Kiturami KF User manual

KF WOOD BOILERS FOR HEATING AND HOT WATER
INSTALLATION AND OPERATION
MANUAL
HEATING –AIR CONDITIONING
Oil and natural gas Boilers

Thank you for selecting the KF Kiturami wood boiler.
Please read carefully the instruction manual for proper
installation of the boiler and keep it for future use.
CONTENTS
SAFETY WARNINGS
DESCRIPTON OF KF BOILER
INSTALLATION OF KF BOILER
HYDRAULIC INSTALLATION OF KF BOILER
CHIMNEY INSTALLATION
KF BOILER CONTROL
THERMOSTAT CTR - 6080
SAFETY OPERATIONS
KF BOILER ELECTRICAL CONNECTION
KF BOILER IGNITION
CIRCULATOR & AIRVENT
OPERATION
GENERAL WARNINGS
MAINTENANCE
DAMAGES, DETECTION AND SOLUTIONS
TECHNICAL SPECIFICATIONS
2
page 11
page 12-13
page 14
page 14
page 15
page 3
page 4
page 5
page 6
page 7
page 8
page 9
page 9
page 10
page 10

SAFETY WARNINGS
It indicates points to remember with symbols in order to make the use of the boiler easier. In this way you
can see and avoid accidents.
Because your safety and the safety of others is very important, please look at the symbols below carefully
and understand them absolutely before proceeding to read the manual.
Each symbol has following meaning:
General danger,
Warning and caution
Things to be done
Do not touch
Not fire
General prohibitions
Must be grounded
Attention
• Protect the boiler from snow and rain. Ensure that it is instalLED in a covered area for better and safer
operation.
• Do not leave in front of and around the boiler flammable materials.
• In winter, even if you are away from home, do not disconnect the boiler from the mains.
3

DESCRIPTION OF KF BOILER
SAFETY WARNINGS
12
13
14
9
10
11
1
5
6
3
2
7
8
4
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
Boiler cleaning locker
Door for checking the flame
Wood supplying door
Setting the input of air
Boiler control
Power supply
Red and white: thermostat connection
Green wires: circulator connection
Chimney
Cold domestic water inlet
Output of water to radiators
Hot domestic water outlet
Discharge to open expansion tank
Safety valve
4

KF BOILER INSTALLATION
The boiler must be placed in an area with sufficient comfort –spaciousness so you can control it and
maintain it easily.
How to place the boiler:
• Place it on unburned - non-combustible materials, such as concrete which can withstand much weight.
• Never put the boiler in a small, enclosed space without ventilation or a very humid space. This will cause
incomplete combustion because of oxygen deficiency.
• Do not install the boiler in unprotected, open space.
• Connect the plug of the boiler to the mains using a socket only for it.
Attention
The installation should be performed by qualified technicians and in accordance with the
instructions.
5

HYDRAULIC INSTALLATION OF KF BOILER
Install the KF KITURAMI wood boiler according to the following drawing:
Place the open expansion tank at least 1 meter above the rest Plumber Heating.
The diameter of the discharge and filling pipe shall be at least Φ22.
Place an expansion tank and a safety valve in the hydraulic domestic waterinstallation.
Before connecting the domestic water to the boiler measure the pressure of the water supply network.
Then adjust the expansion water tank at the same bar and insert a corresponding safety valve. E.g. we
assume the water is 4 bars. Then select a valve of 6 bars and adjust the expansion tank at 4 bars.
6
WOOD BOILER WIRING
Open expansion
tank
Filling Boiler
Water
Safety Valve
Heating return
Water discharge
Hot domestic water
outlet
Heating flow
Domestic water inlet

CHIMNEY INSTALLATION
The installation of the chimney to the wood boiler plays important role and should be done very carefully.
Place the chimney according to the following drawings:
Connect the horizontal and vertical part of the chimney with a
cleaning T.
The vertical part of the chimney, should be at least 3m.
When neighboring buildings are at 1m distance from the
chimney, install chimney in such a way that it will be 1m or more
higher than the highest roof.
If not properly instalLED the chimney, there will be reduced
performance, soot and operational problems will occur.
Connect drain tube of the boiler.
7

