Klimor MCKT-HPX Operator's manual

DOCUMENTATION OF AUTOMATIC CONTROL
FOR COMPACT UNITS
DTR.MCKT-HPX.
AUT-009.5.0
PAGE
GDYNIA
MCKT
-
HPX
2016
1/35
KLIMOR Spółka z ograniczonąodpowiedzialnością, 81-035 Gdynia, ul. B. Krzywoustego 5
Fax: [phone]; Tel.: [phone]
Service – Fax: [phone]; Tel.: [phone] Mobile: [phone]
Information provided in this document is subject to change
email: [email protected] – Office
[email protected] – Service
DOCUMENTATION OF AUTOMATIC
CONTROL FOR COMPACT VENTILATION
UNIT MCKT-HPX
SERVICE
Tel.: [phone]
Fax: [phone]
Mobile: [phone]
Email: [email protected]
November 2016

DOCUMENTATION OF AUTOMATIC CONTROL
FOR COMPACT UNITS
DTR.MCKT-HPX.
AUT-009.5.0
PAGE
GDYNIA
MCKT
-
HPX
2016
2/35
KLIMOR Spółka z ograniczonąodpowiedzialnością, 81-035 Gdynia, ul. B. Krzywoustego 5
Fax: [phone]; Tel.: [phone]
Service – Fax: [phone]; Tel.: [phone] Mobile: [phone]
Information provided in this document is subject to change
email: [email protected] – Office
[email protected] – Service
CONTENTS: .............................................................................................................................................. PAGE
1. INTRODUCTION ................................................................................................................................................3
1.1 DESCRIPTION OF CONTROL SYSTEM ...........................................................................................................3
1.2 FUNCTIONS OF CONTROL SYSTEM...............................................................................................................3
1.3 ELECTRIC PROTECTION .................................................................................................................................3
1.4 COMMUNICATION.............................................................................................................................................3
2. SUPPORTED DEVICES.....................................................................................................................................3
2.1 FANS ..................................................................................................................................................................3
2.1.1 RPM ADJUSTMENT OF MCKT-HPX 1 AND MCKT-HPX 2 FAN MOTORS ......................................................3
2.1.2 RPM ADJUSTMENT OF MCKT-HPX 3 FAN MOTORS .....................................................................................3
2.2 HEAT EXCHANGER ..........................................................................................................................................5
2.3 HEAT PUMP.......................................................................................................................................................5
2.4 FILTERS.............................................................................................................................................................5
2.5 OPTIONAL DEVICES.........................................................................................................................................5
2.5.1 PRELIMINARY ELECTRIC HEATER .................................................................................................................5
2.5.2 INLET AND OUTLET AIR DAMPERS ................................................................................................................5
3. CONTROL PANEL .............................................................................................................................................6
3.1 ASSEMBLY AND CONNECTION OF CONTROL PANEL..................................................................................6
3.2 CONTROL PANEL USER GUIDE ......................................................................................................................7
4. PRELIMINARY HEATER....................................................................................................................................7
5. AIR DAMPERS: INLET AND OUTLET AIR DAMPERS......................................................................................7
6. OPERATION OF THE CONTROL PANEL .........................................................................................................8
6.1 DESCRIPTION OF THE SCREENS...................................................................................................................8
6.1.1 SIMPLIFIED MENU SCREENS..........................................................................................................................8
6.1.2 MAIN SCREEN...................................................................................................................................................9
6.1.3 MAIN MENU .....................................................................................................................................................10
7. WIRING DIAGRAMS ........................................................................................................................................19
8. DANFOSS FC 51 INVERTERS FOR MCKT-HPX 3 .........................................................................................27
9. BMS VARIABLE LIST – RTU MODBUS PROTOCOL......................................................................................28
10. CONTROL MODULES OF PRELIMINARY ELECTRIC HEATERS..................................................................33
10.1 FUNCTIONAL DESCRIPTION .........................................................................................................................33
10.2 COOPERATION OF THE PRELIMINARY HEATER CONTROL MODULE WITH THE MCKT-HPX CONTROL
SYSTEM ......................................................................................................................................................................33

