KLING & FREITAG VIDA M Series User manual

EN | | VERSION 1.1 | 08/19/2019
USER‘S MANUAL
K&F VIDAM

User‘s Manual K&F VIDAM
©KLING & FREITAG GMBH Version 1.1 Page 3 of 40
Table of Content
Chapter / Content Page
1 Introduction 5
1.1 Icons Used 5
1.2 About this user's manual 5
2 Product Description 6
2.1 Intended Use 6
2.2 Versions 6
2.3 System requirements 7
2.4 Items Included 7
2.4.1 Items Included VIDA M 110 / 110 S 7
2.4.2 Items Included VIDA M 220 / 220 S 7
2.5 Overview of VIDA M 110 / 110 S Parts 8
2.6 Overview of VIDA M 220 / 220 S Parts 9
2.7 Front-panel indicator 10
2.8 Accessories 11
2.9 Dimensions 12
2.9.1 Dimensions VIDA M 110 / 110 S 12
2.9.2 Dimensions VIDA M 220 / 220 S 13
2.10 Technical Specifications 14
2.10.1 Technical Specifications VIDA M 110 14
2.10.2 Technical Specifications VIDA M 110 S 15
2.10.3 Technical Specifications VIDA M 220 16
2.10.4 Technical Specifications VIDA M 220 S 17
2.11 Measuring Diagrams 18
3 General Safety Instructions 20
4 Initial installation of VIDA M 220 / 220 S modules 21
5 Wiring 24
5.1 Terminal positions and purpose 24
5.2 Kardioid 24
5.2.1 AC power inlet 24
5.2.2 Audio terminals 25
5.2.3 GPIO 26
6 GPIO specifications 27
6.1 GPI 27
6.1.1 GPI internal wiring: 28
6.2 GPO 29
7 Systemlatency 30
7.1 Dante latency 30
7.1.1 Example 30
7.1.2 Changing between Dante redundancy operating modes 31

User‘s Manual K&F VIDAM
Page 4 of 4 Version 1.1 ©KLING & FREITAG GMBH
7.1.3 Setting up Dante latency with an additional hop 31
8 Initial Operation 32
9 Updates 34
9.1 Firmware Update 34
9.2 Dante Update 35
10 Care and Maintenance 36
11 Transportation and Storage 37
12 Disposal 37
12.1 Germany 37
12.2 EU, Norway, Iceland, and Liechtenstein 37
12.3 All Other Countries 37
13 EC Declaration of Conformity 38

© KLING & FREITAG GMBH Version 1.1 Page 5 of 40
User's Manual K&F VIDAM
1 Introduction
1.1 Icons Used
1.2 About this user's manual
EN | Translation of the original instructions
All KLING&FREITAG manuals are originally authored in German.
© KLING&FREITAG GmbH, all rights reserved.
All specifications regarding the features of the described products and applicable safety guide-
lines provided in this manual are based on information available at the time of publishing.
We assume no responsibility for technical specifications, dimensions, weights, and properties.
All information in this manual is subject to change without notice.
To ensure safe operation, all persons using the speaker system must have access to
these user's manual and all other relevant material during installation. Ohne dieses
gelesen, verstanden und griffbereit vor Ort zu haben, darf das Lautsprechersystem
weder aufgebaut noch eingesetzt werden.
KLING&FREITAG spare manuals are separately available for order or can be downloaded
from our website: www.kling-freitag.de
Contact Us: [e-mail]
KLING & FREITAG GMBH, Junkersstr. 14, D-30179 Hannover
Phone [phone], fax [phone] (other countries)
WARNUNG
This icon indicates a risk of injury or death. Not following these instructions may result in seri-
ous health problems including potentially fatal injuries.
VORSICHT
This icon indicates a possibly dangerous situation. Not following these instructions may cause
minor injuries or damage.
HINWEIS
This icon marks instructions for proper use of the described products. Not following these in-
structions may cause malfunctions or damage.
TIPP
This icon marks information provided for simplified use of the described products.

