Klaxon Flashguard LED Flasher Module 102325 User manual

Installation Instructions
Flashguard LED Flasher Module
To Flashguard Xtra
1. Straighten the two LEDs by gently bending them in to
the upright position.
2. Peel the backing off the adhesive mounting brackets
provided and attach them to the inside of the cover as
shown below.
6 cm
3. Connect the unit to a suitable 12V supply, observing
polarity. The two LEDs will now flash alternately.
4. Slot the PCB into the mounting brackets with the LEDs
pointing towards the lens. Bend the LEDs into position if
required.
5. Fix the unit to the wall in the same way as an ordinary
simulated unit.
Wrigley Street, Oldham, Lancashire. OL4 1HW
Tel [phone] Fax [phone]
E-mail [email protected] www.klaxonsignals.com

Installation Instructions
Flashguard LED Flasher Module
To Flashguard XL PLus
PCB
È
È
È
È
1. Straighten the two LEDs by gently bending them in to
the the upright position.
2. Fix the board to the cut-out inside the cover using the
self-ashesive pads provided. Screws can be used if
desired.
3. Connect the unit to a
suitable 12V supply,
observing polarity. The
two LEDs will now
flash alternately.
4. Fix the unit to the wall
in the same way as an
ordinary simulated unit.
The Installers Choice
Part No. 102325