DOCUMENTATION OF AUTOMATIC CONTROL
FOR COMPACT UNITS
DTR.MCKT-HPX.
AUT-009.5.0
PAGE
GDYNIA
MCKT
-
HPX
2016
3/35
KLIMOR Spółka z ograniczonąodpowiedzialnością, 81-035 Gdynia, ul. B. Krzywoustego 5
Fax: [phone]; Tel.: [phone]
Service – Fax: [phone]; Tel.: [phone] Mobile: [phone]
Information provided in this document is subject to change
email: [email protected] – Office
[email protected] – Service
1. INTRODUCTION
1.1 Description of Control System
The control system is specifically designed for MCKT-HPX AHUs. The control algorithm, making use of up to 5
temperature sensors in total, enables highly efficient heat recovery from the air extracted from rooms. Application of
EC motors in MCKT-HPX 1 and MCKT-HPX 2 as well as AC motors controlled with inverters in MCKT-HPX3 also
enables stepless adjustment of fan RPM in entire control range.
The control system supports the heat pump as well as option’s air dampers and preliminary electric heater.
The room panel equipped with 4-line display, enables communication between a user and the control system
installed in the MCKT-HPX. A panel equipped with temperature sensor can be located in any room, which facilitates
operation and improves the comfort of usage.
The application of the MODBUS RTU protocol enables connecting the controller to the facility’s BMS system and
remote control and adjustment of the AHU.
1.2 Functions of control system
The control system is in charge of the following functions:
• Power supply: 1×230VAC – MCKT-HPX 1 i 3×400V MCKT-HPX 2 i MCKT-HPX 3
• power supply, protection and independent control of fan motors, heat pump compressor
• 24VAC power supply of optional air damper actuators
• power supply of control panel
• 2× communication ports RS 485
• 3x analog outputs 0-10V
• 5x non-voltage relay digital outputs, switched
• 5x digital temperature sensor inputs
• 4x non-voltage digital inputs
• 2x analog inputs 0-10V
• 2x quick transistorized output (PWM)
• weekly calendar with possible 4 time zones for each day
1.3 Electric protection
The control system has to be energized in accordance with the wiring diagram and has to be protected with a circuit
breaker with an appropriate rating for the receivers used.
Protection of fans, heat pump compressor and compressor casing heater depend on their output and are provided on
appropriate wiring diagrams.
1.4 Communication
The automatic control system enables communication with the BMS system using the MODBUS RTU –RS485
protocol.
Summary of variables in point 9.
2. SUPPORTED DEVICES
2.1 Fans
The control system enables independent control using 0÷10V voltage signals of air supply and air exhaust fans
equipped with 1-phase EC motors for MCKT-HPX 1 i MCKT-HPX 2 and 3-phase (3x230V) AC with inverters for
MCKT-HPX 3 size. It also enables providing power supply and protecting each of them individually.
2.1.1 RPM adjustment of MCKT-HPX 1 and MCKT-HPX 2 fan motors
The controller provides a 0÷10V signal directly to the EC motor
2.1.2 RPM adjustment of MCKT-HPX 3 fan motors
The controller provides the 0÷10V signal to the inverter which in a proportional way changes frequency of the fan
motor current.
AHUs are equipped with inverters with 1×230V 50Hz power supply, which control fan motors powered with 3x230V
50Hz. Each inverter is equipped with control panel shown below.

DOCUMENTATION OF AUTOMATIC CONTROL
FOR COMPACT UNITS
DTR.MCKT-HPX.
AUT-009.5.0
PAGE
GDYNIA
MCKT
-
HPX
2016
4/35
KLIMOR Spółka z ograniczonąodpowiedzialnością, 81-035 Gdynia, ul. B. Krzywoustego 5
Fax: [phone]; Tel.: [phone]
Service – Fax: [phone]; Tel.: [phone] Mobile: [phone]
Information provided in this document is subject to change
email: [email protected] – Office
[email protected] – Service
Picture 1 Inverter control panel for the MCKT-HPX 3
Picture 2 Description of inverter control panel for the MCKT-HPX 3
Use the [Menu] key to select one of the following menus:
Status
For readouts only.
Quick Menu
For access to Quick Menus 1 and 2, respectively.
Main Menu
For access to all parameters.
Navigation Keys
[Back]: For moving to the previous step or layer in the
navigation structure.
[▲] [▼]: For manoeuvring between parameter groups,
parameters and within parameters.
[OK]: For selecting a parameter and for accepting changes
to parameter settings.
Pressing [OK] for more than 1 s enters 'Adjust' mode. In
'Adjust' mode, it is possible to make fast adjustment by
pressing [▲] [▼] combined with [OK].
Press [▲] [▼] to change value. Press [OK] to shift between
digits quickly.
To exit 'Adjust' mode, press [OK] more than 1 s again with
changes saving or press [Back] without changes saving.
Operation Keys
A yellow light above the operation keys indicates the
active key.
[Hand on]: Starts the motor and enables control of the
frequency converter via the LCP.
[Off/Reset]: The motor stops except in alarm mode. In that
case the motor will be reset.
[Auto on]: The frequency converter is controlled either via
control terminals or serial communication.
[Potentiometer] (LCP12): The potentiometer works in two
ways depending on the mode in which the frequency
converter is running.
In Auto Mode the potentiometer acts as an extra
programmable analog input.
In Hand on Mode the potentiometer controls local
reference.

