klover ECOMPACT Series Quick start guide

ENGLISH
Pellet-burning
boiler ECOMPACT
150-190-250-290
INSTALLATION, USE, MAINTENANCE AND
HELPFUL TIPS
Main Revision 1.1
FPH_supplement: 001

DICHIARAZIONE DI
CONFORMITÀ
DECLARATION OF
CONFORMITY
Emesso da - Issued by
Indirizzo - Address
:
KLOVER s.r.l.
Via A. Volta, 8
37047 San Bonifacio (VR)
Tipo di apparecchio - Type of equipment
:
Heating boiler for solid fuel automatically stoked
Marchio commerciale -Trademark
:
KLOVER
Modello o tipo - Model or type
:
ECOMPACT 150
Uso - Use
:
Central heating in residential buildings
Costruttore - Manufacturer
:
KLOVER s.r.l.
L’oggetto della presente dichiarazione è conforme alle seguenti direttive UE:
The object of this declaration is comply with the following EU directives
2006/42/CE Direttiva macchine.
2006/42/CE Machinery Directive.
2014/35/UE del 26 Febbraio 2014 relativa l’armonizzazione delle legislazioni degli stati membri relative alla messa a disposizione sul mercato del
materiale elettrico destinato ad essere adoperato entro taluni limiti di tensione.
2014/35/UE 26 February 2014 on the harmonization of the laws of the Member States relating to the making available on the market of electrical
equipment designed for use within certain voltage limits.
2014/30/UE del 26 Febbraio 2014 relativa l’armonizzazione delle legislazioni degli stati membri relative alla compatibilità elettromagnetica.
2014/30/UE 26 February 2014 on the harmonization of the laws of the Member States relating to electromagnetic compatibility.
2011/65/UE del 21 Luglio 2016 relativa l’armonizzazione delle legislazioni degli stati membri relative alla restrizione all’uso di sostanze pericolose
nelle apparecchiature elettriche e elettroniche.
2016/65/UE 21 July 2016 on the harmonization of the laws of the Member States relating to the restriction in use of hazardous substances in
electrical and electronic equipment.
Riferimenti alle norme armonizzate:
References to the relevant harmonized standards:
EN 303-5
EN 55014-1 EN 55014-2
EN 61000-3-2 EN 61000-3-3
EN 62233
EN 60335-1
EN 60335-2-102
EN 50581
In qualità di costruttore e/o rappresentante autorizzato della società all’interno della CEE, si dichiara sotto la propria responsabilità che gli
apparecchi sono conformi alle esigenze essenziali previste dalle Direttive su menzionate.
As the manufacturer’s authorised representative within the EEC, we hereby declare under our sole responsibility that the equipment complies with
the provisions of the Directives stated above.
San Bonifacio (VR), 22/03/2018
Mario Muraro
Chairman of the Board

DICHIARAZIONE DI
CONFORMITÀ
DECLARATION OF
CONFORMITY
Emesso da - Issued by
Indirizzo - Address
:
KLOVER s.r.l.
Via A. Volta, 8
37047 San Bonifacio (VR)
Tipo di apparecchio - Type of equipment
:
Heating boiler for solid fuel automatically stoked
Marchio commerciale -Trademark
:
KLOVER
Modello o tipo - Model or type
:
ECOMPACT 190
Uso - Use
:
Central heating in residential buildings
Costruttore - Manufacturer
:
KLOVER s.r.l.
L’oggetto della presente dichiarazione è conforme alle seguenti direttive UE:
The object of this declaration is comply with the following EU directives
2006/42/CE Direttiva macchine.
2006/42/CE Machinery Directive.
2014/35/UE del 26 Febbraio 2014 relativa l’armonizzazione delle legislazioni degli stati membri relative alla messa a disposizione sul mercato del
materiale elettrico destinato ad essere adoperato entro taluni limiti di tensione.
2014/35/UE 26 February 2014 on the harmonization of the laws of the Member States relating to the making available on the market of electrical
equipment designed for use within certain voltage limits.
2014/30/UE del 26 Febbraio 2014 relativa l’armonizzazione delle legislazioni degli stati membri relative alla compatibilità elettromagnetica.
2014/30/UE 26 February 2014 on the harmonization of the laws of the Member States relating to electromagnetic compatibility.
2011/65/UE del 21 Luglio 2016 relativa l’armonizzazione delle legislazioni degli stati membri relative alla restrizione all’uso di sostanze pericolose
nelle apparecchiature elettriche e elettroniche.
2016/65/UE 21 July 2016 on the harmonization of the laws of the Member States relating to the restriction in use of hazardous substances in
electrical and electronic equipment.
Riferimenti alle norme armonizzate:
References to the relevant harmonized standards:
EN 303-5
EN 55014-1 EN 55014-2
EN 61000-3-2 EN 61000-3-3
EN 62233
EN 60335-1
EN 60335-2-102
EN 50581
In qualità di costruttore e/o rappresentante autorizzato della società all’interno della CEE, si dichiara sotto la propria responsabilità che gli
apparecchi sono conformi alle esigenze essenziali previste dalle Direttive su menzionate.
As the manufacturer’s authorised representative within the EEC, we hereby declare under our sole responsibility that the equipment complies with
the provisions of the Directives stated above.
San Bonifacio (VR), 22/03/2018
Mario Muraro
Chairman of the Board

