Klipsch R-2800-C User manual

R-2800-C
The affordable Klipsch R-2800-C makes
discrete audio a convincing reality for almost
anyone. Upholding the same high-
performance standards as all Klipsch
products, this in-ceiling loudspeaker
employs an 8-inch gray polymer woofer
cone and a 1-inch soft/silk dome tweeter to
deliver superior and seamless sound.
Perfect for consumers who want high
fidelity with low visibility, this well thought
out speaker design is also one of the easiest
to install products on the market. By
incorporating a proprietary two-screw
mounting solution, all it takes is one trip up
the ladder to get this speaker rockin'.
Available in a white finish, this speaker can
be paired with one of Klipsch’s new
installation kits (sold separately). Each of
these revolutionary kit designs allow for
increased mounting flexibility and
incorporate a mud ring, wire tie and
universal metal mesh wing for multi-position
placement and a color-coded bracket for
easy speaker size identification.
8" Two-Way In-Ceiling Loudspeaker
SPECIFICATIONS
FREQUENCY RESPONSE 65Hz-20kHz ± 3dB
SENSITIVITY 93dB @ 1 watt/1 meter
NOMINAL IMPEDANCE 8 ohms
CROSSOVER FREQUENCY 2700Hz
POWER HANDLING 50 watts (200 watts peak)
ENCLOSURE MATERIA/TYPE ABS/ Infinite baffle, front flush with ceiling
DRIVE COMPONENTS Two-way system using one 1" (2.54cm)
silk dome tweeter and one 8" (20.3cm)
polymer woofer
WIRE GAUGE ACCOMMODATED 12
WEIGHT 7.9 lbs. (3.6 kg)
DIAMETER 1
1" (27.94cm)
MOUNTING DEPTH 4.5" (1
1.43cm)
CUTOUT DIMENSIONS 9.75" (24.77cm)
FINISH White
INSTALLATION KIT IK-800-C (sold separately)
■Good sensitivity and power handling, strong bass
■Weatherized components
■Rugged ABS frame
■Time saving two-screw mounting method
■Paintable to match ceiling
www.klipsch.com
1-800-KLIPSCH
All specifications are subject to change without notice. ©2004