Page 6 of 40 Version 1.1 © KLING & FREITAG GMBH
User's Manual
VIDA M1.119.08.201908/19/20 19
K&F VIDAM
2 Product Description
2.1 Intended Use
Be sure to use the VIDAM speaker system for stationary indoors installations only. The system
is not designed for repeated assembly, reconfiguration, disassembly, or transport.
Any use not described in this User’s Guide is not an intended use.
2.2 Versions
VIDAM is available in four versions designed for different applications and transmission rang-
es.
WARNUNG
Risks imposed by falling or overturning parts
Be sure to install, suspend, fasten, and use Kling &<###Space: 1##>Freitag speakers only us-
ing the designated fixtures as specified in this document.
Never down-tilt speakers mechanically.
HINWEIS
Possible malfunctions
Never operate the speaker in an environment where the temperature exceeds 45 °C / 113 °F.
Never operate the speaker in places exceeding an altitude of 2,000 meters / 6,000 ft.
Make sure that the humidity is between 10% and 90%.
This product is not designed for use in corrosive environments.
Potential interference with household appliances
This device is not designed for home use.
VIDA M 110
•Asymmetrical design
•Transmission range: approx. 20
meters
•Height: 1.1 meters
VIDA M 110 S
•Symmetrical design
•Transmission range: approx. 25
meters
•Height: 1.1 meters
VIDA M 220
•Asymmetrical design
•Transmission range: approx. 30
meters
•Height: 2.2 meters
VIDA M 220 S
•Symmetrical design
•Transmission range: approx. 32
meters
•Height: 2.2 meters

© KLING & FREITAG GMBH Version 1.1 Page 7 of 40
User's Manual K&F VIDAM
2.3 System requirements
•Mounting hardware
•Computer running Windows 8, 8.1, or 10
•VIDAApp
The VIDAApp required for setting up the speaker system is freely available at the Win-
dows Store.
For this purpose, visit the Microsoft App Store and search for VIDA App.
For more information, refer to the VIDAApp User's Manual, which is available for down-
load at our website.
www.kling-freitag.de
•Audio source connected to Analog, AES 3, or Dante.
2.4 Items Included
2.4.1 Items Included VIDA M 110 / 110 S
•VIDA M 110 / 110 S speaker (1 piece)
•Counterbore caps (12 pieces)
•Sealing plate for the connector panel (1 piece)
•Countersunk screw M4x10 for fixing the sealing plate (7 pieces)
•3-pin power connector (1 piece)
•9-pin audio-in connector (1 piece)
•15-pin GPIO connector (1 piece)
•Cable tie (3 pieces)
•Loctite 2400 (5 ml)
•User’s manual (1 piece)
2.4.2 Items Included VIDA M 220 / 220 S
•Passive module for VIDA M 220 or VIDA M 220 S (1 piece)
•Active module for VIDA M 220 or VIDA M 220 S (1 piece)
•Mounting plate for fastening the modules (2 pieces)
•Countersunk screw M6x10 for fastening the modules (12 pieces)
•Counterbore caps (12 pieces)
•Sealing plate for the active-module connector panel (1 piece)
•Sealing plate for the passive-module connector panel (1 piece)
•Countersunk screw M4x10 for fastening the sealing plates (14 pieces)
•3-pin power connector (1 piece)
•9-pin audio-in connector (1 piece)
•15-pin GPIO connector (1 piece)
•Cable tie (3 pieces)
•Loctite 2400 (5 ml)
•User’s manual (1 piece)

Page 8 of 40 Version 1.1 © KLING & FREITAG GMBH
User's Manual
VIDA M1.119.08.201908/19/20 19
K&F VIDAM
2.5 Overview of VIDA M 110 / 110 S Parts
[A] Inlet for connecting mounting
hardware (also available at the
bottom)
[B] Bores for fastening mounting
hardware. Can be sealed using
the supplied caps when not in
use.
[C] Connector panel
[D] Sealing plate for connector panel
[E] Screws for fastening the sealing
plate:
7 x Countersunk screw M4x10,
hexagon socket wrench IS2,5 (7
pieces)