DICHIARAZIONE DI
CONFORMITÀ
DECLARATION OF
CONFORMITY
Emesso da - Issued by
Indirizzo - Address
:
KLOVER s.r.l.
Via A. Volta, 8
37047 San Bonifacio (VR)
Tipo di apparecchio - Type of equipment
:
Heating boiler for solid fuel automatically stoked
Marchio commerciale -Trademark
:
KLOVER
Modello o tipo - Model or type
:
ECOMPACT 250
Uso - Use
:
Central heating in residential buildings
Costruttore - Manufacturer
:
KLOVER s.r.l.
L’oggetto della presente dichiarazione è conforme alle seguenti direttive UE:
The object of this declaration is comply with the following EU directives
2006/42/CE Direttiva macchine.
2006/42/CE Machinery Directive.
2014/35/UE del 26 Febbraio 2014 relativa l’armonizzazione delle legislazioni degli stati membri relative alla messa a disposizione sul mercato del
materiale elettrico destinato ad essere adoperato entro taluni limiti di tensione.
2014/35/UE 26 February 2014 on the harmonization of the laws of the Member States relating to the making available on the market of electrical
equipment designed for use within certain voltage limits.
2014/30/UE del 26 Febbraio 2014 relativa l’armonizzazione delle legislazioni degli stati membri relative alla compatibilità elettromagnetica.
2014/30/UE 26 February 2014 on the harmonization of the laws of the Member States relating to electromagnetic compatibility.
2011/65/UE del 21 Luglio 2016 relativa l’armonizzazione delle legislazioni degli stati membri relative alla restrizione all’uso di sostanze pericolose
nelle apparecchiature elettriche e elettroniche.
2016/65/UE 21 July 2016 on the harmonization of the laws of the Member States relating to the restriction in use of hazardous substances in
electrical and electronic equipment.
Riferimenti alle norme armonizzate:
References to the relevant harmonized standards:
EN 303-5
EN 55014-1 EN 55014-2
EN 61000-3-2 EN 61000-3-3
EN 62233
EN 60335-1
EN 60335-2-102
EN 50581
In qualità di costruttore e/o rappresentante autorizzato della società all’interno della CEE, si dichiara sotto la propria responsabilità che gli
apparecchi sono conformi alle esigenze essenziali previste dalle Direttive su menzionate.
As the manufacturer’s authorised representative within the EEC, we hereby declare under our sole responsibility that the equipment complies with
the provisions of the Directives stated above.
San Bonifacio (VR), 17/07/2017
Mario Muraro
Chairman of the Board