DOCUMENTATION OF AUTOMATIC CONTROL
FOR COMPACT UNITS
DTR.MCKT-HPX.
AUT-009.5.0
PAGE
GDYNIA
MCKT
-
HPX
2016
5/35
KLIMOR Spółka z ograniczonąodpowiedzialnością, 81-035 Gdynia, ul. B. Krzywoustego 5
Fax: [phone]; Tel.: [phone]
Service – Fax: [phone]; Tel.: [phone] Mobile: [phone]
Information provided in this document is subject to change
email: [email protected] – Office
[email protected] – Service
2.2 Heat exchanger
The control system controls defrosting of the cross-flow heat exchanger. When the controller receives a signal from
the temperature sensor (Tr) installed at the exchanger's air exhaust outlet regarding a drop of this temperature below
the setting (factory default: 0°C), it initiates the defrosting mode. It consists in turning on the preliminary heater, heat
pump compressor and air supply fan. Once the situation is under control (temperature above the setting) and after
3minutes, the AHU switches back to the normal operation mode.
2.3 Heat pump
The control system contains a complete algorithm of heat pump control with reverse operation option.
It covers the following functions:
- Turning on/off the compressor
- Turning on/off the solenoid valve controlling the compressor
- Turning on/off the 4-way valve switching the system operation
- Read out of high pressure gauge alert
- Read out of low pressure gauge alert
- Controlling the compressor casing heater
The MCKT-HPX AHU can be equipped with the preliminary electric heater (optional), which heats up fresh air
and ensures correct operation of the heat pump at low external temperatures (below -5°C).
2.4 Filters
The pressure gauges installed at filters indicate filter contamination and the need to replace them. When excessive
pressure drop on any of the filters is detected an alarm signal is displayed.
It is necessary to plan filter exchange/cleaning. The system should not operate for a longer with contaminated filters
as it can cause damage of the heat pump and/or fans' motors.
2.5 Optional devices
The MCKT-HPX control systems enable control of other devices which are not provided as standard AHU equipment.
They contain:
2.5.1 Preliminary electric heater
Preliminary electric heater energized and controlled with a separate module.
Power supply for the heater MCKT-HPX 1 – 1×230V/50Hz, for MCKT-HPX 2,3 – 3×400V/50Hz.
Heaters electric data – see point 10.
It is recommended to use pressure gauge pf air supply fan connected to appropriate terminals of electric heater
module.
2.5.2 Inlet and outlet air dampers
Inlet and outlet air dampers with on/off-controlled actuators, with 24VAC power supply.

DOCUMENTATION OF AUTOMATIC CONTROL
FOR COMPACT UNITS
DTR.MCKT-HPX.
AUT-009.5.0
PAGE
GDYNIA
MCKT
-
HPX
2016
6/35
KLIMOR Spółka z ograniczonąodpowiedzialnością, 81-035 Gdynia, ul. B. Krzywoustego 5
Fax: [phone]; Tel.: [phone]
Service – Fax: [phone]; Tel.: [phone] Mobile: [phone]
Information provided in this document is subject to change
email: [email protected] – Office
[email protected] – Service
3. CONTROL PANEL
The main component designed for communication with the controller of the control system is the control panel (it is
also possible to control the equipment with the BMS in the MODBUS RTU protocol).
Picture 3 Control panel view
3.1 Assembly and connection of control panel
The DEN16-C panel is energized with 12VDC supply from the Unibox controller. The power supply and control is
carried out both using 4-strand communication cable. It can be terminated at each side with RJ11 connectors (4-pin,
size 6) or can be connected directly to COM1 clamp connection. The cable with RJ connectors should be interlaced
as shown:
Picture 4 RJ clamp terminal view
If cables longer than 5 meters are used, it is recommended to use twisted-pair cables, eg. UTP
(1st pair: +12V, G0; 2nd pair: A, B).
Picture 5 Panel diameters

DOCUMENTATION OF AUTOMATIC CONTROL
FOR COMPACT UNITS
DTR.MCKT-HPX.
AUT-009.5.0
PAGE
GDYNIA
MCKT
-
HPX
2016
7/35
KLIMOR Spółka z ograniczonąodpowiedzialnością, 81-035 Gdynia, ul. B. Krzywoustego 5
Fax: [phone]; Tel.: [phone]
Service – Fax: [phone]; Tel.: [phone] Mobile: [phone]
Information provided in this document is subject to change
email: [email protected] – Office
[email protected] – Service
3.2 Control panel user guide
SWITCHING SYSTEM ON – press the OK button and hold it for 2s
SWITCHING SYSTEM OFF – press the ESC button and hold it for 2s
Menu navigation:
Active menu row is indicated with symbols, depending on editing capabilities of related parameters.
The ●symbol indicates that a parameter can be modified in the active menu line.
The ○symbol indicates that a parameter cannot be modified (preview only)
The ►symbol indicates that there is an embedded menu in the active line.
The symbol indicates that there is a locked embedded menu or unavailable parameter in the active line.
UP – scrolling menu line up
DOWN – scrolling menu line down
RIGHT – lower menu level
LEFT – higher menu level
OK - entering parameter edit mode/leaving edit mode with confirming changes
ESC – back to STANDBY screen/leaving edit mode and withdrawing changes
Navigation in the simplified menu:
RIGHT/LEFT – scrolling menu right/left
Description of each controller screens – see point 6.
NOTE!
1. The MCKT-HPX AHU is supplied with factory settings of individual parameters provided to the controller.
2. The user has to configure the system according to conditions in a facility where the MCKT-HPX is installed.
3. Changing most of the parameters entered by an user requires the password.
4. PRELIMINARY HEATER
In order to ensure appropriate operation of heat pump at external air temperate <-5°C it is recommended to use
preliminary electric heater installed at fresh air input for MCKT-HPX.
Electric connection of the heater – based on data provided in point 10.
The preliminary heater is energized and controlled with a separate control module which is energized independently
from the MCKT-HPX control cabinet.
MCKT-HPX 1 – 1×230V 20A power supply.
MCKT- HPX 2 and 3 – 3×400V power supply, 22.5A and 33.9A respectively.
Setting up the controller – “Settings” screen > “Preliminary heater”.
5. AIR DAMPERS: INLET AND OUTLET AIR DAMPERS
It is recommended to install dampers with actuators cutting out airflow when the unit is not in operation.
Air damper actuators, on/off-controlled with 24VAC power supply.
Electric connection of actuators to the control system – according to diagrams provided in point 7.