© KLING & FREITAG GMBH Version 1.1 Page 9 of 40
User's Manual K&F VIDAM
2.6 Overview of VIDA M 220 / 220 S Parts
[A] Passive module
[B] Inlet for connecting mounting
hardware (bottom inlet for con-
necting the active module)
[C] Bores for fastening mounting
hardware. Can be sealed using
the supplied caps when not in
use. Use the bores at the bottom
for connection with the active
module [H].
[D] Connector panel for fastening
the active module
[E] Sealing plate for the passive-
module connector panel
[F] Screws for fastening the sealing
plate:
7 x Countersunk screw M4x10,
hexagon socket wrench IH2.5
[G] Fastener for connecting the pas-
sive module to the active module
[H] Active module
[I] Cable with connectors and
grommets for connecting the
passive module. The VIDA M 220
has only one single cable!
[J] Inlet for connecting to the pas-
sive module (inlet at the bottom
is for fastening mounting hard-
ware)
[K] Bores for fastening the active
module [A]. The bores at the
bottom are for fastening mount-
ing hardware. Can be sealed us-
ing the supplied caps when not
in use.
[L] Connector panel
[M] Sealing plate for the active-mod-
ule connector panel
[N] Screws for fastening the sealing
plate:
7 x Countersunk screw M4x10,
hexagon socket wrench IH2.5

Page 10 of 40 Version 1.1 © KLING & FREITAG GMBH
User's Manual
VIDA M1.119.08.201908/19/20 19
K&F VIDAM
2.7 Front-panel indicator
Each VIDAM features an LED indicator located behind the front grille. You can turn the LED
on and off using the VIDAApp in order to identify a specific VIDAM speaker.
The indicator color shows the following statuses:
•Power-up (blue): The speaker is being powered up and will be ready for operation shortly.
•Beam error (red-lit): The speaker has been powered up successfully and is ready for oper-
ation; however, the sound-ray setup needs to be checked.
•Identification (green): The speaker is part of the selected speaker group.
•Error (flashing red and green): Configuration error. Perform a firmware update. See chap-
ter »Firmware Update«, page 34.

© KLING & FREITAG GMBH Version 1.1 Page 11 of 40
User's Manual K&F VIDAM
2.8 Accessories
VIDAM wall bracket
VIDAM flying frame
VIDAM adapter,
suitable for VIDA M 110 / 110 S

Page 12 of 40 Version 1.1 © KLING & FREITAG GMBH
User's Manual
VIDA M1.119.08.201908/19/20 19
K&F VIDAM
2.9 Dimensions
2.9.1 Dimensions VIDA M 110 / 110 S

© KLING & FREITAG GMBH Version 1.1 Page 13 of 40
User's Manual K&F VIDAM
2.9.2 Dimensions VIDA M 220 / 220 S

Page 14 of 40 Version 1.1 © KLING & FREITAG GMBH
User's Manual
VIDA M1.119.08.201908/19/20 19
K&F VIDAM
2.10 Technical Specifications
2.10.1 Technical Specifications VIDA M 110
Concept Active 2-way coaxial line array with electronic beam
steering
Input signal Each speaker is fed through a dedicated DSP/amp channel.
Frequency range @-10 dB 95 Hz – 22 kHz
Frequency range @±3 dB 125 Hz – 21 kHz
Horizontal coverage angle
(nominal) 90° nominal
Coverage angle vertical Continuously adjustable spread angle up to 90°.
±45° steering angle
Max. SPL 131 dB
Components 16 × 1” dome tweeters
8 × 4” bass/midrange drivers
Connectors
DANTE™ (primary/secondary)/remote (RJ45), AES67
compliant, AES/EBU input (9-pin Phoenix terminal block),
Analog input (9-pin Phoenix terminal block),
GPIO (15-pin Phoenix terminal block),
AUX OUT (9-pin Phoenix terminal block)
AUX OUT Controllable DSP output, e.g. for subwoofer expander,
+6 dBu nominal level
Analog input Fullscale at +18 dBu
Wide-range power supply 100 – 240 VAC, 50 / 60 Hz
Rated input power
a)
a) @ 1/8 full-scale
185 W
Maximum power
consumption 450 W
Enclosure
Aluminum extrusion profile, highly robust powder coating,
opaque steel grille with acoustic foam, hidden connector
panel
Dimensions (H x W x D) 1083 mm × 150 mm × 133 mm
Weight 16.5 kg
Colors
RAL 9005 (black), standard
RAL 9010 (white), standard
RAL spot color, on request