KF - 3203 B BOILER CONTROL
‘Boiler water temperature indication
Ventilator LED
Circulator LED
Low water level LED
Overheating LED
Ventilator activation button
Power (Reset) button
Boiler water temperature indication
Ventilator operation LED
Circulator operation LED
Shows the water temperature in the boiler and displays
trouble codes in case of problems.
During the operation of the ventilator the LED remains open. (it
is turned off automatically when the temperature drops below
40°C).
During the operation of the pump, The LED remains on.
The LED lights in the absence of water in the boiler and is
deactivated the circulator.
The circulation pump resumes when the boiler is filled with
water.
In case of overheating, the LED turns on.
We press the button when we kindle the wood in the boiler
and the water temperature is below 40°C.
Starting the boiler or restarting after failure.
Low water level LED
Overheating LED
Ventilator activation button
Power (Reset)
8

THERMOSTAT (CTR-6080)
Boiler water temperature
display
65
ON/OFF RESET
button
Boiler water
temperature selection
POWER
HEATING
HOT
WATER
Heating room
selection
Hot domestic
water selection
Boiler Water Temperature Display - Displays the water temperature in the boiler with numbers. Also displays
Trouble Codes in case of malfunction.
Boiler Water Temperature Selection –Select the desired temperature from 45°C to ~85°C.
ON/OFF (Reset) Button - Activates or deactivates the boiler. Also restarts the boiler in case of blocking.
(When the boiler is not operating, the thermostat must be closed).
Room Heating Selection - With this option, the boiler works to warm the space.
Hot Domestic Water Selection - The circulation pump stops working and plenty of hot water is available. To
have heating again, you should select the heating room mode.
Safety operations
Anti-freezing protection mode –The circulation pump is activated automatically when the water temperature
drops below 8° C to avoid the formation of ice on the heating network. It automatically returns to normal
operation when the temperature rises to 9° C.
Low water level mode - After filling water in the boiler, the pump will operate for 2 minutes continually to help
the air outcome from the water heating system.
Nonstick protection of the circulation pump mode –It activates the circulation pump, when we have selected the
hot water mode and the water temperature is below 40°C.

KF BOILER ELECTRICAL CONNECTION
• Connect the circulator with the green wires to the boilers.
• Connect the thermostat with the red (+) & white (-) wire to the boiler.
• Insert the plug tothe mains.
KF BOILER IGNITION
• During the first ignition let air damper with an open door.
• Press the POWER button on the boiler control.
• Activate the room thermostat with the ON / OFF button.
• Select the desired water temperature and press the room heating mode selection.
• Place wood in the combustion chamber and kindle the fire.
• Press the button for activating the ventilator.
10

Instructions for regulating the wood burning
Original factory setting: 1 door open
After the boiler is heated, open or close the air damper as the wood boiler works. Close the damper if the
wood is burned quickly or open it if the wood is not burned good. Use the settings as in the following
illustrations.
3 doors open
(all)
2 doors open
1 door open
closed
Μην αγγίζετε την καμινάδα κατά τη λειτουργία του λέβητα.
CIRCULATOR &
AIR VENT
OPERATION
Water
temperature
selection in °C
45
55
65
75
85
Air Vent
ON
45
48
56
64
64
OFF
50
55
65
75
75
Circulator
ON
48
50
58
67
74
OFF
43
45
46
53
55
11

GENERAL WARNINGS
Use an outlet only for the plug of the boiler.
Attention to any electrical leakage!
The supplied current should be 230V/60Hz. Ensure the current voltage.
Do not clean the boiler with water.
Do not store flammable materials near the boiler.
• There is risk of fire. Make sure that there is a fire extinguisher in the boiler room.
• In case of damage please contact the service department or your supplier.
Do not touch the chimney during the boiler operation.
• It may cause burns.
Antifreeze protection.
• The antifreeze protection prevents ice forming in the boiler and pipework.
To operate the antifreeze protection, make sure that the boiler is connected with current.
• When you are away from home for some time, let the kitchen tap dripping.
• The antifreeze protection does not work if a power failure occurs or if the plug is not connected to the
mains.
12