DOCUMENTATION OF AUTOMATIC CONTROL
FOR COMPACT UNITS
DTR.MCKT-HPX.
AUT-009.5.0
PAGE
GDYNIA
MCKT
-
HPX
2016
8/35
KLIMOR Spółka z ograniczonąodpowiedzialnością, 81-035 Gdynia, ul. B. Krzywoustego 5
Fax: [phone]; Tel.: [phone]
Service – Fax: [phone]; Tel.: [phone] Mobile: [phone]
Information provided in this document is subject to change
email: [email protected] – Office
[email protected] – Service
6.
OPERATION OF THE CONTROL PANEL
6.1 Description of the screens
6.1.1 Simplified menu screens
First six screens scrolled with the LEFT/RIGHT buttons enables in easy way the preview and settings of the most
important parameters of AHU operation. Use the UP/DOWN buttons to change parameters.
Implemented changes do not require confirmation with the OK button.
Changing parameters at screens 4, 5, 6 is only possible in the MANUAL mode.
6.1.1.1 Simplified menu screen 1
[Tref] – current value of temperate readout from a reference sensor
[ON/OFF] – turning on/off the AHU using this screen requires pressing and holding down OK/ESC button for 2
seconds.
6.1.1.2 Simplified menu screen 2
[Tref] – current value of temperate readout from external sensor
6.1.1.3 Simplified menu screen 3
[Mode] – {MANUAL, MAX, 1d, 2d+5d, 7d} – currently selected operation mode
6.1.1.4 Simplified menu screen 4
[Tzad] – currently requested temperature – this parameter can be edited in manual mode only
System status ON/OFF
Currently displayed parameter
Navigation buttons left/right

DOCUMENTATION OF AUTOMATIC CONTROL
FOR COMPACT UNITS
DTR.MCKT-HPX.
AUT-009.5.0
PAGE
GDYNIA
MCKT
-
HPX
2016
9/35
KLIMOR Spółka z ograniczonąodpowiedzialnością, 81-035 Gdynia, ul. B. Krzywoustego 5
Fax: [phone]; Tel.: [phone]
Service – Fax: [phone]; Tel.: [phone] Mobile: [phone]
Information provided in this document is subject to change
email: [email protected] – Office
[email protected] – Service
6.1.1.5 Simplified menu screen 5
[N%] – current setting of air supply fan – the parameter is editable only in manual mode, changes at 10% intervals
between min and max values defined in the advanced settings.
6.1.1.6 Simplified menu screen 6
[W%] – current setting of air exhaust fan – the parameter is editable only in manual mode, changes at 10% intervals
between min and max values defined in the advanced settings.
6.1.2 MAIN SCREEN
[dd] – current day
[hh:mm] – current time
[X] – {X=1|2|3|4} – indication of operation in week mode timer and calendar zone, in which the controller currently
operates
[MODE] – {MANUAL, MAX, 1d, 2d+5d, 7d} – currently selected operation mode
[Tz] – current value of external temperature
[Tzad] – currently preset temperature
[Tref] – current value of temperate readout from a master (reference) sensor
[N=, W=] – current speed of air supply and exhaust fans
[STATUS] – system’s current operation mode:
{STOP} – system is not working
{INIT} – opening dampers
{WORK} – standard operation
{RPRT} – standard operation, activation of the exchanger anti-freeze protection
{WOUT} – fan coasting after finished operation
{AST} – indication of AUTO STOP function operation
[ALARM] – current status of system alarms – see ALARMS menu
[App__] – information on currently chosen application
[Rs] – info about the master (reference) sensor selected for control
dd hh:mm X
MAIN MENU
►
MODE =
MANUAL
Tz=±__._°C
Tzad=__°C
Tref=__°C
N=__% W=__%
STATUS=_____
ALA M=___
App__, s=__

DOCUMENTATION OF AUTOMATIC CONTROL
FOR COMPACT UNITS
DTR.MCKT-HPX.
AUT-009.5.0
PAGE
GDYNIA
MCKT
-
HPX
2016
10/35
KLIMOR Spółka z ograniczonąodpowiedzialnością, 81-035 Gdynia, ul. B. Krzywoustego 5
Fax: [phone]; Tel.: [phone]
Service – Fax: [phone]; Tel.: [phone] Mobile: [phone]
Information provided in this document is subject to change
email: [email protected] – Office
[email protected] – Service
6.1.3 MAIN MENU
6.1.3.1 OPERATION MODE
[TRYB] – this parameter enables choosing a required operation mode:
{MANUAL} – operation in manual mode, all operating parameters set by the operator
{MAX} – turning on operation for FW time, preset fan speed at MAX level, once preset time elapses, switching
back to operation in the previously selected mode
{1d} – operation in automatic mode – specific settings for each weekday
{2d+5d} – operation in automatic mode – separate settings for MO–FR and separate ones for SA–SU
{7d} – operation in automatic mode – common settings for MO–SU
Settings of MANUAL mode
This screen enables setting preset fans speed and temperature in the MANUAL mode:
[N] – setting the air supply fan control value
[W] – setting the air exhaust fan control value
[Tzad] – temperature requested in MANUAL mode
Settings of ZONE mode
These screens enable setting operating AHU parameters in the ZONE mode:
[DN] – selection of weekday, which zones will be programmed
{MO, TU, … , SU} – setting for selected weekday of the 1d schedule
{5d} – settings for MO–FR of the 2d+5d schedule
{2d} – settings for SA–SU of the 2d+5d schedule
{7d} – settings for MO–SU of the 7d schedule
///Ust.ST .1
DN=dd
T=__°C
N=__% W=__%
Kon.Str.=__
FS=____
//ZONE setting
Zone1 ►
Zone2 ►
Zone3 ►
Zone4 ►
\\MANUAL setting
N=__% W=__%
Tzad=__°C
/OPE ATION MODE
MODE=MANUAL
MANUAL setting ►
ZONE setting ►
MAX setting ►
MAIN MENU
Operation mode ►
Input ►
Outputs ►
Settings ►
Adv.Settings ►
Alarms ►
Passwords ►
Info ►
Time/Language ►
evert settings►