DICHIARAZIONE DI
CONFORMITÀ
DECLARATION OF
CONFORMITY
Emesso da - Issued by
Indirizzo - Address
:
KLOVER s.r.l.
Via A. Volta, 8
37047 San Bonifacio (VR)
Tipo di apparecchio - Type of equipment
:
Heating boiler for solid fuel automatically stoked
Marchio commerciale -Trademark
:
KLOVER
Modello o tipo - Model or type
:
ECOMPACT 290
Uso - Use
:
Central heating in residential buildings
Costruttore - Manufacturer
:
KLOVER s.r.l.
L’oggetto della presente dichiarazione è conforme alle seguenti direttive UE:
The object of this declaration is comply with the following EU directives
2006/42/CE Direttiva macchine.
2006/42/CE Machinery Directive.
2014/35/UE del 26 Febbraio 2014 relativa l’armonizzazione delle legislazioni degli stati membri relative alla messa a disposizione sul mercato del
materiale elettrico destinato ad essere adoperato entro taluni limiti di tensione.
2014/35/UE 26 February 2014 on the harmonization of the laws of the Member States relating to the making available on the market of electrical
equipment designed for use within certain voltage limits.
2014/30/UE del 26 Febbraio 2014 relativa l’armonizzazione delle legislazioni degli stati membri relative alla compatibilità elettromagnetica.
2014/30/UE 26 February 2014 on the harmonization of the laws of the Member States relating to electromagnetic compatibility.
2011/65/UE del 21 Luglio 2016 relativa l’armonizzazione delle legislazioni degli stati membri relative alla restrizione all’uso di sostanze pericolose
nelle apparecchiature elettriche e elettroniche.
2016/65/UE 21 July 2016 on the harmonization of the laws of the Member States relating to the restriction in use of hazardous substances in
electrical and electronic equipment.
Riferimenti alle norme armonizzate:
References to the relevant harmonized standards:
EN 303-5
EN 55014-1 EN 55014-2
EN 61000-3-2 EN 61000-3-3
EN 62233
EN 60335-1
EN 60335-2-102
EN 50581
In qualità di costruttore e/o rappresentante autorizzato della società all’interno della CEE, si dichiara sotto la propria responsabilità che gli
apparecchi sono conformi alle esigenze essenziali previste dalle Direttive su menzionate.
As the manufacturer’s authorised representative within the EEC, we hereby declare under our sole responsibility that the equipment complies with
the provisions of the Directives stated above.
San Bonifacio (VR), 17/07/2017
Mario Muraro
Chairman of the Board

1
CONTENTS
CONTENTS ........................................................................................................................................................................ 1
INTRODUCTION................................................................................................................................................................. 3
IMPORTANT SAFETY INSTRUCTIONS................................................................................................................................... 3
THE MACHINE AND THE PELLETS ................................................................................................................................. 4
COMPONENTS OF THE APPLIANCE ..................................................................................................................................... 4
OVERALL DIMENSIONS ECOMPACT 150 -190 ................................................................................................................. 6
OVERALL DIMENSIONS ECOMPACT 250 -290 ................................................................................................................. 7
CONNECTIONS DATA SHEET ECOMPACT 150 -190 ......................................................................................................... 8
CONNECTIONS DATA SHEET ECOMPACT 250 -290 ......................................................................................................... 9
TECHNICAL SPECIFICATIONS ECOMPACT 150 ............................................................................................................... 10
TECHNICAL SPECIFICATIONS ECOMPACT 190 ............................................................................................................... 11
TECHNICAL SPECIFICATIONS ECOMPACT 250 ............................................................................................................... 12
TECHNICAL SPECIFICATIONS ECOMPACT 290 ............................................................................................................... 13
AIRBORNE NOISE DATA ................................................................................................................................................... 14
PELLET PROPERTIES ...................................................................................................................................................... 14
REQUIREMENTS OF THE PLACE OF INSTALLATION................................................................................................. 15
POSITIONING.................................................................................................................................................................. 15
SPACES AROUND AND ABOVE THE APPLIANCE.................................................................................................................. 15
EXTERNAL AIR INTAKE .................................................................................................................................................... 16
THE FLUE AND CONNECTION TO THE SAME....................................................................................................................... 16
CHIMNEY ....................................................................................................................................................................... 18
ELECTRICAL CONNECTION .......................................................................................................................................... 19
CONTROL OF ANY COUPLED BOILER ................................................................................................................................ 19
CONTROL OF A POSSIBLE THREE-WAY MOTORIZED VALVE FOR DHW SYSTEM MANAGEMENT ............................................. 19
CONNECTION TO THE ROOM THERMOSTAT....................................................................................................................... 20
HYDRAULIC CONNECTION............................................................................................................................................ 20
THE DISPLAY .................................................................................................................................................................. 21
THE MENU ....................................................................................................................................................................... 23
INITIAL START-UP .......................................................................................................................................................... 26
SYSTEM CONFIGURATION ............................................................................................................................................... 26
FILLING THE SYSTEM FOR THE FIRST TIME........................................................................................................................ 28
PELLET LOADING AND CONNECTION TO THE MAINS POWER SUPPLY................................................................................... 29
IGNITION CYCLE.............................................................................................................................................................. 29
SWITCH-OFF CYCLE........................................................................................................................................................ 29
MODIFYING THE WORKING POWER .................................................................................................................................. 30
CHANGING THE WATER TEMPERATURE BOILER OR BUFFER............................................................................................... 30
PROBLEMS, ALARMS, USEFUL ADVICES ................................................................................................................... 31
USEFUL INFO….............................................................................................................................................................. 31
WHAT HAPPENS IF…...................................................................................................................................................... 31
ALARM SIGNALS ............................................................................................................................................................. 32
CLEANING AND MAINTENANCE ................................................................................................................................... 33
PRECAUTIONS BEFORE CLEANING ................................................................................................................................... 33
ROUTINE CLEANING........................................................................................................................................................ 33
NON-ROUTINE CLEANING ................................................................................................................................................ 35
CLEANING THE CERAMIC GLASS ...................................................................................................................................... 36
CLEANING THE FLUE....................................................................................................................................................... 37

