Kodak PIXPRO WPZ2 User manual

User Manual
DIGITAL CAMERA
KODAK PIXPRO WPZ2

1
Declaration of Conformity
Responsible Party: JK Imaging Ltd.
Address: JK Imaging Ltd., 17239 So. Main Street, Gardena, CA 90248 USA
Company website: kodakpixpro.com
INDUSTRY CANADA
This device complies with Canadian RSS210.
This device complies with Industry Canada license-exempt RSS standard (s).Operation is subject to the
following two conditions: (1) this device may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation of the device.
Radiation Exposure Statement:
This product complies with the Canadian portable RF exposure limit set forth for an uncontrolled
environment and is safe for intended operation as described in this manual. Additional RF exposure
reduction can be achieved if the product can be kept as far as possible from the user body or set the device
to lower output power if such function is available.
BEFORE YOU START

2
For Customers in Europe
This symbol [crossed-out wheel bin WEEE Annex IV] indicates separate collection of electrical
waste and electronic equipment in the European countries. Please do not throw the equipment into
domestic refuse. Please use the return and collection systems available in your country for proper,
safe disposal of this product.
“CE” mark indicates that this product complies with the European requirements for safety, health,
environment and customer protection. “CE” marked cameras are intended for sales in Europe.
Europe – EU Declaration of Conformity
This device complies with the essential requirements of the R&TTE Directive 2014/53/EU. The
following test methods have been applied in order to provepresumption of conformity with the
essential requirements of the R&TTE Directive 2014/53/EU:
- EN 609501: 2006+A11:2009 +A1:2010 +A12:2011
Safety of Information Technology Equipment
- EN 50566: 2013
Product standard to demonstrate compliance of radio frequency ields from handheld and body-
mounted wireless communication devices used by the general public (30 MHz — 6 GHz)
- EN 622092: 2010
Human exposure to radio frequency ields from handheld and bodymounted wireless communication
devices — Human models, instrumentation, and procedures
Part 2: Procedure to determine the speciic absorption rate (SAR) for wireless communication devices
used in close proximity to the human body (frequency range of 30 MHz to 6 GHz)

3
- EN 300 328 V1.8.1 : 2012
Electromagnetic compatibility and Radio spectrum Matters (ERM); Wideband Transmission systems;
Data transmission equipment operating in the 2.4 GHz ISM band and using spread spectrum
modulation techniques; Harmonized EN covering essential requirements under article 3.2 of the
R&TTE Directive.
- EN 301 4891 V1.9.2: 2011
Electromagnetic compatibility and Radio Spectrum Matters (ERM); Electro Magnetic Compatibility
(EMC) standard for radio equipment and services; Part 1: Common technical requirements.
- EN 301 48917 V2.2.1:2012
Electromagnetic compatibility and Radio spectrum Matters (ERM); Electro Magnetic Compatibility
(EMC) standard for radio equipment and services; Part 17: Speciic conditions for 2.4 GHz wideband
transmission systems and 5 GHz high performance RLAN equipment.
Manufacturer: Sintai Optical (Shenzhen) Co., Ltd
Address: Qiwei Ind Sec, 1st, 2nd,& 3RD Bldg, Lisonglang Village, Gongming Town, Bao’an
District, Shenzhen, Guangdong, China
Batteries: Please dispose of used batteries at designated collection centers.
Packaging: Please follow local regulations for the recycling of packaging.
For Customers in the U.S.A.
Federal Communication Commission Interference Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.

4
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is encouraged to try to correct the interference
by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modiications not expressly approved by the party responsible for compliance
could void the user’s authority to operate this equipment.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
Radiation Exposure Statement:
This product complies with the FCC portable RF exposure limit set forth for an uncontrolled environment
and is safe for intended operation as described in this manual. Additional RF exposure reduction can be
achieved if the product can be kept as far as possible from the user body or set the device to lower output
power if such function is available.

5
About this Manual
Thank you for purchasing this KODAK PIXPRO Digital Camera. Please read this manual carefully and keep it
in a safe place for future reference.
JK Imaging Ltd. reserves all rights of this document. No part of this published manual may be
reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language or
computer language, in any form, by any means, without the prior written permission of JK Imaging Ltd.
All trademarks mentioned in this manual are used for identiication purposes only and are properties of
their respective owners.
This manual provides you with instructions on how to use your new KODAK PIXPRO Digital Camera. Every
eort has been made to ensure that the contents of this manual are accurate; however JK Imaging Ltd.
reserves the right to make changes without notice.
Throughout this manual, the following symbols are used to help you locate information quickly and
easily:
Indicates useful information.
The following symbols may be used throughout this manual to facilitate your understanding of how to
operate the camera:
[Item properties]: The optional properties in the camera interface are indicated by the [ ] symbol.