GENERAL WARNINGS
Is proposed inspection and maintenance of the boiler once a year by qualified personnel.
Close manually the air damper if an interruption power occurs and there is wood burning in the
boiler.
Do not put a lot of wood at once.
Placing a lot of wood there is a risk of overheating and the risk of possible burns caused by hot
water or steam.
Always close the door after you put the supplying wood.
Always close the supplying door and clean the residual ash because otherwise there is a risk of
fire.
Be careful when opening or closing the supplying door because there is a risk of burns.
Install the boiler at a place that allows you easy cleaning.
Use dry wood.
The wet wood during combustion leaves residues like resin making necessary the very frequent
maintenance of the boiler.
If using wet wood you must clean the boiler very often.
13

MAINTENANCE
• Ensure that the boiler is cold during its maintenance.
• Clean the boiler mound of with a brush.
• Pick up with a broom the soot from the chamber and the cleaning door.
For greater money saving clean the boiler frequently.
DAMAGES –DETECTION AND SOLUTIONS
In case that any damage occurs to the boiler, the thermostat will display one of the following codes:
04
05
95
&
Low
Water
Is disconnected the temperature sensor or is damaged.
There is a high temperature in the boiler water. The function of the ventilator stops while the
circulation pump continues to run.
Close the air damper.
There is a lack of water. Fill water into the open expansion tank.
When the boiler is filled with water, the circulation pump will automatically start functioning
and will work for two minutes for easier air extraction from the water in the heating system.
The circulation pump will not work if is selected the hot domestic water mode.
If there is no voltage
Check the plug. Check the outlet in which you inserted the plug.
There is electricity, but the ventilator and the circulator do not operate.
Check their connections.
The boiler is hot but the area and the radiators are cold
Check the piping network for the existence of air and if any, remove it from the radiators by
evaporation.
Check if the circulation pump operates.
Keep the chimney clean for the normal operation of the boiler.
14

Use a circulation pump proportional to the boiler dynamics and
the installation requirements.
Install a water drain valve in the installation.
TECHNICAL SPECIFICATIONS
TYPE
FUEL
POWER (KW)
HEATING PERFORMANCE (KW)
COMBUSTION TYPE
ABILITY TO CONSUME WOOD (Kgr/h)
RECOMMENDED INSTALLATION TYPE
MAXIMUM PERFORMANCE IN HEATING (%)
MAXIMUM PERFORMANCE IN HOT WATER (%)
PERFORMANCE IN HOT WATER (KW)
HEATING SUPPLY SECTIONS
HOT WATER SUPPLY SECTIONS
DISCHARGING SECTION
CHIMNEY DIAMETER (Ø)
DIMMENSIONS WIDTH –LENGTH - HEIGHT
WEIGTH (Kgr)
SAFETY OPERATIONS
KF 35
WOOD
KF 60
40,7 69,8
23,2-34,9 34,9-45,5
FORCED COMBUSTION
8,1 10,5
OPEN EXPANSION TANK
75
75
23,2 - 34,9 34,9-45,5
32A
20A
20A
150
700*1000*1050 870*1325*1390
250 330
• OVERHEATING
• LOW WATER LEVEL
• ANTIFREEZE PROTECTION
Exhaust gases outlet temperature: less than 300 ° C.
The external shape and dimensions can be changed without prior notice.
15

Exclusive Representation
Collateral of Egnatia Road P.O. Box 1200 P.C. 57 008 Diavata
Interchange, Thessaloniki
Tel.: [phone] • Fax.: [phone]
e-mail: [email protected] • www.climacontrol.gr
HEATING –AIR CONDITIONING