DOCUMENTATION OF AUTOMATIC CONTROL
FOR COMPACT UNITS
DTR.MCKT-HPX.
AUT-009.5.0
PAGE
GDYNIA
MCKT
-
HPX
2016
11/35
KLIMOR Spółka z ograniczonąodpowiedzialnością, 81-035 Gdynia, ul. B. Krzywoustego 5
Fax: [phone]; Tel.: [phone]
Service – Fax: [phone]; Tel.: [phone] Mobile: [phone]
Information provided in this document is subject to change
email: [email protected] – Office
[email protected] – Service
[T] – setting preset temperature in the selected zone
[N] – setting the air supply fan control value
[W] – setting the air exhaust fan control value
[Kon.Str.] – end time of the selected zone
Picture 6 Programming of time zones
[FS] – turn ON/OFF setting in a selected zone:
{STOP} – system is not working
{RUN} – system is working
Settings of the MAX mode
[FW] – quick ventilation function: enables turning on fans regardless of the fan calendar in the MAX mode for the
preset time {1min–5h}, once the preset time elapses the system switches back to the operation according to the
ZONE/MANUAL settings (depending on the previously selected mode)
[N] – setting the control value of air supply fan in the MAX mode
[W] – setting the control value of air exhaust fan in the MAX mode
[FL] – current time left to the end of quick ventilation function
6.1.3.2 INPUTS
Sensors
[Tz] – current external temperature
[Tn] – current air supply temperature downstream of the counterflow heat exchanger
[Tn] – current air supply temperature downstream of the heat pump
[Tp] – current air temperature indicated by the sensor located in the DEN16-C panel
[Tw] – current temperature of air exhausted from rooms
[To] – current air temperature downstream of the heat recovery at the air exhauster
//SENSO S
Tz =±__._°C
Tn =±__._°C
Tn2=±__._°C
Tp =±__._°C
Tw =±__._°C
Tr =±__._°C
/INPUTS
Sensors ►
Digital ►
Analog ►
//MAX setting
FW=__min
N=__% W=__%
FL=__min

DOCUMENTATION OF AUTOMATIC CONTROL
FOR COMPACT UNITS
DTR.MCKT-HPX.
AUT-009.5.0
PAGE
GDYNIA
MCKT
-
HPX
2016
12/35
KLIMOR Spółka z ograniczonąodpowiedzialnością, 81-035 Gdynia, ul. B. Krzywoustego 5
Fax: [phone]; Tel.: [phone]
Service – Fax: [phone]; Tel.: [phone] Mobile: [phone]
Information provided in this document is subject to change
email: [email protected] – Office
[email protected] – Service
Digital inputs
Status indication of the Unibox digital inputs and Extender [0|1] module:
{DI2} – input 0 (DI0) – not used
{DI1} – input 1 (DI1) – pressure gauge of low pressure
{DI1} – input 2 (DI2) – pressure gauge of air supply/exhaust filter
{DI3} – input 3 (DI3) – fire alarm
{DI4} – input 4 (DI4) – pressure gauge of high pressure
{DI5} – input 5 (AIN0) – fan inverter alarm
{DI6} – input 6 (AIN1) – preliminary heater alarm
Analog inputs
Indication of analog inputs:
[AIN0] – fan inverter alarm
[AIN1] – preliminary heater alarm
6.1.3.3 OUTPUTS
Digital outputs
Indicating the status of the Unibox relay outputs [0|1]:
{DO1} – relay 1 (OUTPUT1) – solenoid valve 1
{DO2} – relay 2 (OUTPUT2) - 4-way valve
{DO3} – relay 3 (OUTPUT3) – air supply/exhaust dampers
{DO4} – relay 4 (OUTPUT4) – heat pump compressor
{DO5} – relay 5 (OUTPUT5) – solenoid valve 2
//DIGITAL
OUTPUTS
DO1=_
DO2=_
DO3=_
DO4=_
DO5=_
OUTPUTS
Digital ►
Analog ►
PWM ►
//WE.ANALOG.
AIN0=00%
AIN1=00%
//DIGITAL INPUTS
DI0=_
DI1=_
DI2=_
DI3=_
DI4=_
DI5=_
DI6=_