2
PELLET-BURNING BOILER ECOMPACT 150-190-250-290
EN - Rev 1.1
MAINTENANCE ............................................................................................................................................................... 37
PCB PARAMETERS ........................................................................................................................................................ 38
PARAMETER TABLES ECOMPACT 150........................................................................................................................... 38
PARAMETER TABLES ECOMPACT 190........................................................................................................................... 40
PARAMETER TABLES ECOMPACT 250........................................................................................................................... 42
PARAMETER TABLES ECOMPACT 290........................................................................................................................... 44
WIRING DIAGRAM........................................................................................................................................................... 46
STANDARD WARRANTY CONDITIONS......................................................................................................................... 47
Dear client,
First of all we would like to thank you for choosing a “KLOVER” product and we hope you will be satisfied with this
product.
Read carefully the warranty certificate on the last page of this User guide.
We would like to thank you again for trusting KLOVER products, and we would also like inform you that these models
are the result of forty years of experience in the manufacture of solid fuel products using water as heat transfer fluid.
Every single detail of the product is manufactured by qualified staff, using the most advanced equipment.
The manual contains a detailed description of the appliance and its operation, instructions for proper installation, basic
maintenance and control points, which must be periodically performed; furthermore it contains practical advice which
helps to obtain maximum performance from the appliance with minimum fuel consumption.
Stay warm with KLOVER!
Copyright
All rights reserved. The reproduction of any part of this manual, in any form, without the explicit written permission of
KLOVER Srl. is forbidden. The content of this manual may be modified without notice. Although the documentation
contained in this manual has been carefully compiled and checked, KLOVER srl cannot be held liable for any damages
arising from the use of the same.
Copyright © 2018 KLOVER srl

