Kobalt KRH 124B-03 User manual

PH1996
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-888-3KOBALT (1-888-356-2258), 8 a.m. - 8 p.m., EST,
Monday - Friday.
ATTACH YOUR RECEIPT HERE
Serial Number Purchase Date
Español p. 17
ITEM #1260303/1260304
BRUSHLESS
ROTARY HAMMER
MODEL #KRH 124B-03

2
TABLE OF CONTENTS
Product Specications...................................................................................... 2
Packaging Contents.........................................................................................3
Safety Information............................................................................................ 4
Preparation....................................................................................................... 8
Operating Instructions...................................................................................... 9
Care and Maintenance...................................................................................15
Troubleshooting.............................................................................................. 15
Warranty.........................................................................................................15
PRODUCT SPECIFICATIONS
COMPONENT SPECIFICATION
Rated voltage 24V
No-load speed 0-1400/min
Rated impact 0-4500 IPM
Max. drilling dia. 7/8″ (concrete)
1-1/4″ (wood)
1/2″ (steel)
Tool holder SDS-plus
Operating temperature -4°F - 113°F (-20°C-45°C)
Charging temperature 41°F - 104°F (5°C-40°C)

3
PACKAGE CONTENTS
CBA D
E
F
G
J
H
I
PART DESCRIPTION PART DESCRIPTION
A Dust-protection cap F LED worklight
B Locking sleeve G Auxiliary handle
C Mode selector H Depth gauge
D Direction-of-rotation selector I Belt clip
EVariable-speed trigger switch JScrew
WARNING
• Remove the tool from the package and examine it carefully. Do not discard the carton or any
packaging material until all parts have been examined.
• If any part of the tool is missing or damaged, do not connect the plug to the power source or
use the tool until the part has been repaired or replaced. Failure to heed this warning could
result in serious injury.

4
SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble or operate
this product. If you have any questions regarding the product, please call customer service at
1-888-3KOBALT, 8 a.m. - 8 p.m., EST, Monday - Friday.
WARNING
• The operation of any power tool can result in foreign objects being thrown into your eyes,
which can result in severe eye damage. Before beginning power-tool operation, always wear
safety goggles or safety glasses with side shields and a full-face shield, when needed. We
recommend using a wide vision safety mask over eyeglasses or standard safety glasses
with shields. Always use eye protection marked to comply with ANSI Z87.1.
• Some dust created by power sanding, sawing, grinding, drilling, and other construction
activities contains chemicals known to the state of California to cause cancer, birth defects,
or other reproductive harm. Some examples of these chemicals are:
– Lead from lead-based paints
– Crystalline silica from bricks, cement, and other masonry products
– Arsenic and chromium from chemically-treated lumber
• Your risk from these exposures varies, depending upon how often you do this type of work.
To reduce your exposure to these chemicals:
– Work in a well-ventilated area.
– Work with approved safety equipment, such as dust masks that are specially designed to
lter out microscopic particles.
– Avoid prolonged contact with dust from power sanding, sawing, grinding, drilling, and
other construction activities. Wear protective clothing and wash exposed areas with soap
and water. Allowing dust to get into your mouth or eyes or to lie on the skin may promote
absorption of harmful chemicals.
Know the Tool
To operate this tool, carefully read this manual and all labels afxed to the tool before using it.
Keep this manual available for future reference.
Important
This tool should be serviced only by a qualied service technician.

5
SAFETY INFORMATION
Read All Instructions Thoroughly
Some of the following symbols may be used on this tool. Please study them and their meaning.
Proper interpretation of these symbols will allow you to operate the tool better and more safely.
SYMBOL DEFINITION SYMBOL DEFINITION
V Volts n0No-load Speed
Direct Current /min Revolutions or Strokes per Minute
W Watts IPM Impact per Minute
A danger, warning,
or caution. It means
‘Attention! Your safety
is involved.’
To reduce the risk of injury, user
must read instruction manual.
General Power Tool Safety Warnings
WARNING
• Read all safety warnings, instructions, illustrations and specications provided with this
power tool. Failure to follow all instructions listed below may result in electric shock, re and/
or serious injury.
Save all warnings and instructions for future reference
• Keep work area clean and well lit. Cluttered or dark areas invite accidents.
• Do not operate power tools in explosive atmospheres, such as in the presence of
ammable liquids, gases or dust. Power tools create sparks, which may ignite the dust or
fumes.
• Keep children and bystanders away while operating a power tool. Distractions can
cause you to lose control.
Electrical Safety
• Power tool plugs must match the outlet. Never modify the plug in any way. Do not use
any adaptor plugs with earthed (grounded) power tools. Unmodied plugs and matching
outlets will reduce the risk of electric shock.
• Avoid body contact with earthed or grounded surfaces such as pipes, radiators,
ranges and refrigerators. There is an increased risk of electric shock if your body is
earthed or grounded.
• Do not expose power tools to rain or wet conditions. Water entering a power tool will
increase the risk of electric shock.
• Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the
power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or
entangled cords increase the risk of electric shock.
• When operating a power tool outdoors, use an extension cord suitable for outdoor
use. Use of a cord suitable for outdoor use reduces the risk of electric shock.

