Klaxon OLITE G0223IT0339 User manual

OLITE COMPUTER TABLE
G0223IT0339 / G0223IT0427 / G0223IT0428
Component Checklist
Installation Steps
STEP 1
MINIFIX SET DRUM INSERTING SCREW INSERTING
Installation Instructions
1. This product should only be installed by someone who fully understand the installation instructions.
2. Make sure that the supporting surface will safely support the combined load of the equipment, hardware
& components
3. Never exceed the maximum load capacity.
4. Always use assistant or mechanical lifting equipment, if needed, to safely lift & position equipment.
5. Tighten screws firmly, but do not over-tighten. Over-tightening can damage the screw & reduce their
holding power
6. This product is intended for indoor use only. Using this product outdoors could lead to product failure
& personal injury.
FIX ALL Minifix-Screws and Minifix-Drums:
Note: Make sure
Drum inserting
as same as above,
Drum arrow direction
at side surface
hole side.
Note: Tight the screw clock-vise till
the thread disappear.
STEP 4
Connect I with B:
Note: Tighten all JCBC / DW Screw OR Minifix-Drum
Properly.
SCREW
SCREW HOLDER
DRUM
DOWEL
PUSH DOWN
STEP 2
Unlock Mode:
Minifix-Drum
Arrow at Hole
Side Before
Inserting Minifix-Screw
STEP 3
Lock Mode:
Note: Make sure all the given points otherwise
it will not fix properly.
Note: Make sure all the given points otherwise
it will not fix properly.
Tight Minifix-Drum
Clock-wise
Till It Stops
and Fits properly
JCBC / DW SCREWS
For Direct Installation
as given Instruction Minifix Screw Set
Channels

STEP 5
Connect G with B and Connect F with G, I:
Note: Tighten all JCBC / DW Screw
OR Minifix-Drum
Properly.
STEP 6
Connect C with I and Connect D with B, C by given
channel and Connect H with B, C:
Note: Tighten all JCBC / DW Screw
OR Minifix-Drum
Properly.
STEP 7
Connect E with D; Connect A to above
set with B, H, C:
Note: Tighten all JCBC / DW Screw
OR Minifix-Drum
Properly.
OLITE COMPUTER TABLE
G0223IT0339 / G0223IT0427 / G0223IT0428
INSTALLATION GUIDE
Having Problems with INSTALLATION???
Got a Broken Part??? | DON’T WORRY !!
JUST CALL / WHATSAPP
[phone]
How to Connect Buffers at Bottom Base
2. Connect Given
Buffers at this
marks by nails
or screws
1. Different types of Buffers