3
PELLET-BURNING BOILER ECOMPACT 150-190-250-290
EN - Rev 1.1
INTRODUCTION
Important safety instructions
Please read these instructions before installing and using the product.
-The installation and initial start-up of the appliance must be performed by skilled personnel trained in the relevant
safety standards. They will be responsible for the definitive installation of the appliance and its proper operation.
KLOVER srl shall not be held liable if these precautions are not observed.
-During the installation and use of the appliance, all local regulations - including those referring to national and
European Standards - must be observed.
-Connect the flue gas outlet to a flue with the specifications described in the “Flue and its connection” section of this
User guide.
-The appliance is not suitable for installation on a shared flue system.
-If the flue should catch fire, use appropriate fire extinguishing equipment or call the fire brigade.
-Connect the product to an earthed power socket. Avoid using sockets controlled by switches or automatic timers.
-Do not use the power supply cable if damaged or worn.
-If a multiple socket is used, make sure that the total voltage of the connected devices does not exceed the rated
voltage for the socket. Also make sure that the total voltage of all the devices connected to the socket does not
exceed the maximum permitted level.
-The plug on the appliance’s power cable should be connected only once the assembly and installation of the
appliance is complete. It should remain accessible after installation if the appliance is not fitted with a suitable and
accessible two-pole switch.
-Do not use flammable substances to clean the appliance or its parts.
-Do not leave flammable containers and substances in the place where the appliance is installed.
-The appliance works exclusively with wood pellets and only with the hearth door shut.
-NEVER open the door of the appliance during normal operation.
-The use of poor quality pellets or any other material can damage the appliance operation, voiding the warranty and
exempting the manufacturer from all liability.
-Do not use the appliance as an incinerator or for any use other than that for which it was designed.
-Do not use fuels other than those recommended.
-Do not use liquid fuels.
-The appliance, and its outer surfaces in particular, become very hot to the touch during operation; handle with
caution in order to avoid burns.
-Keep fuel and flammable materials at a safe distance.
-Only use original spare parts recommended by the manufacturer.
-Do not make any unauthorised modifications to the appliance.
-Do not touch the hot components of the product (ceramic glass, flue pipe) during normal operation.
-Never touch the appliance if you are barefoot and/or if you have wet or damp parts of the body.
-Use the appropriate button to switch off the electrical panel. Do not disconnect the power supply cable while the
appliance is operating.
-During the ignition phase and normal operation of the appliance, maintain the necessary safety distance and do not
remain standing in front of it.
-Keep children away from the appliance when it is running since they could get burned by touching its hot
components.
-Do not leave the packaging elements within reach of children or unassisted disabled persons.
-Children and inexperienced people must not be allowed to use the appliance.
-The appliance may be used by children no younger than 8 years of age and people with reduced physical, sensory or
mental capabilities, or those without experience of the appliance, as long as they are supervised or have received
instructions on how to use the appliance safely and understand the hazards inherent to the appliance.
-Children should not play with the appliance.
-User maintenance and cleaning operations should not be carried out by unsupervised children.
-Do not use the appliance in ways other than those indicated in this user guide.
-The appliance is designed for indoor use only.
-The appliance is designed for heating water and should therefore be connected to a plumbing system (radiators,
under-floor heaters, etc.). This system should be suitably designed and sized to distribute the power generated by
the appliance.

4
PELLET-BURNING BOILER ECOMPACT 150-190-250-290
EN - Rev 1.1
-This user guide constitutes an integral part of the appliance. If the product is sold to another user, this manual must
be passed on to the new owner.
- The Klover ECOMPACT boilers are not suitable for use in UK smoke exempt areas.
KLOVER S.R.L. DECLINES ALL LIABILITY IN CASE OF ACCIDENTS DUE TO FAILURE TO COMPLY WITH THE
SPECIFICATIONS OF THIS MANUAL.
KLOVER S.R.L. DECLINES ALL LIABILITY DUE TO INCORRECT USE OF THE PRODUCT BY THE USER,
UNAUTHORISED MODIFICATION AND/OR REPAIRS, AND USE OF NON-ORIGINAL SPARE PARTS OR SPARE
PARTS NOT SPECIFICALLY DESIGNED FOR USE ON THIS PRODUCT MODEL.
KLOVER S.R.L. SHALL NOT BE HELD LIABLE FOR THE STOVE'S INSTALLATION. THE INSTALLER IS THE
SOLE PARTY RESPONSIBLE FOR THIS OPERATION AND IS ALSO ENTRUSTED WITH CHECKING THE FLUE,
EXTERNAL AIR VENT AND THE CORRECTNESS OF THE PROPOSED INSTALLATION SOLUTIONS. ALL THE
SAFETY REGULATIONS SET OUT IN THE SPECIFIC LAWS IN FORCE IN THE COUNTRY WHERE THE MACHINE
IS INSTALLED MUST BE OBSERVED.
NON-ROUTINE MAINTENANCE MUST ONLY BE PERFORMED BY AUTHORISED AND QUALIFIED STAFF.
To ensure the validity of the warranty, the user must comply with the instructions contained in this guide and, in
particular, must:
-Use the appliance within its operating limits;
-Regularly perform all maintenance activities;
-Authorise expert and competent people to use the appliance.
Failure to comply with the instructions contained in this guide shall automatically void the warranty.
THE MACHINE AND THE PELLETS
Components of the appliance
The table below shows the standard features of the appliance:
Expansion tank
10 l
Safety valve
2.5 bar
Pressure gauge
0 –4 bar
Automatic air vent valve
Yes
Heating system pump
Yes. Mod.25/70
Electrical setting for the connection of the domestic water flow switch
Yes
Electrical setting for boiler / buffer sensor
Yes
Electrical setting for the control of the optional automatic pellet loader
Yes
Remote control
Optional
The appliance is delivered with the following equipment:
-No. 1 - user, installation and maintenance guide;
-No. 1 - power supply cable;