6
SAFETY INFORMATION
• If operating a power tool in a damp location is unavoidable, use a residual current
device (RCD) protected supply. Use of an RCD reduces the risk of electric shock.
Personal Safety
• Stay alert, watch what you are doing and use common sense when operating a power
tool. Do not use a power tool while you are tired or under the inuence of drugs,
alcohol or medication. A moment of inattention while operating power tools may result in
serious personal injury.
• Use personal protective equipment. Always wear eye protection. Protective equipment
such as a dust mask, non-skid safety shoes, hard hat or hearing protection used for
appropriate conditions will reduce personal injuries
• Prevent unintentional starting. Ensure the switch is in the off-position before
connecting to power source and/or battery pack, picking up or carrying the tool.
Carrying power tools with your nger on the switch or energizing power tools that have the
switch on invites accidents.
• Remove any adjusting key or wrench before turning the power tool on. A wrench or a
key left attached to a rotating part of the power tool may result in personal injury.
• Do not overreach. Keep proper footing and balance at all times. This enables better
control of the power tool in unexpected situations.
• Dress properly. Do not wear loose clothing or jewelry. Keep your hair and clothing away
from moving parts. Loose clothes, jewelry or long hair can be caught in moving parts.
• If devices are provided for the connection of dust extraction and collection facilities,
ensure that these are connected and properly used. Use of dust collection can reduce
dust-related hazards
• Do not let familiarity gained from frequent use of tools allow you to become
complacent and ignore tool safety principles. A careless action can cause severe injury
within a faction of a second.
Power tool use and care
• Do not force the power tool. Use the correct power tool for your application. The
correct power tool will do the job better and safer at the rate for which it was designed.
• Do not use the power tool if the switch does not turn it on and off. Any power tool that
cannot be controlled with the switch is dangerous and must be repaired.
• Disconnect the plug from the power source and/or remove the battery pack,
if detachable, from the power tool before making any adjustments, changing
accessories, or storing power tools. Such preventive safety measures reduce the risk of
starting the power tool accidentally.
• Store idle power tools out of the reach of children and do not allow persons
unfamiliar with the power tool or these instructions to operate the power tool. Power
tools are dangerous in the hands of untrained users.
• Maintain power tools and accessories. Check for misalignment or binding of moving
parts, breakage of parts and any other condition that may affect the power tool’s
operation. If damaged, have the power tool repaired before use. Many accidents are
caused by poorly maintained power tools.
• Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to control.
• Use the power tool, accessories and tool bits etc. in accordance with these
instructions, taking into account the working conditions and the work to be
performed. Use of the power tool for operations different from those intended could result in
a hazardous situation.

