KLD GT5H Assembly instructions

KLD GuitarAMP
GT5H
Tube GuitarAmplifier Manual
Kailing Electronic Co.,Ltd
http://www.kldguitar.com

Intended to alert the user to the presence of un-insulated “ dangerous voltage”
within the product’s enclosure that may be of sufficient magnitude to constitute
a risk of electric shock to persons.
Intended to alert the user to the presence of important operating and
maintenance (servicing) instructions in the literature accompanying the product
CAUTION: efore you “ON” GT-5H, please ensure it has been connected with
speaker. If not, it will damage tube and transform.
CAUTION Risk of electrical shock –DO NOT OPEN!
CAUTION To reduce the risk of electric shock, do not remove cover. No User
serviceable parts inside. Refer servicing to qualified service personnel.
WARRING To prevent electrical shock or fire hazard, do not expose this
appliance to rain or moisture. efore using this appliance, read the operating
guide for further warnings
Congratulations
CongratulationsCongratulations
Congratulations on your purchase of the GT-5H.This is smaller amp head
made by Kailing electronic Co.,Ltd ( http://www.kldguitar.com). One 12ax7 is
preamp design and one 6l6 is power amplifier. The KLDguitar GT-5HA is a single
end Class A guitar tube head amplifier. It is 5w. This guitar amplifier makes
small-room sessions lots of fun! A higher-gain preamp circuit has been added to
take the overdrive tone beyond that of the original. A choice of High or Low gain
inputs are included. With a switchable Pentode/Triode, you get the only amp in
its class that can deliver the full tonal range from instantaneous punch to
deliciously creamy / crunchy overdrive, with precise control via the output
volume.
FEATURES
5 watts (rms)
Tubs: One 6L6 and one 12AX7.
External jack for 4 and 8 ohms speaker
Controls: Gain. Volume and Tone
Hi-Lo impedance input
DI output (XLR Out)
Standby
Single End Class A
Pentode/Triode SW (3/5 W)
Precision made parts used for lowest signal to noise ratio.
5W metal oxide power resistors. 600V polypropylene film/foil and polyester
military capacitors

1. LOW INPUT: (1)
The input jack will accept signals from low impedance guitar pickups, e sure to
use a high-quality shielded cable to connect the guitar to the amplifier.
2. High INPUT:(2)
The input jack will accept signals from high impedance guitar pickups, e sure to
use a high-quality shielded cable to connect the guitar to the amplifier.
3. Gain (3)
Preamp Gain levels control
4. Tones:(4)
Tones level control
5. VOLUME:(5)
Volume controls. The final level adjustment should be made after the desired
sound has been achieved
6. STANBY:(6)
7.POWER:(7)
8. POWER SOCKET (8)
9.PENTODE /TRIODE SW (9)
5w/2.5w power switch
10. XLR DI:(10).
XLR DI out for recording.
11. OUTPUT:(11)
Provide for connection of external 4ohms speaker cabinet.
12. OUTPUT:(12)
Provide for connection of external 8ohms speaker cabinet.
SPECIFICATIONS
SPECIFICATIONSSPECIFICATIONS
SPECIFICATIONS
POWER AMPLIFIER SECTION
6L6’s with 12AX7 driver
Rated Power &Load
5w RMS into 8, 4 ohms
Power @Clipping(Typically)
(5%THD,1KHZ,120vAC line) 5W RMS into 8 ,4ohms( ias must be reduced to
measure)
Frequency Response:
+0,-2db,50HZ to 15KHZ,@, 20w RMS into 16 ohms
Hum &Noise:

Greater than 80 db below rated power
Power consumption:
50wtts 50/60HZ.120Vac(domestic)
PREAMPSECTION
12AX7’s
The following specs are measured @1KHz with the controls present as follows:
Pre
Nominal Level is with Input Gain
MINI level is with Input Gain
Preamp Normal Input
Impedance: Very high Z, 470Kohm
Effect send
-Load Impedance: 1Kohm or Greater; Nominal Output Level: -6d V, 0.5V RMS
Effect Return
Impedance: High Z, 2M ohms
Designed input Level:
-6d V,0.5VRMS (Switching jack provides Effect Send to Effects Return
connection when not used
IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONSIMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
WARNING :
WARNING :WARNING :
WARNING : When using electric products, basic cautions should always be
followed.
1. Read all safety and operating instructions before using this product.
2. All safety and operating instructions should be retained for future reference.
3. Obey all cautions in the operating instructions and on the back of the unit.
4. All operating instructions should be followed.
5. This production should not be used near water, i.e.. a bathroom , sink,
swimming pool, wet basement, etc.
6. This product should not be placed near a source of heat such as a stove,
radiator, or another heat producing amplifier.
7. This product should be located so that its position does not interfere with its
proper ventilation. It should not be placed flat against a wall or placed in a
built-in enclosure that will impede the flow of cooling air
8. Connect only to a power supply of the type marked on the unit adjacent to
the power supply cord.
9. Never break off the ground pin on the power supply cord
10.Power supply cords should always be handle carefully. Never walk or place
equipment on power supply cords. Periodically check cords for cuts or signs
of stress, especially at the plug and the point where the cord exits the unit.
11.The power supply cord should be unplugged when the unit is to be unused
for long periods of time.
12.If this products is to be cleaned with damp rag. The vinyl covering used on
some units can be cleaned with a damp rag or an ammonia-based household
cleaner if necessary. Disconnect unit from power supply before cleaning.
13. If the product is to be mounted in equipment rack, rear support should be
provided.
14.Care should be taken so that objects do not fall and liquids are not spilled
into the unit through the ventilation holes or any other openings.
15.This unit should be checked by a qualified service technician if:
A: The power supply cord or plug has been damaged
: Anything has fallen or been spilled into the unit.
C: The unit does not operate correctly
D: The unit has been dropped or the enclosure damaged.
16.The user should not attempt to service this equipment. All service work

should be done by a qualified service technician.
17.Exposure to extremely high noise levels may cause a permanent hearing loss.
Individuals vary considerably in susceptibility to noise induced hearing loss.
ut nearly everyone will lose some hearing if exposed to sufficiently intense
noise for a sufficient time.
SAVE THESE INSTRUCTIONS
Other Tips
Other TipsOther Tips
Other Tips
1.What time tube must be removed.
1.What time tube must be removed.1.What time tube must be removed.
1.What time tube must be removed.
(1) clear micro sound effect
(2) “kalakala” noise in background of Guitar
(3) Out power reduced
(4) ass become confuse
(5) Treble damaged
2.
2.2.
2. How to removed Tube.
How to removed Tube.How to removed Tube.
How to removed Tube.
Please look for expert to change tube. If you want change it self, please do
as below. Turn off the AMP, and take off electric power plug, wait for the
tube cold.