© KLING & FREITAG GMBH Version 1.1 Page 15 of 40
User's Manual K&F VIDAM
2.10.2 Technical Specifications VIDA M 110 S
Concept Active 2-way coaxial line array with electronic beam
steering
Input signal Each speaker is fed through a dedicated DSP/amp channel.
Frequency range @-10 dB 95 Hz – 22 kHz
Frequency range @±3 dB 125 Hz – 21 kHz
Horizontal coverage angle
(nominal) 90° nominal
Coverage angle vertical Continuously adjustable spread angle up to 90°.
±45° steering angle
Max. SPL 131 dB
Components 32 × 1” dome tweeters
8 × 4” bass/midrange drivers
Connectors
DANTE™ (primary/secondary)/remote (RJ45), AES67
compliant, AES/EBU input (9-pin Phoenix terminal block),
Analog input (9-pin Phoenix terminal block),
GPIO (15-pin Phoenix terminal block),
AUX OUT (9-pin Phoenix terminal block)
AUX OUT Controllable DSP output, e.g. for subwoofer expander,
+6 dBu nominal level
Analog input Fullscale at +18 dBu
Wide-range power supply 100 – 240 VAC, 50 / 60 Hz
Rated input power
a)
a) @ 1/8 full-scale
240 W
Maximum power
consumption 585 W
Enclosure
Aluminum extrusion profile, highly robust powder coating,
opaque steel grille with acoustic foam, hidden connector
panel
Dimensions (H x W x D) 1083 mm × 150 mm × 133 mm
Weight 17.4 kg
Colors
RAL 9005 (black), standard
RAL 9010 (white), standard
RAL spot color, on request

Page 16 of 40 Version 1.1 © KLING & FREITAG GMBH
User's Manual
VIDA M1.119.08.201908/19/20 19
K&F VIDAM
2.10.3 Technical Specifications VIDA M 220
Concept Active 2-way coaxial line array with electronic beam
steering
Input signal Each speaker is fed through a dedicated DSP/amp channel.
Frequency range @-10 dB 95 Hz – 22 kHz
Frequency range @±3 dB 125 Hz – 21 kHz
Horizontal coverage angle
(nominal) 90° nominal
Coverage angle vertical Continuously adjustable spread angle up to 90°.
±45° steering angle
Max. SPL 133 dB
Components 32 × 1” dome tweeters
16 × 4” bass/midrange drivers
Connectors
DANTE™ (primary/secondary)/remote (RJ45), AES67
compliant, AES/EBU input (9-pin Phoenix terminal block),
Analog input (9-pin Phoenix terminal block),
GPIO (15-pin Phoenix terminal block),
AUX OUT (9-pin Phoenix terminal block)
AUX OUT Controllable DSP output, e.g. for subwoofer expander,
+6 dBu nominal level
Analog input Fullscale at +18 dBu
Wide-range power supply 100 – 240 VAC, 50 / 60 Hz
Rated input power
a)
a) @ 1/8 full-scale
305 W
Maximum power
consumption 700 W
Enclosure
Aluminum extrusion profile, highly robust powder coating,
opaque steel grille with acoustic foam, hidden connector
panel
Dimensions (H x W x D) 2167.5 mm × 150 mm × 133 mm
Weight 31.6 kg
Colors
RAL 9005 (black), standard
RAL 9010 (white), standard
RAL spot color, on request

© KLING & FREITAG GMBH Version 1.1 Page 17 of 40
User's Manual K&F VIDAM
2.10.4 Technical Specifications VIDA M 220 S
Concept Active 2-way coaxial line array with electronic beam
steering
Input signal Each speaker is fed through a dedicated DSP/amp channel.
Frequency range @-10 dB 95 Hz – 22 kHz
Frequency range @±3 dB 125 Hz – 21 kHz
Horizontal coverage angle
(nominal) 90° nominal
Coverage angle vertical Continuously adjustable spread angle up to 90°.
±45° steering angle
Max. SPL 133 dB
Components 32 x 1“ dome tweeters
16 × 4” bass/midrange drivers
Connectors
DANTE™ (primary/secondary)/remote (RJ45), AES67
compliant, AES/EBU input (9-pin Phoenix terminal block),
Analog input (9-pin Phoenix terminal block),
GPIO (15-pin Phoenix terminal block),
AUX OUT (9-pin Phoenix terminal block)
AUX OUT Controllable DSP output, e.g. for subwoofer expander,
+6 dBu nominal level
Analog input Fullscale at +18 dBu
Wide-range power supply 100 – 240 VAC, 50 / 60 Hz
Rated input power
a)
a) @ 1/8 full-scale
305 W
Maximum power
consumption 700 W
Enclosure
Aluminum extrusion profile, highly robust powder coating,
opaque steel grille with acoustic foam, hidden connector
panel
Dimensions (H x W x D) 2167.5 mm × 150 mm × 133 mm
Weight 31.6 kg
Colors
RAL 9005 (black), standard
RAL 9010 (white), standard
RAL spot color, on request