6
If there is dust, sand or other foreign materials on
the waterproof rubber of the battery cover and its
contact surface, please wipe it with a clean, dry
and lint free cloth as soon as possible.
Before using the product underwater, make sure
that there is no damage to or foreign debris on
the waterproof rubber gasket. Then close the
battery cover tightly to ensure the waterproof
capability of the product.
Waterproof rubber with scratches and cracks
will allow water to penetrate into the product.
Contact customer service immediately
for maintenance with replacement of new
waterproof rubber.
SAFETY NOTES
Waterproof / Dustproof / Shockproof
JIS / IEC waterproof grade 8 (IPX8).
JIS / IEC dustproof grade 6 (IP6X).
Height for shockproof rating is 2m (6.6 feet).
Waterprooing Notes:
Do not use the product below 15 meters (49.2
feet) underwater. The product can remain
waterproof for one hour at the depth of 15m
(49.2 feet).
Do not use this product in a geothermal spring
or in water at a temperature greater than 40 °C
(104°F).
Please do not open the battery cover
underwater.
If water accidentally comes in contact with the
product, please do not open the battery cover.
Turn the product o, and dry it with a clean, dry
and lint free cloth. Then open the battery cover,
and remove the battery and the memory card.
When opening the battery cover, if there are
water drops on the contact surface between
the inside of the battery cover and the body,
please dry the water drops.
After using the product in water or near sand,
mud or other foreign materials, please rinse it
with clean water (close the battery cover before
cleaning). After cleaning, dry the product with a
clean, dry and lint free cloth.
Waterproof Rubber

7
Safety Notes for this Camera
Do not drop the camera or allow it to hit solid
objects.
Do not attempt to disassemble or repair the
camera.
Do not use or store the camera in dusty places
or on a beach to help prevent dust or sand from
entering the camera, causing possible damage.
Do not use or store the camera in a hot
environment or in direct sunlight.
Do not use or store the camera near powerful
magnetic ields, for example near a magnet or
transformer.
Avoid touching the lens of the camera.
Do not expose the camera to direct sunlight for
a long period of time.
To prevent the camera from being damaged by
moisture, do not use or store the camera in very
humid environments, such as in rain or near
bodies of water.
If water accidentally comes in contact with
the interior of the camera, turn the camera
o immediately, remove the battery and the
memory card and dry it completely within 24
hours.
When you take the camera from a cold
environment to a warmer environment,
condensation may occur. Please wait for a
reasonable period of time before you turn the
camera on.
Make sure the camera is turned o before you
remove the battery and memory card.
When you clean the body of the camera, do
not use abrasive, alcohol-based or organic
cleansers or solvents.
Use a professional lens cleaning cloth and
appropriate cleaner to wipe and clean the lens.
Download your photos and remove the memory
card when you are going to store the camera
for long periods of time.
If this camera is not in use for a long period of
time, please keep it in a dry and clean storage
location.
Our company will not pay compensation for any
failure of playback of pictures or videos caused
by improper operation.

8
Safety Notes for Battery
Please use a battery that is the same type as the
one included.
Please use the included USB cable and AC
adapter to charge the battery inside the
camera.
If battery luid leaks inside the camera, contact
our customer service department immediately.
If battery luid leaks onto your skin, rinse your
skin with clean water and seek immediate
medical attention.
Disposal of used batteries should be carried
out in accordance with your local (national or
regional) regulations.
To prevent the battery from being damaged,
do not drop the battery or allow it to hit solid
objects or to be scratched by foreign objects.
Do not let the battery come in contact with
metal objects (including coins) to avoid short
circuiting, discharging, excessive heat or
possible leakage.
Do not attempt to disassemble the battery.
Do not expose the battery to water. Always keep
the battery contacts dry.
Do not heat the battery or throw it into a ire to
avoid a possible explosion.
Do not store the battery in a hot environment or in
direct sunlight.
If the battery overheats during charging or use,
stop charging or stop use immediately. Turn o
the product, remove the battery carefully and
wait until it cools down.
When the camera is stored for a long period of
time, remove the battery and keep it in a safe,
dry place that is not accessible to infants and
children.
In colder environments, the performance of the
battery could be noticeably reduced.
When you install the battery, align the battery
markings according to the positive and
negative markings inside the camera battery
compartment. Never force the battery into the
battery compartment.

