Bringing big movie and music sound to
smaller rooms, the Icon V Series VB-15
bookshelf speaker offers the same
advanced technology as the line’s
floorstanding models only it takes up less
space and has more placement options.
The VB-15 employs a 5.25"fiber-com-
posite woofer cone that is lightweight, yet
powerful. Not only does this reliable
low-frequency driver create improved
tonal balance and imaging, it also
generates amazing dynamics
and deep bass.
Even more remarkable is the VB-15’s
all-new, patent-pending Tractrix®Horn-
loaded tweeter with XT technology. This
exclusive design equalizes the speed of
sound waves from the horn and smoothes
the dispersion pattern.
In order to maintain an even transition
between drivers, the VB-15 employs a
high-definition, precision-voiced crossover
for tighter tolerance and higher
accuracy—in other words, a “front
and center” soundstage.
The VB-15’s compact and stylish black
cabinet with a furniture-grade wood
veneer top cap is internally braced for
tight, natural bass. The removable top
grille opens up the rich, high tones, while
the durable fixed grille at the bottom
protects the woofer from damage.
www.klipsch.com
1-800-KLIPSCH
All specifications are subject to change without notice. ©2008
Bookshelf Loudspeaker
• Patent-pending round XT Horn for improved directivity
• Aluminum dome tweeter for precise highs
• High-output woofer for amazing lows
• Magnetically shielded to avoid TV interference
• High-style, contemporary black cabinet ts any décor
• Fixed bottom grille protects woofer
• Easy to drive with typical A/V receiver
VB-15
frequency response 59Hz - 22kHz +/- 3dB
low frequency extension 52Hz
power handling 75 W continuous, 300 W peak
sensitivity 92.5dB
nominal impedance 8 ohms compatible
crossover frequency 2200Hz
drive components Shielded two way system utilizing one
5.25" fiber-composite lightweight
cone woofer and one 1" aluminum
dome tweeter mounted in a
4.5" square 90˚x90˚ XT
Tractrix®Horn
enclosure material MDF (medium density fiberboard)
enclosure type Bass reflex via rear flared port
height 13.75" (34.9 cm)
width 7" (17.8 cm)
depth 8.75" (22.2 cm)
weight 10.75 lbs (4.9 kg)
finishes Black vinyl with furniture-grade black
wood veneer top cap
SpecificationS