Page 18 of 40 Version 1.1 © KLING & FREITAG GMBH
User's Manual
VIDA M1.119.08.201908/19/20 19
K&F VIDAM
2.11 Measuring Diagrams
Horizontal Directivity
Vertical Directivity
-180°
-150°
-120°
-90°
-60°
-30°
0°
30°
60°
90°
120°
150°
180°
Attenuation (dB)
3 - 6
6 - 9
9 - 12
12 - 15
15 - 18
> 18
< 3
125 250 500 1k 2k
Frequency [Hz]
4k 8k 16k
-180°
-150°
-120°
-90°
-60°
-30°
0°
30°
60°
90°
120°
150°
180°
Attenuation (dB)
3 - 6
6 - 9
9 - 12
12 - 15
15 - 18
> 18
< 3
125 250 500 1k 2k
Frequency [Hz]
4k 8k 16k

© KLING & FREITAG GMBH Version 1.1 Page 19 of 40
User's Manual K&F VIDAM
Vertical Directivity, optimised
Frequency response ‘on axis’
-180°
-150°
-120°
-90°
-60°
-30°
0°
30°
60°
90°
120°
150°
180
Attenuation (dB)
3 - 6
6 - 9
9 - 12
12 - 15
15 - 18
> 18
< 3
125 250 500 1k 2k
Frequency [Hz]
4k 8k 16k
20 100
-30
-20
-10
0
10
1k 10k 20k
SPL [dB]
Frequency Response

Page 20 of 40 Version 1.1 © KLING & FREITAG GMBH
User's Manual
VIDA M1.119.08.201908/19/20 19
K&F VIDAM
3GeneralSafetyInstructions
WARNUNG
Risk of electric shock
•The system must be connected to the mains by a qualified electrician only.
•Make sure that the power outlet has a ground connector and it is connected to the device
through the PE conductor of the power cord!
•Always route power cords so that they are protected from damage caused by stepping on
it, tensile stress, or getting caught.
•All equipment interconnected through signal cables must be connected to common
ground. Failing to do so may result in an electric shock or permanent damage to the con-
nected equipment.
Risk of electric shock and falling parts
•Never perform any maintenance work on the equipment other than what is described in
these user's manual.
•Repair work must be carried out by qualified service personnel authorized by
KLING&FREITAG.
Risks imposed by falling or overturning parts
•To be installed by qualified personnel only.
•Be sure to install, suspend, fasten, and use KLING&FREITAG speakers only using the des-
ignated mounting hardware as specified in this document.
•Observe the safety instructions in the User's Manuals to the respective mounting
hardware.
•Unless otherwise stated, use only KLING & FREITAG original parts for mounting the
speakers.
•Dieses Lautsprechersystem darf nicht mechanisch geneigt werden.
•Never try removing the individual modules of VIDA M 220 / 220 S speakers after these have
been joined, screwed, and glued together during initial installation.
Danger of fire
•The device does not include a master fuse. Be sure to protect the supply line appropriately
(230 V: 16 A fuse max.; 115 V: 20 A fuse max.)!
•Also make sure the supply line has an appropriately dimensioned cable cross-section.
VORSICHT
Risk due to high volumes
This equipment is capable of delivering sound pressure levels in excess of 90dB SPL, which
may cause permanent hearing damage. Keep your distance from operating speakers.
HINWEIS
Possible malfunctions
•RF interference at the power cord or line cables may result in unwanted noise.
