,
Left
8182604 White
8182178 Meteorite
6 Button Set,
Middle
8182603 White
8182179 Meteorite
7 Button Set,
Right
8182602 White
8182176 Meteorite
8 8182180 Button Set,
Start
9 8182166 Light, Indicator
(Status)
10 8182170 Window, Display
11 8182168 Light, Indicator
(3 Lights)
12 8182167 Light, Indicator
(9 Lights)
13 8182224 Brace, Front Top
14 8181640 Channel, Water
15 8182774 Microcomputer,
Machine Control
16 8181756 Screw
17 8182212 Harness, Wiring
(Main)
18 8182165 Light, Indicator
(Program)
19 8182169 Light, Indicator
(8 Lights)
20 8182171 Bezel, Knob
21 8182181 Overlay, Door
22 8182182 Medallion
23 8182175 Knob, Control
24 Endcap, Left
8182599 White
8182174 Meteorite
25 Endcap, Right
8182600 White
8182164 Meteorite
26 Handle, Drawer
(Includes
Illus. 24)
8182598 White
8182172 Meteorite

DISPENSER PARTS
7
For Models: KHWS02RWH3, KHWS02RMT3
(White) (Meteorite)
8181484

DISPENSER PARTS
8
For Models: KHWS02RWH3, KHWS02RMT3
(White) (Meteorite)
8181484
Illus. Part
No. No. DESCRIPTION
1 8182862 Valve, Inlet
2 8181710 Hose, Flowmeter
(L−Shaped)
3 8181751 Clamp
4 8181696 Flowmeter
5 8182173 Cushion, Handle
6 8181708 Hose, Flowmeter
7 8183010 Nozzle, Inlet
9 8183036 O−Ring
11 8181726 Cam, Actuator
12 8181725 Lever, Water
Distribution
13 8181723 Actuator
15 8181727 Spring, Lever
16 8181724 Connection, Lever
17 Dispenser
8183032 White
8183033 Meteorite
18 8181712 Nozzle,
Distribution
19 8181747 Seal
20 Handle, Drawer
8182598 White
8182172 Meteorite
21 Drawer,
Detergent
8181720 White
8182160 Meteorite
22 Container,
Detergent
8181722 White
8182184 Meteorite
23 Siphon,
Bleach/Softener
8182665 White
8182161 Meteorite
24 Separator
8181730 White
8182162 Meteorite
25 8181721 Hook, Drawer
26 8182123 Cap
27 8183022 Harness, Wiring
(Inlet Valve)

TUB AND BASKET PARTS
9
For Models: KHWS02RWH3, KHWS02RMT3
(White) (Meteorite)
8181484

TUB AND BASKET PARTS
10
For Models: KHWS02RWH3, KHWS02RMT3
(White) (Meteorite)
8181484
Illus. Part
No. No. DESCRIPTION
1 8182132 Nut, Pulley
2 8182650 Pulley
3 8182633 Belt
4 8181745 Grid, Ventilation
5 8181744 Pipe, Ventilation
6 8181746 Clamp
7 8181743 Hose, Exhaust
8 8181666 Tub, Rear
9 8181644 Counterweight,
Rear
10 8181673 Gasket, Tub
11 8182247 Basket
12 8182233 Baffle, Basket
13 8181748 O−Ring
14 8181731 Airtrap
15 8181645 Counterweight,
Front (2)
16 8182814 Spring,
Suspension
17 8181647 Bolt
18 8181742 Clamp
19 8181794 Hose, Tub to
Dispenser
20 8181667 Clamp
21 8181665 Tub, Front
22 8181648 Nut, Push−In
23 8182812 Shock Absorber
24 8181686 Clamp,
Heating Element
25 8182666 Element, Heating
26 8181705 NTC
27 8181687 Screw
Following Parts Not Illustrated
8182126 Screw, Baffle
Mounting

PUMP AND MOTOR PARTS
11
For Models: KHWS02RWH3, KHWS02RMT3
(White) (Meteorite)
8181484

PUMP AND MOTOR PARTS
12
For Models: KHWS02RWH3, KHWS02RMT3
(White) (Meteorite)
8181484
Illus. Part
No. No. DESCRIPTION
1 8182706 Control Unit
(Motor)
4 8181733 Ball
5 8181734 Clamp
6 8181732 Hose,
Tub to Pump
7 8181753 Clamp
8 8182820 Grommet, Damper
(Rear)
9 8181752 Clamp
10 8182821 Pump (Complete)
11 8182816 Grommet, Damper
(Front)
13 8181736 Seal, Filter Cap
14 8183027 Cap, Filter
16 8182793 Motor
17 8181782 Harness, Motor
18 8181761 Bolt, Motor
19 8181755 Retainer,
Drain Hose
20 8181740 Drain Hose
(Inner)

OPTIONAL PARTS (NOT INCLUDED)
13
For Models: KHWS02RWH3, KHWS02RMT3
(White) (Meteorite)
8181484
Illus. Part
No. No. DESCRIPTION
PAINT, TOUCH−UP (1/2oz.)
72017 White
4396603 Meteorite
PAINT, PRESSURIZED SPRAY
(12 oz.)
350938 Primer, Gray
350930 White
PAINT, BULK (1 qt.)
799344 White (Uncut)
ACCESSORY PARTS
285863 Drain Extension