DOCUMENTATION OF AUTOMATIC CONTROL
FOR COMPACT UNITS
DTR.MCKT-HPX.
AUT-009.5.0
PAGE
GDYNIA
MCKT
-
HPX
2016
13/35
KLIMOR Spółka z ograniczonąodpowiedzialnością, 81-035 Gdynia, ul. B. Krzywoustego 5
Fax: [phone]; Tel.: [phone]
Service – Fax: [phone]; Tel.: [phone] Mobile: [phone]
Information provided in this document is subject to change
email: [email protected] – Office
[email protected] – Service
Analog outputs
Current status of the Unibox controller's analog outputs:
[OUTA] – current adjustment of the analog output of the supply fan’s control [%]
[OUTB] – current adjustment of the analog output of the exhaust fan’s control [%]
[OUTC] – current control level of the analog output of the preliminary electric heater control [%]
PWM output
[PWM1] – switching on the preliminary electric heater: 0% off, 99% on
[PWM2] – current control level of the PWM output of the preliminary electric heater control [%]
Enter service password 11-02 to enter the menu
6.1.3.4 SETTINGS
Temperature controller
[Rsn] – this parameter enables selection of the reference sensor according to which temperature control will be
carried out:
{TN} – air supply temperature sensor 1: control of temperature in the air supply duct;
{TN2} – air supply temperature sensor 2: fixed-value control algorithm is executed; requested fixed
temperature in the air supply duct is maintained;
{TW} – exhaust temperature sensor: the controller determines the supply air temperature based on the
averaged temperature of the exhausted air, while maintaining air supply threshold temperatures
{TP} – room temperature sensor: the controller determines the air supply temperature based on the air
temperature in the room, where the DEN16-C is located, while maintaining air supply threshold temperatures
Limiting supply air temperature:
[Thi] – upper temperature threshold
[Tlo] – lower temperature threshold
[H2TzEn] – external temperature over which the heat pump with heating function does not receive permission to
operate
[CTzEn] – external temperature below which the heat pump with cooling function does not receive permission to
operate
//TEMP
CONT OLLE
sn=___
Thi=±__°C
Tlo=±__°C
H2TzEn=__°C
CTzEn=__°C
/SETTINGS
eg.Temp. ►
Heating ►
Cooling ►
Pre.heater ►
Display ►
Communication ►
//PWM
PWM1=00%
PWM2=00%
//ANALOG OUTPUTS
OUTA=00%
OUTB=00%
OUTC=00%

DOCUMENTATION OF AUTOMATIC CONTROL
FOR COMPACT UNITS
DTR.MCKT-HPX.
AUT-009.5.0
PAGE
GDYNIA
MCKT
-
HPX
2016
14/35
KLIMOR Spółka z ograniczonąodpowiedzialnością, 81-035 Gdynia, ul. B. Krzywoustego 5
Fax: [phone]; Tel.: [phone]
Service – Fax: [phone]; Tel.: [phone] Mobile: [phone]
Information provided in this document is subject to change
email: [email protected] – Office
[email protected] – Service
Heat pump heating cycle
[RunH2] – {ON|OFF} – permission to operate the heat pump in heating function
[H2on] – heat pump turn-on threshold value in heating sequence function
[H2off] – heat pump turn-off threshold value in heating sequence function
Heat pump cooling cycle
[RunC] – {ON|OFF} – permission to operate the heat pump in cooling function
[Con] – heat pump turn-on threshold value in cooling sequence function
[Coff] – heat pump turn-off threshold value in cooling sequence function
Preliminary heater
[RunH1] – {ON|OFF} – preliminary heater operation permit
[TzOn] – turn-on temperature of the preliminary heater in the external temperature function
[TnOff] – temperature of deactivating the preliminary heater in the Tn air supply temperature function
When the external temperature drops below TzOn, the preliminary heater receives the operation permit. It operates
till the external temperature rises or the Tn air supply temperature exceeds the TnOff value.
[H1] – current status of the preliminary electric heater:
{1} – heater turned on
{0} – heater turned off
Picture 7 Heater programming
Display
[Contrast] – adjusting display contrast
[Backlight] – {1-9 min} switch off time of the display backlight
[Sound] – activation of the panel speaker
{YES} – speaker ON
{NO} – speaker OFF
//Display
Contrast=_
Backlight=__
Sound=___
//P E.HEATE
unH1=___
TzOn=±__°C
TnOff=±__°C
H1=_
//COOLING
unC=___
Con=__%
Coff=__%
//HEATING
unH2=___
H2on=__%
H2off=__%

DOCUMENTATION OF AUTOMATIC CONTROL
FOR COMPACT UNITS
DTR.MCKT-HPX.
AUT-009.5.0
PAGE
GDYNIA
MCKT
-
HPX
2016
15/35
KLIMOR Spółka z ograniczonąodpowiedzialnością, 81-035 Gdynia, ul. B. Krzywoustego 5
Fax: [phone]; Tel.: [phone]
Service – Fax: [phone]; Tel.: [phone] Mobile: [phone]
Information provided in this document is subject to change
email: [email protected] – Office
[email protected] – Service
Communication
[CtrlCOM2, CtrlCOM3] – selection of remote or local control using COM2/COM3 port:
{Loc} – local control with use of the DEN16-C panel; possibility of reading data via MODBUS
{Rem} – remote control, possibility of writing and reading data via MODBUS
[COM2, COM3] – {YES|NO} enables switching on communication with the use of the COM2/COM3 port and the
MODBUS RTU (RS485) data bus.
[BR2] – {9600|19.200} data transmission speed for COM2 (can only be changed in the STOP mode) [bits/s]
[BR3] – {9600|19.200|57.600|115.200} data transmission speed for COM3 (can only be changed in the STOP mode)
[bits/s]
[WifiPIN] – 4-digit PIN of the wireless communication module
The menu is available after entering the factory password
6.1.3.5 ADVANCED SETTINGS
Inputs
[DI0f]:[DI6f] –selecting alarm message displayed for the digital input’s signal:
{DIN} – digital input, no message
\\*INPUTS
DI0f=Din
S=_ =_
DI1f=LoP
S=_ =_
DI2f=Flt
S=_ =_
DI3f=POZ
S=_ =_
DI4f=HiP
S=_ =_
DI5f=VAL
S=_ =_
DI6f=!HE
S=_ =_
AINfn=__
/ADVANCED SETTINGS
Inputs ►
Fan ►
Sensors ►
Temp control ►
Heat recovery►
Heat pump ►
Time blocks ►
Auto Stop ►
Factory settings
►
//Communication
CtrlCOM2=___
COM2=___
B 2=_____
CtrlCOM3=___
COM3=___
B 3=_____
WifiPIN=____