7
SAFETY INFORMATION
• Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery
handles and grasping surfaces do not allow for safe handling and control of the tool in
unexpected situations.
Battery tool Use and Care
• Recharge only with the charger specied by the manufacturer. A charger that is suitable
for one type of battery pack may create a risk of re when used with another battery pack.
• Use power tools only with specically designated battery packs. Use of any other
battery packs may create a risk of injury and re.
BATTERY PACK CHARGER
KB 124-03; KB 224-03; KB 424-03;
KB 524-03; KB 624-03
KRC 2445-03;
KRC 2490-03
• When battery pack is not in use, keep it away from other metal objects, like paper
clips, coins, keys, nails, screws or other small metal objects, that can make a
connection from one terminal to another. Shorting the battery terminals together may
cause burns or a re.
• Under abusive conditions, liquid may be ejected from the battery; avoid contact. If
contact accidentally occurs, ush with water. If liquid contacts eyes, additionally seek
medical help. Liquid ejected from the battery may cause irritation or burns
• Do not use a battery pack or tool that is damaged or modied. Damaged or modied
batteries may exhibit unpredictable behavior resulting in re, explosion or risk of injury.
• Do not expose a battery pack or tool to re or excessive temperature. Exposure to re
or temperature above 130 °C may cause explosion.
• Follow all charging instructions and do not charge the battery pack or tool outside the
temperature range specied in the instructions. Charging improperly or at temperatures
outside the specied range may damage the battery and increase the risk of re.
Service
• Have your power tool serviced by a qualied repair person using only identical
replacement parts. This will ensure that the safety of the power tool is maintained.
• Never service damaged battery packs. Service of battery packs should only be performed
by the manufacturer or authorized service providers.
Specic Safety Warnings for Hammer
• Wear ear protectors. Exposure to noise can cause hearing loss.
• Use auxiliary handle(s), if supplied with the tool. Loss of control can cause personal
injury.
• Hold power tool by insulated gripping surfaces, when performing an operation where
the cutting accessory may contact hidden wiring. Cutting accessory contacting a “live”
wire may make exposed metal parts of the power tool “live” and could give the operator an
electric shock.
• Use suitable detectors to determine if utility lines are hidden in the work area or call
the local utility company for assistance. Contact with electric lines can lead to re and
electric shock. Damaging a gas line can lead to explosion. Penetrating a water line causes
property damage or may cause an electric shock.

8
SAFETY INFORMATION
• When working with the power tool, always hold it rmly with both hands and provide
for a secure stance. The power tool is guided more secure with both hands.
• Secure the workpiece. A workpiece clamped with clamping devices or in a vice is held
more secure than by hand.
• Always wait until the power tool has come to a complete stop before placing it down.
The tool insert can jam and lead to loss of control over the power tool.
PREPARATION
Know Your Rotary Hammer
This rotary hammer can be used for hammer drilling in concrete, brick, and stone, and for
light chiseling work; for drilling in wood and metal as well as for screwdriving with specied
accessories.
Before attempting to use the rotary hammer, familiarize yourself with all of its operating
features and safety requirements.
WARNING
• Do not allow familiarity with the rotary hammer to cause carelessness. Remember that one
careless moment is enough to cause severe injury. Before attempting to use any tool, be
sure to become familiar with all of the operating features and safety instructions.
• Do not attempt to modify this tool or create accessories not recommended for use with this
tool. Any such alteration or modication is misuse and could result in a hazardous condition
leading to possible serious personal injury.

9
OPERATING INSTRUCTIONS
1. To Attach Battery Pack
a. Place the direction-of-rotation selector (D) in
the center-lock position.
b. Align the raised portion on the battery pack
with the grooves on the bottom of the tool,
then slide the battery pack onto the tool, as
shown.
c. Make sure that the battery-release buttons
on the battery pack snap into place and the
battery pack is secured to the tool before
beginning operation.
NOTICE: When placing the battery pack on the
tool, be sure that the raised rib on the battery pack
aligns with the groove on the tool and the latches snap into place properly. Improper assembly
of the battery pack can cause damage to internal components.
To Detach Battery Pack
a. Place the direction-of-rotation selector (D) in the center-lock position.
b. Press the battery-release buttons to release the battery pack.
c. Pull forward on the battery pack to remove it from the tool.
WARNING
• Battery tools are always in operating condition. Therefore, the direction-of-rotation selector
(C) should always be in the center-lock position when the tool is not in use or when carrying
the rotary hammer at your side.
2. Direction-of-Rotation Selector
The direction of bit rotation is reversible and is
controlled by a selector (D) located above the
switch. With the rotary hammer held in the normal
operating position:
a. Press the direction-of-rotation selector (D) to
the left for forward rotation.
b. Press the direction-of-rotation selector to the
right for reverse rotation.
c. Setting the selector in the center (lock) position
helps reduce the possibility of accidental
starting when not in use.
The rotation-direction setting is not available for
chiseling mode.
NOTICE: To prevent gear damage, always allow the rotary hammer to come to a complete
stop before changing the direction of rotation.
NOTICE: The rotary hammer will not run unless the direction-of-rotation selector is fully
engaged to the left or right.
2
D
1
Battery-release
button

