RSX-3
As one of the newest members of the
Reference Satellite family, the RSX-3 is the
smallest and most affordable monitor in the
line. This extremely compact loudspeaker
delivers the same dynamic sound experience
that has made its larger counterparts best-
sellers.
Available in a black or silver finish, the RSX-3
is a two-way magnetically shielded speaker
that employs a 3.5-inch aluminum woofer and
0.75-inch titanium-dome compression driver
coupled to an exclusive round MicroTractrix™
Horn for maximum clarity and efficiency. This
speaker also features high-quality network
components and premium internal wiring.
The woofer is a long-throw unit driven by a
powerful magnetic motor structure. The
Cerametallic™ cone is lightweight with
excellent rigidity, which dramatically reduces
any resonance. As a result, the RSX-3 is
capable of robust bass extending low enough
for comfortable operation with today’s built-
in A/V preamp/processor and receiver
crossovers.
The RSX-3 has an integrated pedestal stand
with a ball joint that allows it to be adjusted in
almost any direction by using the provided
allen wrench. Keyhole points are featured on
the underside of the stand base for no-hassle
wall mounting. The speaker grille magnetically
snaps into place over the front baffle, while
sturdy five-way binding posts ensure simple
connection to any type of cable.
The RSX-3 is sold in a single box that includes
four RSX-3s and one RCX-3. This speaker
will also be available in a complete home
theater package called the Cinema 6. This
package includes four RSX-3s, one RCX-3 and
a Reference Series RW-8 subwoofer.
3.5"Two-Way Satellite Loudspeaker
■High sensitivity
■MicroTractrix Horn tweeter for clean, detailed highs
■Ball-joint pedestal stand with keyholes allows easy placement
■Integrates well with all Klipsch powered subwoofers
■Magnetically shielded drivers to prevent video interference
SPECIFICATIONS
BANDWIDTH 116Hz-20kHz ± 3dB
SENSITIVITY 89dB @ 2.83 volts/1 meter
NOMINAL IMPEDANCE 8 ohms compatible
CROSSOVER FREQUENCY 2740Hz
POWER HANDLING 40 watts (160 watts peak)
ENCLOSURE TYPE Bass-reflex via rear-firing port
DRIVE COMPONENTS Two way system using one .75'' (1.8cm)
magnetically shielded, titanium dome
compression driver tweeter with an integral
round 90˚ MicroTractrix Horn and one 3.5''
(8.9cm) magnetically shielded, Cerametallic
cone woofer
WEIGHT 4.4 lbs. (2kg) including base
HEIGHT 8.75" (22.2cm) including base
WIDTH 4.8" (12.2cm)
DEPTH 6.7" (17cm)
FINISH Black or Silver
MOUNTING Base swivels 360˚ for on-wall mounting
via keyholes
www.klipsch.com
1-800-KLIPSCH
All specifications are subject to change without notice. ©2004