DOCUMENTATION OF AUTOMATIC CONTROL
FOR COMPACT UNITS
DTR.MCKT-HPX.
AUT-009.5.0
PAGE
GDYNIA
MCKT
-
HPX
2016
16/35
KLIMOR Spółka z ograniczonąodpowiedzialnością, 81-035 Gdynia, ul. B. Krzywoustego 5
Fax: [phone]; Tel.: [phone]
Service – Fax: [phone]; Tel.: [phone] Mobile: [phone]
Information provided in this document is subject to change
email: [email protected] – Office
[email protected] – Service
{FLT} – collective alarm of the air supply and exhaust filters
{FRS} – anti-frost alarm
{!HE} – electrical heater alarm
{POZ} – fire alarm
{VNP} – air supply (or air supply and exhaust) fan compression too low
{VAL} – air supply/exhaust fan’s TK/inverter alarm
{LoP} – low pressure signal of heat pump compressor
{HiP} – high pressure signal of heat pump compressor
[S] – status of an individual input with the alarm message
{0} – alarm at open connector (the connector is normally closed - NC)
{1} – alarm at closed connector (the connector is normally open - NO)
[R] – selection of the alarm statuses number occurring during one hour to cancel the alarm
{0} – no need to confirm an alarm – alarm decay results in returning to normal operation
{1} – the first alarm from a particular input requires canceling
{2-6} – the number of alarms that needs to appear in an hour from the first alarm status in order for the alarm
to require confirmation on screen 0
[AINFn] – selecting a method to display universal inputs
{AI} – analog input
{DI} – digital input
Fans
[Nmin, Wmin] – the parameters limit the min requested RPM of the air supply and exhaust fans – it is not possible to
reduce the fan RPM below that value.
[MaxRpmN] – max air supply motor’s RPM value expressed by percentage of rated RPM (RpmN)
[MaxRpmW] – max air exhaust motor’s RPM value expressed by percentage of rated RPM (RpmW)
Sensors
[TpCor] – value read correction of the room sensor in the range (- 3°C; 0°C)
Temperature controller
Settings of the controller of the main heating/cooling loop:
[Ti1] – integration constant
[1/Kp1] – reinforcement converse
Settings of the controller of the lower limit of the air supply temperature:
[Ti2] – integration constant
[1/Kp2] – reinforcement converse
Settings of the controller of the upper limit of the air supply temperature:
[Ti3] – integration constant
[1/Kp3] – reinforcement converse
Heat recovery
//*TEMP.
CONT OLLE
Ti1=__
1/Kp1=__
Ti2=__
1/Kp2=__
Ti3=__
1/Kp3=__
//*SENSO S
TpCor=-_._°C
\\*FANS
Nmin=__%
Wmin=__%
Max pmN=__%
Max pmW=__%

DOCUMENTATION OF AUTOMATIC CONTROL
FOR COMPACT UNITS
DTR.MCKT-HPX.
AUT-009.5.0
PAGE
GDYNIA
MCKT
-
HPX
2016
17/35
KLIMOR Spółka z ograniczonąodpowiedzialnością, 81-035 Gdynia, ul. B. Krzywoustego 5
Fax: [phone]; Tel.: [phone]
Service – Fax: [phone]; Tel.: [phone] Mobile: [phone]
Information provided in this document is subject to change
email: [email protected] – Office
[email protected] – Service
[Rpr] – {YES|NO} – activation of anti-frost protection
[Sice] – selecting a sensor, based on which the anti-frost function will be carried out:
{Tr} – air exhaust sensor downstream the heat recovery
[Tice] – temperature of the anti-frost protection’s activation limit {0-30°C}
[RpOFF] – {0-59min} – delay after the system start, when the Rpr anti-frost protection function is activated
Heat pump
[AFPraca] – {YES|NO} – operation permit of the heat pump compression
Time blocks
[T1on] – activation delay of the fans after start
[T1off] – fans coasting time after stopping operation
[T2on] – not used
[T2off] – not used
[T3on] – not used
[T3off] – not used
[T4on] – not used
[T4off] – cooling OFF delay
[T5on] – not used
[T5off] – heating OFF delay
[T6on] – compressor ON delay in relation to the solenoid valve
[T6off] – compressor OFF delay in relation to the solenoid valve
[TRS1on] – min pause time between a switching off and switching on again the compressor
[TRS2on] – 4d valve opening time once the operation is finished, to compensate the system pressures
//*TIME BLOCKS
T1on =1m
T1off=0s
T2on =0s
T2off=0s
T3on =0s
T3off=0s
T4on =0s
T4off=10s
T5on =0s
T5off=10s
T6on =5s
T6off=5s
T S1on=2m
T S2on=1s
//*HEAT PUMP
AFpraca=___
//*HEAT ECOVE Y
pr=___
Sice=__
Tice=±__°C
pOFF=__min