9
Safety Notes for Memory Cards
The memory card referred to in this user manual
is a microSD card/microSDHC card that is Class
4 or higher and no larger than 32GB.
We highly suggest buying only well-known,
name brand memory cards to ensure peak
performance and reliability.
Format the memory card using the camera
before you use it to store photo or video iles or
when you insert a new memory card.
Do not drop the memory card or allow it to hit
solid objects to avoid damaging it.
Do not attempt to disassemble or repair the
memory card.
Do not expose the memory card to water.
Always keep it dry.
Do not remove the memory card when
the camera is turned on. Otherwise, the
memory card and photo/video iles could be
permanently damaged.
Do not directly edit the data on the memory
card. Copy the data to your computer before
you edit iles.
When the camera is stored for long periods
of time, be sure to download your photos and
remove the memory card. Store the memory
card in a dry environment.
Do not modify the name of the iles or folders
of the memory card using your computer.
Modifying the ile names may cause the iles to
not be recognized on the camera or a possible
permanent error may occur.
A photo taken with the camera will be stored in
the folder that is automatically generated on the
memory card. Do not store photos that are not
taken using this camera in these folders as the
pictures cannot be recognized during playback.
When you insert the memory card, make sure
the notch of the card matches the markings on
the top of the camera card slot.

10
Other Safety Notes
Do not disconnect the power or turn the camera o during the updating process. Doing so may cause
incorrect data to be written and the camera may not power on later.
Do not hang the neck strap of the camera around the neck of a child.
When using your camera on an airplane, observe the relevant rules speciied by the airline and FAA
regulations.
Due to the limitations of manufacturing technology, the LCD may have a few dead or bright pixels. These
pixels do no eect the quality or performance of the camera, photos or video.
In a humid environment, only wipe LCD protective cover with a soft, dry, cleaning cloth.
If the LCD screen is damaged, pay particular attention to the liquid crystal in the screen. If any of the
following situations arise, take the recommended immediate action indicated below:
1. If liquid crystal comes in contact with your skin, please wipe with a dry cloth, wash thoroughly with
soap, and rinse with plenty of clean water.
2. If liquid crystal gets into your eye, lush the eye immediately with plenty of clean water for at least 15
minutes and then seek for medical assistance.
3. If liquid crystal is swallowed, immediately lush your mouth thoroughly with clean water and induce
vomiting. Seek for medical assistance.

11
BEFORE YOU START....................... 1
SAFETY NOTES .............................. 6
CONTENTS..................................... 11
GETTING STARTED......................... 15
Accessories Included................................... 15
Part Names ................................................... 16
Installing Battery and Micro SD Memory
Card .............................................................. 18
Charging the Battery.................................... 20
Turning Camera On and O......................... 21
How to Take Pictures.................................... 21
Set your Language, Date/Time.................... 22
Set your Language, Date/Time after the
First Power-On........................................ 22
Resetting your Language....................... 22
Resetting Date/Time .............................. 23
MODE OVERVIEW .......................... 24
Display Setting ............................................. 24
LCD Screen Display...................................... 25
Overview of the Screen Icons in Photo
Shooting Mode ...................................... 25
Overview of the Screen Icons in Movie
Mode....................................................... 26
Using the Mode Button ................................ 27
Auto Mode .................................................... 28
Program AE................................................... 30
Manual Mode................................................ 30
Movie Mode.................................................. 31
Scene Mode (SCN)....................................... 32
Panorama Mode .............................. 35
Anti-Shake ....................................... 36
Underwater Mode ........................................ 37
CONTENTS

12
Wi-Fi® Mode.................................................. 38
AP Mode ................................................. 39
Station .................................................... 40
Setting .................................................... 43
BASIC OPERATION......................... 45
Using the Zoom Function............................. 45
Macro Mode.................................................. 46
Self-Timer Setting......................................... 47
Flash Mode ................................................... 48
EV Setting ..................................................... 49
Exposure Compensation ....................... 49
ISO.......................................................... 50
Shutter Adjustment................................ 50
Using Quick Recording ................................ 51
PLAYBACK ...................................... 52
Overview of the Screen Icons in Playback
Mode............................................................. 52
Viewing Photos and Videos ......................... 53
Thumbnail View............................................ 54
Using Zoom Playback (for Still Pictures
Only) ............................................................. 55
Continuous Capture Group Playback.......... 56
Animation Panorama Play ............................ 57
Slideshow ..................................................... 58
Deleting Photos and Videos......................... 59
USING THE MENUS........................ 60
Photo Setup Menu........................................ 60
Expo Metering (Exposure Metering) ..... 60
Image Size.............................................. 61
Continuous Auto Focus (AF )................. 61
Continuous Shot .................................... 62
Focus Setting ......................................... 63

