KNX Module IC-IP-S.1.0 User manual

module-electronic.ru
KNX IP INTERFACE
IC-IP-S.1.0
Application Program: ver. 1.0
User Manual: ver. 1.0
User Manual

CONTENT
Content . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1 Basic information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.1 Specification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.2 Appearance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.3 Installation and connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2 KNXnet/IP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.1 IP tunneling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.2 IP routing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.3 IP bootloader / boot mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3 Operational description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.1 IP interface application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.2 IP network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.3 Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.3.1 Programming button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.3.2 Individual address assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.4 Function button. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.4.1 Factory reset. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.4.2 Boot mode activation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.4.3 LED status display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4 ETS database parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.2 IP configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
5 Web front-end . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
5.1 Accessing the IC-IP-S.1.0 web front-end . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
5.1.1 Via windows network UPnP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
5.1.2 Via IP address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
5.1.3 Via MAC address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5.2 Device info . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5.3 KNX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5.4 Firmware update / boot mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
5.5 IP tunneling address assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
6 State of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
6.1 Default factory setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
7 Legal Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
page 2
module-electronic.ru

1 BASIC INFORMATION
The KNX IP interface provides access to the KNX bus from the Ethernet network using the KNXnet/IP
protocol. Using to configure, monitor, visualize and manage devices on the KNX network.
• Protocol KNXnet/IP
• Up to 4 connections simultaneously
• Ethernet 10/100 BaseT IP
• LED status indication
• Long telegrams with up to 240 bytes APDU length are supported
• WEB interface for monitoring status and device settings
• Remote firmware update
• Power supply via KNX bus
• DIN rail 35mm mounting
IC-IP-S.1.0
page 3
module-electronic.ru

1.1 SPECIFICATION
Device model
IC-IP-S.1.0
Inputs
Ethernet connector
RJ45, female
KNX interface
Specification
TP-256
Available application soware
ETS 4 and later
KNX connector
4-wire EIB connector (PUSH WIRE spring clips) for standard cable TP1 0,8мм Ø
Supported protocols
KNXnet/IP, ARP, ICMP, IGMP, HTTP, UPnP discovery, UDP/IP, TCP/IP, DHCP и AutoIP
KNX physical address by default
15.15.0
Power supply
via KNX bus: 21...30В DC
Consumption on the KNX bus (29V DC)
< 20mA
< 600mW
Operation temperature
-5°C ... + 45°C
Operation humidity
5 ... 95% (no condensation)
Degree of protection
IP 20, clean environment
Mounting type
DIN rail 35mm
Dimensions
36 х 90 х 71mm (2TE)
Weight
68 g
page 4
module-electronic.ru

1.2 APPEARANCE
90mm
36mm 71mm
C
5
D
B
4
2
1
3
A
A. Ethernet connector B. Function button C. Programming button D. KNX TP connector
1. LED IP state 2. LED bus state KNX TP 3. LED telegram traffic IP
4. LED telegram traffic KNX TP 5. Programming LED
1. IP state
Green: IP line OK
OFF: No IP connection
2. Bus state KNX TP
Green: KNX TP line OK
OFF: KNX TP line not connection
3. Telegram traffic IP
Green (blinking): Telegram traffic
Red (blinking): Transmission error
OFF: No telegram traffic
4. Telegram traffic KNX TP
Green (blinking): Telegram traffic
Red (blinking): Transmission error
OFF: No telegram traffic
5. Programming
Red: Programming Mode / Boot Mode active
Red (blinking): No IP connection
OFF: Programming Mode / Boot Mode not active
page 5
module-electronic.ru

+
-
KNX bus
Ethernet
ATTENTION! Installation and connection of the device to the mains must only be carried
out by qualified personnel! Be sure to turn off the power before installing or removing the
device! Even when the device is turned off, the output terminals can be live! Do not
connect to the outputs a load that exceeds the recommended values! The design of the
device meets the requirements of electrical safety according to GOST 12.2.007.0-75.
1.3 INSTALLATION AND CONNECTION
INSTALLATION
WIRING DIAGRAMS
Attaching to DIN rail
Removing from DIN rail
page 6
module-electronic.ru