DOCUMENTATION OF AUTOMATIC CONTROL
FOR COMPACT UNITS
DTR.MCKT-HPX.
AUT-009.5.0
PAGE
GDYNIA
MCKT
-
HPX
2016
18/35
KLIMOR Spółka z ograniczonąodpowiedzialnością, 81-035 Gdynia, ul. B. Krzywoustego 5
Fax: [phone]; Tel.: [phone]
Service – Fax: [phone]; Tel.: [phone] Mobile: [phone]
Information provided in this document is subject to change
email: [email protected] – Office
[email protected] – Service
Auto Stop function
[AS] – {YES|NO} activation of the AUTO STOP function forcing cyclic breaks in the 24h work cycle for the period of
time defined by the [ASDurat] parameter {1-30 min}, by number of hours defined by the [Int] parameter {1-23}
[Tleft] –current duration of device operation when the AUTO STOP function is activated
[Count] –number of the AUTO STOP function calls during 24h
Factory settings
[Factory settings] - {YES|NO} – selecting revert to factory settings (all parameters)
[Ap] – {App22} – does not apply to the MCKT HPX AHU
6.1.3.6 ALARMS
[RESET] – {0|1} changing status into 0 enables alarm reset. If a current alarm status does not require deleting the
message will disappear automatically after the alarm decays. Before the alarm can be reset the alarm condition must
decay.
[AL] – current status of the internal system’s alarms:
{COM} – no communication between the DEN16-C panel and Unibox controller
[AL0-AL6] – current status of the external system alarms:
{OK} – no alarms
{FRS} – anti-frost alarm
{FLT} – collective alarm of the air supply and exhaust filters’ pressure gauges
{!HE} – electrical heater alarm
{POZ} – fire alarm
{VNP} – air supply (or air supply and exhaust) fan compression too low
{VAL} – air supply/exhaust fan’s TK/inverter alarm
{LoP} – low pressure signal of heat pump compressor
{HiP} – high pressure signal of heat pump compressor
/ALA MY
ESET=_
AL =___
AL0=___
AL1=___
AL2=___
AL3=___
AL4=___
AL5=___
AL6=___
//*FACTO Y SETTINGS
Ust.Fab.=___
Ap=__
//*AUTO STOP
AS=___
Int=__h
ASdurat=__
Tleft=__min
Count=__

DOCUMENTATION OF AUTOMATIC CONTROL
FOR COMPACT UNITS
DTR.MCKT-HPX.
AUT-009.5.0
PAGE
GDYNIA
MCKT
-
HPX
2016
19/35
KLIMOR Spółka z ograniczonąodpowiedzialnością, 81-035 Gdynia, ul. B. Krzywoustego 5
Fax: [phone]; Tel.: [phone]
Service – Fax: [phone]; Tel.: [phone] Mobile: [phone]
Information provided in this document is subject to change
email: [email protected] – Office
[email protected] – Service
6.1.3.7PASSWORDS
[Password] – 4-digit access password to the service (11-02) or factory settings
6.1.3.8INFO
[Soft ver.] – current software version:
{sw} – DEN16-C panel
{mb} – UNIBOX controller
6.1.3.9 Time/Language
[Day] – setting the current weekday
[Time] – setting the current time
[Lang] – {PL|ANG} – language selection
6.1.3.10 Reverting the factory defaults
[Ustaw.Dom.] – {YES|NO} – reverting default parameters' values of week timer and service presets
7. WIRING DIAGRAMS
Dimensions of the control cabinet for MCKT-HPX (the same for all sizes): L×H×B - 380×300×120 mm
Wiring diagrams present STANDARD (right) version of the MCKT-HPX.
In non-standard version (left) of the MCKT-HPX, the 4-WAY VALVE is connected to the “NC” connector of the
“OUTPUT 2” relay.
The next pages of the manual contain information regarding:
- Wiring diagram of MCKT-HPX1
- Wiring diagram of MCKT-HPX2
- Wiring diagram of MCKT-HPX3
/FACTO Y
DEFAULTS
Ust.Dom.=
___
/TIME AND
LANGUAGE
Day:__
Time:hh-mm
Lang=__
/INFO
Soft ver.:
Sw___
Mb___
/PASSWO DS
Password:__-__

DOCUMENTATION OF AUTOMATIC CONTROL
FOR COMPACT UNITS
DTR.MCKT-HPX.
AUT-009.5.0
PAGE
GDYNIA
MCKT
-
HPX
2016
20/35
KLIMOR Spółka z ograniczonąodpowiedzialnością, 81-035 Gdynia, ul. B. Krzywoustego 5
Fax: [phone]; Tel.: [phone]
Service – Fax: [phone]; Tel.: [phone] Mobile: [phone]
Information provided in this document is subject to change
email: [email protected] – Office
[email protected] – Service
Picture 8.1 MCKT-HPX 1 wiring diagram