13
White Balance Setting ........................... 63
Color Eect ............................................ 64
Select Scene .......................................... 65
Photo Shooting Setting Menu ..................... 67
Quality .................................................... 67
Auto Focus (AF) Assist Beam................. 68
Digital Zoom........................................... 68
Date Imprint ........................................... 69
Quick Review.......................................... 69
Face Detection ....................................... 70
Movie Menu .................................................. 71
Expo Metering (Exposure Metering) ..... 71
Video Quality.......................................... 72
Color Eect ............................................ 73
Movie Setting Menu ..................................... 74
Digital Zoom........................................... 74
Playback Menu ............................................. 75
Display Mode.......................................... 75
HDR......................................................... 76
Red-Eye Reduction................................. 76
Rotate ..................................................... 77
Resize ..................................................... 77
Color ...................................................... 78
Playback Setting Menu ................................ 79
Protect.................................................... 80
Delete ..................................................... 81
DPOF (Digital Print Order Format)......... 82
Trim......................................................... 82
Setup Menu .................................................. 83
Power Saver............................................ 84
Sound Settings....................................... 84
Language................................................ 85
World Time ............................................. 85
Date & Time............................................ 85

14
LCD Brightness....................................... 85
SD Card /Firmware....................................... 86
Format ................................................... 87
Copy to Card.......................................... 87
File Numbering....................................... 88
Reset....................................................... 88
Firmware (FW) Version ........................... 89
CONNECTIONS.............................. 90
Connecting to a Computer.......................... 90
Setting the USB Mode ........................... 90
Transferring Files to Your Computer ..... 91
Connecting to PICTBRIDGE™ Compatible
Printers.......................................................... 92
Setting the USB Mode ........................... 92
Connecting to your Printer.................... 93
Using the PICTBRIDGE™ Menu..................... 94
Print (with Date) ..................................... 94
Print (without Date)................................ 95
Print Index .............................................. 96
Print DPOF Images ................................. 97
Exit.......................................................... 97
APPENDICES .................................. 98
Speciications............................................... 98
Prompts and Warning Messages ................. 102
Troubleshooting ........................................... 106

15
GETTING STARTED
Your camera box should contain the camera model you purchased along with the following accessories.
If anything is missing or appears to be damaged, please contact your retailer irst or our customer service
center. (The AC Adapters may be a little dierent in shape due to the dierence of countries or regions this
type of cameras are sold to, and are subject to matching the physical product).
Accessories Included
Micro USB Cable
Warranty Card
AC Adapter Wrist StrapRechargeable
Li-ion Battery
Quick Start Guide
Quick Start Guide Service Card
STOP

16
Part Names
8
7
63
1 24 5
1. Strap Eyelet
2. Shutter Button
3. Power Button
4. Auto Focus (AF) Assist Beam/
Self-Timer Lamp
5. Speaker
6. Microphone
7. Flash Lamp
8. Lens

17
910
11
12
13
14
15
16
17
19
20
22212324
18
25
26
9. Mode Button
10. Zoom Button
11. Indicator Lamp
12. Quick Video Recording Button
13. Display Button/Arrow Button (Up)
14. Flash Button/Arrow Button (Right)
15. SET Button
16. Delete Button/Self-Timer Button/
Arrow Button (Down)
17. Playback Button
18. Menu Button
19. Battery Cover Door
20. Battery Cover Door (Open) Toggle
Switch
21. Battery Cover Door Lock
22. Macro Button/
Arrow Button (Left)
23. LCD
24. Tripod Socket (1/4’’ Standard)
25. Micro USB Port
26. Micro SD Card Slot (32GB max)

18
2. Insert the battery into the battery compartment
as shown in step ③being sure to line up metal
contacts on bottom of battery with the contacts
in slot. Push the battery down until it locks in
place.
3
1. Unlock the battery cover door lock as shown
in step ①, push the battery cover door open
switch to open the battery cover door as shown
in step ②.
2
1
Installing Battery and Micro SD Memory Card
Battery
Lock Knob

19
4. Close the battery cover door as shown in step
⑤, push the battery cover door switch to close
the battery cover door as shown in step ⑥and
be sure to lock the battery cover door latch as
shown in step ⑦.
75
6
3. Insert the Micro SD memory card (not to exceed
32GB) into the memory card slot as shown
in step ④, push exposed edge of the Micro
SD memory card fully into the slot with your
ingertip.
4
A micro SD memory card is NOT included
with this camera packaging and needs to
be purchased separately. This camera takes
a microSD/microSDHC memory card. We
recommend using a name brand memory
card that is Class 4 or higher and has a
capacity of 4GB to 32GB. This camera is not
compatible with standard SD cards.
To remove your memory card, open the
battery cover door, gently press the memory
card to eject it and remove it carefully.