5
PELLET-BURNING BOILER ECOMPACT 150-190-250-290
EN - Rev 1.1
Automatic air vent
valve
Main ON/OFF switch
Extractor flue gas pass
inspection
Safety thermostat
with manual reset
Pressure gauge
(indicates the
pressure of the
heating system)
High-efficiency
circulating pump for
heating system
Combustion chamber
door
Display
FRONT VIEW
LEFT FRONT TECHNICAL COMPARTMENT
Terminal for room
thermostat connection
Air intake pipe
Anti-interference filter
connection for power supply cable
with 2 built-in fuses (4A 250V).
Exapnsion vessel 10 lt with
pre-load 1 bar
Circulating pump speed
switch

6
PELLET-BURNING BOILER ECOMPACT 150-190-250-290
EN - Rev 1.1
Overall dimensions ECOMPACT 150 - 190

7
PELLET-BURNING BOILER ECOMPACT 150-190-250-290
EN - Rev 1.1
Overall dimensions ECOMPACT 250 - 290

8
PELLET-BURNING BOILER ECOMPACT 150-190-250-290
EN - Rev 1.1
Connections data sheet ECOMPACT 150 - 190
Description of connections
M= System Delivery
3/4" M
R= System Return
3/4" M
F= Domestic cold water inlet (on prepared models only)
1/2" M
C= Domestic hot water outlet (on prepared models only)
1/2" M
S= Upper or rear flue gas outlet
100 mm M
A = Rear or side fitting for connection of optional extraction pipe
40 mm
E = Electrical cable outlet
REAR VIEW

9
PELLET-BURNING BOILER ECOMPACT 150-190-250-290
EN - Rev 1.1
Connections data sheet ECOMPACT 250 - 290
Description of connections
M= System Delivery
3/4" M
R= System Return
3/4" M
F= Domestic cold water inlet (on prepared models only)
1/2" M
C= Domestic hot water outlet (on prepared models only)
1/2" M
S= Upper or rear flue gas outlet
100 mm M
A = Rear or side fitting for connection of optional extraction pipe
50 mm
E = Electrical cable outlet
REAR VIEW

10
PELLET-BURNING BOILER ECOMPACT 150-190-250-290
EN - Rev 1.1
Technical specifications ECOMPACT 150
Heat input (nominal setting)
kW (Kcal/h)
15.7 (13,500)
Heat input (reduced setting)
kW (Kcal/h)
4.5 (3,850)
Nominal thermal output
kW (Kcal/h)
14.6 (12,550)
Reduced thermal power
kW (Kcal/h)
4.2 (3,600)
Efficiency delivered to water at nominal thermal power
%
92.6
Efficiency delivered to water at reduced thermal power
%
93.3
CO at 10% oxygen at nominal thermal power
%
0.010
CO at 10% oxygen at reduced thermal power
%
0.033
Maximum power uptake
Watt
430*
Power uptake during operation at nominal thermal power
Watt
63
Power uptake during operation at reduced thermal power
Watt
35
Power uptake in stand-by
Watt
2
Nominal voltage
V
230
Nominal frequency
Hz
50
Expansion vessel litres/preloading bar
10 / 1
Maximum operating/recommended pressure
bar
2.5 / 1.5
Water side resistance at Δt= 20 K
mbar
135
Flue outlet diameter
mm
100
Air intake pipe diameter
mm
40
Minimum chimney draught at nominal thermal power
Pa
10.5
Minimum chimney draught at reduced power
Pa
6.7
Combustion gas mass at nominal thermal power
g/s
10.3
Combustion gas mass at reduced power
g/s
4.5
Pellet tank capacity
lt (kg)
92 (55)
Pellet tank filling opening dimensions
mm
330 x 260
Average exhaust flue gas temperature at nominal thermal power
°C
107.3
Average exhaust flue gas temperature at reduced power
°C
85.2
Boiler unit capacity
litres
42
Width
mm
1120
Height
mm
1150
Depth
mm
500
Minimum safety distance from flammable materials (side/rear)
mm
200 / 200
Weight
Kg
300
Boiler class as per EN303-5:2012
5
* Power consumption only during the ignition cycle.
The appliance's heat output may vary depending on the type of pellets used.