2 KNXnet/IP
IC-IP-S.1.0 is a KNX IP interface. KNX IP interfaces are highly similar to USB interfaces. The only difference
is that they use the IP communication medium and the KNXnet/IP communication protocol. However,
KNX end devices can be integrated directly via IP. This makes the Ethernet a real KNX medium.
As documented in the KNXnet/IP protocol specifications, KNX telegrams can be transmitted encapsulated
in IP packets. Ethernet networks as well as Internet can be used to route or tunnel KNX telegrams. In this
way, IP interfaces and IP routers are an alternative to USB data interfaces and TP line/area/backbone
couplers, respectively. In the latter case, a TP backbone can be completely replaced by a fast Ethernet
based line then called IP backbone.
The presence of the Internet Protocol (IP) has led to the definition of the KNXnet/IP protocol. KNXnet/IP
offers the possibility for point-to-point connections for the ETS (KNXnet/IP Tunneling) and/or between
supervisory system and KNX installation. The KNXnet/IP device management enables KNXnet/IP device
configuring via the KNX network in order to reduce the time required for complete network configuration.
2.1 IP TUNNELING
2.2 IP ROUTING
IP Routing is the way of interconnecting KNX lines and areas by IP network(s) via KNXnet/IP. In IP
networks, the KNXnet/IP Routing defines the way of KNXnet/IP router communication.
2.3 IP BOOTLOADER / BOOT MODE
The IP bootloader function is used to update the firmware and completely rewrite the flash memory
content. This is not just a simple application download. Both communication stack and application
soware are downloaded.
The firmware update procedure via IP is executed by a web front-end, which is independent from ETS,
and makes use of special messages to speed up the process. To be protected, their contents are
encrypted.
Entering Boot Mode is equivalent to activating the IP bootloader function.
page 7
module-electronic.ru

3 OPERATIONAL DESCRIPTION
In network installations IC-IP-S.1.0 is used as KNX IP interface. Aer connecting to KNX TP, IC-IP-S.1.0
operates with its default settings. Setting the correct Individual Address is necessary to include IC-IP-S.1.0
in the present KNX bus system.
3.2 IP NETWORK
IC-IP-S.1.0 sends telegrams from/to the TP network to/from the IP network in accordance with the
KNXnet/IP protocol specification. Important notes:
џAll KNX IP devices that are intended to communicate with each other via IP must have the same IP
multicast address.
џIf the IP address is changed from the IP side it may happen that ETS does no longer recognize the
device and connection cannot be maintained (tunneling uses IP addresses). So, it is recommended
to change IP addresses and restart only from TP side.
џIf problems occur for IP address assignment please ask your network administrator.
џAccording to the topology, the Tunneling addresses always have to be assigned in the range of
subline addresses. For more information about additional Individual Addresses for tunneling
please refer to IP Tunneling Address Assignment.
џTo program devices of a line different to which the device used for (re)programming is connected,
the use of a correct topology is mandatory!
3.1 IP INTERFACE APPLICATION
IP Interface is designed for use in 10/100 BaseT networks compliant to IEEE802.3. The AutoSensing
function sets the baud rate (10 Mbit or 100 Mbit) automatically. IP address can be received from a DHCP
server. For this, the automatic assignment setting of the IP address can be set by ETS (use DHCP). If set so
and no DHCP server is found, IC-IP-S.1.0 starts an AutoIP procedure and autonomously assigns the IP
address. The IP address that IC-IP-S.1.0 receives during its start-up (via DHCP or AutoIP) is retained until
next start-up (e.g. due to power off or reprogramming). If IC-IP-S.1.0 is supposed to have a fixed IP address
(as well as subnet mask and standard gateway) it can be set by ETS.
ETS does not provide an unload procedure for applications.
page 8
module-electronic.ru

3.3.2 INDIVIDUAL ADDRESS ASSIGNMENT
To download the desired Individual Address or an ETS setting the Programming Mode must be activated.
Successive pressing the Programming Button will turn on and off the Programming Mode. LED 7 lighting
in red colour indicates Programming Mode is active. When Programming Mode is activated, the ETS is
able to download the Individual Address.
A blinking red Programming LED indicates the Ethernet cable is not properly connected or no IP
network connection is available.
Also when Boot Mode is active, successive pressing the Programming Button will turn on and off
Programming Mode and Programming LED.
To configure the device an interface connection (IP, USB) to the KNX bus system is required. The device is
supplied with the Individual Address 15.15.0. The KNX product database entry (available for ETS4 and
higher) can be downloaded from the website and from the KNX Online Catalog.
The Individual Address can be assigned to the device by setting the desired address in the properties
window of the ETS. Aer starting the ETS download and then pressing the Programming Button the
device restarts itself.
3.3 PROGRAMMING
3.3.1 PROGRAMMING BUTTON
Figure 1. ETS properties window
page 9
module-electronic.ru

3.4 FUNCTION BUTTON
The Function Button activates IC-IP-S.1.0´s special function. Factory Reset can be activated. Device
settings of IC-IP-S.1.0 can be reset to manufacturer default values with the Factory Reset function. During
the firmware update procedure the Function Button has to be pressed for Boot Mode activation.
3.4.1 FACTORY RESET
A long press (≈ 15 sec) of the Function Button soon followed by a short press (≈ 3 sec) executes the Factory
Reset. Aer the first press, the LED display lights like described in Table 1. Aer the second press, all
parameters will be set to factory default (incl. Individual Address). Subsequently, LEDs indicate normal
operation again.
3.4.2 BOOT MODE ACTIVATION
For Boot Mode activation the firmware update process must be executed. During the process, the
Function Button must be pressed to enter Boot Mode (see chapter 5.4).
Figure 2. Boot Mode is active
page 10
module-electronic.ru

3.4.3 LED STATUS DISPLAY
Number
LED
Colour
Comment
1
State IP
orange
Lights red if not connected
2
Bus state KNX TP
orange
Table 1. LED status display for factory reset aer first button press
Number
LED
Colour
Comment
1
State IP
green
2
Bus state KNX TP
blinking green
3
Telegram traffic IP
blinking green
no the same tempo as LED2
7
Programming LED
red
Table 2. LED status display for boot mode
page 11
module-electronic.ru

4.1 GENERAL
The host name is the name with that the device appears within the Windows network.
4 ETS DATABASE PARAMETERS
All screen shots are related to the IC-IP-S.1.0 database file R1-1f in ETS5.
Figure 3. General tab parameters
ETS Parameter
Setting
{Factory Default}
Comment
Host name
<30 characters allowed>
{KNX IP Interface}
Field to enter the device name providing an easy
search of the devices by ETS, by Windows Network
and by KNXnet/IP visualisation systems.
Table 3. General tab parameter settings
4.2 IP CONFIGURATION
Here, HTTP port and IP address assignment can be configured.
Figure 4. IP configuration tab parameters, DHCP on
page 12
module-electronic.ru

ETS Parameter
Setting
{Factory Default}
Comment
HTTP port
80
8080
{8080}
Select one of the two official system ports.
DHCP
do not use
use
{use}
If DHCP is used, no further IP parameters have to
be set.
Table 4. IP configuration tab parameter settings, DHCP on
Figure 5. IP configuration tab parameters, DHCP off
ETS Parameter
Setting
{Factory Default}
Comment
IP address
0-255.0-255.0-255.0-255
{0.0.0.0}
IP byte 1 to 4: manual input
Subnet mask
0-255.0-255.0-255.0-255
{255.255.255.0}
SM byte 1 to 4: manual input
Default gateway
0-255.0-255.0-255.0-255
{0.0.0.0}
DG byte 1 to 4: manual input
DNS server
0-255.0-255.0-255.0-255
{0.0.0.0}
DNS byte 1 to 4: manual input
Table 5. IP configuration tab parameter settings, DHCP off
page 13
module-electronic.ru

5 WEB FRONT-END
The web front-end can be used to read out IC-IP-S.1.0´s actual device parameters (HTTP port, IP address,
MAC address, …), to update its firmware and to adjust the (additional) tunneling addresses. To identify a
particular IC-IP-S.1.0 of a KNX network the Programming LED/Programming Mode can be remotely
switched on and off without pressing the on-device Programming Button.
To switch back from Boot Mode to normal operation in is necessary to run the firmware update
procedure and then abort, or wait for the 10 min timeout.
5.1 ACCESSING THE IC-IP-S.1.0 WEB FRONT-END
There are three ways to access the IC-IP-S.1.0. It can be accessed like a Microso Windows UPnP network
device (Windows7 or later) and by a web browser. For access by a web browser either the IP address or
the MAC address, together with the HTTP port, have to be known. How to use IP address and MAC address
with the browser´s URL bar is described in the following.
For access via web browser the HTTP port that is set by ETS (or the factory default parameter value)
has to be used.
IC-IP-S.1.0 is able to use both official HTTP system port (80 and 8080).
Factory default HTTP port is 8080.
page 14
module-electronic.ru

5.1.1 VIA WINDOWS NETWORK UPnP
Figure 6. IC-IP-S.1.0 as UPnP network device («KNX TP IP»)
When the UPnP network function is enabled, IC-IP-S.1.0 appears in the Windows Network. A click on the
IC-IP-S.1.0 network device opens the web front-end with the standard web browser. If IC-IP-S.1.0 is not
visible as an UPnP network device a manual restart is recommended. Aer that, the device becomes
visible in the list of network devices.
page 15
module-electronic.ru

5.1.2 VIA IP ADDRESS
When IP address and HTTP port (80 or 8080) are known, this information is sufficient to access the IC-IP-
S.1.0 web front-end by a web browser. The actual IP address is shown in the ETS list of Discovered
Interfaces.
Figure 7. Identifying IC-IP-S.1.0`s IP address with ETS
According to IC-IP-S.1.0´s pre-set IP configuration (HTTP port, IP address and DHCP, respectively) in the
URL bar has to be entered (without brackets):
http://{IP address}:{HTTP port}/
Example1: DHCP is not used. With the latest ETS download the IP address was set to 192.168.1.32 and
HTTP port was set to 80. In the browser´s URL bar has to be entered «http://192.168.1.32:80/».
Example2: With the latest ETS download HTTP port was set to 8080 and DHCP was activated. The DHCP
server assigned a free IP address to IC-IP-S.1.0 and ETS shows this IP address to be
192.168.1.201. In the browser´s URL bar has to be entered «http://192.168.1.201:8080/».
page 16
module-electronic.ru

5.1.3 VIA MAC ADDRESS
When NetBIOS is installed (by default on Windows systems and Linux systems containing SAMBA) the MAC
address that is printed on a label on the side of the IC-IP-S.1.0 housing can be used. Due to name
resolution is mandatory to establish communication by Host name, activation of NetBIOS is necessary.
Use the MAC address in the form of AA-BB-CC-XX-YY-ZZ and the pre-set HTTP port to be entered in the
browser´s URL bar as described here (without brackets):
http://knx-ipif-{XXYYZZ}:{HTTP port}/
Example1: On the housing side UIMip is labelled with MAC address D0-76-50-11-22-33 and the pre-set
HTTP port is 8080. Then, in the web browser´s URL bar has to be entered «http://knx-ipif-
112233:8080/».
5.2 DEVICE INFO
Aer accessing the web front-end the Device Info tab is shown. All general information about the current
device settings is visible.
Figure 8. Device info tab
page 17
module-electronic.ru

5.3 KNX
Here, all KNX specific addresses are shown. Setting changes can easily be checked. With a simple click on
«On» or «Off» Programming Mode can be switched on/off. This function is equivalent to a Programming
Button press. Together with the Device Info tab it is easy to distinguish the regarded device (with a certain
IP address or MAC address or serial number) from other similar devices in the same IP network.
Four tunneling addresses can be set. ETS sets the first tunneling address. With a click on «Set» the
remaining ones are set. Moreover, routing multicast address and serial number of the device are shown.
Figure 9. KNX tab
The web browser used has to support SVG graphics.
page 18
module-electronic.ru

5.4 FIRMWARE UPDATE / BOOT MODE
Under the Update tab the IC-IP-S.1.0 firmware can be updated via IP i.e. the Ethernet network like
described in following steps. During the remote update process IC-IP-S.1.0 enters Boot Mode. Then LEDs
1, 2, 3, and 7 light as described in Table 2.
If Boot Mode is already active only the web front-end instructions from step 3 to step 5 must be
followed (refresh, request update).
Boot Mode is still active aer device reset and aer factory reset.
To exit Boot Mode it is necessary to enter the Update tab of the web front-end. Then either the firmware
update has to be completed (if a new firmware is available) or the firmware update process has to be
stopped by a click on the «Abort» button. Aer that IC-IP-S.1.0 restarts and continues with normal
operation.
Step 1: Open the update tab of the web front-end.
Figure 10. Update tab
Step 2: Activate programming mode (KNX tab or programming button).
Figure 11. Update tab and activated programming button
page 19
module-electronic.ru

Step 3: Aer Programming Mode activation give a short press to the Function Button. Then
click on the «refresh» button (alternatively, refresh the browser).
Figure 13. Request update
Step 4: When the «request update» button appears it has to be pressed to select the update file
and enter «Boot Mode».
Figure 12. Update authorized
Step 5: The update file can be selected and uploaded. Clicking on the «Abort» button cancels
the firmware update procedure and the device exits Boot Mode.
Figure 14. Select update file
page 20
module-electronic.ru
