KMART 42956945 User manual

Cardio Spin Bike
Key Code：42956945
WARNING! READ ALL INSTRUCTIONS CAREFULLY BEFORE USING
THIS PRODUCT. FAILURE OF INCORRECT OR EXCESSIVE TRAINING
MAY CAUSE INJURIES TO HEALTH.

Safety Instruction and Precaution
Please read this manual carefully before using this spin bike and make sure that you read the
information supplied before commencing any exercise with this product.
1. Please consult a doctor before commencing any exercise with this equipment and if you
develop any uncommon symptoms during use you should seek further medical advice.
2. The spin bike must be placed on a hard, flat surface, cover the floor with carpet to prevent
damage to the ground. For safety, please keep distance between spin bike and other
obstacles not less than 0.6 meters.
3. Please be sure that you operate spin bike according to the instruction manual, periodically
checking all the parts for signs of wear or damage. If you find defective parts or there is
noise whilst assembling the bike or during use, stop operating and make sure all operating
parts are fixed prior to continued use.
4. Please check the equipment carefully before use, and check bike strictly according to
installation principle every 1-2 month after use to keep the equipment running normally.
5. While using, please wear suitable clothes and shoes for training to avoid anything getting
caught in the bike.
6. Make sure the sensor is fixed on the bracket nearby the flywheel before exercise.
7. Check all parts first before doing exercises. Tighten all the bolts and nuts on a regular basis
and never operate the spin bike if it is not functioning properly.
8. Always climb on the spin bike from the lowest position of the foot pedal and the flywheel
is not in motion.
9. Keep children away from the equipment unless they are supervised by an adult.
10. Create a realistic training plan before use, and use this product according to the
instructions of use in this instruction manual.
11. The resistance of the product can be adjusted, please select the appropriate resistance.
12. Don’t touch the flywheel during use to avoid any injury.
13. Attempt to use the two wheels which are located on the front base to move spin bike
around if necessary.
14. Product is in compliance with EN 20957-1 & 10 CLASS HC as well as AS 4092. Suitable for
domestic home use only.

Product Diagram
Parts List
No.
Description
QTY
No.
Description
QTY
1
Main Frame
1
10
Ball pin
2
2
Rear Stabilizer
1
11
Screw knob
2
3
Front Stabilizer
1
12
Inner hex spanner
1
4
Bottle
1
13
Open spanner
1
5
Seat adjustable post
1
14
Wrench（in spare）
1
6
Saddle
1
15
Screw/Spacer/Cap nut(M8x35mm)
4
7
Seat post
1
16
Pedal(L/R)
1
8
Front adjustable post
1
17
Handlebar
1
9
Monitor
1
Technical Parameters
Overall size
122x51x105cm
Product total surface area
0.54m2
Maximum user weight
100kg
Product total weight
27.9kg

Assembly Instruction
1. Put M8x35mm bolt (Part 15) on front stabilizer（Part 3）, fingers hold the bolt bottom, put the front
stabilizer in the front hole at the base of main frame (Part 1), add spacer and M8 cap nut (Part 15) in bolt,
then tighten it with open spanner(Part 13). Use the same way to install the rear stabilizer(Part 2)on main
frame.
2. Take out the pedal (Part 16), there is superscript “L”&“R” on the pedal, take out “R” pedal and screw out
the nut from the bolt, then screw the bolt into the nut of“R” crank on main frame. After tighten it in
clockwise with open spanner, screw the nut into the bolt again to ensure the pedal assembled in the “R”
crank firmly. Take out pedal belt, buckle it up on pedal as picture shows. Take out “L” pedal, use the
same way to assemble it into “L” crank, the bolt of “L” pedal is screwed into the nut of “L” crank should
be in counter clockwise direction.
Note:“L”&“R”are marked on crank as well. Please install pedal accordingly, otherwise it will damage
the product. And please fasten the feet strap, or it will fall down after long usage.
3. Take out the saddle (Part 6), connect seat post (Part 7) and seat adjustable post (Part 5) together by the
plum-head bolt which screwed on seat post, then adjust the angle of saddle and assemble it into seat
post (Part 7) by tightening the nut on the saddle with open spanner. Insert the post to the back tube of
main frame, and adjust the saddle to appropriate height, then fix the post to the tube of main frame with
ball pin (Part 10) and fasten it with screw knob (Part 11).
Note: Saddle can also be adjusted back and forward by the plum-head bolt.
Note: the foot pad on front and rear
stabilizer can be adjusted to keep the
product stable on the floor after fully
assembled.

4. Take out handlebar (Part 17), connect handle bar with front adjustable post together (Part 8) with
hardware M8x12mm (Assembled in the hole) and fasten by inner hex spanner (part 13). Insert the post to
the front tube of main frame, and adjust the handlebar to appropriate height, then fix the post to the
tube of main frame with ball pin (Part 10) and fasten it with screw knob (Part 11).
5. Take out the monitor, and slide it to the buckle on the handlebar, then connect the two cable together.
Note: the cable from the handlebar should be connected to the one with PULSE of the monitor, and
the cable from the flywheel should be connected with the one from SENSOR of the monitor which is
in same color marked on cables.
6. The control knob and protective cover are pre-assembled in the equipment. Press the control knob can
stop the flywheel quickly when in emergency, please make sure they are fitted correctly (see below
image).
Exercise Instruction
A successful exercise program consists of a warm-up, aerobic exercise and a cool-down. Do the entire
program at least two and preferably three times a week, resting for a day between workouts. After several
months, you can increase your workout to four or five times per week. Warming up is an important part of
your workout and should begin every session. It prepares your body for more strenuous exercise by heating
up and stretching out your muscles, increasing your circulation and pulse rate, and delivering more oxygen
to your muscles. At the end of your workout, repeat these exercises to reduce muscle soreness.
Monitor Instruction
1) Product specification
TIME……00:00--99:59 Minute: Second
SPD……0.0--99.9KM/H
DST……0.00--99.99KM
CAL……0.0--999.9KCAL
ODO……0.0--999.9KM
PULSE……40--240BPM
Warning! Keep away from young
children. Injuries may occur if the
Spin Bike is operated in their vicinity
without properly fitted guards.

2) Key Functions for MODE/RESET
MODE: Press the red button to select SCAN or lock onto a particular function.
RESET: Press the red button for 3 seconds to remove all the records except ODO.
3) Function Instruction
SCAN: Automatic display the following functions in order, TIME-SPD-DST-CAL-ODO-PULSE.
TIME: Press MODE key until the pointer advances to TIME. The monitor will display the total working
time from starting exercise.
SPEED: Press MODE key until the pointer advances to SPD. The monitor will display the current speed.
DISTANCE: Press Mode key until the pointer advances to DST. The monitor will display the total trip
distance from starting exercise.
CALORIES: Press Mode key until the pointer advances to CAL. The monitor will display total
consumption calories from starting exercise.
ODOMETER: Press the Mode key until the pointer advances to ODO. The monitor will display the total
accumulated distance.
PULSES: Press the Mode key until the pointer advances to PULSES. The monitor will display the current
heart rate in beats per minute.
AUTO ON/OFF: The system turns on when any key is pressed or when it receives any signal input from
the speed sensor. The system turns off automatically when the sensor has no signal input or no any
key is pressed for approximately 4 minutes.
4) Battery
This monitor uses 2pcs AAA batteries (not included).
If the display monitor shows improper data on the screen its advised to reinstall the batteries to
have a better result.
All data will be removed when batteries are changed.
Use Instruction
The spin bike is easy to operate. The steps outlined will enable the user to work the bike properly.
Stand next to your bike seat and analyze its height. The top of the seat should be right at your hip bone.
Unscrew the screw knob (Part 11) and ball pin (Part 10) below the seat and slide the seat up or down to
adjust it to your hip height. Insert and screw the ball pin to fix the height, then tighten the knob again to
secure it.
Adjust the distance between the seat and the handlebars to match the length of your forearm. Place at
the very front of the seat. Your finger tips should barely touch the front of the bike. Unscrew the knob at the
back of the seat to slide it forward or back and tighten to secure it.
Climb onto the seat of the bike and place your feet on the pedals in the stirrups. Reach down and pull the
thin belt to tighten the stirrup around each foot.
Set the handlebars at a height that is comfortable for you. You should reach forward, bending at the lower
back and hips to reach them, but they should not be so far away that you are straining or feel tension in
your lower back. Unscrew the screw knob (Part 11) and ball pin (Part 10) on the tube of main frame, adjust
up or down to a suitable height. Insert and screw the ball pin to fix the height, then tighten the knob again
to secure it.
WARNING! The handlebar and seat adjustment shall not exceed the mark indicating the minimum
insertion depth on the post. Failure to follow the instruction may cause damage to the spin bike or
lead to a personal injury. If any of the adjustment devices are left projecting, they could interfere
with your movement.

The control knob is in front of you. Rotating the knob in a clockwise direction will increase the resistance
of spin bike, rotating the knob in anticlockwise direction will decrease the resistance of spin bike. Press
down the knob when it in emergency, the spin bike will stop quickly.
Keep your feet flat as you pedal. Keep your back flat and not hunched as you reach forward to the handle
bars. Rotate the control knob to the right to increase resistance.
When doing standing flats or climbs resist the urge to support all of your weight with the handlebars. Use
them for balance and stability only.
Put a bottle of water on the bracket, the cycling can be an intense class and you will not hop off your bike
for water.
To show the pulse on the monitor, you should touch your both palms on the handrail sensor of the
handlebars.
WARNING! Please keep a safety distance of 0.6m around the equipment during exercising.
WARNING! Heart rate monitoring systems may be inaccurate. Over exercising may result in serious
injury or death. If you feel faint stop exercising immediately.
Care and maintenance
1. Proper use of the equipment will increase the life span of the bike.
2. Screws will get loose after exercise please check and tighten the screws properly every week so as to
avoid any possible damage to the equipment or personal injury.
3. Regularly check the safety device of brake ball and the guard of protective cover every week and
make sure the functions are kept in good integrity.
4. Special pay attention to the belt which is the most susceptible to wear.
5. Wipe clean with damp cloth. Do not use abrasive material or solvents.
6. Failure to perform routine maintenance could result in personal injury and/or equipment damage.
7. Keep far away from children when not in use.
8. Always store in a dry and ventilated area.
©KMART AUSTRALIA LIMITED
KMART AUSTRALIA – 690 SPRINGVALE ROAD, MULGRAVE, VIC 3170 AUSTRALIA.
KAMRT NEW ZEALAND – REGIONAL OFFICE C/O KMART PAPATOETOE STORE.
HUNTERS PLAZA, GREAT SOUTH ROAD, PAPATOETOE, AUCKLAND, NEW ZEALAND.
Made in China