11
PELLET-BURNING BOILER ECOMPACT 150-190-250-290
EN - Rev 1.1
Technical specifications ECOMPACT 190
Heat input (nominal setting)
kW (Kcal/h)
19.7 (16,950)
Heat input (reduced setting)
kW (Kcal/h)
4.5 (3,850)
Nominal thermal output
kW (Kcal/h)
18.2 (15,650)
Reduced thermal power
kW (Kcal/h)
4.2 (3,600)
Efficiency delivered to water at nominal thermal power
%
92.3
Efficiency delivered to water at reduced thermal power
%
93.3
CO at 10% oxygen at nominal thermal power
%
0.010
CO at 10% oxygen at reduced thermal power
%
0.033
Maximum power uptake
Watt
430*
Power uptake during operation at nominal thermal power
Watt
63
Power uptake during operation at reduced thermal power
Watt
35
Power uptake in stand-by
Watt
2
Nominal voltage
V
230
Nominal frequency
Hz
50
Expansion vessel litres/preloading bar
10 / 1
Maximum operating/recommended pressure
bar
2.5 / 1.5
Water side resistance at Δt= 20 K
mbar
145
Flue outlet diameter
mm
100
Air intake pipe diameter
mm
40
Minimum chimney draught at nominal thermal power
Pa
10.0
Minimum chimney draught at reduced power
Pa
6.7
Combustion gas mass at nominal thermal power
g/s
12.3
Combustion gas mass at reduced power
g/s
4.5
Pellet tank capacity
lt (kg)
92 (55)
Pellet tank filling opening dimensions
mm
330 x 260
Average exhaust flue gas temperature at nominal thermal power
°C
114.0
Average exhaust flue gas temperature at reduced power
°C
85.2
Boiler unit capacity
litres
42
Width
mm
1120
Height
mm
1150
Depth
mm
500
Minimum safety distance from flammable materials (side/rear)
mm
200 / 200
Weight
Kg
300
Boiler class as per EN303-5:2012
5
* Power consumption only during the ignition cycle.
The appliance's heat output may vary depending on the type of pellets used.

12
PELLET-BURNING BOILER ECOMPACT 150-190-250-290
EN - Rev 1.1
Technical specifications ECOMPACT 250
Heat input (nominal setting)
kW (Kcal/h)
25.8 (22,100)
Heat input (reduced setting)
kW (Kcal/h)
7.5 (6,450)
Nominal thermal output
kW (Kcal/h)
23.3 (20,050)
Reduced thermal power
kW (Kcal/h)
6.5 (5,600)
Combustion efficiency at nominal thermal power
%
95.3
Efficiency delivered to water at nominal thermal power
%
90.3
Combustion efficiency at reduced thermal power
%
93.3
Efficiency delivered to water at reduced thermal power
%
87.9
CO at 10% oxygen at nominal thermal power
%
0.004
CO at 10% oxygen at reduced thermal power
%
0.022
Maximum power uptake
Watt
430*
Power uptake during operation at nominal thermal power
Watt
87
Power uptake during operation at reduced thermal power
Watt
54
Power uptake in stand-by
Watt
3.2
Nominal voltage
V
230
Nominal frequency
Hz
50
Expansion vessel litres/preloading bar
10 / 1
Maximum operating/recommended pressure
bar
2.5 / 1.5
Water side resistance at Δt= 20 K
mbar
184
Flue outlet diameter
mm
100
Air intake pipe diameter
mm
60
Minimum chimney draught at nominal thermal power
Pa
12.6
Minimum chimney draught at reduced power
Pa
10.6
Combustion gas mass at nominal thermal power
g/s
12.7
Combustion gas mass at reduced power
g/s
6.0
Pellet tank capacity
lt (kg)
120 (75)
Pellet tank filling opening dimensions
mm
400 x 290
Average exhaust flue gas temperature at nominal thermal power
°C
95.7
Average exhaust flue gas temperature at reduced power
°C
65.4
Boiler unit capacity
litres
52
Width
mm
1180
Height
mm
1220
Depth
mm
570
Minimum safety distance from flammable materials (side/rear)
mm
200 / 200
Weight
Kg
380
Boiler class as per EN303-5:2012
5
*Power consumption only during the ignition cycle.
The appliance's heat output may vary depending on the type of pellets used.

