Knightsbridge JB002 Instruction Manual

INSTALLATION & MAINTENANCE MANUAL
JB002 JB003 & JB004
88
IP
68
1

2
These instructions should be read carefully and retained after installation for further reference and
maintenance.
GENERAL INSTRUCTIONS:
• Before installation/maintenance ensure that the supply to the cable to be joined is switched off and
the circuit fuses are removed or switched off
• Installation of these products must be carried out by a competent person or by a qualified electrician
to the current IEE Wiring and Building Regulations
• Please recycle this unit
• 230V 50Hz
• JB002 and JB003 - IP68 (5mtrs max) JB004 – IP68
• 3 - Pole screw-fix terminals
• H07RN-F cable – min 0.75mm 3 core – max 4.00mm 3 core
• EN50262
SAFETY
INSTALLATION
JB002
LOCKING
NUT
SEALS
GLANDS
GASKET
CONNECTOR
SHELL
12 3
4 5 6

3
JB003
1
3
657
5
6
6
4
2
SHELL
GLANDS
GASKET
CONNECTOR
LOCKING NUT
SEALS

4
ML Accessories Limited
LU5 5TA
www.mlaccessories.co.uk 10-14-PSV2SC88