10
OPERATING INSTRUCTIONS
3. Variable-speed Trigger Switch
a. To turn the rotary hammer ON, press the
variable-speed trigger switch (E).
b. To turn it OFF, release the variable-speed
trigger switch.
c. The variable-speed trigger switch delivers
higher speed with increased trigger pressure
and lower speed with decreased trigger
pressure.
4. Mode Selector
WARNING
• ALWAYS place the direction-of-rotation selector
(D) in the center-lock position when not using
the tool, cleaning, or making adjustments.
Failure to do so could result in accidental
starting which can cause serious personal injury.
The mode selector (C) allows the tool to be set for
various applications. Rotate the selector until the
button snap-locks to change the operating mode.
Drilling mode : For drilling action in woods,
metals, plastics, or other materials and for
screwdriving.
Hammer drilling mode : For drilling with hammer action in concrete, brick, or similar hard
material.
Chiseling mode : For light chipping and chiseling applications.
Non-working mode : For use only to rotate a at chisel to the desired position.
NOTICE: Never change the mode setting when the tool is running. Otherwise, the machine
can be damaged.
4
C
3
E

11
OPERATING INSTRUCTIONS
5. LED Worklight
The LED worklight (F), located on the foot of the
rotary hammer, will illuminate when the trigger
switch is depressed. This provides additional light
on the surface of the workpiece for operation in
lower-light conditions.
The LED worklight will turn off after the trigger
switch is released.
The LED worklight will blink rapidly if the tool has
stopped working in order to protect internal
circuits; please wait for the tool to cool down, at
which point it can be started again.
The LED worklight will blink slowly to indicate
that the battery charge is very low.
6. Auxiliary Handle
WARNING
• ALWAYS place the direction-of-rotation selector
(D) in the center-lock position when not using
the tool, cleaning, or making adjustments.
Failure to do so could result in accidental
starting which can cause serious personal injury.
• This rotary hammer is equipped with an auxiliary
handle (G). For ease of operation, you can use
the handle with either the left or right hand.
The handle can be rotated to any postion 360°
around the tool.
To assembly the auxiliary handle:
a. Remove the battery from the tool.
b. Loosen the auxiliary handle by turning the handle counterclockwise.
c. Attach the auxiliary handle over the locking sleeve (B) to the end position.
d. Hand-tighten the handle by turning the handle clockwise.
To adjust the auxiliary handle assembly:
a. Remove the battery from the tool.
b. Loosen the auxiliary handle by turning the handle counterclockwise.
c. With the handle loose, turn the auxiliary handle to the desired operating position.
d. Hand-tighten the handle by turning the handle clockwise.
5
F
6
G

12
OPERATING INSTRUCTIONS
7. Depth Gauge
WARNING
• ALWAYS place the direction-of-rotation selector
(D) in the center-lock position when not using
the tool, cleaning, or making adjustments.
Failure to do so could result in accidental
starting which can cause serious personal injury.
• The rotary hammer is equipped with a depth
gauge (H) to set the drill depth when using the
tool.
a. Remove the battery from tool.
b. Press the clamp button on the auxiliary handle
(G), then insert the depth gauge through the
hexagonal hole in handle. Make sure that the side with ribs are facing downward.
c. Adjust the depth gauge to the desired position and then release the clamp button. The
depth gauge will be secured in the position.
8. Installing and Removing the Belt Clip
a. Align the rib of the belt clip (I) with the hole on
the base of the rotary hammer.
b. Insert the screw (J) and tighten the screw
securely with a Phillips screwdriver (not
included).
c. To remove the belt clip, use a Phillips
screwdriver to loosen the screw holding the
belt clip to the rotary hammer.
8
I
J
7
G
H
Depth
Clamp
Button

13
OPERATING INSTRUCTIONS
9. Changing Accessory
WARNING
• ALWAYS place the direction-of-rotation selector
(D) in the center-WARNING: ALWAYS place the
direction-of-rotation selector (D) in the center-
lock position when not using the tool, cleaning,
or making adjustments. Failure to do so could
result in accidental starting which can cause
serious personal injury.
Accessory selection
For drilling in wood, metal, and plastic and for
screwdriving, use the corresponding SDS-plus
adapter (not included) to use the normal bit which
is not SDS-plus type.
For hammer drilling/chiseling, use SDS-plus bits.
To Install the Accessory
The dust-protection cap prevents the entry of most
drilling dust into the tool holder during operation.
When installing the bit/adapter, take care that the
dust-protection cap is not damaged. Replace it
immediately if damaged. We recommend having
this carried out by an after-sales service provider.
a. Clean and lightly grease the shank end of the
SDS-plus accessory.
b. Insert the accessory into the chuck with a
turning motion until it engages. The accessory
locks in position automatically.
c. Pull accessory to check that it is locked correctly.
To Remove the Accessory
a. Pull back the locking sleeve (B).
b. Hold the locking sleeve and remove the accessory.
The SDS plus accessory is designed freedom of movement which causes eccentricity when
tool is off-loaded; however, the accessory automatically centers itself during operation without
affecting drilling precision.
NOTE: Do not use bits/chisels with damaged shanks.
9a B
A
9b B

14
OPERATING INSTRUCTIONS
10. Operating the Rotary Hammer
WARNING
• To reduce the risk of explosion, check the utility
lines electricity, gas or water supply line are
hidden in the work area before any work.
• When working at low temperatures:
The hammering mechanism begins to operate
only when the tool has reached a minimum
operating temperature.
Press the tip of the hammer bit briey against
the work surface while power on the tool. Repeat
this procedure if necessary until reaches the
minimum operating temperature.
Drilling
When drilling in wood, metal, and plastic and for
screwdriving with accessories without SDS-plus
(e.g. drill bit with cylindrical shaft), the corresponding
SDS-plus adapter (not included) should be used.
a. Install the suitable adapter.
b. Set the tool at drilling mode , and set the
depth gauge to the desired drilling depth.
c. Hold the rotary hammer rmly with both hands.
d. Support the workpiece near the drilling site.
Clamp the workpiece securely so that the
workpiece will not move while drilling.
e. When drilling ferrous metal, pre-drill a smaller
hole and lubricate drill bit with oil.
f. Turn on the tool and start drilling.
g. Always waiting for the tool to stop completely
before place it on the work piece.
Hammer Drilling
WARNING
• Do not use bit without SDS-plus for hammer
drilling. Bit and drill chuck would be damaged by
hammer drilling.
• When working with a SDS-plus bit, set the operating
mode selector to hammer drilling mode .
Chipping and Chiseling
a. Set the mode selector (C) to the chiseling mode.
b. Install the appropriate chisel.
c. To adjust the head of the chisel to the desired
angle, set the operating mode to non-working
mode and rotate the chisel by hand. Return the operating mode to the Chiseling mode .
d. Adjust the auxiliary handle as required.
e. Hold the tool rmly with both hands.
f. Turn on the tool and start working.
NOTE: Turn the tool on and apply slight pressure on the tool so that the tool will not bounce
around and uncontrolled. Pressing very hard on the tool will not increase the efciency.
10a
10b
10c

15
CARE AND MAINTENANCE
All maintenance should only be carried out by a qualied service technician.
Cleaning
Before cleaning or performing any maintenance, disconnect the plug from the power source.
For safe and proper operation, always keep the tool and its ventilation slots clean.
Always use only a soft, dry cloth to clean your rotary hammer; never use detergent or alcohol.
TROUBLESHOOTING
WARNING
• Turn the switch to the “OFF” position, place the direction-of-rotation selector (D) in the
center-lock position before performing troubleshooting procedures.
PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION
Tool does not work. Low battery capacity. Charge the battery pack.
Bit doesn’t rotate. Operating mode selector
knob not engaged.
Move the operating mode selector until it
engages.
No hammering
action and the tool
wobbles.
1. The tool is too cold.
2. Operating mode
selector is set to
drilling mode.
1. Allow tool to reach the minimum
operating temperature.
2. Set operating mode selector to hammer
drilling mode or chiseling mode.
WARRANTY
For 5 years from the date of purchase, the tool is warranted for the original purchaser to be
free from defects in material and workmanship. This guarantee does not cover damage due
to abuse, normal wear, improper maintenance, neglect, unauthorized repair/alteration, or
expendable parts and accessories expected to become unusable after a reasonable period of
use. This warranty is limited to 90 days for commercial and rental use.
If you think your product meets the above guarantee criteria, please return it to the place of
purchase with valid proof of purchase and the defective product will be repaired or replaced at
no charge. This guarantee gives you specic legal rights, and you may also have other rights
that vary from state to state.

Printed in China

17
¿Preguntas, problemas, piezas faltantes? Antes de volver a la tienda, llame a nuestro
Departamento de Servicio al Cliente al 1-888-3KOBALT (1-888-356-2258), de lunes a
viernes de 8 a.m. a 8 p.m., hora estándar del Este.
ADJUNTE SU RECIBO AQUÍ
Número de serie Fecha de compra
ARTÍCULO #1260303/1260304
TALADRO PERCUTOR
SIN ESCOBILLAS
MODELO #KRH 124B-03

18
ÍNDICE
Especicaciones del producto........................................................................ 18
Contenido del paquete................................................................................... 19
Información de seguridad............................................................................... 20
Preparación....................................................................................................24
Instrucciones de funcionamiento.................................................................... 25
Cuidado y mantenimiento ..............................................................................31
Solución de problemas................................................................................... 31
Garantía .........................................................................................................32
ESPECIFICACIONES DEL PRODUCTO
COMPONENTE ESPECIFICACIONES
Rango de voltaje 24 voltios
Velocidad sin carga 0 a 1400/min
Clasicación contra impactos 0 a 4500 IPM
Diámetro de perforación máx. 7/8 pulg. (concreto)
1-1/4 pulg. (madera)
1/2 pulg. (acero)
Soporte para herramientas SDS-plus
Temperatura de funcionamiento -20 °C a 45 °C (-4 °F a 113 °F)
Temperatura de carga 5°C a 40°C (41°F a 104°F)

19
CONTENIDO DEL PAQUETE
CBA D
E
F
G
J
H
I
PIEZA DESCRIPCIÓN PART DESCRIPTION
ATapa de protección contra el polvo FLuz de trabajo LED
BManguito de jación G Manija auxiliar
C Selector de modo H Medidor de profundidad
D Selector de dirección de rotación I Sujetador para cinturón
EInterruptor tipo gatillo de
velocidad variable J Tornillo
ADVERTENCIA
• Retire la herramienta del paquete y examínela con cuidado. No deseche la caja ni ningún
material de embalaje hasta después de examinar todas las piezas.
• Si falta alguna pieza o si alguna pieza está dañada, no je el paquete de baterías ni use
la herramienta hasta reparar o reemplazar la pieza. No seguir esta advertencia podría
provocar lesiones graves.

20
INFORMACIÓN DE SEGURIDAD
Lea y comprenda completamente este manual antes de intentar ensamblar u operar este
producto. Si tiene preguntas relacionadas con el producto, llame al Departamento de Servicio
al Cliente al 1-888-3KOBALT, de lunes a viernes de 8 am. a 8 p.m., hora estándar del Este.
ADVERTENCIA
• La operación de cualquier herramienta eléctrica puede arrojar objetos extraños a sus ojos
y, de esta manera, causar graves daños oculares. Use siempre lentes o gafas de seguridad
con protecciones laterales y, cuando sea necesario, una mascarilla que cubra todo el rostro
antes de comenzar a operar una herramienta eléctrica. Recomendamos usar una máscara
de seguridad de visión amplia sobre los lentes o gafas de seguridad con protecciones
estándar. Siempre use lentes de protección que cumplan con la norma ANSI Z87.1.
• Parte del polvo producido por el lijado, serruchado, trituración y taladrado eléctrico, y otras
actividades de construcción, contiene sustancias químicas reconocidas por el estado de
California como causantes de cáncer, defectos congénitos u otros daños en el aparato
reproductivo. Algunos ejemplos de estos productos químicos son:
– Plomo de pinturas a base de plomo.
– Sílice cristalina de ladrillos, cemento y otros productos de mampostería.
– Arsénico y cromo de madera tratada con químicos.
• El riesgo que corre debido a la exposición a estos químicos varía según la frecuencia con
que realiza este tipo de trabajo. Para disminuir su exposición a estas sustancias químicas:
– Trabaje en un área bien ventilada.
– Trabaje con equipo de seguridad aprobado, como las mascarillas antipolvo
especialmente diseñadas para ltrar partículas microscópicas.
– Evite el contacto prolongado con el polvo producido por el uso de lijas, sierras,
trituradoras, taladros eléctricos y otras actividades de construcción. Use ropa protectora
y lave todas las áreas expuestas del cuerpo con agua y jabón. Si el polvo ingresa a la
boca o a los ojos, o cae sobre la piel, podría provocar la absorción de productos químicos
dañinos.
Conozca la herramienta
Para operar esta herramienta, lea cuidadosamente este manual y las etiquetas jadas a la
herramienta antes de usarla. Guarde este manual para referencia futura.
Importante
Solo un técnico calicado puede reparar esta herramienta.