13
PELLET-BURNING BOILER ECOMPACT 150-190-250-290
EN - Rev 1.1
Technical specifications ECOMPACT 290
Heat input (nominal setting)
kW (Kcal/h)
29.7 (25,550)
Heat input (reduced setting)
kW (Kcal/h)
7.3 (6,300)
Nominal thermal output
kW (Kcal/h)
26.8 (23,050)
Reduced thermal power
kW (Kcal/h)
6.6 (5,700)
Combustion efficiency at nominal thermal power
%
95.1
Efficiency delivered to water at nominal thermal power
%
90.1
Combustion efficiency at reduced thermal power
%
94.3
Efficiency delivered to water at reduced thermal power
%
89.7
CO at 10% oxygen at nominal thermal power
%
0.002
CO at 10% oxygen at reduced thermal power
%
0.028
Maximum power uptake
Watt
430*
Power uptake during operation at nominal thermal power
Watt
87
Power uptake during operation at reduced thermal power
Watt
54
Power uptake in stand-by
Watt
3.2
Nominal voltage
V
230
Nominal frequency
Hz
50
Expansion vessel litres/preloading bar
10 / 1
Maximum operating/recommended pressure
bar
2.5 / 1.5
Water side resistance at Δt= 20 K
mbar
211
Flue outlet diameter
mm
100
Air intake pipe diameter
mm
60
Minimum chimney draught at nominal thermal power
Pa
11.7
Minimum chimney draught at reduced power
Pa
9.8
Combustion gas mass at nominal thermal power
g/s
15.8
Combustion gas mass at reduced power
g/s
5.5
Pellet tank capacity
lt (kg)
120 (75)
Pellet tank filling opening dimensions
mm
400 x 290
Average exhaust flue gas temperature at nominal thermal power
°C
112.3
Average exhaust flue gas temperature at reduced power
°C
65.3
Boiler unit capacity
litres
52
Width
mm
1180
Height
mm
1220
Depth
mm
570
Minimum safety distance from flammable materials (side/rear)
mm
200 / 200
Weight
Kg
380
Boiler class as per EN303-5:2012
5
* Power consumption only during the ignition cycle.
The appliance's heat output may vary depending on the type of pellets used.

14
PELLET-BURNING BOILER ECOMPACT 150-190-250-290
EN - Rev 1.1
Airborne noise data
The sound levels in the following table are basaed on the sound measurement of an Ecompact 250.
The sound level of the individual units was pltted at the distance of 1m from the sound source.
Ambient level measurement: 33 dB.
UNIT
MEASUREMENT
UNIT IN CONTINUOUS OPERATION
Extract fan (Power level 1)
35
Extract fan (Power level 5)
43
Extract fan (Cleaning cycle)
49
UNITS IN NON-CONTINUOUS OPERATION
Auger screw motor
42
Turbulator cleaning motor
43
Circulating pump
38
Please note that all of the measurements were taken in-house and do not come from a certified test centre.
This data should therefore be viewed as guidance only.
Pellet properties
The appliance has been tested with all types of pellets available on the market. The pellets must have the following
properties:
-Diameter 6 mm.
-Maximum length 35 mm.
-Maximum humidity content 8 –9 %.
-100% wood. Totally additive-free.
-Maximum ash residue 1.1 %.
To obtain good performance from the appliance, we recommend using good quality pellets. Pellets should be poured
into the tank using a shovel, and not directly from the bag.
Good quality pellets should have the following properties:
-Constant diameter cylinders with a smooth, shiny surface;
-There should not be a lot of sawdust inside the packaging;
-After grabbing a bunch of pellets and placing them into a container filled with water, good-quality pellets will sink and
poor-quality ones will tend to float;
-The quality certification data, in particular conformity to international standards such as EN14961-2, DIN 51731 and
O-NORM M7135, should be indicated on the packaging;
-The packages should be intact since pellets tend to absorb humidity. Humidity not only reduces the calorific value
and increases the amount of flue gases expelled, but also causes swelling of the product which may create problems
with the appliance.
The production of pellets must be compliant with some international standards (such as EN14961-2, DIN 51731 and O-
NORM M7135) which establish minimum values for quality checks on pellets. To facilitate the right choice of the
combustible material you can find below one of the most common certification marks identifying the quality of the pellets:
