Klaxon G0250IT0103 User manual

COFFEE TABLE
Component Checklist
Installation Steps
STEP 1
MINIFIX SET DRUM INSERTING SCREW INSERTING
Installation Instructions
1. This product should only be installed by someone who fully understand the installation instructions.
2. Make sure that the supporting surface will safely support the combined load of the equipment, hardware
& components
3. Never exceed the maximum load capacity.
4. Always use assistant or mechanical lifting equipment, if needed, to safely lift & position equipment.
5. Tighten screws firmly, but do not over-tighten. Over-tightening can damage the screw & reduce their
holding power
6. This product is intended for indoor use only. Using this product outdoors could lead to product failure
& personal injury.
FIX ALL Minifix-Screws and Minifix-Drums:
Note: Make sure
Drum inserting
as same as above,
Drum arrow direction
at side surface
hole side.
Note: Tight the screw clock-vise till
the thread disappear.
STEP 4
Connect E with F:
Note: Tight all Minifix-Drum Properly.
SCREW
SCREW HOLDER
DRUM
DOWEL
PUSH DOWN
STEP 2
Unlock Mode:
Minifix-Drum
Arrow at Hole
Side Before
Inserting Minifix-Screw
STEP 3
Lock Mode:
Note: Make sure all the given points otherwise
it will not fix properly.
Note: Tight all Minifix-Drum Properly.
Tight Minifix-Drum
Clock-wise
Till It Stops
and Fits properly

STEP 5
Connect G with F:
Note: Tight all Minifix-Drum Properly.
STEP 6
Connect C, B & D, A on both sides of G & E :
Note: Tight all Minifix-Drum Properly.
STEP 7
Place H on top of C, B & D, A:
Note: Tight all Minifix-Drum Properly.
INSTALLATION GUIDE
COFFEE TABLE - G0250IT0103
